Sony SUPW1 User Manual

For Customers and Sony Dealers

in North and Central America

Wall-Mount Bracket

4-092-246-12 (1)

Instructions Manuel d’instructions Manual de instrucciones

US FR ES

SU-PW1

Thank you for purchasing this product.

To Customers

Sufficient expertise is required for installing this product. Be sure to subcontract the installation to Sony dealers or contractors and pay adequate attention to safety during the installation.

WARNING

If the safety precautions are not observed and the product is used incorrectly, it may result in a fire or serious injury. This instruction manual shows the important precautions necessary to prevent accidents and to promote the correct handling of the product. Be sure to read this instruction manual thoroughly and use the product correctly. Be sure to keep this instruction manual available for future reference.

For Sony Dealers

Sufficient expertise is required for installing this product. Be sure to read this instruction manual thoroughly to do the installation work safely. We are not liable for any damage or injury caused by mishandling or improper installation. After installation, please hand this installation manual to the customers.

This Wall-Mount Bracket is designed by Sony for use with the specified product. Do not use this bracket with equipment other than the following product.

Specified product: Flat panel Color Television (KE-42XBR900/KE-50XBR900)

On Safety

Products by Sony are designed with safety in mind. If the product is used incorrectly, however, it may result in serious injury through a fire, an electric shock or by causing the product to topple over. Be sure to observe the proper safety precautions to prevent accidents.

2 (US)

For Customers

WARNING

If the following precautions are not observed, there is a possibility of either death or serious injury through a fire, an electric shock or an explosion.

Be sure to subcontract the installation to qualified contractors and keep small children away during the installation.

If persons other than qualified contractors install the Wall-Mount Bracket, the following accidents may happen.

• The Display Unit may fall and cause a serious injury such as a bruise or a fracture during an earthquake.

• If the wall on which the Wall-Mount Bracket is installed is unstable, uneven, or not perpendicular to the floor, the unit may fall and cause injury or property damage. The wall should be capable of supporting a weight of at least four (4) times the Display Unit weight (KE-42XBR900: 53 kg (116 lb 14 oz) × 4 = 212 kg (467 lb 6 oz), KE-50XBR900: 39 kg (85 lb 16 oz) × 4 = 156 kg (343 lb 15 oz)).

• If the installation of the Wall-Mount Bracket on the wall is not sufficiently sturdy, the unit may fall and cause injury or property damage.

Be sure to subcontract the installation to qualified contractors when moving or dismounting the Wall-Mount Bracket.

If persons other than qualified contractors transport or dismount the Wall-Mount Bracket, the Display Unit may fall and cause injury or property damage. Be sure that two or more persons carry or dismount the Wall-Mount Bracket.

Do not spill liquid of any kind on the Display Unit.

If you allow the Display Unit to get wet, this may result in a fire or an electric shock.

Do not remove bolts, etc., after mounting the Display Unit.

If you do so, the Display Unit may fall.

Do not disassemble or make alterations to the parts of the Wall-Mount Bracket.

If you do so, the Wall-Mount Bracket may fall and cause injury or property damage.

English

Do not mount any equipment other than the specified product.

This Wall-Mount Bracket is designed for use with the specified product. If you mount equipment other than the specified product, it may fall and cause injury or property damage.

3 (US)

Do not block the ventilating holes on the Display Unit.

If you block the ventilating holes on the Display Unit by covering the top of the Display Unit with a cloth or the like, the Display Unit may become overheated and this may cause a fire.

Do not apply any load other than the Display Unit on the Wall-Mount Bracket.

If you do so, the Display Unit may fall and cause injury or property damage.

Do not lean on or hang from the Display Unit.

The Display Unit may fall and the user may be caught under the weight of the unit and suffer serious injury.

To prevent a fire or an electric shock, do not expose the Display Unit to rain or moisture.

If you allow the Display Unit to get wet, this may result in a fire or an electric shock.

Never place the Display Unit in hot, humid or excessively dusty places. Do not install the Display Unit where it may be exposed to mechanical vibrations.

If you do so, this may cause a fire or an electric shock.

Keep flammable objects or open flames (e.g. candles) away from the Display Unit.

To prevent a fire, keep flammable objects or open flames (e.g. candles) away from the Display Unit.

4 (US)

CAUTION

If the following precautions are not observed, there is a possibility of injury or property damage.

Do not install the Wall-Mount Bracket on wall surfaces where the corners or the sides of Display Unit would protrude away from the wall surface.

Do not install the Wall-Mount Bracket on wall surfaces such as a pillar, where the corners or the sides of Display Unit would protrude away from the wall surface. If a person or object happens to hit the protruded corner or side of the Display Unit, this may cause injury or property damage.

Do not handle the product with excessive force during cleaning or maintenance.

Do not apply excessive force on the topside of the Display Unit. If you do so, this may cause injury or property damage by causing the Display Unit to fall.

Do not install the Display Unit over or under an air-conditioner.

If you do so, the Display Unit may be exposed to air currents from the air-conditioner. This may result in a malfunction of the Display Unit.

Precautions

• If you use the Display Unit installed on the Wall-Mount Bracket for a long time, the wall behind or above the Display Unit may become discolored or the wallpaper may come unstuck, depending on the material of the wall. If the Wall-Mount Bracket is removed after installing them on the wall, the screw holes are left.

• If you have routed 300 ohm feeder cables behind the wall, we recommend that you change them to 75 ohm coaxial cables. If it is necessary to continue to use 300 ohm feeder cables, be sure to confirm that sufficient space is available between the Display Unit and the feeder cables behind the wall before starting the installation. Consult your contractor on an appropriate installation location where the Display Unit suffers no radio noise before starting the installation.

5 (US)

Install the Wall-Mount Bracket

For Sony Dealers

WARNING To Customers

Sufficient expertise is required for installing this product. Be sure to subcontract the installation to Sony dealers or contractors and pay adequate attention to safety during the installation.

To Sony Dealers

The following instructions are for Sony Dealers only. Be sure to read safety pr ecautions described above and pay adequate attention to safety during the installation, maintenance and checking of this product.

Be sure to install the Wall-Mount Bracket securely to the wall following the instructions in this instruction manual.

If any of the screws are loose or fall out, the Wall-Mount Bracket may fall and cause injury or property damage. Be sure to use the appropriate screws for the material of the wall and install the unit securely, using eight or more M8 or the equivalent screws.

Do not allow the Power Cord or the Display Cable to be pinched.

If the Power Cord or the Display Cable is pinched between the unit and the wall or is bent or twisted by force, the metallic part of the cord or cable may be exposed and cause a short circuit or a break in the cord or cable. This may cause a fire or an electric shock.

Be sure to use the supplied screws and attachment parts properly following the instructions given in this instruction manual. If you use substitute items, the Display Unit may fall, and cause bodily injury to someone or damage to the Display Unit.

Be sure to assemble the bracket properly following the instructed procedure explained in this instruction manual.

If any of the screws are loose or fall out, the Display Unit may fall, and cause bodily injury to someone or damage to the Display Unit.

Be sure to tighten the bolts and screws securely in the designated position.

If you fail to do so, the Display Unit may fall, and cause bodily injury to someone or damage to the Display Unit.

Be careful not to subject the Display Unit to shock during installation.

If the Display Unit is exposed to shock, it may fall or break apart. This may cause injury.

6 (US)

Be sure to install the Display Unit on a wall that is both perpendicular and flat.

If you fail to do so, the Display Unit may fall and cause injury.

After proper installation of the Display Unit, secure the cables properly.

If people or objects get tangled in the cables, this may result in injury.

Be careful not to hurt your hands or fingers during the installation.

Be careful not to hurt your hands or fingers when installing the Wall-Mount Bracket or the Display Unit.

The screws needed to secure the Wall-Mount Bracket to the wall are not supplied.

Use the appropriate screws for the wall material and structure when mounting the Wall-Mount Bracket.

Step 1: Check the parts required for the installation

Prepare a Phillips driver and the

appropriate screws (eight or more M8 or the equivalent screws, not supplied), depending on the material of the wall, beforehand.

Open the package and check the parts.

Screws (+PSW5 × 12) (2) Plate Unit (1) Mounting Hook Unit (2)

7 (US)

Step 2: Decide on the installation location

Unit: mm (inches)

300

)

⁄ (11

Be sure to keep the distance between the Plate Unit and the ceiling or the protruding parts of the wall as shown in the diagram on the left.

100

⁄16)

)

⁄

100 (3

100

⁄16)

Tip

See the cross section diagram in “Specifications” (p.15 (US)) for details on dimensions when the Display Unit is installed on the wall.

Step 3: Install the Plate Unit on the wall

Align the unit so that it is exactly level.

Plate Unit

Screw hole to be used for temporarily attaching the bracket.

Screw the Plate Unit to the wall temporarily and align the position of the Plate Unit so that it is exactly level.

WARNING

• The screws securing the Wall-Mount Bracket to the wall are not supplied.

• Be sure to use the appropriate screws, depending on the material and structure of the wall.

8 (US)

KE-42XBR900/KE-50XBR900

Fix the Plate Unit to the wall using eight or more M8 or the equivalent screws (not supplied).

1Be sure to tighten the screws securely so that they

will not come loose.

2Firmly tighten the screw screwed in temporarily in

Procedure 1.

WARNING

•We recommend using the screw hole locations specified in the diagram on the left when attaching the Plate Unit temporarily. If the Plate Unit cannot be attached securely enough, use additional screws.

• Be sure to confirm that the Plate Unit is securely fixed to the wall.

)

⁄

35 (1

)

330 (13)

)

⁄

35 (1

110

⁄ (4

)

⁄ (4

)

⁄ (4

530 (20 7⁄8)

140 (5 1⁄2)

600 (23 5⁄8)

)

⁄

400 (15

KE-50XBR900 Unit: mm (inches)

ABCDEF

1,573 856 342 86 244 184

(61 15⁄16) (33 11⁄16) (13 15⁄32) (3 3⁄8) (9 19⁄32) (7 1⁄4)

KE-42XBR900 Unit: mm (inches)

ABCDEF

1,352 720 208 152 178 182

(53 7⁄32) (28 11⁄32) (8 3⁄16) (5 31⁄32) (7) (7 5⁄32)

9 (US)

Adjust the angle of the arms.

1Take out the screws from the right and left sides of

the arm base. Then choose the notch corresponding to the desired angle (0, 5, 10, 15 or 20 degrees) and fit the arm base to it.

2Firmly secure each arm base using the screws taken

out in Procedure 1.

Note

Be sure to adjust the angles of the right and the left arms to the same angle.

•0 degrees: Leave the white screws as they are tightened.

• Other than 0 degrees: Take out the white screws.

10 (US)

Step 4: Install the Display Unit

WARNING

Be sure to complete the installation before connecting the Power Cord to the wall outlet. If you allow the Power Cord to be pinched under or between pieces of equipment, this may result in a short circuit or an electric shock. If you stumble over the Power Cord or the Display Interface Cable, the stand may topple over, and this may result in injury.

Hitch the Mounting Hook Unit on

the hooks on the rear side of the Display Unit. Then slide the Mounting Hook Unit and fix it using the supplied screws (+PSW5 × 12).

Soft rag such as a blanket

Rear side of the Display Unit

11 (US)

Connect the Power Cord and the Display Cable supplied with the Display Unit to the Display Unit.

Connect the Power Cord and the Display Cable to the connectors on the rear side of the Display Unit.

Tip

See the instruction manual of the Flat Panel Color Television (KE-42XBR900/KE-50XBR900) for more details on connecting the Power Cord and the Display Cable.

Power cord and Display Interface Cable

Fasten the Display Interface Cable and the Power Cord to the wall, etc. When you route the cable and the cord in the wall, bore a 50 mm diameter hole in the wall as shown in the diagram in the left.

inches)

⁄

10 mm (

12 (US)

Install the Display Unit on the Plate Unit.

1Hold the Display Unit and bring it close to the Plate

Unit so as to align the lower hooks of the Mounting Hook Units with the lowest support shafts near the bottom of the Plate Unit.

2Hitch the upper and lower hooks of the two

Mounting Hook Units onto the four support shafts of the Plate Unit all at the same time as shown in the diagram on the left.

3Confirm the eight hooks are firmly hooked on the

four shafts on the Plate Unit.

4Firmly tighten the securing screws on the right and

the left with a long shaft Phillips screwdriver.

13 (US)

Removing the Display Unit

For Sony Dealers

Unplug the Power Cord from the wall outlet.

Loosen the securing screws on the right and left until they will not turn any more.

Be sure that two or more persons hold the Display Unit and slide it upward to remove the Display Unit.

WARNING

• Be sure that two or more persons hold the Display Unit when carrying it.

• Be careful not to allow the cords and cables to get hung up when removing the Display Unit.

• Be careful not to hurt your hands or fingers when removing the Display Unit.

14 (US)

Specifications

Unit: mm (inches) Weight: 8.0 kg (17 lb 10 oz)

Design and specifications are subject to change without notice.

Angle

)

⁄

385 (15

600 (23 5⁄8)

)

⁄

400 (15

51 (2)

KE-42XBR900 Unit: mm (inches)

Angle Dimensions

a ABCDE

0°

720 160 173 400 147

(28 11⁄32) (6 5⁄16) (6 13⁄16) (15 3⁄4) (5 25⁄32)

5°

10°

720 207 162 400 156

(28 11⁄32) (8 5⁄32) (6 3⁄8) (15 3⁄4) (6 5⁄32)

720 253 148 400 164

(28 11⁄32) (9 31⁄32) (5 13⁄16) (15 3⁄4) (6 15⁄32)

15°

720 297 130 400 172

(28 11⁄32)(11 11⁄16) (5 1⁄8) (15 3⁄4) (6 25⁄32)

20°

720 339 108 400 178

(28 11⁄32) (13 11⁄32) (4 1⁄4) (15 3⁄4) (7)

KE-50XBR900 Unit: mm (inches)

Angle Dimensions

a ABCDE

0°

856 166 307 400 149

(33 11⁄16) (6 17⁄32) (12 3⁄32) (15 3⁄4) (5 7⁄8)

5°

856 225 296 400 160

(33 11⁄16) (8 27⁄32)(11 21⁄32) (15 3⁄4) (6 5⁄16)

10°

856 283 280 400 169

(33 11⁄16)(11 5⁄32)(11 1⁄32) (15 3⁄4) (6 21⁄32)

15°

856 338 260 400 177

(33 11⁄16) (13 5⁄16) (10 1⁄4) (15 3⁄4) (6 31⁄32)

20°

856 391 235 400 183

(33 11⁄16) (15 13⁄32) (9 1⁄4) (15 3⁄4) (7 7⁄32)

15 (US)

*FOR RESIDENTS OF THE UNITED STATES / POUR LES HABITANTS DES ETATS-UNIS /

PARA RESIDENTES DE LOS ÉSTADOS UNIDOS

LIMITED W ARRANTY

Sony Electronics, Inc. (“Sony”) warrants this product against defects in material or workmanship, subject to any conditions set forth as follow:

1. This warranty is expressly limited to the replacement of Sony Wall-Mount Bracket parts and components.

2. For a period of 30 days from the date of purchase, Sony will supply parts that are determined to be defective or missing, at no charge, to the original purchaser. After the warranty period, you will be charged for all orders.

This warranty does not cover damages which occur in shipment or failures due to acts of God, accident, misuse, abuse, negligence, faulty installation, misapplication, setup, improper maintenance, commercial use, or modification of, or to any part of the product. This warranty does not cover Products sold AS IS or WITH ALL FAULTS. This warranty is valid only in the United States.

Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence that the unit is within the warranty period, must be presented to obtain the replacement parts.

REPLACEMENT PARTS AS PROVIDED UNDER THIS WARRANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER SONY SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANT TION OF THIS WARRANTY.

ABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURA-

Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the abo which vary from state to state.

In order to obtain replacement parts, you must provide a PROOF OF PURCHASE and complete the information on this warranty card. Fax or mail these to:

Name: ______________________________________________________________________________________________

Address: ____________________________________________________________________________________________

City: _____________________________ State: _____________ Zip Code: ______________ Phone: __________________

Model: __________________________________

Part No. Description Quantity Reason

____________ ________________________________ ___________ _____________________________________ ____________ ________________________________ ___________ _____________________________________ ____________ ________________________________ ___________ _____________________________________ ____________ ________________________________ ___________ _____________________________________

ve limitations or

exclusions may not apply to you. This warranty gi

ves you specif

•

ic legal rights, and you may ha

ve other rights

*FOR RESIDENTS OF CANADA / POUR LES HABITANTS DU CANADA / PARA RESIDENTES DE CANADIENSES

Please examine all packaging

materials before discarding.

If any parts are missing or damaged,

please review the parts list found

in the assembly manual,

identify the missing or damaged part,

and call the Sony Customer

Service Center at

1-877-779-9929

Veuillez examiner tout l’emballage

avant de le jeter. Si des pièces sont

manquantes ou endommagées,

veuillez vérifier les pèces qui se trouvent

dans le manual de montage,

identifier les pieces manquantes ou

endommagées, et appeler

le service client de Sony Au numéro”

1-877-779-9929

Por favor examine todo el material

de empaque antes de tirario.

Si cualquier parte resulta

faltante o está dañada, por favor

revise la lista de partes que se encuentra en el manual de ensamble, identifique la parte dañada of faltante,

y llame al centro servicio

al cliente de Sony al

1-877-779-9929

+ 36 hidden pages
