soundmaster CD9220 User guide

DEUTSCH

ESPANOL

ENGLISH

ČEŠTINA

FRANÇAIS

MAGYAR

NEDERLANDS

LIETUVOS

ITALIANO

SLOVENSKÝ

PORTUGUÊS

CD9220

Hersteller

Wörlein GmbH Tel.: [phone]
Gewerbestrasse 12 Fax.: [phone]
D 90556 Cadolzburg Email. [e-mail]
GERMANY Web: www.woerlein.com

Safety, Environmental and Setup Instructions

ENVIRONMENTAL PROTECTION

Do not dispose of this product with the normal household
waste at the end of its life cycle. Return it to a collection
point for the recycling of electrical and electronic devices.
This is indicated by the symbol on the product, user
manual or packaging

The materials are reusable according to their markings. By
reusing, recycling or other forms of utilization of old devices you
make an important contribution to the protection of our
environment.

Please contact your local authorities for details about collection

points.

WARNING

Risk of electric shock

Do not open!

Caution: To reduce the risk of electric shock, do not remove the

cover (or back). There are no user serviceable parts inside.

Refer servicing to qualified service personnel.

This symbol indicates the presence of dangerous
voltage inside the enclosure, sufficient enough to
cause electric shock.

This symbol indicates the presence of important
operating and maintenance instructions for the device

Used batteries are hazardous waste and NOT to be

disposed of with the household waste! As a

consumer you are legally obligated to return all

batteries for environmentally responsible recycling –

no matter whether or not the batteries contain harmful

substances*)

Return batteries free of charge to public collection points in your

community or shops selling batteries of the respective kind.

Only return fully discharged batteries

*) marked Cd = cadmium, Hg = mercury, Pb = lead

 Only use mercury and cadmium-free batteries.
 Used batteries are hazardous waste and NOT to be

disposed of with the household waste!!!

 Keep batteries away from children. Children might swallow

batteries.

 Contact a physician immediately if a battery was swallowed.
 Check your batteries regularly to avoid battery leakage.
 Batteries shall not be exposed to excessive heat such as

sunshine, fire or the like.

 CAUTION: Danger of explosion if battery is incorrectly

replaced

 Replace only with the same or equivalent type

CAUTION - INVISIBLE LASER

RADIATION WHEN OPENING THE

COVER OR PRESSING THE SAFETY

INTERLOCK. AVOID EXPOSURE TO

THE LASER BEAM.

To prevent possible hearing damage, do not
listen at high volume levels for long periods

 No objects filled with liquids, such as vases,

shall be placed on the apparatus.

 The mains plug or an appliance coupler is used

as the disconnect device, the disconnect devices
shall remain readily operable.

 Connect this device to a properly installed and

earthed wall outlet only. Make sure the mains
voltage corresponds with the specifications on
the rating plate.

 Make sure the mains cable stays dry during

operation. Do not pinch or damage the mains
cable in any way.

 A damaged mains cable or plug must

immediately be replaced by an authorized service
center.

 In case of lightning, immediately disconnect the

device from the mains supply.

 Children should be supervised by parents when

using the device.

 Clean the device with a dry cloth only.
 Do NOT use CLEANING AGENTS or ABRASIVE

CLOTHS!

 Do not expose the device to direct sunlight or

other heat sources.

 Install the device at a location with sufficient

ventilation in order to prevent heat accumulation.

 Do not cover the ventilation openings!
 Install the device at a safe and vibration-free

location.

 Use the device in dry indoor environments only.
 Protect the device from humidity.
 This apparatus is for moderate climates areas use,

not suitable for use in tropical climates countries.

 Install the device as far away as possible from

computers and microwave units; otherwise radio
reception may be disturbed.

 Do not open or repair the enclosure. It is not safe

to do so and will void your warranty. Repairs only
by authorized service/ customer center.

 No naked flame sources, such as lighted

candles, should be placed on the unit.

 When you are necessary to ship the unit store it

in its original package. Save the package for this
purpose.

 In case of malfunction due to electrostatic

discharge or fast transient (burst), remove and
reconnect the power supply.

 If the unit is not using for a long period of time,

disconnect it from the power supply by
unplugging the power plug. This is to avoid the
risk of fire.

EN

1. LCD

Display

2. Battery charging indicator

3. ESP

Turns on/off ESP (Electronic
Skip Protection)

4. Play Pause

switches the player on, starts
or pauses playback.

5. 5V DC

jack for connecting external
power supply.

6. RESUME

HOLD
OFF Switch

Enable resume function
locks all buttons
switch off HOLD and

RESUME.

7. Phones

3.5mm headphone jack to
connect the headphones.

8. Vol

adjusts the volume

9. X-BASS

HI VOL

selects the bass enhancement
switch off Volume restriction

10. ALBUM

selects next album

11. STOP

stop playback, clears a
program or switches the
player off

12.

skips and searches backward or forward

13. PROG/MODE

PROG: program tracks, reviews the program.

MODE: selects the different playing possibilities: REPEAT and RANDOM

14. CD DOOR

15. OPEN

opens the CD lid.

16. Battery compartment

17. Recharge

ON/OFF

ON: when using adaptor, recharge the rechargeable batteries.
OFF: when using adaptor, switch off for standard/conventional batteries.

Attention

On operation with standard/conventional batteries, be sure
that the charging switch

“RECHARGE” (17) slide to OFF position.
Otherwise the batteries may become hot and may

explode.

CD9220 / English Instruction Manual

LOCATION OF CONTROLS

BATTERIES (Not supplied)

1

Open the battery compartment and insert either 2 normal or alkaline

batteries type AA (LR6, UM3).

Old and new or different types of batteries should not be combined.
Don’t use petrol, alcohol or other abrasive cleansers to clean the exterior.

Replace the battery or connect the mains adapter as soon as battery
icon appeared.

Remove batteries if they are empty or if the unit will not be used for a
long time.

Batteries contain chemical substances, so they should be disposed of
properly.

Only use the provided mains adapter (5V/1A) micro USB
jack. Any other product may damage the set.

Attention
Slide the charging switch to OFF position
if using normal batteries.

Connect the mains adapter to 5V DC on the set and
to the wall outlet.

Note: Always disconnect the adapter if you are not using it.

CD9220 / English Instruction Manual

Inserting batteries

Indication of empty batteries

POWER SUPPLY / GENERAL INFOMATION

RECHARGEABLE BATTERY OPERATION

This unit can fully recharge the specified rechargeable battery, in approximately 16 hours at 130
mA. The rechargeable batteries (NOT supplied) should be recharged before they are used for
the first time because they are low in power or if they have not been used for a long period (over
60 days).

1. Open the battery compartment cover and insert two of the recommended rechargeable
batteries, matching polarity (1.2V 1300mA for NiMH). (Both batteries must be of
rechargeable Nickel–Metal Hydride (Ni-MH) type battery otherwise the batteries may
explode or leak.)

2. Plug in the AC adaptor then set the Recharge switch to ON position to start charging. (Use
only the AC adaptor supplied with the set for charging.)

3. After 16 hours. Please unplug the AC adaptor and switch the Recharge switch to the off
position. (Do not charge continuously for 24 hours or more. Doing so can cause the
performance of the rechargeable battery to deteriorate.)

4. If the operating time decreases drastically even when the rechargeable batteries are
properly recharge, purchase a new set of rechargeable Nickel-Metal Hydride batteries.

5. When charging for the first time or after a long time, playing time may be reduced. In this
case, charge and discharge the batteries several times.

Note : You may play DISCS whilst charging the batteries.

2

NiMH

Capacity (mAh/series)

Charging Time (hrs)

AA size 1300mAH

16

Input Rating

Output Rating

DC 5.0V / 1.0A

2xAA-DC 2.8V 130mA average

Condition

LED Indicator

Recharge switch is ON
Charging function enable

Red light - Charging the battery

No light – Charging completed

Recharge switch is OFF
Charging function disable

No light

CD9220 / English Instruction Manual

IMPORTANCE

1. It is normal for batteries to become hot during charging and they will gradually cool down to
room temperature after fully charged.

2. Remove batteries from the CD player if not going to be used for a long time.

3. Battery storage temperature: -20 ~ 35°C/ CD player operation temperature: 0 ~ 45°C

4. Charging time may vary based on different battery capacities.
(The charging time is varying on the used battery capacity. If the battery capacity is larger the

charging time becomes longer; if smaller the charging time becomes shorter.

Caution

1. Do not use the charging function in humid conditions.

2. Do not use the charging function if it has a damaged plug.

3. Do not use the charging function after it has been dropped or damaged.

4. Do not open/disassemble the CD player.

5. Unplug the CD player before maintenance or cleaning.

6. Do not use the charging function in direct sunlight.

7. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.

8. Children should not play with the CD player while using charging function.

9. Cleaning and user maintenance should not be made by children without supervision.

Charging Time

* Charging time is subjected to the power rating of the CD player with 5V DC output
Specifications:

LED Indications

3

At full power, prolonged listening to the player can damage the ear
of the user.

To prevent possible hearing damage, do not listen at high volume
levels for long periods.

Press and hold the HI VOL button until display shown “HI VOL” to allow
the volume to be increased above safe levels.

To disable HI VOLUME, press and hold the HI VOL button 2 secs.

 Do not touch the lens (Laser head) of the CD player.
 Do not expose the unit, batteries or CDs to humidity,

rain, sand or excessive heat (caused by heating
equipment or direct sunlight).

CD9220 / English Instruction Manual

HEADPHONES

HEADPHONE VOLUME WARNING

Connect headphones with volume set low and increase it if required. Prolonged listening
through some headphones at high volume setting can result in hearing damage.
Earphones or headphones must comply with EN 50332-1 / E50332-2 to ensure continue
protection from excessive sound pressure.

IMPORTANT!
Hearing safety:

Do not play your headphones at a high volume. Hearing experts advice that continuous
use at high volume can permanently damage your hearing.

Traffic safety:

Do not use headphones while driving a vehicle. It may create a hazard and it is illegal in
many countries. Even if your headphones are an open-air type designed to let you hear
outside sounds, do not turn up the volume so high that you cannot hear what is going on
around you.

LISTENING AT HI VOLUME

Remarks:

HI VOL will be automatically cancel when continues listening 20 hours or above.
HI VOL will be automatically cancel when unit switch OFF or open the CD door.

CD PLAYER AND CD HANDLING

 You can clean the CD player with soft, slightly dampened and lint-free cloth. Do not use any

cleaning agents as they may be corrosive.

 To clean the CD, wipe it in a straight line from the center toward the edge using soft and lint-

free cloth. A cleaning agent may damage the disc! Never write on a CD or attach a sticker to
it.

 The lens may cloud over when the unit is moved suddenly from cold to warm surroundings.

Playing a CD is not possible then. Leave the CD player in a warm environment until the
moisture has evaporated.

 Active mobile phones in the vicinity of the CD player may cause malfunctions.

 Avoid dropping the unit as this may cause damage.

4

Adjust the volume by using VOL .

Press the XBASS button repeatedly to enable or disable a strong bass
enhancement.
You can hear the bass different from the earphone.

With this set you can play

-all pre-recorded audio CDs

-all finalized audio CDRs and CDRWs

-MP3-WMA-CDs (CD-ROMs with MP3/ WMA files)

3. Press to switch the unit on.

“----“ are displayed briefly when reading the contents of the disc.

Press again to start playback. For audio CD tracks, the current
track number and the elapsed playing time are displayed.

5. To remove the disc, hold it by its edge and press the hub gently
while lifting the disc.

6. Press again to switch off the player

CD9220 / English Instruction Manual

VOLUME

SOUND ADJUSTMENT

PLAYING A DISC

1. Push the OPEN slide to open the CD lid.

2. Insert a disc, printed side up, by pressing gently on the disc’s center so that it fits onto
the hub. Close the CD lid by pressing it down.

4. Press to stop playback.
The total number of tracks and the total playing time of an audio disc are displayed.
The total number of albums and tracks of MP3/WMA-CD are displayed.

Notes:

- After press it may take some time to read the disc until the first MP3 track is played.

- The set switches off automatically after 110 seconds, if no control is operated in the

stop mode.

PLAYING ENHANCED MUSIC CDS AND MIXED MODE CDS

On enhanced music CDs and mixed mode CDs, there are audio CD tracks as well as MP3
files.

- All audio CD tracks normally placed in album 1 or the last album number.

- When audio CD tracks are played, the display shows the album number, track number,
elapsed time, but no MP3 is displayed.

- When MP3 files are played, the display shows the album number, track number,
elapsed time and MP3 icon.

- When WMA files are played, the display shows the album number, track number and
elapsed time.

Note: Enhanced music CD and mixed mode CD containing computer data (text file, picture)
are not recommended in order to allow the set to play audio CDs and Mp3 files correctly.

5

Selecting a track during playback

Briefly press or once or several times to skip to beginning of the
current, previous or subsequent track.

- Playback continues with the selected track.

Searching for a passage during playback

1. Keep or pressed to find a particular passage in a backward or forward
direction.
Searching is started and playback continues at a low volume.

2. Release the button at the desired passage.

 Normal playback continues.

You can store up to 20 tracks in a program. A single
track may be store more than once in the program.

1. While playback is stopped

2. Press PROG to enter programming.
PROG indicator and track number briefly on display.

3. Select a track with or then press PROG to store the track.

4. Repeat step 2-3 to store all desired tracks

5. Press to start playback of your programmed tracks.

CD9220 / English Instruction Manual

PAUSE

1. Press to interrupt playback. - The elapsed playing time blinks.

2. To resume playback, press to again

Note: The set will return to the stop mode automatically after 110 seconds in pause mode.

SELECTING ALBUMS AND TRACKS ON MP3-WMA-CD

Selecting Album (only in MP3 mode)

Press the ALBUM▲ button to select the next album (if available).

PROGRAMMING TRACK NUMBERS

- PROG is shown and playback starts.

• To add additional tracks to your program, press to stop playback and continue
with step 2 and 3.

In the stop mode, you can review the programed track(s) by pressing or .
The display shows all the stored tracks in sequence.

Note:

If you try to store more than 20 tracks, start the program form the already first stored
title.

Clearing the program
While playback is stopped, press to clear program.

- PROG indicator goes off and the program is cleared.

Note: The program will also be cleared if the power supply is interrupted, or if the CD-

player lid is opened, or if the set switches off automatically.

6

1. Press MODE repeatedly during playback to select:

 REP 1: The current track played repeatedly.
 ALL: The entire disc is played repeatedly.
 INTRO: The entire disc is played the first 10 seconds.
 RND: All tracks of the disc are played in random order once.

2. To return to normal playback, press MODE repeatedly until
REP1, ALL, INTRO and RND disappear.

With a conventional portable MP3-CD player you might have
experienced that the music stopped e.g. when you were
jogging.
The ESP prevents loss of sound caused by light vibrations and
shocks. Continuous playback is ensured. However it does not
protect the unit against any damage caused by dropping.

You can interrupt playback and continue from the position
where playback stopped (RESUME).

1. Set the OFF-RESUME-HOLD slider to RESUME position
to activate RESUME. RESUME is shown.

2. Press in once whenever you want to stop playback and
switch the unit off.

You can lock the buttons of the set. When a key is pressed, no
action will be executed. With HOLD activated, you can avoid
accidental activation of other functions.

1. Switch the slider to HOLD to activate HOLD.
All buttons are locked, HOLD is shown when you press
any button.

2. To deactivate HOLD, switch the slider to OFF.

CD9220 / English Instruction Manual

PLAYING TRACKS REPEATEDLY, INTRO OR IN RANDOM ORDER - MODE

ESP (Electronic Skip Protection)

In this set ESP is default “ON”. It is possible to set ESP off in audio CD playback (ESP is

always on in MP3 playback).
Press ESP button to deactivate ESP function - ESP disappears.
Press ESP button again to activate ESP function - ESP is displayed.

RESUME

3. Press to resume playback, the playback continues from where you have stopped.
 To deactivate RESUME, set the slider to OFF position. - RESUME goes off.

Note:

If open and close the CD lip during playback, RESUME function is also activated.
RESUME becomes reset by changing the CD.

HOLD

7

Problem

Solution / Cause

No

power,
playback does not
start

– Insert the batteries correctly.
– Replace the batteries.
– Connect the mains adapter securely.

Hold indication and/
or no reaction to
controls

– Deactivate HOLD.
– Disconnect the set from the power to controls supply or take out the

batteries for a few seconds.

No sound or bad
sound quality

– Press to resume playback.
– Adjust the volume.
– Check and clean the connections.
– Keep this set away from active mobile phones or strong magnetic

fields.

„dISC“ / „Err“/ error
message

– Insert a disc, label upwards.
– Clean or replace the disc.
– Wait until the steamed up lens has cleared.
– Make sure you have inserted an audio disc or an MP3/WMA-CD.
– Make sure the inserted CDR or CD-RW is recorded correctly.

Music is not played

– Make sure that the file names of the MP3 files end with .mp3 /
WMA files end with .wma

Missing directories on

MP3-CD

– Make sure the total number of files and albums on your MP3/WMA-

CD does not exceed (MP3+WMA) 600 and (CD) 99 respectively.

– Only albums with MP3 files are shown. Other computer data file is

skipped.

The disc skips tracks

– Clean or replace the disc.
– Make sure REP, INTRO, RND, ALL or PROG are not selected.

Music skips or
popping sound when

– Play the music file on your computer. If the problem persists, encode

the audio track again and make a new CD-ROM.

CD9220 / English Instruction Manual

Troubleshooting

TECHNICAL SPECIFICATIONS

Power Supply: AC 100-240V ~ 50/ 60Hz , 150 mA Model: TBA0050500100VDE

DC output: 5V 1A
Batteries: DC 3V (AA x 2) (Optional, not supplied)
Battery playback time: 6-8 hrs (Alkaline battery)

Recharge battery type: Nickel–Metal Hydride (Ni-MH) 1.2V / AA size
Charging Time around 16 hours with 130 mA

IMPORTER

Wörlein GmbH Tel.: [phone]
Gewerbestrasse 12 Fax.: [phone]
D 90556 Cadolzburg Email: [e-mail]
Germany Web: www.woerlein.com

Technische Änderungen und Druckfehler vorbehalten
Copyright by Woerlein GmbH, 90556 Cadolzburg, www.woerlein.com
Vervielfältigung nur mit ausdrücklicher Genehmigung der Woerlein GmbH

8
