Page 1
-30
WARNING
been dropped.
TG100
USAGE:
1.
SOUNDSATION TG100 is a desktop gooseneck
microphone is a professional microphone designed
for applications such as large-scale conferences,
public addresses, outdoor speeches etc.
It adopts a back electret condenser cartridge,
which delivers bright and clear sound. This
uni-directional microphone featuring high sensitivity
and low self-noise can operate by battery power or
via phantom power received from an external device
like a mixer . Its flexible gooseneck can be adjusted
smoothly and quietly to fit any needs and situations
and a red LED conveniently mark the on-off state.
The zinc base of the microphone has been designed
with focus on stability and duration over time.
TECHNICAL SPECIFICATIONS
Element：φ9.7mm Back Electrect Condenser
Polar Pattern: Uni-directional
Frequency Response: 100Hz-13kHz
Sensitivity: -38dB±3dB(0dB=1V/Pa at 1kHz)
Output Impedance: 200Ω±30%(at 1kHz)
Operating Voltage: Phantom Power 9-52V or 3V Battery
Battery Type: AA/UM3,1.5V
1. Do not cover the microphone cartridge by hands or install the unit close to speakers as it may cause howling noise. If this happens, simply turn down the volume,
2. Only use attachments/accessories specified by the manufacturer.
3. Unplug this apparatus during lightning storms or when unused for long periods of time.
4. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is
-40
-50
-60
(dBV/Pa)
-70
20 2K
take the microphone further away from the speakers, and let the cartridge not face the speakers
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has
50 100 200 500 1K 5K
(Hz)
Frequency Response Graph
1. Install two 1.5V AA batteries at the base of the gooseneck
2. Connect the gooseneck microphone to its base.
3. Plug the XLR connector of the attached cable and connect the
4. Turn the volume control down to zero then turn on the power
5. The best distance from the microphone cartridge while
The box contains:
Gooseneck microphone
Powered base (
Windscreen
XLR F to XLR M 3 meter cable
Two AA size batteries
Desktop Gooseneck Microphone
microphones. ( be aware of their polarities ). If using the
phantom power, please connect the parts according to the
following drawing.
PHANTOM POWER
XLRF
20K
SUPPLIER
TABLE GOODSENECK
MICROPHONE
)
AMPLIFIER,
MIXER,
POWER AMPLIFIER
microphone to a mixer.
switch of both the mixer and the microphone and adjust the
volume.
speaking should be kept at 5 to 30 cm.
by N 2 AA 1,5 alkaline batteries or 48V phantom power
SOUNDSATION is a trademark of FRENEXPORT SPA – Via Enzo Ferrari , 10 – 62017 Porto Recanati – Italy www.soundsationmusic.com
Page 2
MA DE I N CH IN A
