Page 1
Digital Color Printer
UP-D9500
Page 2
A Digital Color Printer with High Quality and Great Versatility
Dual mode versatility gives you the choice of vibrant color reproduction using dye
sublimation technology or an economical simulation of off-set printing using variable dot printing.
Page 3
Selectable Printing Methods
Dye Sublimation for Brilliant Color
Prints
The Sony UP-D9500 with dye sublimation
media provides full, 24-bit continuous tone
CMYK printing. From your first color test to
your final contract proof, advanced dye
sublimation printing technology provides
you vibrant, clear, reliable color reproduction
on standard glossy paper.
Dye sublimation
printing
Variable Dot Printing for Off-Set Print
Matching
The UP-D9500 with variable dot printing
technology produces a print that is similar in
dot size, and finish to off-set printing. Ideal
for proofing layouts, image data, color and
off-set print work, variable dot printing is
accurate, consistent and economical.
Press Satelite
Digital
Press
Press Center
Digital
Press
Creative at Client
Digital
Proof
Printer
Commercial Creative
Digital
Proof
Printer
Imaging for Remote Proofing
Stable Color Reproduction
Consistent color reproduction is critical for
any proofing application. From remote
proofing applications with multiple matched
printers to a single in-house system, the UPD9500 delivers precise color registration and
color consistency by utilizing two unique
technologies: (1) a Sony Paper Chucking
Drum which establishes precise paper
registration during the printing process; and
(2) automatic ribbon lot compensation which
adjusts the printer for minor variation in media
production lots. These two unique features
coupled with the advanced design of the UPD9500 ensure consistent, accurate color prints,
print after print.
Color Ink Ribbon
Digital
Proof
Printer
Digital
Proof
Creative at Client
Printer
Digital
Proof
Printer
Large Print Area and
Paper Size Ideal for Proofing
With an image size of 458 x 323 mm (18 1/8 x
3
12
/4 inches) on paper measuring 523 x 330
mm (20
5
/8 x 13 inches), half-inch registration
marks and color patches can be easily printed
alongside a standard two page spread. This
gives you the color controls and versatility you
need for professional proofing.
A4++ print paper for A4 and letter size proof will soon be available.
*
523 (205/8) mm
1
/8) mm
458 (18
Letter
Tabloid
A3
323 (12
330 (13) mm
3
/
4
) mm
Variable dot
printing
Paper
Digital Color Printer UP-D9500
Chucking Drum
A4
A3++ Paper Size
A4++ Paper Size
Flexible Color Matching
The UP-D9500 incorporates standard preset
color tables such as SWOP, Commercial,
JapanColor and EuroColor, ideal for press
color matching. Beyond these standard color
tables, you can achieve a precise simulation of
a target press by creating an original color
table. This is done measuring press proofs of
IT8.7/3 color patches via a spectrophotometer,
such as the Gretag Spectrolino & SpectroScan,
and downloading this table to the UP-D9500.
A Variety of
Professional Interfaces
Compatibility with Macintosh
■
Windows
Quick Data Transfer supporting
■
EtherTalk 10Base5 and 10Base-T
Incorporates Adobe PostScript
■
Level 2 Interpreter
Large capacity HDD (Hard Disk Drive)
■
for spool printing and font downloads
Supports DCS (Desktop Color
■
Separation) format file
TM
95/NT operation systems
TM
Unit:mm (inch)
and
Page 4
Specifications
Printing method:
Resolution:
Gradation:
Printing paper size:
Printed picture size:
Picture elements:
Picture memory:
HDD:
Printing time:
Interface port*3:
Power requirements:
Power consumption:
Dimensions:
Mass:
Safety regulations:
Supplied software:
Supplied accessories:
Optional accessories:
Dye sublimation thermal transfer
Variable dot thermal transfer
300 x 300 dpi, 300 x 600 dpi (dye sublimation only)
256 gradations for Yellow, Magenta, Cyan and Black
A3++ : 330 x 523 mm (13 x 20 5/8 inches)
A4++*1: 330 x 307 mm (13 x 12 1/8 inches)
A3++ : Max. 323 x 458 mm (12 3/4 x 18 1/8 inches)
A4++*1: Max. 323 x 242 mm (12 3/4 x 9 5/8 inches)
Max. 3810 x 5408 dots (300 x 300 dpi mode),
3810 x 10816 dots (300 x 600 dpi mode)
32 MB
2 GB
A3++ : Approx. 250 seconds (300 x 300 dpi mode)
A4++*1: Approx. 170 seconds (300 x 300 dpi mode)
LocalTalk, Parallel, 10 Base-T, 10 Base5, SCSI
UC: 120 V, 50/60 Hz
CE: 220 to 240 V, 50/60 Hz
UC: 3.3 A
CE: 1.8 A
510 (W) x 310 (H) x 642(D)mm
(20 1/8 x 12 1/4 x 25 3/8 inches)
40 kg (88 lb 3 oz)
UC: UL1950, CSA C22.2 No.950
CE: EN60950
(For Macintosh OS and Windows 95/NT OS)
PS Printer driver, PPD file and PDF file for QuarkXPress
Photoshop Plug-in Module
Network/Color Matching Utility and IT8.7/3 color patch digital data
ICC profile (2)
On-line Manual in Adobe Acrobat 's PDF format
Ink Ribbon Holder
Paper Tray (1)
AC Power Cable
Operation Manual
A3++ Size Dye Sublimation Print Paper (60 sheets x 3 packs) UPP-9510
A3++ Size Dye Sublimation Color Ink Ribbon (180 prints) UPR-9510
A4++ Size Dye Sublimation Print Paper(60 sheets x 4 packs) UPP-9511*1
A4++ Size Dye Sublimation Color Ink Ribbon (240 prints) UPR-9511
A3++ Size Variable Dot Print Paper (60 sheets x 3 packs) UPP-9550
A3++ Size Variable Dot Color Ink Ribbon (180 prints) UPR-9550
A4++ Size Variable Dot Print Paper (60sheets x 4 packs) UPP-9551
A4++ Size Variable Dot Color Ink Ribbon (240 prints) UPR-9551
Ink Ribbon Holder (with cover) UPA-9500
Add-On Memory Kit (32 MB) UPK-9500
*1
Will soon be available.
*2 Using the optional UPK-9500 add-on Memory Kit ,
the picture memory of the UP-D9500 will be expandable
up to 128 MB. In 300 x 600 dpi mode during dye
sublimation printing, the UP-D9500 requires 64 MB
of picture memory.
Windows is a trademark of Microsoft Corporation.
Macintosh , EtherTalk and LocalTalk are trademarks of
Apple Computer Inc.
Adobe, PostScript, Photoshop and Acrobat are trademarks
of Adobe Systems Incorporated.
QuarkXPress is a trademark of Quark, Inc.
*2
Rear Panel Connector Section
TM
642(25
3
/
8
)
*1
*1
*1
510 (201/8)
Distributed by
MK4218/2SMC-9803
310 (12
1
/
4
)
Unit:mm (inch)
Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony is a trademark of Sony Corporation.
Features and specifications subject to change without notice.
Printed in Japan
C
1998 Sony Corporation
