Sony Ericsson T618

Getting to know your phone 4

Key functions, quick keys, entering letters and characters.

Personalizing your phone 22

Download settings or choose from the phone.

Calling 31

Use the Phonebook, voice control, call options.

Messaging 51

Multimedia messaging, chat and e-mail.

Camera 60

Use the camera.

Setting up WAP and e-mail 63

All you need to know about setting up WAP and e-mail.

Using WAP 71

WAP browser, bookmarks.

Transferring and exchanging information 74

Bluetooth wireless technology, synchronization.

More features 79

Calendar, alarm clock, stopwatch, timer, games.

Security 87

SIM card lock, phone lock.

Troubleshooting 89

Why doesn’t the phone work the way I want?

Additional information 91

Safe and efficient use, warranty, declaration of conformity.

Icons 98

What do the icons mean?

Index 105

This is the Internet version of the user's guide. © Print only for private use.

Contents 1

Page 2

Sony Ericsson

GSM 900/1800/1900

Third edition (August 2003) This manual is published by Sony Ericsson Mobile Communications AB, without any warranty. Improvements and changes to this manual necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this manual.

©Sony Ericsson Mobile Communications AB, 2003

Publication number: EN/LZT 108 6484 R2A

Please note:

Some of the services in this manual are not supported by all networks. This also applies to the GSM International Emergency Number 112.

Please contact your network operator or service provider if you are in doubt whether you can use a particular service or not.

2Contents

Please read the Guidelines for Safe and Efficient Use and the Limited Warranty chapters before you use your mobile phone.

The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc.

T9™ Text Input is a trademark or a registered trademark of Tegic Communications.

T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.

Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries/ regions.

End-user license agreement for Sun™ Java™ J2ME™.

This is the Internet version of the user's guide. © Print only for private use.

Page 3

1. Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or otherwise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in part.

2. Export Regulations: Software, including technical data, is subject to U.S. export control laws, including the U.S. Export Administration Act and its associated regulations, and may be subject to export or import regulations in other countries/regions. Customer agrees to comply strictly with all such regulations and acknowledges that it has the responsibility to obtain licenses to export, re-export, or import Software. Software may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba, Irak, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any country to which the U.S. has

embargoed goods; or (ii) to anyone on the U.S. Treasury Department's list of Specially Designated Nations or the U.S. Commerce Department's Table of Denial Orders.

3. Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS 252.2277013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable.

Other product and company names mentioned herein may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

Contents 3

Page 4

Getting to know your phone

About this user’s guide

The “Getting to know your phone” chapter gives a quick overview of the main functions of the phone, shortcuts and general information.

More information and downloads are available at

www.SonyEricsson.com.cn or wap.SonyEricsson.com.

Available services

Some services and functions described in this user’s guide are network or subscription-dependent, which means that all menus may not be available in your phone.

This symbol indicates that a service or function is network or subscription-dependent.

Please consult your network operator for more information about your subscription.

Assembly

Before you can use your phone you need to:

• Insert the SIM card.

4 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

• Attach and charge the battery. See “SIM card and battery information” on page 5.

Note: Always turn off the phone and detach the charger before you insert or remove a SIM card.

The SIM card

When you register as a subscriber with a network operator, you get a SIM (Subscriber Identity Module) card. The SIM card contains a computer chip that keeps track of your phone number, the services included in your subscription, and your Phonebook information, among other things.

Tip: Check if your information is saved to the SIM card before you remove it from another phone. For example, Phonebook entries may be saved in the phone memory.

Page 5

SIM card and battery information

It may take up to 30 minutes before an icon appears when charging.

1. Insert the SIM card. Slide the silvery holder over the SIM card to lock it in place.

2. Place the battery on the back of the phone with the connectors facing each other.

3. Place the back cover as shown in the picture and slide it into place.

4. Connect the charger to the phone at the flash symbol. The flash symbol on the charger plug must face upwards.

5. It may take up to 30 minutes before the battery charging icon appears in the display.

6. Wait approximately 4 hours or until the icon indicates that the battery is fully charged. If you do not see the battery icon after this time, press any key or the joystick to activate the display.

7. Remove the charger by tilting the plug upwards.

Note: You have to insert the SIM card and charge

the battery before you can use the phone.

Getting to know your phone 5

This is the Internet version of the user's guide. © Print only for private use.

Page 6

Turning the phone on

• Enter your PIN (Personal Identity Number), if you have one for your SIM card.

On/off

Your PIN is provided by your network operator.

If you make a mistake while entering your PIN, delete the wrong number by pressing .

If your PIN starts with the same digits as an emergency number, for example 112, the digits are not hidden with an * when you enter them. This is so that you can see and call an emergency number without entering a PIN. See “Making emergency calls” on page 31.

Note: If you enter the wrong PIN three times in a

To turn on the phone

• Press the on/off button on the top of the phone.

Note: The first time you turn on the phone it takes up to 40 seconds to begin operating.

row, the SIM card is blocked and the message PIN blocked appears. To unblock it, you need to enter your PUK (Personal Unblocking Key). Your PUK is provided by your network operator.

To turn off the phone

• Press and hold the on/off button at the top of the phone.

6 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 7

Navigating the menus

Example

The main menus are shown as icons on the desktop. To go to the desktop, press the joystick.

Desktop

Press to go to the desktop. Move up, down, left, right through menus. Press to select highlighted items.

To set an alarm

1. Use the joystick to scroll to Organizer, and press the left key to select it.

2. Use the joystick to scroll down to Alarms, and press the left key to select this function. Press the left key again to select Alarm.

3. Enter the time and press the left key to save your entry.

Throughout this user’s guide instructions such as those above will be given in a shorter form, as follows:

To set an alarm

1. Scroll to Organizer, Alarms, Alarm.

Press to go back one level in the menus. Press and hold to return to standby.

Press to select the options shown above these keys in the display.

2. Enter the time,

Save.

To make and receive calls from standby

• Enter the area code and phone number, press

End call to end the call.

• Press

• When the phone rings, press

Getting to know your phone 7

This is the Internet version of the user's guide. © Print only for private use.

Call.

Yes to answer the call.

Page 8

Key functions

Press once to activate camera function. Press again to take a picture.

Volume keys increase/ decrease the earpiece volume during a call. Scroll through menus, lists and text. Enter the Status menu in standby. Press twice to reject an incoming call. Press once to turn off the ring signal when receiving a call.

Press to select the options that appear in the display immediately above these keys.

Press once to go back one

level in the menus. Press and hold to return to standby.

Delete numbers, letters or an

1-9, 0 Enter digits, 0-9, and letters.

Infrared port. Press and hold to switch the

phone on or off. Press to go directly to

the Internet. Move through the menus,

lists and texts.

item from a list. Press and hold to turn off the microphone (during calls) or turn off sound.

Press and hold to enter the international prefix +.

Enter # or a space

Enter *. Shift between lower/

upper case.

8 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 9

Quick keys

Useful key combinations are described below.

To... When in standby:

make an emergency call enter the emergency

number and press

Call

enter Call contact press enter Internet services press voice dial press and hold a volume

key or say your magic word

enter Call list press

CALLS

call your voice mail press and hold enter the + sign press and hold turn off the ring signal

when receiving a call

press , or press a

volume key once set the phone to silent press and hold reach a contact beginning

with a specific letter

press and hold any of the

keys -

To... When in standby:

reach a phone number at a specific position.

speed dial press any of the number

enter the first submenu of the shortcut menu

enter the main menu press or press the

enter the menu to see today’s date, the profile in use and the model name of the phone

change the language to Automatic

change the language to English

change the language to Chinese

reject a call press

Getting to know your phone 9

This is the Internet version of the user's guide. © Print only for private use.

press the position number and

keys - and

Call

press

centre of the joystick press a volume key once

press 8888

press 0000

press 0008

Page 10

To... During a call:

put a call on hold press Hold retrieve a call press Retrieve turn off the microphone press and hold enter a quick

press

options menu

To. ..

reach the second letter or character of a key

reach the third letter or character of a key

To... When in the menus:

move through menus or lists

press (and hold) a volume

key or use the joystick delete an item press and hold

shift between capital and lower-case letters

enter numbers press and hold any of the

when in lists go back to standby press and hold

enter a space press delete letters and

numbers shift between multitap or

T9 Text input methods shift between input

languages (including character or numeric)

10 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

When entering letters using multitap text input:

press the volume key and press any of the number keys

press , then the letter

number keys

press

press and hold

Page 11

To...

When entering letters

using T9 Text Input:

view alternative words press or accept a word and add

press aspace

enter a full stop press shift between capital and

lower-case letters

press , then the

letter enter numbers press and hold any of the

number keys delete letters

press and numbers

shift between multitap or

press and hold T9 Text input methods

shift between input

press and hold languages (including

Help texts

More information, explanations or tips about selected menus or functions are available in your phone.

To get help

• Select the menu or function and press

Delete and edit

If you add items, for example, a contact, a note, an appointment or a WAP bookmark, you can delete or edit them.

To delete an item

• Select an item and press .

To edit an item

• Select an item, press

More, and choose from the list

of options.

character or numeric)

Getting to know your phone 11

This is the Internet version of the user's guide. © Print only for private use.

Info.

Page 12

Online services

Online services are customized services offered by network operators, independently of mobile phones and mobile phone manufacturers.

A SIM card which supports Online services works in the same way as a normal SIM card. When you have inserted your SIM card and turned on your phone, your network operator can download data to your SIM card. When you restart your phone after the first data download, a new submenu appears under the menu.

To enter your new menu system

• Scroll to Connectivity, Online services.

Note: This menu only appears if your SIM card supports this service. Some operators may not use the name “Online services”. Your phone may not support all of the services offered.

12 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 13

Menu overview

Operator direct link

Internet services My shortcuts Camera Messaging Entertainment

Pictures & sounds

View we ek Ring volume Select profile My numbers Edit shortcuts

Phonebook Calls Connectivity Organizer Settings

Call contact Find and send** Add contact Manage contact Pictures Personal rings Voice commands Special numbers Advanced Options

Missed calls Calling local* Call list Switch to line 1* Divert calls Manage calls Time and cost Next call Options

Online services* Bluetooth Infrared port WAP o ptio ns Synchronization GSM Networks Data comm. Accessories

Calendar Notes Alarms Timer Stopwatch Calculator Code memo

Te xt Picture Call voice mail E-mail Chat WAP p ush Area info Options

Sounds and alerts Display Profiles Language Time and date Voice control Locks Handsfree Master reset

Games & more Other games

Getting to know your phone 13

This is the Internet version of the user's guide. © Print only for private use.

My pictures More pictures My sounds More sounds Themes More themes Picture editor Music DJ Record sound

* Please note that some menus are operator, network and subscription dependent.

** Only visible during calls

Page 14

Entering letters

You can enter letters, for example, when you add names to the Phonebook, write text messages or enter WAP addresses.

Apart from the way you normally enter letters in your phone, using multitap text input, you can use T9™ Text Input for entering text messages and

Multitap text input

When saving names in the Phonebook or when writing WAP addresses, you enter letters using multitap text input. You press each key as many times as needed to show the letter you want. In the following example, we are going to write a name in

the Phonebook. e-mail, for example, if the input language you select supports this. T9™ Text Input is a predictive input method and is a quicker way to write texts. See “T9™ Text Input” on page 15.

To enter letters using multitap text input

1. Scroll to Phonebook, Add contact.

Add and then the appropriate key,

2. Press

- , or , repeatedly until the

Input languages

Before you start entering letters, you need to select the input languages that you want to use when writing.

To select input languages

1. Scroll to Settings, Language, Input.

2. Scroll to the language that you want to use for

entering letters and check each language you want.

Ok to exit the menu.

3. Press When writing, you can switch to one of your selected input languages by pressing

More and then

selecting Input language. See “The list of options” on page 16.

14 Getting to know your phone

character you want appears in the display. See the table below:

Press… to get…

. , - ? !’ @ : ; / ( )1 A B C Å Ä Æ à Ç 2 Γ D E F è É 3 ∆ Φ G H I ì 4 J K L 5 Λ M N O Ñ Ö Ø ò 6 P Q R S ß 7 Π Σ T U V Ü ù 8

This is the Internet version of the user's guide. © Print only for private use.

Page 15

Press… to get…

W X Y Z 9 + 0 θ Ξ Ψ Ω Space ↵ ¶

More for an options list

to delete letters and numbers to shift between capital and

lower-case letters

- press and hold to enter numbers

To enter a ‘C’, press the volume key and press .

T9™ Text Input

You can use T9™ Text Input when writing, for example, text messages and e-mail. The T9™ Text Input method uses a built-in dictionary that recognizes the most commonly used word for each sequence of key presses. This way, you press each key only once, even if the letter you want is not the first letter on the key.

Example:

• To enter an ‘A’, press once.

• To enter a ‘B’, quickly press twice.

• To shift between capital and lower-case letters, press , then enter the letter.

Note: Standard abc must selected in order to use multitap text input.

Tip: You can also use the volume keys as a shortcut to certain letters:

To shift from multitap to T9 text input method

• Press and hold .

To enter letters using T9™ Text Input

1. Scroll to Messaging, Text, Write new.

2. For example, if you want to write the word “Jane”,

press , , , .

3. If the word shown is the one you want:

• press to accept and add a space. (To accept a word without adding a space, press .)

To en ter a ‘ B’, press the volume key and press .

Getting to know your phone 15

This is the Internet version of the user's guide. © Print only for private use.

Page 16

If the word shown is not the one you want:

•Press

or repeatedly to view alternative

words (candidates). Accept a word and add a space by pressing .

If you do not find the word you want by pressing or :

More to go to a list of options.

•Press

• Select Spell word.

• Press and hold to delete the entire word, or delete one letter at a time by pressing

repeatedly.

• Write the new word using multitap text input and

Insert.

press The word is added to the dictionary. The next time you enter the word, it appears as one of the alternative words.

4. Continue writing your message. See “Sending text

The list of options

If you press

More when writing a text message, you

enter a list of options:

• Add symbol – Symbols and punctuation marks such as ? and , are shown. Move between the symbols by using the joystick.

• Insert item – Pictures, melodies and sounds.

• Spell word – Change the suggested word by using multitap text input.

• Te xt f ormat – Change style, size and alignment.

• Input language – Change input language.

• Input method – Change input method.

• Word suggestions – Select to show a list of suggested words.

• My words – A list of words you have added to the dictionary.

• Help.

messages” on page 51. Press to enter a full stop. To enter other punctuation marks, press

and then or repeatedly. Accept by pressing . Press and hold to select an input language.

16 Getting to know your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 17

Chinese input

This mobile phone has different input methods for entering Chinese characters:

• Pinyin input

Switching between Chinese and English input

In the Chinese editing mode, you can select and switch quickly to another input mode by pressing and holding .

• Stroke input You can use these methods, for example, to enter Chinese names and Chinese short messages.

General instructions

Regardless of which input method you choose, your phone has a function to speed up the entry of

Before you start

Chinese is the default language. If you want to select another language or input method before you start entering Chinese characters, please refer to the following procedures:

Chinese characters. Whenever you enter a stroke or a Pinyin letter, a candidate row of the most frequently used characters containing that stroke or relating to that letter, appears at the bottom of the input area.

If the character you want is not displayed in the

To select a menu language

• Scroll to Settings, Language, Menus.

candidate row, press to present another candidate row. Continue pressing until the character you want is displayed. Alternatively, you can enter the

To select an input mode

• Scroll to Settings, Language, Input.

next stroke or Pinyin, and a new set of characters will immediately be displayed in the candidate row. To go back to the previous row, press . To enter a

Switching between Chinese input methods

In the Chinese editing mode, you can select and

character in the candidate row, move the cursor to

that character and press the joystick. switch quickly to another Chinese input method by pressing and holding .

Getting to know your phone 17

This is the Internet version of the user's guide. © Print only for private use.

Page 18

Input methods in detail

Stroke categories

The 5 stroke categories are defined in the

Stroke input

A Chinese character is built up of strokes. There are more than 30 basic strokes, which are grouped into 5 stroke categories. Each category is represented on

table below:

Number

Stroke

Key

Personalizing your phone

You can adjust the phone settings to suit your own requirements.

To send a theme

You can exchange themes via IR, Bluetooth wireless technology, picture message or e-mail. Please note that you are not allowed to exchange copyrightprotected material. For more information on sending

Note: If you change a setting which is included in a profile, the active profile is also changed. See “Profiles” on page 29.

themes in messages, see “Messaging” on page 51.

1. Scroll to Pictures & sounds, Themes.

2. Select a theme, press

More.

3. Select Send.

Themes

4. Select a transfer method.

You can change the appearance of the display, for example, the colours and background picture, by using themes. Your phone comes with some pre-set themes. You cannot delete these, but you can create new themes and download them to

To receive and save a theme

1. From standby, press

More and select Turn on

Bluetooth or Turn on infrared.

2. When you receive the theme, press

your phone.

Pictures

For more information, visit

www.SonyEricsson.com.cn or wap.SonyEricsson.com.

Your phone comes with a number of pictures. You can:

• Download more pictures to your phone.

• Have a picture as wallpaper when in standby mode.

To download a theme

1. Scroll to Pictures & sounds, More themes.

2. Select a link.

22 Personalizing your phone

This is the Internet version of the user's guide. © Print only for private use.

Save to save it.

Page 23

• Assign a picture to a contact in the Phonebook. When that person calls, the picture appears in the display (provided your subscription supports the Calling Line Identification service). See “To add a picture to a phonebook contact” on page 34.

• Insert a picture in a text message.

To turn wallpaper on or off

• Scroll to Settings, Display, Wallpaper, Activate.

To set a picture as wallpaper

1. Scroll to Settings, Display, Wallpaper, Set picture.

2. Select a picture.

All pictures are saved in My pictures, in the Pictures & sounds menu.

Tip: You can select Wallpaper by pressing when viewing pictures in My pictures.

You can also save animations in your phone. These are handled like pictures.

To edit and save a picture

1. Scroll to Pictures & sounds, My pictures.

Handling pictures

You can add, edit, or delete pictures in My pictures. The number of pictures that can be saved depends on the size of the pictures. File types supported are GIF, JPEG and WBMP.

2. Scroll to the picture you want,

3. Scroll to Edit. You can now start to edit the picture.

More, select Save picture. The picture is saved

4. Press in My pictures.

The pictures are shown in thumbnail view.

To get a full view, press

View.

Note: To edit pictures taken with the camera, you must select 120x160 as picture size.

To view your pictures

• Scroll to Pictures & sounds, My pictures.

To draw a picture

1. Scroll to Pictures & sounds, Picture editor.

To download a picture

2. Select a type.

• Scroll to Pictures & sounds, More pictures.

Personalizing your phone 23

This is the Internet version of the user's guide. © Print only for private use.

More.

Page 24

3. Select Tool and choose the tool you want to work with.

Exchanging pictures

You can exchange pictures via IR, Bluetooth wireless technology, picture message or e-mail.

When editing or drawing a picture:

Press… to…

move the cursor up and left. move the cursor up. move the cursor up and right. move the cursor left. activate the current drawing tool. move the cursor right. move the cursor down and left. move the cursor down. move the cursor down and right.

More view an options menu.

press and hold to exit the picture editor. undo the last action. select tool.

Please note that you are not allowed to exchange copyright-protected material. For more information on sending pictures in messages, see “Messaging” on page 51. Save the e-mail address of a WAP album in your Phonebook and you can save pictures in that album if you send the pictures as attachments.

To send a picture

1. Scroll to Pictures & sounds, My pictures. Scroll to the picture you want,

2. Select Send.

3. Select a transfer method.

If you use infrared make sure that the infrared ports are facing each other.

To receive and save a picture

1. Scroll to Connectivity, Bluetooth, Turn on.

2. When you receive the picture, press

in My pictures.

select a colour.

24 Personalizing your phone

This is the Internet version of the user's guide. © Print only for private use.

More.

Save to save it

Page 25

When you receive a picture in a text message or a picture message, a new message appears in your Inbox. To save the picture in My pictures, highlight the picture by moving the joystick to select it and

Save.

press

Ring signals and melodies

Your phone comes with a number of ring signals and melodies. You can edit your own ring signals and melodies and send them to a friend in a text message. It is also possible to exchange melodies via WA P, Bluetooth wireless technology, IR or cable.

Screen saver

The phone has a screen saver, which is activated automatically when the phone has been in idle mode

Please note that you are not allowed to exchange copyright-protected material. You can also download ring signals to your phone.

for a few seconds. After a few more seconds, the screen saver changes to sleep mode to save power. To turn the screen saver On or Off, scroll to Settings,

To select a ring signal

• Scroll to Settings, Sounds and alerts, Ring signal.

Display, Screen saver, Activate.

To download a ring signal

To use a picture as the screen saver

You select a picture saved in the phone and use it as

1. Scroll to Pictures & sounds, More sounds.

2. Select a link.

the screen saver.

1. Scroll to Settings, Display, Screen saver, Set picture.

2. Scroll to and select the picture you want to use as the

screen saver.

Yes to accept.

3. Press

To set the ring signal volume

1. Scroll to Settings, Sounds and alerts, Ring volume.

2. Press or to decrease or increase the volume.

Save to save the setting.

3. Press

• To turn the ring signal on or off, press and hold . All signals except the alarm are turned off.

Personalizing your phone 25

This is the Internet version of the user's guide. © Print only for private use.

Page 26

To compose a ring signal or melody

1. Scroll to Pictures & sounds, Music DJ.

2. Choose to insert a selection of pre-recorded

music blocks. You can choose from four different selections.

3. Copy and paste these blocks to build up your melody.

More to play the melody and view

4. Select other options.

Receiving melodies

You can receive a sound or melody via IR, Bluetooth wireless technology, text, picture message, or download it via WAP. When you receive the sound or melody, press

Save to save it in My sounds.

Increasing ring

You can choose a ring signal that rises in steps from the lowest volume to the highest.

Note: To edit your own melody, scroll to Pictures & sounds, My sounds, select the melody and press

More. Select Edit.

To send a melody

1. Scroll to Pictures & sounds, My sounds.

2. Scroll to a melody,

More.

3. Select Send. Select a transfer method.

To turn increasing ring On or Off

• Scroll to Settings, Sounds and alerts, Increasing ring.

Specific ring signals for personal calls

If you subscribe to the Two Line Service, you can set different ring signals for the two voice lines. Line 1 and Line 2 are displayed instead of Voi c e c a l l s . If your subscription includes the Calling Line

Note: To send a ring signal or melody in a text message, see “To insert an item in a text message”

Identification (CLI) service, you can assign a personal ring signal to up to ten callers.

on page 52.

26 Personalizing your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 27

To set a specific ring signal for a caller

1. Scroll to Phonebook, Personal rings, New contact.

2. Enter the first letters of the contact,

Ok.

3. Select a contact.

4. Select a ring signal.

Menu language

Most SIM cards automatically set the menu language to the language of the country/region where you bought your SIM card. If this is not the case, the preset language is English.

Sound and alerts

You can choose to be notified of an incoming call by the buzzing of the vibrating alert. You can set the

To change the menu language

1. Scroll to Settings, Language, Menus.

2. Select a language.

phone’s vibrating alert to one of the following:

• On – all the time.

• On if silent – on when the ring volume is turned off or when you have set the phone to silent.

• Off – all the time.

Display light

The display light can be set to automatic or on. In automatic mode, the display light is turned off a few seconds after you last press a key.

• To set the display light, scroll to Settings,

To set the vibrating alert

1. Scroll to Settings, Sounds and alerts, Vibrating alert.

2. Select the setting you want.

From the Settings, Sounds and alerts menu, you can also select Message alert, Key sound and turn on the Minute minder.

If you turn on the minute minder, you hear a beep

Display, Light.

• To set the display contrast, scroll to Settings, Display, Contrast.

Time settings

The time is always displayed in standby.

• To set the time, scroll to Settings, Time and date, Set time.

once every minute during a call.

Personalizing your phone 27

This is the Internet version of the user's guide. © Print only for private use.

Page 28

You can choose a 12-hour clock or a 24-hour clock.

• To set the time format, scroll to Settings, Time and date, Time forma t.

Answering mode

When using a portable handsfree kit, you can choose to answer a call by pressing any key (except the key) or set the phone to answer the call

Date

When the phone is in standby mode, you can press a volume key up or down to see today’s date in the

automatically.

• To select answering mode, scroll to Settings, Handsfree, Answering mode.

Status menu.You can set the date and date format in the Settings, Time and date menu.

Start-up picture

When you turn your phone on or off, the Sony

Advanced time settings

Under Advanced in the Settings, Time and

Ericsson start-up picture appears in the display. Your operator’s own greeting may be shown instead.

date menu, you can set time zone and daylight saving time. By changing these you also change the time.

When your phone changes network, and the time

To select a start-up picture

1. Scroll to Settings, Display, Start-up picture.

2. Select My pictures.

sent out from the operator deviates from the time in your phone, you are asked whether you want to update the time if you have turned on Auto time zone. If you press

Yes, the time is

updated automatically.

My phone numbers

You can check your own phone number(s).

• To check your phone number, scroll to Phonebook, Special numbers, My numbers. If your number is not saved on your SIM card, you can enter it yourself.

28 Personalizing your phone

This is the Internet version of the user's guide. © Print only for private use.

Page 29

Keypad lock

You can lock the keypad to avoid dialling a number by accident.

To add a function to my shortcuts

1. Scroll to My shortcuts, Edit shortcuts.

2. Select a function from the list by pressing

3. Enter the position number you want for this function

Note: Calls to the international emergency

number 112 can still be made, even when the

in your menu and press

Save to exit the list.

4. Press

Ok.

keypad is locked.

Profiles

Automatic keylock

Automatic keylock means the keypad is locked 25 seconds after you last press a key.

• To lock the keypad manually, press

Calling

Before you can make or receive any calls, you must turn on the phone and be within range of a network. See “Turning the phone on” on page 6.

Making calls

1. Enter the area code and the phone number.

Call to make the call.

2. Press

End call to end the call.

3. Press

To change the earpiece volume during a call

Use the volume keys on the side of the phone to increase or decrease the earpiece volume during acall.

To turn off the microphone during a call

• Press and hold until the display shows Muted.

• Press and hold again to resume the conversation.

Automatic re-dialling

If the connection of the call failed and the display shows Retry?, press

Yes. The phone re-dials the

number (up to ten times):

• Until the call is connected.

• Until you press a key or receive a call.

Note: Do not hold the phone to your ear while waiting. When the call is connected, the phone gives out a loud signal. Automatic re-dialling is not available for fax and data calls.

Making international calls

1. Press and hold until a + sign appears in the display. The + replaces the international prefix number of the country/region from which you are calling.

2. Enter the country/region code, area code (without the leading zero) and phone number,

Call.

Note: The microphone must be turned on to change the earpiece volume during a call.

Making emergency calls

• Enter 112 (the international emergency number),

Call.

This is the Internet version of the user's guide. © Print only for private use.

Calling 31

Page 32

Your phone supports the international emergency numbers, 112, 911 and 08. This means that these numbers can normally be used to make an emergency call in any country/region, with or without a SIM card inserted, if a GSM network is within range.

Note: Some network operators may require that a SIM card is inserted, and in some cases that the PIN has been entered as well.

If your subscription includes the Calling Line Identification service and the caller’s number is identified, the number is displayed. If you have saved the number in the Phonebook, the name and number are displayed. If you have assigned a picture to a contact, the picture is displayed. If the number is a restricted number, the display shows Withheld.

To answer a call

Yes.

• Press

In some countries/regions, other emergency numbers may also be promoted. Your operator may therefore

To reject a call

No.

• Press

have saved additional local emergency numbers on the SIM card.

• To view your local emergency numbers, scroll to

Tip: You can also use your voice to answer or reject calls. See “Voice control” on page 37.

Phonebook, Special numbers, SOS numbers.

Missed calls

Receiving calls

When you receive a call, the phone rings and the

If you have missed a call, Missed calls:1 appears in standby, indicating the number of missed calls.

display shows Answer?

To check your missed calls

Yes to display the missed calls.

1. Press

2. To call a number from the list, scroll to the number,

Call.

32 Calling

This is the Internet version of the user's guide. © Print only for private use.

Page 33

Call list

The numbers of the last 30 calls that you have made are saved in the call list. If your subscription includes the Calling Line Identification service and

To check or change your standard priority level

1. Scroll to Calls, Manage calls, Default priority.

2. The network sends available priority levels.

3. Select a priority level.

the caller’s number is identified, you will also find the numbers of answered and missed calls in the call list.

To change the priority for one call

1. Enter the phone number you want to call.

2. Scroll to Calls, Next call, Next incoming call.

To call a number from the call list

1. To enter the call list, press

Calls from standby.

2. Scroll to the number you want to call,

Call.

3. Select a priority. The number is called.

Phonebook

In the Phonebook you can store the information on

• To clear the call list, scroll to Calls, Options, Clear call list.

• To turn the call list on or off, scroll to Calls, Options, Call listing.

your SIM card and on your phone. You have space for up to 510 numbers. You can save all the information needed to contact people. You can also set how much information you want to show for your contacts.

Call priority service

You can request a certain priority when you make a call, if your subscription supports the call priority service.

Entries saved are stored in your phone’s memory, not on your SIM card. To synchronize your phonebased contact list with your PDA or PC, see “Synchronization” on page 77.

The priority levels are defined by your operator and are normally within the range of 0 - 4, where 0 is the highest priority.

To set the fields in contact information

1. Scroll to Phonebook, Options, Contact info.

Check/Uncheck to select or clear fields.

2. Press

This is the Internet version of the user's guide. © Print only for private use.

Calling 33

Page 34

If your Phonebook is empty, you are prompted to copy information from your SIM card. If you press

No, you can add new contacts. If you press Yes, your

names and numbers are copied from your SIM.

To add a contact

1. Scroll to Phonebook, Add contact.

2. Scroll to the field you want to fill in,

3. Enter the information,

Ok.

Add.

4. Select the next field and so on.

5. When you have entered the information, press

Tip: To enter an unsaved number, press

Look up

when you are in a number field, and select a number in the unsaved numbers list.

Pictures, personal rings and voice commands

You can add a picture, personal ring signal and voice command to a contact.

• Select Personal rings to add a personal ring signal.

• Select Voice commands to add a voice command.

To call a contact from your contact list

1. From standby, press and hold one of the number keys 2-9 to find a contact beginning with the first letter on that key (or closest following).

• For example, press and hold 5 to go to the first

contact beginning with “J”. To go to a contact beginning with “L” press 5 three times after you

Save.

have entered the list of contacts.

2. When the contact you want to call is highlighted,

Select.

press

3. Select the number you want to call.

To call a contact from your SIM card

1. Scroll to Phonebook, Advanced, Call from SIM.

2. Enter the first letters of the contact,

3. Scroll to the name,

Call.

Ok.

To add a picture to a phonebook contact

1. Scroll to Phonebook, Pictures.

2. Enter the first letters of the contact,

Ok.

Updating the phonebook

When needed, you can easily update or delete any contact information.

3. Select a contact.

4. This takes you to My pictures. Select a picture,

34 Calling

Yes.

This is the Internet version of the user's guide. © Print only for private use.

Page 35

To edit a contact

1. Scroll to Phonebook, Manage contact, Edit contact.

2. Enter the first letters of the contact,

3. When the contact is highlighted, press

Ok.

Edit.

4. Select Edit info.

5. Scroll to the field you want to fill in,

6. Enter the information,

Ok.

Edit.

7. Select the next field and so on.

8. When you have entered the information, press

Save.

Default (standard) number

Each contact has a default phone number. The first phone number you link to a contact automatically becomes the default number. If you scroll to a certain contact in the Call contact list and then press

Select, the default number is highlighted.

To set the default number

1. Scroll to Phonebook, Manage contact, Edit contact.

2. Enter the first letters of the contact,

To delete a contact

• Scroll to Phonebook, Manage contact, Delete contact. Then select the contact and

Delete.

press

3. Select the contact,

4. Select Default number. Highlight the number you

want as default, press

Edit.

Select.

Groups

Tip: You can also delete a contact by pressing when the contact is highlighted.

You can create a group of contacts. By doing so, you can send text messages to several recipients at the same time. See “Sending text messages” on page 51.

To delete all contacts

• To delete all contacts, scroll to Phonebook, Advanced, Delete all.

Note: Contacts that are saved on the SIM card are not deleted.

To create a group of contacts

1. Scroll to Phonebook, Manage contact, Groups, New group,

Add.

2. Enter a name for the group,

3. Select New member,

Add.

4. Enter the first letters of the contact,

This is the Internet version of the user's guide. © Print only for private use.

Ok.

Calling 35

Page 36

5. Select the contact.

6. Select a phone number.

7. Repeat steps 3-6 to add more members.

To receive a business card

1. From standby, press

More and scroll to

Turn on Bluetooth or Turn on infrared.

2. When you receive the business card, press

Business cards

You can add your own business card to the Phonebook.

• To add your own business card, scroll to Phonebook, Manage contact, My card. Then select Add.

To send a contact

1. Scroll to Phonebook, Manage contact, Send contact.

2. Enter the first letters of the contact you want

Ok.

to send,

3. Scroll to the contact you want to send,

Exchanging business cards

4. Select transfer method. You can exchange business cards between your phone and another similar phone, a PDA or a PC, using Bluetooth wireless technology, the infrared port, text or picture message.

To send your business card

1. Scroll to Phonebook, Manage contact, My card, Send.

2. Select a transfer method.

When you receive a business card via a text message, you accept the card by pressing

Yes. To be

able to receive a business card using the infrared port or Bluetooth wireless technology, you need to turn

To send all contacts

• Scroll to Phonebook, Advanced, Send all and select a transfer method.

Copy names and numbers

You can copy the names and numbers between your phone’s memory and the SIM card. The number of phone numbers that can be saved depends on the type of SIM card.

To copy names and numbers to the SIM card

• Scroll to Phonebook, Advanced, Copy all to SIM.

these functions on.

36 Calling

This is the Internet version of the user's guide. © Print only for private use.

Yes.

Send.

Page 37

Note: Everything on the SIM card is replaced.

If you insert a SIM card with saved numbers in your phone, you can call a number by selecting Phonebook, Advanced, Call from SIM. If you want to edit a name and number saved on the SIM card, you first need to copy the name and number to the phone.

To change position numbers

1. Scroll to Phonebook, Advanced, Position list.

2. Select the phone number you wish to change.

3. Select the position to which you want to move the

phone number.

4. Repeat steps 2 and 3 to continue to move phone numbers.

5. When you have finished, press

back.

To copy names and numbers to the phone

• Scroll to Phonebook, Advanced, Copy from SIM.

Checking the memory

With the Memory status function in your Phonebook, you can check how many positions you

Tip: When you have selected a name on the SIM card in the Call from SIM menu, you can copy it to the phone by pressing

More and then selecting Copy

to phone.

have left in your memory for the phone, SIM, e-mail and voice commands.

To check the memory

• Scroll to Phonebook, Advanced, Memory status.

Speed dialling

You can save the phone numbers that you want to reach easily in positions 1-9 on your SIM card.

Voice control

With your phone, you can use your voice to:

• Voice dial – call someone by saying the name and

To call any of these phone numbers from standby:

• Enter the position number and press

Call.

number type.

• Re-dial the last dialled number.

• Answer and reject calls when using a handsfree kit.

• Change profile.

This is the Internet version of the user's guide. © Print only for private use.

Calling 37

Page 38

• Record or listen to sound recordings by using voice commands.

• Activate the voice control by saying a “magic word”. You can save approximately 50 recorded words as voice commands in the 40 seconds available. This also depends on what is saved in the memory with

5. Lift the phone to your ear, wait for the tone and say the command that you want to record. The voice command is played back to you.

6. If the recording sounds OK, press voice command. If not, press

7. Repeat steps 4 and 5 for each voice command you need.

other functions. When recording, make sure you are in a quiet environment.

You also need to record voice commands for each contact name, for example, “John”.

Before voice dialling

You must first turn on the voice dialling function and record your voice commands.

To record a voice command for a contact name

1. Scroll to Settings, Voice control, Voice dialling, Edit names, New voice.

To turn voice dialling on and record number types

1. Scroll to Settings, Voice contro l, Voice dialling.

2. Select On. Now you are going to record a voice

2. Select a contact.

3. Follow the instructions in the display.

An icon appears next to a contact name that has a voice command.

command for each number type you use with your Phonebook contacts, for example, “home” or “mobile”.

3. Instructions appear. Press

Ok.

4. Select a number type.

Caller name

You can choose whether you want to hear the recorded contact name when you receive an incoming call from that contact.

• To turn the caller name On or Off, scroll to Settings, Voice control, Caller name.

38 Calling

This is the Internet version of the user's guide. © Print only for private use.

Yes to save the

No and repeat step 4.

Page 39

Voice dialling

You can voice dial by saying a pre-recorded word or by using specific key sequences.

Redialling

You can use your voice to redial the last dialled number, if you record a voice command for redialling.

To make a call

1. From standby, press and hold a volume key for one second.

2. Lift the phone to your ear, wait for the tone and say a name, for example “John”. The name is played back to you.

3. If you have several numbers for that contact, after a second tone, say the number type,

To turn on and record a redial command

1. Scroll to Settings, Voice control, Voice redial.

2. Select On.

3. Instructions appear. Press

4. Lift the phone to your ear, wait for the tone and say

“Redial”, or another word. If the recording sounds OK, press

Yes. If not, press No and repeat step 4.

for example, “home”. The number type is played back to you, and the call is connected.

To redial using a voice command

1. From standby, press and hold a volume key for one second.

From standby, you can also initiate voice dialling, voice profiles and voice control of sound recordings by:

2. Lift the phone to your ear, wait for the tone and say “Re-dial”. The voice command is played back to you and the last dialled number is called.

• Pressing and holding a volume key.

• Pressing the handsfree button (when using a portable handsfree or a Bluetooth headset).

• Saying the magic word. See “The magic word” on page 40.

Voice answering

You can answer or reject incoming calls by using your voice, when using a portable handsfree or a car handsfree kit.

This is the Internet version of the user's guide. © Print only for private use.

Ok.

Calling 39

Page 40

To turn on voice answering and record voice answer commands

1. Scroll to Settings, Voice contro l, Voice answer.

2. Select On.

3. Select the accessories you want to be able to use

with voice answering by pressing

Save.

then

4. Instructions appear. Press

Check and

Ok.

5. Lift the phone to your ear, wait for the tone and say “Answer”, or another word. If the recording sounds OK, press

6. Say “Busy”, or another word. Press

Yes. If not, press No and repeat step 5.

Ok.

The magic word

You can record a magic word and use it as a voice command to allow total handsfree access to voice control. Instead of pressing a volume key, you say the magic word and then one of your recorded voice commands. The magic word is especially suitable when using a car handsfree kit.

Tip: Choose a long, unusual word or phrase which can easily be distinguished from ordinary background speech.

To turn on and record the magic word

To answer a call using voice commands

When the phone rings, say “Answer”. The call is connected.

1. Scroll to Settings, Voice control, Magic word.

2. Select On.

3. Select the accessories you want to be able to use

with the magic word by pressing

Save.

To reject a call using voice commands

When the phone rings, say “Busy”. The call is rejected. The caller is diverted to voice mail, if turned on, or hears a busy tone.

then

4. Instructions appear. Press

5. Lift the phone to your ear, wait for the tone and say

the magic word.

Tip: Turn off the magic word when you no longer need total handsfree access in order to save battery power.

40 Calling

This is the Internet version of the user's guide. © Print only for private use.

Check and

Ok.

Page 41

Changing profiles

If you record voice commands for your profiles, you can change profile with your voice.

To turn on and record recording commands

1. Scroll to Settings, Voice control, Sound recorder.

2. Select On.

3. Instructions appear. Press

To turn on and record profile commands

1. Scroll to Settings, Voice contro l, Voice profiles.

2. Select On.

3. Instructions appear. Press

Ok.

4. Select a profile.

5. Lift the phone to your ear, wait for the tone and say

the profile name. Repeat steps 4 and 5 to record voice commands for the other profiles.

4. Lift the phone to your ear, wait for the tone and say “Record”, then press

5. Say “Play”, press

Yes.

To start a recording using a voice command

1. From standby, press and hold a volume key for one second.

2. Lift the phone to your ear, wait for the tone and say “Record”. The voice command is played back to you

To change a profile using voice commands

1. From standby, press and hold a volume key for

and a tone indicates that the recording has begun.

3. To end the recording, press

one second.

2. Lift the phone to your ear, wait for the tone and say the profile command for the required profile. The profile command is played back to you and the current profile is changed.

To listen to recordings using a voice command

1. From standby, press and hold a volume key for one second.

2. Lift the phone to your ear, wait for the tone and say “Play”. The voice command is played back to you.

Sound recordings

3. Listen to your recordings. Press

Instead of using the menus, you can record voice commands to start or to listen to a recording.

This is the Internet version of the user's guide. © Print only for private use.

Ok.

Stop.

Stop to stop.

Calling 41

Page 42

Editing your voice commands

You can keep all your voice commands up to date by re-recording them or deleting the ones you do not use. See the following example:

• The voice command was too short – it should be around one second long and more than one syllable.

• You spoke too late or too soon – speak immediately after the tone.

• You did not record the voice command when the

To re-record a voice command

1. Scroll to Settings, Voice contro l, Voice profiles, Edit commands.

2. Select a voice command.

3. Select Replace voice.

handsfree was attached – for voice control with a handsfree kit, record when the handsfree is attached.

• You used another intonation – use the same intonation as you did when recording the voice command.

To listen to a recorded voice command, select Play voice.

4. Lift the phone to your ear, wait for the tone and say the command. You can also edit the voice command for a contact

Voice mail

If your subscription includes an answering service, callers can leave a voice mail message when you cannot answer a call.

name in Edit contact in the Phonebook menu.

Receiving a voice mail message Tips when recording and using voice commands

If your phone cannot detect speech, one of the following might have happened:

Depending on your network operator, you are

informed that someone has left a message by a text

message or by a voice mail indication. Press

listen to the message.

• You spoke too softly – try speaking more loudly.

• You held the phone too far away – hold it as you do during a call.

42 Calling

This is the Internet version of the user's guide. © Print only for private use.

Yes to

Page 43

Calling your voice mail service

You can easily call your voice mail service by pressing and holding , if you have saved your voice mail number in the phone. You get the number from your service provider.

• To enter the number, scroll to Messaging, Options, Voice mail number.

Note: If you subscribe to cost information, you must enter your PIN2 to clear the cost or time counter.

Setting the call cost

You can use the Tariff function to specify the price per call unit. If you do not specify a price per call unit, the number of call units appears.

Call time and cost

During a call, the duration of the call is shown in the display. If you subscribe to cost information, the call cost (or the number of call units) is displayed.

To enter the price per call unit

1. Scroll to Calls, Time and cost, Call costs, Set tariff.

2. Enter your PIN2,

3. Select Change,

Ok.

4. Enter the code for the currency you want, (for example GBP for Pounds Sterling),

You can check the duration of your last call, outgoing calls and the total time.

5. Enter the price per call unit, To enter a decimal point, press .

• To check the call time, scroll to Calls, Time and cost, Call timers and select an option. To reset the call time meter, select Reset timers.

Credit limit for calls

You can enter a total amount of money that

can be used for making calls. When the You can check the cost of your last call and the total cost of your calls.

• To check the call cost, scroll to Calls, Time and cost,

amount reaches zero, no more calls can be

made. Please note that the credit limit is only an

estimated value. Call costs and select an option. To reset the call cost meter, select Clear total cost.

This is the Internet version of the user's guide. © Print only for private use.

Ok.

Calling 43

Page 44

To set a credit limit

1. Scroll to Calls, Time and cost, Call costs, Set credit.

2. Enter your PIN2,

3. Select Change,

4. Enter an amount,

Ok.

To turn on a call divert

1. Scroll to Calls, Divert calls.

2. Select a call category and then a divert alternative.

3. Select Activate.

4. Enter the phone number to which you want your

calls to be diverted and press

Diverting calls

the Phonebook. If you cannot answer incoming voice, fax or data calls, you can divert them to another number, for example your

To turn off a call divert, select a divert option and

select Cancel. answering service.

For voice calls, you can choose between the

following divert alternatives:

• Divert always – divert all voice calls.

• When busy – divert calls if you are already on

the phone.

• Not reachable – divert calls if your phone is

To check status

• Scroll to Calls, Divert calls. Select a call type. Scroll to the divert you want to check. Select Get status.

• To check the status of all call diverts, select Check all in the Divert calls menu.

turned off or if you are unreachable.

• No reply – divert calls that you do not answer within a specified time limit (operator-dependent).

More than one call

You can handle more than one call simultaneously. For example, you can put an ongoing call on hold, while you make or

Note: When the Restrict calls function is on, some Divert calls options cannot be activated.

44 Calling

answer a second call, and then switch between the two calls.

This is the Internet version of the user's guide. © Print only for private use.

Ok, or retrieve it from

Page 45

Call waiting service

If the call waiting service is on, you hear a beep in the earpiece if you receive a second call during an ongoing call.

• To turn the call waiting service on or off, scroll to Calls, Manage calls, Call waiting.

To make a second call

Hold to put the ongoing call on hold.

1. Press

2. Enter the number you want to call and press

Call, or

retrieve a number from the Phonebook.

Note: You can only put one call on hold.

• Press the joystick and select Switch calls to switch between the two calls.

• Press the joystick, then select Join calls to join the two calls into a conference call.

• Press the joystick, then select Transfer call, to connect the two calls. You are disconnected from both calls.

End call to end the ongoing call, then press

• Press

Yes to retrieve the held call.

End call twice to end both calls.

• Press

Note: You cannot answer a third call without ending one of the first two calls.

Receiving a second call

• To answer the second call and put the ongoing call on hold, select

answer.

• To reject the second call and continue the ongoing call, select Busy.

Conference calls

In a conference call, you can have a joint conversation with up to five other people. You can also put a conference on hold and make another call.

•Select Release&answer to answer the second call and to end the ongoing call.

Note: There may be additional charges for calls involving multiple parties. Contact your service

Handling two calls

provider for more information.

When you have one ongoing call and one call on hold, you can do the following:

This is the Internet version of the user's guide. © Print only for private use.

Calling 45

Page 46

Creating a conference call

To create a conference call, you must first have one ongoing call and one call on hold.

• Press the joystick, then select Extract part to select the participant that you want to talk with.

• Select Join calls to resume the conference call.

To join the two calls into a conference call

• Press the joystick and select Join calls,

Yes.

Two voice lines

Your phone may have two voice lines with different phone numbers. This may be

To add a new participant

Hold to put the conference call on hold.

1. Press

2. Call the next person you wish to include in the

useful if, for example, you want to keep business and private calls on separate lines.

• To select a line, scroll to Calls, Switch to line 1.

conference call.

3. Press the joystick and select Join calls. Repeat steps 1 to 3 to include more participants.

All outgoing calls are made on this line until you change it. Incoming calls can still be received on either line.

To release a participant

1. Press the joystick and select Release part.

2. Select the participant.

You can change the names of the lines, and have different settings for each line, for example, different ring signals.

• To change the name of a line, scroll to Settings,

To end the conference call

End call.

• Press

Display, Edit line tags.

Having a private conversation

You can have a private conversation with one of the participants and put the other participants on hold.

46 Calling

This is the Internet version of the user's guide. © Print only for private use.

Page 47

Calling card calls

You can use the calling card service to redirect the cost of a call to a credit card or a calling card account, instead of your normal account. This may be useful, for example, when making long distance calls.

3. Select New card. Enter the card settings (the access number and name of the calling card server, and the verification code). You get this information from your card provider. Select which you want to send first – the number that you want to call, or the verification code.

You can save two separate calling card numbers. The numbers and the codes associated with them are protected by the code.

Before making a calling card call, you need to select and activate a card.

To select a card

1. Scroll to Calls, Time and cost, Calling cards, My cards.

2. Enter your phone lock code,

3. Select a card.

Note: You cannot use the calling card service for fax

4. Select Activate card.

and data calls.

To make a calling card call

To turn the calling card service on or off

1. Scroll to Calls, Time and cost, Calling cards, Use calling cards.

2. Enter your phone lock code,

Ok.

3. Select On or Off.

1. Enter the phone number of the person you want to

call or retrieve the number from the Phonebook.

More, select Call via call. card

2. Press The access number of the calling card server is called. During the connecting phase, you are asked to send the phone number you want to call and the

To save a card number

1. Scroll to Calls, Time and cost, Calling cards, My cards.

2. Enter your phone lock code,

Ok.

verification code.

Yes when the display shows Send called

3. Press

number?, or wait a few seconds and the number and code are sent automatically.

This is the Internet version of the user's guide. © Print only for private use.

Ok.

Calling 47

Page 48

Restricted dialling

• To change the PIN, select Change password. You can use the restrict calls service to restrict outgoing and incoming calls. This may be useful, for example, when you are abroad. To use this service, you need a password which you get from your service provider.

Fixed dialling

The fixed dialling function allows calls to be made only to certain numbers saved on the SIM card. Fixed dialling requires a SIM card that allows fixed numbers to be saved. The

Note: If you divert incoming calls, you cannot

fixed numbers are protected by your PIN2.

activate some Restrict calls options.

Note: Calls to the international emergency number

The following calls can be restricted:

• All outgoing calls – All outgoing.

112 can still be made, even when the fixed dialling function is on.

• All outgoing international calls – Outgoing intl.

• All outgoing international calls except to your home country/region – Outgoing intl roam.

• All incoming calls – All incoming.

• All incoming calls when you are abroad (when roaming) – Inc when roam.

• Partial numbers can be saved. For example, saving 0123456 allows calls to be made to all numbers starting with 0123456.

• Numbers with question marks can be saved. For example, saving 01234567?0, allows calls to be made to numbers from 0123456700 to 0123456790.

To turn a call restriction on or off

To enter a question mark, press and hold .

1. Scroll to Calls, Manage calls, Restrict calls.

2. Select an option.

3. Select Activate or Cancel.

4. Enter your PIN,

Ok.

• To turn off all call restrictions, select Cancel all.

48 Calling

To turn fixed dialling on or off

1. Scroll to Phonebook, Options, Fixed dialling.

2. Enter your PIN2,

Ok.

3. Select On or Off.

This is the Internet version of the user's guide. © Print only for private use.

Page 49

• To save a fixed number, scroll to Phonebook, Special numbers, Fixed numbers. Select New number and

enter the information.

• To call outside a Closed User Group, select Calls, Manage calls, Closed groups, Open calls and then select On.

Closed user groups

The Closed User Group function is a way of lowering call costs. On some networks it is cheaper to make calls within a call group. You can save ten groups.

Accept calls

With the accept calls service, you can choose to receive calls only from certain numbers. Other calls are automatically rejected by a busy tone. The phone numbers of calls you have rejected are saved in the Call List.

To add a group

1. Scroll to Calls, Manage calls, Closed groups, Edit list.

2. Scroll to New group,

3. Enter the name of the user group,

4. Enter the index number,

Add.

Ok.

You get the index number from your operator.

To add numbers to the accepted callers list

1. Scroll to Calls, Manage calls, Accept calls, Accepted list.

2. Scroll to New,

Add.

This takes you to the Phonebook or Groups.

3. Select an entry.

• To select an accept option, scroll to Calls,

To activate a group

Manage calls, Accept calls, Accept options.

1. Scroll to Calls, Manage calls, Closed groups, Edit list.

2. Select a group.

3. Select Activate.

Calls can only be made within the selected group.

This is the Internet version of the user's guide. © Print only for private use.

Calling 49

Page 50

Networks

When you turn on the phone, it automatically selects your home network if this is within range. If it is not within range, you may use another network, provided your network operator has an agreement that allows you to do so. This is called roaming.

You can select the network you want to use, or

Notepad

You can use the phone to make a note of a phone number during a call. When you press the number keys, the person you are talking to hears tone signals. To turn these tone signals off during the call, press the joystick and select Turn off tones. When you end the call, the number remains in the display.

You can then call the number by pressing you can add a network to your list of preferred networks. You can also change the order in which networks are selected during an automatic search. For all such options, scroll to Connectivity, GSM Networks.

Showing or hiding your number

If your subscription supports the Calling

Line Identification Restriction (CLIR)

service, you can hide your phone number

when making a call.

Tone signals

You can use telephone banking services or control an answering machine by sending tone signals (also known as DTMF tones or touch tones) during a call.

To show or hide your phone number

1. Enter the phone number you want to call.

More and select Call and hide ID or

2. Press

Call and show ID.

• To send the tones, press the number keys 0-9, or .

• To clear the display after the call is finished, press .

50 Calling

This is the Internet version of the user's guide. © Print only for private use.

Call.

Page 51

Messaging

Your phone supports various messaging services text messaging, chat messaging, picture messaging and e-mail. Please contact your service provider for details of which services you can use. For more information about text, see “Entering letters” on page 14.

To set the service centre number

1. Scroll to Messaging, Text, Options, Service centres. If the service centre number is saved on the SIM card, it appears in the display.

2. If there is no number in the list, select New number,

Add.

3. Enter the number, including the international “+” sign and country/regional code,

Ok.

Text messaging

Text messages can be sent to one person, several recipients or to a group of recipients that you have

Sending text messages

For information about entering letters, see “Entering letters” on page 14.

saved in the Phonebook. See “Groups” on page 35. Text messages can also contain pictures, animations, melodies and sounds.

To write and send a text message

1. Scroll to Messaging, Text, Write new.

2. Write your message.

Continue, the following options appear:

Before you start

• First make sure that the number of your service centre is set. The number is supplied by your service provider and is usually saved on the SIM card.

3. Select

• Contacts – send the message to a phonebook entry.

• Phone number or E-mail address– send the message to a phone number or to an e-mail address.

• SIM entries – send the message to an entry on your SIM card.

• Groups – send the message to a group of contacts.

This is the Internet version of the user's guide. © Print only for private use.

Messaging 51

Page 52

• Unsaved numbers – send the message to a number in your unsaved list.

4. Enter a recipient’s phone number/e-mail address or

Look up to retrieve contact information.

press

Send.

5. Press

3. Select Text f o rma t . Then select Tex t styl e , Text size,

Alignment or New paragraph.

4. Select a text format,

Ok.

Receiving text messages

When you receive a text message, the phone beeps

Note: If you send a text message to a group, you are charged for each member of that group.

and the message Read now? appears in the display.

Yes to read the text message, or No if you want

Press to read the message later. You may not receive all

To insert an item in a text message

parts of a long message at the same time.

1. Scroll to Messaging, Te xt , Write new.

2. While writing your message press

3. Select Insert item.

4. Select Picture, Sound effect, Melody,

Animation or Picture (other).

5. Select an item,

Yes.

More.

• While reading the text message you can, for example, start a chat session with the sender or go to a WAP address found in the text message.

When you have read the text message, press to view a list of options. Press to close the text message.

Text formatting

You can change the style, size and alignment of the text, and create new paragraphs, in a text message.

Calling a number in a text message

You can call a phone number that appears in an text message.

To format the text in a text message

• Select the phone number,

1. Scroll to Messaging, Te xt , Write new.

2. Write the text message. Press

52 Messaging

More.

This is the Internet version of the user's guide. © Print only for private use.

Call.

Page 53

Saving incoming text messages

Incoming text messages are saved in the phone memory. It is also possible to save messages on the SIM card. Messages that you have saved on the SIM card remain there until you delete them.

Tem pla tes

If you have one or more messages that you send often, you can save these as templates. There are five pre-defined templates in your phone, but you can also create your own.

To save from a text message

When the phone number, WAP address, picture, animation or melody is highlighted, press Then select

Save.

More.

• A picture or animation is saved in My pictures.

• A melody is saved in My sounds.

To create a template

1. Scroll to Messaging, Text, Templates, New template,

2. Write the message,

3. Press

Press

Add.

Ok. Yes if you want to send the message now. No to save the template.

• A phone number is saved in Phonebook.

• A WAP address is saved in Bookmarks.

Message options

You can set a default value for the message

Long messages

A text message can contain up to 160 Latin characters or 70 Chinese characters. You can send a longer message by linking two or more messages. Please note that you are charged for each message within a linked message.

• To turn long messages on, select Long messages from the Messaging, Te xt , Options menu,

options below, or you can turn on the Set on send option which means that you choose the settings each time you send a message.

• SMS type – The phone supports different types of messages. Your service provider may offer the facility of converting a text message into a format (e-mail or fax, for example) that suits the equipment that is going to receive the message.

then select On.

This is the Internet version of the user's guide. © Print only for private use.

Messaging 53

Page 54

• Validity period – If your message cannot be delivered, for example, if the recipient has turned off the phone, your service centre can save the message to send it later.

• Request reply – Include a reply request if you want the recipient of your message to reply.

• Status request – Check if a message has been delivered.

Picture Messages

Picture messages can contain text, pictures and sounds and are sent via MMS (Multimedia Messaging Service). You must have a subscription that supports MMS. Picture messages can be sent to a mobile phone and e-mail account. You can also send contacts, calendar entries, sound recordings and notes as attachments.

To set a default message option

1. Scroll to Messaging, Te xt , Options.

2. Select an option.

Before you start

Before sending a picture message, make sure that:

• The number to your service centre is set. To set the message server number, scroll to Messaging,

To turn set on send on or off

• Repeat steps 1 and 2 above, then select Set on send.

Picture, Options, Message server.

• You have entered the WAP settings. Scroll to Messaging, Picture, Options, WAP profile and select

To check the status of a sent message

• Scroll to Messaging, Tex t, Sent items, select a text message,

More, View status.

Select or Create new. To create a WAP profile, see

“Setting up WAP and e-mail” on page 63. Your operator can automatically download all the settings you need.

To compose and send a picture message

1. Scroll to Messaging, Picture, Create new. The following options appear:

• Picture – From My pictures.

54 Messaging

This is the Internet version of the user's guide. © Print only for private use.

Page 55

• Te xt – Write a message.

• Sound – From My sounds.

• Camera picture – From the Camera.

• Recording – Add a sound recording. Use the volume keys to change the volume in Picture message recordings.

• Page – Start a new page.

2. Select an option.

Add to continue composing the message.

3. Press

More for the following options:

4. Press

• Send – Send the message.

• SIM entries – send the message to an entry on your SIM card.

• Groups – send the message to a group of contacts.

• Unsaved numbers – send the message to a number in your unsaved list.

6. Enter a recipient’s phone number or press to retrieve contact information.

Send.

7. Press

Note: If you entered the number manually, press

proceed to go to “Advanced send options”.

• Preview – View the message before sending.

• Preview page – View the page in the message.

• Page timing – Set the duration in seconds that the page will be shown on the recipient’s display.

• Background – Set the background colour.

• Delete page – Remove a page.

5. Select

Send the following options appear:

• Contacts – send the message to a phonebook entry.

• Phone number – send the message to a phone number.

• E-mail address – send the message to an email address.

Send options

Before sending a picture message, you can set different options.

• To edit an option, scroll to Messaging, Picture, Options.

Advanced send options

You can enter more information to accompany the message as follows:

• To : – Phone number or e-mail address. These can be selected from the Phonebook.

• Subject: – Write a title,

• Cc: – Phone number or e-mail address.

This is the Internet version of the user's guide. © Print only for private use.

Look up

Yes.

Messaging 55

Page 56

• Bcc: – Phone number or e-mail address.

• Attachments: – Add your own card, a business card or a melody from My sounds.

• Priority: – High, normal, low.

• Delivery report: – Turn on or off.

• Read report: – Turn on or off.

Restrict messages

From the Messaging, Picture, Options, Restrict messages, Home network or Roaming network select

one of the following:

• Allow – Your phone automatically downloads messages to your phone as soon as they come to your operator’s server. This is default.

Tip: You can base your message on one of the pre-defined templates.

• Always ask – You will be prompted to download or to keep it on the server.

• Restrict – New messages appear in the box as icons.

To use a pre-defined template for a picture message

1. Scroll to Messaging, Picture, Templates.

2. Select a template and press

Replace to make

changes.

No prompt is received with the message.

• From the Messaging, Picture, Options, Restrict messages, Filter, select the type of message you want to reject automatically:

• Advertisements

• Anonymous

Receiving picture messages

When you receive a picture message, the phone beeps and the message Read now? appears in the display. Press

Yes to read the message.

Mobile chat

The mobile chat function works in the same way as a chat on the Internet. You can choose a nickname that will appear in the recipient’s display each time you

Note: You can receive a maximum of 20 messages.

send a chat message.

You may have to delete old messages before you can receive new ones.

56 Messaging

This is the Internet version of the user's guide. © Print only for private use.

Page 57

To enter a chat nickname

1. Scroll to Messaging, Chat.

2. Select Nickname.

If you receive a new chat message while another chat session is ongoing, press ongoing session and start the new one.

3. Enter your nickname (maximum of 11 characters or 12 Chinese characters),

Ok.

Area information

Area information is a type of text message

To start a chat session

1. Scroll to Messaging, Chat, Start new.

2. Enter the recipient’s phone number and press

retrieve it from the Phonebook by pressing

3. Write your message,

Send.

Ok, or

Look up.

(for example, a local traffic report) that is sent to all subscribers in a certain network area. When you receive an area information message, the message automatically appears in the display. You cannot save area messages. Please consult your service provider for more information about area

Receiving a chat session invitation

When you receive a chat session invitation, the phone beeps and the message Chat Message Chat now? appears in the display.

• To read the chat message, press

• Write your chat message reply and press

Yes.

• To suspend a chat session, press .

• To resume a chat session, scroll to Messaging, Chat, Resume.

• To end a chat session, press and hold .

• To reject a chat message, press

No.

information codes.

• To turn area information on or off, scroll to Messaging, Area info, Reception.

• To enter an area information code, scroll to Messaging, Area info, Message list, New code.

Cell information

The cell information channel is used by some network operators to send messages to their subscribers within a certain network area.

• To turn on the channel, scroll to Messaging, Area info, Cell information.

This is the Internet version of the user's guide. © Print only for private use.

Yes to end the

Messaging 57

Page 58

E-mail

You can use your phone to send and receive e-mail messages. Please note that you need a subscription that supports data transmission. For more information, consult your service provider.

and select either Phonebook or Archive. When you have finished adding recipients, press to return to writing an e-mail message.

• Cc: – If you want to send a copy of the message

to someone.

• Priority: – Set the message priority.

Before you start

First make sure that you have:

• Set up a data account.

• Subject: – Write a title,

• Te xt : – Write your message,

• Attachments – Add pictures to a message.

See “Data account” on page 65.

• Set up and selected an e-mail account. See “E-mail account settings” on page 70.

To retrieve a number from the phonebook or archive

Look up.

press When you have finished, press

Sending and receiving e-mail messages

The Send and receive option offers the fastest way to send e-mail messages saved in the Outbox and check for new e-mail messages.

3. Select one of the following:

• Send now – The e-mail message is sent.

• Send with attach. – You can attach a picture from My pictures or from a digital camera connected via IR. Select a picture and press

To write and send an e-mail message

1. Scroll to Messaging, E-mail, Write new.

2. Select:

• To : – Then add name, enter an e-mail address, or retrieve an e-mail address from the Phonebook. To retrieve a saved address from the Phonebook or received messages in your inbox, press

58 Messaging

• Save to outbox – The e-mail message is saved in the Outbox.

• Save to drafts – The e-mail message is saved in the Drafts folder.

• Send and receive in the E-mail menu – All e-mail messages in the Outbox are sent.

This is the Internet version of the user's guide. © Print only for private use.

Done

Ok.

Done.

Send.

Page 59

To receive and read e-mail messages

1. Scroll to Messaging, E-mail, Send and receive.

2. When the e-mail messages have been downloaded to

the phone, scroll to Messaging, E-mail, Inbox to

Archiving

You can archive an e-mail message in order to read it later. You can archive only as much text as the display shows.

read them.

To archive an e-mail message

Note: The phone can save up to six complete e-mail messages depending on size or you can download headers only. See “E-mail account settings” on page 70. All e-mail messages are also saved on your e-mail server.

1. Open the e-mail message.

2. Make sure that the text you want to archive is visible

in the display.

3. Place the cursor in the text and press

4. Select Copy to archive The text can be found in

Archive in the menu. An arrow in the top or bottom left corner indicates that there are more messages on the server.

To delete an e-mail message (POP3 users)

1. Scroll to Messaging, E-mail, Inbox.

To reply to an e-mail message

Reply.

1. Select

2. Select Write new or Include this msg to include the

received message.

3. Write a message,

Send.

2. Scroll to the message and press

3. Select Mark for deletion. The message is deleted the

next time you connect to your e-mail server by

selecting Send and receive.

To delete e-mail messages (IMAP4 users) To save an e-mail address or a phone number

• When the e-mail address or phone number is highlighted, select

Save.

1. Scroll to Messaging, E-mail, Inbox.

2. Scroll to the message and press

3. Select Mark for deletion. The message is marked for

deletion on the server.

This is the Internet version of the user's guide. © Print only for private use.

More.

Messaging 59

Page 60

4. Select Empty inbox in the Options menu.

5. The message is deleted the next time you connect to

your e-mail server by selecting Send and receive.

60 Camera

This is the Internet version of the user's guide. © Print only for private use.

Camera

Your mobile phone has a digital camera. You can take pictures and send them as picture messages. To do this, you need a subscription that supports this service. Please check with your network operator. You can also use a picture as a screen saver or as wallpaper, or save it together with a contact in your phonebook so that the picture appears when that person calls. See “To add a picture to a phonebook contact” on page 34.

Page 61

Taking pictures

There are different ways to take a picture. You can scroll to Camera and hold the phone as shown in the illustration. You can see the subject in the phone display. Press

Capture to take the picture.

Press the camera button on the side of the phone to activate the camera. Hold the phone as shown in the illustration. You can see the subject in the phone display. Press the camera button again to take the picture.

Tip: You can take a rapid succession of pictures by repeatedly pressing the joystick.

This is the Internet version of the user's guide. © Print only for private use.

Camera 61

Page 62

You can also take a self-portrait. Hold the phone as shown in the illustration. You can see your reflection in the mirror provided. Press the camera button on the side of the phone to activate the camera. Press the camera button again to take the picture.

Options

When the camera is activated, press following options.

My pictures – View all your pictures. Size – Choose between 288x352 or 120x160. Night mode – Use in poor lighting conditions. Effects – Select different effects for your picture. Default name – Create a name for your picture. Self timer – The picture is taken a few seconds later.

Tip: To adjust the brightness, press the joystick up or down repeatedly.

Note: All phones that support pictures can receive the picture size 120x160. Some phones that support pictures cannot receive the picture size 288x352. The best picture size to view on a PC is 288x352.

Saving, discarding and deleting pictures

To discard a picture

When you have taken a picture, a Save icon will appear in the display immediately above the joystick. If you do not want to save the picture,

Discard.

select

62 Camera

This is the Internet version of the user's guide. © Print only for private use.

More for the

Page 63

To save a picture

• Press the joystick to save the picture in My pictures.

To delete a picture from My pictures

1. Scroll to Pictures & sounds, My pictures.

2. Highlight the picture you wish to delete,

Scroll to and select Delete,

Yes.

More.

Note: If Memory full appears, you cannot save any more pictures until you have deleted an item from the phone’s memory.

Picture messaging

Before you send a picture message, you need to enter your service centre number and WAP settings in your phone. Your network operator provides you with the settings. See “Setting up WAP and e-mail” on page 63. The phone that you are sending the picture to needs to support data transmission and pictures in order to receive and show the picture.

Setting up WAP and e-mail

In order to use the Internet, browse via WAP services or send and receive picture and e-mail messages, the following are required:

1. A phone subscription that supports data transmission.

2. Settings entered in your phone.

• Your settings may already be entered when you

buy your phone.

• You can receive settings in a text message

from your network operator or service provider. Settings are also available at www.SonyEricsson.com.cn.

• You can set up with the wizard in Connectivity,

WAP options, WAP profiles, New profile. The wizard is also started when you try to access the Internet without having configured a profile.

3. You may also have to register as a WAP/e-mail user with your service provider or network operator.

To take and send a picture

1. Scroll to Camera.

2. Take a picture by pressing

Send and create your picture message.

3. Press

Capture.

Note: Some settings are not necessarily mandatory. Please consult your network operator or service provider for more information.

Setting up WAP and e-mail 63

This is the Internet version of the user's guide. © Print only for private use.

Page 64

Receive settings in a text message

Your GSM network operator or Internet service

Note: The wizard starts automatically if no WAP settings exist in your phone.

provider may be able to send the required data account, WAP and e-mail settings direct to your phone in a text message.

To set up with the wizard

1. Scroll to Internet services, and select a homepage (for example Sony Ericsson).

To request settings from Sony Ericsson

1. Use a PC to go to http://www.SonyEricsson.com.cn. Select your region and then use the Configurators to request that a text message be sent to your phone with the settings you need.

2. When the message arrives,

Yes to install the new settings.

•Press

• After installation, see “Using WAP” on page 71.

2. Create now? appears. Press

3. Enter a name for the profile. Press

4. Select Connect using. Press

5. Select New account. Press

6. Select an account type, GSM data or GPRS data.

7. Select New account, and press

enter the following:

• A name for the data account.

• For GSM enter phone number and for GPRS enter

Note: If settings already exist in your phone, you can either keep or replace them. See “Enter or edit settings manually” on page 65.

APN (Access point name address) – the address of the external data network you want to connect to, either an IP address or a text string.

• Use your user id to log on to the external

Set up with the wizard

If your phone is not set up for WAP, you can ask your network operator or service provider to provide you with WAP settings information. Then you can simply use the wizard in your phone to help guide you through the relevant settings.

64 Setting up WAP and e-mail

data network.

• Use your password to log on to the external data network.

• Save the new data account.

• Select the new data account to be used.

8. Enter IP address for the gateway.

This is the Internet version of the user's guide. © Print only for private use.

Yes.

Ok.

Edit.

Add.

Edit,

Page 65

9. Save the new profile.

When editing a profile, you can do the following:

• Change the name of the profile.

Enter or edit settings manually

You can manually enter or edit settings information from your network operator or service provider.

• Select data account.

• Enter, Select, Change WAP gateway server address.

• Add more profile settings, see below.

To create profile settings manually

• Remove the profile.

1. Scroll to Connectivity, WAP options, WAP profiles.

2. Select New profile and press

profile, or select an existing profile and press edit an existing profile.

• See steps 3 - 7 in “To set up with the wizard” on page 64.

Add to create a new

Edit to

If you select Advanced settings you can also do the following:

• Enter the address of the WAP site you want to have as your homepage.

• Select an alternative data account, if the first fails.

• Enter your user id for the WAP gateway.

Note: If no settings exist, you must enter data account (connection settings) as well as WAP profile settings.

• Enter your password for the WAP gateway.

• See “WAP security” on page 68.

• View pictures while browsing.

3. Enter or edit settings until all required information is entered. Press

Save.

Data account

You may want to create or edit an existing

To edit profile settings

data account.

1. Scroll to Connectivity, WAP options, WAP profiles.

2. Select an existing profile and press

Edit to edit an

existing profile.

Setting up WAP and e-mail 65

This is the Internet version of the user's guide. © Print only for private use.

Page 66

To create a data account manually

• an e-mail gateway phone number.

1. Scroll to Connectivity, Data comm., Data accounts.

2. See steps 5 - 7 in “To set up with the wizard” on

page 64.

Descriptions

A data account includes connection settings for access to an Internet server at your service provider.

To edit a data account

1. Scroll to Connectivity, Data comm., Data accounts.

2. Select a data account.

3. Select

Edit.

4. Select the setting you want to edit.

5. Repeat step 4 for other settings you want to edit.

A WAP profile includes user settings that allow browsing and picture messaging. An e-mail account includes user settings that allow e-mail messaging direct from your phone, such as those provided by your Internet service provider. Alternatively, E-mail via WAP includes user settings that also allow e-mail messaging, such as

More settings information

To use the WAP browser, via a WAP service provider, you need settings for:

those provided by your Internet service provider. However, this is set up on your service provider’s WAP si te.

•a specific data account for WAP, and a WA P p r of i l e.

Note: Check with your WAP service provider if their site supports e-mail.

To use e-mail messaging, via an Internet service provider, you need settings for:

•a specific data account for e-mail, and an e-mail account.

WAP profile

The WAP settings are stored in a WAP profile. In most cases, you only need to use one profile to

access the Internet. To send a text message to an e-mail address via your network operator, you need to set:

66 Setting up WAP and e-mail

This is the Internet version of the user's guide. © Print only for private use.

Page 67

You set up and use additional WAP profiles, for example, when accessing secure Internet sites, such as a banking site or a corporate intranet. You then simply switch between profiles when you need to change the network connection. See “To set up with the wizard” on page 64 for more information.

GPRS settings that are available:

• APN – the address of the external data network you want to connect to, either an IP address or a text string.

• Your user id to log on to the external data network.

• Your password to log on to the external

Data account

You can have several data accounts saved in your phone with different settings for different purposes. The main setting for a data account is the connection method.

Data account settings can be created with the

wizard. See “Set up with the wizard” on page 64.

data network.

• Password request – if this setting is on, you are asked for a password each time you log on to the external data network.

• Preferred service – if you want to be able to accept incoming calls during a GPRS session, select Automatic. If not, select GPRS only.

• The IP address that the phone uses when

You can choose either GSM data or GPRS data account types.

communicating with the network. If you do not enter an address, the network provides you with a temporary IP address.

Note: Please contact your network operator for charging details.

• If the network does not provide the IP address to the DNS server automatically, you may enter it here.

GPRS (General Packet Radio Service) allows access where you can always be online.

• Advanced settings – these are optional. Consult your network operator.

Note: You need a subscription that supports GPRS.

Setting up WAP and e-mail 67

This is the Internet version of the user's guide. © Print only for private use.

Page 68

GSM settings include some settings that are similar to GPRS settings and some that are GSM specific as follows:

Note: Security for a connection between a WAP gateway and a WAP service provider is the responsibility of the WAP service provider.

• The phone number of your Internet service provider.

• Select the speed you want for the connection.

• Select analogue or ISDN connection.

To turn on a secure connection

1. Scroll to Connectivity, WAP options, WAP profiles.

2. Select the profile to be used. Press

3. Select Advanced, Security.

Note: If you want to change access type, you have to

4. Select On or Off.

create a new data account and select the access type you want to use.

Security module (Locks)

The security module is located on the SIM card, if

Preferred service

You can set GPRS or GSM as the preferred service.

your network operator or service provider supplies such a service. It can contain both certificates and your private keys. The security module is protected

To select preferred mode

• Scroll to Connectivity, Data comm., Preferred

by a special access PIN and your phone asks you for it when establishing a secure connection.

service and select GPRS and GSM or GSM only.

To enter the access PIN (for the security

WAP security

Your phone has support for WAP secure browsing. When you turn on security, the connection between

module) and the signature PIN

• Scroll to Connectivity, WAP options, Security, Locks.

your phone and the WAP gateway is secure.

68 Setting up WAP and e-mail

This is the Internet version of the user's guide. © Print only for private use.

Edit.

Page 69

Digital signatures

You can sign a contract with your phone by entering a digital signature PIN as if signing with a pen on paper. Digital signature records can be traced back to your private key through a certificate that is used for signing a contract. All transactions (signed contracts) made with your phone when browsing are stored in your phone.

1. Server certificates are used to identify a WAP gateway to the phone and to show that it is certified by a trusted authority. The server certificate is checked against trusted certificates that are stored in the phone or in a security module. If the phone cannot verify the identity of a server, you are given the option to terminate or continue the connection.

2. Trusted certificates are used to verify the WAP gateway that you are trying to connect to. Your

To check your contracts

• Scroll to Connectivity, WAP options, Security, Contracts.

phone may already contain trusted certificates when you buy it. If you have a security module, it may also contain trusted certificates. You can also download trusted certificates from www.SonyEricsson.com.cn.

Trusted certificates and Client certificates

To establish a secure connection when using certain WAP services, for example banking or WAP shopping, you need certificates in your phone.

3. Client certificates are located in a security module together with your private keys. Client certificates can be used to present your identity to a bank or other services. They can also be used for digital signatures.

• The different types of certificates are as follows:

To check the certificates in your phone

• Scroll to Connectivity, WAP options, Security, Client certificates.

Setting up WAP and e-mail 69

Page 70

E-mail account settings

An e-mail account specifies, for example, the server that is used for your e-mail messages.

• Protocol – select POP3 or IMAP4.

• Incoming server – enter the name or IP address of the service provider for incoming e-mail messages. For example, mail.server.com or 10.1.1.1.

There are two ways to create an e-mail account:

• create an e-mail account manually

• use the Internet

• Incoming port – if needed, change the number of the port used by the protocol you are using.

• Mailbox – enter a user name for your e-mail account.

• Password – enter a password for your e-mail

To create an e-mail account manually

1. Scroll to Messaging, E-mail, Options.

2. Select Edit account.

3. Select New account.

4. Enter a name for the account, for example Home or Office.

5. Select Connect using.

6. Select the data account you want to use with this

e-mail account.

7. Enter the rest of the settings in the list, some of which are optional. To enter the settings, scroll to the setting, press

Ok to confirm. Repeat this for each required setting.

Select and enter the information. Press

You use the same e-mail settings in your phone as in your PC e-mail program. If you do not have an e-mail service, contact your operator to get all the necessary settings.

70 Setting up WAP and e-mail

account. Your service provider may alternatively request a password on connection.

• Outgoing server – enter the name or IP address of the SMTP server to be able to send e-mail messages.

• Outgoing port – if needed, change the number of the port used by the SMTP protocol.

• E-mail address – enter your e-mail address.

• Download – select whether to receive headers and text or headers only.

• From name – enter your name.

• Signature – select if you want to add your business card to your e-mail messages.

• Copy outgoing – Select On, if you want e-mail messages sent from your phone also to be sent to an e-mail address of your choice. This way, your sent messages are copied and can be saved for future reference.

Page 71

• Check interval – Select how often you want the phone to connect to your e-mail server and check for incoming e-mail messages.

If you have both an office and a home e-mail account, you can set one of them as default:

•Select Set account from the Messaging, E-mail, Options menu and select the account.

Internet

At www.SonyEricsson.com.cn on how to enter your e-mail settings. Use the e-mail configurator to set up your phone for e-mail, or read the Getting Started document. Contact your network operator for information about your settings.

you can get support

Using WAP

Your phone has a WAP (Wireless Application Protocol) browser and e-mail messaging which are designed to bring a modified Internet to your mobile phone. A wide range of services are available, for example, news, entertainment, timetables, reservations, banking, e-commerce, positioning and e-mail.

Before you start

First make sure that you have:

• A phone subscription that supports data transmission.

• Correct settings in your phone for mobile Internet, WAP and/or e-mail messaging.

• Registered as a WAP/E-mail user with your network operator or service provider.

Note: See “E-mail account settings” on page 70 or “E-mail” on page 58 for more information about e-mail set-up and messaging.

Using WAP 71

Page 72

To select a WAP profile

1. Scroll to Connectivity, WAP options, WAP profiles.

2. Select the profile you want to use.

You then return to the WAP options menu and the WAP profile is selected.

Using the WAP browser

To start browsing

• Select either the top middle or top left icon on the desktop. When the WAP page is loaded into the phone, press

More and select from the following:

• Open your home page at the top of the list,

for example, SonyEricsson.

• Go to one of your bookmarks. Select Bookmarks.

• Enter the address of a WAP site. Select Enter

address, to enter a new WAP address or select one of the 10 most recently entered addresses.

Tip: When you enter a WAP address, the normal

http:// prefix is not needed.

Options when browsing

More.

1. Select

2. Select one of the following:

• Go to the home page set for the current profile.

• Add the site you are currently browsing to your list of bookmarks, or see the list of bookmarks for the current profile.

• Enter the WAP address of a site you want to visit.

• Save a picture from the site.

• Send a text message with a link to the current WAP page to another phone.

• Send a link to the current site to another phone via infrared or Bluetooth.

• Refresh the contents of the WAP page.

• Disconnect and go to standby.

• Display current status information, for example, profile, access type, connection time, data rate, security, address.

• Set the current site as the home page of the WAP profile you are using.

• Push inbox for incoming messages via WAP.

To exit WAP and disconnect

More and scroll to Exit WAP.

• Press

72 Using WAP

Note: If you select an e-mail address when browsing a WAP site, you can reply with a text message.

Page 73

Using bookmarks

You use bookmarks in your mobile phone just as you do with a PC Internet browser. You can have up to 25 bookmarks.

To download from wap.sonyericsson.com.cn

1. Scroll to SonyEricsson.

2. Select what you want to download and follow the

instructions that appear.

To work with bookmarks

1. Scroll to Internet services.

More, Bookmarks.

2. Press

3. Select the bookmark you want to work with.

More and select one of the following options:

4. Press

• Go to – Go to the marked WAP address.

Stored information

The following information can be saved in your phone:

• Cache – improves memory efficiency.

• Passwords – improves server access efficiency.

• Cookies – improves site access efficiency.

• Edit – Edit the name and/or the WAP address of the bookmark.

• Delete – Delete the bookmark.

To clear cache

• Scroll to Connectivity, WAP options, Clear cache.

• Send as text msg – Send a link to the WAP address in a text message.

• Send – Send a link to the current WAP address via infrared.

To remember passwords

• Scroll to Connectivity, WAP options, Passwords, Remember pwds.

• Set as homepage – Set the WAP address as the home page.

To clear passwords

• Scroll to Connectivity, WAP options, Passwords,

Downloading

Clear passwords. You can download pictures, themes, games and ring signals, for example, from WAP sites directly to your phone.

Using WAP 73

Page 74

To allow cookies

1. Scroll to Connectivity, WAP options, Cookies.

2. Select Allow cookies.

Transferring and exchanging

information

To clear cookies

1. Scroll to Connectivity, WAP options, Cookies.

2. Select Clear cookies.

It is advisable to clear any sensitive information about previously visited WAP services. This is to avoid a security risk if your phone is misplaced, lost or stolen.

74 Transferring and exchanging information

Bluetooth™ wireless technology

Your phone has built-in Bluetooth wireless

technology which makes it possible for you to

connect your phone wirelessly to other Bluetooth

devices such as a handsfree, PC or other phones.

You can, for example, have a conversation via a

cordless Bluetooth handsfree or browse the Internet,

wirelessly connected via your mobile phone.

You can automatically synchronize information in

your phone and your PC. You can also exchange,

for example, contacts, calendar items and pictures.

Note: We recommend that your phone and the

Bluetooth device you are communicating with are

within a range of 10 metres. The connection may be

improved if there are no solid objects in between

your phone and the other Bluetooth device.

Page 75

Before you start

To communicate with another Bluetooth device, you first need to add the device to the list of my devices. To synchronize with your PC, and to browse the

3. Enter a passkey (up to 16 digits) for the device, both in the phone and, for example, in the PC. (If a passkey does not come with the Bluetooth device when you buy it, you need to create one yourself.)

Internet, you also need to install software on your PC from the Sony Ericsson web site, www.SonyEricsson.com/support.

You can exchange items or play games without

Note: To add a device or accept the addition of a device to My devices means that the device has access to functionality and content in the phone.

having to add the other device to the list of My devices.

To organize your list of devices

• Scroll to Connectivity, Bluetooth, My devices.

To turn Bluetooth on

1. In standby, press

More.

Then select a device from the list and press view a list of options.

2. Select Turn on Bluetooth.

Phone name

To add a device to your phone

1. Scroll to Connectivity, Bluetooth, My devices, New device.

Add and your phone searches for all types of

Press available devices. Press

More if you want to select a

You can choose a name for your phone. This name is shown in other devices when your phone is found, and is also used for the infrared port.

• To enter a name, scroll to Connectivity, Bluetooth, Options, Phone name.

specific type of device to search for.

2. The phone searches for Bluetooth devices. A list of available devices appears in the display. Select a device.

In order for your phone to be found by other Bluetooth devices, you must make sure Bluetooth is turned on and your phone is visible to other devices.

Transferring and exchanging information 75

More to

Page 76

To hide or show your phone when using Bluetooth

1. Scroll to Connectivity, Bluetooth, Options, Visibility.

2. Select Show phone or Hide phone.

Sending and receiving

To send an item using Bluetooth wireless technology, you need to make sure that the devices are within 10 metres.

Handsfree

To send an item

After you select Bluetooth as the transfer method, a

To add a Bluetooth handsfree to your phone

1. Scroll to Connectivity, Bluetooth, Handsfree, My handsfree, New handsfree.

2. Select

Add.

list of possible receivers is presented. First in the list will be the last device you were in contact with and devices that have been previously added to your phone. The phone also searches for other devices which are shown in the list

Transferring sound when using a handsfree

When you are using a Bluetooth handsfree with your your phone, you can choose where the sound should be transferred during a call.

More in standby during the call, select Tra nsfer

• Press

Tip: You can send certain items in your phone (calendar overviews, appointments and tasks, contacts, text messages) to specific Bluetooth printers.

sound. Then select either to transfer sound to the

phone or to other handsfree devices that have been added to your phone.

• You can select where to direct the sound when

Note: In countries/regions where the use of Bluetooth wireless technology is not allowed, you must ensure that the Bluetooth function is set to Off.

making call.

• Scroll to Connectivity, Bluetooth, Handsfree,

Ongoing call, then select In handsfree, In phone, Always ask.

76 Transferring and exchanging information

Page 77

Infrared port

You can use the built-in infrared port to establish contact between your phone and a PC or another device equipped with an infrared port.

To connect two devices

1. Place your phone as in the picture. The infrared port on the phone must face the infrared port on the other device.

Activate the infrared port

Before you can connect to another infrared device you have to activate the infrared port in your phone.

• To activate the infrared port, scroll to Connectivity, Infrared port. From standby, you can also select

More, Turn on infrared.

Note: If you are connecting to a PC, make sure your PC has activated infrared communication (Start, Settings, Control Panel, Infrared, Options tab, Enable infrared communication).

2. Your phone now establishes contact with the other device.

Synchronization

You can synchronize the calendar and Phonebook in your phone with similar programs in, for example, a PC, PDA or mobile phone and with similar programs on the Internet.

Transferring and exchanging information 77

Page 78

• To select which order first name and last name

Fax and data calls

appear in the phone when you synchronize contacts, scroll to Phonebook, Options, Synchronize view.

Send fax and data calls

To send fax messages and make data calls, you need to

Synchronization with nearby devices

After installing the synchronization program

connect your phone to a computer, and then start the appropriate software program.

from the Sony Ericsson WAP site, www.SonyEricsson.com/support, you can synchronize your phone with your PC.

A status bar shows the progress of the synchronization. If you use a cable, the synchronization starts as soon as you connect the

Receive fax and data calls

The procedure of receiving fax messages and data calls depends on your network and subscription. If you have separate numbers for voice, fax and data calls,

your phone recognizes the type of call. cable. For more information, please refer to the synchronization software online help.

To receive a fax or data call (separate numbers)

1. Connect your phone to a computer.

Internet synchronization

You can synchronize your mobile phone contacts, appointments and tasks with similar programs on the Internet, using WAP. Contact your network operator

2. Answer the call from within the software program (if it does not answer automatically). You cannot answer a fax or data call by pressing on the phone.

for more information about these programs on the Internet and to receive user id, password and addresses for the different programs. You must also have a WAP profile set in your mobile phone.

One number

If you have a SIM card that does not support separate fax and data numbers, the phone does not recognize the type of incoming call.

78 Transferring and exchanging information

Yes

Page 79

If you want to receive a fax or data call, you have to set the phone to one of these options. Once you have set your phone for a specific incoming call, it stays like this until you change it. To select the call type you want your next incoming call to be, scroll to Calls, Next call, Next incoming call.

More features

Alarm clock

The alarm can be set to ring at a specific time within 24 hours, or recurrently at a specific time on several days. You can have both these alarms set at the same time. Even if you have set your phone to silent, the alarm signal rings. The alarm clock also rings if the phone is turned off.

To set an alarm

1. Scroll to Organizer, Alarms, Alarm.

2. Enter the time,

Save.

• To change the alarm time, scroll to Organizer, Alarms, Alarm, New time.

• Press any key to turn the alarm signal off when it rings. If you do not want the alarm to be repeated,

Yes.

press

• To cancel the alarm, scroll to Organizer, Alarms, Alarm, Cancel.

• To set a recurrent alarm, scroll to Organizer, Alarms, Recurrent alarm. Then enter the time and select the days that you want the alarm to recur by scrolling and pressing

Check. Press Save to exit the menu.

More features 79

Page 80

• To select an alarm signal, scroll to Settings, Sounds and alerts, Alarm signal.

• Press to delete a digit or symbol.

• Press to start a new calculation.

Stopwatch

Scroll to Organizer, Stopwatch.

Start to start the stopwatch.

• Press

New lap to start a new lap time.

• Press

Stop to finish.

• Press

Restart to restart the stopwatch.

• Press

Reset to reset the stopwatch.

• Press

Note: The stopwatch is turned off when you answer an incoming call or when you exit the stopwatch menu.

Code memo

Instead of having to remember all the different security codes for credit cards, you can, for example, save them in the code memo in your phone. Then all you need to remember is the password to open the code memo. You can save a maximum of ten codes in the code memo.

Checkword and security

To confirm that you have entered the correct password for the code memo and to prevent unauthorized access to your codes, you must enter a

Timer

The phone has a timer that can be set to count down from 99 hours, 59 minutes, 59 seconds.

• To set the timer, scroll to Organizer, Tim er. When the signal rings, press any key to turn it off.

checkword. When you enter your password to open the code memo, the checkword is shown for a short time. If the password is correct, the correct codes are shown. If you enter the incorrect password, the checkword and the codes that are shown are also incorrect.

Calculator

The phone has a calculator, which can add, subtract,

Factors strengthening the security of the Code

memo function are:

multiply, divide and calculate percentages.

• Enter a digit and scroll to a symbol (+, -, x, /, %, .).

80 More features

Page 81

• You get no feedback about whether the password is correct, except for the checkword, and only you know the checkword.

• All codes are encrypted in the mobile phone.

• When you access your codes, they are shown for a limited time only.

To open code memo

1. Scroll to Organizer, Code memo.

2. Enter your password,

Ok.

Your entered checkword appears. When the decryption process has finished, your codes are shown.

To open code memo for the first time

1. Scroll to Organizer, Code memo. A message with instructions appears.

Ok.

2. Press

3. Enter a four-digit password to open Code memo,

4. Re-enter the new password to confirm.

5. Enter a checkword (maximum 15 characters),

Ok.

The checkword can consist of both letters and numbers. To enter a number, press and hold the key.

To change the password

1. Open code memo as described above.

More, Change password.

2. Press

3. Enter your new password,

Ok.

4. Re-enter the new password,

5. Enter a checkword,

Ok.

Forgot your password?

If you forget your password, just enter any password to access the Code memo function. The checkword

To add a new code

1. Scroll to Organizer, Code memo.

and codes that are then shown are incorrect. You must now reset the Code memo.

2. Enter your password.

3. Select New code,

Add.

4. Enter a name associated with the code, for example, the name of the credit card company,

5. Enter the code,

Ok.

To reset code memo

More, Reset.

1. Press

2. Reset code memo? appears. Press

Ok.

Yes.

More features 81

Page 82

The Code memo is reset and all entries are cleared. The next time you enter the Code memo, you must start at “To open code memo for the first time” on page 81.

Calendar

You can use the calendar to keep track of important

To add a new appointment

1. Scroll to Organizer, Calendar, Add appointment.

2. Enter the appropriate information, for example,

subject, location, icon and times. Confirm each entry

Ok, Select, or Save.

with

3. If you want to set a reminder for your appointment, select a reminder.

meetings that you need to attend, phone calls that you need to make or tasks that you need to do. The calendar can be synchronized with a PC calendar or, using WAP, with a calendar on the Web. For more information see “Synchronization” on page 77.

To add a new task

1. Scroll to Organizer, Calendar, Ta sk s, New task,

Add.

2. Select a category.

• If the category is a phone call, enter the phone

Ok.

Appointments and tasks

You can save up to 300 appointments and 80 tasks in your calendar, depending on the size of each item. You can choose to add a new appointment or task, or

number,

3. Enter a subject,

Ok.

4. If you want to set a reminder for your appointment,

Yes. Save the date and time.

press

to use an old appointment or task as a template by copying and editing it.

Viewing your calendar

To view your calendar content, scroll to Organizer,

Tip: When you are in the list of appointments and tasks for a certain day, you can press

More to edit,

delete, reschedule, send or copy. You can also call a

Calendar, and then select one of the following:

• View today – All appointments for today as well

as unfinished tasks are shown.

number included in a phone call task.

82 More features

Page 83

• Vi ew w e ek – Move within and among the days by moving the joystick. Press

Select to view a

certain day.

• Reminders – Select Always if you want the reminder to sound even though the phone is turned off.

• View month – Move within and among the days or weeks by moving the joystick. Press view a certain week. Days on which you have appointments are marked in bold.

Select to

Check the status

You can check how much space is left for new appointments and tasks

• To check the status, scroll to Organizer, Calendar,

Tip: In the monthly and weekly views, you can go to

Advanced, Memory status.

next week by pressing 3, to next month by pressing 6 and to next year by pressing 9. You can go back a week, a month or a year by pressing 1, 4, and 7

Tip: To delete all appointments and tasks in your calendar, select Delete all in the Advanced menu.

respectively. To reach the current day, press .

Exchanging calendar entries

Calendar settings

•Select Options from the Organizer, Calendar menu and then select one of the options:

You can send and receive appointments and tasks using Bluetooth wireless technology, the infrared port or picture message.

• Vi ew .

Starting day – Select a start day for the week. Week display – Select 5-day week or 7-day week.

• Profile switch – If you want the phone to remind

you to switch profile when a meeting is about to start, select Manual. If you want the profile to be switched automatically, select Auto, then select

To send an appointment or a task

1. In the list of appointments and tasks for a certain day, scroll to the item you want to send and

More.

press

2. Select Send.

3. Select a transfer method.

a profile.

More features 83

Page 84

To receive an appointment or a task

1. From standby, press

More and scroll to

Turn on Bluetooth or Turn on infrared . Both the infrared port and the Bluetooth function are activated for ten minutes.

2. Add appointment? or Add task? appears. Press to save the appointment or task in your calendar. If your calendar is full, you must remove calendar

Yes

Sound recorder

With the Sound recorder function, you can record either your own memos or calls. All participants in the call are automatically recorded. The recording is stopped if any party ends the call.

The recordings are saved in your mobile phone and can be accessed even if you change your SIM card.

items before you can save any new ones.

Note: In some countries/regions or states it is

Find an appointment or task

You can search for appointments and tasks that

required by law that you inform the other person before recording the call.

contain a specific text.

To record a call

To search for appointments or tasks

1. Scroll to Organizer, Calendar, Advanced, Find.

1. During the call press the joystick.

2. Select Record.

2. Check or uncheck if you want to search for

appointments or tasks (if you have added any).

Save.

Press

3. Enter the text you want to search for,

Ok.

Appointments or tasks that match your search are shown. Select to view the item or edit, delete, reschedule, send, or copy the item by pressing

More.

To start a sound recording

• Scroll to Pictures & sounds, Record sound.

• Wait until you hear a tone. When the recording starts, the display shows Recording together with the time of the current recording.

To end the recording

Stop.

• Press

84 More features

Page 85

Tip: You can start recording or listening to recordings with a voice command. See “Voice control” on page 37.

The recording stops automatically if you receive an incoming call or when the call ends. You hear a tone a few seconds before the memory is full.

To listen to your recordings

1. Scroll to Pictures & sounds, My sounds.

2. Select the recording you wish to hear. Press

Play.

To send a recording

1. Scroll to Pictures & sounds, My sounds.

2. Scroll to the recording you wish to send.

More and select Send.

3. Press

Entertainment

Your phone has several entertaining applications and games. You can play some of the games with another person, both using your phone, or you can play on two phones, using Bluetooth wireless technology or infrared. You can also download games and applications directly to your phone. Help texts are available in some games and applications.

To start an application

1. Scroll to Entertainment, Games & more.

2. Select an application,

Start.

To download an application

1. Scroll to Entertainment, Games & more.

2. Scroll to a direct link,

Start.

To delete or rename a sound recording

1. Scroll to Pictures & sounds, My sounds.

2. Scroll to the recording you wish to delete or rename.

More when the recording is highlighted.

3. Press

4. Select Delete or Rename.

Note: Make sure the file sizes do not exceed the free

memory in your phone. See “Checking the memory” on page 37.

To start and end a game

1. Scroll to Entertainment, Other games.

2. Select New game,

Security

SIM card lock

The SIM card lock protects your subscription, but not your phone itself, from unauthorized use. If you change SIM cards, the phone still works with the new SIM card.

Most SIM cards are locked at the time of purchase. If the SIM card lock is on, you have to enter a “PIN” (Personal Identity Number) every time you turn on your phone.

If you enter your PIN incorrectly three times in a row, the SIM card is blocked. This is indicated by the message PIN blocked. To unblock it you need to enter your “PUK” (Personal Unblocking Key). Your PIN and PUK are supplied by your operator.

To unblock your SIM card

1. PIN blocked appears in the display.

2. Enter your PUK and press

3. Enter a new four- to eight-digit PIN and press

4. Re-enter the new PIN to confirm and press

• To edit your PIN, scroll to Settings, Locks, SIM lock, Change PIN.

Ok.

Security 87

Page 88

Note: If the message “Codes do not match” appears, you entered the new PIN incorrectly. If the message “Wrong PIN” appears, followed by “Old PIN:”, you entered your old PIN incorrectly.

• To edit your PIN2, scroll to Settings, Locks, SIM lock, Change PIN2.

To turn the SIM card lock on or off

1. Scroll to Settings, Locks, SIM lock, Protection.

2. Select On or Off.

3. Enter your PIN and press

Ok.

Phone lock on

If the phone lock is on, the message Phone locked appears each time you turn on the phone. You have to enter your code followed by

Yes to use

your phone.

Automatic

If the phone lock is set to automatic, you do not need to enter your phone lock code until a different SIM card is inserted in the phone.

• To edit your phone lock code, scroll to Settings, Locks, Phone lock, Change code.

Phone lock

The phone lock protects the phone against unauthorized use if it is stolen and the SIM card is

Note: It is important that you remember your new code. If you should forget it, you have to hand in your phone to your local Sony Ericsson retailer.

exchanged. It is not on when you buy the phone. You can change the phone lock code (0000) to any fourto eight-digit personal code. The phone lock can be set to on, automatic or off.

To set the phone lock

1. Scroll to Settings, Locks, Phone lock, Protection.

2. Select an alternative.

3. Enter the phone lock code and press

88 Security

Ok.

Page 89

Troubleshooting

This chapter lists some problems that you might encounter while using your phone. Some problems require that you call your service provider, but you can easily correct most of the problems yourself.

The phone cannot be switched on

Grey menu options

Grey text indicates a function that is temporarily unavailable, for example due to your subscription or due to a certain setting which has not been turned on.

Since you cannot send themes, pictures and sounds that are copyright-protected, the Send menu is sometimes unavailable.

Hand-held phone

Recharge or replace the battery. See “SIM card and battery information” on page 5.

No indication of charging

When you start charging a battery that is empty or a battery that has not been used for a long time, it may take up to 30 minutes before the battery icon appears in the display.

Menu language

If the display shows a language that you do not understand, you can always choose Automatic (determined by your SIM card) by pressing 8888

in standby. You can always choose English by

pressing 0000 in standby.

Error messages

Insert SIM

There is no SIM card in the phone or you may have inserted it incorrectly. Insert a SIM card. See “SIM card and battery information” on page 5.

Insert correct SIM card

The phone is set to work only with certain SIM cards. Insert the correct SIM card.

SOS calls only

You are within range of a network, but you are not allowed to use it. However, in an emergency, some operators allow you to call the international emergency number 112. See “Making emergency calls” on page 31.

Troubleshooting 89

Page 90

No network

There is no network within range or the received signal is too weak. You have to move to get a signal that is strong enough.

PUK blocked – contact operator

You entered your personal unblocking key code (PUK) incorrectly 10 times in a row. Contact your network operator or service provider.

Wrong PIN/Wrong PIN2

You have entered your PIN or PIN2 incorrectly.

• Enter the correct PIN or PIN2, and press

Yes.

Phone locked

The phone is locked. To unlock the phone, See “Phone lock” on page 88.

See “SIM card lock” on page 87.

Phone lock code:

Codes do not match

When you want to change a security code (for example, your PIN) you have to confirm the

Your phone comes with the phone lock code, 0000. You can change it to any four- to eight-digit code. See “Phone lock” on page 88.

new code by entering it again. The two codes that you have entered do not match. See “SIM card lock” on page 87.

Number not permitted

The Fixed Dialling function is on and the number you have dialled is not on your fixed numbers list.

PIN blocked/PIN2 blocked

See “Fixed dialling” on page 48.

You have entered your PIN or PIN2 incorrectly three times in a row. To unblock your phone, see “SIM card lock” on page 87.

Charging, alien battery

The battery you are using is not a Sony Ericssonapproved battery and is charging slowly for safety reasons.

90 Troubleshooting

Page 91

Additional information

Guidelines for Safe and Efficient Use

Please read this information before using

your mobile phone.

RECOMMENDATIONS

• Always treat your product with care and keep it in a clean and dust-free place.

• Do not expose your product to liquid or moisture or humidity.

• Do not expose your product to extreme high or low temperatures.

• Do not expose your product to open flames or lit tobacco products.

• Do not drop, throw or try to bend your product.

• Do not paint your product.

• Do not use your product near medical equipment without requesting permission.

• Do not use your product when in, or around aircraft, or areas posted “turn off two-way radio”.

• Do not use your product in an area where a potentially explosive atmosphere exists.

• Do not place your product or install wireless equipment in the area above your car’s air bag.

• Do not attempt to disassemble your product. Only Sony Ericsson authorised personnel should perform service.

• Do not direct the infrared ray at anyone’s eye and make sure that it does not disturb any other infrared units.

• To avoid hearing impairment, accept the call before holding your product (or portable handsfree device) to your ear.

ANTENNA

Only use an antenna that has been specifically designed by Sony Ericsson for your mobile phone. Use

Additional information 91

Page 92

of unauthorised or modified antennas could damage your mobile phone and may violate regulations, causing loss of performance and SAR levels above the recommended limits (see below).

EFFICIENT USE

Hold your mobile phone as you would any other phone. Do not cover the top of the phone when in use, as this affects call quality and may cause the phone to operate at a higher power level than needed, thus shortening talk and standby times.

RADIO FREQUENCY (RF) EXPOSURE AND SAR

Your mobile phone is a low-power radio transmitter and receiver. When it is turned on, it emits low levels of radio frequency energy (also known as radio waves or radio frequency fields).

Governments around the world have adopted comprehensive international safety guidelines, developed by scientific organizations, e.g. ICNIRP (International Commission on Non-Ionizing Radiation Protection), through periodic and thorough evaluation of scientific studies. These guidelines establish permitted levels of radio wave exposure for the general population. All Sony Ericsson mobile phone models are designed to operate within these stringent levels. The levels include a safety margin designed to assure

92 Additional information

the safety of all persons, regardless of age and health, and to account for any variations in measurements.

Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio frequency energy absorbed by the body when using a mobile phone. The SAR value is determined at the highest certified power level in laboratory conditions, but the actual SAR level of the mobile phone while operating can be well below this value.

This is because the mobile phone is designed to use the minimum power required to reach the network. Therefore, the closer you are to a base station, the more likely it is that the actual SAR level will decrease.

Variations in SAR below the radio frequency exposure guidelines do not mean that there are variations in safety. While there may be differences in SAR levels among various mobile phones, all Sony Ericsson mobile phone models are designed to meet radio frequency exposure guidelines.

A separate leaflet with SAR information for this mobile phone model is included with the material that comes with this mobile phone. This information can also be found, together with more information on radio frequency exposure and SAR, on www.SonyEricsson.com.cn.

DRIVING

Please check if local laws and regulations restrict the use of mobile phones while driving or require drivers to

Page 93

use handsfree solutions. We recommend that you use only Ericsson or Sony Ericsson handsfree solutions intended for use with your product. Please note that because of possible interference to electronic equipment, some vehicle manufacturers forbid the use of mobile phones in their vehicles unless a handsfree kit with an external antenna supports the installation.

Always give full attention to driving and pull off the road and park before making or answering a call if driving conditions so require.

PERSONAL MEDICAL DEVICES

Mobile phones may affect the operation of cardiac pacemakers and other implanted equipment. Please avoid placing the mobile phone over the pacemaker, e.g. in your breast pocket. When using the mobile phone, place it at the ear opposite the pacemaker. If a minimum distance of 15 cm (6 inches) is kept between the mobile phone and the pacemaker, the risk of interference is limited. If you have any reason to suspect that interference is taking place, immediately turn off your mobile phone. Contact your cardiologist for more information.

For other medical devices, please consult the

manufacturer of the device.

CHILDREN

DO NOT ALLOW CHILDREN TO PLAY WITH YOUR MOBILE PHONE OR ITS ACCESSORIES. THEY COULD HURT THEMSELVES OR OTHERS, OR COULD ACCIDENTALLY DAMAGE THE MOBILE PHONE OR ACCESSORY. YOUR MOBILE PHONE OR ITS ACCESSORY MAY CONTAIN SMALL PARTS THAT COULD BE DETACHED AND CREATE A CHOKING HAZARD.

DISPOSING OF THE PRODUCT

Your mobile phone should not be placed in municipal waste. Please check local regulations for disposal of electronic products.

POWER SUPPLY

Connect the AC power adapter only to designated power sources as marked on the product. Make sure the cord is positioned so that it will not be subjected to damage or stress. To reduce risk of electric shock, unplug the unit from any power source before attempting to clean it. The AC power adapter must not be used outdoors or in damp areas. Never alter the cord or plug. If the plug will not fit into the outlet, have a proper outlet installed by a qualified electrician.

Additional information 93

Page 94

EMERGENCY CALLS

Mobile phones operate using radio signals, which cannot guarantee connection under all conditions. Therefore you should never rely solely upon any mobile phone for essential communications (e.g. medical emergencies).

Emergency calls may not be possible on all cellular networks or when certain network services and/or mobile phone features are in use. Check with your local service provider.

BATTERY USE AND CARE

We recommend that you fully charge the battery before you use your mobile phone for the first time. The battery can only be charged in temperatures between +5°C (+41°F) and +45°C (+113°F).

A new battery or one that has not been used for a long time could have reduced capacity the first few times it is used.

The talk and standby times depend on the actual transmission conditions when using the mobile phone. If the mobile phone is used near a base station, less power is required and talk and standby times are prolonged.

Under normal conditions the stand-by time for this battery is 170-325 hours.

• War ning ! May explode if disposed of in fire.

94 Additional information

• Use only Ericsson or Sony Ericsson branded original batteries and chargers intended for use with your mobile phone. Other chargers may not charge sufficiently or may produce excessive heat. Using other batteries and chargers could be dangerous.

• Do not expose the battery to liquid.

• Do not let the metal contacts on the battery touch another metal object. This could short-circuit and damage the battery.

• Do not disassemble or modify the battery.

• Do not expose the battery to extreme temperatures, never above +60°C (+140°F). For maximum battery capacity, use the battery in room temperature.

• Turn off your mobile phone before removing the battery.

• Keep out of children’s reach.

• Use the battery for the intended purpose only.

Page 95

• Do not allow the battery to be put into the mouth. Battery electrolytes may be toxic if swallowed.

DISPOSING OF THE BATTERY

Please check local regulations for disposal of batteries or call your local Sony Ericsson Customer Care Center for information.

The battery should never be placed in municipal

waste. Use a battery disposal facility if available.

Limited Warranty

Sony Ericsson Mobile Communications AB, S-221 88 Lund, Sweden, (Sony Ericsson), provides this Limited Warranty for your mobile phone and original accessory delivered with your mobile phone (hereinafter referred to as “Product”).

Should your Product need warranty service, please return it to the dealer from whom it was purchased, or contact your local Sony Ericsson Customer Care Centre (national rates may apply) or visit www.SonyEricsson.com.cn to get further information.

WHAT WE WILL DO

If, during the warranty period, this Product fails to operate under normal use and service, due to defects in design, materials or workmanship, Sony Ericsson authorised distributors or service partners, in the country/region where you purchased the Product, will, at their option, either repair or replace the Product in

accordance with the terms and conditions stipulated herein.

Sony Ericsson and its service partners reserve the right to charge a handling fee if a returned Product is found not to be under warranty according to the conditions below.

Please note that your personal settings/downloads might be lost when the Product is repaired or replaced.

CONDITIONS

1. The warranty is valid only if the original proof of

purchase issued to the original purchaser by an, for this Product, Sony Ericsson authorised dealer, specifying the date of purchase and serial number*, is presented with the Product to be repaired or replaced. Sony Ericsson reserves the right to refuse warranty service if this information has been removed or changed after the original purchase of the Product from the dealer.

2. If Sony Ericsson repairs or replaces the Product, the

repaired or replaced Product shall be warranted for the remaining time of the original warranty period or for thirty (30) days from the date of repair, whichever is longer. Repair or replacement may involve the use of functionally equivalent reconditioned units. Replaced parts or components will become the property of Sony Ericsson.

Additional information 95

Page 96

3. This warranty does not cover any failure of the Product

due to normal wear and tear, or due to misuse, including but not limited to use in other than the normal and customary manner, in accordance with the Sony Ericsson instructions for use and maintenance of the Product. Nor does this warranty cover any failure of the Product due to accident, software or hardware modification or adjustment, acts of God or damage resulting from liquid.

4. Since the cellular system on which the Product is to

operate is provided by a carrier independent from Sony Ericsson, Sony Ericsson will not be responsible for the operation, availability, coverage, services or range of that system.

5. This warranty does not cover Product failures caused

by installations, modifications, or repair or opening of the Product performed by a non-Sony Ericsson authorised person.

6. The warranty does not cover Product failures which

have been caused by use of accessories or other peripheral devices which are not Ericsson or Sony Ericsson branded original accessories intended for use with the Product.

7. Tampering with any of the seals on the Product will

void the warranty.

96 Additional information

8. THERE ARE NO EXPRESS WARRANTIES,

WHETHER WRITTEN OR ORAL, OTHER THAN THIS PRINTED LIMITED WARRANTY. ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL SONY ERICSSON OR ITS LICENSORS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOST PROFITS OR COMMERCIAL LOSS, TO THE FULL EXTENT THOSE DAMAGES CAN BE DISCLAIMED BY LAW.

Some countries/regions/states do not allow the exclusion or limitation of incidental or consequential damages, or limitation of the duration of implied warranties, so the preceding limitations or exclusions may not apply to you.

The warranty provided does not affect the consumer’s statutory rights under applicable legislation in force, nor the consumer’s rights against the dealer arising from their sales/purchase contract.

* In some countries/regions additional information is requested. If so, this is clearly shown on the valid proof of purchase.

Page 97

FCC Statement

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

We, Sony Ericsson Mobile Communications AB of Nya Vattentornet S-221 88 Lund, Sweden.

declare under our sole responsibility that our product

Sony Ericsson type AAB-1021011-CN

and in combination with our accessories, to which this declaration relates is in conformity with the appropriate standards 3GPP TS 51.010-1, EN 301489-7, EN 300328, EN 301489-17 and EN 60950, following the provisions of, Radio Equipment and Telecommunication Terminal Equipment directive

99/5/EC with requirements covering EMC directive 89/336/EEC, and Low Voltage directive 73/23/EEC.

Lund, August 2003

Place & date of issue

Kentaro Odaka, Head of Product Business Unit GSM/UMTS

We fulfil the requirements of the R&TTE Directive (99/5/EC).

Additional information 97

0682

Page 98

Icons

The table below shows icons which may appear in standby or in the menus.

Icon Description

Desktop icons

Your personal phone book.

Handling of text, pictures, e-mail and voice messages.

Handling of call time, call cost information and ongoing calls.

Handling of ongoing calls. Only available during calls.

Camera function.

Handling of pictures, sounds and themes.

Personal settings including profiles, display, language, time and locks.

Gives you access to Internet services.

98 Icons

Icon Description

Calendar, alarm clock and other extras.

Receive items via Bluetooth, infrared, networks, data communications settings, WAP options and accessories.

Create your own menu for the functions you use most often.

Operator services.

Games and applications.

Standby

Desktop icon.

Tells you the strength of the GSM network signal.

GPRS is within range.

GPRS is within range and can be used.

Page 99

Icon Description

Tells you are in a premium charge zone.

Tells you the status of the battery.

You cannot receive any incoming calls.

Icon Description

The kedypad is locked.

The card lock or phone lock is on. A secure WAP connection is established.

You have received a text message.

You have missed an incoming call.

All incoming calls are diverted to a defined number.

No calls or only certain calls from numbers in a list are received.

All signals are off, except the alarm and timer.

The alarm clock has been set and is on.

The timer has been set and is on.

A profile other than Normal has been chosen.

You have received an e-mail message.

You have received a picture message.

You have received a voice message.

You have received a WAP push message.

The infrared port is on.

Infrared communication is in progress.

A GPRS session is in progress.

Line 1 is in use for outgoing calls.

Icons 99

Page 100

Icon Description

Line 2 is in use for outgoing calls.

Ciphering is currently not being provided by the network.

The network is preferred and can be used.

The network is forbidden and cannot be used.

Your home network is within range and can be used.

An ongoing call.

A chat session is in progress.

The Bluetooth function is on.

A Bluetooth headset, added to your phone.

A Bluetooth phone, added to your phone.

Icon Description

A Bluetooth printer, added to your phone.

A Bluetooth PDA, added to your phone.

Other Bluetooth device.

The appointment is a meeting.

The appointment is a date.

The appointment is to travel.

The appointment is a vacation.

The appointment is an anniversary.

A miscellaneous appointment.

A miscellaneous task.

An all day calendar appointment.

A Bluetooth PC, added to your phone.

100 Icons

Sony Ericsson T618 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Getting to know your phone

Personalizing your phone

Calling

Messaging

Camera

Setting up WAP and e-mail

Using WAP

74 Transferring and exchanging information

More features

Security

Troubleshooting

Additional information

Icons
