Page 1
BEH009
User’s manual
1. Product Description 2
2. Product General Specifications 2
2.1 General Specifications 2
2.2 Function Button / LED indicators 3
2.3 User Interface 4
3. Charging 4
4. INSTRUCTIONS 5
4.1 Power ON 5
4.2 Power OFF 5
4.3 Pairing 5
4.4 Answering incoming calls 5
4.5 Transfer a call (connect with HandsFree Profile) 5
4.6 Reject a call (connect with HandsFree Profile) 5
4.7 Volume Control 5
4.8 Mute/Un-mute the microphone 5
4.9 Ending a call 6
4.10 Making a call 6
Page 2
1. Product Description
BEH009 is a wireless Bluetooth headset, which enables users to answer incoming calls
wirelessly from Bluetooth enabled mobile phone. Also allows “wireless＂ VoIP phone calls
(like: Skype®) through Bluetooth enabled computers and PDA. The Bluetooth headset
support Headset and Hands Free Profile.
2. Product General Specifications
2.1 General Specifications
Product ID BEH009
Product Category End-user portable product
Bluetooth specification Bluetooth 1.2
Support Profile Hands-Free, Headset
Power Class Class 2
Support packet types HV1/HV2/HV3
Support hopping mode USA/EU (79 channel)
Interoperability All devices that support the Bluetooth Headset, Hands-Free
profile or Audio Gateway role
Sensitivity <[email protected]%BER
Output Power -6 ~ +4dBM
Frequency range 2400-2483.5MHz
Talk Time 4~6hrs
Standby time 170hrs
Rechargeable battery 120mA 3.7V
Power Adapter DC 5.10V / 200mA
Size 58.70mm × 21.55 mm × 15.18mm
Weight Ear Hook 16.0g
Clipper 13.0g
Page 3
2.2 Function Button / LED indicators
Symbol Functions
TALK button
Power ON/OFF: ON/press for 6 sec、OFF/press for 3
sec
Answer call: Short Press
End call: Short Press
Pairing: Under OFF mode press for 9 sec.
Volume Up button (+) Adjust volume up; mute; Transfer
Volume Down button (-) Adjust volume down; mute ; Last Number Redial
Green LED Flash 5 times when Bluetooth headset is turned on;
Flash once every 3 seconds under Standby mode;
Flash twice every 3 seconds during Incoming-call
Mode;
Flash 3 times every 3 seconds during Connected mode;
Red LED Flashes 5 times when Bluetooth headset is turned OFF.
Flashes every 20 sec when battery is low;
Red LED ON when battery is charging;
Green and Red LED cross flash under Pairing mode
DC Jack (2.3mm) Charging use
2.3 User Interface
BEH009 include Headset and Hands-free profile, the profile functions shows as below table.
The profile that is in use depends on the profile the Bluetooth device supports or is currently
operating. During each connection, there is only one profile is in use. Both profiles can not
exist at the same time in a connection. Please refer to the user’s manual of the Bluetooth
device.
Headset Profile:
Talk Button Volume Up (+) or Down (-)
Short Press Long Press Short Press
Long Press
(release when hear
a beep sound)
OFF - Power ON - -
Waiting for a call Voice Dial Power OFF - -
Start Voice Dial
Cancel Voice
Dial
Power OFF - -
Ringing Answer Power OFF - -
Call Active End call Power OFF
Adjust volume by
one step
Mute
Page 4
Hands Free Profile:
Talk Button Volume Up (+) Volume Down (-)
Volume Up (+)
and Down (-)
staus
Short
Press
Long Press
Short
Press
Long
Press
(release
when hear a
beep sound)
Short
Press
Long
Press
(release
when hear
a beep
sound)
Short
Press
Long
Press
(release
when hear
a beep
sound)
Power OFF
-
6 sec. for Power
ON
9 sec. for Pairing
- - - - -
Waiting for
a call
Initiate
Voice
Dial
Power OFF
Volume
Up
-
Volume
Down
Last
Number
Redial
Setting up
Voice Dial
Cancel
Voice
Dial
Power OFF
- - - - -
Ringing Answer
Reject(release
when hear a Do
sound)
- - - - -
Call Active
End
call
Power OFF
Volume
Up
Transfer
Call to
phone
answer
Volume
Down
Last
Number
Redial
Mute
3. Charging
The BEH009 is powered by a built-in rechargeable battery and the battery is not fully charged
when the BEH009 was packaged. Therefore, before using the BEH009 in the first time,
please charge the battery using the enclosed 5.10V DC power adapter. (When you charge
the BEH009 for the first time, please charge at least 5~6 hours.)
To charge the BEH009, you need to:
1. Connect the lead from the 5.10V DC power adapter to the charger connector and the
charger to an AC wall socket.
2. During charging, Red LED On. It takes 1.5 to 2 hours to fully recharge the battery.
3. When the battery is fully charged, Red LED will shut OFF.
Note: If Red LED flashes every 20 sec in standby mode that means the battery is low and the
needs to be recharged.
Page 5
4. INSTRUCTIONS
4.1 Power ON
1. Under “Power OFF” mode, Press and hold the TALK button for at least 6 seconds until 2
beeps are heard.
2. Green LED flashes 5 times rapidly for a few times.
3. The Bluetooth headset is now turned ON. Green LED will flash once every 3 seconds.
4.2 Power OFF
1. Under “Power ON” mode, Press and hold the TALK button for at least 3 seconds until 2
beeps are heard.
2. Red LED flashes 5 times rapidly for a few times
3. The Bluetooth headset is now turned OFF.
4.3 Pairing
Before you can use the BEH009 Bluetooth headset function, you must pair it first. To pair the
BEH009 Bluetooth headset function with the mobile Phone or Audio Gateway device, you
need to:
1. Turning the BEH009 Bluetooth headset OFF
2. Press and hold the TALK button for 9 sec. The two LEDs would cross-flash RED/GREEN,
then release the TALK button.
3. The BEH009 Bluetooth headset function is now in pairing mode and is ready to be paired
with a Bluetooth-enabled device. (Please refer to the instructions provided by
Bluetooth-enabled device to do the pairing process.)
4. The default passkey of BEH009 is ‘0000’ .
5. When pairing success, Green LED flashes every 3 seconds, it means BEH009 under
standby mode, user may accept calls. If the LEDs still cross-flashes RED/GREEN, it
means the pairing was failed. You need to go back to Step 1 and pair again.
4.4 Answering incoming calls
When a ring tone be heard at the earphone. Press TALK button to answer the call.
4.5 Transfer a call
During a phone call, hold Volume Up (+) Button and release it when hear a beep sound) to
transfer the call from headset to mobile phone
4.6 Reject a call
During a ring, hold Talk Button and release it when hear a beep sound to reject the call.
Page 6
4.7 Volume Control
Press Volume Up (+) button to turn the volume up.
Press Volume Down (-) button to turn the volume down.
4.8 Mute/Un-mute the microphone
z Press and hold both Volume Up (+) and Volume Down (-) button and release them
when hear a beep sound to mute the microphone.
z Press both Volume Up (+) and Volume Down (-) button and release them when hear a
beep sound to un-mute.
4.9 Ending a call
To finish a call, short-press TALK button.
4.10 Making a call
1. Voice Dialing
(Please check if your phone supports V oice Dialing and then follow the phone’ s user guide
to record voice tags.)
During standby mode, Press TALK button.wait for a beep sound then say the name of the
recorded voice tags you want to call.
2. Using mobile phone to dial
Just Input dial number form mobile phone and press the dial button
3. Last Number Redial (connect with HandsFree Profile)
During standby mode, Press Volume Down (-) and release when hear a beep sound to
auto redial last number.
