Sony D6633, Xperia Z3 Part List

Part List

- mechanical -

Xperia Z3

D6633,L55t, L55u

1291-7735 Rev 1

© Sony Mobile Communications AB – Company Internal

Part List Mechanical/

CONTENTS

1 Part List ........................................................................................... 3

2 Revision History ........................................................................... 11

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

2(11)

Part List Mechanical/

Designation

Part No.

RLC Part

Location

1 Part List

The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts

mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred to
by a simple descriptive name for better understanding.

Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g. Battery Cover.

RLC, Reversed Logistic Classification column for replaced part handling, See the Spare Part Handling
chapter in Mechanical/Generic Repair Manual 1220-1333.

Adhesive Battery Front 1282-1899

Adhesive Charge FPC 1282-3276

C

C

Charge FPC 1280-6834

Sheet Sub PBA 1290-0790

Adhesive Rear Panel

1288-3738

Adhesive Relay FPC B 1286-1191

C

C

C

C

Adhesive Relay FPC A 1282-3271

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

C

3(11)

Designation

Part No.

RLC Part

Location

Adhesive WP Audio Jack

Antenna BT + WLAN 1285-3560

Audio Jack 1285-7766

Cap SIM
Cap SIM Black
Cap SIM Copper
Cap SIM White

1282-1919

1285-2985
1285-8077
1290-4819

Part List Mechanical/

C

C

C

C

Cap USB
Cap USB Black
Cap USB Copper
Cap USB White

Cover Holder -A

Cushion 10pin BB speaker 1286-1246

Cushion Audio Jack FPC BtB 1286-7043

1285-3014
1285-8082
1290-4817

1285-3559

C

C

C

C

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

4(11)

Designation

Part No.

RLC Part

Location

Cushion Battery 1282-1898

Cushion Battery FPC BtB 1282-4139

Cushion Camera BtB 1282-1901

Cushion Chat Camera 1282-1927

Part List Mechanical/

C

C

C

C

Cushion Rear Panel 1289-4962

Cushion Relay FPC bottom BtB 1286-7044

Cushion Relay FPC BtB 1282-4137

Embedded Battery 1281-2461

C

C

C

B

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

5(11)

Designation

Part No.

RLC Part

Location

Film Display BtB 1286-6445

Film for TP FPC 1286-1276

Front Assy
Front Assy Black
Front Assy Copper
Front Assy White

Gasket conductive USB 1286-7041

1288-5869
1288-5871
1288-5870

C

C

A

C

Part List Mechanical/

Gasket speaker rubber 1285-3561

Gore Sheet(1st mic) 1282-1787

Grill Receiver Black 1282-1929

Holder key volume

1285-7769

C

C

C

C

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

6(11)

Designation

Part No.

RLC Part

Location

Holder Mic sub assembly

Holder Receiver sub assembly 1282-1875

1282-1878

Part List Mechanical/

C

C

Holder Speaker sub assembly

Label tray
Label tray D6633
Label tray L55u

Core Unit Label
Core Unit Label D6633 L55u

Label Guide
Label Guide D6633 L55u

1285-3542

1285-7652
1290-3312

1285-8695

1285-7661

C

C

C

C

Label tray
Label tray L55t

Core Unit Label
Core Unit Label L55t

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

1290-3313

1290-5654

C

C

7(11)

Designation

Part No.

RLC Part

Location

Part List Mechanical/

Label Guide
Label Guide L55t

Liquid indicator 1275-3307

Loudspeaker B

Magnetic connector
Magnetic connector Black
Magnetic connector White

Main Antenna

1290-3315

1286-7114

1281-9617
1281-9655

1285-3552

C

C

C

C

C

Main Camera 1280-7695

Plate holder speaker

Rear Panel
Rear Panel Black,L55t
Rear Panel Black,L55u,D6633
Rear Panel Copper,L55t
Rear Panel Copper,L55u,D6633
Rear Panel White,L55t
Rear Panel White,L55u,D6633

1285-3551

1288-8875
1288-8892
1288-8881
1288-8898
1288-8880
1288-8896

B

C

B

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

8(11)

Designation

Part No.

RLC Part

Location

Relay FPC
Relay FPC PBA

1285-7754

Part List Mechanical/

B

RF cable 1281-9925

Screw M14×3.3 1285-7670

Sheet ACO L 1286-1249

Sheet ACO R 1286-1254

C

C

C

C

Sheet Chat Camera 1288-0301

Sheet Sub ANT 1290-3567

Shield Main Camera 1285-3562

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

C

C

C

9(11)

Designation

Part No.

RLC Part

Location

SIM Tray(L55u, D6633) 1285-0492

SIM Tray(L55t only) 1285-0492

Dummy SIM assy (L55t only) 1288-7849

Sub Antenna 1281-7580

Part List Mechanical/

C

C

C

C

Sub Camera 1280-7656

Sub PBA-A 1286-8355

Sub PBA-B 1285-7780

Cushion MIC 1290-5371

C

C

C

C

1291-7735 Rev 1
© Sony Mobile Communications AB – Company Internal

10(11)

Rev.

Date

Changes / Comments

2 Revision History

1 2014-09-12 Initial release
