SY-KT333 DRAGON Lite
Motherboard
Introduction
Hardware
Installation
Quick Start Guide
Setup
Quick BIOS
The SOYO CD
SOYO™
SY-KT333 DRAGON Lite Motherboard
AMD® K7 Athlon & DuronTM processors
VIA KT333 AGP/PCI Motherboard
100/133 MHz Front Side Bus supported
ATX Form Factor
Copyright © 2002 by SOYO Computer Inc.
Tr a d e m ar k s :
SOYO is a registered trademark of SOYO Computer Inc. All trademarks are properties of their owners.
Product Rights:
All names of the product and corporate mentioned in this publication are used for identification purposes only.
The registered trademarks and copyrights belong to their respective companies.
Copyright Notice:
All rights reserved. This manual has been copyrighted by SOYO Computer Inc. No part of this manual may
be reproduced, transmitted, transcribed, translated into any other language, or stored in a retrieval system, in
any form or by any means, such as by electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without permission in writing from SOYO Computer Inc.
Disclaimer:
SOYO Computer Inc. makes no representations or warranties regarding the contents of this manual. We
reserve the right to amend the manual or revise the specifications of the product described in it from time to
time without obligation to notify any person of such revision or amend. The information contained in this
manual is provided to our customers for general use. Customers should be aware that the personal computer
field is subject to many patents. All of our customers should ensure that their use of our products does not
infringe upon any patents. It is the policy of SOYO Computer Inc. to respect the valid patent rights of third
parties and not to infringe upon or to cause others to infringe upon such rights.
Disclaimer:
Please be advised that some SOYO motherboards are designed with overclocking features and may allow
users to run the components beyond manufacturer's recommended specifications. Overclocking beyond
manufacturer's specifications is not recommended nor endorsed by SOYO, Inc. and will void your
manufacturer's warranty. Overclocking beyond manufacturer's specifications is not encouraged and should
be assumed at the user's own risk. Unsafe overclocking can damage the user's system or cause serious
personal injury. If the user is unsure or in doubt about overclocking, please seek professional advise. SOYO,
Inc. is not responsible for any direct or indirect damage resulting from overclocking.
Restricted Rights Legend:
Use, duplication, or disclosure by the Government is subject to restrictions set forth in subparagraph (c)(1)(ii)
of the Rights in Technical Data and Computer Software clause at 252.277-7013.
About This Guide:
This Quick Start Guide can help system manufacturers and end users in setting up and installing the
motherboard. Information in this guide has been carefully checked for reliability; however, to the correctness
of the contents there is no guarantee given. The information in this document is subject to amend without
notice.
For further information, please visit our Web Site on the Internet. The address is
"http://www.soyo.com.tw".
KT333 DRAGON Lite Serial - Version 1.3- Edition: July 2002
* These specifications are subject to amend without notice
2
SY-KT333 DRAGON Lite
Quick Start Guide
1
1
Congratulations on your purchase of the
Guide illustrates the steps for installing and setting up your new motherboard.
This guide provides all users with the basic steps of motherboard setting and operation. For further
information, please refer to the SY-KT333 DRAGON Lite motherboard User’s Manual that came with
your motherboard.
Introduction
SY-KT333 DRAGON Lite
motherboard. This Quick Start
Unpacking
When unpacking the motherboard, check for the following items:
The SY-KT333 DRAGON Lite AGP/PCI Motherboard
The user manual
Introduction
The Installation CD-ROM
SOYO Bonus Pack CD-ROM
One IDE Device ATA 66 Flat Cable
One Floppy Disk Drive Flat Cable
One Heat Sink Compound
Two motherboard Spacer Support
3
SY-KT333 DRAGON Lite Quick Start Guide
V
SY-KT333 DRAGON Lite Motherboard Layout
PS/2 KB
Connector
PS/2 Mouse
Connector
Introduction
USB 1_2
COM 1
COM 2
LINE-OUT
LINE-IN
MIC
PRT
GAME PORT
H/W
Audio
ATX Power
AGP Slot
PCI Slot #1
IDE 1 IDE 2
FDC1
3
Header
1
113
2
WOL
14
PCI Slot #2
PCI Slot #3
PCI Slot #4
PCI Slot #5
3V
Lithium
Battery
□
T8233A
JP5
13
(Optional)
USB 2.0
CHIP
Super
I/O
JP44
14
SMCARDCN
4
Supports Socket A AMD® K7 processors
Supports 200/266 MHz Front Side Bus
-
Athlon /XP CPU (750MHz ~ 2100+)
-
Duron /Morgan CPU (650MHZ ~
1.2GHz)
Supports 200/266/333 DDR (Double Data
Rate) module
PC99, ACPI
Ultra DMA 33/66/100/133
(ATA 33/66/100/133)
Supports Wake-On-LAN (WOL)
Power-on by modem and alarm and PS/2
Keyboard
SY-KT333 DRAGON Lite
Key Features
Supports suspend to RAM (STR)
Supports 5 sets of voltage monitoring
On-board hardware audio
Power failure resume
Supports multiple-boot function
Smart Card Reader
- Compliant with Personal Computer Smart
Card
（
- Compliant with smart card
protocols
- Supports card present detect
Quick Start Guide
PC/SC）Working Group standard
（
ISO 7816
）
Introduction
Supports onboard hardware monitoring
Easy CPU settings in BIOS with the “SOYO
COMBO Setup”
- CPU FSB frequency
- CPU multiplier
- CPU Vcore voltage
- DDR RAM Clock
- DDR Voltage
- AGP Voltage
- Supports Smart Card insertion power-on
feature
1 x IrDA port
3 x DIMM slots for DDR RAM memory
5 x 32-bit bus master PCI slots
1 x AGP slot
4 x USB ports onboard
ATX power connector
5
SY-KT333 DRAGON Lite Quick Start Guide
2
2
Installation
Follow the directions in this section which is designed to guide you through a quick and correct method
to install your new
SY-KT333 DRAGON Lite motherboard User's Manual and Technical Reference online manual on the
CD-ROM package that came with your motherboard.
Installation
To avoid damage to your motherboard, please follow these simple rules while handling
this equipment:
Before handling the motherboard, ground yourself by touching on to an unpainted portion of the
system's metal chassis.
Remove the motherboard from its anti-static packaging. Hold the motherboard by the edges
and avoid touching its components.
Check the motherboard for damage. If any chip appears to be loose, press carefully to seat it
firmly in its socket.
SY-KT333 DRAGON Lite
motherboard. For detailed information, please refer to the
Gather and prepare all necessary components to complete the installation successfully:
Socket A processor with built-in CPU cooling fan (boxed type)
DDR RAM module(s)
Computer case with adequate power supply unit
Monitor
PS/2 Keyboard
Pointing Device (PS/2 Mouse)
Speaker(s) (optional)
Disk Drives: HDD, CD-ROM, Floppy drive…
External Peripherals: Printer, Plotter, and Modem (optional)
Internal Peripherals: Modem and LAN cards (optional)
Note:
If you want to use an external speaker connected to "Line-out" port, please make sure to use an
"amplified speaker" that can generate proper output sound volume.
6
SY-KT333 DRAGON Lite
p
Quick Start Guide
We will now begin the installation process. Please follow the step-by-step
procedure designed to lead you to a complete and correct installation.
Step 1
- Assembling the motherboard to the case
Step 2
- Install the Central Processing Unit (CPU)
Step 3
- Install memory modules
Step 4
- Install expansion cards
Step 5
- Connect cables, case wires, and power supply
Install the Motherboard
Step 1.
Assembling the motherboard to the case
Installation
To avoid shorting the motherboard to the case,
lease use the provided spacer support on this
screw hole…
DIMM1DIMM3
7
SY-KT333 DRAGON Lite Quick Start Guide
Step 2. Install the CPU
CPU Mount Procedure:
purchased separately, follow these instructions.
1
1
Installation
To mount the AMD® K7 Athlon & DuronTM processor that you have
2
3
4
1. Lift the socket handle up to a vertical position.
2. Align the blunt edge of the CPU with the matching pinhole edge on the socket.
3. Seat the processor in the socket completely and without forcing.
4. Then close the socket handle to secure the CPU in place.
Remember to connect the CPU Cooling Fan to the appropriate power connector on
the motherboard. The fan is a key component that stabilizes the system. It prevents the
equipment from overheating and prolongs the life of your CPU.
8
SY-KT333 DRAGON Lite
CPU Fan Installation
Your Socket A processor kit comes with a cooling fan. Mount the fan on the processor according to the instructions provided
by the manufacturer. The fan is a key component that will ensure system stability. The fan prevents overheating, therefore
prolonging the life of your CPU.
Note: Remember to connect the fan to the appropriate power source.
Quick Start Guide
CPU Fan Mount Procedure:
instructions on how to mount the CPU fan properly.
1. Apply thermal paste to the die of the CPU.
2. Carefully mount the fan on top of the CPU and clip-on the first lock.
To prevent scratch or damage on the motherboard, please follow the
Installation
1
9
SY-KT333 DRAGON Lite Quick Start Guide
3. Clip-on the second lock and please make sure not to damage/scratch the board.
2
Installation
4. The fans power connector should be connected to CPUFAN1.
DIMM1DIMM3
Note: If the fan is defective or power connector is not connected to CPUFAN1, the system will enable Fan
Off Control function. See below for more information on FOC function.
10
SY-KT333 DRAGON Lite
Quick Start Guide
FOC (Fan-Off Control)
The newly designed SOYO “FOC” is based on the concept of total protection for CPU, which is very
different from currently seen on the market. The H/W control function is used to see a passive security
system of monitoring and warning. S/W Simultaneous Signal Follow-ups techniques and Auto Power Off
System are included to prevent all possible damage caused by the malfunctioning of the CPU fan. With the
help of “O/S On Time Monitoring And Warning” function, provided by the H/W monitoring system, the
double-protection purpose is achieved.
“FOC” includes the following functions:
(1) Simultaneous Signal Follow Ups: Before the system enters the O/S, H/W will detect the signals
of the CPU fan pins, get their revolution information and send it to the BIOS.
(2) Auto Power Off System: If the BIOS receives the information of CPU fan revolution, it continues
to function normally. If no signal is received, it will inform the system and disconnects the power
supply immediately to protect the CPU from overheating.
Installation
Note
: The following must be observed to secure the normal functioning of “Fan-Off Control”:
1. FOC only works on CPUFAN 1.
2. CPU fan with sensor pins must be used.
3. CPU fans approved by AMD are strongly recommended.
The “HOT KEY” function is provided for the CPU fans without sensor pins, to avoid the power off. Users
may press the “Insert” key to jump over the “Power Off” mode; go to the BIOS and disable “FOC”. Now
system can be booted normally.
We provide the following User-Friendly protection features:
1. Fan-Off Control : The motherboard detects the status of the CPU fan and protects the CPU by
automatically disconnecting the power supply. The default value of this function is Enable.
After booting up, the user may disable it.
2. Heat Dissipation Paste: Heat Dissipation Paste is included for all Socket-A motherboards, to
enhance the heat dissipation capability.
Furthermore, we strongly recommend our users to enable the function of H/W monitoring in
the BIOS. This function, together with the FOC, provides the total protection to the CPU and
allows it to maximize its performance.
11
SY-KT333 DRAGON Lite Quick Start Guide
Step 3. Configure Memory
Your board comes with three DIMM sockets, providing support for up to 3GB of main memory using
unbuffered and non-ECC DIMM modules from 64MB to 1GB. On this motherboard, DRAM speed can
be set independent from the CPU front side bus speed. Depending on the DRAM clock speed setting in
the BIOS setup, appropriate memory modules must be used. For 100MHz DRAM speed, use
PC1600 memory; for 133MHz DRAM speed, use PC2100 memory; for 166 MHz DRAM speed, use
PC2700 memory.
Installation
Memory Configuration Table
Number of Memory
Modules
RAM Type DDR RAM
Memory Module Size
(MB)
Step 4 Install Expansion Card
The motherboard has 1 AGP PRO slot and 5 PCI slots.
1. Read the related expansion card’s instruction document before inserting the expansion card into
the computer.
2. Press the expansion card firmly into expansion slot in motherboard.
3. Be sure the metal contacts on the card are indeed seated in the slot.
DIMM 1 DIMM 2 DIMM 3
64 / 128 / 256 / 512 / 1024 MB
4. Replace the screw to secure the slot bracket of the expansion card.
5. Install related driver from the operating system.
Step 5 Connections to the Motherboard
This section tells how to connect internal peripherals and the power supply to the motherboard.
The internal peripherals consist of IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis Fan, Front
Panel Devices (Internal Speaker, Reset Button and IDE LED Switch.), Wake-On-LAN card, VGA card,
Sound Card, and other devices.
For more details on connecting internal and external peripherals to your new SY-KT333 DRAGON Lite
motherboard, please refer to SY-KT333 DRAGON Lite motherboard User's Manual and Technical
Reference online manual on the CD-ROM.
12
SY-KT333 DRAGON Lite
Connectors and Plug-ins
Standard IrDA (Infrared Device Header):SIRCON Wake-On-LAN Header: JP44
Quick Start Guide
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Pin7 Pin8 Pin9 Pin10
VCC NC IRRX GND IRTX VCC NC CIRRX GND CIRTX
SMCARDCN
Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Pin7 Pin8 Pin9 Pin10 Pin11 Pin12 Pin13 Pin14
VCC NC NC NC Scrfet RST CLK NC NC Scrio GND Scrpres NC NC
USB3 USB4
Pin1 Pin2 Pin3 Pin4
Power Data(-) Data(+) GND
CPU Cooling Fan: CPUFAN1 CPU Cooling Fan: CPUFAN2
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3
GND 12V SENSOR GND 12V NC
Chassis Fan: CHAFAN1 Chassis Fan: CHAFAN2/3
Pin1 Pin2 Pin3 Pin1 Pin2 Pin3
CONTROL 12V SENSOR GND 12V NC
CD -IN: CDIN1 / CDIN2 Pin1 Pin2 Pin3 Pin4
Connect the CD Line-in cord from the CR-ROM
device to the matching connector CDIN
Pin6 Pin7 Pin8 Pin9 Pin10
Power Data(-) Data(+) GND GND
CDIN1 L G G R
CDIN2 G L G R
Pin1 Pin2 Pin3
5V-SB GND MP_Wakeup
Installation
Power LED
Speaker
HDD LED
Pin1 Pin2 Pin3
VCC NC GND
Speaker
Pin1 Pin2 Pin3 Pin4
VCC NC NC Speaker out
ATX Power On/Off: PWRBT
ATX Power Supply: ATX PW
Power LED
Reset
Pin1 Pin2 Pin1 Pin2 Pin1 Pin2
LED Anode LED Cathode Power On/Off GND Control PIN GND
Connect your power switch to this header (momentary switch type).
To turn off the system, press this switch and hold down for longer than 4 seconds.
Attach the ATX Power cable to this connector. (This motherboard requires an ATX power supply, an AT power supply can
NOT be used.)
When using the Power-On by PS/2 Keyboard function, please make sure the ATX power supply is able to provide at least
720mA on the 5V Standby lead (5VSB) in order to meet the standard ATX specifications.
PWRBT
HDD LED PWRBT RESET
13
SY-KT333 DRAGON Lite Quick Start Guide
CMOS Clear (JP5)
In some cases the CMOS memory may contain wrong data, follow the steps below to clear the CMOS
memory.
1. Put the jumper back to 1-2 to allow writing of new data into the CMOS memory.
2. Clear the CMOS memory by momentarily shorting pin 2-3 on jumper JP5. This jumper can be
easily identified by its white cap.
Installation
CMOS Clearing Retain CMOS Data Clear CMOS Data
JP5 Setting
Note: You must unplug the ATX power cable from the ATX power connector when
performing the CMOS Clear operation.
Short pin 1-2 to retain
new settings
12 3
Short pin 2-3 for
at least 5 seconds to
clear the CMOS
12 3
Audio Speakers connections
When using 2 channel speaker, connect the speaker cable to line-out.
If you’re using 4 channel speaker, connect the front L/R speakers to line-out and rear L/R speakers to
Line-in. make sure to set the audio software for 4 channel speaker system.
Line-out Line-in
14
SY-KT333 DRAGON Lite
Quick Start Guide
3
3
This motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings
are software configurable with the BIOS
FEATURE] combines the main parameters that you need to configure, all in one menu, for a quick
setup in BIOS.
After the hardware installation is complete, turn the power switch on, then press the
system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will be
shown on the screen. Then, follow these steps to configure the CPU settings.
Step 1.
Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to “Auto”.
Step 2. Select [LOAD OPTIMIZED DEFAULTS]
Select the “LOAD OPTIMIZED DEFAULTS” menu and type “Y” at the prompt to load the BIOS optimal
setup.
Step 3.
Set the
Quick BIOS Setup
[SOYO COMBO FEATURE].
Select [STANDARD CMOS SETUP]
Select [SOYO COMBO FEATURE]
[CPU Frequency Select]
to 100/133MHz, depending on the Front Side Bus of your CPU.
The [SOYO COMBO
<DEL>
key during the
Setup
Quick BIOS
To overclock your CPU’s Front Side Bus,
1MHz increment or you can input the desired FSB value of the CPU.
Set the
your CPU’s Front Side Bus, it overclocks your DDR Clock as well.
Note:
DDRAM clock speed should not be lower than the CPU speed. Ex, if you have a 133MHz FSB
Step 4.
Press
[DRAM Clock]
The maximum FSB you can overclock for a 100MHz FSB CPU is 132MHz and 233MHz for
133MHz FSB CPU.
CPU, BIOS will not have 100MHz option in the DRAM clock.
SOYO is not responsible for damage done in your CPU or system instability due to
overclocking.
Select [SAVE & EXIT SETUP]
<Enter>
to save the new configuration to the CMOS memory, and continue the boot sequence.
to 100/133/166 MHz or By SPD, depending on the DDR Clock. If you overclock
[Frequency 1MHz Stepping]
enables you to overclock in
15
SY-KT333 DRAGON Lite Quick Start Guide
4
4
Your SY-KT333 DRAGON Lite motherboard comes with a CD-ROM labeled "SOYO CD." The
SOYO CD contains
Step 1.
If you are running Windows NT/2K/XP, the SOYO-CD will not detect your motherboard type. In that case
the following dialog will pop up. Please choose your motherboard model number and press OK.
Now the SOYO-CD Start Up Menu will come up as shown on the following page
The SOYO CD
The SOYO-CD will Auto Run only in Windows Base Operating System .
a. The user's manual for your new motherboard -in PDF format,
b. The drivers software available for installation, and
c. A database in HTML format with information on SOYO motherboards and other
products.
Insert the SOYO CD into the CD-ROM drive
The SOYO CD
(SOYO CD Start Up Program Menu)
Under Windows 95/98/ME, the SOYO CD Start Up Program automatically detects the SOYO
motherboard the system uses and displays the corresponding model name.
16
SY-KT333 DRAGON Lite
Quick Start Guide
The user's manual files included on the SOYO CD are in PDF (Postscript Document) format. In order
to read a PDF file, the appropriate Acrobat Reader software must be installed in your system.
Note:
The Start Up program automatically detects if the Acrobat Reader utility is already present in
your system, and otherwise prompts you on whether or not you want to install it. You must install the
Acrobat Reader utility to be able to read the user's manual file. Follow the instructions on your screen
during installation, then once the installation is completed, restart your system and re-run the SOYO
CD.
Step 2. Install Drivers and Utilities
The following drivers need to be installed in order for the system to operate properly
1. VIA 4 in 1 driver.
2. C-Media 4 channel audio driver. – Only required if you are using the onboard audio.
The rest of the available drivers are optional.
Click the
motherboard. The Start Up program displays the drivers available for the particular model of
motherboard you own. We recommend that you only install those drivers.
Install Drivers
button to display the list of drivers software that can be installed with your
The SOYO CD
17
SY-KT333 DRAGON Lite Quick Start Guide
driver
VIA 4 in 1 Driver Package for Win 9x/ME/NT/2k/XP
C-MEDIA 4-channel onboard audio Driver/Application for Win 9x/ME/2000/NT/XP
KT333 DRAGON Lite hardware monitor for Win 9x/ME/2000/NT/XP
KT333 DRAGON Lite ITE SIM card reader driver for Win 9x/ME/2000/NT/XP(english)
C-MEDIA 4-channel onboard audio Driver for NT4.0 Installation
Cancel
OK
(Driver Installation Menu)
revision:
A short description of all available drivers follows:
VIA 4 in 1 Driver Package for Win 9x/ME/NT/2k/XP
VIA 4 In 1 driver includes four system drivers to improve the performance and maintain
the stability of systems using VIA chipsets. These four drivers are :
VIA Registry (INF) Driver, VIA AGP VxD driver, VIA ATAPI Vendor Support Driver and
VIA PCI IRQ Miniport Driver. For Windows NT users, the VIA IDE Bus Mastering driver is
the only driver to be installed in your system.
A description of 4 drivers follows:
The SOYO CD
Bus Master PCI IDE Driver
The ATAPI IDE driver enables the performance enhancing bus mastering
functions on ATA-capable Hard Disk Drives and ensures IDE device compatibility.
AGP VxD Driver
VIA AGP VxD Driver is to be installed if you are using an AGP VGA device.
VIAGART.VXD will provide service routines to your VGA driver and interface
directly to hardware, providing fast graphical access.
VIA Chipset Functions Registry
VIA Registry (INF) Driver is to be installed under Windows. The driver will enable
the VIA Power Management function.
IRQ remapping utility (This driver is installed automatically)
VIA PCI IRQ Miniport Driver is to be installed under Windows 98 only, it sets the
system's PCI IRQ routing sequence.
18
SY-KT333 DRAGON Lite
C-MEDIA 4-channel Onboard Audio Driver/Application for Win 9x/ME/
Quick Start Guide
2000/NT/XP
1. The driver supports 2/4/6 speakers 3D positional audio.
2. The application is include
CD Player/MIDI Player/MP3/Wave Player/Mixer
with the
control over your PC’s audio functions.
KT333 DRAGON Lite hardware monitor for Win 9x/ME/2000/NT/XP
Your motherboard comes with a hardware monitoring IC. By installing this utility
Temperature, Fan speed and Voltages can be monitored. It is also possible to set alarms
when current system values exceed or fall below pre-set values.
KT333 DRAGON Lite ITE SIM card reader driver for Win 9x/ME/2000/NT/
XP(english)
If you have reader card, it must be installed.
Select which driver you want to install and click
OK,
or click
Cancel
to abort the driver
installation and return to the main menu.
Note:
Once you have selected a driver, the system will automatically exit the SOYO CD
to begin the driver installation program. When the installation is complete, most drivers
require to restart your system before they can become active.
Step 3.
Check the Latest Releases
Click the 'Check the latest Releases' button to go the SOYO Website to automatically
find the latest BIOS, manual and driver releases for your motherboard. This button will
only work if your computer is connected to the internet through a network or modem
connection. Make sure to get your modem connection up before clicking this button.
(* Internet Explorer is a Microsoft Trademark)
The SOYO CD
19
SY-KT333 DRAGON Lite Quick Start Guide
5
5
Audio Driver Installation for Windows 98/98se.
After you have installed the audio driver, windows may prompt you to restart your computer.
When your computer restarted it may look for windows driver from your Win98CD and ask you to
insert your Win98/98se CD to your CD-drive. At this point you need to insert the Win98 CD to your
CD-drive and type in D:\win98 (assuming your CD-Rom in driver D).
Audio Driver Installation for Windows NT
1. Double click my computer.
2. Double click control panel.
3. Double click multimedia and select devices.
4. Select ADD and select OK.
5. Click on “Browse” then point it to the SOYO CD for the Audio driver.
Audio Driver Installation
6. The audio driver path is in SOYO CD “D:\audio\cmi8738_6ch\Win_NT40\drv”
(where D: is your CD-ROM).
Installation
Audio Driver
20
SY-KT333 DRAGON Lite
Quick Start Guide
Quick Trouble shoot tips
Boot-up Issues
The system do not power-up, no beeping sound heard and the CPU fan does not turn
on.
1. Check if the power cord is plug to the power source.
2. Check if the power is connected to the M/B.
3. Check if the cable of the case power button is connected to the M/B power button
connector (see connectors and plug-ins in the manual for more info).
4. Make sure the power supply is not defective. Change the power supply. The
minimum should be 250 watts.
5. Remove the M/B from the case and test the system. The M/B might be shorted to the case.
The system power-up, no video, no beeping sound heard, but the CPU fan is turning.
1. Clear CMOS battery. (JP5 connector, see Quick start guide for more info on how
to clear the CMOS).
2. Check all the jumper settings on the M/B. (if the M/B have any).
3. Check if the CPU is ok by using another CPU (check the Quick start guide for
CPU supported on this M/B).
4. Check if the power supply is ok. The minimum should be 250 watts.
5. Make sure the CPU fan is connected to CPUFAN1 connector.
6. Remove the M/B from the case and test the system. The M/B might be shorted to
the case.
The system power-up, no video, beeping heard.
1. Clear CMOS battery. (JP5 connector, see Quick start guide for more info on how
to clear the CMOS).
2. Check all the jumper settings on the M/B. (if the M/B have any).
3. Check the memory module and the VGA card if inserted properly on the M/B.
4. If yes, change the memory module, it might be defective. Make sure the memory
specification is supported by the M/B. (for more info on this, check our FAQ
website).
5. Change the VGA card.
The system turns on for some seconds then shutdown by itself.
1. Check if the CPU fan is connected to the CPUFAN1 connector.
2. The CPU might be overheating. Check the CPU FAN if it is defective or see if the
CPU fan is in contact with the CPU.
3. Clear CMOS battery. (JP5 connector, see Quick start guide for more info on how
to clear the CMOS).
21
SY-KT333 DRAGON Lite Quick Start Guide
4. If you already checked the power supply specification, change the power supply it
might be defective. The minimum is 250 watts.
When I boot up my system, everything works fine, it sees my CPU and memory,
detects my hard drive, floppy drive and CD-ROM but locks up at "Verify DMI pool
data... ". Don't go any further. What should I do?
1. Clear CMOS battery. (JP5 connector, see Quick start guide for more info on how
to clear the CMOS).
2. If still has the problem, remove all other add-on cards except video card see if it
move further. Then put peripherals in one by one to identify which one cause the
lockup.
3. Change the CPU.
During Boot-up, my computer says CMOS memory Checksum error. What is the
problem?
1. Clear CMOS memory.
2. Re-flash BIOS. Check on how to flash BIOS on the later part of this book.
3. Change the CMOS battery, the battery might be drained.
4. The BIOS chip might be failing.
I hear 3 beep sound before the system boot-up, is this normal?
Yes, this is normal. This is to inform the user that the system is still booting up.
I hear 1-2 beeping sound and then the system shutdown, what is the problem?
Make sure to connect the CPU fan to CPUFAN1 connector.
Stability Issue
My system intermittently locks up, very unstable
1. Check the CPU Temp, it might be overheating. Change the CPU FAN.
2. Do not over clock your CPU
3. Check the specification of the memory module, maybe the M/B do not support it.
4. Go to BIOS setup and load fail safe settings. Please check if the system
performance in the BIOS setup is set to Turbo/Maximum.
5. Check website for latest BIOS update.
6. Check website for FAQ’s regarding instability issue.
7. Change the memory module or CPU.
8. The power supply might not have enough wattage to support all the peripherals. If
your system has other peripherals connected, like CD-RW, extra HDD, etc.
disconnect them.
9. Install VIA 4 in 1 driver.
22
SY-KT333 DRAGON Lite
My system intermittently locks up, during Windows installation.
1. Go to BIOS and load “load optimized default”.
2. Check website for any BIOS update.
3. If still has the problem, remove all other add-on cards except CPU/Memory/
Video card/Hard disk. See if you can finish Windows installation. Then put
peripherals in one by one to identify which one cause the lockup.
My system will not boot-up when I set my CPU to 133MHz FSB, works with
100MHz FSB
1. Make sure to put some thermal paste above the CPU.
2. CPU might be defective.
Quick Start Guide
BIOS Issue
Where can I find the BIOS revision of my mainboard?
It will be displayed on the up-left corner on the screen during boot-up. It will show as your
board type followed by the revision number, such as kvxa_2BA1 (meaning BIOS revision
2BA1 for the SY-K7V Dragon plus! board) or 6BA+ IV_2AA2 which means SY-6BA+ IV
motherboard with 2AA2 BIOS.
Where can I find the latest BIOS of my motherboard?
Please go to the technical support page of one of the SOYO websites (Taiwan:
www.soyo.com.tw
How can I flash the BIOS?
1. Download the BIOS on our support website.
2. Make a bootable floppy disk with out any memory manager loaded (i.e. himem,
emm386, etc…).
3. Copy the BIOS file and awdflash utility to the diskette.
4. Type "awdflash biosname.bin /sn /py".
5. Then reboot.
After flashing the BIOS, my system will not boot-up.
1. Try clearing the CMOS.
2. The BIOS chip is defected due to unsuccessful flash, contact your nearest SOYO
branch for re-flashing.
), and look up your motherboard to find the latest BIOS revision.
Is there a way to reprogram my BIOS after an unsuccessful flash?
No other way, you need to send back the BIOS ROM to your nearest SOYO branch for
re-flashing.
23
SY-KT333 DRAGON Lite Quick Start Guide
VGA Issue
I cannot set my VGA to go higher than 16 color (640x 480).
1. Make sure that you have installed the VIA 4 in 1 driver.
2. Install/ re-install the VGA driver.
After wake-up from Suspend to RAM or Standby mode, the screen has no display but
I can hear the hard disk operating
1. Install VIA 4 in 1 driver.
2. Check the VGA card manufacturer for driver update, or make sure the VGA card
support Suspend to Ram function.
Audio Issue
How can I disable the on-board Audio?
Go to the SOYO Combo Feature in the BIOS setup, then set the “onboard 4CH H/W audio”
to disable.
I cannot get the sound working on my system.
1. Check if the speaker wire is connected to the line out connector in the M/B.
2. Check if the speaker power is powered on.
3. Install the audio driver supplied on our driver disc.
4. Check BIOS setup if “onboard 4CH H/W audio” is enabled.
5. If sound already installed, check our website for audio driver update.
The sound is working in my system, but when I play CD music from the CD-ROM, I
do not get any sound. What is wrong?
This is because the 3-wire audio cable from the CD-ROM to the on-board CDIN1 connector
in the M/B is not connected. See manual for location of CDIN1.
The sound from my sound card is distorted when Windows start. What is wrong?
If you are using an ISA sound card, please make sure the IRQ needed for the sound card is
set to 'Legacy ISA' in the BIOS. In other word, if your ISA sound card takes IRQ5, then set
IRQ5 to 'Legacy ISA'.
The sound and everything else works fine except that the recorder and microphone do
not work. What is wrong?
1. Please go to sound properties and check if the recorder and microphone in the are
enabled.
2. Check if Microphone is ok.
24
SY-KT333 DRAGON Lite
Quick Start Guide
Hard disk/FDD/CD-ROM issue
My Western digital HDD is not detected during boot-up
Change the jumper settings to cable select or single.
Sometimes the system finds my CD-ROM, sometimes not
1. Check CD-ROM if it is working properly.
2. The power supply might not have enough wattage to support all the peripherals. If
your system has other peripherals connected, like CD-RW, extra HDD, etc.
disconnect them.
When I boot up my new computer I got "floppy boot failure" and the LED on the
floppy stays on
Make sure the red wire of floppy ribbon cable goes to Pin1 on the floppy drive side (don't
trust the "key lock" or "notch") and use the end-connector of the cable (don't use middle one).
For updated FAQs, please check
http://www.soyousa.com/faqs.html
http://www.soyo.com.tw/faq.htm
or
25
SY-KT333 DRAGON Lite Quick Start Guide
How to contact us:
If you are interested in our products, please contact the SOYO sales department in the
region you live.
If you require Technical Assistance, please contact our Technical Support in the region
you live.
SOYO prefers Email as communication medium, remember to always add to the email the
country that you live in.
TA IWA N
SOYO COMPUTER INC.
Hong Kong
SOYO ASIA LTD.
No. 21 Wu-Kung 5 Rd., Hsing Chuang
City, Taipei Hsien, Taiwan, R.O.C.
TEL: 886-2-22903300
FAX: 886-2-22983322
http://www.soyo.com/
Email: info@mail.soyo.com.tw
USA
SOYO INC.
41484 Christy Street, Fremont, CA
94538, USA
TEL: 1-510-226-7696
FAX: 1-510-226-9218
http://www.soyousa.com/
Email: sales@soyousa.com
GM
SOYO Deutschland GmbH
(SAAT Technology GmbH)
5C, Big Star Centre, 8 Wang Kwong
Road, Kowloon Bay, Kowloon, Hong Kong
TEL: 852-2-710-9810
FAX: 852-2-710-9078
http://www.soyo.com.hk/
Email: soyo@hkstar.com
August-Wilhelm-Kuhnholz-Str. 15,
D-26135 Oldenburg (Oldb), Germany
TEL: 49-441-209100
FAX: 49-441-203442
http://www.soyo.de/
Email: sales@soyo.de
26
2
V
3
e
L
Edition: July 200
SY-KT333 DRAGON Lit
ersion 1.
SERIA
Loading...
