SOUNDMASTER NR976 User Manual [en, de]

Download

Page 1

DEUTSCH

ESPANOL

ENGLISH

PORTUGUÊS

FRANÇAIS

SLOVENSKÝ

NEDERLANDS

ČEŠTINA

ITALIANO

MAGYAR

NR976

Hersteller

Wörlein GmbH Tel.: +49 9103/71670 Gewerbestrasse 12 Fax.: +49 9103/716712 D 90556 Cadolzburg Email. [email protected] GERMANY Web: www.woerlein.com

Page 2

Safety, Environmental and Setup Instructions

ENVIRONMENTAL PROTECTION

Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging

The materials are reusable according to their markings. By reusing, recycling or other forms of utilization of old devices you make an important contribution to the protection of our environment.

Please contact your local authorities for details about collection

points.

WARNING

Risk of electric shock

Do not open!

Caution: To reduce the risk of electric shock, do not remove the

cover (or back). There are no user serviceable parts inside.

Refer servicing to qualified service personnel.

This symbol indicates the presence of dangerous voltage inside the enclosure, sufficient enough to cause electric shock.

This symbol indicates the presence of important operating and maintenance instructions for the device

Used batteries are hazardous waste and NOT to be

disposed of with the household waste! As a

consumer you are legally obligated to return all

batteries for environmentally responsible recycling –

no matter whether or not the batteries contain harmful

substances*)

Return batteries free of charge to public collection points in your

community or shops selling batteries of the respective kind.

Only return fully discharged batteries

*) marked Cd = cadmium, Hg = mercury, Pb = lead

 Only use mercury and cadmium-free batteries.  Used batteries are hazardous waste and NOT to be

disposed of with the household waste!!!

 Keep batteries away from children. Children might swallow

batteries.

 Contact a physician immediately if a battery was swallowed.  Check your batteries regularly to avoid battery leakage.  Batteries shall not be exposed to excessive heat such as

sunshine, fire or the like.

 CAUTION: Danger of explosion if battery is incorrectly

replaced

 Replace only with the same or equivalent type

CAUTION - INVISIBLE LASER

RADIATION WHEN OPENING THE

COVER OR PRESSING THE SAFETY

INTERLOCK. AVOID EXPOSURE TO

THE LASER BEAM.

To prevent possible hearing damage, do not listen at high volume levels for long periods

 Use the device in dry indoor environments only.  Protect the device from humidity.  This apparatus is for moderate climates areas use,

not suitable for use in tropical climates countries.

 No objects filled with liquids, such as vases,

shall be placed on the apparatus.

 The mains plug or an appliance coupler is used

as the disconnect device, the disconnect devices shall remain readily operable.

 Connect this device to a properly installed and

earthed wall outlet only. Make sure the mains voltage corresponds with the specifications on the rating plate.

 Make sure the mains cable stays dry during

operation. Do not pinch or damage the mains cable in any way.

 A damaged mains cable or plug must

immediately be replaced by an authorized service center.

 In case of lightning, immediately disconnect the

device from the mains supply.

 Children should be supervised by parents when

using the device.

 Clean the device with a dry cloth only.  Do NOT use CLEANING AGENTS or ABRASIVE

CLOTHS!

 Do not expose the device to direct sunlight or

other heat sources.

 Install the device at a location with sufficient

ventilation in order to prevent heat accumulation.

 Do not cover the ventilation openings!  Install the device at a safe and vibration-free

location.

 Install the device as far away as possible from

computers and microwave units; otherwise radio reception may be disturbed.

 Do not open or repair the enclosure. It is not safe

to do so and will void your warranty. Repairs only by authorized service/ customer center.

 No naked flame sources, such as lighted

candles, should be placed on the unit.

 When you are necessary to ship the unit store it

in its original package. Save the package for this purpose.

 In case of malfunction due to electrostatic

discharge or fast transient (burst), remove and reconnect the power supply.

 If the unit is not using for a long period of time,

disconnect it from the power supply by unplugging the power plug. This is to avoid the risk of fire.

Page 3

NR976 / English Instruction Manual

PREPARATION FOR USE

UNPACKING AND SET UP

• Carefully remove the unit from the display carton and remove all packing materials from the unit.

• Unwind the AC power cord and extend it to its full length.

• Unwind the UKW Antenna wire and extend it to its full length.

• Place the unit on a stable, level surface, convenient

to an AC outlet, out ,of direct sunlight and away from sources of excess heat, dust, moisture, humidity or strong magnetic fields.

• Open the CD door. Lift the CD diskette cover, remove the transit card which was used to secure the laser during shipment and dispose of this card

• Connect the plug to your AC outlet.

POWER SOURCE

This system is designed to operate on normal 230V 50Hz AC only. Attempting to operate this system from any other power source may cause damage to the system and such damage is not covered by your warranty.

IMPORTANT: Raising And Lowering The CD Door

• To open the lid, raise it as far as it will go until the lid support bracket ‘locks’ into the open position

• To close the lid, lift it upward slightly until the lid support bracket ‘unlocks’ and then gently lower the lid.

TO AVOID DAMAGING THE CABINET OR THE LID, NEVER FORCE THE LID

CLOSED.ALWAYS RAISE THE LID TO RELEASE THE LID SUPPORT BRACKET.

Door support bracket, pull forward to release and lower door.

To Raise The Door, Lift Here.

Page 4

NR976 / English Instruction Manual

LOCATION OF CONTROLS AND INDICATORS

FRONTPANEL

1. UKW Tuning Dial Scale

2. VOLUME Control

3. CD Door Support Bracket

4. CD Door

5. CD Tray

6. CD Control Buttons

7. Speaker

8. PHONES Jack

9. Function Buttons (CD/UKW/POWER)

10. TUNING Control

TOPVIEW (CD-PLAYER)

11. PROGRAM Indicator

12. CD Number Track Display

13. REPEAT/ALL Button

14. PROGRAM Button

15. B.SKIP Button

16. F.SKIP Button

17. PLAY/PAUSE Button

18. STOP Button

19. CD Diskette Cover Lifter

BACKPANEL

20. AC Power Cord

21. FM Antenna

Page 5

NR976 / English Instruction Manual

OPERATING INSTRUCTIONS

Listening to the Radio

1.) Press the “POWER” button and set the volume to the lower level. The tuning backlight

lights up.

2.) Rotate the “TUNING” control to tune to the desired station.

3.) Adjust the “VOLUME” control as desired.

4.) When you have finished listening, press the “POWER” button again to turn off the unit. The

tuning backlight light goes off.

Antenna Information

UKW- The UKW wire antenna is located on the back cabinet. If necessary, adjust the position and direction of this antenna until find the position that provides the best reception.

Playing Compact Discs

1.) Press the “POWER” button and set the volume to the lower level. The tuning backlight lights up.

2.) Press the function (CD) for the CD function. The CD track number display comes “On”.

3.) Place your disc on the CD spindle with the printed label side facing up and lower the CD cover.

4.) The disc will spin for a few seconds while the player reads the disc. Afterwards the display shows the number of content.

Start the playback of the CD by pressing the “PLAY/PAUSE”

button. Now the actual track number is shown in the display.

Note: You may leave the CD door open during playback if you wish,

but it is recommended to close it for better sound and also to prevent excess dust from accumulating on the CD spindle.

5.) Adjust the “VOLUME” control as desired.

6.) Playback will continue until the end of the disc. When the disc ends the display shows the total number of tracks and the disc. You may also stop playback at any time by pressing the “STOP” button.

Page 6

NR976 / English Instruction Manual

Pause Control

In play mode, press the “PLAY/PAUSE” button once. Pause playback but the disc continues to spin and the display flashes.

Press the “PLAY/PAUSE” button once more to cancel pause and resume playback. The display stops flashing.

Skipping Tracks and High Speed Music Search

During CD/R-RW playback, repeatedly press the “F.SKIP” (Forward Skip) or “B.SKIP” (Back Skip) button to select the desired track or by press and hold one of the buttons to find the desired passage of the track.

Repeat Playback

This feature allows you to continuously repeat a single track or the entire disc.

To Repeat A Single Track Press the “REPEAT/ALL” button once. The Repeat indicator flashes. Press

the “B.SKIP” or “F.SKIP” button to select the desired track, then the unit begins to repeat playback of the selected track

To Repeat The Entire Disc Press the “REPEAT/ALL” button twice. The repeat, indicator remains On

and the unit begins to repeat playback of the entire disc.

To cancel repeat playback, press the “REPEAT/ALL” button until the repeat Indicator goes ‘Off’ . Repeat playback is also cancelled by pressing the “STOP” button or setting the function selector

to the UKW position.

Page 7

NR976 / English Instruction Manual

Programmed Playback

This feature allows you to program 20 CD tracks on a disc for playback in any desired order.

Note: You can program tracks while a disc is stopped.

1.) Press the “PROGRAM” button to enter the Program Mode. The Program

number briefly shows ‘01’, the Program indicator flashes.

2.) Press the “F.SKIP” or “B.SKIP” button to select the first track number you

wish to enter in the program memory. Example: Track Number ‘8’.

3.) When the desired track number appears on the display, press the

“PROGRAM” button again to memorize the track.

4.) Repeat steps 2-3, select a different track number each time until you

have entered up to 20 CD tracks in the program memory.

Note: You may program the same track number to play multiple times in the

program sequence if desired.

5.) Press the “PLAY/PAUSE” button to begin programmed playback. The

“PROGRAM” indicator stops flashing and remains ‘On’. Playback will begin with the first track you have programmed and will continue until the last programmed track has been played.

IMPORTANT NOTE Automatic switch-off: The appliance will switch off about 15 minutes after finishing last playback.

TECHNICAL SPECIFICATIONS

(UKW) FM Frequency:

87,5 - 108 MHz

Operation voltage:

230V ~ 50Hz

Power consumption:

19W

Features and specifications are subject to change without prior notice.

IMPORTER

Wörlein GmbH

Tel.:

+49 9103 71 67 0

Gewerbestrasse 12

Fax.:

+49 9103 71 67 12

D 90556 Cadolzburg

E-Mail:

[email protected]

Deutschland

Web:

www.woerlein.com

Technische Änderungen und Druckfehler vorbehalten Urheberrecht Woerlein GmbH, 90556 Cadolzburg, www.woerlein.com Vervielfältigung nur mit ausdrücklicher Genehmigung der Woerlein GmbH

PROGRAMM

Page 8

Hiermit bestätigt Wörlein GmbH, dass sich dieses Gerät in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 2014/53/EU befindet.

Eine Kopie der Konformitätserklärung kann unter folgender Adresse bezogen werden. Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Germany Email: [email protected] Tel.: +49 9103 71 67 0

Hereby, Wörlein GmbH declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

A copy of the Declaration of Conformity may be obtained at the following location:

Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Germany Email: [email protected] Tel.: +49 9103 71 67 0

Par la présente, Wörlein GmbH déclare que cet appareil est conforme aux exigences principales et autres clauses applicables de la Directive 2014/53/EU.

Vous pouvez demander de recevoir une copie de la déclaration de conformité en écrivant à l'adresse suivante :

Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Germany Email: [email protected] Tel.: +49 9103 71 67 0

Wörlein GmbH verklaart hierbij dat dit apparaat in overeenkomst is met de essentiële vereisten en andere relevante bepalingen van de Richtlijn 2014/53/EU.

Er kan een kopie van de Conformiteitsverklaring worden verkregen op de volgende locatie:

Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Germany Email: [email protected] Tel.: +49 9103 71 67 0

Con la presente, Wörlein GmbH dichiara che questo dispositivo è conforme ai requisiti essenziali e altre disposizioni contenute nella Direttiva 2014/53/EU.

Una copia della Dichiarazione di conformità è disponibile al seguente indirizzo: Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Germania Email: [email protected] Tel .: +49 9103 71 67 0

Härmed Wörlein GmbH deklarerar att denna enhet är i överensstämmelse med de grundläggande kraven och andra relevanta bestämmelser i direktiv 2014/53/EU.

En kopia av försäkran om överensstämmelse kan erhållas på följande plats: Wörlein GmbH, Gewerbestrasse 12, D 90.556 Cadolzburg, Tyskland E-post: [email protected] Tel .: +49 9103 71 67 0

Herved Wörlein GmbH erklærer, at denne enhed er i overensstemmelse med de væsentlige krav og øvrige relevante krav i direktiv 2014/53/EU.

En kopi af Overensstemmelseserklæringen kan fås på følgende placering: Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Tyskland E-mail: [email protected] Tel .: +49 9103 71 67 0

Tímto Wörlein GmbH prohlašuje, že toto zařízení je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 2014/53/EU.

Kopii Prohlášení o shodě lze získat v následujícím umístění: Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Německo E-mail: [email protected] Tel .: +49 9103 71 67 0

Por este meio, Wörlein GmbH declara que este dispositivo está em conformidade com os requisitos essenciais e outras disposições da Directiva 2014/53/EU.

Uma cópia da Declaração de Conformidade pode ser obtida no seguinte local: Wörlein GmbH, Gewerbestrasse 12, D 90556 Cadolzburg, Alemanha Email: [email protected] Tel .: +49 9103 71 67 0
