Thank you for purchasing Soundsation Spiral Looper Pro-FX.
Before operating it, please read the following instructions.
1. Right Footswitch
2. Left Footswitch
3. Effect state indicator
4. LOOPER state indicator
5. Right input
6. Right output
7. Left input
8. Left output
9. Mode Switch: STOP/FX
10. Mode Switch:
CHANGE: change left and right channel
FORWARD: Forward play
REVERSE: Reverse play
(Rercording function disabled)
11. Record/Play rate
12. Left output level
13. DC9V( )
14. Right output level
15. USB interface
(File Import/Export and system upgrade)
With SPIRAL LOOPER you can easily export your loops in Wav format to you computer (PC/Mac).
You can also import Wav files from computer to your looper and play them immediately.
Download and install the SPIRAL MANAGER software (available for PC and Mac)
Download the SPIRAL MANAGER free software at www.soundsationmusic.
com/en/services/product-downloads or visit product page at
www.soundsationmusic.com
Unzip and run the .exe file
To EXPORT your loop:
Once you have recorded your loop, simply connect the looper to your computer via USB
cable (included). You don’t need to use the DC adaptor, your loop remains stored when
you turn the pedal off.
Click ‘Export’ to save in your file in the desired folder with the desired name. Done!
To IMPORT your loop:
Connect your looper to your computer via USB cable (included). You don’t need to use the
DC adaptor, USB will power the looper on.
Click ‘Import’ and choose the desired loop in your folders. Done!
NOTE: Only Wav files are allowed for import/export features. You can import
only one loop per session in your looper. This means that if your import a
new loop you will override the stored one.
Left Footswitch Right Footswitch
REC/PLAY/OVERDUB
PRESS ONCE
RECORD
PRESS AND HOLD PRESS AND HOLD
PRESS TWICE PRESS AND HOLD
PRESS ONCE
PLAY
UNDO/REDO
UNDO REDO
STOP/CLEAR
STOP CLEAR LOOP
PRESS ONCE
OVERDUB
STOP MODE
PRESS ONCE HOLD
STOP CLEAR LOOP
FX MODE
PRESS ONCE
FX ON
PRESS ONCE
FX OFF
◆ Maximum Recording Time: 10 Minutes
◆ Maximum Overdubbing Times: Unlimited
◆ True bypass circuit
◆ Bit rate: 24 bit
◆ Working Current: 100mA
◆ Dimensions: 116(D)*90(W)*35(H)mm
◆ Weight: 522g (with box)
◆ Power Supply: DC 9V (Center Negative)
◆ Accessories: Manual, USB cable, downloadable software (PC/Mac)
Made in china
SOUNDSATION is a registered trademark of FRENEXPORT SpA. All rights reserved
