Introduction
SY-P4VSA
Motherboard
Hardware
Installation
Setup
Quick BIOS
The SOYO CD
Quick Start Guide
SOYO™
SY-P4VSA Motherboard
mPGA Socket 478 processors
VIA P4X266 AGP/PCI Motherboard
400 MHz Front Side Bus supported
ATX Form Fa ct or
Copyright © 2001 by Soyo Computer Inc.
Trademarks:
Soyo is the registered trademark of Soyo Computer Inc. All trademarks are the properties of
their owners.
Product Rights:
All names of the product and corporate mentioned in this publication are used for identification
purposes only. The registered trademarks and copyrights belong to their respective companies.
Copyright Notice:
All rights reserved. This manual has been copyrighted by Soyo Computer Inc. No part of this
manual may be reproduced, transmitted, transcribed, translated into any other language, or
stored in a retrieval system, in any form or by any means, such as by electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without permission in writing from Soyo
Computer Inc.
Disclaimer:
Soyo Computer Inc. makes no representations or warranties regarding the contents of this
manual. We reserve the right to amend the manual or revise the specifications of the product
described in it from time to time without obligation to notify any person of such revision or
amend. The information contained in this manual is provided to our customers for general use.
Customers should be aware that the personal computer field is subject to many patents. All of
our customers should ensure that their use of our products does not infringe upon any patents. It
is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to
infringe upon or to cause others to infringe upon such rights.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
252.277-7013.
About This Guide:
This Quick Start Guide can help system manufacturers and end users in setting up and installing
the Motherboard. Information in this guide has been carefully checked for reliability; however,
to the correctness of the contents there is no guarantee given. The information in this document
is subject to amend without notice.
For further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
P4VSA Serial - Version 1.2 - Edition: December 2001
* These specifications are subject to amend without notice
2
SY-P4VSA
Quick Start Guide
1
1
Congratulations on your purchase of the
illustrates the steps for installing and setting up your new Motherboard.
This guide provides all users with the basic steps of Motherboard setting and operation. For
further information, please refer to the SY-P4VSA Motherboard User's Manual that came
with your Motherboard.
Introduction
SY-P4VSA
Motherboard. This Quick Start Guide
Unpacking
When unpacking the Motherboard, check for the following items:
The SY-P4VSA VIA P4X266 AGP/PCI Motherboard
Introduction
This Quick Start Guide
The Installation CD-ROM
SOYO Bonus Pack CD-ROM
One IDE Device ATA 100 Flat Cable
One Floppy Disk Drive Flat Cable
One Heat Sink Compound
3
SY-P4VSA Quick Start Guide
V
SY-P4VSA Motherboard Layout
PS/2 Mouse
PS/2 KB
Connector
Connector
Introduction
USB 1
COM A
COM B
AOUT
AIN
AMIC
USB 2
PRT
AGAME
ONBOARD
AUDIO
J29
P1
P2
4
1
CDIN
SDRAM
T8753
SDRAM
AGP Slot
PCI#1
PCI#2
□
DIMM1
ATX Pow e r
IDE 2IDE 1
DIMM2
DIMM3
FDC
JP10
WOL
Header
IT8705F
PCI#3
ITE
1
13
14
SMCARDCN
51
2
SIRCON
PCI#4
PCI#5
1
55
66
10 10
USB3_ 4 USB5_ 6
3V
Lithiu m
Battery
1
Speaker
Keylock
Power
LED
J25
1
JP5
HDD
LED
PWRBT
Reset
CMOS Clear
Jumper
(Optional)
4
SY-P4VSA
Key Features
Quick Start Guide
Supports Intel® mPGA Socket 478
processors
- Pentium
Supports 400 MHz Front Side Bus
Frequency
PC99, ACPI
Ultra 33/66/100 (ATA 33/66/100)
Supports Wake-On-LAN (WOL)
Supports PC-133 SDRAM
Supports ACPI Suspend Indicator
Power-on by modem, alarm and PS/2
Keyboard
Power failure resume
Supports Suspend to RAM
Supports onboard hardware monitoring
and includes Hardware Doctor™ utility
®
4
Supports multiple-boot function
AGP 2.0 Compliant;
AGP Connector supports:
- 1X/2X/4X data transfer
Smart Card Reader
- Compliant with Personal Computer
Smart Card (PC/SC) Working Group
standard
- Compliant with smart card (ISO 7816)
protocols
- Supports card present detect
- Supports Smart Card insertion
power-on feature
3 x DIMM slots for SDRAM memory
1 x 32-bit AGP slot
5 x 32-bit bus master PCI slots
Introduction
Supports AC97 Codec
Easy CPU settings in BIOS with the
“SOYO COMBO Setup”
- CPU voltage adjust
- CPU ratio adjust
- CPU FSB adjust
6 x USB ports onboard
1 x IrDA port
ATX 12V power connector
5
SY-P4VSA Quick Start Guide
2
2
Hardware
Installation
Follow the directions in this section which is designed to guide you through a quick and
correct method to install your new
refer to the SY-P4VSA Motherboard User's Manual and Technical Reference online manual
on the CD-ROM that came with your Motherboard.
Installation
To avoid damage to your Motherboard, please follow these simple rules while
handling this equipment:
Before handling the Motherboard, ground yourself by touching on to an unpainted
portion of the system's metal chassis.
Remove the Motherboard from its anti-static packaging. Hold the motherboard by the
edges and avoid touching its components.
Check the Motherboard for damage. If any chip appears to be loose, press carefully
to seat it firmly in its socket.
SY-P4VSA
Motherboard. For detailed information, please
Gather and prepare all necessary components to complete the installation successfully:
Socket mPGA 478 processor with built-in CPU cooling fan (boxed type)
SDRAM module (s)
Computer case with adequate power supply unit
Monitor
PS/2 Keyboard
Pointing Device (PS/2 Mouse)
Speaker(s) (optional)
Disk Drives: HDD, CD-ROM, Floppy drive…
External Peripherals: Printer, Plotter, and Modem (optional)
Internal Peripherals: Modem and LAN cards (optional)
VGA Card (AGP, PCI)
6
