Soundstream TARANTULA RS.1 User's Operation Manual

FCC ID NOTICE

This device complies with Part 15 of the FCC rules. Operation is s

ubject to the following conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including inte

rference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user’s authority to operate

www.security.soundstream.com

this device.

RS.1

REMOTE VEHICLE STARTER

USER’S OPERATION GUIDE

REV.5

PAGE 2

RS.1

OWNER'S MANUAL

TABLE OF CONTENTS

Important Notes.......................................................................Page 3

Remote Start Optional Operations.........................................Pages 4-5

Lock Doors Unlock Doors

Remote Start Operations........................................................Pages 6-7

Remote Start Key Takeover
Remote Shutdown Idle Mode
Extended Runtime Turbo Timer Mode

Service Mode............................................................................Page 8

Activate Service Mode
Deactivate Service Mode

Timer Mode/ Cold Start...........................................................Page 9

Enter and Select Start Interval
Exit Timer Mode

Diagnostics..............................................................................Page 10

Diagnostic Chart

Warranty...................................................................................Page 11

Contact.....................................................................................Page 12

PAGE 3

RS.1

OWNER'S MANUAL

IMPORTANT NOTES

ATTENTION

Please take a moment to review the safety precautions before
operating your system.

1) For safety reasons, the owner/user of this system MUST INSTALL
a CARBON MONOXIDE DETECTOR in the living area near to where
the vehicle is being stored or parked.

2) It is the sole responsibility of the owner/user to keep the remote
transmitters away from the reach of children and handle with care
so that the system does not unintentionally start.

3) When the vehicle is parked in an enclosed/partially enclosed area
(ex: garage, car port...), being serviced (ex: oil change) or the
vehicle is loaned to an operator not familiar with a remote starter,
the system MUST BE placed Service Mode.

NEVER REMOTE START THE SYSTEM IN AN ENCLOSED/

PARTIALLY ENCLOSED AREA!

4) MANUAL TRANSMISSION STARTERS Never install a automatic
remote start module into a manual transmission vehicle. Doing so
could result in EXTENSIVE DAMAGE TO YOUR VEHICLE,
PROPERTY DAMAGE AND POSSIBLY CAUSE SERIOUS INJURIES
OR EVEN DEATH. IF THIS SYSTEM WAS INSTALLED IN A MANUAL
TRANSMISSION VEHICLE, RETURN TO YOUR DEALER AND HAVE
IT DISABLED UNTIL THE CORRECT MODEL CAN BE INSTALLED.

5)

PAGE 4

OWNER'S MANUAL

SYSTEM OPERATIONS

RS.1

The LOCK/ UNLOCK Button will toggle between the Lock and Unlock feature
each time the button is pressed.

NOTES:

- The LEDs can be programmed not to flash when locked by the remote
transmitter.

** Optional Feature’s may require additional parts and labor.

1. Press and release the LOCK/ UNLOCK Button on the remote transmitter.

2. The park lights will flash and the horn (optional) will honk one time.

3. The doors will lock (optional)

4. The LED on the antenna will start flashing within five seconds.

- If the system is in Service Mode the doors will Lock/ Unlock but the horn will not
honk.

- The LEDs will turn on solid if the system is in Service Mode.

See Valet / Service Mode in this manual for further information

LOCK DOORS

PRESS & RELEASE
