FEATURES

• Mobile Intel®Celeron™900 MHz1processor

• All-in-one design with floppy drive, hard drive, and CD-RW/DVD combo drive

• 14.1" XGA (1024 x 768) TFT screen

• 128 MB RAM (expandable to 512 MB)

• 15 GB

• 10BASE-T/100BASE-TX integrated Ethernet

• AGP-enabled Intel

• Standard-capacity lithium-ion battery, dual

• i.LINK

• NTSC video out

• Integrated V.90 modem

• Three Programmable Power Keys (PPK) for easy

• Optional port replicator

• Built-in stereo speakers

• Available with Microsoft

• Built-in stereo speakers

1 MHz denotes microprocessor internal clock speed; other factors may affect

2 With weight saver in floppy drive bay. 3 GB means one billion bytes when referring to hard drive capacity. Accessible capacity may vary. 4 i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394

5 Estimated battery life. Actual battery life may vary on usage. 6 Certain restrictions apply to Express Repair Service. 7 From date of purchase upon registration. 8 Requires payment of additional fees or subscription for use. 9 Certain software product(s) included with this computer may include features such as copy protection and content management technology. USE OF THE SOFTWARE PRODUCT(S) REQUIRES AGREEMENT TO APPLICABLE END USER AGREEMENTS AND FULL COMPLIANCE WITH APPLICABLE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply). 10 Using optional second battery in floppy drive bay. 11 Not available on Windows®2000 models. 12 Available with Windows®2000 only.

Sony Electronics Inc. For more information: 1.800.4SONYPC (476-6972) Web address: http://www.sony.com/vaio

Computer Interface: The computer industry lacks standards, and therefore, there are a multitude of varying software packages and add-on hardware options. This personal computer is not manufactured to any specific software, and Sony does not and cannot make any warranty or representation with respect to the performance of this product with any particular software packages and/or non-Sony add-on hardware option except those mentioned in this document. Sony hereby disclaims any representations or warranty that this product is compatible with any combination of products you may choose to connect. While Sony representatives or Sony authorized dealers may be able to assist you and may make recommendations, they are NOT authorized to vary or waive this disclaimer. Purchasers must determine for themselves the suitability and compatibility of the hardware and software in each and every particular instance. Some pre-installed software titles may not include full documentation. Software titles preinstalled on the Sony Notebook Computer are subject to change without notice. Simulated graphic shown on display.

©2001 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, i.LINK, VAIO are registered trademarks and DVgate, Jog Dial, Media Bar, PictureGear, Handycam, MovieShaker, OpenMG, 3Max+ and Visual Flow are trademarks of Sony. Intel SpeedStep technology and Pentium are registered trademarks of Intel Corporation. Microsoft and Windows are trademarks of Microsoft Corporation. All other trademarks are trademarks of their respective owners. This product meets the standards of the International Energy Star Program for energy efficiency. Features and specifications are subject to change without notice. Non-metric weights and measurements are approximate.

hard drive

815EM graphics chip with up to 11 MB video SDRAM (shared) and 3D graphics support and Intel’s Dynamic Video Memory Technology

battery capability

(IEEE 1394) S400 interface4supports high-speed digital video, audio, and data transfer capabilities among equipped Sony products

access to key applications

Edition

, Microsoft®Windows®XP Professional

and Microsoft®Windows®2000 Professional

application performance.

connector. All products with an i.LINK connector may not communicate with each other.

Windows®XP Home

Screen: 14.1" XGA (1024 x 768) TFT screen

MAX

Battery: 2X battery life

MAX

Mobility: Approximately 6 lbs.2light;

MAX

PLUS:

• All-in-one design with floppy drive, hard drive, and CD-RW/DVD combo drive

• i.LINK®(IEEE 1394) interface

• Integrated 10/100Base-T Ethernet

Sony Digital Handycam®camcorder sold separately.

SPECIFICATIONS

Model

PCG-FX310, PCG-FX310K and PCG-FX310P

Processor

Mobile Intel®Celeron™ processor 900 MHz

Cache Memory

128 KB integrated on-die level 2

Bus Speed

100 MHz

Bus Architecture

AGP

LCD

14.1" XGA (1024 x 768) TFT

Graphics

Intel®815EM graphics chip with up to 11 MB video

SDRAM (shared) and Intel’s Dynamic Video Memory technology

Digital Audio

Intel®815EM with 3D surround

MPEG

MPEG1 and MPEG2 digital video Supports full screen playback

Standard RAM

128 MB SDRAM (128x1) expandable to 512 MB

Open Slots

1 SO:DIMM

Hard Drive

15 GB3fixed

CD-RW/DVD Combo Drive

Fixed CD-RW/DVD combo drive

Floppy Disk Drive

Removable 1.44 MB, 3.5" internal operation

Floppy disk drive bay also supports second lithium-ion

battery when floppy drive is removed

Ethernet

10BASE-T/100BASE-TX integrated Ethernet

Modem

Integrated V.90 modem

Keyboard

86 key QWERTY layout 19mm key pitch 3mm stroke

Pointing Device

Electro-Static touch pad

Speaker

Built-in stereo speakers

Battery

Lithium-ion battery (PCGA-BP1N) Supports dual battery operation

Battery Life

1.5–2.0 hours with one battery

5.0–6.0 hours with optional second battery

PC Card Slots

Supports one or two type II or one type III PC card CardBus support

Other Interfaces

Serial, parallel, VGA monitor, NTSC video out, USB(2),

RJ-11 phone jack, i.LINK

, mic-in, headphone, port replicator, RJ-45

interface Ethernet, port replicator

Power Requirements

58.5 watts maximum (19.5V DC / AC100-240V)

Power Management

Energy Star®compliant Advanced power management - ACPI compatible

(IEEE 1394) S400

PCG-FX310 PCG-FX310K PCG-FX310P

Sony VAIO®FX Pro All-in-One Notebook

about 2" thin

Size (H x W x D)

1.5"-1.9" X 12.8" X 10.5"

Weight

6.2 lbs. (with weight saver in floppy drive bay)

6.7 lbs. (with floppy drive in floppy drive bay)

Supplied Accessories

Lithium-ion battery, AC adapter, weight saver, floppy

disk drive, power cord, and video cable

Optional Accessories

Additional battery (PCGA-BP71A) Network port replicator (PCGA-PRFX1) USB mouse (PCGA-UMS1/A) Carrying case (PCGA-CCF) Notebook backpack (PCGA-CCP1) Additional AC adapter (PCGA-AC19V1) Wireless LAN Access Point (PCWA-A200) Wireless LAN PC Card (PCWA-C100)

Service

One year limited Express Service

Limited Warranty

One year parts and labor (90 days without registration)

Telephone Support

Hardware: One year Software and operating system: 90 days

INCLUDED SOFTWARE Operating System

FX310: Microsoft®Windows®XP Home Edition FX310K: Microsoft®Windows®2000 Professional FX310P: Microsoft®Windows®XP Professional

Key Pre-Installed Software

Adaptec Easy CD Creator Adobe Acrobat®Reader Adobe PhotoShop Elements Adobe Premiere®LE

PhotoPrinter 2000 Pro

Arcsoft

Microsoft Norton AntiVirus PC-Cillin®2000 Quicken QuickTime RealNetworks®Real Jukebox RealNetworks®RealPlayer Sony DigitalPrint Sony DVgate Sony MovieShaker Sony OpenMG™Jukebox Sony PictureGear Sony Smart Capture Sony SonicStage Sony VisualFlow VAIO®Support Agent WinDVD

Word 2002

200113or 2002

™

3.1

Online Center

America Online Earthlink®Total Access Microsoft®Internet Explorer Netscape Communicator Sony Style Connect

Preloaded with

RealJukebox for Sony

™13

™

™13

®13

™

™12

™

®8

9,8

®8

Printed in U.S.A. 08/01
