Safety / Regulations Guide

Safety / Regulations Guide

VAIO Computer Information

Safety information

❑ Warning: This apparatus must be earthed. (Except the products with a 2-pin type plug.)
❑ The socket-outlet shall be installed near the equipment and shall be easily accessible.
❑ Opening or dismantling the main unit or any of its accessories, for whatever reason,

could lead to damages that are not covered by the guarantee.

❑ To avoid electrical shock, do not open the cabinet. Refer servicing to qualified

personnel only.

❑ Audio and picture distortion may occur if this equipment is positioned in close proximity

to any equipment emitting electromagnetic radiation.

❑ To prevent fire or shock hazard, do not expose your computer or any of its accessories

to rain or moisture.

❑ Never install modem or telephone wiring during a lightning storm.
❑ Never install telephone jacks in wet locations unless the jack is specifically designed

for wet locations.

❑ Never touch uninsulated telephone wire or terminals unless the telephone line has

been disconnected at the network interface.

❑ Use caution when installing or modifying telephone lines.
❑ Avoid using the modem during an electrical storm.
❑ Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.
❑ Do not short-circuit the metal terminals of the battery pack or wet them with any liquid,

for example water, coffee or juice.

❑ Do not block the air vents and avoid placing your computer on dusty surfaces.
❑ It is recommended that you do not use your computer directly on your lap. The

temperature of the base of the unit may rise during normal operation and over time
could result in discomfort or burns.

❑ Do not place the AC adapter in contact with your skin. Remove the AC adapter away

from your body if it becomes warm and causes discomfort.

The optical disc drive of your computer is classified as a CLASS 1 LASER PRODUCT and
complies with the Laser Products Safety Standard IEC/EN 60825-1.

Caution - Repair and maintenance of this equipment should be made only by Sony
authorised technicians. Improper use and repairs can create a safety hazard.

Caution - Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.

For incorporated optical disc drive
Caution - Class 3B visible and invisible laser radiation when open. Avoid direct exposure to

the beam.

- Maximum power: 390 W ( 650nm), 563 W ( 780nm), 39 W ( 405nm)

- Beam divergence: 0.6 ( 650nm), 0.45 ( 780nm), 0.85 ( 405nm)

- Pulse duration: Continuous wave

μ λ μ λ μ λ

λ λ λ

5

For VPCZ1 Series with the optical disc drive

These models are classified as CLASS 1 LASER PRODUCTS and comply with the Laser
Product Safety Standard IEC 60825-1(2007)/EN 60825-1(2007).

Caution - Class 3B visible and invisible laser radiation when open. Avoid direct exposure to
the beam.

- Maximum power: 390 W ( 650nm), 563 W ( 780nm), 39 W ( 405nm)

- Beam divergence: 0.6 ( 650nm), 0.45 ( 780nm), 0.85 ( 405nm)

μ λ μ λ μ λ

λ λ λ

- Pulse duration: Continuous wave

Caution - Repair and maintenance of this equipment should be made only by Sony
authorised technicians. Improper repairs and use can create safety hazards.

Caution - Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.

The CLASS 1 label is located on the bottom of the notebook near the model number.

The CLASS 3B warning label is located on the frame below the unit's keyboard or located
inside the battery compartment.

6

Safety / Regulations Guide

VAIO notebooks and VAIO desktops with AC adapters

VAIO notebooks are designed to operate only with genuine Sony batteries. Therefore, and
in order to guarantee a safe usage of your VAIO notebook, only a genuine Sony
rechargeable battery pack should be used. Also, it is highly recommended that you use a
genuine Sony AC adapter that meets the quality assurance standard, and supplied by Sony
for your VAIO computer.

This AC adapter is intended for use with VAIO IT products only. Please do not use it for any
other purpose. If the power cable of the AC adapter bundled with your computer comes with
a 3-pin plug, please make sure that the electrical connection will be properly earthed.

To disconnect your computer completely from mains voltage, unplug the AC adapter from
mains. The socket outlet shall be installed near the equipment and shall be easily
accessible.

i.LINK, PC Card, monitor and DVI connectors are not supplied with Limited Power Sources,
if such connectors are provided.

Always keep the battery pack installed while the computer is in use.
To prevent possible damage and risk of ignition to your computer during transportation, first

attach any supplied connector covers and slot protectors in their appropriate locations, and
secure the battery pack in the battery compartment.

When travelling to and within the United States of America, please be aware that the U.S.
Department of Transportation (DOT) recently published new regulations that apply to
passengers travelling with lithium metal batteries and lithium ion batteries.

For detailed information, visit
http://safetravel.dot.gov/whats_new_batteries.html.

VAIO desktops only

VAIO desktops are for indoor use only.
Some models have multiple country specific power cords supplied with them. Please use

the power cord suited to the power outlet in your country.
To disconnect your VAIO desktop completely from mains voltage, unplug the power cable.
The socket outlet shall be installed near the equipment and shall be easily accessible.

Regulatory information

Sony hereby declares that this product, whether or not it includes a wireless kit - including
a wireless keyboard and/or a wireless mouse and/or a wireless receiver, is in compliance
with the essential requirements and other relevant provisions of
European Directive 1999/5/EC.

To obtain a copy of the declaration of conformity (DoC) with the R&TTE Directive, please
access the following URL: http://www.compliance.sony.de/

This product complies with EN 55022 Class B and EN 55024 for use in following areas:
residential, commercial and light industrial.

This product has been tested and found compliant with the limits set out in the
EMC Directive for using connection cables not longer than 3 metres.

VAIO desktops with wireless kit

Referring to the R&TTE Directive, the wireless keyboard and the wireless mouse are
classified as Class 1 products.

7

Precautions on using the battery

❑ Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer. Discard used batteries according
to the manufacturer’s instructions.

❑ The battery pack used in this device may present a fire or chemical burn hazard if

mistreated.

❑ Do not disassemble, heat above 60°C (140°F) or incinerate.
❑ Dispose of used batteries promptly and properly.
❑ Keep away from children.
❑ Do not short-circuit the metal terminals of the battery pack or wet them with any liquid,

for example, water, coffee, or juice.

Disposal of the internal backup memory battery

❑ Your VAIO product is equipped with an internal backup memory battery that should not

have to be replaced during the lifetime of the product. When the battery needs to be
replaced, please contact VAIO-Link.

❑ Dispose of the battery properly at its end-of-life.
❑ In some areas the disposal of non-hazardous batteries in household or business waste

may be prohibited.

❑ Please use the public collection system.

Disposal of AA batteries

❑ Depending on the model, some accessories powered by AA batteries may be bundled

with your VAIO computer.

❑ For installing the batteries, please refer to the instruction manual.
❑ Do not handle damaged or leaking batteries.
❑ Batteries may explode or leak if improperly recharged, disposed of in fire, mixed with

other types of battery or improperly installed.

❑ Batteries may present a fire or chemical burn hazard if mistreated.
❑ Dispose of properly at end-of-life.
❑ In some areas, the disposal of batteries in household or business waste may be

prohibited. Please use the appropriate public collection system.

VAIO notebooks only: Disposal of lithium ion batteries

❑ Do not handle damaged or leaking lithium ion batteries.
❑ Dispose of used batteries promptly and properly.
❑ In some areas the disposal of lithium ion batteries in household or business waste may

be prohibited.

❑ Please use the appropriate public collection system.

8

Safety / Regulations Guide

Disposal of Old Electrical & Electronic Equipment (Applicable in the
European Union and other European countries with separate
collection systems)

This symbol on the product or on its packaging indicates that this product shall
not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of

For more detailed information about recycling of this product, please contact your local
Civic Office, your household waste disposal service or the shop where you purchased the
product.

this product. The recycling of materials will help to conserve natural resources.

Disposal of waste batteries (applicable in the European Union and
other European countries with separate collection systems)

Either of the symbols shown next may appear on the
battery or on the packaging to indicate that the battery

or

battery contains more than 0.0005% mercury or 0.004% lead.
By ensuring these batteries are disposed of correctly, you will help prevent potentially

negative consequences for the environment and human health which could otherwise be
caused by inappropriate waste handling of the battery. The recycling of the materials will
help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a
permanent connection with an incorporated battery, this battery should be replaced by
qualified service staff only.
To ensure that the battery will be treated properly, hand over the product at end-of-life to
the applicable collection point for the recycling of electrical and electronic equipment.

For all other batteries, please view the section on how to remove the battery from the
product safely. Hand the battery over to the applicable collection point for the recycling of
waste batteries.

For more detailed information about recycling of this product or battery, please contact your
local Civic Office, your household waste disposal service or the shop where you purchased
the product.

provided with this product shall not be treated as
household waste.

On certain batteries this symbol might be used in
combination with a chemical symbol. The chemical
symbols for mercury (Hg) or lead (Pb) are added if the

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108­0075 Japan. The Authorized Representative for EMC and product safety is Sony
Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or
guarantee matters, please refer to the addresses given in separate service or guarantee
documents.
