This is the Xperia™ R1 Plus User Guide for the Android™ 7.1.2 software version. If
you're not sure which software version your device is running, you can check it in the
Settings menu.
System and application updates can present the features in your device in another
way than described in this User Guide. The Android™ version might not be affected in
an update. For more information about software updates, see Updating Your Device
on the 32 page.
To Check the Current Software Version of Your Device
1 From your Home screen, tap .
2 Find and tap Settings > About phone > Android™ v ers ion.
Limitations to Services and Features
Some of the services and features described in this User Guide may not be supported
in all countries or regions, or by all networks or service providers. The GSM
International Emergency Number can always be used in all countries, regions,
networks and by all service providers, provided that the device is connected to the
cellphone network.
Please contact your network operator or service provider to determine the availability
of any specific service or feature and whether additional access or usage fees apply.
The use of certain features and applications described in this guide may require
access to the internet. You may incur data connection charges when you connect to
the internet with your device. Contact your wireless service provider for more
information.
1 Headset jack
2 Front camera
3 Receiver
4 Microphone
5 Light sensor
6 Charging/Notification light
7 Volume buttons
9 Microphone
10 Charger/USB Type-C cable port
11 Speaker
12 Rear camera
13 Flashlight
14 Nano SIM/Memory card slot
8 Power button
Assembly
Your device only supports nano SIM cards. The nano SIM card and the memory
card have separate slots in the same holder. Make sure you don’t confuse the two.
To prevent data loss, be sure to turn off your device or unmount the memory card
before you drag out the holder to remove the nano SIM card or memory card from
the device.
To insert the Nano-SIM card and the microSD card
Do not cut your SIM card, for example, using a blade or scissors, as this may
damage your device.
1 Using your fingernail, drag out the nano SIM card tray.
2 Firmly place the Nano-SIM cards and the microSD card in the correct orientation as
shown in the illustration.
3 Gently push the tray back into the slot until it fits into place.
Press and hold down the power key until the device vibrates.
2
Enter your PIN for SIM card 1 and SIM card 2 when requested, then tap .
3
Wait a while for the device to start.
Screen Protection
Before using your device, remove the protective film by pulling up on the protruding
tab.
Starting Your Device for the First Time
It is recommended that you charge the battery for at least 30 minutes before starting
up your device for the first time. You can still use your device whi le it is charging,
see Charging Your Device on page 30.
The first time you start your device, a setup guide helps you to configure basic
settings, personalize your device, and sign in to your accounts, for example a
Google™ account.
To Turn On the Device
It is important to use the USB Type-C™ cable (provided) when charging your device
as other types of USB cable can damage your device. It is recommended to charge
the battery for at least 30 minutes before you turn on the device for the first time.
Your SIM card PIN is initially supplied by your service provider, but you can change
it later from the Settings menu. To correct a mistake made while entering your SIM
card PIN, tap .
To Turn off the Device
1 Press and hold down the power key until the options menu opens.
2 In the options menu, tap Power off.
It may take a while for the device to shut down.
8
Why Do I Need a Go ogle ™ Acount?
Your Xperia™ device from Sony runs on the Android™ platform developed by Google™. A
range of Google™ applications and services is available on your device when you purchase
it, for example, Gmail™, Google Maps™, YouTube™, and the Play Store™ application which
gives you access to the Google Play™ online store for downloading Android™ applications.
To get the most out of these services, you need a Google™ account. For example, a
Google™ account enables you to do all of the following:
• Download and install applications from Google Play™.
• Synchronize your email, contacts, and calendar using Gmail™.
• Chat with friends using the Duo™ application.
• Synchronize your browsing history and bookmarks using the Google Chrome™
web browser.
For more information about Android™ and Google™, go to http://support.google.com.
It is crucial that you remember your Google™ account username and password. In some
situations, you may need to identify yourself for security reasons using your Google™
account. If you fail to give your Google™ username and password in such situations,
your device is locked. Also, if you have more than one Google™ account, be sure to
enter the details for the relevant account.
To Set Up a Google™ Account on your Device
1 From your Home screen, tap .
2 Find and tap Settings > Accounts > Add account > Goo gle.
3 Follow the registration wizard to create a Google™ account, or sign in if you.
4 already have an account.
You can also sign in to or create a Google™ account from the setup guide the first
time you start your device. Alternatively, you can go online and create an account at
www.google.com/accounts.
To Remove a Google™ Account
5 From your Home screen, tap .
6 Tap Settings > Accounts > Google.
7 Select the Google™ account you want to remove.
8 Tap : > Remove account.
9 Tap Remove account again to confirm.
If you remove your Google™ account, any security features that are linked to your
Google™ account will no longer be avail abl e.
Your device includes several security options, strongly recommended in case of loss or
theft.
These options are as follows:
• Set a secure screen lock on your device using a PIN, password, or pattern to prevent
anyone from accessing or resetting your device.
• Add a Google™ account to prevent others from using your device if it gets stolen or
wiped.
Verifying the Ownership of Your Device
Certain protection featur es requir e you to either unlock your screen with your PIN,
password, or pattern, or enter your Google™ account information. Below are
examples of protection features and some of the required credentials:
Factory
Data
Reset
protection
Android™
Device
Manager
You must unlock your screen before you are allowed to perform a Factory
Data Reset.
If you remotely reset your device using this service, you must enter
the username and password for a Google™ account. The device
must be connected to the internet before the setup process can be
completed. Otherwise, you will not be able to use your device after
the reset.
For Android™ Device Manager, it is necessary to enter information from a Google™
account. This can be any Google™ account which you have set up on the device as
an owner. If you cannot provide the relevant account information during a setup
to
process, you won't be able
Screen
Lock
use the device at all.
There are several screen lock options available. The security level of each lock type
is listed below in order of weakest to strongest:
• Swipe– no protection, but you have quick access to the Homescreen.
• Pattern– draw a simple pattern with your finger to unlock your device.
• PIN– enter a numeric PIN of at least four digits to unlock your device.
• Password– enter an alpha-numeric password to unlock your device.
It is very important that you remember your screen unlock pattern, PIN, or password. If
you forget this information, it may not be possible to restore important data, such as
contacts and messages. If you have set up a Microsoft® Exchange ActiveS ync® (EAS)
account on your Xperia™ device, the EAS security settings may limit the lockscreen
type to only a PIN or password. This occurs when your network administrator
specifies a lockscreen type for all EAS accounts for enterprise security reasons.
Contact the network administrator of your company or organization to check what
network security policies are implemented for cellular devices.
For more settings for each screen lock type, tap
beside Screen lock.
To Change Your Screen Lock Type
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock.
3 Choose an option and follow the instructions on your device.
To Create a Screen Lock Pattern
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock > Pattern.
3 Choose an option and follow the instructions on your device.
If you enter an incorrect lock pattern five times in a row, you must wait 30
seconds before trying again.
To Change the Screen Lock Pattern
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock.
3 Draw your screen unlock pattern.
4 Tap Pattern, choose an option, and follow the instructions on your device.
To Create a Screen Lock PIN
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock > PIN.
3 Choose an option. Enter a numeric PIN, and then tap CONTINUE.
4 Re-enter and confirm your PIN, then tap OK.
To Create a Screen Lock Password
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock > Password.
3 Choose an option and follow the instructions on your device.
To Activate the Swipe Unlock Function
1 From your Home screen, tap .
2 Find and tap Settings > Security > Screen lock.
3 Draw your screen unlock pattern, or enter your PIN or pass wor d depe ndi ng on
The Smart Lock feature makes unlocking your device easier by letting you
set it to unlock automatically in certain situations. You can keep your device
unlocked, for example, when it’s connected to a Bluetooth® device or when
you’re carrying it with you.
You can set Smart Lock to keep your device unlocked using the following settings:
• On-body detection: Keep your device unloc k ed whe n you're carrying it with you.
• Trusted places: Keep your device unlocked when you're in a familiar, secure location,
such as your home.
• Trusted devices: Keep your device unlocked when a trusted Bluetooth® is connected.
• Trusted voice: Set up voice recognition to search in any screen.
The Smart Lock feature may not be available in every market, country, or region.
With Smart Lock enabled you still need to unlock your device manually after
restarting, and Within leaving the device inactive for 4 hours
.
The Smart Lock feature is developed by Google™ and the exact functionality may
change over time due to updates from Google™.
Connecting to Trusted Devices
You can designate a connected device as trusted and keep your Xperia™ device
unlocked while connected. If you have a device that you connect to regularly using
Bluetooth®, for example, a home entertainment system or a fitness tracker, you can
add it as a trusted device and bypass the added security of the lockscreen to save
time. This feature is suitable if you’re normally in a relatively secure place when you
use these devices. In some cases, you may still need to manually unlock your
device before a trusted device can be connected.
It is not recommended to add devices that are constantly connected to your device
as
trusted
As soon as a trusted device is switched off or moves out of range, your screen locks
and you need your PIN, pattern or password to unlock it.
Making Sure You're Secure when Using Trusted Devices
Different Bluetooth® devices support different Bluetooth® standards and security
capabilities. There's a chance someone could keep your Xperia™ device unlocked
by imitating your Bluetooth® connection, even if your trusted device is no longer
nearby. Your device is not always able to determine whether your connection is
secure from someone trying to imitate it.
When your device can't determine whether you're using a secure connection, you'll
get a notification on your Xperia™ device and may need to manually unlock it
before the trusted device can keep it unlocked.
Bluetooth® connectivity range can vary depending on factors like the model of your
device, the connected Bluetooth® device, and your environment. Depending on
these factors, Bluetooth® connections can work over distances up to 100 meters.
Connecting to Trusted Places
When the Trusted places feature is set up, the lockscreen security on your Xperia™
device gets disabled when you are in a designated trusted location. For this feature
to work, you must have an internet connection (preferably over Wi-Fi) and allow
your device to use your current location.
To set up trusted places, first make sure high-accuracy location mode or batterysaving location mode is enabled on your device before you add home or custom
locations.
The exact dimensions of a trusted location are an estimate and may extend beyond
the physical walls of your home or other areas you have added as trusted locations.
This feature can keep your device unlocked within a radius of up to 80 meters. Also
be aware that location signals can be replicated or manipulated. Someone with
access to specialized equipment could unlock your device.
SIM Card Protection
You can lock and unlock each SIM card that you use in your device with a PIN
(Personal Identification Number). When a SIM card is locked, the subscription
linked to the card is protected against misuse, meaning you have to enter a PIN
every time you start your device.
If you enter the PIN incorrectly too many times, your SIM card will get blocked. You
then need to enter your PUK (Personal Unblocking Key) and a new PIN. Your PIN
and PUK are supplied by your service provider.
To Set Up a SIM Card Lock
1 From the Homescreen, tap .
2 Find and tap Settings > Security > Set up SIM card lock.
3 Tap the Lock SIM card slider to enable or disable the SIM card lock.
4 Enter the SIM card PIN and tap OK. The SIM card lock is now active and you will
be prompted to enter the PIN every time you restart the device.
1 From the Home screen, tap .
2 Find and tap Settings > Securit y > Set up SIM card lock.
3 Tap Change SIM PIN.
4 Enter the old SIM card PIN and tap OK.
5 Enter the new SIM card PIN and tap OK.
6 Retype the new SIM card PIN and tap OK.
To Unlock a Blocked SIM Card Using the PUK Code
1 Enter the PUK code and tap .
2 Enter a new PIN code and tap .
3 Re-enter the new PIN code and tap
.
If you enter an incorrect PUK code too many times, you need to contact your network
operator to get a new SIM car
d.
Finding the Identification Number of Your Device
Your device has a unique identificatio n number. This number is referred to as the IMEI
(International Mobile Equipment Identity). You should keep a copy of this number. Also, if
your device is stolen, some network providers can use this number to stop the device from
accessing the network in your country or region.
To View Your IMEI Number via the Device Settings
1 From your Home screen, tap .
2 Find and tap Settings > About phone > Status > IMEI inf ormation.
You can also view the IMEI number by opening the phone dialer and entering *#06#.
When your device is on and left idle for a set period of time, the screen darkens to save
battery power and locks automatically. This lock prevents unwanted actions on the
touchscreen when you are not using it. W hen you bu y your device, a bas ic sc reen swipe
lock is already set. This means you have to swipe left or upward on the screen to unlock it.
You can change the security settings later and add other kinds of locks. See Screen Lock
on the 10 page.
To activate the screen
•
Briefly press the power key
.
To lock the screen
•
When the screen is active, briefly press the power key
.
Homescreen
The Homescreen is the starting point for using your device. It’s similar to the desktop on a
computer screen. Your Homescreen can have up to up to unlimited panes, which extend
beyond the regular screen display width. The number of Homescreen panes is
represented by a series of dots on the lower part of the Homescreen. The highlighted dot
shows the pane that is currently displayed.
The Application screen, which you open from the Homescreen, contains the
applications that come pre-installed on your device as well as applications that you
download.
To view all applications on the Application screen
1 From your Home screen, tap .
2 Slide up and down on the Application screen.
To Enable or Disable the Recommended Apps Listings
The first time you access the application screen, you get the option to enable or
disable recommended apps listi n gs . You can also enable or disable this feature later
by following the steps below:
1 Touch and hold any area on your Homescreen, then tap
2 Tap the App recommendations slider.
.
To Open an Application from the Application Screen
• When the Application screen is open, flick up or down to find the application, and
then tap the application.
To Search for an Application from the Application Screen
1 When the Application screen is open, tap Search applications or simply swipe
down on the Application screen or Homescreen.
2 Enter the name of the application you want to search for.
To Add an Application Shortcut to the Homescreen
1 On the Application screen, touch and hold an application icon, and then drag the icon to
the top of the screen. The Homescreen opens.
2 Drag the icon to the desired location on the Homescreen, then release it.
To Move an Application on the Application Screen
1 When the Application screen is open.
2 Make sure Own order is selected under Sort apps.
3 Touch and hold the application, and then drag it to the new location.
To Disable or Uninstall an Application from the Application Screen
Disabling a pre-installed app deletes all data, but the app can be enabled again from
Settings > Apps. Only downloaded apps can be fully uninstalled.
1 Touch and hold any area on the Application screen. All applications that can be disabled
or uninstalled are then indicated by .
2 Tap the relevant application, then tap DISABLE if the app came pre-installed on
your device or OK if the app was downloaded and you would like to uninstall it.
You can navigate between applications using the navigation keys and the recently
used applications window, which lets you switch easily between all recently used
applications. The navig ation keys are the Back key, the Home key, and the Recent
apps key. You can also pop open two applications on the screen at once using the
split screen mode, if the application supports multi-window function. Some
applications get closed when you press the Home key
to exit while others are
paused or continue to run in the background. If an application is paused or running in
the background, you can continue where you left off the next time you open the
application.
1 Clear all – Close all the recently used applications
2 Recently used applications window – Open a recently used application
3 Recent apps key – Open the recently used applications window and the favorites bar
4 Home key – Exit an application and go back to the Homescreen
5 Back key – Go back to the previous screen within an application or close the application
To open the recently used applications window
• Press
.
To Quickly Switch Between Recently Used Applications
• Quickly press
twice.
To Close All the Recently Used Applications
• Tap
and then tap CLEAR ALL.
To Open a Menu in an Application
• While using the application, tap .
Menus are not available in all applications.
Split screen mode enables you to view two applications at once, for example, if you want
to view your email inbox and a web browser at the same time.
1 Application 1 in upper window
2 Split screen border – Drag to resize windows
3 Application 2 in lower window
4 Split screen key – Select a recently used application
5 Home key – Go back to the Homescreen
6 Back key – Go back to the previous screen within an application or close the application
Not all applications support split screen mode.
To Use Split-Screen Mode
1 Make sure the two applications that you want to use in split screen mode are
open and running in the background.
2 Tap
3 In the lower part of the screen, tap the second desired application.
4 In portrait orientation, drag the black bar in the center up or down to resize the
5 To exit split-screen mode, tap and hold
1 Touch and hold any empty area on your Home screen, then tap Widgets.
2 Find and tap the widget you want to add.
, then drag and drop the desired application to the top part of the screen.
windows.
.
Widgets
Widgets are small applications that you can use directly on your Homescreen. They
also function as shortcuts. For example, the Weather widget allows you to see basic
weather information directly on your Homescreen. When you tap the widget, the full
Weather application opens. You can download additional widgets from Google Play™.
1 Touch and hold a widget, and then release it. If the widget
can be resized, for example, the Calendar widget, then a highlighted frame and resizing
dots appear.
2 Drag the dots inward or outward to shrink or expand the widget.
3 To confirm the new size of the widget, tap anywhere on the Home screen.
To Move a Widget
Touch and hold the widget, and then drag it to the new
•
location.
To Remove a Widget
•
Touch and hold the widget, and then drag it to Remove from home screen.
Shortcuts and folders
Use shortcuts and folders to manage your applications and keep your Home screen tidy.
Access a folder containing applications
1
2 Access an application using a shortcut
To Add an Application Shortcut to Your Homescreen
1 Touch and hold an empty area on your Home screen.
2 In the customization menu, tap Widgets > Shortcuts.
3 Scroll through the list and select an application. The selected application gets
added to the Home screen.
To Move an Item on the Homescreen
•Touch and hold the item, and then drag the item to the
new location.
To Remove an Item from the Homescreen
•Touch and hold the item, and then drag the item to
Remove from home screen at the top of the screen.
To Create a Folder on the Homescreen
•Touch and hold an application icon or a shortcut, and then
drag and drop it on top of another application icon or shortcut.
To Add Items to a Folder on the Homescreen
•Touch and hold an item, and then drag the item to the folder.
1 Tap the folder to open it.
2 Tap the folder's title bar to show the Folder name field.
3 Enter the new folder name and tap DONE.
Background and Themes
Your device com es with a def au lt bac kgr ound , but you can ada pt t he Home screen
and Lock sc re en to your ow n s tyle using wa llp aper s an d themes featuring d iff eren t
colors and patt erns .
A wallpaper m ay be use d wi thou t cha nging an y of the ot her elem ents of you r
Homescreen a nd Loc k screen . Liv e wal lpa pers add vi sual ef fec ts to your inter ac tions
with the touch screen, l et t i ng t he display change dynamically.
Themes can i nc lu de a wallpaper, a s c r ee ns a v er, title bars , an d a sound scheme that
all fit together t o create a un ique look and feel for your device.
To Change Your Wallpaper
1 Touch and hold any empty area on your Home screen.
2 Tap Wallpapers and select an option.
You ca
Homescreen and Lockscreen. Follow the steps above, then tap
Taking a screenshot
n also change your Loc k sc reen wallpaper or set the same image for both your
. Tap the desired
You can capt ure still im ag es of a n y s cr e en o n your devic e as a s creenshot.
Screenshots you take ar e au tomaticall y sav e d in Photo.
To Take a Screenshot
You can tak e a s c re enshot by pr essing and holding the power key, choose
Screenshot on the dialog.
To View Your Screenshot
1 Double-tap the status bar to display the Notification panel.
2 Tap the screenshot.
You can als o v i e w your s creenshots i n th e Photo application.
Notifications
Notifications inform you of events such as new messages and calendar notifications
as well as activities in progress, such as file downloads. Notifications appear in the
following places:
1 To open the Notification panel, drag the status bar downward, or simply double- tap it.
2 To close the Notification panel, drag or flick the panel upward.
After opening the Notification panel, you can access the Quick Settings panel by
dragging the status bar down again.
To Take Action on a Notification in the Notification Panel
•
Tap the notification.
You can directly reply to chat or email messages in the Notification panel.
To Dismiss a Notification from the Notification Panel
•
Swipe the notification left or right.
Not all notifications can be dism iss ed.
To change settings for notifications, simply drag the notification slowly to the left or
right, then tap
.
To expand a notification on the Notification panel
•
Drag the notification downward to expand and view more information about the
notification without opening the app.
Not all notifications are expandable.
To Clear All Notifications from the Notification Panel
•T
ap CLEAR ALL.
To Take Action on a Notification from the Lockscreen
Get all notifications on the lockscreen. When you have this setting
turned on, keep in mind that all content (including the content of
incoming email and chat messages) will
be visible on your lockscreen unless you designate the relevant
apps as Hide sensitive
content in the App notifications settings menu.
Hide sensitive
notification
content
You must have a PIN, password, or pattern set up as your screen lock
in order for this setting to be available. Contents hidden is displayed on
the lockscreen when sensitive
notifications arrive. For example, you'll get a notification for an incoming
email or chat, but the content won't be visible on your lockscreen.
Don't show
You won't get any notifications on the lockscreen.
notifications at
all
To Select the Notifications to Display on the Lockscreen
1 From your Home screen, tap .
2 Find and tap Settings > Notifications.
3 Tap
4 Select an option.
, and then tap On the lock screen.
You can keep notifications on the lockscreen until you swipe to dismiss them. To
enable this feature, tap the Keep notifications on lock screen slider.
Setting the Notification Level for an App
Block all Never receive notifications from the selected app.
Sounds and vibrations off
Receive notifications but without sound, vibration, or peeking into
view.
To Set the Notification Level for an App
1 From your Home screen, tap .
2 Find and tap Settings > Notifications.
3 Select the desired app.
4 Tap the sliders to adjust notification settings as desired.
Notification Light
The notification light informs you about battery status and some other events. For
example, a flashing white light means there is a new message or a missed call.
The notification light is enabled by default but can be disabled manually.
When the notification light is disabled, it onl y lights up when ther e is a battery status
warning, such as when the battery level falls below 15 percent.
To Enable or Disable the Notification Light
1 From your Homescreen, tap .
2 Find and tap Settings > Notifications >
.
3 Tap the slider beside Notification light to enable or disable the function.
Perform a basic setup of your device A software update is available System updates are available Downloading system updates Tap to install the downloaded system updates
STAMINA mode is activated
Ultra STAMINA mode is activated
Screenshot captured
A song is playing
The radio is on
The device is connected to a computer via a USB cable Internal storage is 75% full — tap to transfer data to a memory card
Warning
More undisplayed notifications
Not all icons that may appear on your device are listed here. This list is for reference
purposes only, and changes may be m ade witho ut notice.
To Block an Application from Sending Notifications
1 From your Homescreen, tap .
2 Find and tap Settings > Notifications.
3 Select an application.
4 Tap the Block all slider.
Applications overview
Some applications may not be included on your device or may not be
supported by all networks or service providers in all areas.
