- mechanical
-
TM
Part List
1286-9336 Rev 3
Sony Mobile Communications AB – Company Internal
Xperia
Z2
L50t, L50u
Company Internal
Part List (mech)
CONTENTS
1 Part List ........................................................................................... 3
1.1 L50t/L50u Common Parts .................................................................... 4
1.2 L50t Specific Parts ............................................................................. 10
1.3 L50u Specific Parts ............................................................................ 11
2 Revision History ........................................................................... 12
1286-9336 Rev 3
Sony Mobile Communications AB –
2(12)
Company Internal
Part List (mech)
1 Part List
The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts
mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred to
by a simple descriptive name for better understanding.
Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g. Battery Cover.
RLC, Reversed Logistic Classification column for replaced part handling, See the Spare part handling
chapter in Mechanical/Generic Repair Manual (1220-1333).
1286-9336 Rev 3
Sony Mobile Communications AB –
3(12)
Company Internal
Part No.
Part List (mech)
1.1 L50t/L50u Common Parts
The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts
mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred to
by a simple descriptive name for better understanding.
Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g. Battery Cover.
The following location pictures are used with L50t.
Designation
Adhesive Audio Jack 1284-2449 C
RLC
Part Location
Adhesive Back Panel Assy 1278-7465 C
Adhesive Battery Bottom 1278-8592 C
Adhesive Battery Top 1280-1891 C
Adhesive Top Speaker 1280-7307 C
Adhesive Vibrator 1278-8319 C
1286-9336 Rev 3
Sony Mobile Communications AB –
4(12)
Company Internal
Part No.
Designation
Ant WLAN/BT Holder Assy 1278-7451 C
Antenna Speaker Box Assy 1278-4878 C
Battery 1277-3687 B
RLC
Part List (mech)
Part Location
Camera 1271-4830 B
Camera Chat 1277-4382 C
Cap SD
Cap SD Black
Cap SD Silver
Cap SIM
Cap SIM Black
Cap SIM Silver
1280-7030
1278-6813
1280-7034
1278-6814
C
C
Cap USB
Cap USB Black
Cap USB Silver
1286-9336 Rev 3
Sony Mobile Communications AB –
1280-7028
1278-6812
C
5(12)
Company Internal
Part No.
Designation
Carrier Holder Main Mic 1278-5669 C
Charge FPC Assy 1278-3380 C
Conductive Adhesive PBA Sub 1280-7556 C
RLC
Part List (mech)
Part Location
Core Unit Label 1277-4850 C
Display Frame Assy
Display Frame Assy Black
Display Frame Assy White
Gasket Battery BtB Connector 1289-2588 C
Holder 2nd Mic 1278-5045 C
1281-3185
1281-3187
A
Holder Camera Chat 1277-4733 C
1286-9336 Rev 3
Sony Mobile Communications AB –
6(12)
Company Internal
Part No.
Designation
Liquid indicator 1275-3307 C
RLC
Part List (mech)
Part Location
Magnetic Connector
Magnetic Connector Black
Magnetic Connector White
Panel Bottom
Panel Bottom Black
Panel Bottom White
PBA Sub 1277-7618 C
Relay FPC Assy 1278-3131 B
1276-5805
1277-2489
1278-4891
1280-3528
C
C
RF Cable 1278-4883 C
RF LCP FPC Assy 1278-4932 C
1286-9336 Rev 3
Sony Mobile Communications AB –
7(12)
Company Internal
Part No.
Designation
Screw Other Len:3.0 Diam:1.4 1248-2360 C
Sheet Battery Adhesive Top 1284-2559 C
Sheet FPC Battery 1277-4834 C
RLC
Part List (mech)
Part Location
Sheet_Thermal_Conductive_C 1279-4655 C
SIM Tray 1282-1828 C
Top FPC Assy 1278-3345 C
Top Speaker 1277-7135 C
Tray Core Unit Label 1278-7293 C
1286-9336 Rev 3
Sony Mobile Communications AB –
8(12)
Company Internal
Part No.
Designation
Vibrator 1264-2341 C
RLC
Part List (mech)
Part Location
1286-9336 Rev 3
Sony Mobile Communications AB –
9(12)
Company Internal
Designation
Part No.
Part
Location
Part List (mech)
1.2 L50t Specific Parts
The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts
mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred to
by a simple descriptive name for better understanding.
Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g. Battery Cover.
RLC
Back Panel Assy
Back Panel Assy Black_CMCC
Back Panel Assy White_CMCC
1281-3190
1281-3189
B
1286-9336 Rev 3
Sony Mobile Communications AB –
10(12)
Company Internal
Designation
Part No.
Part
Location
Part List (mech)
1.3 L50u Specific Parts
The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts
mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred to
by a simple descriptive name for better understanding.
Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g. Battery Cover.
RLC
Back Panel Assy
Back Panel Assy Black_CU
Back Panel Assy White_CU
1285-0284
1285-0285
B
1286-9336 Rev 3
Sony Mobile Communications AB –
11(12)
Company Internal
Rev.
Date
Changes / Comments
2 Revision History
1 2014-Apr-01 Initial release
2 2014-Apr-25 Added L50u
3 2014-Jul-17 Added Gasket Battery BtB Connector
Part List (mech)
1286-9336 Rev 3
Sony Mobile Communications AB –
12(12)
