Soundstream RUBICON RUB.102, RUBICON RUB.104, RUBICON RUB.122, RUBICON RUB.124, RUBICON RUB.152 User Manual

2013 RUBICON

SUBWOOFERS

RUB.102 RUB.104
RUB.122 RUB.124
RUB.152 RUB.154

Thank you for choosing SOUNDSTREAM woofers. Designed and engi­neered in the USA, this product combines innovative technology with
the finest materials to consistently deliver Absolutely State of the Art
performance, sound quality, reliability, and value. This SOUNDSTREAM
product reflects our commitment to offer you unparalleled perfor­mance and quality for years of dependable service and listening en­joyment.

Pressed Paper Pulp Cone

Butylle-Rubber Surround

2.0” 4-layer VC on Aluminum Former

Nickel Plated 8ga. Compression Terminals

Poly-Cotton Suspension Spiders

Vented T-Yoke Back-plate

Woven Polyproplyene Dust Cap

Refernce Blue Stamped Steal Basket

Features, Parameters, & Dimensions

Enclosure Construction

Enclosure Dimensions

Enclosure Recommendations

www.SOUNDSTREAM.com

www.SOUNDSTREAM.com

Included in this manual are a number of different enclosure sugges­tions. These are by no means the only enclosures to use, but they
provide a starting point to determine the correct enclosure for your
needs many factors must be addressed (amount of power, vehicle,
placement, crossovers, etc) Therefore, as always, SOUNDSTREAM rec­ommends that your subwoofer be installed by an authorized SOUND-
STREAM dealer.

All enclosures should be made of .75” (3/4”) material only. When pos­sible, make the baffle 1.5” (1 ½) thick and add .75” (3/4”) to the depth
of the enclosure to compensate. All volumes INCLUDE vent/port and
subwoofer displacements. DO NOT change the volume unless you
plan on adding a substantial amount of bracing. For added per­formance, applying a coat of fiberglass resin to the interior walls will
greatly improve sealing the enclosure. Adding a thin layer of poly-fill
will improve response by smoothing out reflections within the enclo­sure.

Imp. D. 2ohm D. 4ohm D. 2ohm D. 4ohm D. 2ohm D. 4ohm
Re 2.1876 4.0370 2.1543 4.0477 2.2162 4.1146
Fs (hz) 28.30 32.86 21.69 24.13 22.33 22.66
Qes 1.0591 1.1784 0.7645 0.8962 1.6304 1.1404
Qms 2.5699 4.1909 3.7782 3.1217 5.6687 3.3447
Qts 0.7500 0.9198 0.6359 0.6963 1.2662 0.8504
Le

(mh)

0.7678 1.1611 0.7095 1.1121 0.7627 1.2266

DIam 10Inch 10Inch 12Inch 12Inch 15Inch 15Inch
sD In^2 78.5398 78.5398 113.0973 113.0973 176.7146 176.7146
Vas (L) 60.5335 119.4120 201.2519 157.2500 320.4872 326.0756
BL 8.3654 7.1181 8.8132 11.9677 7.4701 11.9778
mms 90.5191 71.6184 202.178 209.0668 292.5135 279.2097
sen 82.87 87.30 86.04 85.67 85.15 86.97
Rms/

max

450 450 500 500 550 550

cutout D.9.6Inch 9.6Inch 11.6Inch 11.6Inch 14.5Inch 14.5Inch

mount D.6Inch 6Inch 6 5/8 Inch 6 5/8 Inch 7.25Inch 7.25Inch

RuB-102 RuB-104 RuB-122 RuB-124 RuB-152 RuB-154

seaLeD RuB-102/104 RuB-122/124 RuB-152/154
m

In .75 cu Ft 1.25 cu Ft 1.5 cu Ft

optImum 1.0 cu Ft 1.75 cu Ft 2.5 cu Ft
poRteD
mIn 1.0 cu Ft 1.75 cu Ft 2.5 cu Ft
poRt WxL 4”x10” 4”x4” 6”x4.5”
F3 (h

z) 50 48 41

optImum 1.5 cu Ft 2.0 cu Ft 3.0 cu Ft
poRt WxL 4” x 7.5” 5” x 8.5” 6” x 2.7”
F3 (h

z) 43 39 34
