Sony TM-0000 User Guide

13.2

INSTRUCTION MANUAL

Introduction

Thank you for your purchase of "SO-03E".

For proper use of the SO-03E, read this manual carefully before and while you use the SO-03E.

About manuals of SO-03E

In addition to this manual, the operations of SO-03E are described in "

クイックスタートガイド

(Quick Start

Guide)" (in Japanese only) and "Instruction Manual" application of the terminal (in Japanese only).

●"クイックスタートガイド

(Quick Start Guide)"

(Supplied accessories)

The initial operations and settings after purchasing the terminal, screen view contents and operations of main function are explained. (In Japanese only)

●

"Instruction Manual" (Application of the terminal)

Similarly to this manual, operations and settings of each function are explained. To use "Instruction Manual" application, from the Home screen, tap and [Instruction Manual]. When using for the first time, download and install the application according to the onscreen instructions. If you delete "Instruction Manual" application, you can access Google Play from Play Store to install again. From the Home screen, tap [Play Store] and search "Instruction Manual" application to select, then follow the onscreen instructions to install. You can use the application as an electronic book. You can also shift to actual operations by tapping the description in the contents or view reference contents.

❖

Note

･

For downloading or updating the application, a high packet communication charge will be applied because of a large amount data communication. For this reason, subscription of packet flat-rate service is highly recommended.

●

"Instruction Manual" (PDF file)

Operations and settings of each function are explained. It can be downloaded from NTT DOCOMO website. http://www.nttdocomo.co.jp/english/support/ trouble/manual/download/index.html

* You can download the latest information of "

ク

イックスタートガイド

(Quick Start Guide)" (in

Japanese only). The URL and contents are subject to change without prior notice.

❖

Note

･

Reproduction or reprint of all or part of this manual without prior permission is prohibited.

･

Important information for SO-03E is posted in the following website. Be sure to check before using. http://www.sonymobile.co.jp/support/use_support/ product/so-03e/ (In Japanese only)

●

スマホなるほどツアーズ

for docomo with series

"Tips of smartphone for docomo with series" (Widget in the terminal)

An widget with which you can easily learn useful functions and basic operations you should know with Docomodake. To use Tips of smartphone for docomo with series, from the Home screen, tap .

Operation descriptions

In this manual, each key operation is described with

p, x, y, r, m

. And selection operations of the icons or function items on the touch screen are described as follows.

❖

Information

･

In this manual, the instructions are described with the default Home screen. If you set the other application to the home screen, the operations may differ from the descriptions.

･

Display examples and illustrations used in this manual are just images for explanations and may be different from actual ones.

･

In this manual, the easier procedure is described for the functions and settings which have multiple operating procedures.

･

Please note that "SO-03E" is called "the terminal" in this manual.

･

In this manual, explanations for "docomo" as Home application are provided. To switch the Home applications, see "Learning Home screen" (P.70).

Description Operation

From the Home screen, tap and tap [Settings]

[About

phone].

From the Home screen, tap (Applications button), and then tap "Settings" on the next screen and "About phone" on the following screen in order.

Touch and hold an icon.

Keep touching an icon longer (12 seconds).

･

SO-03E (with warranty)

･

Back Cover SO21

･

クイックスタートガイド

(Quick Start Guide) (In

Japanese only)

･

SO-03E

のご利用にあたっての注意事項

安全上／取り扱い上のご注意

(Notes on usage Safety/Handling precautions) (In Japanese only)

･

Battery Pack SO08

･

Desktop Holder SO14 (with warranty)

･

1Seg antenna cable SO01

･

microSD card (2GB) (Sample)

(Inserted in the terminal when purchased.)

･

Stereo Headset with Microphone (Sample)

* with manual

For details on optional devices, see "Optional and related devices" (P.239).

Supplied accessories

Contents/Precautions

Contents

■

Supplied accessories. . . . . . . . . . . . . . . . . 2

■

About using the terminal . . . . . . . . . . . . 5

■

Safety Precautions (Always follow these

directions) . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■

Handling precautions. . . . . . . . . . . . . . . 17

■

Waterproofness/Dustproofness . . . . . 24

Before Using the Terminal . . . 30

Part names and functions................................................30

docomo mini UIM card .....................................................31

microSD card...........................................................................33

Charging.....................................................................................35

Turning power on/off.........................................................39

Initial settings...........................................................................40

Status bar ...................................................................................41

Notification panel.................................................................43

Notification LED.....................................................................44

Basic operations.....................................................................45

Searching information in the terminal and web

pages ............................................................................................48

Character entry.......................................................................49

Setting character entry......................................................62

Setting Xperia

™

Japanese keyboard........................62

USB keyboard/Bluetooth keyboard...........................68

docomo Palette UI. . . . . . . . . . . 70

Home screen............................................................................70

Application screen................................................................76

Phone . . . . . . . . . . . . . . . . . . . . . . 85

Making/Receiving a call ....................................................85

Operations during a call....................................................88

Call history.................................................................................89

Call settings..............................................................................91

Phonebook...............................................................................92

Mail/Web browser . . . . . . . . . .102

sp-mode mail....................................................................... 102

Message (SMS)..................................................................... 102

Email........................................................................................... 105

Gmail.......................................................................................... 112

Google Talk............................................................................ 112

Early Warning "Area Mail".............................................. 113

Web browser........................................................................ 114

Settings. . . . . . . . . . . . . . . . . . . .118

Viewing the setting menu............................................ 118

Wireless & networks ......................................................... 118

Device ....................................................................................... 130

PERSONAL .............................................................................. 139

SYSTEM..................................................................................... 151

File management . . . . . . . . . . .154

Handling a file...................................................................... 154

Transferring and moving data................................... 154

Using infrared communication................................. 158

Using Bluetooth function ............................................. 161

Sharing files with DLNA devices............................... 165

Applications . . . . . . . . . . . . . . .167

dmenu...................................................................................... 167

dmarket.................................................................................... 167

Play Store ................................................................................ 168

Osaifu-Keitai .......................................................................... 169

Contents/Precautions

1Seg............................................................................................175

FM radio...................................................................................183

Camera......................................................................................185

Playing multimedia content........................................203

Album........................................................................................205

YouTube...................................................................................207

Connecting the terminal to TV to watch photos

and videos..............................................................................208

Media Player..........................................................................210

Timescape

™

.........................................................................213

Location services................................................................216

Calendar...................................................................................221

Alarm & clock........................................................................223

ドコモバックアップ

(docomo backup)..................227

OfficeSuite..............................................................................229

International roaming . . . . . . 230

Overview of International roaming (WORLD

WING).........................................................................................230

Available Services...............................................................230

Before using........................................................................... 231

Making/Receiving calls in the country you stay

.......................................................................................................234

International roaming settings..................................236

Appendix/Index. . . . . . . . . . . . 239

Optional and related devices .....................................239

Troubleshooting.................................................................239

Smartphone Anshin Remote Support ................. 246

Warranty and After Sales Services............................ 247

Updating software.............................................................250

Main specification..............................................................253

Specific Absorption Rate of Mobile Phone, etc.

.......................................................................................................256

End User Licence Agreement.....................................268

About Open Source Software....................................269

Export Controls and Regulations..............................269

Intellectual Property Right ........................................... 270

SIM unlock.............................................................................. 273

Index.......................................................................................... 274

Contents/Precautions

･

The terminal supports LTE, W-CDMA, GSM/ GPRS and Wireless LAN Systems.

･

Because a terminal operates using radio frequencies, it cannot be used inside a tunnel, underground, in a building or other locations where radio waves do not reach the terminal, in locations with weak radio wave condition, or out of Xi/FOMA service area. The services may not be available on high upper floors of high-rise apartments or buildings, even if you can see no obstructions around you. On occasion, your calls may become disconnected even in areas with strong radio wave condition, even if you are not moving, or even if there are 4-antenna marks in the terminal's display.

･

Because your terminal uses radio waves to communicate, it is possible that a third party may attempt to tap your calls. However, the LTE, W-CDMA, GSM/GPRS system automatically scrambles all calls through a private call feature. Therefore, even if third party successfully intercepts your call, they will only hear noise.

･

The terminal operates on radio frequencies by converting voice into digital signals. If the caller moves into an area of adverse radio wave condition, the digital signal may not be restored accurately, and the voice received in the call may differ slightly from the actual voice.

･

Note down the information saved in the terminal in a separate note and keep it safely. Note that DOCOMO assumes no responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the model or other handling of the terminal.

･

You are recommended to save important data to microSD card.

･

As with PCs, some user-installed applications may disrupt the stability of the terminal performance, or unexpectedly transmit information via the Internet causing improper use of your location information as well as personal information recorded on the terminal. Therefore, verify the supplier and operating conditions of the applications to be used before using them.

･

This terminal has Xi Area, FOMA Plus-Area and FOMA HIGH-SPEED Area support.

･

The terminal does not support i-mode sites (programs) or i-

ppli.

About using the terminal

Contents/Precautions

･

The terminal automatically performs communication for synchronizing data, checking the latest software version, maintain connection with the server, etc. If you transmit a large amount of data such as downloading applications or watching movie, a packet communication charge becomes high. Subscription of packet flatrate service is highly recommended.

･

Depending on the applications or service you use, packet communication fees may be charged even in Wi-Fi communication.

･

Public mode (Driving mode) is not supported.

･

Setting the terminal to Silent mode does not mute sounds for shutter, playback of video or music, alarm, dial pad touch tones during a call, sound emitted when tapping [End call], etc.

･

The names of the operators are displayed on unlocking screen (P.40).

･

Your phone number (own number) can be checked as follows: From the Home screen, tap and tap [Settings]

[About phone]u[Status].

･

The software version of your terminal can be checked as follows: From the Home screen, tap and tap [Settings]

[About phone].

･

You can perform software update by downloading an update file with a PC via Internet and connecting the PC to the terminal. For details, see "Connecting to a PC and updating" (P.252).

･

By some software updates, the operating system (OS) may be version-upgraded for improving the terminal quality. For this reason, you always need to use the latest OS version. And some applications that used in the previous OS version may not be available or some unintended bugs may occur.

･

You can use the terminal only with docomo mini UIM card. If you have a UIM or FOMA card, bring it to a docomo Shop to replace. If you use a docomo mini UIM card (red), you cannot use some Osaifu-Keitai compatible services such as international use. Bring it to a docomo Shop to replace in February, 2013 (scheduled) or later.

･

Set the screen lock to ensure the security of your terminal for its loss. For details, see "Screen lock" (P.146).

･

If your terminal is lost, change your each account password to invalidate authentication using a PC to prevent other persons from using Google services such as Google Talk, Gmail, Google Play, etc., Facebook, Twitter and mixi.

･

Google application and service contents are subject to change without prior notice.

Contents/Precautions

･

The terminal supports only sp-mode, mopera U and Business mopera Internet. Other providers are not supported.

･

To use tethering, subscription of sp-mode is required.

･

Packet communication charge when using tethering varies depending on the charging plan you use. Subscription of packet flat-rate service is highly recommended.

･

For details on usage charge, etc., refer to the following website. http://www.nttdocomo.co.jp/english/

Notice: Pursuant to the Japanese Radio Law (

電波法

)

and the Japanese Telecommunications Business Law (

電気通信事業法

), this device has

been granted a designation number according to the "Ordinance concerning the Technical Regulations Conformity Certification etc. of Specified Radio

Equipment (

特定無線設備の技術基準適合証明等

に関する規則

R-(W-CDMA)/Article 2-1-11-3, R-(W-CDMA)/Article 2-1-11-7, IEEE802.11bgn (2.4GHz)/Article 2-1-19, IEEE802.11an (5GHz)/Article 2-1-19-3, IEEE802.11an (5GHz)/Article 2-1-19-3-2, LTE/Article 2-1-11-19, BT/Article 2-1-19: 202-LSA035 and "Ordinance Concerning Technical Conditions Compliance Approval etc. of

Terminal Equipment (

端末機器の技術基準適合

認定等に関する規則

T-(W-CDMA): AD 12-0022 202

AD 12-0034 202 202-SMA046

Contents/Precautions

■

For safe and proper use of the terminal, please read the "Safety Precautions" prior to use. Keep the Manual in a safe place for future reference.

■

ALWAYS observe the safety precautions since they intend to prevent personal injury or property damage.

■

The following symbols indicate the different levels of injury or damage that may result if the guidelines are not observed and the terminal is used improperly.

■

The following symbols indicate specific directions.

■

"Safety Precautions" are described in the following categories:

1. Handling the terminal, battery pack, adapter, desktop holder, docomo mini UIM card, 1Seg

antenna cable (common) . . . . . . . . . . . . . . . . . . . .8

2. Handling the terminal . . . . . . . . . . . . . . . . . . . . . . 10

3. Handling battery pack. . . . . . . . . . . . . . . . . . . . . . 12

4. Handling adapter or desktop holder . . . . . . . . 13

5. Handling the docomo mini UIM card. . . . . . . . 15

6. Handling the terminal near electronic medical

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

7. Material list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Safety Precautions (Always follow these directions)

Failure to observe these guidelines may immediately result in death or serious injury.

Failure to observe these guidelines may result in death or serious injury.

Failure to observe these guidelines may result in injury and property damage.

DANGER

WARNING

CAUTION

Indicates prohibited actions.

Indicates not to disassemble.

Indicates not to use where it could get wet.

Indicates not to handle with wet hands.

Indicates compulsory actions in accordance with instructions.

Indicates to remove the power plug from the outlet.

Don’t

No disassembly

No liquids

No wet hands

Unplug

Contents/Precautions

1. Handling the terminal, battery pack, adapter, desktop holder, docomo mini UIM card, 1Seg antenna cable (common)

DANGER

Do not use, store or leave the equipment in hot places (e.g. by the fire, near a heater, under a kotatsu, in direct sunlight, in a car in the hot sun). (including the event that you ware the equipment in the pocket of your clothes, etc.)

Doing so may cause fire, burns or injury.

Do not place equipment inside cooking appliance such as a microwave oven or highpressure containers.

Doing so may cause fire, burns, injury or electric shock.

Do not disassemble or modify the equipment.

Doing so may cause fire, burns, injury or electric shock.

Do not let the equipment get wet with water, drinking water, urine of pet animals, etc.

Doing so may cause fire, burns, injury or electric shock.

For waterproof, see

→

P.24. "Waterproofness/

Dustproofness"

Use the battery pack and adapter specified by NTT DOCOMO for your terminal.

Failure to do so may cause fire, burns, injury or electric shock.

WARNING

Do not subject the equipment to excessive force or throw it.

Doing so may cause fire, burns, injury or electric shock.

Do not allow the contacts for the desktop holder, the microUSB jack or headset jack to touch conducting foreign substances (a piece of metal, pencil lead, etc.). Never allow these objects to get inside.

Doing so may cause fire, burns, injury or electric shock.

Do not cover or wrap the equipment with a cloth or bedding in use or while charging.

Doing so may cause fire or burns.

Power off the terminal before you step into a place where flammable gas can leak, such as gas stations. Stop charging if you charge the battery.

Gas may catch fire. When using Osaifu-Keitai in a place such as a gas station, turn OFF the terminal before using it. (When NFC/Osaifu-Keitai lock is activated, deactivate it before turning OFF the terminal.)

Don’t

No disassembly

No liquids

Don’t

Contents/Precautions

If you notice anything unusual about the equipment such as an unusual odor, overheating, discoloration or deformation during operation, charging or storage, immediately perform the following measures.

・

Remove the power plug from the power outlet or cigarette lighter.

・

Power off the terminal.

・

Remove the battery pack from the terminal.

Failure to do so may cause fire, burns, injury or electric shock.

CAUTION

Do not place on an unstable or inclined platform.

Doing so may cause the device to fall and cause injury.

Do not keep in a place that is very humid, dusty, or subject to high temperature.

Doing so may cause fire, burns or electric shock.

If children use the terminal, parents or guardians should give them the proper instructions for use. Make sure that they use the terminal as instructed.

Failure to do so may cause injury.

Keep the equipment out of the reach of babies and infants.

Failure to do so may cause accidental swallowing or injury.

Be careful especially when using the terminal connected to the adapter continuously for a long time.

If you play a game, watch 1Seg, etc. for a long time while charging, the temperature of the terminal, battery pack and AC adapter may rise. If you are directly in contact with hot parts for a long period of time, it may cause your skin to become red, itchy, or develop a rash depending on your physical condition and also it may cause low-temperature burn.

2. Handling the terminal

WARNING

Do not direct the infrared data port toward your eye and transmit signals.

Doing so may cause harmful effect your eyes.

Do not direct the infrared data port toward home electric appliances etc. equipped with infrared device when using infrared communication.

Doing so may cause an accident because of erroneous operation of infrared device.

Do not turn on the light with the lighting luminescence part close to the eyes. Especially to shoot infants or young children, step away from them 1 m or more.

Doing so may cause blurred vision. Or injury by dazzling eyes or surprising may occur.

Don’t

Contents/Precautions

Do not allow a foreign substance such as water and other liquids, metal parts, or flammables to get in the docomo mini UIM card or microSD card slot on the terminal.

Doing so may cause fire, burns, injury or electric shock.

Do not turn on the light toward a driver of a car etc.

Doing so may disturb driving and cause an accident.

Power off the terminal in a place where the use is prohibited such as in airplane or hospital.

Failure to do so may affect electronic equipment and electronic medical equipment. Follow the instructions of each medical facility for the use of mobile phones on their premises. Prohibited acts such as mobile phone usage on board an airplane may be punished by law. If usage of mobile phones in an aircraft is admitted by setting airplane mode, etc., use the terminal under the direction of the airline. If the microUSB cable is connected into the USB jack for charging etc., the terminal is automatically powered on although the operations are not available. Be careful not to connect the microUSB cable in a place where the use is prohibited such as in airplane or hospital.

Always keep the terminal away from your ear when you talk setting the hands-free function. Also, when you play game, play back music, etc. connecting the Earphone/Microphone, etc. to the terminal, adjust the volume adequately.

If the volume is too loud, it may cause difficulty in hearing. Moreover, if you barely hear the surrounding sounds, it may cause an accident.

If you have a weak heart, set the vibrator or ringtone volume carefully.

Failure to do so may affect your heart.

If you are wearing any electronic medical equipment, check with the relevant medical electronic equipment manufacturer or vendor whether the operation may be affected by radio waves.

The radio waves from the terminal may affect electronic medical equipment.

Don’t

Contents/Precautions

Power off the terminal near electronic devices or equipment operating on high precision control or weak signals.

Failure to do so may interfere with the operation of electronic devices or equipment. * The followings are some electronic devices

or equipment that you should be careful of: Hearing aids, implantable cardiac pacemaker, implantable cardioverter defibrillator, other electronic medical equipment, fire detector, automatic door, and other automatically controlled devices or equipment. If you use an implantable cardiac pacemaker, implantable cardioverter defibrillator, or other electronic medical equipment, check with the relevant medical electronic equipment manufacturer or vendor whether the operation can be affected by radio waves.

Be careful about broken glasses or exposed internal from the terminal if the display or the camera lens is broken.

Shatterproof film-applied hardened glass is used on the display surface and the acrylic resin is applied on camera lens so as not to be shattered when broken. But they may cause injury if you touch a cut surface or exposed portion mistakenly.

CAUTION

Do not swing the terminal around by holding a strap etc.

The terminal may hit you or others and cause accident such as injury.

Do not use damaged terminal.

Doing so may cause fire, burns, injury or electric shock.

When using the motion sensor, check the safety around you, hold the terminal firmly, and do not shake it unnecessarily.

May cause accident such as injuries.

If the display is mistakenly damaged and when the liquid crystal runs out, do not get it on your skin such as face, hands, etc.

Doing so may cause blindness or injury on your skin. If the liquid crystal gets in your eye or mouth, rinse with clean running water, and get medical treatment immediately. Also, if it gets on your skin or clothes, use something such as alcohol to wipe off and wash it with soap in clear water.

To use the terminal in car, check with automobile manufacturer or dealer to determine how the device is affected by radio waves before using.

In rare cases, using the phone in some vehicle models can cause the vehicle's electronic equipment to malfunction. In that case, stop using the terminal immediately.

Don’t

Contents/Precautions

The use of the terminal may cause itching, rashes, eczema, or other symptoms depending on the user's physical condition. Immediately stop using and get medical treatment in such a case.

For material of each part →P.16 "Material list"

When watching the display, take a certain distance from the display in a fully bright place.

Failure to do so may reduce visual acuity.

3. Handling battery pack

■

Check that the battery type matches the type displayed on the battery pack label.

DANGER

Do not connect a wire or other metal objects to the jack. And, do not carry or store the terminal with objects like a metal necklace.

Doing so may cause battery pack to ignite, burst, heat or leak.

Check the orientation of the battery pack to attach to the terminal, and do not try to force the battery pack onto the terminal if you are having trouble attaching it.

Doing so may cause battery pack to ignite, burst, heat or leak.

Do not throw the terminal into fire.

Doing so may cause battery pack to ignite, burst, heat or leak.

Do not stick a nail into the terminal, hit it with a hammer, or step on it.

Doing so may cause battery pack to ignite, burst, heat or leak.

If the battery pack's fluid etc. contacts eyes, immediately flush the eyes with clean water and see a doctor right away. Do not rub the eyes.

Failure to do so may cause blindness.

WARNING

If the battery pack seems to have abnormalities such as deformation or scratches due to falling, never use it.

Doing so may cause battery pack to ignite, burst, heat or leak.

If the battery pack leaks or gives off a strange smell, immediately remove it from the vicinity of open flames.

The leaking liquid may ignite fire, catch fire, or explode.

Be careful not to let your pet bite the battery pack.

Doing so may cause battery pack to ignite, burst, heat or leak.

CAUTION

Do not discard the battery pack together with other garbage.

Doing so may cause igniting or environmental destruction. Tape the terminals of old battery packs to insulate them, and then bring them into a sales outlet such as docomo Shop. If your local municipality has a battery recycling program, dispose of them as provided for.

Display Type of Battery

Li-ion 00 Lithium Ion Battery

Don’t

Contents/Precautions

Do not use or charge a wet battery pack.

Doing so may cause battery pack to ignite, burst, heat or leak.

If fluid etc. leaks out from the battery pack, do not make the fluid contact with your skin of face or hands.

Doing so may cause blindness or injury on your skin. If the fluid etc. gets into your eyes or mouth, or contacts skin or clothes, immediately flush the contacted area with clean running water. If the fluid gets into the eyes or mouth, immediately see a doctor after flushing.

4. Handling adapter or desktop holder

WARNING

Do not use the adapter cord if it gets damaged.

Doing so may cause fire, burns or electric shock.

Do not use the AC adapter or desktop holder in a very humid place such as bathroom.

Doing so may cause fire, burns or electric shock.

DC adapter is only for a negative ground vehicle. Do not use DC adapter for a positive ground vehicle.

Doing so may cause fire, burns or electric shock.

Do not touch the adapter if you hear thunder.

Doing so may cause electric shock.

Do not short-circuit the microUSB plug while it is connected to the power outlet or cigarette lighter socket. Do not touch the microUSB plug with your hands, fingers, or any part of your body.

Doing so may cause fire, burns or electric shock.

Do not place heavy objects on the adapter cord.

Doing so may cause fire, burns or electric shock.

When you insert and remove the AC adapter from power outlet, do not contact a metal strap or other metal objects with the jack.

Doing so may cause fire, burns or electric shock.

Do not touch the adapter cord, desktop holder or outlet with wet hands.

Doing so may cause fire, burns or electric shock.

Use the adapter only on the specified power supply and voltage. When charging the terminal overseas, use AC adapter for global use.

Failure to do so may cause fire, burns or electric shock. AC adapter : AC 100 V DC adapter : DC 12 V or 24 V (only for a negative-ground vehicle) AC adapter for global use : AC 100 V to 240 V (Make sure to connect the adapter to a household AC power outlet.)

Don’t

No wet hands

Contents/Precautions

When the fuse in a DC adapter is blown, make sure to use the specified fuse.

Failure to do so may cause fire, burns or electric shock. For the specified fuse, see the users manuals that supplied with a DC adapter.

Clean dust from the power plug.

Failure to do so may cause fire, burns or electric shock.

When you connect the AC adapter to the power outlet, insert it firmly.

Failure to do so may cause fire, burns or electric shock.

When you disconnect the power plug from the outlet or cigarette lighter socket, do not pull the adapter cord with excessive force. Instead, hold the adapter to disconnect.

Failure to do so may cause fire, burns or electric shock.

Always remove the power plug from the outlet or cigarette lighter when not using the adapter for an extended period.

Failure to do so may cause fire, burns or electric shock.

Immediately remove the power plug from the outlet or cigarette lighter socket if water or other fluids get into the adapter.

Failure to do so may cause fire, burns or electric shock.

Before cleaning, remove the power plug from the power outlet or the cigarette lighter socket.

Failure to do so may cause fire, burns or electric shock.

5. Handling the docomo mini UIM card

CAUTION

Be careful of the cut surface when removing docomo mini UIM card.

Failure to do so may cause injury.

6. Handling the terminal near electronic medical equipment

■

The following instructions observe the guidelines of the Electromagnetic Compatibility Conference, Japan to protect electronic medical equipment from radio waves from mobile phones.

WARNING

Please observe the following guidelines in medical facilities.

・

Do not take the terminal into the operating rooms, ICU (Intensive Care Unit), or CCU (Coronary Care Unit).

・

Power off the terminal inside hospital wards.

・

Power off the terminal in the lobby and other places if there are any electronic medical equipment operating in the vicinity.

・

Follow the instructions of each medical facility when they specify areas forbidding to use and carrying a mobile phone.

Unplug

Contents/Precautions

Power off the terminal in crowded places such as rush-hour trains. There may be a person with an implantable cardiac pacemaker or implantable cardioverter defibrillator near you.

The radio waves from the terminal may affect the operation of implantable cardiac pacemaker or implantable cardioverter defibrillator.

If you use an implantable cardiac pacemaker or implantable cardioverter defibrillator, keep the terminal 22 cm or more away from the implant at all times.

The radio waves from the terminal may affect the performance of electronic medical equipment.

If you need to use electronic medical equipment other than implantable cardiac pacemaker or implantable cardioverter defibrillator outside medical facilities such as treating at home, check with the relevant medical electronic equipment manufacturer whether the operation may be affected by radio waves.

The radio waves from the terminal may affect the performance of electronic medical equipment.

7. Material list

Part Material

Surface

treatment

Exterior case (case : front)

Nylon resin (with glass)

UV coating

Exterior case : black, turquoise (case : rear)

PC resin (with glass)

Discontinuous evaporation coating (tin) + UV coating

Exterior case : white, pink (case : rear)

PC resin (with glass)

UV coating

Exterior case : black (microUSB jack cover)

PC resin (with glass)

Discontinuous evaporation coating (tin) + Urethan coating

Exterior case : turquoise (microUSB jack cover)

PC resin (with glass)

Discontinuous evaporation coating (tin) + UV coating

Exterior case : white, pink (microUSB jack cover)

PC resin (with glass)

UV coating + Urethan coating

Exterior case : black, turquoise (headset jack cover)

PC resin (with glass)

Discontinuous evaporation coating (tin) + UV coating

Exterior case : white, pink (headset jack cover)

PC resin (with glass)

UV coating

Exterior case : black only (back cover)

PC resin (with glass) + Silicon rubber

Urethan coating

Contents/Precautions

Exterior case : white, pink, turquoise (back cover)

PC resin (with glass) + Silicon rubber

UV coating

Exterior case (earpiece)

PC resin Urethan coating

Transparent plate (camera)

PC + PMMA resin

AR treatment

Transparent plate (flash/photo light)

PC resin

―

Transparent plate (display)

Glass + PET resin

Hard coating

Side keys (power key, volume key) : turquoise only

PC resin Discontinuous

evaporation coating (tin) + UV coating

Side keys (power key, volume key) : black, white, pink

PC resin UV coating

Battery pack (contacts)

Copper alloy First nickel

plating/Gold plating

Battery pack (body) PP resin

―

Battery pack (label) PET resin UV coating Desktop holder

(upper case)

ABS resin

―

Desktop holder (lower case)

ABS resin

―

Desktop holder (lock)

POM resin

―

Desktop holder (button)

POM resin

―

Part Material

Surface

treatment

Desktop holder (contacts)

Phosphor bronze

Gold plating

Desktop holder (label)

Polyester resin

―

Desktop holder (rubber foot)

Polyester resin

―

Desktop holder (screws)

SWCH Black chromate

plating

1Seg antenna cable (headset jack : upper surface)

PP resin

―

1Seg antenna cable (headset jack : ring)

PC resin

―

1Seg antenna cable (headset jack : body)

Elastomer resin

―

1Seg antenna cable (cable)

Elastomer resin

―

1Seg antenna cable (plug : upper surface)

PP resin

―

1Seg antenna cable (plug : ring)

PC resin

―

1Seg antenna cable (plug : body)

Elastomer resin

―

1Seg antenna cable (plug : metal)

Brass Gold plating

Part Material

Surface

treatment

Contents/Precautions

■

Common precautions

･

SO-03E is waterproof/dustproof, however, do not allow water or dust to seep into the terminal and do not allow accessories or optional devices to get wet or dust.

The battery pack, adapter, desktop holder, docomo mini UIM card and 1Seg antenna cable are not waterproof/dustproof. Do not use in a bathroom or other highly humid area or do not let rain touch. Or putting them on your body, humidity of sweat may cause internal corrosion and malfunction. Note that malfunctions, which are determined to be caused by water as result of inspections, are outside the scope of the warranty. Since these conditions are outside of the scope of the warranty, a repair, if at all possible, is charged.

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

- Do not rub it roughly with a dry cloth. The display may be damaged.

- Drops of water or dirt left on the display may cause stains.

- Do not use alcohol, thinner, benzine, cleaning detergent, etc. to clean the terminal. These chemicals may erase the printing on the terminal or cause discoloration.

･

Clean the terminals occasionally with a dry cotton swab.

If the jack is soiled, connection gets worse and it may cause power to be turned off or insufficient battery charge, so clean the jack with a dry cotton swab etc. When cleaning, be careful not to damage the terminals.

･

Do not leave the terminal near the air conditioning vent.

Extreme temperature changes may produce condensation and corrode the internal parts of the terminal, causing it to malfunction.

･

Make sure to use the terminal, battery pack, etc. without excessive force.

If you put the terminal in a bag full of items or sit down with the terminal in the pocket of your cloth, it may damage the display, internal circuit board and battery pack, causing malfunction. If doing so while the external device is connected to the microUSB jack or headset jack, it may damage the connector and cause malfunction.

･

Do not rub or scratch the display with metal.

The display may get scratched and it may cause malfunction or damage.

･

Read the users manuals supplied with optional devices.

■

The terminal precautions

･

Do not press touch screen surface forcibly, or not operate with a sharppointed objects such as nail, ballpoint pen, pin, etc.

Doing so may cause damage of touch screen.

Handling precautions

Contents/Precautions

･

Do not use the terminal in extremely hot or cold places.

Use the terminal where the temperature ranges between 5

℃

and 40℃ (limited to the temporary

use for 36

℃

or more) and humidity ranges

between 45% and 85%.

･

Using the terminal near ordinary phone, television or radio may cause interference in these electric appliances. Make sure to move far away from them when using the terminal.

･

Note down the information saved in the terminal in a separate note and keep it safely.

Under no condition will DOCOMO be held liable for any damaged or lost data saved in the terminal.

･

Do not drop or give a strong impact to the terminal.

Doing so may cause malfunction or damage.

･

Do not insert the plug of the external device into the microUSB jack or headset jack at the slant or pull it obliquely while connecting.

Doing so may cause malfunction or damage.

･

The terminal could become warm while in use and charging. This condition is not abnormal. You can continue using the terminal.

･

Do not leave the camera under direct sunlight.

If you do so, some of the elements may melt or become faded.

･

Usually, use the terminal with microUSB jack cover and headset jack cover closed.

Failure to do so may get dust or water inside and cause malfunction.

･

Do not use the terminal with the back cover removed.

Doing so may cause removal of battery pack, malfunction or damage.

･

Do not remove the microSD card or power off the terminal while using the microSD card.

Doing so may cause data loss or malfunction.

･

Do not let magnetic cards, etc. close to the terminal.

The magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

･

Do not bring strong magnetic objects close to the terminal.

Strong magnetic objects may cause misoperation.

■

Battery pack

･

The battery pack is a consumable accessory.

Replace the battery pack if the terminal has extremely short operation time on a full charge, though it may vary by operating conditions. Purchase a new battery pack of the specified type.

Contents/Precautions

･

Charge the battery pack in an environment with the proper ambient

temperature (5

℃

to 35℃).

･

The operating time of the battery pack varies depending on the operating environment and the secular degradation of the battery pack.

･

The battery pack may swell out as it comes to near the end of its lifetime depending on the usage conditions, but it is not a problem.

･

Be careful especially about the following points when preserving the battery pack.

- The battery is fully charged (immediately after the charging is complete)

- The battery has run out (the phone cannot power on)

The performance and life of the battery pack may deteriorate. It is recommended that you store the internal battery with the remaining battery level of about 40% as a guide.

■

The adapter precautions

･

Charge the battery pack in an environment with the proper ambient

temperature (5

℃

to 35℃).

･

Do not charge in the following places.

- Places that are very humid, dusty or exposed to strong vibrations.

- Near ordinary phone or TV/radio.

･

The adapter cable could become warm while charging. This condition is not abnormal. You can continue using the terminal.

･

When using the DC adapter for charging, do not turn off the vehicle engine.

Doing so may cause the vehicle battery run out.

･

When you use the power outlet with a mechanism to prevent the plug from being removed, follow the instructions on the outlet's user's manual.

･

Do not give a strong impact to the adapter. Also, do not bend or deform the microUSB plug.

Doing so may cause malfunction.

■

docomo mini UIM card

･

Do not use unnecessary force to insert/ remove the docomo mini UIM card.

･

Note that DOCOMO assumes no responsibility for malfunctions occurring as the result of inserting and using docomo mini UIM card with another IC card reader/writer.

･

Always keep the IC portion clean when you use the card.

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

Contents/Precautions

･

Note down the information saved in the docomo mini UIM card in a separate note and keep it safely.

Under no condition will DOCOMO be held liable for any damaged or lost data saved in the terminal.

･

Take an expended docomo mini UIM card to sales outlet such as docomo Shop for proper disposal in order to protect the environment.

･

Do not carelessly damage, contact, or short-circuit an IC.

Doing so may cause data loss or malfunction.

･

Do not drop a docomo mini UIM card or subject it to impact.

Doing so may cause malfunction.

･

Do not bend a docomo mini UIM card or place a heavy object on it.

Doing so may cause malfunction.

･

Do not insert the docomo mini UIM card on which any label or seal is stuck into the terminal.

Doing so may cause malfunction.

■

Bluetooth function precautions

･

To secure the Bluetooth communication security, the terminal supports the security function compliant with Bluetooth standards, but the security may not be sufficient depending on the setting. Concern about the communication using the Bluetooth function.

･

Please be aware that DOCOMO is not responsible for data leak when making data communications using Bluetooth.

･

Frequency band

The frequency band used by the terminal's Bluetooth/wireless LAN function is written on the battery pack compartment. The label can be read as follows.

2.4 : This radio equipment uses the 2400 MHz band.

FH/XX/DS/OF

：

Modulation scheme is the FH-SS, other system, DS-SS, or OFDM system.

1 : The estimated interference distance is 10

m or less.

4 : The estimated interference distance is 40

m or less.

8 : The estimated interference distance is 80

m or less.

: The full band between 2400 MHz

and 2483.5 MHz is used and the band of the mobile identification device can be avoided.

Available channels vary depending on the country. For use in an aircraft, contact the airline beforehand.

Contents/Precautions

･

Bluetooth cautions

The operating frequency band of the terminal is used by industrial, scientific, consumer and medical equipment including microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (hereinafter referred to as "another station").

- Before using this equipment, confirm that "another station" is not being operated nearby.

- In the event of the terminal causing harmful radio wave interference with "another station", promptly change the operating frequency or stop radio wave emission by turning off the power, etc.

- If you have further questions, contact "General Inquiries" on the last page.

■

Wireless LAN (WLAN) precautions

･

Wireless LAN (WLAN) exchanges information using radio waves, and allows you to freely establish LAN connection if you are within an area where radio wave reaches. On the other side, if you communicate without appropriate security settings, communications may be intercepted or hacked by malicious parties. It is recommended to make necessary security settings on your responsibility and expense.

･

Wireless LAN

Do not use wireless LAN near magnetic devices such as electrical appliances or AV/OA devices, or in radio waves.

- Magnetism or radio waves may increase noises or disable communications (especially when using a microwave oven).

- When used near TV, radio, etc., reception interference may occur, or channels on the TV screen may be disturbed.

- If there are multiple wireless LAN access points nearby and the same channel is used, search may not work correctly.

･

2.4GHz device cautions

The operating frequency band of the WLAN device is used by industrial, scientific, consumer and medical equipment including home electric appliances such as microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (radio stations requiring a license).

- Before using the device, confirm that premises radio stations for identifying mobile units, specified low power radio stations and amateur radio stations are not being operated nearby.

- If the device causes harmful radio interference to premises radio stations for identifying mobile units, immediately change the frequency band or stop use, and contact "General Inquiries" on the last page for crosstalk avoidance, etc. (e.g. partition setup).

Contents/Precautions

- If the device causes radio interference to specified low power radio stations or amateur radio stations, contact "General Inquiries" on the last page.

･

5GHz device cautions

The following channel numbers and frequency bands are available in Japan.

5GHz wireless LAN device is prohibited to use outdoor by Law.

Channel number (Ch)

Frequency

band (MHz)

5.2GHz band

36 5,180 38 5,190 40 5,200 44 5,220 46 5,230 48 5,240

5.3GHz band

52 5,260 54 5,270 56 5,280 60 5,300 62 5,310 64 5,320

5.6GHz band

100 5,500 102 5,510 104 5,520 108 5,540 110 5,550 112 5,560 116 5,580 118 5,590 120 5,600 124 5,620 126 5,630 128 5,640 132 5,660 134 5,670 136 5,680 140 5,700

Channel number (Ch)

Frequency

band (MHz)

Contents/Precautions

■

FeliCa reader/writer function precautions

･

FeliCa reader/writer function of the terminal uses weak waves requiring no licenses for radio stations.

･

It uses 13.56 MHz frequency band. When using other reader/writers in your surroundings, keep the terminal away sufficiently from them. Before using the FeliCa reader/writer, confirm that there are no radio stations using the same frequency band nearby.

■

Note

･

Do not use altered terminal. Using an altered device is a violation of the Radio Law.

A "Technical Conformity Mark " affixed on the manufacturer's specification sticker certifies that the terminal meets technical regulations for specified radio equipment that are based on the Radio Law. If you remove the screws and alter the inside of the terminal, the technical regulations conformity certification becomes invalid. Do not use the terminal with the certification invalid, as it is a violation of the Radio Law.

･

Be careful when using the terminal while driving.

Using a handheld mobile phone while driving will result in a penalty. However, absolutely necessary cases such as rescue of a sick person or maintaining public's safety are exempted.

･

Use the FeliCa reader/writer function only in Japan.

FeliCa reader/writer function of the terminal conforms to Japanese radio standards. If you use this function overseas, you may be punished.

･

Do not alter the basic software illegally.

It is regarded as the software modification and Repairs may be refused.

Contents/Precautions

SO-03E provides waterproofness of IPX5*1, IPX7

and dustproofness of IP5X*3 with microUSB jack cover, headset jack cover and back cover firmly attached.

*1 IPX5 means that a phone keeps functioning

after applying a jet flow of 12.5 L/min. from every direction from a distance of approximately 3 m for at least 3 minutes using water nozzle in 6.3 mm inner diameter.

*2 IPX7 means that a phone keeps functioning

after SO-03E is slowly submerged to depth of 1 m in static tap water at room temperature, left there for 30 minutes and then taken out.

*3 IPX5 means a degree of protection that a

phone keeps functioning and can be used safely after left for 8 hours in equipment with dust particles in diameter of 75 µm or less that are stirred.

･

You can talk without an umbrella in the rain (for rainfall of 20 mm or less per hour).

- Do not open or close microUSB jack cover or headset jack cover when your hands are wet or waterdrops are attached to the terminal.

･

You can wash the terminal when it gets dirt or stained with liquid other than tap water.

- Wash the terminal with tap water at normal temperature (5

℃

-35℃) by weaker water

flow (less than 6 L/min.) at distance of approximately 10 cm away from the tap or shower.

- When washing the terminal, attach the back cover, then hold microUSB jack cover and headset jack cover so as not to open, and wash the terminal with your hands, not using brush or sponge. After washing, drain the terminal before use (P.28).

･

You can use at a poolside. Do not throw water from the pool on the terminal, or soak it in pool water.

Waterproofness/ Dustproofness

What you can do with waterproofness/dustproofness of SO-03E

Contents/Precautions

To avoid water ingress, be sure to observe the following points.

･

Do not throw any liquid other than room temperature tap water on the terminal, or soak it in such liquid.

･

Firmly close the microUSB jack cover, headset jack cover and back cover. Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between contact surfaces may allow water to enter.

･

Do not poke the microphone, earpiece, speaker, second microphone or strap hole with a sharp object.

･

Do not let the terminal fall. It may become scratched causing the waterproof/dustproof performance to degrade.

･

The microUSB jack cover, headset jack cover and the rubber gasket of the inner side of the back cover play important roles for keeping waterproof/dustproof performance. Do not remove or damage them. Also, prevent dust from adhering to it.

･

Do not peel off the round mesh sheet on the inner side of the back cover. Doing so makes waterproof ineffective.

■

Opening the microUSB jack cover and headset jack cover

Open the covers with your finger by the grooves.

■

Closing the microUSB jack cover and headset jack cover

Press the covers in the directions of the arrows and ensure there are no gaps.

■

Removing back cover

Insert the tip of your finger into the groove at the bottom of the terminal, and lift up the back cover in the direction of the arrow ( ).

To ensure waterproofness/ dustproofness

Contents/Precautions

■

Attaching back cover

Check the orientation of the back cover, and attach it to the terminal ( ), then press down the part firmly, and then check that there are no gaps between the terminal and back cover ( ).

･

Be careful not to hook the projection part on the edge of the back cover with finger when attaching the back cover.

It is recommended to replace the parts for maintaining waterproof/dustproof property once every two years regardless of whether any abnormality is present. DOCOMO replaces the parts as a chargeable service. Bring the terminal to a sales outlet such as a DOCOMO-specified repair office.

Do not perform actions shown in the illustrations below.

Observe the following precautions to use the terminal properly.

･

Accessories and optional devices are not waterproof/dustproof.

Important precautions

Washing with brush/sponge

Using Soap/Detergent/

Bath powder

Machine-

washing

Applying strong

water ow

Soaking in

ocean water

Using in hot

spring

Attaching sand/mud

Contents/Precautions

･

Do not apply water flow stronger than allowed (water flow of 6L/min. or more : e.g., such water flow that gives you pain when applied to your skin directly from a faucet or shower). SO-03E provides IPX5 waterproofness, but doing so may cause malfunction.

･

If the terminal gets wet with salt water, sea water, refreshing beverage or mud or sand adhered, wash it immediately. If they dry out, it is hard to remove the dirt and it may cause damage or malfunction.

･

Do not put the terminal in hot water, use it in a sauna or apply hot airflow (from a hair dryer etc.) to it.

･

Do not move the terminal in water or slam the terminal against the surface of water.

･

If you put the terminal in tap water, be sure to have it within 30 minutes.

･

When you use the terminal in swimming pool, obey rules of the facility.

･

The terminal does not float on water.

･

Do not leave water on the terminal. In cold region, the terminal freezes up and may cause malfunction.

･

Do not leave water on the microphone, earpiece, speaker, second microphone or strap hole. Such water may interfere with talking.

･

If the terminal gets splashed with water or other liquid while microUSB jack cover, headset jack cover or back cover is opened, the liquid may get inside the terminal causing electric shocks or malfunction. Stop using the terminal, turn off the power and contact a DOCOMO-specified repair office.

･

If the microUSB jack cover, headset cover, the rubber gasket of the inner side of the back cover is damaged or deformed, have it replaced at DOCOMO-specified repair office.

･

Waterproof is not effective while using the 1Seg antenna cable.

DOCOMO does not guarantee actual operations under all states. Malfunctions deemed to be caused by inappropriate operation by the customer are not covered by the warranty.

+ 241 hidden pages
