SoundTraxx Coach Lighting Decoder User Manual

SoundTraxx Accessory Decoder
User’s Guide For the Blackstone Models
Open Platform Passenger Coach and
Long Caboose Lighting Decoder
Software Release 1.00
Notice
The information in this document is subject to change without notice.
SoundTraxx (Throttle Up!) shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance or use of this material.
This document contains information protected by copyright. No part of this document may be photocopied or reproduced in any form without the prior written consent of Throttle Up! Corp.
Product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.
SoundTraxx, SoundTraxx DCC, and Hyperlight are trademarks of Throttle Up! Corp.
Table of Contents
All Aboard! ...........................................................................1
Overview ................................................................................................1
Operation .............................................................................2
Using Your SoundTraxx Lighting Decoder ............................................. 2
Basics of Programming ......................................................3
Programming the CVs ........................................................................... 3
Basic Programming ............................................................9
Step 1: Conguring the Address ............................................................9
Step 2: Conguring the Decoder ......................................................... 11
Step 3: Conguring the Lighting Outputs.............................................12
Step 4: Conguring for Consist Operation ........................................... 16
Step 5: Function Mapping....................................................................17
Step 6: Analog Mode ...........................................................................20
Troubleshooting ................................................................ 22
Appendix A - Decimal-Hex-Binary Conversion ...............23
Appendix B - List of Conguration Variables .................24
Overview
All Aboard!
Congratulations on the purchase of your SoundTraxx lighting decoder for Blackstone Models Long Caboose and Open Platform Coaches. This user’s guide will walk you through the various aspects of programming your decoder, as well as some tips for troubleshooting. For instructions on wiring and a wiring diagram please refer to the decoder’s packaging.
Technical Bulletins and Application Notes covering various topics are also published from time to time, and these may be downloaded free of charge from our website at www.soundtraxx.com.
SoundTraxx Lighting Decoder User’s Guide Page 1
Operation
Using Your SoundTraxx Lighting Decoder
Your SoundTraxx decoder has been shipped with all CVs pre-programmed so you can begin using it in your model right out of the box without any programming at all. Install your lighting decoder according to the installation instructions that were included with the product. The default function assignments are as follows:
Mobile Decoders
Function Key Effect
F0 Hyperlight Lighting Output F5 Interior Lights F6 Hyperlight Lighting Output F7 Dimmer
While these are the default settings, you may wish to make changes to the function mapping later. For now, simply set your model on the track, select address 3, and press F5 to light the interior. As you can see, no programming is necessary to enjoy your lighting decoder, but you will probably wish to change the address to the number of the individual coach or caboose. Alternatively you can assign a consist address that makes up the train ID for a string of passenger coaches. The following section will introduce you to CVs and how and why you may wish to change them.
SoundTraxx Lighting Decoder User’s Guide Page 2
Basics of Programming
Programming the CVs
What is a CV?
CV stands for Conguration Variable, which is the industry-adopted term for a decoder’s user-programmable memory locations. CVs allow you to customize individual decoder properties such as the address, momentum, throttle response, and much more. Once a CV has been programmed, the setting will be permanently remembered even after the power has been turned off. A CV can be modied as often as necessary by simply reprogramming it with a new value.
With the large number of CVs available, rst inspection of the available options may cause confusion and little panic! Relax. As you have already seen the decoder has been shipped with all CVs pre-programmed so you can begin using your locomotive immediately without having to worry about what adjustments to make.
The following paragraphs break the decoder’s CVs into various subsystems so it is only necessary to change a few CV’s at a time. As you become comfortable with it’s operation, move onto a new section and begin exploring the options and capabilities found there. For more technically inclined users, detailed information on any CV can be found in the Coach and Caboose
Lighting Decoder Technical Reference.
Bits and Bytes
One of the most confusing aspects of programming a CV is guring out what all the different bits, bytes and x’s found in the various decoder manuals mean. The problem is compounded further by differences in each command station manufacturer’s user interface. For users unfamiliar with such terms, a short math lesson (ugh!) is in order before proceeding:
Each decoder CV stores a numeric value that can be represented in one of three forms:
Decimal - This is the form everyone is familiar with and we use in our day-to­day lives. Numbers are represented as a sequence of digits composed of the numerals 0,1,2,3,4,5,6,7,8, and 9.
Hexadecimal - Also referred to as simply “hex”, this is a more specialized number representation that, in addition to 0 through 9, also uses the characters A-F. It has the advantage that a given decimal number can be more compactly represented. For example, the decimal number 127 converts to a simple 7F in hex (one less digit). This allows user interfaces with a limited number of digits (i.e., the LCD on your cab) to display a wider range of numbers.
Binary - Binary numbers get their name from the fact they use only two digits 0 and 1 called ‘bits’ and is the fundamental number system used by all computers including the ones found inside a digital decoder. Because there
SoundTraxx Lighting Decoder User’s Guide Page 3
Basics of Programming
are only two bit values, it takes more digits to represent a number using binary. The decimal number 127, for example, is written as 01111111 in binary notation. A ‘byte’ is a binary number made up of eight bits. And a ‘nibble’ is half a byte or four bits. Really! We didn’t make that up.
Coincidentally, each CV is made up from one byte or eight bits and can store any number between 0 and 255. Most of the CVs contain a single piece of data that can be easily represented in any of the three forms, i.e., CV 3, the acceleration rate, can be loaded with any value from 0 to 255 and it always affects the same thing - the acceleration rate.
On the other hand, some CVs use individual bits to control different features. This allows up to eight individual features to be controlled by a single CV and is done to conserve the number of CVs. As the bit variables can take on only one of two values (0 and 1) they are usually used for simple variables that are either On or Off, enabled or disabled or something similar. Unfortunately, bit variables are difcult to represent in any form other than binary and still preserve any meaning. Because most DCC system user interfaces don’t use binary representation, these numbers are the most difcult to work with and require a tedious series of additions to convert to the decimal or hex form used by most systems.
We have tried to use the decimal number system in this manual when describing the proper values to program into a given CV; however, you will occasionally nd values listed in the Technical Reference in binary, hex and decimal values. Hex numbers can be distinguished from a decimal number by noting a 0x prex. Thus 0x10 is the hex version of sixteen and not ten as one might guess. Binary numbers are represented using a ‘b’ sufx. 100b is really the number four and not one hundred. To further assist the math­impaired, we have provided a handy-dandy conversion table in Appendix A that allows one to quickly convert between decimal, hex and binary.
When working with individual bits such as in CV 29, we suggest the following procedure for determining the correct value to program. Referring to the CV description, write down the value desired for each individual bit. Consider for example, the case of CV 29. We would like to set this CV so that speed tables are enabled and the 28 speed-step mode is in effect. Referring to the Technical Reference, we see that bit 4 and bit 1 should be set to 1 and all other bits are cleared to zero. Remembering that we are dealing with binary, write down the individual bit values and we get:
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
We then look up the binary value 00010010b in Appendix A and see that it corresponds to the decimal value 18 (0x12 in hex). This is the value to use
when programming the CV.
SoundTraxx Lighting Decoder User’s Guide Page 4
Basics of Programming
If you don’t have the conversion chart available, you can also calculate the value in the following manner. Reading from right to left, each bit has a decimal value associated with it, beginning with a 1 and doubling this value as you go from bit 0 to bit 7. This value is only counted when the bit is a ‘1’. Looking at the gure below, you can see that using this method, bit 1 has a value of 2 and bit 4 has a value of 16. Adding these two numbers together gives the correct decimal value of 18.
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
When bit is set to 1, value = 128 64 32 16 8 4 2 1
Therefore: 0 + 0 + 0 + 16 + 0 + 0 + 2 + 0 = 18
Programming Methods
There are two methods for changing the decoder’s CVs:
Service Mode Programming - This programming mode usually requires the locomotive to be placed on a special programming track or connected to a dedicated programmer. Your decoder can support four types of service mode
instructions:
Address Mode - Can change CV 1 (Primary Address) only. Register Mode - Can change CVs 1,2,3,4,7,8 and 29 only. Paged Mode - Uses a page register to indirectly modify any CV. Direct Mode - Can directly change any CV.
Operations Mode Programming - Sometimes called ‘Ops Mode’ or ‘Programming on the Main’, this programming mode allows the CVs to be changed while the locomotive is operating on the layout even when other locomotives are present. The neat thing about this mode is that the CVs can be changed in the middle of operation allowing the engineer for example, to increase the momentum rate of a locomotive after it couples to a train. The main disadvantage of operations mode programming is that the CV data cannot be read back to verify its value.
Programming and Reading CVs
Although your decoder will accept any changes you make on a programming track the decoder will not successfully read back a CV value because there is no motor load on to the decoder. Decoders generate a current pulse to the motor to create an acknowledgement. Without the motor load the command station has no way of receiving the acknowledgement from the decoder. Furthermore, the Super Capacitor interferes with the read back process.
To verify that the decoder has accepted the programming watch the interior lights for a ‘blip’ (a quick change in brightness). This is the lighting decoder’s way of showing an acknowledgement pulse. It is also important to understand that when you attempt to program on a programming track you must rst wait for the capacitor to fully discharge or else it cannot program
SoundTraxx Lighting Decoder User’s Guide Page 5
Basics of Programming
the CVs in the decoder. Simply remove the model from the mainline and wait for the lights to turn off. This will indicate the SuperCap has discharged. (This usually takes between 35 and 120 seconds depending on the values you have in CV 55 and 56 as well as how many bulbs you have on the outputs.)
Programming Procedure
As each DCC system is different, the procedure for programming a CV will vary depending upon the system. Unfortunately, we cannot provide detailed instructions to cover every command station and have to assume that you have some level of understanding regarding it’s capabilities and operating procedures. For specic programming procedures, please consult your DCC system manual.
Locking and Unlocking CVs
The CV Lock/Unlock is a relatively new feature available in some DCC decoders which allows you to program a decoder without the danger of overwriting the programming in another. This especially useful in installations where multiple decoders are used. For example, if you have installed a function decoder in addition to the mobile decoder, you may wish to lock the CVs after programming to prevent accidentally programming one or the other.
CV 15 and 16 are used for locking and unlocking the decoder. To use the CV Lock feature implemented in CV 15 and 16, Bit 0 of CV 30 must rst be set to 1 (the default value is 0). This is to avoid inadvertently locking the decoder when the CV Lock feature is not needed.
CV 15 is the Unlock Code and may be programmed to any value between 0 and 255 regardless of whether the decoder is locked or unlocked. CV 16 is the Lock Code and may be set to any value between 0 and 7 but only when the decoder is unlocked. Attempts to program CV 16 with a value greater than 7 will be ignored.
The decoder is unlocked when the value in CV 15 matches the value in CV
16. Otherwise the decoder is locked and can not be programmed in either operations mode or service mode. Further, a locked decoder can not be reset to its factory defaults until it is rst unlocked. These decoders are shipped from the factory with all CVs unlocked, that is, CV 15 and 16 are both set
to 0.
Note that if the decoder is unlocked, changing the value in CV 16 will instantly lock the decoder. You must then set CV 15 to the same value as was just programmed into CV 16 to unlock the decoder again.
If you decide to use the CV Locking feature for a multi-decoder installation, each decoder installed inside that locomotive must rst have its Lock Code in CV 16 set prior to installation of any other decoders. Otherwise, all the decoders will have the same Lock Code and the feature will not work. The easiest way to go about this is to rst install one decoder and program its Lock Code. Then install the next decoder and program its Lock Code. Since
SoundTraxx Lighting Decoder User’s Guide Page 6
Basics of Programming
the rst decoder is now locked it will be unaffected by the programming of the second decoder (unless you accidentally set the Lock Code of the two decoders to the same value. If this happens you will need to disconnect one decoder and start over). Continue in this manner until all decoders have been installed and their Lock Codes have been set.
It is a good idea to set up a standardized system so you don’t forget the Lock Code settings. You might, for example, set all motor decoders to a CV Lock Value of 1, sound decoders to a value of 2 and function decoders to a value of 3. Keeping CV 15 set to 0 will guarantee the decoder stays locked until you are ready to begin programming.
Example: Let’s say you will be installing a motor decoder, a sound decoder and a function decoder in one locomotive. Using the previously described system, you would rst install the motor decoder and set its Lock Code by programming CV 16 to 1. Since CV 15 is currently set to 0 (the default value), the decoder is immediately locked. Now install the sound decoder and set its Lock Code by programming CV 16 to 2. Since CV 15 is still set to 0, this decoder is also immediately locked. Now install the function decoder and set its Lock Code by programming CV 16 to 3. At this point, all three decoders are installed and locked. Starting with the motor decoder, set CV 15 (the Unlock Code) to 1 to unlock and program the motor decoder. When you are nished set CV 15 to 2 and program the sound decoder. Finally, set CV 15 to 3 and program the function decoder. When you are done, set CV 15 back to 0 to lock all the decoders.
If You Forget the Lock Code
As there are only eight possible combinations, you can easily determine a forgotten Lock Code setting using trial and error with the following procedure:
Place the model on the programming track and set CV 15 to 0, then attempt to set CV 16 to 0. If the decoder’s lights ash then it is unlocked. If it does not ash its lights then it is locked. If the decoder is locked set CV 15 to 1 and then try setting CV 16 to 1. If the decoder’s lights ash it is unlocked. If it remains locked continue the exercise with values 2-7 until CV 16 causes the decoder to ash its lights. Once the lights have ashed the decoder is unlocked and you can make any CV changes you desire.
Troubleshooting Tip
Be aware that even if you are not planning to use the CV Lock feature, it can still be accidentally activated by inadvertently programming CV 15 or 16 with a non-default value. If you have a decoder that is otherwise working (i.e. responding to function commands) but has suddenly stopped accepting CV changes, then rst run through the procedure under “If you Forget the Lock Code” to determine if the decoder has been locked.
SoundTraxx Lighting Decoder User’s Guide Page 7
Basics of Programming
Resetting the CVs or Starting Over
Occasionally, something goes wrong and the decoder will not respond as expected. Usually, this is caused by one or more CVs being programmed to the wrong value. The CVs can be quickly reset to their factory default values using the following procedure.
1. Program CV 30 to 2 (or CV 8 to 8) using either Service Mode or
Operations Mode
2. Place the model on a powered section of track. If it is already on the mainline, cycle power to the decoder by turning power to the track off and then back on. (Remember you must allow the capacitor to discharge.)
3. After power is restored to the track there should be no indication of activity.
4. After a six-second time period, the interior light will blink 16 times indicating that the CVs were successfully reset.
5. The decoder should now respond to short address 3 just as it did when it was rst unpacked.
6. If you cannot get the decoder to reset, check to see that it has not been inadvertently locked (see “If You Forget the Lock Code” in the previous section).
SoundTraxx Lighting Decoder User’s Guide Page 8
Basic Programming
Step 1: Configuring the Address
The rst group of CVs you will want to change are those that set your
Lighting decoder’s address:
CV 1, Primary Address CV 17:18, Extended Address
The decoder may be set up to recognize either the primary address (also called the short address), which provides a range of 1 to 127 or the extended (long) address, which has a range of 0001 to 9999! Whether you use the primary or extended address will rst depend on whether or not your DCC system uses extended addressing (not all of them do - if in doubt, see your command station owner’s manual.) Second, it will depend on your preferences and the numbering scheme you use for setting your decoder addresses. The extended address has the advantage that you can use all four digits of a caboose or coach’s road number for the decoder address making it easy to remember. Be aware that some DCC systems do not support the full range of available addresses.
Primary Address
To use the primary address, simply set CV 1 to the desired address between
1 and 127.
Programming Notes: Both the primary and extended address may be changed at any time using service mode.
Some DCC systems will also allow the decoder address to be modied using operations mode programming (consult your system manual for details). Please note that when programming in operations mode, the following restrictions apply:
If the decoder’s primary address is enabled (i.e., CV 29, bit 5 is 0), only the extended address may be changed using operations mode
programming.
If the decoder’s extended address is enabled (i.e., CV 29, bit 5 is 1), only the primary address may be changed using operations mode
programming.
Extended Address
The extended address is actually made up of two CVs, 17 and 18. Unless you are an experienced user, you should not try to program these CVs individually as a specic protocol is required in order for the decoder to accept the new data (See the Technical Reference for details). Since most command stations that support extended addressing will automatically generate the correct protocol, simply follow their instructions for setting the
extended address.
SoundTraxx Lighting Decoder User’s Guide Page 9
Basic Programming
Once the extended address is stored in CV 17 and 18, bit 5 of CV 29 must be set to 1 so the decoder will recognize the extended address format. Otherwise, the decoder will continue to respond only to its primary address. See the next section, Conguring the Decoder.
SoundTraxx Lighting Decoder User’s Guide Page 10
Basic Programming
Bit 7 Bit 0
Step 2: Configuring the Decoder
The next CV you will want to change is CV 29, Decoder Conguration Byte. CV 29 is one of those complicated bit variables mentioned earlier and is used in conjunction with other CVs to set a multitude of decoder characteristics including Direction, Speed Step Mode Selection, and Alternate Power Mode Enable.
0 0 EAM RES ACK APS F0 DIR
Direction - Causes the decoder to invert direction commands so that the coach’s lights run in reverse when it receives a command to move forward and vice-versa. This is only if you are using the F0(f) and/or F0(r) outputs on the decoder. It will not affect the FX5 or FX6 outputs.
Speed Step Mode Selection - As it is a digital system, your decoder splits the throttle voltage over its minimum and maximum range into discrete speed steps. The decoder can be congured so there are 14, 28 or 128 individual speed steps. Since not all DCC systems have the ability to control 28 or 128 speed steps, your choice will depend upon the technical capabilities of your command station. Running your decoder in the wrong speed step mode will make the F0 lighting outputs ash on and off.
Primary or Extended Address - Sets the decoder to recognize its primary address in CV 1 or extended address in CV 17:18 (see “Conguring the Address”, page 13).
Alternate (Analog) Power Mode - Enables the decoder to work with an alternate power mode (such as DC operation) as set by CV 12 when a DCC signal is not present.
To assist the novice user, we have created Table A on page 16 that lists the correct value for CV 29 to get the desired operating modes.
To use the table, simply nd the row that has the modes you want and program CV 29 with the listed value.
The advanced user should refer to the Technical Reference for more details. Remember, table values are in decimal. If your command station uses Hex (Hexadecimal), you will need to convert the value shown using Appendix A.
SoundTraxx Lighting Decoder User’s Guide Page 11
Basic Programming
Bit 7 Bit 0
Step 3: Configuring the Lighting Outputs
SoundTraxx Lighting decoders have up to four function outputs used for controlling the car lights.
Each can be set for a variety of effects or as simple on/off lights. In addition, you can use the Grade Crossing Logic to automatically activate the selected lighting effect when you activate function 2.
There are eight CVs for customizing the lighting effects:
CV 49, Headlight Conguration CV 50, Backup Light Conguration CV 51, FX5 Light Conguration CV 52, FX6 Light Conguration CV 55, F0 (f and r) LED Brightness CV 56, FX5 and FX6 LED Brightness CV 60, Grade Crossing Effect Hold Time.
Setting the Hyperlight Effects
Each lighting output has a corresponding CV that determines its operating
characteristics:
LED R17 XING PHSE HYPERLIGHT SELECTION
Hyperlight Select - Each output can be programmed to one of several Hyperlight™ Lighting Effects as listed in Table A (pg 15). Most effects are self-descriptive and primarily warning beacons used for diesel locomotives. Some effects, such as the Mars Light, were used in some steam engines as well.
Dimmable Headlight - The function output is normally an on/off output. If the output is on, the output level will be reduced about 60% whenever the dimmer function is on.
Mars Light - This effect simulates the sweeping gure-8 pattern of this popular warning beacon.
Pyle National Gyralite - The Gyralite is similar to the Mars Light, but generates a slow, wide, oval headlight sweep pattern.
Dual Oscillating Headlights - Similar in appearance to the common twin­sealed-beam headlight, the oscillating headlight uses a moving reector to sweep the headlight beam in a tight circular motion.
SoundTraxx Lighting Decoder User’s Guide Page 12
Basic Programming
Single and Dual Strobes - The Strobe effects simulate the white-hot burst of light associated with the Xenon Strobe. Western-Cullen D312 Rotary Beacon - This effect provides a spectacular rendition of the revolving reector and bulb assembly of the prototype warning beacon found atop many diesels of the 60’s and 70’s.
Prime Stratolite - The Stratolite was a newer version of the rotary beacon, with the prototype consisting of a revolving reector with four individual lamps arranged in a circular pattern which are electronically ashed in a clockwise sequence. The Stratolite ashes in a rather mechanical ‘stepped’ fashion, as opposed to the smooth motion of the Rotary Beacon.
Type I and Type II Ditch Lights - These are identical when operating. However, if the grade crossing logic is enabled, the Type I ditch light will revert to a steady on state when it is not ashing whereas the Type II lights will turn off.
Exhaust Flicker - This effect produces a random icker whose intensity increases with locomotive speed. This effect is best used by placing a red/orange LED in the rebox or in the smokestack. As the locomotive increases speed, it will glow brighter, imitating an increase in sparks and
exhaust gases.
Firebox Flicker (coal potbelly stove icker) - This effect produces a random icker whose intensity resembles a burning re and can be used with a lamp placed in the coal stove area of your coach. The effect is improved when two lights are used, one yellow and one red or orange and each connected to a separate function output.
Dyno-Light - This effect for steam locomotives synchronizes the lamp brightness to the “output” of the dynamo such that the lamp brightness gradually increases as the dynamo builds up speed.
Phase Select - Alters the timing of the effect so that it is 180 degrees out of phase with the other effects. This allows you to have two light effects that blink back and forth if desired. Set one effect to phase A and the other to phase B.
Grade Crossing Logic - Causes the lighting effect to become active only when function 2 has been activated (and the corresponding lighting function key is also on). A typical use would be to cause the ditch lights to ash at a grade crossing. The grade crossing logic can be used with almost all the Hyperlight effects. The on/off, dimmable headlight, Dyno-Light, FRED, exhaust icker, and rebox icker effects will not be affected. The other effects will either turn off (strobes and beacons) or revert to a steady on state (mars light, ditch lights, etc.) as appropriate to prototype practice.
Rule 17 Headlight Operation - Converts the headlight and backup light to independent, non-directional functions. When enabled, the headlight is controlled as if it were FX5, Function 5 and the backup light as FX6,
Function 6.
SoundTraxx Lighting Decoder User’s Guide Page 13
Basic Programming
LED Compensation Mode - SoundTraxx Lighting Decoder’s Hyperlight effects can be used with either incandescent bulbs or LEDs. However, because of their differences in brightness characteristics, some lighting effects will appear less life-like when initially set up with an LED. To correct this, the LED compensation mode should be enabled which will improve the contrast of the lighting effect by automatically adjusting the function output level to correct for the different brightness characteristics of an LED.
To set the Hyperlight conguration CVs, proceed as follows:
1. First nd the CV value in Table G on the next page for the desired lighting effect and operating mode.
2. If you wish to enable Rule 17 Mode, add 64 to the table value shown,
otherwise, proceed to Step 3.
3. If you’re using incandescent bulbs, skip to Step 4. If you are using LEDs, enable the LED Compensation Mode by adding 128 to the sum
computed in Step 2.
4. Program the sum computed in Step 3 into the CV corresponding to the
appropriate function output. Use CV 49 to set the headlight, CV 50 for the backup light.
Setting the LED Brightness
CVs 55 and 56 set the overall brightness of the lighting outputs. This can be helpful to decide how bright you want your marker lamps, coal stove ickering re, or rear end marker lights for your car. It can also be helpful to make the charge on the capacitor last longer. The capacitor will stay charged for around 30 seconds when you have the decoder set to the default of 100% brightness, but if you lower this to 50% the capacitor will stay charged for over 90 seconds. This can be helpful for analog operation where you may have short station stops, and want the lights to stay lit while stopped at the
station.
CV 55 adjusts the F0 (f and r) outputs while CV 56 adjusts the FX5 and FX6 outputs. The number entered into CV 55 or 56 will be the overall percentage of brightness. For example a value of 50 would make the lights half as bright as the default, which is 100. A value of 100-255 will set the output to 100% brightness while a value of 0 will disable the output.
Setting the Flash Rate and Hold Time
CV 59 is used to adjust the ash rate of the Hyperlight effect and has a range of 0-15 with 15 being the slowest ash rate. When the Grade Crossing Logic feature is enabled, CV 60 is used to adjust the length of time (in seconds) an effect will remain active after the whistle key is released. CV 60 can be programmed with any value between 0 and 15.
Example, Mars Light with Grade Crossing Logic
In this example, we will congure the headlight output for use with an incandescent bulb as a Mars Light with Grade Crossing Logic enabled. Following the steps outlined above, we proceed as follows:
SoundTraxx Lighting Decoder User’s Guide Page 14
Basic Programming
1. We rst look up the initial CV value in Table A for a Mars Light under the column labeled ‘Crossing Logic On’ and nd it is 34 for Phase A and 50 for Phase B. Since we are only setting up one light, we do not care about the Phase and choose the value for Phase A, 34.
2. Since we are not using Rule 17, we skip to Step 3.
3. Since we are not using LEDs, we skip to Step 4.
4. CV 49 (Headlight Conguration) is programmed with the value found in
Step 1 or 34.
Lastly, we need to set the grade crossing hold time to about six seconds by
programming CV 60 to 6.
Table A. Hyperlight Control Mode Settings
CV Value
Effect Type
Crossing Logic Off Crossing Logic On
On-off
Dimmable
Mars Light
Gyralite
Oscillating Headlight
Single Flash Strobe
Double Flash Strobe
D312 Rotary Beacon
Prime Stratolite
Type I Ditch Light
Type II Ditch Light
FRED
Exhaust Flicker
Firebox Flicker
Reserved
Phase A Phase B
0
1
2
3
4
5
6
7
8
9
10
11
12
13
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Phase A Phase B
32
33
34
35
36
37
38
39
40
41
42
43
44
45
48
49
50
51
52
53
54
55
56
57
58
59
60
61
Dyno-Light
SoundTraxx Lighting Decoder User’s Guide Page 15
15
31
47
63
Basic Programming
Step 4: Configuring for Consist Operation
The decoder supports advanced consist operations, which use three related
CVs:
CV 19, Consist Address CV 21, Consist Function Control 1 CV 22, Consist Function Control 2
Consists Explained
In a traditional sense a consist is a group of locomotives that are set up to respond to throttle command as a single unit. For the purpose of lighting decoders however, setting up a consist can also be helpful. This can allow you to light an entire eet of passenger cars that you can have set to one single consist address, for example the train’s ID. The consist CV (19) allows the decoders to recognize a new address assigned to the consist without changing its primary or extended address. Additionally, they allow each car to operate under the same address, but limit certain function properties to only some cars in the consist. For example, if you had a passenger train of ve cars you would want the interior lights to turn on in all ve, but you may want only the rear car to have its marker lights lit designating the end of the
train.
Consist Address
Each car in the consist is assigned the same consist address by programming CV 19 with the consist address between 1 and 127. To deactivate the consist address and restore normal operation, CV 19 must be reprogrammed to 0.
Note that when the consist address is set, the decoder will continue to respond to instructions sent to its primary or extended address except for
speed and direction data.
The decoder will not respond to operations mode programming commands sent to its consist address. These commands must always be used with the primary or extended address.
Consist Function Enable
CV 21 and 22 allow you to dene how each car individually responds to function commands sent to the consist address. When the consist is enabled, CV 21 controls which of functions 1-8 are active and CV 22 controls the F0 function for forward (F0(f)) and reverse (F0(r)), as well as functions 9-12.
CV 21 and 22 take effect only when the consist address is set. When function commands are used with the decoder’s primary or extended address, all functions will continue to work regardless of the settings of CV 21 and 22.
SoundTraxx Lighting Decoder User’s Guide Page 16
Basic Programming
Use Table B to calculate the correct value for CV 21, and Table C to calculate the correct value for CV 22. Begin by looking at Table B and determining which functions you want active in the consist and circle the number below it. When you are done, add up all the circled numbers in the row and program the total into CV 21.
Table B. Consist Function Control 1
F1 1 F2 2 F3 4 F4 8 F5
CV#
21
16
F6
32
F8
F7
64 128
Now look at Table C and do the same: add up all the circled numbers in the
row and program CV 22 with the sum.
Table C. Consist Function Control 2
CV#
22
F0(f) F0(r)
1 2
F9
4
F10
8
F11
16
Note that each decoder in the consist will require a different set of values for CV 21 and 22 depending upon your requirements.
F12
32
SoundTraxx Lighting Decoder User’s Guide Page 17
Basic Programming
Step 5: Function Mapping
Function Mapping Explained
Function mapping allows the decoder to be recongured so that function outputs can respond to a different function key input. This is especially useful for users who have throttles with less than six function keys as now they can pick and choose what effects they can control instead of being restricted to an arbitrary assignment.
There are 14 function mapping CVs - twelve CVs, 35-46 are used to assign output control to function keys 1 through 12 respectively.
The other two CVs, 33 and 34 are both for the F0 function. CV 33 controls which outputs are on when F0 is on and the car is moving forward. CV 34 controls which outputs are on when F0 is on and the car is moving in reverse. If the same output is selected in both CV 33 and CV 34, that function will turn on when the F0 function is on regardless of the cars direction.
Not all keys can control all outputs or effects. The table below shows which functions can be mapped to which outputs. Note that a function key can be set up to control more than one output.
Function Mapping Table
Control CV
Function Key
33
F0 (f)
34
F0 (r)
35
F1
36
F2
37
F3
38
F4
39
F5
40
F6
41
F7
42
F8
43
F9
44
F10
45
F11
46
F12
Bold Numbers indicate default settings.
1
1
1
1
FX 0F
FX 0R
2
2
2
2
Xing Logic
4
4
4
4
8
8
8
8
1
1
1
1
X
RESERVED
16
16
16
16
2
2
2
2
X
FX5
32
32
32
32
RESERVED
FX6
64
64
64
64
8
4
8
4
8
4
4
8
1
X
1
1
128
128
128
128
16
16
16
16
2
2
2
1
1
1
RESERVED
32
32
32
32
4
4
4
2
2
2
RESERVED
RESERVED
64
64
64
64
8
8
8
4
4
4
128
128
128
128
16
16
16
8
8
8
Dimmer
X
X
X
32
32
32
16
16
16
RESERVED
64
64
64
32
32
32
RESERVED
128
128
128
64
64
64
RESERVED
RESERVED
128
128
128
SoundTraxx Lighting Decoder User’s Guide Page 18
Basic Programming
An output can be also be controlled by more than one function key. In the second case, if an output is mapped to two function keys, either key will turn that output on, however, the output will not turn off until both function keys have been turned off.
To determine the correct CV value,
1. Find the column in the Function-Mapping Table corresponding to the function or sound effect output you wish to control.
2. Next locate the row corresponding to the function key you wish to use for controlling the selected output.
3. Note the number located in the box at the intersection of the row and column you have selected.
4. Program the CV listed in the row chosen in step 2 with the value found in
step 3.
SoundTraxx Lighting Decoder User’s Guide Page 19
Basic Programming
Step 6: Analog Mode
Analog Mode
Your SoundTraxx lighting decoder is designed to be used in both Analog (DC) and DCC Modes. The decoder has been defaulted to have analog mode operation enabled, but it is a good idea to understand how these features are enabled should any CVs be changed. First, CV 12 must be set to a value of 1 or the decoder will not recognize DC voltage. Next bit 2 in CV 29 must be enabled. Finally the lighting outputs that you wish to have light up in analog must be turned on through CVs 13 and 14. Again, all these CVs have been defaulted to operate in analog mode..
Analog Mode Operation
When analog mode is enabled, you may control your decoder using an ordinary power-pack.
The throttle must be turned up to around 4 volts to provide sufcient voltage to power up the decoder’s capacitor and internal circuitry. At this point, you will begin to see the lights turn on.
When operating in analog mode, be careful not exceed the decoder’s input voltage rating of 27 volts. When your track voltage exceeds 21 volts, the decoder will automatically shut down and begin ashing Error Code 10 on all of its lighting outputs. When you see this condition, back down on the throttle immediately.
Important: Your decoder will work best in analog mode when using a high quality, electronically regulated power pack, preferably one that supplies smooth, ltered DC power. Older rheostat style power packs and pulse power packs will result in erratic and unreliable operation and should not be used with the decoder. If your power pack provides a Pulse power switch, leave it in the ‘Off’ position.
Analog Mode Options
As discussed earlier CVs 13 and 14 must be set up to activate the functions to turn on in analog mode.
Analog Function Enables
CV 13, Analog Function Enable 1 CV 14, Analog Function Enable 2
These CVs allow you to force a function input to the ON state whenever your decoder switches over to analog mode. This is most useful for turning on lighting effects when running on a DC powered layout.
SoundTraxx Lighting Decoder User’s Guide Page 20
Basic Programming
To enable any of Functions F1 thru F8, refer to Table D below and circle the numbers corresponding to the function inputs you want to enable. Then add up the circled numbers and program this value into CV 13.
Table D. Analog Function Enable 1
F1 1 F2 2 F3 4 F4 8 F5
CV#
13
16
F6
32
F8
F7
64 128
Similarly, to enable Function F9 thru F12 or F0, refer to Table E below and circle the numbers corresponding to the function inputs you want turned on. Then add up the circled numbers and program this value into CV 14.
Table E. Analog Function Enable 2
CV#
14
F0(f) F0(r)
1 2
F9
4
F10
8
F11
16
F12
32
Note that when you enable a particular function input for analog mode operation, it has the same effect as pressing the equivalent function key on your DCC cab. The Mobile Decoder’s function mapping settings will ultimately determine which output or sound effect is activated by the enabled function. Assuming you have not changed the default function mapping, then enabling the F0(f) function in analog mode will turn on the F0(f) output.
SoundTraxx Lighting Decoder User’s Guide Page 21
Troubleshooting
Troubleshooting
If you should have any difculties with the operation of your SoundTraxx Lighting Decoder, rst check this section for hints on trouble shooting. We have found that most problems are caused by an errant CV value and are easily corrected. When all else fails, try resetting the CV values back to their defaults (see the section ‘Basic Programming’) and try again.
Lights icker on and off
Decoder is in 14 speed step mode and command station is set to 28
speed steps.
Lights do not work
Decoder is in 28/128 speed step mode and command station is set
to 14 speed steps.
Function mapping is improperly set. Burned out light bulbs. If using 1.5 volt micro-bulbs, resistor value is too large. Broken lamp wires.
If you are still having difculties, contact our customer service department for
guidance.
SoundTraxx Service Department
210 Rock Point Drive Durango, CO 81301 Telephone (970) 259-0690 Fax (970) 259-0691 Email: support@soundtraxx.com
SoundTraxx Lighting Decoder User’s Guide Page 22
Appendix A
Decimal-Hex-Binary Conversion Table
DECIMAL HEX BINARY (76543210)
0 00 00000000 1 01 00000001 2 02 00000010 3 03 00000011 4 04 00000100 5 05 00000101 6 06 00000110 7 07 00000111 8 08 00001000 9 09 00001001 10 0A 00001010 11 0B 00001011 12 0C 00001100 13 0D 00001101 14 0E 00001110 15 0F 00001111 16 10 00010000 17 11 00010001 18 12 00010010 19 13 00010011 20 14 00010100 21 15 00010101 22 16 00010110 23 17 00010111 24 18 00011000 25 19 00011001 26 1A 00011010 27 1B 00011011 28 1C 00011100 29 1D 00011101 30 1E 00011110 31 1F 00011111 32 20 00100000 33 21 00100001 34 22 00100010 35 23 00100011 36 24 00100100 37 25 00100101 38 26 00100110 39 27 00100111 40 28 00101000 41 29 00101001 42 2A 00101010 43 2B 00101011 44 2C 00101100 45 2D 00101101 46 2E 00101110 47 2F 00101111 48 30 00110000 49 31 00110001 50 32 00110010 51 33 00110011 52 34 00110100 53 35 00110101 54 36 00110110 55 37 00110111 56 38 00111000 57 39 00111001 58 3A 00111010 59 3B 00111011 60 3C 00111100 61 3D 00111101 62 3E 00111110 63 3F 00111111
DECIMAL HEX BINARY (76543210)
64 40 01000000
65 41 01000001 66 42 01000010 67 43 01000011
68 44 01000100
69 45 01000101 70 46 01000110 71 47 01000111
72 48 01001000
73 49 01001001
74 4A 01001010 75 4B 01001011
76 4C 01001100 77 4D 01001101
78 4E 01001110
79 4F 01001111
80 50 01010000 81 51 01010001 82 52 01010010 83 53 01010011 84 54 01010100 85 55 01010101 86 56 01010110 87 57 01010111 88 58 01011000 89 59 01011001 90 5A 01011010 91 5B 01011011
92 5C 01011100 93 5D 01011101 94 5E 01011110 95 5F 01011111 96 60 01100000 97 61 01100001
98 62 01100010
99 63 01100011 100 64 01100100 101 65 01100101 102 66 01100110 103 67 01100111
104 68 01101000
105 69 01101001
106 6A 01101010 107 6B 01101011 108 6C 01101100
109 6D 01101101 110 6E 01101110 111 6F 01101111 112 70 01110000 113 71 01110001 114 72 01110010 115 73 01110011 116 74 01110100 117 75 01110101
118 76 01110110
119 77 01110111
120 78 01111000
121 79 01111001
122 7A 01111010 123 7B 01111011
124 7C 01111100 125 7D 01111101 126 7E 01111110 127 7F 01111111
DECIMAL HEX BINARY (76543210)
128 80 10000000 129 81 10000001 130 82 10000010 131 83 10000011 132 84 10000100 133 85 10000101 134 86 10000110 135 87 10000111 136 88 10001000 137 89 10001001 138 8A 10001010 139 8B 10001011 140 8C 10001100 141 8D 10001101 142 8E 10001110 143 8F 10001111
144 90 10010000 145 91 10010001 146 92 10010010 147 93 10010011
148 94 10010100
149 95 10010101 150 96 10010110 151 97 10010111
152 98 10011000
153 99 10011001
154 9A 10011010 155 9B 10011011
156 9C 10011100 157 9D 10011101
158 9E 10011110
159 9F 10011111
160 A0 10100000 161 A1 10100001 162 A2 10100010 163 A3 10100011 164 A4 10100100 165 A5 10100101 166 A6 10100110 167 A7 10100111 168 A8 10101000 169 A9 10101001 170 AA 10101010 171 AB 10101011 172 AC 10101100 173 AD 10101101 174 AE 10101110 175 AF 10101111 176 B0 10110000 177 B1 10110001 178 B2 10110010 179 B3 10110011 180 B4 10110100 181 B5 10110101 182 B6 10110110 183 B7 10110111 184 B8 10111000 185 B9 10111001 186 BA 10111010 187 BB 10111011 188 BC 10111100 189 BD 10111101 190 BE 10111110 191 BF 10111111
DECIMAL HEX BINARY (76543210)
192 C0 11000000 193 C1 11000001 194 C2 11000010 195 C3 11000011 196 C4 11000100 197 C5 11000101
198 C6 11000110
199 C7 11000111
200 C8 11001000
201 C9 11001001
202 CA 11001010 203 CB 11001011
204 CC 11001100 205 CD 11001101 206 CE 11001110 207 CF 11001111
208 D0 11010000
209 D1 11010001 210 D2 11010010 211 D3 11010011 212 D4 11010100 213 D5 11010101 214 D6 11010110 215 D7 11010111
216 D8 11011000
217 D9 11011001
218 DA 11011010 219 DB 11011011
220 DC 11011100 221 DD 11011101 222 DE 11011110 223 DF 11011111 224 E0 11100000 225 E1 11100001 226 E2 11100010 227 E3 11100011
228 E4 11100100
229 E5 11100101 230 E6 11100110 231 E7 11100111
232 E8 11101000
233 E9 11101001
234 EA 11101010 235 EB 11101011
236 EC 11101100 237 ED 11101101
238 EE 11101110
239 EF 11101111 240 F0 11110000 241 F1 11110001 242 F2 11110010 243 F3 11110011 244 F4 11110100 245 F5 11110101 246 F6 11110110 247 F7 11110111
248 F8 11111000
249 F9 11111001
250 FA 11111010 251 FB 11111011
252 FC 11111100 253 FD 11111101 254 FE 11111110 255 FF 11111111
SoundTraxx Lighting Decoder User’s Guide Page 23
Appendix B
List of Configuration Variables (CVs)
The following is a quick reference list of CVs used by Tsunami. See the Tsunami Technical Reference for detailed information about their uses.
CV 1 Primary Address Control CV 7 Manufacturer Version ID (Read Only) CV 8 Manufacturer ID CV 11 Packet Time Out Value CV 12 Power Source Conversion CV 13 Analog Function Enable 1 CV 14 Analog Function Enable 2 CV 15 CV Unlock Register CV 16 CV Lock ID Code CV 17,18 Extended Address CV 19 Consist Address CV 21 Consist Function Group 1 CV 22 Consist Function Group 2 CV 29 Conguration Register 1 CV 30 Error Information/Alternate Mode Selection CV 33 FL(f) Output Location CV 34 FL(r) Output Location CV 35 F1 Output Location CV 36 F2 Output Location CV 37 F3 Output Location CV 38 F4 Output Location CV 39 F5 Output Location CV 40 F6 Output Location CV 41 F7 Output Location CV 42 F8 Output Location CV 43 F9 Output Location CV 44 F10 Output Location CV 45 F11 Output Location CV 46 F12 Output Location CV 49-52 Hyperlight Effect Select (for FL(f), FL(r), Function 5, 6) CV 55 F0 (f and r) LED Brightness CV 56 FX5 and FX6 LED Brightness CV 59 Flash Rate CV 60 Crossing Hold Time CV 62 Transponding Control CV 64 Analog Mode Max Motor Voltage CV 105 User Identier #1 CV 106 User Identier #2
SoundTraxx Lighting Decoder User’s Guide Page 24
©2011 Throttle Up! Corp.
DCC
TM
New Dimensions in Digital Sound Technology
210 Rock Point Drive Durango, CO 81301
(970) 259-0690 Fax: (970) 259-0691 Email: Sales@soundtraxx.com
All Rights Reserved.
COMPATIBLE WITH THE NMRA DCC STANDARDS AND RECOMMENDED PRACTICES
Loading...
