TEMS™ Pocket 5.3
Sony Ericsson K800i
User’s Manual
This manual is provided by Ericsson AB without any kind of warranty. Improvements and changes in this description due to typographical errors or inaccuracies in current information, or improvements to programs and/or equipment may be made by Ericsson AB at any time without notice. These changes will, however, be incorporated into new editions of this manual.
No part of this publication may be reproduced, transmitted, stored in a retrieval system, nor translated into any human or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of the copyrighted owner, Ericsson AB.
TEMS is a trademark owned by Telefonaktiebolaget L M Ericsson. All other trademarks are the property of their respective holders.
© Ericsson AB 2007. All rights reserved.
Publication number: LZT 108 9090 R3A
Contents
Contents
1. Introduction |
1 |
1.1. What’s New in TEMS Pocket 5.3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.2. What Was New in TEMS Pocket 5.2. . . . . . . . . . . . . . . . . . . . . . . . . 1 1.3. What Was New in TEMS Pocket 5.1. . . . . . . . . . . . . . . . . . . . . . . . . 1 1.4. What Was New in TEMS Pocket 5.0. . . . . . . . . . . . . . . . . . . . . . . . . 2
2. |
Overview |
3 |
|
2.1. Data Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
3 |
|
2.2. Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
4 |
3. |
Data Views |
5 |
3.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.1. General Data View Properties . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.2. The Built-in Help Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.1.3. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2. Survey of Data Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3. W/G Cells (View No. 1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4. PDP Context (View No. 1.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.5. MM/GMM (View No. 1.3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.6. Time Log (View No. 1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.6.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.7. GPS (View No. 1.5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.8. WCDMA Cells (View No. 2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.8.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.9. WCDMA Channel (View No. 2.2) . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.10. WCDMA Data (View No. 2.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . |
18 |
3.10.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
3.11. GSM Cells (View No. 3.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 3.11.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LZT 108 9090 R3A |
i |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.12. GSM Cell Id (View No. 3.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3.12.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.13. GSM BA List (View No. 3.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 3.13.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.14. GSM Serving Cell (View No. 4.1) . . . . . . . . . . . . . . . . . . . . . . |
24 |
3.15. GPRS Data (View No. 4.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . |
27 |
3.15.1. Data View Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
29 |
3.16. GPRS Info (View No. 4.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
30 |
3.17. GSM C/I Info (View No. 4.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
31 |
3.18. GSM AMR (View No. 4.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
32 |
3.19. The WAP Browser Data Views . . . . . . . . . . . . . . . . . . . . . . . . . . . |
34 |
3.19.1. WCDMA WAP Browser Data View . . . . . . . . . . . . . . . . . |
35 |
3.19.2. GPRS WAP Browser Data View . . . . . . . . . . . . . . . . . . |
37 |
4. TEMS Pocket Functions in the Activity Menu |
39 |
4.1. Operational Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.2. Insert Filemark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3. Start/Stop Logfile Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.4. Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.5. Start/Stop FTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.6. Connect/Disconnect GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.7. Start/Stop Call Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.8. Pocket Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5. The Pocket Menu |
42 |
5.1. General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.2. Cell Control Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 5.2.1. Lock to RAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 5.2.2. Lock Cell WCDMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 5.2.3. Lock ARFCN GSM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 5.2.4. Lock Band GSM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 5.2.5. Interplay between Locking Functions. . . . . . . . . . . . . . . . . . 45 5.2.6. Comparison with Locking Functions in
TEMS Investigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 5.2.7. Ignore Cell Barred . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 5.2.8. Reset Control Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.3. Events Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 5.3.1. Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 5.3.1.1. Viewing the Event Log . . . . . . . . . . . . . . . . . . . . . . . 47
ii
Contents
5.3.1.2. Clearing the Event Log . . . . . . . . . . . . . . . . . . . . . . . 48 5.3.1.3. Enabling and Disabling Event Logging . . . . . . . . . . . 48 5.3.1.4. Shortcuts to Event Settings and Event Counters . . . 49 5.3.2. Event Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 5.3.2.1. Viewing Event Settings . . . . . . . . . . . . . . . . . . . . . . . 49 5.3.2.2. Modifying Event Settings. . . . . . . . . . . . . . . . . . . . . . 49 5.3.3. Event Counters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 5.3.3.1. Viewing Event Counters . . . . . . . . . . . . . . . . . . . . . . 51 5.3.3.2. Resetting Event Counters . . . . . . . . . . . . . . . . . . . . . 51 5.3.4. Event Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 5.3.5. List of Logged Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 5.3.5.1. CC Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 5.3.5.2. MM Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 5.3.5.3. SM Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 5.3.5.4. GMM Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 5.3.5.5. RR Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 5.3.5.6. IRAT Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 5.3.5.7. RRC Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 5.3.5.8. Session Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.4. Data Views Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 5.5. GPS Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 5.5.1. GPS Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 5.5.2. GPS Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 5.5.3. GPS Time Synch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 5.6. FTP Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 5.6.1. FTP Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 5.6.2. FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 5.6.3. Exporting FTP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 5.6.4. Importing FTP Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.7. Logfile Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 5.7.1. Save Logfile To . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 5.7.2. Autostart Logfile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 5.7.3. Upload Logfile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 5.7.3.1. Setting an Upload Schedule . . . . . . . . . . . . . . . . . . . 68 5.7.4. FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.8. Call Sequence Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 5.9. Info Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 5.10. General Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 5.10.1. WAP Data View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 5.10.2. Data View Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 5.10.3. Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 5.10.4. Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
LZT 108 9090 R3A |
iii |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
5.10.5. Cell Id Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
5.10.6. Power Display (GSM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
5.10.7. Measure Mode Display (GSM). . . . . . . . . . . . . . . . . . . . . . 74
5.10.8. Auto Answer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.10.9. Redial Disconnected Calls . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.10.10. Reset All. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6. |
Controlling the Phone’s Packet-switched |
|
Behavior |
76 |
|
|
6.1. GMM Attach/Detach . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 76 |
|
6.2. PDP Context Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 77 |
7. |
Support Contact Information |
78 |
Appendix A. Parameter Values |
79 |
|
A.1. Activate PDP Context Failure Cause . . . . . . . . . . . . . . . . . . . . . . . 79
A.2. CCCH Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
A.3. Channel Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
A.4. Deactivate PDP Context Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
A.5. CC Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
A.6. GMM Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
A.7. GPRS Network Mode of Operation . . . . . . . . . . . . . . . . . . . . . . . . 82
A.8. PDP Context Request Parameters. . . . . . . . . . . . . . . . . . . . . . . . . 83
A.8.1. Delay Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
A.8.2. Reliability Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
A.8.3. Peak Throughput . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
A.8.4. Precedence Class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
A.8.5. Mean Throughput . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
A.9. RR Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
A.10. MM Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
A.11. Routing Area Update Failure Cause. . . . . . . . . . . . . . . . . . . . . . . 86
A.12. RR Internal Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
A.13. RRC Failure Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
A.14. RRC Protocol Error Cause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
A.15. SM Cause. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
A.16. GPS Fix Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
iv
|
Contents |
Appendix B. Graphic Representation of |
|
Parameter Values |
89 |
B.1. C/I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
B.2. Ec/No . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
B.3. FER, RLC/LLC Decode Errors/Retransmissions . . . . . . . . . . . . . . 90
B.4. RxLev, RSCP (= RSSI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
B.5. RxQual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
B.6. TxPower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Appendix C. Default Settings in TEMS Pocket |
|
Menus |
92 |
C.1. Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.2. Cell Control Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.3. Events Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.4. Data Views Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.5. GPS Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
C.6. FTP Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
C.7. Logfile Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
C.8. General Settings Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Index |
95 |
LZT 108 9090 R3A |
v |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
vi
Chapter 1. Introduction
1.Introduction
Welcome to TEMS Pocket.
TEMS Pocket is an advanced cellular network diagnostics tool built into a Sony Ericsson or Nokia phone. TEMS Pocket is suitable for day-to-day verification, maintenance and troubleshooting of cellular networks but is also handy for many cell planning tasks.
This document describes TEMS Pocket 5.3 as implemented in the Sony Ericsson K800i phone.
1.1.What’s New in TEMS Pocket 5.3
The focus for this release has been to implement TEMS Pocket in the Nokia N75 supporting WCDMA on 850 and 1900 MHz, and to introduce a low-end edition (named “Classic”) of the Sony Ericsson-based TEMS Pocket.
In the K800i TEMS Pocket edition described in this document, a number of bugs have been corrected.
1.2.What Was New in TEMS Pocket 5.2
TEMS Pocket 5.2 was implemented in each of the following mobile phones:
•Sony Ericsson K790i, K790a, and K800i New features include:
•Support of the Arabic language in Sony Ericsson K790i and K800i phones
•Saving of FTP settings to file
•GPS time added in GPS data view
1.3.What Was New in TEMS Pocket 5.1
TEMS Pocket 5.1 was implemented in each of the following mobile phones:
•Sony Ericsson K790i, K790a, and K800i
LZT 108 9090 R3A |
1 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
•Nokia N80
New features included:
•Support for EGPRS on the 850, 900, 1800, and 1900 MHz bands
–Sony Ericsson K790i: 900/1800/1900 MHz
–Sony Ericsson K790a: 850/1800/1900 MHz
–Nokia N80: 850/900/1800/1900 MHz
•Support for GPS positioning of data with Bluetooth GPS
•Compatibility with TEMS Investigation 8.0 versions of the supported phones
•Improved and automated logfile and FTP features
•Call sequences (voice)
•C/I measurements in GSM networks
•Filemarks
•Time log data view
•Improved data views and menus
•Improved events
1.4.What Was New in TEMS Pocket 5.0
(The 5.0 version was built into a Sony Ericsson W900i phone.)
•WCDMA network parameters, air interface measurements, and events
•Many new GSM events, including call events
•Event counting
•Combined data views showing both WCDMA and GSM (both simultaneously when inter-RAT neighbor measurements are being made)
•Possible to record logfiles that can be replayed in TEMS Investigation and TEMS Automatic
•Possible to set up and run FTP sessions (Get and Put) using Pocket functionality
•Improved on-screen help (callout boxes)
2
Chapter 2. Overview
2.Overview
2.1.Data Views
Most of the data displayed by TEMS Pocket is to be found in data views. When you turn the phone on the first time it will display the W/G Cells data view (after you have selected Start phone from the Start-up menu):
On later occasions, when turned on, the phone will display the data view last inspected, provided that the Pocket functions are activated.
The data views are divided into categories. Each data view is numbered according to the format “x.y”, where “x” is the category and “y” the position of the data view within that category. You browse the categories by moving the navigation key left and right, and the data views within a category by moving the navigation key up and down. TEMS Pocket remembers the view last displayed in each category; when you return to a category, that view is shown.
The top section of the display preserves the ordinary signal strength and battery power level indicators as well as other symbols belonging to the regular user interface of the phone. However, it also shows an icon for the latest TEMS Pocket event that occurred (see section 5.3.4) and a symbol indicating that a logfile is being recorded (see section 4.3).
If the default phone display with the operator name appears instead of a TEMS Pocket data view, this is because TEMS Pocket has been put in
LZT 108 9090 R3A |
3 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
background or inactive mode (see section 4.1). By default TEMS Pocket is in active mode, and its data views are visible.
The data views are exhaustively described in chapter 3.
2.2.Menus
When you press the Activity key on the phone, a tab with TEMS Pocket commands appears on top in the Activity menu:
Most of the commands in this menu are found only here. The menu is gone through in chapter 4.
From the Activity menu you can also access the Pocket menu, which is the chief means of configuring TEMS Pocket: see chapter 5. The Pocket menu can alternatively be accessed from the phone’s main menu: Settings → General → Pocket menu.
Note: If the phone memory is full, TEMS Pocket settings can no longer be saved. Remove some files to free up memory.
The Pocket menu is also used to inspect and manage the event log (see section 5.3.1). A shortcut to the event log is found in the Activity menu.
4
Chapter 3. Data Views
3.Data Views
3.1.General
3.1.1.General Data View Properties
The data views in category 1 (numbered “1.x”) are capable of showing both WCDMA and GSM data. Both will appear simultaneously if the phone is making inter-RAT neighbor measurements.
The data views in category 2 chiefly contain WCDMA-specific data, and those in category 3 and 4 chiefly contain GSMand GPRS/EGPRS-specific data.
All data views have the same general structure in idle mode and dedicated/ active mode.
Whenever a parameter is currently not valid, this is indicated in the data view by a dash “–” or a string of dashes.
Certain parameters are presented both numerically and graphically, the number appearing on top of a colored bar whose length and color depend on the parameter value. These parameters are tagged “numeric/graphic” in sections 3.3–3.19. The rules for the graphic presentation are found in appendix B, page 89.
In the case of frequency hopping, the hopping list is shown one channel at a time, a new channel appearing every second.
3.1.2.The Built-in Help Function
If you press More and select “Toggle help”, a callout box appears describing the piece of data in the top left corner of the screen. Use the navigation key to navigate the contents of the data view.
LZT 108 9090 R3A |
5 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
•To turn off the help function, press the Return key
. Alternatively, press More and choose Toggle help again.
3.1.3.Data View Actions
In some data views you can perform an action relating to a piece of data shown in the view. For example, in data views listing cells, you can lock on one of the cells.
All data view actions are performed by pressing the More button and choosing Data view actions. A submenu appears listing the available actions.
Specifics on data view actions are found in the subsequent sections.
6
Chapter 3. Data Views
3.2.Survey of Data Views
No. |
View Name |
Description |
|
|
|
1.1 |
W/G Cells |
Combines WCDMA Cells (2.1) and GSM |
|
|
Cells (3.1) views into a dual mode view. |
|
|
|
1.2 |
PDP Context |
Displays PDP addresses and PDP context |
|
|
settings for each address, including NSAPI |
|
|
and APN. |
|
|
|
1.3 |
MM/GMM |
Displays identities common to WCDMA and |
|
|
GSM, such as TMSI, P-TMSI, and CGI of |
|
|
last registered network. |
|
|
|
1.4 |
Time Log |
Displays time spent by the phone in various |
|
|
states since last power-on. |
|
|
|
1.5 |
GPS |
Displays essential GPS data: latitude and |
|
|
longitude, altitude and speed, number of |
|
|
satellites, fix quality, time and date. Note: |
|
|
This view is only available if TEMS Pocket |
|
|
has the GPS option installed. |
|
|
|
|
|
|
2.1 |
WCDMA Cells |
Displays UARFCN, cell status, scrambling |
|
|
code, RSCP, Ec/No, and path loss for each |
|
|
cell in active set and monitored/detected |
|
|
neighbor sets. |
|
|
|
2.2 |
WCDMA Channel |
Displays SIR and SIR target, power control |
|
|
information, RRC state, and information on |
|
|
transport channels used. |
|
|
|
2.3 |
WCDMA Data |
Presents SIR and SIR target, power control |
|
|
information, RRC state, and information on |
|
|
uplink and downlink RLC and transport |
|
|
channel performance. |
|
|
|
– |
WCDMA WAP |
Displays a subset of the WCDMA Data view |
|
browser view |
(2.3) during WAP browsing. |
|
|
|
LZT 108 9090 R3A |
7 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
No. |
View Name |
Description |
|
|
|
|
|
|
3.1 |
GSM Cells |
Displays ARFCN, BSIC, RxLev, C1/C31, |
|
|
and C2/C32 for the serving cell and each |
|
|
neighbor. Also presents system information |
|
|
data for cell access, selection, and location. |
|
|
|
3.2 |
GSM Cell Id |
Displays ARFCN, LAC, CI, and RxLev for |
|
|
the serving cell and each neighbor. Also |
|
|
presents system information data for cell |
|
|
access, selection, and location. |
|
|
|
3.3 |
GSM BA List |
Presents the GSM BA neighbor list as |
|
|
received from the network and shows which |
|
|
BCCH ARFCN the list was received from. |
|
|
|
|
|
|
4.1 |
GSM Serving Cell |
Presents system information data on |
|
|
serving cell depending on mode (idle/ |
|
|
connected). Note: TMSI, P-TMSI, and TLLI |
|
|
have been moved to the MM/GMM data |
|
|
view. |
|
|
|
4.2 |
GPRS Data |
Displays traffic channel ARFCN, timeslots |
|
|
and coding schemes used, and LLC and |
|
|
RLC performance on uplink and downlink. |
|
|
|
4.3 |
GPRS Info |
Displays traffic channel ARFCN, timeslots |
|
|
and coding schemes used, and vital GPRS/ |
|
|
EGPRS configuration parameters |
|
|
|
4.4 |
GSM C/I Info |
Displays C/I information for the most |
|
|
frequently utilized timeslot for each ARFCN |
|
|
in use. |
|
|
|
4.5 |
GSM AMR |
Displays GSM logical channel information, |
|
|
AMR codec selected on uplink and |
|
|
downlink, and statistics on AMR codec |
|
|
utilization. |
|
|
|
– |
GPRS WAP |
Displays a subset of the GPRS Data view |
|
browser view |
(4.2) during WAP browsing. |
|
|
|
8
Chapter 3. Data Views
3.3.W/G Cells (View No. 1.1)
Screenshot
Key (not shown in this format in the phone display)
Lines 1–4 show WCDMA cells and are thus primarily used in WCDMA mode. However, when WCDMA neighbors are measured in GSM mode, these neighbors also appear here. Note that if you have locked the phone to GSM (Lock to RAT function, section 5.2.1), no WCDMA neighbors will ever be measured.
W: WCDMA cell type: One of
•S: Serving cell
•A: Active set member
•M: Monitored neighbor
•D: Detected neighbor
•– (with values on the rest of the line): Inter-RAT, WCDMA neighbor measured in GSM mode
UARFC: UARFCN, UMTS Absolute Radio Frequency Channel Number
SC: Scrambling Code
RSCP: Received Signal Code Power (dBm), numeric/graphic
Ec/No: Ec/No (dB), numeric/graphic
PL: Pathloss (dB); this measurement appears only when ordered by the network
Lines 5–8 show GSM cells and are thus primarily used in GSM mode. If GSM neighbors are measured while in WCDMA mode, these neighbors also appear here. Note that if you have locked the phone to WCDMA (Lock to RAT function, section 5.2.1), no GSM neighbors will ever be measured.
Line 5: GSM serving cell
Lines 6–8: Three strongest GSM neighbors G: GSM channel type for serving cell: One of
•B: BCCH; P: PBCCH, p: Hopping PBCCH
•S: SDCCH, s: Hopping SDCCH
•T: TCH, t: Hopping TCH
•D: PDTCH, d: Hopping PDTCH
LZT 108 9090 R3A |
9 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
Screenshot
Key
ARFC: ARFCN, Absolute Radio Frequency Channel Number
BS: BSIC, Base Station Identity Code
RxLev: Received Signal Strength (unit userconfigurable: see section 5.10.6), numeric/graphic
Lines 9–10 are used in both WCDMA and GSM mode, showing information on the network that the phone is currently using. The information shown in WCDMA and GSM mode is partly different, as detailed below.
This information is repeated in many other data views.
C: Current RAT {G: GSM, W: WCDMA, –: No service}
(U)ARFC: WCDMA: Serving cell UARFCN; GSM: Serving cell BCCH ARFCN
B: WCDMA: Serving cell Scrambling Code; GSM: Serving cell BSIC
RSSI: Serving cell Received Signal Strength Indicator (= RSCP in WCDMA; = RxLev in GSM), numeric/graphic
RAC: Serving cell Routing Area Code MCC: Serving cell Mobile Country Code MNC: Serving cell Mobile Network Code LAC: Serving cell Location Area Code
RNC: Serving cell Radio Network Controller ID (WCDMA only; Cell Identity for WCDMA consists of RNC + CI)
CI: Serving cell Cell Identity
10
Chapter 3. Data Views
3.3.1.Data View Actions
•You can lock on a cell or (in WCDMA mode) an UARFCN that is listed in the data view.
•Choose the cell or UARFCN to lock on by moving the red frame, using the navigation key. When you have navigated to the desired item, press Select.
•To unlock, enter the Data view actions menu again and give the appropriate Unlock command.
LZT 108 9090 R3A |
11 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.4.PDP Context (View No. 1.2)
Screenshot
Key
Lines 1–6 show data on the active PDP contexts (up to three) and the contents of the PDP context request.
PDP Address: IPv4 PDP address (12-digit number). See 3GPP TS 24.008, sec. 10.5.6.4.
NSAPI: Network Service Access Point Identifier. See 3GPP TS 24.008, sec. 10.5.6.2.
D: Delay Class {0 ... 4}
R: Reliability Class {0 ... 5}
K: Peak Throughput {0 ... 9}
P: Precedence Class {0 ... 3}
MT: Mean Throughput {0 ... 18, 31}
(For the meanings of values, see appendix A.8.) APN: Access Point Name
Lines 7–8 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
There are no actions associated with this data view.
12
Chapter 3. Data Views
3.5.MM/GMM (View No. 1.3)
Screenshot
Key
Lines 1–4 show data related to Mobility Management/GPRS Mobility Management.
TMSI: Temporary Mobile Subscriber Identity (hex)
T3212C: T3212, current time between location updates {Off, 0 ... 1530 minutes}
T3212M: T3212, max time between location updates {Off, 0 ... 1530 minutes}
PTMSI: Packet TMSI (hex)
GMM: GMM Attached {A: Attached, –: Not attached}
TLLI: Temporary Logical Link Identifier (hex)
The following four parameters are updated each time the phone performs a Location Area Update or Routing Area Update.
RMCC: Registered MCC
RMNC: Registered MNC
RLAC: Registered LAC
RRAC: Registered RAC
Lines 5–6 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
There are no actions associated with this data view.
LZT 108 9090 R3A |
13 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.6.Time Log (View No. 1.4)
This view shows the time (in hours, minutes, and seconds) that the phone has spent in each of the following states since last power-on.
|
MM |
|
|
Home: Registered in Home PLMN |
|
|
Equiv: Registered in Equivalent PLMN |
|
|
Roam: Registered in Roaming PLMN |
|
|
Unreg: Unregistered |
|
Screenshot |
||
(See 3GPP TS 21.905.) |
||
|
||
|
GSM |
|
|
TCH: Time using Traffic Channel (TCH) |
|
|
PDCH: Time using Packet Data Channel (PDCH) |
|
|
Idle: Time spent in Idle mode |
|
|
WCDMA |
|
|
DCH: Time using Dedicated Channel (DCH) |
|
|
Idle: Time spent in Idle mode |
|
|
No Service: Time spent in No Service mode |
3.6.1.Data View Actions
You can reset all counters in this view by choosing Reset time log.
14
Chapter 3. Data Views
3.7.GPS (View No. 1.5)
This view is shown only if the GPS option has been purchased with the product.
|
Lines 1–8 show GPS data. |
|
|
||
|
Latitude: Latitude in degrees, minutes, and |
|
|
decimal minutes. |
|
|
Longitude: Longitude in degrees, minutes, and |
|
|
decimal minutes. |
|
|
Altitude: Height above sea level in meters. |
|
|
Speed: Speed in km/h. |
|
|
No. of satellites: The number of satellites seen by |
|
Screenshot |
||
the GPS device. |
||
|
Fix quality: Quality of GPS fix; see appendix A.16. |
|
|
Time: Time of day, hh:mm:ss |
|
|
Date: Date, yy-mm-dd |
|
|
No. of satellites and Fix quality will always be valid |
|
|
as long as the phone is connected to the GPS. |
|
|
Lines 9–10 are the same as the two bottom lines in |
|
|
the W/G Cells view: see section 3.3. |
There are no actions associated with this data view.
LZT 108 9090 R3A |
15 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.8.WCDMA Cells (View No. 2.1)
Screenshot
Key
Up to eight cells from the WCDMA active set can be shown.
Lines 1–8
W: WCDMA cell type: One of
•S: Serving cell
•A: Active set member
•M: Monitored neighbor
•D: Detected neighbor
•– (with values on the rest of the line): Inter-RAT, WCDMA neighbor measured in GSM mode
UARFC: UARFCN
SC: Scrambling Code
RSCP: Received Signal Code Power (dBm), numeric/graphic
Ec/No: Ec/No (dB), numeric/graphic
PL: Pathloss (dB); this measurement appears only when ordered by the network
Lines 9–10 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
3.8.1.Data View Actions
You can lock on a WCDMA cell or UARFCN that is listed in the view. The procedures for locking and unlocking are the same as in the W/G Cells view; see section 3.3.1.
16
Chapter 3. Data Views
3.9.WCDMA Channel (View No. 2.2)
Screenshot
Key
Line 1
SIR: Signal-to-Interference Ratio (dB) SIR_TG: SIR Target (dB)
TxPwr: UE Transmit Power (dBm), numeric/ graphic
Line 2
PCA: Power Control Algorithm, see 3GPP TS 25.331
PCSS: Power Control Step Size, see 3GPP TS 25.331
RRC_STATE: RRC State, one of {CELL_DCH, CELL_FACH, CELL_PCH, URA_PCH, IDLE, PASSIVE}
CM: Compressed Mode: 0: No, 1: Yes
Lines 3–8
These lines show the configuration of up to 6 transport channels:
ChId: Transport Channel Id
ChT/D: Transport Channel Type and Direction DLBT: Downlink BLER Target (%)
Rate: Maximum transport channel bit rate (bit/s)
Lines 9–10 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
There are no actions associated with this data view.
LZT 108 9090 R3A |
17 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.10.WCDMA Data (View No. 2.3)
Screenshot
Key
Line 1
SIR: Signal-to-Interference Ratio (dB) SIR_TG: SIR Target (dB)
TxPwr: UE Transmit Power (dBm), numeric/ graphic
Line 2
PCA: Power Control Algorithm, see 3GPP 25.331 PCSS: Power Control Step Size, see 3GPP 25.331
RRC_STATE: RRC State, one of {CELL_DCH, CELL_FACH, CELL_PCH, URA_PCH, IDLE, PASSIVE}
CM: Compressed Mode: 0: No, 1: Yes
Lines 3–6 report the current performance of and some statistics on the WCDMA data transfer. All values are combined values computed over all used channels.
Line 3: RLC protocol level, downlink Line 4: Transport channels, downlink Line 5: RLC protocol level, uplink Line 6: Transport channels, uplink
Rate: Instantaneous data transfer rate in bytes/s. For RLC this bit rate includes AM channels only (not TM and UM).
Err: Percentage of data blocks erroneously decoded (on downlink), numeric/graphic
Retr: Percentage of data blocks retransmitted (on uplink; RLC only), numeric/graphic
TotData: Total bytes transferred (B = bytes, K = kilobytes, M = megabytes). You can reset these counters as explained in section 3.10.1 below.
18
Chapter 3. Data Views
Lines 7–8 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
Screenshot
Key
3.10.1.Data View Actions
You can reset all counters in this view by choosing Reset data counters. This command also resets the counters in the GPRS Data view (see section 3.15).
LZT 108 9090 R3A |
19 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.11.GSM Cells (View No. 3.1)
|
Line 1 (GSM serving cell) |
||
|
|||
|
L: Logical Channel |
||
|
• |
B: BCCH |
|
|
• |
P: PBCCH |
|
|
• |
p: Hopping PBCCH |
|
|
• |
S: SDCCH |
|
|
• |
s: Hopping SDCCH |
|
|
• |
T: TCH |
|
|
• |
t: Hopping TCH |
|
|
• |
D: PDTCH |
|
Screenshot |
|||
• |
d: Hopping PDTCH |
||
|
BC: Serving Cell BCCH ARFCN |
||
|
|||
|
BS: Base Station Identity Code (BSIC) |
||
|
RxLv: Received Signal Strength (unit user- |
||
|
configurable: see section 5.10.6), numeric/graphic |
||
|
R: Routing Area Color, RACo {0 ... 7}; invalid (“–”) if |
||
|
GPRS not available in network |
||
|
If the cell does not broadcast packet channels (no |
||
|
PBCCH), the two rightmost parameters are: |
||
Key |
|||
C1: Pathloss Criterion C1 |
|||
|
|||
|
C2: Cell Reselection Criterion C2 |
||
|
If the cell supports packet channels (broadcasts a |
||
|
PBCCH), the two rightmost parameters become: |
||
|
C31: GPRS Signal Strength Threshold Criterion |
||
|
C31 |
||
|
C32: GPRS Cell Ranking Criterion C32 |
||
20
Screenshot
Key
Chapter 3. Data Views
Lines 2–7 (GSM neighbor cells)
NC1 ... NC6: Neighbor Cell BCCH ARFCN of six strongest neighbors
The rest is as on line 1 except for the addition of: A: Location Area/Routing Area properties:
•=: Same LA/RA
•R: Same LA, different RA
•L: Different LA
•P: PLMN not matching
•–: Unknown
Line 8
MT: MS-TXPWR-MAX-CCH, maximum RACH power (dBm) {GSM 900: 5 ... 39; GSM 1800: 0 ... 36; GSM 1900: 0 ... 33}
RH: Cell Reselection Hysteresis (dB) {0, 2, 3, 6, 8, 10, 12, 14}
B: BS-PA-MFRMS, number of multiframes between paging subgroups {2 ... 9}
CB: Serving cell barred {B: Barred, –: Not Barred}
Lines 9–10 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
3.11.1.Data View Actions
You can lock on a GSM cell that is listed in the view. The procedures for locking and unlocking are the same as in the W/G Cells view; see section 3.3.1.
LZT 108 9090 R3A |
21 |
TEMS Pocket 5.3 User’s Manual – Sony Ericsson K800i
3.12.GSM Cell Id (View No. 3.2)
Screenshot
Key
Line 1 (GSM serving cell)
L: Logical Channel
•B: BCCH
•P: PBCCH, p: Hopping PBCCH
•S: SDCCH, s: Hopping SDCCH
•T: TCH, t: Hopping TCH
•D: PDTCH, d: Hopping PDTCH
BCCH: Serving Cell BCCH ARFCN LAC: Serving Cell Location Area Code CI: Serving Cell Identity
RxLev: Serving Cell RxLev (unit user-configurable: see section 5.10.6), numeric/graphic
Lines 2–7 (GSM neighbors)
NC1 ... NC6: Neighbor Cell BCCH ARFCN of six strongest neighbors
LAC: Neighbor Cell Location Area Code CI: Neighbor Cell Identity
RxLev: Neighbor Cell RxLev
Line 8
MT: MS-TXPWR-MAX-CCH, maximum RACH power (dBm) {GSM 900: 5 ... 39; GSM 1800: 0 ... 36; GSM 1900: 0 ... 33}
RH: Cell Reselection Hysteresis (dB) {0, 2, 3, 6, 8, 10, 12, 14}
B: BS-PA-MFRMS, number of multiframes between paging subgroups {2 ... 9}
CB: Serving cell barred {B: Barred, –: Not Barred}
Lines 9–10 are the same as the two bottom lines in the W/G Cells view: see section 3.3.
22
Loading...
