Mobile Telephone
3-233-439-12(1)
Operating Instructions
CMD-Z7
© 2001 Sony Ericsson Mobile Communications AB
GB
Page 2
01GB01COV-AE4.book Page 2 Friday, August 10, 2001 3:36 PM
2 GB
My CMD-Z7 Information
For easy reference, please record the
following identification numbers for your
phone and SIM Card. This information will
assist you in customer inquiries to your retail
dealer, manufacturer or Network Operator/
Service Provider. In case of loss or theft of
your phone and/or SIM Card, call your
Network Operator/Service Provider
immediately to prevent misuse.
My Mobile Phone Number:
___________________________________
Operator Customer Service Number:
___________________________________
My SIM Card Number:
(Printed on your SIM Card)
___________________________________
My Phone's ID Number (IMEI):
(Printed on the label underneath the battery pack)
___________________________________
Explanation of the icons
(Instruction purpose only.)
Icons Explanations
Important
Notes
Contact your Network Operator/
Service Provider for details
Page 3
01GB01COV-AE4.book Page 3 Friday, August 10, 2001 3:36 PM
Safety Precautions
• Do not use your phone in an aircraft,
hospitals, petrol stations, or in places where
mobile phones are prohibited.
• Note that in some countries using a cellular
phone without a hands-free kit while
driving is not allowed.
• Do not expose your phone to extreme
conditions such as high humidity/rain, high
temperatures, direct sunlight, caustic/harsh
chemicals or dust.
• Do not allow children to play with your
phone.
• Take special care in the disposal of your
battery, using a special facility where
available. Do not puncture, burn, or short
circuit your battery.
• Limit the distance between the mains
socket and the phone when charging for
easy accessibility.
• Consult your physician or the manufacturer
of personal medical devices (pacemakers,
hearing aids. etc.) regarding any restrictions
on the use of a mobile telephone.
• Use only Sony Ericsson Mobile
Communications AB-approved CMD-Z7
batteries and accessories with your phone.
• Do not touch the External Antenna
Connector. Use always Sony original
accessories.
• Do not put your mobile phone in a
microwave oven; this may cause damage
either to the oven or the phone.
Your Sony
Getting
Basic
Menu
Appendix
3 GB
CMD-Z7
Started
Operation
Operation
Page 4
01GB01COV-AE4.book Page 4 Friday, August 10, 2001 3:36 PM
Warning
• Unauthorised batteries, chargers, and
accessories will invalidate any approvals
and warranty given for your phone and may
be dangerous.
• Do not damage or puncture your battery
pack with a sharp object.
• For use in the car, please connect your
GSM mobile phone to an external antenna.
The external antenna can be connected to
your mobile phone via the appropriate
accessory, e.g. Hands-free Kit. Please
contact your car manufacturer concerning
the appropriate position of the external
antenna on your car.
This carton’s top layer is made from 85% recycled paper, fluting and inner layer are made
from 100% recycled paper.
Halogenated flame retardant not used in cabinets.
Halogenated flame retardant not used in printed wiring boards in main portions.
4 GB
Lead free solder is used for soldering in certain portions.
Page 5
01GB01COV-AE4.book Page 5 Friday, August 10, 2001 3:36 PM
Table of Contents
Welcome to Sony CMD-Z7 . . . . . . . . 7
What’s Included in Your Kit . . . . . . . . . . . . . . . . 7
Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Basic Features of Your Phone . . . . . . . . . . . . . . . 8
Advanced Jog Dial . . . . . . . . . . . . . . . . . . . . . . 8
Loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
The Voicemail Key . . . . . . . . . . . . . . . . . . . . . . 8
Manner Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Icon Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Menu Overview . . . . . . . . . . . . . . . . . . . . . . . . 11
Applications Menu . . . . . . . . . . . . . . . . . . . . . 11
Getting Started. . . . . . . . . . . . . . . . 12
Inserting the Battery Pack . . . . . . . . . . . . . . . . . 12
Inserting the SIM Card . . . . . . . . . . . . . . . . . . . . 12
Charging the Battery Pack . . . . . . . . . . . . . . . . . 13
Switching on Your Phone . . . . . . . . . . . . . . . . . . 14
Connecting to the Network . . . . . . . . . . . . . . . . . 15
Basic Operation . . . . . . . . . . . . . . . 16
Making Calls (Saving Phonebook Entries) . . . . 16
Voice Dialing . . . . . . . . . . . . . . . . . . . . . . . . . 17
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . 18
Answering/Ending Calls . . . . . . . . . . . . . . . . . . 19
During a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Entering Text . . . . . . . . . . . . . . . . . 22
Standard Text Entry . . . . . . . . . . . . . . . . . . . . . . 22
T9 Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Phonebook . . . . . . . . . . . . . . . . . . . 24
Phonebook Organisation . . . . . . . . . . . . . . . . . . 24
Saving Phonebook Entries from Standby Mode 24
Making Calls from the Phonebook . . . . . . . . . . 24
Phonebook Menu . . . . . . . . . . . . . . . . . . . . . . . . 25
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Editing the Phonebook . . . . . . . . . . . . . . . . . . . . 27
Your Sony
Getting
Basic
Menu
Appendix
5 GB
CMD-Z7
Started
Operation
Operation
Page 6
01GB01COV-AE4.book Page 6 Friday, August 10, 2001 3:36 PM
Menu Operations . . . . . . . . . . . . . . . 29
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Voice Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Divert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Call History . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Extras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
WAP Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Applications Menu Operations . . . . . . . . . . . . . .58
Appendix . . . . . . . . . . . . . . . . . . . . . 59
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 59
Unblocking the SIM Card . . . . . . . . . . . . . . . . . .61
Technical Specifications . . . . . . . . . . . . . . . . . . . 61
Index . . . . . . . . . . . . . . . . . . . . . . . . 63
6 GB
Page 7
01GB01COV-AE4.book Page 7 Friday, August 10, 2001 3:36 PM
Welcome to Sony CMD-Z7
What’s Included in Your
Kit
The kit should include one mobile phone, one
standard battery, one charger and this manual.
If one of these parts is missing, please contact
your retail dealer immediately.
Quick Reference
1
2
3
4
5
6
1
Ear piece
2
Advanced Jog DialqxExternal Antenna
3
Voice Mail Key
4
Keypad
5
Microphone
6
Flip
7
Display
8
Send Key
9
Memo Key
0 Clear Key
qs
qd
qf
qg
7
8
qh
9
0
qa
qj
qa
On/Off Key
Call End Key
Connector
qc
Headset Connector
qf
Finger Stop
qg
Loudspeaker
qh
Battery Cover
qj
Charging Indicator
qk
Battery Release Button
ql
External Connector
(Charging and
Accessories)
CMD-Z7
Your Sony
qk
Getting
Started
ql
Basic
Operation
Menu
Operation
Appendix
7 GB
Page 8
01GB01COV-AE4.book Page 8 Friday, August 10, 2001 3:36 PM
8 GB
Basic Features of Your
Phone
Advanced Jog Dial
The Jog Dial provides fast and easy menu
navigation with only one hand.
Operation
Rotate Opens Phonebook in
Press
(Click)
Press and
Hold
Press
forward
Press
backward
Function
Standby Mode. Scrolls
through menu options.
Opens Menu in Standby
Mode. Selects an option
(highlighted) in the
display.
Dials the Phone
Number selected.
Exits from one menu to
the previous screen.
Also ends a call.
Opens the “pop up
menu”.
Loudspeaker
During a call, press the Jog Dial backward
and select Loudspeaker to turn the
loudspeaker on/off.
The Voicemail Key
Press and hold to access your Voicemail
(see also page 27).
Page 9
01GB01COV-AE4.book Page 9 Friday, August 10, 2001 3:36 PM
Manner Mode
• In standby mode when the flip is closed,
press the Jog Dial backward to activate/
deactivate the manner modes.
• Once selected, it is possible to switch
among the manner mode functions. All
manner mode icons appear in the display;
rotate the Jog Dial to select one:
– Silent Mode : turns the ringer and
all tones to silent mode.
– Single beep : ringer is restricted to a
discrete single beep.
– Vibr a Alert : V ibra Alert without the
ringer.
– Outdoor Mode : turns the ringer and
all tones to the maximal volume.
Icon Glossary
Icon Explanation
Network not available
Network signal strength (strong)
Battery strength
SMS (Envelope Icon)
Voicemail
Alarm
Silent Mode
Vibra Alert
Single Beep
Outdoor Mode
Ringer off
Missed calls
Incoming call barring
Outgoing call barring
Your Sony
Getting
Basic
Menu
Appendix
9 GB
CMD-Z7
Started
Operation
Operation
Page 10
01GB01COV-AE4.book Page 10 Friday, August 10, 2001 3:36 PM
10 GB
Icon Explanation
Incoming + Outgoing call barring
Conditional Divert
Unconditional Divert
Active call
Call hold
Mute Microphone
Headset connected – active call
Handsfree kit connected
(auto answer on)
Loudspeaker on
Conversation Privacy (ciphering) not
supported
„ Search
Press the Jog Dial backward (pop-up
menu)
T9 (Text editing system)
Icon Explanation
Paste
Page 11
01GB01COV-AE4.book Page 11 Friday, August 10, 2001 3:36 PM
Menu Overview
Press the Jog Dial from standby mode to
access the Main Menu:
Messaging page 30
Read
Create
Settings
Local Area Info
Sounds page 34
Ringer
Set Sound
Voice Memo page 35
Settings page 36
Preferences
Security
Call Data
Call Settings
Divert page 43
All Calls
If Not Reachable
If No Reply
If Busy
All Fax
All Data
Cancel All
WAP page 54
Home
Favourites
Settings
Scheduler page 52
Calendar
Extras page 46
Clock
Calculator
Games
E-Mail
Call History page 45
Outgoing Calls
Incoming Calls
Missed Calls
Delete All
Phonebook page 24
Phonebook Menu
Voicemail
Search
Applications Menu
Press the Jog Dial backward from standby
mode to access the Applications menu:
WAP page 54
Home
Favourites
Settings
E-mail page 49
Read
Send
Settings
Games page 48
Black Jack
Table Soccer
11 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 12
01GB01COV-AE4.book Page 12 Friday, August 10, 2001 3:36 PM
Getting Started
12 GB
Inserting the Battery
Pack
1 Unwrap the battery pack.
2 Press the battery cover release button and
slide down to remove the cover.
3 Align the claws on the battery terminal
with those of the phone and press battery
down.
4 Align the claws at the side of the cover
with the phone and slide back into the
phone until the lock clicks into place.
To remove the Battery Pack
First power off and wait until the display goes
blank. Remove the cover and pull the knob of
the battery up to remove the battery.
If you insert a new battery, please reset the clock.
Inserting the SIM Card
Your SIM card contains a computer chip with
your service details and phone number. Like a
credit card, it should be kept securely and
handled carefully. Do not bend, scratch or
expose to moisture. Avoid static electricity.
To avoid corrupting the memory of your SIM card,
always switch off your phone before removing or
inserting your SIM card.
Page 13
01GB01COV-AE4.book Page 13 Friday, August 10, 2001 3:36 PM
1 Remove the battery cover and the battery.
2 Slide out the SIM card holder by pulling
the knob on the holder.
3 Insert SIM card into the holder.
4 Slide the holder back into the phone.
5 Replace the battery and the cover.
To remove the SIM card
Follow steps 1 to 5 above removing the SIM
card from the holder in step 3.
Charging the Battery
Pack
As supplied, your battery pack will not be
fully charged.
1 Plug the charger into a mains socket.
2 Plug the charger into the bottom (jack) of
the phone.
13 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 14
01GB01COV-AE4.book Page 14 Friday, August 10, 2001 3:36 PM
14 GB
Removing the charger from the phone:
1
2
• Both the status bar within the battery icon
in the display and the charging indicator (red
light) show the charging status.
• Charging (0°C-45°C) is complete when the
battery icon displays all bars, is no longer
blinking and the charging indicator (red light) is
off.
• Full charging can take up to approx. 3 hours, but
may vary depending on certain conditions, (e.g. if
your phone is switched on or temperature is
outside the operating range.)
• When your battery pack is completely empty, it
can take some time until the battery icon appears
when charging.
• As an energy-saving measure, disconnect the
charger from the mains socket and from the
phone after charging.
• On exposure to high temperatures your battery
may expand slightly. This has no influence on
your safety/health and will reduce in size once reexposed to a lower temperature.
• Use only the Sony-specified CMD-Z7 battery
pack and charger.
• Disposal advice: Take special care in the disposal
of the battery, using special facilities where
available.
Usage time
When your battery pack is nearly empty, the
battery icon in the display flashes and a beep
indicates that approximately 1 minute of talk
time remains.
Switching on Your Phone
To switch on/off your phone, press and hold
.
Entering PIN (Personal
Identification Number)
Enter your PIN using the
number keys (the PIN
appears in code as ****)
and press the Jog Dial (or
) to confirm.
Page 15
01GB01COV-AE4.book Page 15 Friday, August 10, 2001 3:36 PM
If you do not enter a PIN code, your phone
will automatically switch off after a few
minutes. It is possible but not recommended
to disable the PIN code prompt (see page 38).
Connecting to the
Network
After successfully entering your PIN code,
your phone searches for an available GSM
network. The network search is automatic and
may take a few seconds.
You are ready to make and receive calls when
the network operator's name and the signal
strength icon appears on the display.
The following indicates the strength of the
received network signal. If the signal is very
weak, there is a risk of losing service.
Strong signal ↔ Weak signal ↔ Network not
available
If you cannot obtain service
• If you cannot obtain network service the
reception strength may be too weak. Move
to a higher elevation, a window or an open
space and make sure that there is nothing
obstructing the antenna.
• Once you have switched on your phone do
not cover the internal antenna area above
the finger Stop with your hand.
Roaming
If you are out of range of your “Home”
Network Operator, especially when abroad,
another Network Operator may be selected
automatically, subject to signal strength and
roaming agreements between network
operators.
15 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 16
01GB01COV-AE4.book Page 16 Friday, August 10, 2001 3:36 PM
Basic Operation
16 GB
Making Calls (Saving
Phonebook Entries)
Dialling a Number
1 Dial the complete
number of the party
you want to call
(including the area
code even when
dialling locally). In
case of International
Calls, press and hold until “+”
appears. Then enter the country code,
followed by the area code and the
number.
2 Press to correct an y errors. Press and
hold to clear the entire number.
3 Press and hold the Jog Dial (or press )
to call the number displayed or
4 Press the Jog Dial and select Save to save
the number to the Phonebook.
If the Auto Redial option is on (see page 42) and the
number you have called is engaged, your phone
automatically displays the Auto Redial option.
Choosing a Phonebook entry
1 Rotate the Jog Dial in standby mode to
open the Phonebook.
2 Use the Jog Dial to display the ABC sort
list. (If there are several numbers stored
for one person’s name, select one of them
using the Jog Dial.)
3 Press and hold the Jog Dial (or press )
to call the number displayed.
To search the Phonebook, press an alphanumeric
key on the keypad to advance to that letter in the
Phonebook. (E.g. to advance to entries beginning
with “M”, press .)
Page 17
01GB01COV-AE4.book Page 17 Friday, August 10, 2001 3:36 PM
Voice Dialing
Voice Dialing makes dialing Phonebook
entries easy. Simply press and hold the Jog
Dial and say person's name (Voice Tag) in the
phone's microphone. Once the phone
recognizes the Voice Tag, the phone
automatically dials after 2 seconds (the 2seconds gives you time to cancel your call by
pressing the Jog Dial or End Key).
It is necessary to set up the Voice Tag in
advance to use the Voice Dialing option (see
“Creating the Voice Tag Entries”, page 17).
You can save up to 10 Phonebook entries with
a Voice Tag.
Creating the Voice Tag Entries
1 Rotate the Jog Dial in standby mode to
open the Phonebook and select the name
to which you want to attach a Voice Tag
and press the Jog Dial.
2 Rotate the Jog Dial to select the name
again and then Voice Tag.
3 Select the respective icons to Record
(), Stop (), Play (), Save () or
Delete ( ) a Voice Tag.
4 Repeat step 3 after the message Once
Again.
Once you have assigned 10 Voice Tags, it is necessary to follow the procedure above and in step 3
choose Delete to delete a Voice Tag. Then select
another name from the Phonebook and follow the
procedure to assign the Voice Tag to a new entry.
17 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 18
01GB01COV-AE4.book Page 18 Friday, August 10, 2001 3:36 PM
18 GB
Speed Dialing
The Speed Dialing option allows you to
“speed dial” your chosen number by pressing
and holding the corresponding key and then
press Call. To use the Speed Dialing option it
is necessary to assign a key to a number in
advance. You can assign up to 8 keys using
keys to only ( is reserved for
voicemail, see page 27).
Creating the Speed Dialing Entries
1 Press and hold the key that you want to
assign a number to.
2 Enter the phone number using the keypad
or by pressing the Jog Dial backward to
select from Phonebook entries.
3 Press the Jog Dial to confirm.
Editing a number
Follow steps 1-3 in “Creating the Speed
Dialing Entries” (see page 18). In step 2,
select one of the following options:
}Call to call the number.
}View to display the number.
} Edit Number to change the number.
} Delete to delete the number.
Speed Dialing Entries can only be saved to your
phone memory.
Page 19
01GB01COV-AE4.book Page 19 Friday, August 10, 2001 3:36 PM
Answering/Ending Calls
When the flip is open
Press the Jog Dial (or ) to accept the call.
When the flip is closed
Press the Jog Dial to accept the call.
• If you do not wish to answer the call, press
or press the Jog Dial backward and select Busy
while the phone is ringing. The call will then be
rejected (the caller will hear a busy tone (network
dependant) or will be diverted if a div ert has been
set).
If a call is not answered, appears on the top
line of the display.
Select the Call History from the Main Menu for
information about the missed call.
• In very rare cases, ciphering does not work in
some networks, meaning that third parties can
listen to your phone call. In this case, appears
on the display.
Press the Jog Dial forward (or press ) to
end a phone call.
Flip Call
When Flip call is set (see page 42) and you
receive a call, you can accept it by opening
the flip cover. Close the flip cover to end the
call.
When the Headset is connected to your
phone, answer a call by pressing the Headset
button (beep). Press and hold the Headset
button to end the call (2x beep).
Connect/disconnect the headset only when
the phone is switched off or in stand-by mode.
19 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 20
01GB01COV-AE4.book Page 20 Friday, August 10, 2001 3:36 PM
20 GB
During a call
Adjusting the Ringer/Speaker
Volume
• During an incoming call, rotate the Jog
Dial to adjust the ringer volume.
• During a call, rotate the Jog Dial to adjust
the speaker/earpiece volume. (Rotate up =
increase volume/Rotate down = decrease
volume)
Use your phone as a Notepad by entering a phone
number during a call. When ending the call, the
number entered will reappear on the display. Use the
Jog Dial to save the number in the Phonebook or to
call the number.
Call Menu
Press the Jog Dial backward during a call for
the following options:
Call Hold
Use Call Hold to manage two calls at the same
time.
One active call
1 Press the Jog Dial backward and select
Call Hold.
2 Press the Jog Dial to confirm.
3 Press the Jog Dial again to access the
Phonebook to retrieve a number (or use
the keypad to enter a number).
4 Press and hold the Jog Dial or to
make a call.
By pressing or using the Notepad to make a
second call, you can put a call on hold automatically.
End All Calls
Choose End all Calls or press to end
multiple calls.
Page 21
01GB01COV-AE4.book Page 21 Friday, August 10, 2001 3:36 PM
Send DTMF
Choose this option for sending DTMF tones,
e.g. when using Voicemail or other services.
Press and hold to clear the number and then
press to exit this option.
Mic Off/Mic On
Choose the Mic Off/Mic On option to mute
and unmute the microphone.
Loudspeaker
Turn the loudspeaker on/off. For best results
when using the loudspeaker, place the phone
on a flat surface approx. 0.5 m distance from
you.
Main Menu
Return to the Main Menu.
One active call (and/or one call on
hold) and one call waiting
When your phone alerts you (beep) that a call
is waiting, there are several options available:
1 The display automatically offers you call
waiting options.
2 } Swap to put the active call on hold and
connect the waiting call (in case of one
active call and one waiting call)
or
} Busy to indicate to the calling party that
your line is engaged.
or
} Replace to end the active call and
retrieve the call waiting.
When the Headset is connected to your
phone, answer a waiting call by pressing the
Headset button (beep). In case of one active
call and one call on hold, alternate between
the active call and the call on hold by pressing
the Headset button (beep).
Conference call
A call with more than 2 participants. To set up
a conference call, press the Jog Dial backward
to open the Call menu and select Join.
It is possible to talk with maximum of 5
callers (network dependant).
21 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 22
01GB01COV-AE4.book Page 22 Friday, August 10, 2001 3:36 PM
Entering Text
22 GB
You have the possibility to enter characters:
• Standard Text Entry using the keypad.
• Standard Text Entry using the Jog Dial.
• Text Entry using the T9 fast text entry
method.
Standard Text Entry
Using the keypad
Press the corresponding alphanumeric key
multiple times until the desired character
appears.
Using the Jog Dial
Press a key once and then rotate the Jog Dial
until the desired character appears. Press the
Jog Dial or wait for a moment to confirm.
Example: To enter “s” when creating
a message:
1 Proceed as in Create (see page 31), then
2 Press . A character or number
appears.
3 Rotate the Jog Dial to “s”.
4 Press the Jog Dial (or wait) to confirm.
• Press to shift among:
lower case letters permanently
upper case letter and then revert back
to lower case
upper case letters permanently
numbers
• Press and hold to activate/deactivate the T9
function (see page 23).
• Press
to clear the character or number just
before the cursor. To clear the entire text, press
and hold .
Page 23
01GB01COV-AE4.book Page 23 Friday, August 10, 2001 3:36 PM
T9 Text Entry
Sample entry with T9 Text Entry:
1 Proceed as in Create (see page 31), then
2 In step 3, press and hold to switch to
T9 mode if does not appear (or press
the Jog Dial backward and select T9).
3 Press
4 To type the word
“Sony”, press each of
the following keys in
order: , , ,
5 At the end of the word, check the preview
bar for the possibilities found for the key
combination you typed.
6 Rotate the Jog Dial to select “Sony”. If
your desired word is first on the list, just
press the Jog Dial to select it (or press
next word).
to shift to
.
.
to enter a space and proceed with the
If the word you intended to type does not appear in
the list, press and hold to switch to multi-tap
mode and type the word using the standard text
entry method (see page 22). When finished, press
and hold to return to T9 mode. This new word
will automatically be added to the T9 memory and
will appear in T9 mode next time.
Adding a symbol or punctuation
To insert a symbol when creating a message.
1 Press
.
2 Use the Jog Dial to scroll from row to
row.
3 Press the Jog Dial to select a row.
4 Rotate the Jog Dial to scroll within the
row.
5 Press the Jog Dial to select a symbol.
For “Smart Punctuation”, just press where you
would add a fullstop, hyphen or apostrophe. T9 will
automatically insert the most likely punctuation.
23 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 24
01GB01COV-AE4.book Page 24 Friday, August 10, 2001 3:36 PM
Phonebook
24 GB
Phonebook Organisation
Your Phonebook is organised in the following
sections:
• Phonebook Menu
• Voicemail (if it is set, see page 27)
• Search
• Customised Phonebook of priority entries
(entries 1-9)
• Alphabetically-ordered Phonebook (sorted
in alphabetical order)
Saving Phonebook Entries
from Standby Mode
See page 16 “Basic Operation – Making Calls
(Saving Phonebook Entries)” and page 25
“Creating Entries in the Phonebook”.
Making Calls from the
Phonebook
See page 16 “Basic Operation – Making Calls
(Saving Phonebook Entries)”.
Page 25
01GB01COV-AE4.book Page 25 Friday, August 10, 2001 3:36 PM
Phonebook Menu
Own Number
The first entry in the Phonebook Menu is a
place holder for your own numbers, where
you can make one or more entries to store
your own mobile number, etc. Depending on
your SIM card, you can save multiple own
number entries (including 3 numbers in the
phone).
Display Own Number
1 } ‘ Phonebook } Phonebook Menu
} Own Number
2 Rotate the Jog Dial to select the name of
the own number.
3 Press the Jog Dial and then choose View
to display the number (Select OK or press
to exit).
Enter Own Number
To save an own number entry follow steps 1-3
and then select an empty memory space using
the Jog Dial. Press the Jog Dial and enter the
number at the prompt.
Call, Edit, Delete, Copy Own Number
See page 27 “Editing the Phonebook”.
Creating Entries
1 } ‘ Phonebook
} Phonebook Menu
} New Entry
2 } SIM to save the entry
to the SIM card
memory or
} Phone to save to the
phone memory.
3 Rotate the Jog Dial to select the Number
Type Icon and press the Jog Dial.
4 Enter the phone number. Press Jog Dial to
confirm.
5 Enter a new name. Press the Jog Dial to
confirm.
25 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 26
01GB01COV-AE4.book Page 26 Friday, August 10, 2001 3:36 PM
26 GB
• When saving the Phonebook entries to the SIM
card, the number of memory spaces depends on
your SIM card.
• When saving the Phonebook entries to the Phone
memory, you can make up to 500 entries (up to
20 characters for each name and up to 40 digits
for each number.)
• To assign a group, select an entry from the
Phonebook and select No Group. Use the Jog
Dial to scroll and then select a group.
Voice Tag
Choose this option to display the list of Voice
Tag entries if a Voice Tag is set. (See also
“Voice Dialing”, page 17.)
Service Numbers
This section of the Phonebook may contain
Service Dialling Numbers (SIM card
dependant). Service Dialling Numbers cannot
be edited.
FDN Phonebook
This section may contain Fixed Dialling
Numbers (SIM card dependant). To add an
entry to the Fixed numbers rotate the Jog Dial
down to New Entry in the FDN Phonebook
and proceed as in Creating Entries in the
Phonebook. You can call, edit, delete and
copy the FDN Phonebook (see “Editing the
Phonebook”). You need the PIN2 code to
edit, delete and copy.
• The FDN Phonebook and Service Dialing
Numbers are SIM card dependant.
• The Service Dialing Numbers cannot be
modified.
Page 27
01GB01COV-AE4.book Page 27 Friday, August 10, 2001 3:36 PM
Voicemail
Press and hold for quick access to your
Voicemail.
Set up your Voicemail
1 } ‘ Phonebook
} § Voicemail
2 Enter the number at
the prompt.
3 Press the Jog Dial to
confirm your entry.
After you have set up your Voice Mail, any
editing of the number can be made via the
Phonebook (see also page 27 “Editing the
Phonebook”).
The Voicemail icon (§) or the envelope icon
(depending on the network) appears in the
display to inform you when you have receiv ed
new voice messages.
Search
} ‘ Phonebook } „ Search
It is possible to search By Name or By Group.
When opening the phonebook, press and hold
to display the list of groups and to access to a
global search.
Editing the Phonebook
Use this option for calling, editing, deleting or
copying phonebook entries. The editing of
entries is possible by Name, Number or by
Note.
Editing a Name/Number
1 } ‘ Phonebook
2 Rotate the Jog Dial to select the name/
number you want to edit and press the Jog
Dial.
3 Press the Jog Dial for a menu of editing
options:
27 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 28
01GB01COV-AE4.book Page 28 Friday, August 10, 2001 3:36 PM
28 GB
• Name editing options:
} Edit Name to change the name.
} Voice Tag to edit the Voice Tag entry.
} Delete Entry to erase the name from
the Phonebook.
} Copy Entry to copy the entry from one
memory location to another.
}View to see the complete name.
• Number editing options:
} Call to call the number.
} Edit Type to change the type of
number (e. g. Mobile, Fax, etc.).
} Edit Number to change the number.
} Delete to erase the number from the
Phonebook.
} Copy to copy the number from one
memory location to another.
}View to display the number.
4 Press the Jog Dial to confirm the
selection.
Editing Note
The Note is like a memo pad for additional
information e.g. e-mail addresses or postal
addresses in the Phonebook.
1 Follow steps 1-3 in “Editing a Name/
Number” (see page 27).
2 Select the Note entry you want to edit.
3 Press the Jog Dial for a menu of editing
options.
} Edit Icon to change the icon.
} Edit Text to change the content.
} Delete to delete the content from the
Phonebook.
}Copy to copy the entry from one
memory location to another.
}View to view the content.
4 Press the Jog Dial to confirm your
selection.
Page 29
01GB01COV-AE4.book Page 29 Friday, August 10, 2001 3:36 PM
Menu Operations
option on option off
Selecting a menu item with the
Jog Dial
1 Press the Jog Dial to select the Main
Menu from standby mode and rotate the
Jog Dial to scroll through the menu
options.
2 Press the Jog Dial to select the menu
option in the centre.
3 Press the Jog Dial forward (or press )
to exit a menu.
Your phone automatically defaults to standby mode
after approximately 10 minutes of inactivity.
Selecting a menu item with the
short-cut key
You can go to each menu by pressing the
short-cut key ( - ) from the main
menu.
Messaging Sounds
Voice memo Settings
Divert Phonebook
Call History Extras
Scheduler WAP
29 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 30
01GB01COV-AE4.book Page 30 Friday, August 10, 2001 3:36 PM
30 GB
Messaging
This feature offers
correspondence options to
read, write and send short
messages (SMS).
Read Message
When a new message
arrives, you will hear a beep which sounds
different from the single beep of the ringer
and see “ in standby mode.
1 } “ Messaging } Read } Inbox
(} Outbox to read sent messages.)
2 Scroll through the list of messages to
select the message you want to read and
press the Jog Dial to confirm. The
message appears on the display.
3 Press the Jog Dial for options to Delete,
Reply, Forward or Call Back the number
in the text.
• The capacity for storing incoming and outgoing
messages depends on your SIM card and the
phone memory.
• The message memory is full when
the display.
• Memory Full appears if you try to save a message
when the memory is already full. Delete old
messages in order to free memory space for new
messages.
• Select Delete All to clear all messages.
To Delete a Message
“ blinks in
1 Follow steps 1-3 in “Read Message” (see
page 30) and select Delete.
2 After selecting the message you want to
delete, select Yes.
Page 31
01GB01COV-AE4.book Page 31 Friday, August 10, 2001 3:36 PM
To Reply or Edit a Message
1 Follow steps 1-3 in “Read Message” (see
page 30) and select Reply.
2 Choose Text Only or Text, Attach (reply
the text with attachment).
3 Edit the message and press the Jog Dial.
4 Select Send (or Save, Cancel, Settings)
and press the Jog Dial to confirm your
selection.
To Forward a Message
Follow steps 1-3 in “Read Message” (see
page 30) and select Forward.
To Call Back the Sender of a
Message or a Number in the
Message Text
1 Follow steps 1-3 in “Read Message” (see
page 30) and select Call Back.
2 Select the number you want to call back
from the number(s) appearing in the
message, then call the number.
Create
Choose Create to create and send a message.
1 } “ Messaging } Create
2 Choose Text Only or Text, Attach (write
the text with a picture/sound message).
3 Create your message.
} Text Only: Enter the message text.
} Text, Attach: Add an attachment and
enter the message text.
4 When creating your message, press the
Jog Dial backward for the following
options:
T9 On/Off, Change Language, Time,
Date, Phonebook, Template,
Last Message, Char. Timer
5 Press the Jog Dial to confirm. Select
Enter Number or choose one of the names
from the Phonebook. Before sending, you
are given the following options:
Send, Save, Cancel, Settings
31 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 32
01GB01COV-AE4.book Page 32 Friday, August 10, 2001 3:36 PM
32 GB
• If you are interrupted (e.g. incoming call) while
creating a message, select Last Message to
retrieve the message and complete it continuing
from step 4 above.
• The picture image and sound message can only
be sent and received among Sony mobile phones
supporting this feature.
SMS list icons indicate the
properties of the message
Received message (unread)
Received message (read)
Settings
} “ Messaging } Settings
Settings allows you to customise outgoing
messages including the format, confirmation
report, etc.
Memory Class
You have the following options:
• SIM to save the message on the recipient's
SIM card.
• Phone to save the message in the recipient's
phone.
• Screen to display the message directly on
the recipient's display (without saving to
the SIM or to the phone). It is not
recommended to send confidential
messages using the screen option.
Validity Period
Specify how long messages are stored in the
service center by selecting: 1 Hour, 6 Hours,
24 Hours, 1 Week, 4 Weeks. The default
validity period is 1 Week (network
dependant).
Reply Cost
Select On if you would like to pay for the
recipient to respond to your message. (This
option is network dependant.)
Page 33
01GB01COV-AE4.book Page 33 Friday, August 10, 2001 3:36 PM
Result Report
Select On if you would like to receive
confirmation that your messages are
transmitted to the recipient successfully.
Message Format
Specify how your message is transmitted:
SMS, E-Mail, Fax, Telex, Voice (if available).
The default setting is SMS.
Service Centre
Before you can send short messages, register
your Service Centre number via the Service
Centre option in the Messaging menu.
Signature
You can create your own signature of up to 32
characters, and choose whether or not to
attach it when you send SMS.
Local Area Info
} “ Messaging } Local Area Info
Receive Cell broadcast messages or general
messages like weather reports, traffic reports,
etc. broadcast to a group of phones in a certain
area. Some of these options may be network
dependant.
1 } “ Messaging } Local Area Info
2 Select one of the following options:
} Received to view cell broadcoast
messages.
} Select Channel to add or delete a
broadcast channel.
} Receive? to choose whether or not to
receive Cell broadcast messages.
}Tone to enable/disable a tone to indicate
that you have received a cell broadcast
message.
3 Press the Jog Dial to confirm your
selection.
33 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 34
01GB01COV-AE4.book Page 34 Friday, August 10, 2001 3:36 PM
34 GB
Sounds
Choose Sounds to access any sound-related
option in your CMD-Z7, for example ringer
melodies, ringer volume, enable/disable
sounds, and record your own ringer melodies
or other sounds.
Ringer
} ” Sounds } Ringer
Ringer Volume
Choose from four ringer volume levels or turn
the ringer off.
appears in standby mode to remind you when
the ringer is turned off.
Ringer Type
Select from among different ringer melodies.
Group Ringer
Assign a ringer sound to the different groups
saved in your Phonebook. It is not possible to
assign a ringer melody to a single name/
number.
My Ringers
It is possible to record own
ringer sounds using the
phone’s microphone.
Choose the respective
Icons to Record ( ),
Stop ( ), Play ( ),
Save ( ) or Delete ( )
a ringer melody.
Set Sound
} ” Sounds } Set Sound
Choose Set Sound to access the following
sound options:
Event Sounds
Assign a sound to be heard at the following
actions of your CMD-Z7: Receive SMS,
Alarm, Scheduler Alarm, Power Up and
Power Down.
It is possible to record sounds using the
phone’s microphone.
Page 35
01GB01COV-AE4.book Page 35 Friday, August 10, 2001 3:36 PM
Key Click
} Key Click to turn the key click sound on/off.
} DTMF to turn the DTMF tones on/off. DTMF
tones are designed to respond to menu
prompts when pressing a key.
} Silent to turn off the key click sound on/off.
Error Tone
Select Error Tone to assign a sound to the
error tone. Choose from a default error tone or
recorded sounds (only if you have sounds
stored under My Sounds).
My Sounds
Select My Sounds to record own sounds using
the phone's microphone. Choose the
respective icons to Record ( ), Stop ( ),
Play ( ), Save ( ) or Delete ( ) a sound.
Voice Memo
Select Voice memo to record and play the
voice memo.
Choose the respective Icons to Record ( ),
Stop ( ), Play ( ) or Delete ( ) a voice
memo.
• In standby mode, you can play back memos by
pressing .
• In standby mode, you can record a memo by
pressing and holding .
• You can record a conversation during a call by
pressing .
• You are responsible for the confidentiality of the
recording.
• You must ask the person you are on the phone
with for permission before recording.
35 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 36
01GB01COV-AE4.book Page 36 Friday, August 10, 2001 3:36 PM
36 GB
Settings
Preferences
} † Settings } Preferences
Choose Preferences to personalise your
phone according to your preferences, e.g.
which language, backlight on/off, etc.
When you receive your phone, it has the
following default settings:
Item Default Page
Language SIM dependent*37
Greeting Off 37
Wallpaper
**
37
Backlight On 37
LCD Contrast 0 37
Select Network Auto 37
Preferred List SIM dependent 37
Memory Info – 37
Factory Reset – 38
*
default language depends on language of the Network
Operator.
**
default wallpaper depends on Network Operator/
Service Provider.
Page 37
01GB01COV-AE4.book Page 37 Friday, August 10, 2001 3:36 PM
Language
} † Settings } Preferences } Language
Select the appropriate language.
• As a short cut, you can also select the language
by pressing *#00(country code)#.
• Select your default language by pressing
*#0000#.
Greeting
The Greeting menu allows you to turn on/off
or to edit the greeting message which appears
when you turn your phone on.
Wallpaper
Select pictures as a wallpaper to appear on the
display in standby mode.
Backlight
Choose Backlight to turn the illumination of
the keypad and display on/off. Switch the
Backlight off and your phone's battery charge
will last longer.
LCD Contrast
To adjust the contrast of your display.
Select Network
This feature gives you the option to select a
network automatically when you turn on your
phone, or manually from a list of available
networks.
Preferred List
Choose Preferred List to edit the automatic
network selection priority list. This feature is
helpful e.g. to prioritise roaming partners.
– Add Network to add a network operator
to the list.
– Move Network to adjust the order in
which the names appear in the list.
– Delete Network to remove a network
operator from the list.
Memory Info
To display how much memory is available for
SIM, Phone and the Note area.
37 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 38
01GB01COV-AE4.book Page 38 Friday, August 10, 2001 3:36 PM
38 GB
Factory Reset
To perform a master reset of all of your
phone's settings back to the factory settings
except Phonebook, Schedule and Network/
SIM card based settings. This will
automatically restart your phone.
Security
} † Settings } Security
The Security options allow you to control who
uses your phone as well as their calling
privileges. However, emergency calls (SOS)
are always possible regardless of the
restrictions/codes you set.
PIN Code
Select PIN code to enable/disable or change
the PIN code. When the PIN code is enabled,
your phone prompts you to enter the PIN code
each time you turn on the phone. You can
change your PIN code to any 4-8 digit
number. Your PIN code can only be changed
if the PIN control is switched on.
After entering the PIN code incorrectly three times,
your PIN is blocked. Enter the PUK (Personal
Unblocking Key) to unblock your PIN.
• After entering the PUK code incorrectly ten
times, your SIM card is completely blocked and
can only be unblocked by your Network
Operator/Service Provider.
• If the PIN code is disabled, the risk of
unauthorised use of your phone is greater. The
disabling of the PIN control is SIM card
dependant.
PIN2 Code
PIN2 is a code provided by your Network
Operator/Service Provider and is required for
access to some features such as FDN
Phonebook or Call Cost. These features are
not supported by all networks.
Page 39
01GB01COV-AE4.book Page 39 Friday, August 10, 2001 3:36 PM
Call Barring
Limit calls made from your phone which can
be useful e.g. if you lend your phone to
someone else but to not want them to make
international calls. The restrictions in the Call
Barring menu require the barring password.
All Outgoing
Restrict all outgoing calls except emergency
calls (112, etc.).
International
Restrict all international calls.
Int. Ex. Home
Restrict all outgoing international calls except
those to your home country.
All Incoming
Restrict all incoming calls.
If Abroad
Restrict all incoming calls when you are
outside of coverage from your registered
Network Operator (e.g. when abroad).
Cancel All
Cancel all settings of the call barring service.
Barring PWD
Some of the restrictions in the Security menu
are controlled in the network e.g. Call
Barring. Your Network Operator/Service
Provider provides a (Network) password if
you register for one or more of these network
call restrictions (Call Barring).
Changing the Barring Password
Select Barring PWD from the Security menu.
Use the keypad to enter the old password and
then enter your new password. Enter the new
password again and press the Jog Dial.
If the message Invalid appears, the old password you
entered was incorrect. If you have difficulties, contact your Network Operator/Service Provider.
Security Code
The Security Code allows you to set a
password to control access to your browser
and E-mail. The default Security Code is:
0000.
39 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 40
01GB01COV-AE4.book Page 40 Friday, August 10, 2001 3:36 PM
40 GB
Call Data
} † Settings } Call Data
Track or control how long you are on the
phone and the cost of calls made. So that Call
costs can be used as a security measure e.g.
when you lend your phone to someone, you
must use your PIN2 as a security code when
you set or change options.
Call Time
Check the length of your last call and total
calls (incoming and outgoing). Rotate the Jog
Dial to select which call time you want to
check.
Call Cost
Check the cost of your last call, total calls,
remaining credit and limit credit. Rotate the
Jog Dial to select the cost you want to check.
Reset Call Time
Use the Jog Dial to reset the Call time.
Call Cost Setting
Call Cost Setting offers a choice of three
options:
• Charge Rate
Select Charge Rate to set the currency and
price per unit which will be used to
calculate the call cost.
Enter your PIN2 code at the prompt. Enter
a currency and the price per unit (to enter a
decimal point, press ).
• Charge Limit
Select Charge Limit to set a unit figure at
which your phone will not allow any more
calls to be made. If Unit in the Charge Rate
menu (see above) was selected, enter the
Unit value. In case of Currency, enter the
Currency value.
Then enter your PIN2 code at the prompt,
then set the charge limit.
• Reset Call Cost
Select Reset Call Cost, enter your PIN2
code and then reset the call cost.
In order to be able to make phone calls again, reset
the Call Cost counter or enter a higher Charge Limit.
Page 41
01GB01COV-AE4.book Page 41 Friday, August 10, 2001 3:36 PM
Call Settings
} † Settings } Call Settings
Some of the following features may not be
supported by some networks.
Caller ID
Choose whether or not you want the party you
are calling to see your telephone number.
Select Caller ID from the Call Settings menu.
Use the Jog Dial to select On, Off or Default
(network default).
Call Waiting
If activated, your phone will alert you (beep)
that a call is waiting so that you don't miss
any calls. Select Call Waiting and use the Jog
Dial to select Activate, Cancel or Check
Status.
Select Line
Some Network Operators offer the possibility
to select between two separate phone lines on
your SIM card. This is useful e.g. for
separating business and private call costs.
To make a line selection in standby mode,
press and hold and use the Jog Dial to
make your selection. 1 or 2 will appear so that
you know which line is active. It is also
possible to make the line selection using the
Call Settings menu option.
Some menu items may not appear in your phone in
some networks unless you specifically subscribe for
them. The following settings (e.g. Divert, Security,
Ringer Tone, Call Waiting and Voicemail) will apply
to the currently selected line. Some items such as
your own number entry and voicemail entry may not
be edited. All calls made will be billed to the currently selected line. The Call Time and Call Cost
settings however, will always show the total time or
cost of both lines.
Any Key Answer
Answer a call by pressing any key on the
keypad.
Select Any Key Answer and use the Jog Dial
to select On or Off.
41 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 42
01GB01COV-AE4.book Page 42 Friday, August 10, 2001 3:36 PM
42 GB
1 Minute Beep
Turn the 1 Minute Beep On (Off) to be (not
be) reminded by a beep in 1 minute intervals
of the time you are on the phone.
Auto Redial
Automatic redial of an engaged line until it is
no longer busy. Select On/Off to activate/
deactivate this function. An incoming call
will interrupt the Auto Redial feature.
This function can be restricted by your Network
Operator/Service Provider.
Show Call Time
Select On/Off to display/not display the
elapsed time of your call.
Auto Answer
Automatic answer of an incoming call. Only
works together with the Handsfree car kit
accessory.
DTMF Tones
DTMF tones are emitted when pressing a key
during menu prompts (e.g. during Voicemail,
etc.). Select On/Off to activate/deactivate this
function.
Data Services
When connected to the optional Data
accessories (also see their user manuals) your
phone can send and receive data.
Selecting a Serial Speed
• Select Serial Speed and use the Jog Dial to
select Automatic, or one of the following
speeds: 115,2 Kbps, 57,6 Kbps, 38,4 Kbps,
19,2 Kbps, 9,6 Kbps.
• Select Automatic for automatic detection of
the serial speed. Enter an “AT” command,
whereafter the phone responds with OK.
Flip Call
Flip call allows you to answer incoming calls
by opening the flip cover and to end the call
by closing it.
Page 43
01GB01COV-AE4.book Page 43 Friday, August 10, 2001 3:36 PM
Divert
You may need to register for this service with
your Network Operator/Service Provider.
Setting a Divert
1 } ° Divert
2 Select a Divert option using the Jog Dial.
3 Select Activate to set the chosen divert
condition.
4 Select Voicemail to divert calls to your
Voicemail or choose a number from the
Phonebook. Choose Enter Number to
enter the number manually using the
keypad.
5 Wait for confirmation from the network.
• In step 3, you also have the option to cancel
or check status. Select Cancel to cancel the
divert; then wait for the network response.
• Select the option Check status to check the
divert settings. Wait for the network
response and then you can view the current
status on the display.
• If the returned response is Failed, the
network was unable to set, clear or check
the selected Divert.
• appears in standby mode if a Divert is
set.
• Sometimes a divert option is automatically
set in the network.
43 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 44
01GB01COV-AE4.book Page 44 Friday, August 10, 2001 3:36 PM
44 GB
The Divert menu offers the following options:
} All Calls
Divert all calls unconditionally (the phone
will not even ring).
} If Not Reachable
Divert incoming calls when your phone is
switched off or out of network coverage.
} If No Reply
Divert incoming calls if you do not answer the
call after a certain period of time.
} If Busy
Divert incoming calls when your are on the
phone (line engaged).
} All Fax
Divert all fax calls (the phone will not even
ring).
} All Data
Divert all data calls (the phone will not even
ring).
} Cancel All
Clear all active diverts.
Page 45
01GB01COV-AE4.book Page 45 Friday, August 10, 2001 3:36 PM
Call History
Provides a record and quick access of up to 10
of the last outgoing calls, up to 10 of the last
incoming calls and up to 10 missed calls.
(This feature is dependent on your Network
Operator/Service Provider.)
1 } ’ Call History
2 Use the Jog Dial to choose one of the
following options: Outgoing Calls,
Incoming Calls or Missed Calls, then
press the Jog Dial.
3 Make a call by pressing and holding the
Jog Dial on one highlighted name/
number.
In Step 2, select Delete All to delete all
names/numbers.
• Caller ID (Caller Line Identification) is required
to support Call History entries.
• When the Call History reaches its capacity, the
oldest number is deleted automatically to provide
space for the newest entry.
As a shortcut, you can also press in standby
mode to display the Call History.
Outgoing call
Incoming call
Missed call
45 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 46
01GB01COV-AE4.book Page 46 Friday, August 10, 2001 3:36 PM
46 GB
Extras
Choose the Extras menu to access the
following sub-menus: Clock, Calculator,
Games and E-Mail.
Clock
} ‡ Extras } Clock
World Clock
Rotate and press the Jog
Dial to select a city from
the map (or press the Jog
Dial backward to list
cities) for the following
options:
} Set ¥ to change the home city.
} Set ® to change the foreign city.
} Daylight Saving to switch between summer
time and winter time.
Alarm
It is possible to set, switch on/off or set the
Alarm to ring at the same time every day
(Repeat Daily). When the alarm is on,
appears in the display in standby mode. If the
phone is switched off, you will not hear the
alarm.
Timer
To start and stop the timer at a certain time.
When the timer is on, appears in the
display in standby mode.
The volume of the alarm/timer is determined by the
ringer volume setting. If the ringer volume is off, the
alarm/timer will ring at the minimum volume. The
alarm/timer will still ring even during a call.
Clock Format
Choose from the following clock formats: 24
Hours, AM/PM, With Date, World Clock.
Choose Off to have no date/time displayed in
standby mode.
Clock Chime
Choose from the following Clock Chime
options: Beep, 8h-20h, Off.
Page 47
01GB01COV-AE4.book Page 47 Friday, August 10, 2001 3:36 PM
Set Date/Time
Use the Jog Dial and keypad to enter the day,
month and year (DD/MM/YY) as well as the
time in hours and minutes (HH/MM).
If you insert a new battery, please reset the clock.
Calculator
} ‡ Extras } Calculator
The Calculator can perform addition (+),
subtraction (-), multiplication (×), division
(÷), and percentage (%) calculation.
• Press to go through the mathematical
operations of +, -, ×, ÷ in that order.
• Press to clear the entered value and
the result.
• Press to start a new calculation while
using the calculator.
1 } ‡ Extras } Calculator
2 Enter a number.
3 Press to select the mathematical
function and then enter another number.
4 Press to select “=” for a result.
In this example we are going to subtract 20%
from 120.
Currency Converter
You can also use the
calculator as a currency
converter.
1 Enter a number into
the calculator screen.
2 Press the Jog Dial
backward.
3 Select the desired currency exchange rate.
4 Press the Jog Dial.
47 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 48
01GB01COV-AE4.book Page 48 Friday, August 10, 2001 3:36 PM
48 GB
Currency Converter Settings
1 Press the Jog Dial backward when the
calculator screen is displayed.
2 Select Settings and press the Jog Dial.
Select from the following:
– Home Currency to set the home
currency.
– Foreign Currency to set the foreign
currency. After setting the foreign
currency, press the Jog Dial to set the
Exchange Rate.
– Currency List to edit the currency
name.
Press the Jog Dial to confirm the currency and the
display will automatically show the next setting.
Games
} ‡ Extras } Games
Select Games from the Extras menu (or press
the Jog Dial backward from standby mode to
access the Applications Menu). Press (or
press the Jog Dial forward) to end the game.
Black Jack
The aim of this game is to
score as close to 21 as
possible. The values of the
cards are:
10, J, Q & K = 10 points
Ace = 1 or 11
all others = face value.
Place your bet by rotating the Jog Dial or
simply enter the sum manually using the
keypad. Once you have confirmed your bet by
pressing the Jog Dial, two cards (one at a
time) are dealt.
By rotating and pressing the Jog Dial choose
HIT to receive more cards and STAY to stop
dealing. When your combined total reaches
10 or 11, you have the possibility to double
your bet (DOUBLE) and receive one more
Page 49
01GB01COV-AE4.book Page 49 Friday, August 10, 2001 3:36 PM
card. Should you receive a pair, you can split
these cards and play 2 games at the same time
(SPLIT) but you must bet the same amount on
both games.
The player who reaches the highest amount
wins the game. Press the Jog Dial to start a
new game. When you have used all of your
money the game is over. However, once your
funds drop to 500, you will receive 50 units
every day.
You must place a bet every time you start a new
game.
Table Soccer
The aim of this game is to
see how many goals you
can score within a time
limit. Your team players
are wearing white. Rotate
the Jog Dial to move your
player up and down the
field and press the Jog Dial to kick the ball.
You can turn your player around by pressing
the Jog Dial twice. The player to be played is
indicated by an arrow on the display.
E-mail
} ‡ Extras } E-mail
You can send and read E-mail by accessing to
your office E-mail server or your Internet
service provider on the Internet (POP3 and
SMTP are supported). You will need the
specific parameters from your internet service
provider in order to complete the setup.
Contact your service provider or operator
directly for complete details for setting
information, as some service provider or
operators do not provide this service. Be sure
to make your settings before you start using
E-mail.
• A Security Code may be necessary when using
your browser or sending E-mail. Use the code
that is set as your Security Code. For details see
Security Code, page 39.
• The maximum size of E-mail that can be sent or
received is 2 Kbytes, including the header.
49 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 50
01GB01COV-AE4.book Page 50 Friday, August 10, 2001 3:36 PM
50 GB
Reading E-mail
After selecting E-mail from the Extras menu
select Read to connect to your server and
display a list of incoming mail. Rotate the Jog
Dial to highlight the E-mail that you want to
read, select it with the Jog Dial to read it.
Also, when you press the Jog Dial you can:
Next: Read the next E-mail.
Prev: Read the previous E-mail.
Reply: Reply the E-mail by pressing the Jog
Dial after selecting the sender.
• You must be logged off of your E-mail account
on your PC in order to access your E-mail using
the phone.
• For optimum E-mail management, the phone will
only display E-mail which is unread and not
already downloaded by your PC. However, you
are still able to use your PC to access mail read
using your phone. You can only delete mail using
your PC.
Sending E-mail
After selecting E-mail from the Extras menu,
select Send and you can compose an E-mail.
To: Enter the address of the person you
want to send the E-mail.
Subject: Enter the subject of your E-mail.
Body: Compose the text of your E-mail.
Press the Jog Dial and select Send to
send the E-mail after entering the
text.
• If you would like to access E-mail sent from your
phone at a later date, copy your own E-mail
account when writing an E-mail.
• Press the Jog Dial backward when writing an
E-mail for additional menu options.
Page 51
01GB01COV-AE4.book Page 51 Friday, August 10, 2001 3:36 PM
Settings
To send and receive E-mail you need to set
the following.
Enter your E-mail address correctly as
indicated by your mail-server manager or
your provider.
Provider
Dial-Up Number: The phone number to dial-
up your provider.
User Name: The user name to access
your provider.
Password: The password to access
your provider.
POP3 Server: The address of the mail
server for receiving E-mail.
SMTP Server: The address of the mail
server for sending E-mail.
Data Call Type: You can select the relay,
when you connect to your
provider. Analogue is
already set.
E-mail
User Name:The user name to access your
mail server.
Password: The password to access your mail
server.
E-mail
Address: Your E-mail address.
Details
POP3 Port: The number of the port for the
mail server for the POP3 port. It
is not necessary to change from
the regular 110.
SMTP Port: The number of the port for the
mail server for the SMTP port. It
is not necessary to change from
the regular 25.
Timeout: Set the amount of time allowed to
connect to your mail server.
DNS Server:The settings for DNS (Domain
Name Server) server.
51 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 52
01GB01COV-AE4.book Page 52 Friday, August 10, 2001 3:36 PM
52 GB
Scheduler
} ™ Scheduler
Display the calendar, save
your daily schedule and
set alarms for important
tasks. The monthly
calendar appears as
follows:
: An event is scheduled for that day.
Enter a new event or a new to
do item
1 Select Scheduler from the Main Menu
and use the Jog Dial to select a day.
(To change the month, press the Jog Dial
backward.)
2 Use the Jog Dial to select New and then
enter a New Event or a New To Do item.
The following options are available if you
select an event.
Edit Icon
Select from a range of icons to be added to the
event entry.
Edit Time
Edit the Time of the event.
Alarm
Select from the following options: switch the
Alarm On/Off, or set it 5 min./1 day before the
event time. If the phone is switched off, you
will not hear the alarm.
Edit Text
Use the Jog Dial and the keypad to edit the
event text.
Delete
Delete the event entry.
View
View details of the event.
Page 53
01GB01COV-AE4.book Page 53 Friday, August 10, 2001 3:36 PM
Daily To Do List
The following options are available if you
select one of the ToDo Items.
Complete
Select Complete if you have completed the
ToDo item. The ToDo entry is ticked. It is
still possible to View, undo complete
(= Incomplete) and to edit this entry.
Edit Text
Edit the ToDo entry.
Delete
Delete the ToDo entry.
View
View details of the ToDo entry. Select OK if
the entry is correct.
When the Calendar is displayed, press the Jog Dial
backward to display the following options:
} „ Month
To display the specified monthly calendar.
} Today
To return the cursor to the Today window.
} Go To ...
To go to the desired date.
} List All
T o list all your entries.
} Delete
You have the choice of the following options:
• Past will permanently delete all past To Do
entries (but keep the current entry/entries).
• All will permanently delete all To Do entries from
the past and of today.
53 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 54
01GB01COV-AE4.book Page 54 Friday, August 10, 2001 3:36 PM
54 GB
WAP Browser
With WAP (Wireless Application Protocol) it
is possible to access a variety of information
such as news or weather reports from around
the world including mobile internet sites.
With this phone you can access various
HTML or WML internet sites.
Choose WAP from the Main Menu using the
Jog Dial or simply press the Jog Dial
backward from standby mode to access the
Applications Menu.
It is necessary to register with a Network
Operator/Service Provider to use this
telephone as a browser. In some cases
registration has already been completed.
Check with your Network Operator/Service
Provider in advance to confirm whether your
subscription allows access to WAP services
and whether it is possible to access WAP
when roaming.
• As a safety measure, a Security Code may be
necessary to use your browser. Use the code that
is set as your Security Code (see page 39).
• Internet access is limited to the sites providing
HTML or WML content. WAP (the Wireless
Application Protocol created for Internet service
via mobile phone) is used to access a WML site.
• You cannot make phone calls while accessing the
mobile Internet.
Getting Started
In order to use WAP, you will need to make
some settings using parameters specified by
your Network Operator/Service Provider. For
your reference, sample parameters are
provided and underlined however you will
need the specific parameters from your
Network Operator/Service Provider in
order to complete the setup. You may be
able to obtain the parameters from the web
page of your Network Operator/Service
Provider.
Page 55
01GB01COV-AE4.book Page 55 Friday, August 10, 2001 3:36 PM
The browser can be configured to access
WAP or HTML sites. The procedure to set up
the configuration depends on the server type.
See an example for WAP below.
1 Select WAP from the Main Menu (or
press the Jog Dial backward from standby
mode to access the Applications Menu).
Then select Settings.
2 Select the first field labeled Empty and
then select Edit.
3 Enter the Security Code (default 0000) at
the prompt (see also page 39).
4 Select Name to enter a name that will be
displayed for your site.
Name: My Provider
5 Select Home Page to enter the URL of the
home page specified by your Network
Operator/Service Provider.
Home Page: wap.myprovider.com
6 Select Server Type to select WAP or
HTML depending on which type of server
your provider has.
Server Type: WAP
7 Select Bearer Service to specify the
bearer type (Data or SMS) your Network
Operator/Service Provider requires.
Bearer Service: Data
8 Select Provider to set the following
parameters specified by your Network
Operator/Service Provider:
Dial Up Number: +12 345 67 890
(number to access the gateway)
ISP User Name: abc
ISP Password: sony
Data Call Type: Automatic
9 Select the arrow to return to the Edit
menu.
10 Select GW Server to enter the address of
the gateway server of your Network
Operator/Service Provider.
GW Server: 10.255.255.255
11 Select Security to choose On for a secure
connection to your gateway (GW port
9203) or Off for a non-secure connection
(GW port 9201) depending on your
Network Operator/Service Provider.
55 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 56
01GB01COV-AE4.book Page 56 Friday, August 10, 2001 3:36 PM
56 GB
12 Select Details and then Timeout to enter
the default timeout value in seconds
specified by your Network Operator/
Service Provider (if your Network
Operator/Service Provider does not
specify a value, 120 seconds should be
sufficient for most Network Operators/
Service Providers).
Timeout: 120
13 Select the arrow to return to the previous
menu. Select Set Home to set this entry as
your home or default address. You are
now ready to begin using WAP! Simply
select Home from the WAP menu to
access your home site.
To set up HTML, you will need to set the Server
Type to HTML as well as the Proxy and Details
settings. However, with HTML the GW Server and
Security settings are not necessary. Contact your
Network Operator/Service Provider for details.
The Browser Menu
Choose WAP from the Main Menu using the
Jog Dial or simply press the Jog Dial
backward from standby mode to access the
Applications Menu. From the WAP menu,
rotate the Jog Dial and then press to select an
item from the menu.
Home
} ® WAP } ¥ Home
Select Home to access the homepage you
have entered in Settings.
Favourites
} ® WAP } © Favourites
Select Favourites to access, edit or delete a
URL from your Favourites list. Rotate the Jog
Dial to select a URL, then press the Jog Dial
to display the following options:
Go: Connect to the selected URL.
Move: Change the order of your Favourites.
Edit: Edit the name and URL of Favourites.
Delete: Delete a URL from your Favourites.
Page 57
01GB01COV-AE4.book Page 57 Friday, August 10, 2001 3:36 PM
You can also access your Favourites while browsing
(see also “While Browsing”). However, you will
need to enter “wsp://” and then the URL to any WAP
sites you would like to access during a WAP session.
Similarly you will need to enter “http://” and then
the URL to any HTML sites you would like to
access while browsing.
Settings
} ® WAP } † Settings
Configure the settings to access WAP
services. Be sure to make these settings
before using WAP.
The icon indicates the site that you have
set as your home site. To change your home
site, select Set Home from the menu after you
choose a site with the Jog Dial. See also
“Getting Started” (see page 54) for details
about the required Settings. Choose Delete to
delete a site profile.
While Browsing
Press (or press the Jog Dial backward)
while browsing, for the following options:
Home: Access your home site.
Refresh: Refresh the displayed page.
Add to
Favourites: Save the current URL.
Favourites: Access a URL from Favourites.
Manual URL:Access a URL by entering it
manually.
Quit: Close your browser and return
to standby mode.
Navigation
When browsing a WAP site, press the Jog
Dial backward to scroll through the option of
a selection field (form field). Press the Jog
Dial to select one or more items. Press
(or press the Jog Dial forward) to exit back to
the previous page when browsing.
Closing the Browser
Press to disconnect (only when the bearer
service is set to Data) and close the browser.
57 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 58
01GB01COV-AE4.book Page 58 Friday, August 10, 2001 3:36 PM
58 GB
Applications Menu
Operations
Your phone has the Applications menu
consisting of WAP, E-Mail and Games.
It is necessary to register with a Network
Operator/Service Provider to use this
telephone as a browser or for E-mail. In some
cases registration has already been completed.
Check with your Service Provider in advance
to confirm whether or not this phone has
access to these services.
When access to network-specific functions
(SIM Application Toolkit) is available, the
menu is displayed in Applications. (This
feature is dependent on your Network
Operator and may not be supported by some
networks.)
Selecting a menu item in
Applications menu
1 Press the Jog Dial
backward in standby
mode.
The Applications
menu appears.
2 Rotate the Jog Dial to
select the desired
menu.
3 Press the Jog Dial to enter the menu
choice.
Page 59
01GB01COV-AE4.book Page 59 Friday, August 10, 2001 3:36 PM
Appendix
Troubleshooting
Problem Possible Causes Possible Remedies
Unable to switch
on
The icon
appears
Call not possible Dialling error Use full national area code. When abroad, use
Empty battery Charge the battery (see page 13).
Defective battery Replace the battery. Note that after several
years, gradual decline is normal.
Weak signal Move to an open space or nearer to a window.
Outside GSM coverage area Check operator coverage map.
SIM not valid Call your service provider.
Network access not allowed Try manual network search (see page 37).
also international access code to reach home
country.
All calls barred Check settings (Password is needed to clear).
Another SIM inserted Check for new restrictions.
Call barring set Check outgoing call barring settings (see page
39).
59 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 60
01GB01COV-AE4.book Page 60 Friday, August 10, 2001 3:36 PM
Problem Possible Causes Possible Remedies
Difficult to hear
––– Adjust earpiece volume, and reduce noise
the other party
Phones loses
Weak signal Reconnection, or connection to another
network
SIM error Damaged SIM card Please contact your service provider.
SIM card not
registered
Not able to
Network does not recognize
the SIM card
Call barring set Check incoming call barring settings (see page
receive calls
Divert set Check call divert settings (see page 43).
Battery Charging
Battery overdischarged Charge the battery a full charging cycle (up to
indicator does not
appear
60 GB
around you (see page 20).
operator is automatic. Switching phone off and
on may accelerate this.
Please contact your service provider.
39).
approx. 3 hours) for the indicator to appear.
Page 61
01GB01COV-AE4.book Page 61 Friday, August 10, 2001 3:36 PM
Unblocking the SIM Card
If you enter the PIN code incorrectly 3 times,
the SIM card is blocked.
1 Enter the PUK and press the Jog Dial (or
press ).
2 Enter the new PIN (4-8 digits) and press
the Jog Dial (or press ).
3 Enter the new Pin code again and press
the Jog Dial (or press ).
The SIM is unblocked.
• If you enter the wrong unblock code (PUK) 10
times, your SIM is blocked completely. In this
case contact your Network Operator/Service
Provider.
• In order to receive more information (SIM and
PUK), please contact your Network Operator/
Service Provider.
Technical Specifications
E-GSM 900 Mobile
Telephone
GSM 1800 Mobile
Telephone
Frequency Range
(Transmission)
Frequency Range
(Reception)
Handset Operating
Temperature
Accessories Operating
Temperature
Class 4 (2 Watts)
Class 1 (1 Watt)
880-915 MHz and
1710-1785 MHz
925-960 MHz and
1805-1880 MHz
-10 °C – +55 °C
±0 °C – +45 °C
61 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 62
01GB01COV-AE4.book Page 62 Friday, August 10, 2001 3:36 PM
62 GB
Licensing
Your CMD-Z7 is authorized for use in GSM
900 / 1800 networks and complies with EU
standards.
• This equipment complies with
the essential requirements of
the Directive 1999/5/EC
Radio and
0168
Telecommunications T erminal
Equipment Directive.
• 95/54/EC “Car Automotive
Directive”
Applies to accessories used in
vehicles confirmed by the
e-mark.
Sony Ericsson Mobile Communications AB
reserves the right to make changes or
improvements to any of the products
described in this guide without prior notice.
T9™ text input is a registered trademark of
Tegic Communications Inc. and the T9™ text
input software is provided under license of
Tegic Communications Inc.
Part of the software included in this product is
© Copyright STNC Ltd. 1994 - 1999 All
rights reserved.
Part of the software included in this product is
© Copyright Microsoft Corporation 2000 2001 All rights reserved.
Page 63
01GB01COV-AE4.book Page 63 Friday, August 10, 2001 3:36 PM
Index
A
Any Key Answer 41
Auto Answer 42
Auto Redial 42
B
Backlight 37
Battery Pack
Charging 13
Inserting 12
C
Calculator 47
Currency Converter 47
Call Cost 40
Call History 45
Call Hold 20
Call Time 40
Call Waiting 21, 41
Caller ID 41
Ciphering 19
Clock
Alarm 46
Set 47
Timer 46
World Clock 46
Connection 15
D
Data Services 42
Divert 43
DTMF 21
E
E-mail 49
Emergency Calls 38, 39
Error Tone 35
Event Sounds 34
F
Factory Reset 38
Flip Call 19
G
Games 11, 48
Greeting Message 37
H
Headset 19, 21
J
Jog Dial 8
K
Key Click 35
L
Language 37
LCD Contrast 37
Local Area Info 33
Loudspeaker 21
M
Memory Info 37
Microphone On/Off 21
N
Network 15
Network Specific Service 58
63 GB
CMD-Z7
Your Sony
Getting
Started
Basic
Operation
Menu
Operation
Appendix
Page 64
01GB01COV-AE4.book Page 64 Friday, August 10, 2001 3:36 PM
64 GB
O
One Minute Beep 42
P
Phonebook
Creating Entries 25
FDN Phonebook 26
Grouping 25
Making Calls 24
Note 28
Own Number 25
Saving Entries 24
Search 27
Service Dialling
Numbers 26
PIN 14, 38
PIN2 38
Preferences 36
Preferred List 37
R
Ringer Type 34
Ringer Volume 34
Adjusting 20
Roaming 15
S
Scheduler 52
Event 52
To Do 53
Security Code 39
Select Line 41
Select Network 37
Selection 15
Signal Strength 15
Silent Mode 9
SIM Application Toolkit 58
SIM Card
Inserting 12
Removing 13
Single Beep 9
SMS (Messaging)
Create 31
Delete 30
Edit 31
Forward 31
Memory class 32
Message Format 33
Read 30
Reply 31
Reply Cost 32
Result Report 33
Service Centre 33
Validity period 32
Speaker Volume
Adjusting 20
Speed Dialing 18
T
T9 Text Entry 23
V
Vibra Alert 9
Voice Dialing 17
Voice Memo 35
Voicemail 8, 27
W
Wallpaper 37
WAP Browser 54
Page 65
01GB01COV-AE4.book Page 65 Friday, August 10, 2001 3:36 PM
Page 66
01GB01COV-AE4.book Page 66 Friday, August 10, 2001 3:36 PM
Page 67
01GB01COV-AE4.book Page 67 Friday, August 10, 2001 3:36 PM
Page 68
01GB01COV-AE4.book Page 68 Friday, August 10, 2001 3:36 PM
Made from chlorine-free, recycled paper
Sony Ericsson Mobile Communications AB
www.sony-europe.com/Z7
Loading...
