Sony VGN-A690 User Manual

Personal Computer

VGN-A600 Series

Quick Start

VAIO® Computer Quick Start

Shortcut Menu

+F1 Displays the VAIO Help and Support Center window. +Tab Switches the selected button on the taskbar. +D Displays the desktop. +E Displays the My Computer window. +F Displays the Search Results window, where you can find a

file or folder. This is the equivalent of selecting Search from the Start menu.

+Ctrl+F Displays the Search Results - Computers window, where

you can locate other computers. This is the equivalent of selecting Search, and then Computer from the Start menu.

+M Minimizes all displayed windows.

Shift+ +M Returns all minimized windows to their previous size.

+R Displays the Run window. This is the equivalent of selecting

Run from the Start menu.

Fn+ +Insert Displays the System Properties window. This is the

equivalent of selecting Control Panel, and then System from

the Start menu. Fn+F5 Decreases the LCD screen brightness. Fn+F6 Increases the LCD screen brightness. Fn+F7 Toggles the display between the computer screen (LCD), a

connected external display, and both the LCD and an

external display. Fn+F12 Puts the system into Hibernate mode, a power management

state. To return the system to normal operating mode, press

the power button. Fn+Esc Puts the system into Standby mode, a power management

state. To return the system to the active state, press any key

or the power button.

Contents

Notice to Users ............................................5

Setting Up ..................................................13

Unpacking Your Computer .......................................13

Locating Controls and Ports ......................................16

About the Indicator Lights ........................................24

About the Wireless Mouse ........................................26

Getting Started ..........................................29

Turning On Your Computer ......................................29

Using the Touch Pad .................................................34

Connecting the Wireless Mouse................................36

Registering Your Computer ......................................37

Locating Your VAIO Computer User Guide ............38

Setting Up A Dial-Up Connection ............................40

Turning Off Your Computer .....................................41

Troubleshooting ........................................43

Support Options.........................................................46

VAIO® Computer Quick Start
