Soundstream Technologies SPL 55 User Manual

2 Ohm Nominal

Coaxial Speaker

OWNER’S MANUAL

55.pub
page 1

1

Friday, September 10, 1999 21:03

SPL 55 Coaxial Speaker

Congratulations on your purchase of the Soundstream SPL 55 Coaxial
Speaker. When used with a high quality 2 ohm rated power amplifier,
the SPL 55 will provide exceptional performance.

As with all high quality car audio components, professional installation
is recommended. Your dealer’s knowledge and experience can ensure
a problem-free, cosmetically integrated installation. If you plan on
installing the SPL 55 speaker yourself, please review this Owner’s
Manual first before attempting installation. In addition, it’s a good idea
to keep the manual for future reference.
SPL 55 Serial Number ______________________________________

Date of Purchase ___________________________________________
Date of Installation _________________________________________
Dealer’s Name ____________________________________________

HARDWARE

Before beginning your installation, please check to see that the number
of parts contained in your box match the list below:

CONNECTOR

Hardware

PARTS LIST

8 each - 1” #8 sheet metal screws (for mounting SPL 55)

Connectors

AND

4 each - 1/4” tab female Gold insulated slip-on connectors

2

55.pub
page 2

Friday, September 10, 1999 21:03

FEATURES

SPL 55 Midrange / Woofer

The SPL 55 is an excellent performer with a combination of high
sensitivity, solid bass and smooth response throughout the audible
range.

• Lightweight Cone designed for good rigidity and high sensitivity

• 2 Ohm Voice Coil for increased voltage sensitivity and higher

output

Aluminum Dome Neodymium Tweeter

The SPL 55's coaxially mounted tweeter is a high performance 1”
Neodymium tweeter designed to deliver outstanding high frequency
reproduction.

• Black Aluminum 1" dome for improved power handling and

linear response

• Ferrofluid-immersed Voice Coil enhances heat dissipation

• Vented Aluminum Voice Coil Former for superb heat dissipation

and high power handling

Passive Crossover Network

• The crossover consists of high quality, 2 pole design for improved
power handling, lower distortion and better imaging.

• Acoustic Summation design combines the crossover with the
speaker's natural roll-off for a steeper slope and increased power

• Dynamic tweeter protection allows for improved power handling
and continuous output

2 Ohm Nominal System Impedance

The 2 Ohm impedance design of the SPL 55 system provides an overall
3 dB increase in output compared to a 4 Ohm design.

•Effectively a doubling of Sound Pressure Level -- with the same
voltage input

•More stable, phase coherent load than two 4 Ohm speakers

3
