Page 1

SY-6IBM

Motherboard

Quick Start Guide

Tested To Comply With FCC Standards

FOR HOME OR OFFICE USE

POST CONSUMER RECYCLED PAPER

100%

Hardware

Installation

Quick BIOS

Setup

Introduction

The SOYO CD

Page 2

SOYO™

SY-6IBM Motherboard

Pentium® III, Pentium® II & CeleronTM processors 82440 BX AGP/PCI Motherboard 3D Audio & AGP built-in 66 & 100 MHz Front Side Bus supported Micro-ATX Form Factor

Trademarks:

Soyo is a registered trademark of Soyo Computer Inc. All trademarks are the property of their owners.

Product Rights:

Product and corporate names mentioned in this publication are used for identification purposes only and may be registered trademarks or copyrights of their respective companies.

All rights reserved. This manual is copyrighted by Soyo Computer Inc. You may not reproduce, transmit, transcribe, store in a retrieval system, or translate into any language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of this publication without express written permission of Soyo Computer Inc.

Disclaimer:

Soyo Computer Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to revise the manual or make changes in the specifications of the product described within it at any time without notice and without obligation to notify any person of such revision or change. The information contained in this manual is provided for general use by our customers. Our customers should be aware that the personal computer field is the subject of many patents. Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.

Restricted Rights Legend:

Use, duplication, or disclosure by the Government is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at

252.277-7013.

About This Guide:

This Quick Start Guide is for assisting system manufacturers and end users in setting up and installing the Motherboard. Information in this guide has been carefully checked for reliability; however, no guarantee is given as to the correctness of the contents. The information in this document is subject to change without notice.

If you need any further information, please visit our Web Site on the Internet. The address is

"http://www.soyo.com.tw".

6IBM Serial - Version 1.2 - Edition: August 1999

* These specifications are subject to change without notice

Page 3

SY-6IBM

Quick Start Guide

Introduction

Congratulations on your purchase of the

SY-6IBM

Motherboard. This Quick Start Guide

describes the steps for installing and setting up your new Motherboard. This guide is designed for all users to provide the basic steps of Motherboard setting and

operation. For further information, please refer to SY-6IBM Motherboard User's Guide and Technical Reference online manual included on the CD-ROM packed with your Motherboard.

Unpacking

When unpacking the Motherboard, check for the following items:

The SY-6IBM 82440 BX AGP/PCI Motherboard

This Quick Start Guide

The Installation CD-ROM

SOYO 3-in-1 Bonus Pack CD-ROM (Norton AntiVirus, Ghost and Virtual Drive)

The CPU Retention Set

One IDE Device Flat Cable

u One Floppy Disk Drive Flat Cable

u Serial port flat cable with a 9-pin connector bracket

Page 4

SY-6IBM

Quick Start Guide

Introduction

SY-6IBM Motherboard Layout

Key Features

Supports Intel Pentium® III processor (450600MHz), Pentium® II processor (233450MHz) & Celeron

processor (266-

433MHz

)

Easy CPU settings in BIOS with the “SOYO COMBO Setup”.

3D YAMAHA YMF740 Audio

ATI Rage 128 Graphics/Video with 8MB Video memory on board

Auto-detect CPU voltage

PC98, APM, ACPI, Ultra DMA/33

Power-on by modem or alarm

Supports Wake-On-LAN (WOL)

Supports Power-On by PS/2 Keyboard

3 x 32-bit bus mastering PCI slots

1 x 16-bit ISA slot

2 x USB ports

1 x IrDA port

Supports multiple-boot function

ATX power connector

Power failure resume

Y2K Complaint

COM 1

VGA

PRT

USB 1

USB 2

PS/2 KB Connector

PS/2 Mouse

Connector

PCI Slot #1

PCI Slot #2

PCI Slot #3

Intel

82371EB

IR1

CPUFAN

COM2

FDC

ISA Slot #1

ATX

Power

JP1

CHAFAN

Flash BIOS

YMF740-V

YAMAHA

W83977EF

-AW

Winbond

Game Port LINE-OUT LINE-IN

MIC JACK

W83781D

8 2 8 AC

Hardware

Monitoring

WOL

Header

JP44

Speaker

Keylock

Power LED

Reset

PWRBT

Turbo

LED

HDD LED

Winbond W83782M

JP5

CMOS Clear

Jumper

JP8

JP3

3 1

ATI

RAGE 128

Lithium

Battery

IDE 2

IDE 1

DIMM 1

DIMM 2

DIMM 3

Slot 1

Intel

82443 BX

AC97

Codec

JP10

Page 5

SY-6IBM

Quick Start Guide

Hardware

Installation

To avoid damage to your Motherboard, follow these simple rules while

handling this equipment:

Before handling the Motherboard, ground yourself by grasping an unpainted portion

of the system's metal chassis.

Remove the Motherboard from its anti-static packaging. Hold it by the edges and

avoid touching its components.

Check the Motherboard for damage. If any chip appears loose, press carefully to seat

it firmly in its socket.

Follow the directions in this section designed to guide you through a quick and correct installation of your new

SY-6IBM

Motherboard. For detailed information, please refer to SY-

6IBM Motherboard User's Guide and Technical Reference online manual included on the

CD-ROM packed with your Motherboard.

PREPARATIONS

Gather and prepare all the necessary hardware equipment to complete the installation successfully:

Slot 1 processor with built-in CPU cooling fan (boxed type)

SDRAM module

Computer case and chassis with adequate power supply unit

Monitor

PS/2 Keyboard

Pointing Device (PS/2 Mouse)

Speaker(s) (optional)

Disk Drives: HDD, CD-ROM, Floppy drive…

External Peripherals: Printer, Plotter, and Modem (optional)

Internal Peripherals: Modem and LAN cards (optional)

Notice 1:

This Motherboard features one built-in VGA port and three built-in audio-stereo

ports. Therefore you do not need to install neither a VGA card nor a sound card.

Notice 2:

If you want to use an external speaker connected to "Line-out" port, please make

sure to use an "amplified speaker" that can generate proper output sound volume.

Page 6

SY-6IBM

Quick Start Guide

Hardware

Installation

Install the Motherboard

Follow the steps below in order to perform the installation of your new

SY-6IBM

Motherboard.

Step 1. Install the CPU

Mark your CPU Frequency:

Record the working frequency of your CPU

that should be clearly marked on the CPU cover.

FSB 66MHz

266MHz (66 x 4.0) 333MHz (66 x 5.0) 400MHz (66 x 6.0) 300MHz (66 x 4.5) 366MHz (66 x 5.5) 433MHz (66 x 6.5)

FSB 100MHz

350MHz (100 x 3. 5) 450MHz (100 x 4.5) 550MHz (100 x 5.5)

400MHz (100 x 4.0) 500MHz (100 x 5.0) 600MHz (100 x 6.0)

CPU Mount Procedure:

To mount the processor that you have purchased

separately, follow these instructions.

Retention Module Step 1. Open the two sides by folding them up.

Step 2.

Push the locks on top of the CPU inward.

Step 3. Insert the CPU into the retention

module. The CPU fits in the CPU slot in only ONE way, do not try to force it in.

Step 4. After completely inserting the CPU, push the two locks on

top of the CPU outward. Now your CPU is ready for use.

To remove the CPU, press

the two notches on top of the CPU inward. Now press the two slides on the retention module down and remove the CPU.

Note: Installing a heat sink and cooling fan on top of your CPU is necessary for proper heat dissipation. Failing to install these items may result in overheating and possible burn-out of your CPU.

Page 7

SY-6IBM

Quick Start Guide

Hardware

Installation

Step 2. Make Connections to the Motherboard

This section tells how to connect internal peripherals and power supply to the Motherboard. Internal peripherals include IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis Fan,

Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices.

For more details on how to connect internal and external peripherals to your new SY-6IBM Motherboard, please refer to SY-6IBM Motherboard User's Guide and Technical Reference online manual on CD-ROM.

Connectors and Plug-ins

IrDA (Infrared Device Header): IR1

Wake-On-LAN Header: JP44

Pin1 Pin2 Pin3 Pin4 Pin5 Pin1 Pin2 Pin3 VCC None IRRX GND IRTX

5VSB GND MP-Wakeup

CPU Cooling Fan: CPUFAN Chassis Fan: CHAFAN

Pin1 Pin2 Pin3 Pin1 Pin2 Pin3

GND 12V SENSOR GND 12V SENSOR

Power LED Keylock

Pin1 Pin2 Pin3

Pin1 Pin2

5V NC GND

Control Pin GND

Speaker

Pin1 Pin2 Pin3 Pin4

5V NC NC Speaker out

HDD LED Turbo LED PWRBT RESET

Pin1 Pin2 Pin1 Pin2 Pin1 Pin2 Pin1 Pin2

LED Anode

LED

Cathode

LED

Cathode

GND

Power On/Off

GND Power Good GND

CD Line-in: J4, J5 Pin 1 Pin 2 Pin 3 Pin 4

J4 R G L G

Connect the CD Line-in cord from the CD-ROM device to the matching header J4 or J5.

J5 R G G L

ATX Power On/Off: PWRBT ATX Power Supply: ATX PW

Connect your power switch to this header (momentary switch type).

To turn off the system, please press this switch and hold down for longer than 4 seconds.

Attach the ATX Power cable to this connector. (This motherboard requires an ATX power supply, an AT power supply can NOT be used.)

Note: Please make sure the ATX power supply is able to provide at least 720mA of current on the +5VSB lead if you want to enable the advanced power management functions, like power failure resume, Power-On by keyboard, etc.

Power LED

Key Lock

Speaker

Reset

PWRBT

Turbo LED

HDD LED

_ _

Page 8

SY-6IBM

Quick Start Guide

Hardware

Installation

Step 3. Configure Memory

Your board comes with three DIMM sockets, providing support for up to 768MB of main memory using DIMM modules from 8MB to 256MB. For 66MHz front side bus CPUs use 12ns or faster memory; for 100MHz front side bus CPUs use 8ns (100MHz, PC100 compliant) memory.

Memory Configuration Table

Number of Memory Modules DIMM 1 DIMM 2 DIMM 3

1 1

2 1

3 1

RAM Type SDRAM

Memory Module Size (MB) 8/16/32/64/128/256 Mbytes

Note:(1) 256 MB memory modules only available on PC registered DIMM.

(2) Always install memory modules in the order prescribed in this table. (3) Do not install unbuffered and registered memory modules together.

Important:

It is of prime importance that you install DIMM modules as outlined in the table

above in order to preserve signal integrity on 100MHz front side bus systems.

Step 4. Enable/Disable Power-On by PS/2 Keyboard (JP1)

You can choose to enable the Power-On by PS/2 Keyboard function by shorting pin 2-3 on jumper JP1, otherwise, short pin 1-2 to disable this function.

Support Power-On

by Keyboard

Disable Enable

JP1 Setting

Disable Power-On by PS/2 Keyboard function (short pin 1-2)

Enable Power-On by PS/2 Keyboard function (short pin 2-3)

Important: When using the Power-On by PS/2 Keyboard function, please make sure the ATX power supply can take at least 720mA load on the 5V Standby lead (5VSB) to meet the standard ATX specifications.

Page 9

SY-6IBM

Quick Start Guide

Hardware

Installation

Step 5. Set JP3 for power up FSB clock and AGP bus clock.

JP3 is used to adjust AGP bus clock frequency depending on the value of the front side bus (FSB) clock, also the setting of the JP3 determines the power up FSB clock which will remain effective until the BIOS set the FSB clock to the CMOS setting.

JP3 Setting

Power up FSB Clock 66MHz 100MHz

AGP Clock

AGP Clock = FSB Clock ÷ 1 AGP Clock = FSB Clock ÷ 1.5

Note1: The factory default setting for JP3 (Power up FSB clock and AGP bus clock) is

100MHz. CPUs that run on 66MHz may not boot at this frequency, so check JP3 before booting for the first time. Also, if the user changes the CPU, care should be taken to set JP3 in accordance with the FSB Frequency of the new CPU.

Note2: The specification of maximum AGP bus Clock frequency is 66.6MHz.

∗

Set JP3 to pin 1-2 short when you use a FSB 100MHz CPU.

∗

Set JP3 to pin 2-3 short when you use a FSB 66MHz CPU.

∗

Set JP3 to pin 1-2 short when you use a FSB 66MHz CPU but want to over clock the FSB clock to 100MHz via the BIOS setting.

Step 6. Set the CPU Working Frequency

You do not need to set any jumper for the CPU Working frequency. Instead, CPU settings are changed through the BIOS

[SOYO COMBO SETUP].

Please refer to Chapter 3 - Quick

BIOS Setup for details on how to set the Slot 1 processor frequency. For the power-up FSB

and AGP clock frequencies, please refer to

Step 5

Step 7. Power Button Enable (JP8)

Your system can be power on by either pressing a power button or typing in a password, which can be set in the BIOS SOYO COMBO Setup. To avoid being unable to power up the system due to of forgetting the password, you can place a jumper cap to short JP8. This will always enable the Power Button.

Power Button

Enable

Power Button always

enabled

Power Button according to

BIOS setting

JP8 Setting

Short pin to always enable the Power Button.

Open pin for a Power Button function according to the BIOS setting.

321

Page 10

SY-6IBM

Quick Start Guide

Hardware

Installation

Step 8. External Suspend Button (JP10)

Some cases come with a suspend button, insert the plug into JP10. In addition to through this button, the system can also enter the suspend mode through your OS.

Note: Suspend mode only functions if your Power Management mode is APM. Make sure that the BIOS setting for Power Management is APM. Windows 98 can be installed with ACPI Power Management (default is APM), in this case suspend mode will not function either.

Step 9. Back Panel Connector

Step 10. Clear CMOS Data (JP5)

Clear the CMOS memory by momentarily shorting pin 2-3 on jumper JP5 for at least 5 seconds, and then by shorting pin 1-2 to retain new settings. This jumper can be easily identified by its white colored cap.

CMOS Clearing Retain CMOS Data Clear CMOS Data

JP5 Setting

Short pin 1-2 to retain the new settings.

Short pin 2-3 for

at least 5 seconds

to clear the CMOS.

Note: You must unplug the ATX power cable from the ATX power connector when performing the CMOS Clear operation.

PS/2 KB

Connector

PS/2 Mouse

Connector

USB1

USB2

COM1

PRT

USB1

VGA

LINE-OUT

LINE-IN

MIC JACK

JOYSTICK

Page 11

SY-6IBM

Quick Start Guide

Hardware

Installation

Note on Over-clocking Capability

The 6IBM Motherboard provides over-clocking capability. Due to the over-clocking setting your system may fail to boot up or hang during run time. If this occurs, please perform the following steps to recover your system from the abnormal situation:

Turn off system power (If you use a ATX power supply, sometimes you have to press the power button for more then 4 seconds to shut down the system)

Set the JP3 to pin 2-3 short if you use a FSB 66MHz CPU

Press and hold down the <Insert> key while turning on the system power. Keep holding down the <Insert> key until you see the message of the CPU type and frequency (133MHz or 200MHz) appear on screen

Press the <Del> key during the system diagnostic checks to enter the Award BIOS Setup program

From the BIOS main menu, select [SOYO COMBO] and move the cursor to the [CPU Frequency] field to set the proper working frequency

Select [Save & Exit SETUP] and press <Enter> to save the configuration to the CMOS memory, and continue the boot sequence

Note: SOYO does not guarantee system stability if the user over clocks the system.

Any malfunctions due to over-clocking are not covered by the warranty.

Page 12

SY-6IBM

Quick Start Guide

Quick BIOS

Setup

Quick BIOS Setup

This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS

[SOYO COMBO SETUP].

The [SOYO COMBO SETUP] menu combines the main CPU parameters that you need to configure, all in one menu, for a quick setup in BIOS.

After the hardware installation is complete, turn the power switch on, then press the

<DEL>

key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Then, follow these steps to configure the CPU settings.

Step 1. Select [LOAD SETUP DEFAULT]

Select the “LOAD SETUP DEFAULT” menu and type “Y” at the prompt to load the BIOS optimal setup.

Step 2. Select [STANDARD CMOS SETUP]

Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to “Auto”.

Step 3. Select [SOYO COMBO SETUP]

Move the cursor to the

[CPU Speed]

field to set the CPU working speed.

Available [CPU Speed] settings on your SY-6IBM Motherboard are detailed in the following table. If you set this field to [Manual], you are then required to fill in the next two consecutive fields: (1) the CPU Ratio, and (2) the CPU Frequency.

CPU Frequency

233MHz (66 x 3.5) 350MHz (100 x 3.5) 266MHz (66 x 4.0) 400MHz (100 x 4.0) 300MHz (66 x 4.5) 450MHz (100 x 4.5) 333MHz (66 x 5.0) 500MHz (100 x 5.0) 366MHz (66 x 5.5) 550MHz (100 x 5.5)

400MHz (66 x 6.0) 600MHz (100 x 6.0) 433MHz (66 x 6.5)

Select the working frequency of your Pentium® III, Pentium® II, Celeron processor among these preset values.

Note: Mark the checkbox that corresponds to the working frequency of your Pentium® III, Pentium® II, Celeron processor in case the CMOS configuration should be lost.

Note:

if you use Bus Frequencies of 75 MHz, make sure that your PCI cards can cope with

the higher PCI clock.

Step 4. Select [SAVE & EXIT SETUP]

Press

<Enter>

to save the new configuration to the CMOS memory, and continue the boot

sequence.

Page 13

SY-6IBM

Quick Start Guide

The SOYO CD

The SOYO-CD will NOT autorun if you use it on an Operating System other than Windows 9x or NT.

Your SY-6IBM Motherboard comes with a CD-ROM labeled "SOYO CD." The SOYO CD contains (1) the user's manual file for your new Motherboard, (2) the drivers software available for installation, and (3) a database in HTML format with information on SOYO Motherboards and other products.

Step 1. Insert the SOYO CD into the CD-ROM drive

The SOYO CD will auto-run, and the SOYO CD Start Up Menu will be shown as below.

(SOYO CD Start Up Program Menu)

If you use Windows 95/98, the SOYO CD Start Up Program automatically detects which SOYO Motherboard you own and displays the corresponding model name.

Step 2. Read SOYO [6IBM] Manual

Click the

Read Manual

button to open the user's manual file of your Motherboard.

Page 14

SY-6IBM Quick Start Guide

The SOYO CD

Please note that if the Start Up program was unable to determine which SOYO Motherboard you own, the manual selection menu will pop up, as shown below. Then select the user's manual file that corresponds to your Motherboard model name and click

OK.

(Manual Selection Menu)

The user's manual files included on the SOYO CD can be read in PDF (Postscript Document) format. In order to read a PDF file, the appropriate Acrobat Reader software must be installed in your system.

Note:

The Start Up program automatically detects if the Acrobat Reader utility is already present in your system, and otherwise prompts you on whether or not you want to install it. You must install the Acrobat Reader utility to be able to read the user's manual file. Follow the instructions on your screen during installation, then once the installation is completed, restart your system and re-run the SOYO CD.

Step 3. Install Drivers

Click the

Install Drivers

button to display the list of drivers software that can be installed with your Motherboard. The Start Up program displays the drivers available for the particular model of Motherboard you own. We recommend that you only install those drivers.

However, to display the list of all drivers software available with SOYO Motherboards, click the

Display all drivers on the SOYO CD

button. Please make sure to install only the

drivers adapted to your system, or otherwise this may cause system malfunctions.

SOYO CD Manuals

Please select your manual in the box below and click OK.

686 boards: 586 boards:

OK Back

6IBM

Page 15

SY-6IBM

Quick Start Guide

The SOYO CD

The following drivers are available for Windows 95

(Driver Installation Menu)

The following drivers are available for Windows 98

(Driver Installation Menu)

Please select the driver you want to install and click OK, You will have to restart your system after installation. Only the drivers that are relevant to your board are displayed initially.

ATI Rage 128 driver for Win 9x ATI Rage 128 driver for Win NT

Intel BusMaster Drivers for Win NT Intel BusMaster Drivers for OS/2

YAMAHA 740 sound drivers for Win 95/98 YAMAHA 740 Xstudio program for Win 9x/NT

Winbond hardware doctor for win 95/98 YAMAHA 740 sound drivers for Win NT

YAMAHA 740 Ystation program for Win 9x/NT

Cancel

Display all drivers on the SOYO CD

Driver Installation

Please select the driver you want to install and click OK, You will have to restart your system after installation. Only the drivers that are relevant to your board are displayed initially.

Intel .inf utility for Win 95 Intel BusMaster Drivers for Win95

ATI Rage 128 driver for Win 9x

ATI Rage 128 driver for Win NT

Intel BusMaster Drivers for Win NT Intel BusMaster Drivers for OS/2 YAMAHA 740 sound drivers for Win 95/98 YAMAHA 740 Xstudio program for Win 9x/NT

Winbond hardware doctor for win 95/98 YAMAHA 740 sound drivers for Win NT

YAMAHA 740 Ystation program for Win 9x/NT

Cancel

Display all drivers on the SOYO CD

Driver Installation

Page 16

SY-6IBM Quick Start Guide

The SOYO CD

A short description of all available drivers follows:

Ø Intel .inf utility for Win 95

Because Windows 95 does not recognize the Southbridge of the newer Intel chipsets (TX, BX, ZX etc) this utility has to be run, it will update the necessary Windows .inf files. (Only for Windows 95)

Ø Intel Busmaster Drivers for Windows 95 Ø Intel Busmaster Drivers for Win NT Ø Intel Busmaster Drivers for OS/2

These are the official busmaster drivers as supplied by Intel.

Note: Do NEVER install two types of busmaster drivers on your system, this will lead to conflicts and system instability.

Ø Winbond hardware doctor for Windows 9x

Your motherboard comes with a hardware monitoring IC. By installing this utility Temperature, Fan speed and Voltages can be monitored. It is also possible to set alarms when current system values exceed or fall below pre-set values.

This utility comes with a preset monitoring rage for the CPU voltage. However, the core voltage of the processor you purchased may fall out of this preset range, so you may need to adjust the pre-set value. Please refer to the SY-6IBM Motherboard’s CD manual for the details.

Select which driver you want to install and click

OK,

or click

Cancel

to abort the driver

installation and return to the main menu.

Note:

Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.

Ø YAMAHA 740 Sound Drivers for Win95/98 and Win NT

Before installing any of the YAMAHA application programs, you MUST first install the YAMAHA 740 drivers for Windows 9x or NT.

Ø YAMAHA 740 Xstudio program for Win 9x/NT Ø YAMAHA 740 Ystation program for Win 9x/NT

These Application programs allow the user to make full use of the functionality that the Yamaha sound chip has to offer. Make sure to install the Yamaha driver for your OS before installing any of the application software.

Ø ATI Rage 128 driver for Win 9xand Win NT

Select this Item and click OK to start up the ATI Rage 128 AGP driver screen. Follow the instructions on the screen to install the drivers and/or application programs you need.

Page 17

SY-6IBM

Quick Start Guide

The SOYO CD

Note:

Step 4. Check the Latest Releases

Click the 'Check the latest Releases' button to go the SOYO Website to automatically find the latest BIOS, manual and driver releases for your motherboard. This button will only work if your computer is connected to the internet through a network or modem connection. Make sure to get your modem connection up before clicking this button.

Step 5. Enter the SOYO CD

Click the

Enter SOYO CD

button to enter the SOYO HTML database. The Start Up program will activate the default HTML browser installed on your system (for example, Internet Explorer or Netscape) to visualize the contents of the SOYO CD.

The SOYO CD contains useful information about your Motherboard and other SOYO products available. For your convenience, this information is available in HTML format, similar to the format widely used on the Internet.

Note:

If no HTML browser is installed on your system, the Start Up program will prompt you on whether or not you would like to install the Internet Explorer* browser. Click YES to install the HTML browser. After the installation is complete, please restart your system. Then re-run the SOYO CD and you will be able to browse the SOYO HTML database.

(* Internet Explorer is a Microsoft Trademark)

Page 18

SY-6IBM Quick Start Guide

How to contact us:

n If you are interested in our products, please contact the SOYO sales

department in the region you live.

n If you require Technical Assistance, please contact our Technical Support in

the region you live. SOYO prefers Email as communication medium, remember to always add to the email the country that you live in.

SOYO Taiwan

No. 21 Wu-Kung 5 Rd., Hsin Chuang City, Taipei Hsien, Taiwan

Region Covered: Taiwan and AsiaPacific. (Including Australia).

Web Site: www.soyo.com.tw

Sales:

Tel: 886-2-22903300-318 Fax: 886-2-22983322 E-mail: [email protected]

Technical Support:

Fax: 886-2-22983322 E-mail: [email protected]

SOYO Europe BV

Signaalrood 19, 2718 SH Zoetermeer The Netherlands

Region Covered: Europe except Germany, Austria and Switserland

Web Site: www.soyo.nl, www.soyo-

europe.com

Sales:

Tel: +31-69-3637500 Fax: +31-79-3637575 Email: [email protected]

Technical Support:

Tel : +31-79-3637500 Fax: +31-79-3637575 Email: [email protected]

SOYO USA

41484 Christy Street, Fremont, CA 94538

Region Covered: US and Canada Web Site: www.soyousa.com,

www.soyo.com

Sales:

Tel: 510-226-7696 Fax: 510-226-9218 Email : [email protected]

Technical Support:

Tel: 510-226-7696 Fax: 510-226-9218 Email : [email protected]

SOYO (U.K.) LTD.

Unit 7, Alice Way, Hounslow Business Park, Hanworth Road, Hounslow, TW3 3UD

Region Covered: United Kingdom and Republic of Ireland

Web Site: www.soyo.co.uk

Sales:

Tel : +44 (0)181 569 4111 Fax: +44 (0)181 569 4134 E-mail: [email protected]

Technical Support:

Tel : +44 (0)181 569 4111 Fax: +44 (0)181 569 4134

Page 19

SY-6IBM

Quick Start Guide

E-Mail: [email protected]

SOYO Deutschland GmbH

August-Wilhelm-Kuhnholz-Str. 15 D-26135 Oldenburg

Region Covered: Germany, Austria and Switzerland. (Zustandig fur Deutschland, Osterreich, Schweiz)

Web Site: www.saat.de, www.soyo-

saat.com, www.soyo-saat.de

Vertrieb Mainboards, Notebooks und SoyoCom Produkte:

E-Mail: [email protected] Fon: +49-(0)441/20910-31/33 Fax: +49-(0)441/203422

Technischer Support:

E-Mail: [email protected] Fon: +49-(0)441/20910-40 Fax: +49-(0)441/203422

SOYO KOREA

Region Covered: Korea

Sales:

Tel : 82-2-716-2850 Fax : 82-2-704-2619 E-mail : [email protected]

Technical Support:

tel : 82-2-717-4392 fax : 82-2-712-5853 e-mail : [email protected]

SOYO Hong Kong

Region Covered: Hong Kong Web Site: www.soyo.com.hk

Sales:

tel: 852-27109810 fax: 852-27109078 E-mail: [email protected]

Technical Support:

tel: 852-27109810 fax: 852-27109078 E-mail: [email protected]

SOYO China (Gin Mei Jei)

Region Covered: All of China

Sales:

Tel: 86-10-62510089 fax: 86-10-62510388 E-mail: [email protected]

Technical Support:

Tel: 86-10-62510089 fax: 86-10-62510388 E-mail: [email protected]

SOYO Japan

Region Covered: Japan Web site: www.soyo.co.jp

Sales:

Tel: 81-3-33682188 Fax: 81-3-33682199 E-mail: [email protected]

Technical Support:

Tel: 81-3-33682188 Fax: 81-3-33682199 E-mail: [email protected]

Page 20

Edition: August 1999

Version 1.2

SY-6IBM SERIAL
