INSTRUCTION MANUAL

15.5

Introduction

Thank you for your purchase of "SO-04G".

For proper use of the SO-04G, read this manual carefully before and while you use the SO-04G.

About manuals of SO-04G

In addition to this manual, the operations of SO-04G are described in "

Guide)" (in Japanese only) and "Instruction Manual" application of the terminal (in Japanese only).

●"クイックスタートガイド

(Supplied accessories)

The initial operations and settings after purchasing the terminal, screen view contents and operations of main function are explained.

●

"Instruction Manual" (Application of the terminal)

Operations and settings of each function are explained. To use "Instruction Manual" application, from the Home screen, When using for the first time, download and install the application according to the onscreen instructions. If you uninstall "Instruction Manual" application, access to Google Play from Play Store to download it again. From the Home screen, tap [Play Store], search " application to select, then install it following the onscreen instructions. You can use the application as an electronic book. You can also shift to actual operations by tapping the description in the contents or view reference contents.

クイックスタートガイド

(Quick Start Guide)"

[Instruction Manual].

取扱説明書

(Instruction Manual)"

(Quick Start

●

"Instruction Manual" (PDF file)

Operations and settings of each function are exp lain ed. It can b e down load ed fro m NTT DOCOM O website. https://www.nttdocomo.co.jp/english/support/ trouble/manual/download/index.html

* You can download the latest information of "

イックスタートガイド

URL and contents are subject to change without prior notice.

❖

Note

･

Reproduction or reprint of all or part of this manual without prior permission is prohibited.

･

Important information for SO-04G is posted in the following website. Be sure to check before using. http://www.sonymobile.co.jp/support/use_support/ product/so-04g/ (In Japanese only)

(Quick Start Guide)". The

ク

Operation descriptions

In this manual, each key (key icon) operation is described with selection operations of the icons or function items on the touch screen are described as follows.

From the Home screen,

[About phone].

Touch and hold an icon.

❖

Information

･

Display examples and illustrations used in this manual are just images for explanations and may be different from actual ones.

･

In this manual, the easier procedure is described for the functions and settings which have multiple operating procedures.

･

Please note that "SO-04G" is called "the terminal" in this manual.

･

In this manual, explanations for "docomo LIVE UX" as Home application are provided (P.63).

･

In this manual, the instructions are described with the default Home screen. If you set the other application to the home screen, the operations may differ from the descriptions.

P, k, b, h, n

Description Operation

From the Home screen, tap (Apps button), and then tap

[Settings]

"Settings" on the next screen and "About phone" on the following screen in order.

Keep touching an icon longer (12 seconds).

. And

Supplied accessories

･

SO-04G (with warranty)

･

Desktop Holder SO26 (with warranty)

･

クイックスタートガイド

(In Japanese only)

(Quick Start Guide)

･

のご利用にあたっての注意事項

SO-04G

安全上／取り扱い上のご注意

(Notes on usage Safety/Handling precautions) (In Japanese only)

･

1Seg antenna cable SO02

For optional accessories compatible with the terminal (optional) , refer to NTT DOCOMO website. https://www.nttdocomo.co.jp/product/ option/ (In Japanese only)

■

Supplied accessories. . . . . . . . . . . . . . . . . 2

■

About using the terminal . . . . . . . . . . . . 5

■

Safety Precautions (Always follow these

directions) . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■

Handling precautions. . . . . . . . . . . . . . . 17

■

Waterproofness/Dustproofness . . . . . 24

Before Using the Terminal . . . 30

Part names and functions................................................30

docomo nano UIM card.................................................... 31

Charging.....................................................................................33

Turning power on/off......................................................... 39

Initial settings........................................................................... 40

Basic operations.....................................................................41

Notification LED .....................................................................45

Status bar ................................................................................... 45

Notification panel .................................................................48

Quick settings panel............................................................ 48

Home screen............................................................................ 49

™

Xperia

Application screen .......................................... 55

Task manager...........................................................................62

Switching Home application.........................................63

Searching information in the terminal and web

pages ............................................................................................ 64

Character entry....................................................................... 64

Setting character entry...................................................... 70

docomo LIVE UX . . . . . . . . . . . . 71

Home screen............................................................................ 71

Managing the Home screen ..........................................71

Application screen................................................................ 73

Display all apps....................................................................... 75

Backing up and restoring the Home screen........ 75

Using My Magazine............................................................. 76

Checking Home application information.............. 77

Phone . . . . . . . . . . . . . . . . . . . . . . 78

Making/Receiving a call .................................................... 78

Operations during a call ................................................... 83

Call history................................................................................. 85

Call settings .............................................................................. 87

Phonebook ............................................................................... 89

Mail/Web browser . . . . . . . . . . . 94

docomo mail ........................................................................... 94

Message (SMS)........................................................................ 94

Email.............................................................................................. 97

Gmail.......................................................................................... 101

Early Warning "Area Mail".............................................. 102

Browser..................................................................................... 103

Apps. . . . . . . . . . . . . . . . . . . . . . .106

dmenu...................................................................................... 106

dmarket.................................................................................... 106

Play Store ................................................................................ 106

Osaifu-Keitai .......................................................................... 108

1Seg............................................................................................ 112

FM radio................................................................................... 118

Camera ..................................................................................... 119

Album ....................................................................................... 133

YouTube .................................................................................. 135

Media Player.......................................................................... 135

Location services................................................................ 137

Schedule.................................................................................. 140

Content s/Precautio ns

Alarm & clock........................................................................ 141

docomo backup ................................................................. 143

Settings . . . . . . . . . . . . . . . . . . . 146

Viewing the setting menu............................................ 146

Wireless & networks.......................................................... 146

Device........................................................................................ 156

Personal.................................................................................... 162

System....................................................................................... 171

File management . . . . . . . . . . 174

Storage structure................................................................ 174

File operation........................................................................ 176

Data communication . . . . . . . 178

Bluetooth function............................................................ 178

NFC communication........................................................ 180

External device connection . 183

Connecting to PC............................................................... 183

Connecting DLNA device ............................................. 186

International roaming . . . . . . 188

Overview of International roaming (WORLD

WING)......................................................................................... 188

Available overseas service ............................................ 188

Before using overseas...................................................... 189

Making/Receiving a call in the country you stay

....................................................................................................... 191

International roaming settings.................................. 193

After returning to Japan................................................. 195

Appendix/Index . . . . . . . . . . . .196

Troubleshooting................................................................. 196

あんしん遠隔サポート

....................................................................................................... 203

Warranty and After Sales Services ........................... 204

Software Update ................................................................ 208

Connecting to a PC to upgrade................................ 211

Main specification ............................................................. 212

Certificate and compliance ......................................... 217

Specific Absorption Rate of Mobile Phone, etc.

....................................................................................................... 217

End User Licence Agreement .................................... 229

Export Controls and Regulations ............................. 230

Intellectual Property Right ........................................... 230

SIM unlock.............................................................................. 234

Index .......................................................................................... 235

(Anshin Enkaku Support)

Content s/Precautio ns

Contents/Precautions

About using the terminal

･

The terminal supports LTE, W-CDMA, GSM/

GPRS and Wireless LAN Systems.

･

Because a terminal operates using radio

frequencies, it cannot be used inside a tunnel,

underground, in a building or other locations

where radio waves do not reach the terminal,

in locations with weak radio wave condition,

or out of Xi/FOMA service area. The services

may not be available on the upper floors of

high-rise apartments or buildings, even if

there are no obstructions around you. On

occasion, your calls may become

disconnected even in areas with strong radio

wave condition, even if you are not moving, or

even if there are 4-signal icon in the terminals

display.

･

Because your terminal uses radio waves to

communicate, it is possible that a third party

may attempt to tap your calls. However, the

LTE, W-CDMA, GSM/GPRS system

automatically scrambles all calls through a

private call feature. Therefore, even if the third

party successfully intercepts your call, they

will only hear noise.

･

The terminal operates on radio frequencies by converting voice into digital signals. If the caller moves into an area of adverse radio wave condition, the digital signal may not be restored accurately, and the voice received in the call may differ slightly from the actual voice.

･

Note down the information saved in the terminal in a separate note on a regular basis or save to an external recording medium such as a microSD card or PC. Note that DOCOMO assumes no responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the model or other handling of the terminal.

･

As with PCs, some user-installed applications may disrupt the stability of the terminal performance, or unexpectedly transmit information via the Internet causing improper use of your location information as well as personal information recorded on the terminal. Therefore, verify the supplier and operating conditions of the applications to be used before using them.

･

This terminal has FOMA Plus-Area and FOMA HIGH-SPEED Area support.

･

The terminal does not support i-mode sites (programs) or i-

ppli.

Content s/Precautio ns

･

The terminal automatically performs

communication for synchronizing data,

checking the latest software version, and

maintaining a connection with the server, and

for other purposes. If you transmit a large

amount of data, such as when downloading

applications or watching video, a packet

communication charge becomes high.

Subscription to Packet Pack/packet flat-rate

service is highly recommended.

･

Depending on the applications or service you

use, packet communication charge may be

applied even in Wi-Fi communication.

･

Public mode (Driving mode) is not supported.

･

Setting the terminal to silent mode does not

mute sounds for shutter, playback of video or

music, dialpad operation sound during a call

or sound emitted when is tapped, etc.

･

The name of the operator is displayed on the

lock screen (P.40).

･

To check your phone number (own number),

from the Home screen,

[Settings]u[About phone]u[Status] to

see "My phone number".

･

To check the software version, from the Home

screen,

･

If available memory in the microSD card or

[Settings]u[About phone].

the terminal is low, running applications may

not operate correctly. In that case, delete the

saved data.

･

You can update software on the terminal to the latest one (P.208, P.211).

･

The operating system (OS) may be upgraded via software updates to improve the quality of the terminal. For this reason, you always need to use the latest OS version. And some applications that used in the previous OS version may not be available or some unintended bugs may occur.

･

You can use the terminal only with a docomo nano UIM card. If you have a docomo mini UIM card, UIM, or FOMA card, bring it to a docomo Shop to replace it with a docomo nano UIM card.

･

Set password etc. for screen lock to ensure the security of your terminal for its loss (P.167).

･

If your terminal is lost, change your each account password to invalidate authentication using a PC to prevent other persons from using Google services such as Gmail or Google Play, or SNS, etc.

･

For services provided by Google, refer to Google Terms of Service. For other web services, refer to each terms of service.

･

Applications and service contents are subject to change without prior notice.

･

The terminal supports only sp-mode, mopera U and Business mopera Internet. Other providers are not supported.

･

To use tethering, subscription of sp-mode is required.

Content s/Precautio ns

･

If you want to use tethering, subscription to

Packet Pack/packet flat-rate service is strongly

recommended.

･

For details on usage charge, refer to NTT

DOCOMO website.

･

Display is manufactured by taking advantage

of highly advanced technology but some

dots may be always or never lit. Note that, this

shows characteristics of liquid crystal displays

and not defects in the terminals.

･

DOCOMO is not liable to any failures or

malfunctions for commercially available

optional equipment.

Safety Precautions (Always follow these directions)

■

For safe and proper use of the terminal, plea se read the "Safety Precautions" prior to use. Keep the Manual in a safe place for future reference.

■

ALWAYS observe the safety precautions since they intend to prevent personal injury or property damage.

■

The following symbols indicate the different levels of injury or damage that may result if the guidelines are not observed and the terminal is used improperly.

Failure to observe these guidelines may

DANGER

WARNING

CAUTION

immediately result in death or serious injury.

Failure to observe these guidelines may result in death or serious injury.

Failure to observe these guidelines may result in injury and property damage.

Content s/Precautio ns

■

The following symbols indicate specific directions.

Indicates prohibited actions.

Don’t

1. Handling the terminal, adapter, desktop holder, docomo nano UIM card, and 1Seg antenna cable (common)

Indicates not to disassemble.

No disassembly

Indicates not to use where it could get wet.

No liquids

Indicates not to handle with wet hands.

No wet hands

Indicates compulsory actions in accordance with instructions.

Indicates to remove the power plug from the outlet.

Unplug

■

"Safety Precautions" are described in the following categories:

1. Handling the terminal, adapter, desktop holder, docomo nano UIM card, and 1Seg antenna

cable (common). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2. Handling the terminal . . . . . . . . . . . . . . . . . . . . . .10

3. Handling adapter or desktop holder. . . . . . . . . 13

4. Handling the docomo nano UIM card . . . . . . . 15

5. Handling the terminal near electronic medical

equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6. Material list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DANGER

Do not use, store or leave the equipment in hot places (e.g. by the fire, near a heater,

Don’t

under a kotatsu, in direct sunlight, in a car in the hot sun) (including wearing the equipment by putting in a pocket of clothes etc.).

Doing so may cause fire, burns or injury.

Do not place equipment inside cooking appliance such as a microwave oven or high-

Don’t

pressure containers.

Doing so may cause fire, burns, injury or electric shock.

Do not disassemble or modify the equipment.

No disassembly

Doing so may cause fire, burns, injury or electric shock.

Do not let the equipment get wet with water, drinking water, urine of pet animals,

No liquids

sweat, etc.

Doing so may cause fire, burns, injury or electric shock. Waterproofness→P.24 "Waterproofness/ Dustproofness"

Content s/Precautio ns

Do not allow liquid (water, drinking water, urine of pet animals, perspiration, etc.) to

No liquids

enter the charging jack, headset jack, or microUSB jack.

Doing so may cause fire, burns, injury or electric shock. Waterproofness Dustproofness"

Use optional devices specified by NTT DOCOMO for the terminal.

Failure to do so may cause fire, burns, injury or electric shock.

→

P.24 "Waterproofness/

WARNING

Do not subject the equipment to excessive force or throw it.

Don’t

Doing so may cause fire, burns, injury or electric shock.

Do not allow the charging jack, headset jack, or microUSB jack to touch conducting

Don’t

foreign substances (a piece of metal, pencil lead, etc.). Never allow these objects to get inside.

Doing so may cause fire, burns, injury or electric shock.

Do not cover or wrap the equipment with a cloth or bedding in use or while charging.

Don’t

Doing so may cause fire or burns.

Power off the terminal before you step into a place where flammable gas can leak, such as

gas stations. Stop charging if you charge the battery.

Gas may catch fire. When using Osaifu-Keitai in a place such as a gas station, turn OFF the terminal before using it (When NFC/Osaifu-Keitai lock is activated, deactivate it before turning OFF the terminal).

If you notice anything unusual about the equipment such as an unusual odor,

overheating, discoloration or deformation during operation, charging or storage, immediately perform the following measures.

・

Remove the power plug from the power outlet or cigarette lighter

・

Power off the terminal

Failure to do so may cause fire, burns, injury or electric shock.

CAUTION

Do not place on an unstable or inclined platform.

Don’t

Doing so may cause the device to fall and cause injury.

Do not keep in a place that is very humid, dusty, or subject to high temperature.

Don’t

Doing so may cause fire, burns or electric shock.

If children use the terminal, parents or guardians should give them the proper

instructions for use. Make sure that they use the terminal as instructed.

Failure to do so may cause injury.

Content s/Precautio ns

Keep the equipment out of the reach of babies and infants.

Failure to do so may cause accidental ingestion, injury, or electric shock.

Be careful especially when using the terminal connected to the adapter

continuously for a long time.

If you play a game, watch videos or 1Seg, etc. for a long time while charging, the temperature of the terminal and adapter may rise. If you are directly in contact with hot parts for a long perio d of time, it may caus e your skin to become red, itchy, or develop a rash depending on your physical condition and also it may cause low-temperature burn.

2. Handling the terminal

■

Type of internal battery for the terminal is as follows.

Display Type of Battery

Li-ion 00 Lithium Ion Battery

DANGER

Do not throw the terminal into fire or apply heat.

Don’t

Doing so may cause internal battery to ignite, burst, heat or leak.

Do not put excessive force such as sticking a nail into the terminal, hitting it with a

Don’t

hammer, or stepping on it.

Doing so may cause internal battery to ignite, burst, heat or leak.

If the internal battery fluid etc. contacts eyes, immediately flush the eyes with clean water

and see a doctor right away. Do not rub the eyes.

Failure to do so may cause blindness.

WARNING

Do not turn on the light with the lighting luminescence part close to the eyes.

Don’t

Especially to shoot infants or young children, step away from them 1 m or more.

Doing so may cause blurred vision. Or injury by dazzling eyes or surprising may occur.

Content s/Precautio ns

Do not allow a foreign substance such as water and other liquids, metal parts, or

Don’t

flammables to get in the docomo nano UIM card slot or microUSB jack/microSD card slot on the terminal.

Doing so may cause fire, burns, injury or electric shock.

Do not turn on the light toward a driver of a car etc.

Don’t

Doing so may disturb driving and cause an accident.

Power off the terminal or put it in Airplane mode before boarding an airplane.

Use of mobile phones on board is restricted. Follow the instructions of each airline. Failure to do so may adversely affect on-board electronic equipment. Prohibited acts related to mobile phone usage on an airplane may be punished by law. If the microUSB cable is connected into the microUSB jack for charging etc. with the terminal powered off, the terminal is automatically powered on although the operations are not available. Be careful not to connect the microUSB cable in a place where the use is prohibited.

Follow the instructions of each medical facility for the use of mobile phones on their

premises.

Power off the terminal in a place where the use is prohibited. Failure to do so may affect electronic equipment and electronic medical equipment. If the microUSB cable is connected into the microUSB jack for charging etc. with the terminal powered off, the terminal is automatically powered on although the operations are not available. Be careful not to connect the microUSB cable in a place where the use is prohibited.

Always keep the terminal away from your ear when you talk setting the hands-free

function. Also, when you play game, play back music, etc. connecting the Earphone/Microphone, etc. to the terminal, adjust the volume adequately.

If the volume is too loud, it may cause difficulty in hearing. Moreover, if you barely hear the surrounding sounds, it may cause an accident.

If you have a weak heart, set the vibrator or ringtone volume carefully.

Failure to do so may affect your heart.

If you are wearing any electronic medical equipment, check with the relevant medical

electronic equipment manufacturer or vendor whether the operation may be affected by radio waves.

The radio waves from the terminal may affect electronic medical equipment.

Content s/Precautio ns

Power off the terminal near electronic devices or equipment operating on high

precision control or weak signals.

Failure to do so may interfere with the operation of electronic devices or equipment. * The following are some electronic devices

or equipment that you should be careful of: Hearing aids, implantable cardiac pacemaker, implantable cardioverter defibrillator, other electronic medical equipment, fire detector, automatic door, and other automatically controlled devices or equipment. If you use an implantable cardiac pacemaker, implantable cardioverter defibrillator, or other electronic medical equipment, check with the relevant medical electronic equipment manufacturer or vendor whether the operation can be affected by radio waves.

Be careful about broken glasses or exposed internal from the terminal if the display or

the camera lens is broken.

The display is made of toughened glass, and the camera lens is made of acrylic resin to prevent the glass from shattering when broken. However, touching a cut surface or exposed portion accidentally may result in injury.

If the internal battery leaks or gives off a strange smell, immediately remove it from

the vicinity of open flames.

The leaking liquid may ignite fire, catch fire, or explode.

CAUTION

Do not swing the terminal around by holding strap, etc.

Don’t

The terminal may hit you or others and cause accident such as injury.

Do not use damaged terminal.

Doing so may cause fire, burns, injury or

Don’t

electric shock.

When using the motion sensor, check the safety around you, hold the terminal firmly,

Don’t

and do not shake it unnecessarily.

Failure to do so may cause accident such as injuries.

If the display is mistakenly damaged and when the liquid crystal runs out, do not get

Don’t

it on your skin such as face, hands, etc.

Doing so may cause blindness or injury on your skin. If the liquid crystal gets in your eye or mouth, rinse with clean running water, and get medical treatment immediately. Also, if it gets on your skin or clothes, use something such as alcohol to wipe off, and wash it off with soap or something similar.

Do not discard the battery together with other garbage.

Don’t

Doing so may cause igniting or environmental destruction. Bring the unnecessary terminal into a sales outlet such as docomo Shop. If your local municipality has a battery recycling program, dispose of them as provided for.

Content s/Precautio ns

To use the terminal in car, check with automobile manufacturer or dealer to

determine how the device is affected by radio waves before using.

In rare cases, using the phone in some vehicle models can cause the vehicle's electronic equipment to malfunction. In that case, stop using the terminal immediately.

The use of the terminal may cause itching, rashes, eczema, or other symptoms

depending on the user's physical condition. Immediately stop using and get medical treatment in such a case.

For material of each part →P.16 "Material list"

When watching the display, take a certain distance from the display in a fully bright

place.

Failure to do so may reduce visual acuity.

If fluid etc. leaks out from the internal battery, do not make the fluid contact with

your skin of face or hands.

Doing so may cause blindness or injury on your skin. If the fluid etc. gets into your eyes or mouth, or contacts skin or clothes, immediately flush the contacted area with clean running water. If the fluid gets into the eyes or mouth, immediately see a doctor after flushing.

3. Handling adapter or desktop holder

WARNING

Do not use the adapter cord if it gets damaged.

Don’t

Doing so may cause fire, burns or electric shock.

Do not use the AC adapter or desktop holder in a very humid place such as bathroom.

Don’t

Doing so may cause fire, burns or electric shock.

DC adapter is only for a negative ground vehicle. Do not use DC adapter for a positive

Don’t

ground vehicle.

Doing so may cause fire, burns or electric shock.

Do not touch the adapter if you hear thunder.

Don’t

Doing so may cause electric shock.

Do not short-circuit the charging jack while it is connected to the power outlet or

Don’t

cigarette lighter socket. Do not touch the charging jack with your hands, fingers, or any part of your body.

Doing so may cause fire, burns or electric shock.

Do not place heavy objects on the adapter cord.

Don’t

Doing so may cause fire, burns or electric shock.

Content s/Precautio ns

When you insert and remove the AC adapter from power outlet, do not contact a metal

Don’t

strap or other metal objects with the jack.

Doing so may cause fire, burns or electric shock.

Do not put an excessive force up, down, left or right when the adapter is connected to

Don’t

the terminal.

Doing so may cause fire, burns, injury or electric shock.

Do not touch the adapter cord, charging jack or outlet with wet hands.

No wet hands

Doing so may cause fire, burns or electric shock.

Use the adapter only on the specified power supply and voltage.

When charging the terminal overseas, use AC adapter for global use.

Failure to do so may cause fire, burns or electric shock. AC adapter : 100V AC DC adapter : 12V or 24V DC (only for a negative-ground vehicle) AC adapter for global use : 100V to 240V AC (Make sure to connect the adapter to a household AC power outlet.)

When the fuse in a DC adapter is blown, make sure to use the specified fuse.

Failure to do so may cause fire, burns or electric shock. For the specified fuse, see the users manuals that supplied with a DC adapter.

Clean dust from the power plug.

Failure to do so may cause fire, burns or

electric shock.

When you connect the AC adapter to the power outlet, insert it firmly.

Failure to do so may cause fire, burns or electric shock.

When you disconnect the power plug from the outlet or cigarette lighter socket, do not

pull the adapter cord with excessive force. Instead, hold the adapter to disconnect.

Failure to do so may cause fire, burns or electric shock.

Remove or insert the adapter to the terminal evenly without applying excessive force.

Failure to do so may cause fire, burns, injury or electric shock.

Always remove the power plug from the outlet or cigarette lighter when not using

Unplug

the adapter for an extended period.

Failure to do so may cause fire, burns or electric shock.

Immediately remove the power plug from the outlet or cigarette lighter socket if water

Unplug

or other fluids get into the adapter.

Failure to do so may cause fire, burns or electric shock.

Before cleaning, remove the power plug from the power outlet or the cigarette

Unplug

lighter socket.

Failure to do so may cause fire, burns or electric shock.

CAUTION

Do not touch the adapter for a long time when it is connected to a power outlet or

Don’t

cigarette lighter socket.

Doing so may cause a burn or other injury.

Content s/Precautio ns

4. Handling the docomo nano UIM card

CAUTION

Be careful of the cut surface when handling a docomo nano UIM card.

Failure to do so may cause injury.

5. Handling the terminal near electronic medical equipment

WARNING

If you use an implantable cardiac pacemaker or implantable cardioverter defibrillator,

keep the terminal 15 cm or more away from the implant at all times.

The radio waves from the terminal may affect the performance of electronic medical equipment.

If you need to use electronic medical equipment other than implantable cardiac

pacemaker or implantable cardioverter defibrillator outside medical facilities such as treating at home, check with the relevant medical electronic equipment manufacturer whether the operation may be affected by radio waves.

The radio waves from the terminal may affect the performance of electronic medical equipment.

When you get close to other people within 15 cm just like not having enough space to

turn around, set the radio wave of the terminal to OFF beforehand ( Airplane mode, to Power off, etc.).

A person in close proximity may put on implanted a medical electrical equipment such as pacemakers and ICDs. The radio waves from the terminal may affect the performance of electronic medical equipment.

Follow the instructions of each medical facility for the use of the terminal on their

premises.

Content s/Precautio ns

6. Material list

Part Material

Exterior case (display around), strap hole

Exterior case (side, microUSB jack/ microSD card slot cover; docomo nano UIM card slot cover)

Exterior case (back side)

Exterior case (camera ring, ring around the headset jack), Power key, Volume key, Camera key

Exterior case (Headset jack)

Transparent plate (camera)

Transparent plate (Display)

Transparent plate (Flash/Photo light)

Magnet connector (resin part)

Surface

treatment

PA r es in (with glass)

PC resin Discontinuous

Coating

vapor deposition + coating (Gray, Blue) Coating (White, Pink)

PC resin Coating

Aluminum alloy

Nylon resin

PMMA resin +

Anodic oxide coating

―

AR treatment

PC resin Hardened glass AFP treatment

PMMA resin Hard coat

PPS resin (Gray, Blue) Nylon resin (White, Pink)

―

Part Material

Magnet connector (sheet metal)

Magnet connector (electrode)

microUSB jack (housing)

microUSB jack (shield)

docomo nano UIM card tray

SUS Acr ylic coating

Phosphor bronze

PA r es in

Stainless Nickel plating

POM resin

Nameplate PET resin Desktop holder

(upper case, lower case)

Desktop holder (Attachment)

Desktop holder (magnet connector)

Desktop holder (contacts, charging

ABS resin

PC resin

Neodymium Nickel plating

Brass Gold plating

jack) Desktop holder

PA r es in

(housing: contacts) Desktop holder

(housing: charging jack)

Desktop holder (shield: charging jack)

Polyester resin

Stainless

Surface

treatment

Gold plating

―

+ tinning

―

― ―

―

Content s/Precautio ns

Part Material

Desktop holder (nameplate)

Desktop holder (serial number label)

Desktop holder (2D barcode label)

Desktop holder (immersion sensing label)

Desktop holder (rubber foot)

1Seg antenna cable (headset jack: top side, connector plug: top side)

1Seg antenna cable (headset jack: body, cable, connector plug: body)

1Seg antenna cable (connector plug: metal section)

Surface

treatment

PET (aluminum evaporation) resin

PET resin

PS resin

Quality paper

Polyester resin

PP resin

Elastomer resin

Brass Gold plating

―

Handling precautions

■

Common precautions

･

SO-04G is waterproof/dustproof; however, do not allow water or dust to enter the terminal or come in contact with accessories or optional devices.

The adapter, desktop holder, docomo nano UIM card and 1Seg antenna cable are not waterproof/ dustproof. Do not use in a bathroom or other highly humid area or do not let rain touch. Or putting them on your body, humidity of sweat may cause internal corrosion and malfunction. Note that malfunctions which are determined to be caused by water as result of inspections are outside the scope of the warranty. Since these conditions are outside of the scope of the warranty, a repair, if at all possible, is charged.

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

- Do not rub it roughly with a dry cloth. The display may be damaged.

- Drops of water or dirt left on the display may cause stains.

- Do not use alcohol, thinner, benzine, cleaning detergent, etc. to clean the terminal. These chemicals may erase the printing on the terminal or cause discoloration.

Content s/Precautio ns

･

Clean the terminals occasionally with a dry cotton swab.

If the jack is soiled, connection gets worse and it may cause power to be turned off or insufficient battery charge, so clean the jack with a dry cotton swab etc. When cleaning, be careful not to damage the terminals.

･

Do not leave the terminal near the air conditioning vent.

Extreme temperature changes may produce condensation and corrode the internal parts of the terminal, causing it to malfunction.

･

Make sure to use the terminal etc. without excessive force.

If you put the terminal in a bag full of items or sit down with the terminal in the pocket of your cloth, it may damage the display, internal circuit board, etc. and cause malfunction. If doing so while the external device is connected to the microUSB jack or headset jack, it may cause damage or malfunction.

･

Do not rub or scratch the display with metal.

The display may get scratched and it may cause malfunction or damage.

･

Read the users manuals supplied with individual optional devices.

■

The terminal precautions

･

Do not press touch screen surface forcibly, or not operate with a sharppointed objects such as nail, ballpoint pen, pin, etc.

Doing so may cause damage of touch screen.

･

Do not use the terminal in extremely hot or cold places.

Use the terminal where the temperature ranges

℃

between 5 use in a bathroom etc. when temperature is

above 36 and 85%.

･

Using the terminal near land-line phone,

and 40℃ (limited to the temporary

℃

) and humidity ranges between 45%

television or radio may cause interference in these electric appliances. Make sure to move far away from them when using the terminal.

･

Note down the information saved in the terminal in a separate note and keep it safely.

Under no condition will DOCOMO be held liable for any damaged or lost data saved in the terminal.

･

Do not drop or give a strong impact to the terminal.

Doing so may cause malfunction or damage.

･

Do not plug an external device at an angle into the headset jack or microUSB jack. Also, do not pull the cable when it is plugged in.

Doing so may cause malfunction or damage.

Content s/Precautio ns

･

The terminal could become warm while in use and charging. This condition is not abnormal. You can continue using the terminal.

･

Do not leave the camera under direct sunlight.

If you do so, some of the elements may melt or become faded.

･

Usually, keep the docomo nano UIM card slot cover and microUSB jack/ microSD card slot cover closed during use.

Failure to do so may get dust or water inside and cause malfunction.

･

While microSD card is being used, do not take the card out and do not turn off the terminal.

Doing so may cause data loss or malfunction.

･

Do not let magnetic cards, etc. close to the terminal.

The magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

･

Do not bring strong magnetic objects close to the terminal.

Strong magnetic objects may cause misoperation.

･

The internal battery is a consumable part.

Replace the internal battery if the terminal has extremely short operation time on a full charge, though it may vary by operating conditions. For replacing internal battery, contact "Repairs" on the last page (in Japanese only) or DOCOMOspecified repair office.

･

Charge the battery in an environment with the proper ambient temperature (5

℃

to 35℃).

･

The operating time of the internal battery varies depending on the operating environment and the degradation level of the internal battery.

･

Be careful especially about the following points when preserving the terminal.

- The battery is fully charged (immediately after the charging is complete)

- The battery has run out (the terminal cannot power on)

The performance and life of the internal battery may deteriorate. It is recommended that you store the battery with the remaining battery level of about 40% as a guide.

Content s/Precautio ns

■

Precautions on the adapter, desktop holder

･

Charge the battery in an environment with the proper ambient temperature (5

℃

to 35℃).

･

Do not charge in the following places.

- Places that are very humid, dusty or exposed to strong vibrations

- Near land-line phone or TV/radio

･

The adapter or desktop holder could become warm while charging. This condition is not abnormal.

･

When using the DC adapter for charging, do not turn off the vehicle engine.

Doing so may cause the vehicle battery run out.

･

When you use the power outlet with a mechanism to prevent the plug from being removed, follow the instructions on the outlet's user's manual.

･

Do not subject the equipment to a strong impact. Do not deform the charging jack.

Doing so may cause malfunction.

･

Do not use unnecessary force to attach/ remove the attachment for the desktop holder.

Doing so may cause malfunction or damage.

･

Magnet is used for magnet connector that is between contacts of the desktop holder. Make sure that any iron sands or metal objects (clips etc.) are not adhered before attaching the terminal. Remove the foreign objects with a soft cloth etc., if any.

･

Do not let magnetic cards, etc. close to the desktop holder.

The magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

･

Do not use them near a place where magnetism of medical electronic equipment or other electronic equipment affects.

■

docomo nano UIM card precautions

･

Do not use unnecessary force to insert/ remove the docomo nano UIM card.

･

Note that DOCOMO assumes no responsibility for any malfunctions resulting from inserting the docomo nano UIM card into another IC card reader/writer and using it.

･

Always keep the IC portion clean when you use the card.

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

Content s/Precautio ns

･

Note down the information registered in the docomo nano UIM card on a separate sheet and keep it for future reference.

Under no condition will DOCOMO be held liable for any damaged or lost data saved in the terminal.

･

Take an expended docomo nano UIM card to a sales outlet such as docomo Shop for proper disposal in order to protect the environment.

･

Do not carelessly damage, contact, or short-circuit an IC.

Doing so may cause data loss or malfunction.

･

Do not drop a docomo nano UIM card or subject it to impact.

Doing so may cause malfunction.

･

Do not bend a docomo nano UIM card or place a heavy object on it.

Doing so may cause malfunction.

･

Do not insert a docomo nano UIM card into the terminal if a label or seal is attached to the card.

Doing so may cause malfunction.

■

Bluetooth® function precautions

･

To secure the Bluetooth communication security, the terminal supports the security function compliant with Bluetooth standards, but the security may not be sufficient depending on the setting. Be aware of security risks when using Bluetooth.

･

Please be aware that DOCOMO is not responsible for any data leakage that might occur when communicating data via Bluetooth.

･

Frequency band

The frequency band used by the terminals Bluetooth/wireless LAN function is written as follows:

2.4 : This radio equipment uses the 2400 MHz band.

Modulation scheme is the

FH/XX/DS/OF

4 : The estimated interference distance is 40

8 : The estimated interference distance is 80

Available channels vary depending on the country. For use in an aircraft, contact the airline beforehand.

：

FH-SS, other system, DS-SS, or OFDM system.

m or less.

: The full band between 2400 MHz

and 2483.5 MHz is used and the band of the mobile identification device can be avoided.

Content s/Precautio ns

･

Bluetooth cautions

The operating frequency band of the terminal is used by industrial, scientific, consumer and medical equipment including microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (hereinafter referred to as "another station").

- Before using this equipment, confirm that "another station" is not being operated nearby.

- In the event of the terminal causing harmful radio wave interference with "another station", promptly change the operating frequency or stop radio wave emission by turning off the power, etc.

- If you have further questions, contact "General Inquiries" on the last page.

■

Wireless LAN (WLAN) precautions

･

Wireless LAN (WLAN) exchanges information using radio waves, and allows you to freely establish LAN connection if you are within an area where radio waves reach. However, without appropriate security settings, communications may be intercepted or hacked by malicious parties. It is recommended to configure necessary security settings on your own judgment and responsibility.

･

Wireless LAN

Do not use wireless LAN near magnetic devices such as electrical appliances or AV/OA devices, or in radio waves.

- Magnetism or radio waves may increase noises or disable communications (especially when using a microwave oven).

- When used near TV, radio, etc., reception interference may occur, or channels on the TV screen may be disturbed.

- If there are multiple wireless LAN access points nearby and the same channel is used, search may not work correctly.

･

2.4GHz device cautions

The operating frequency band of the WLAN device is used by industrial, scientific, consumer and medical equipment including home electric appliances such as microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (radio stations requiring a license).

- Before using the device, confirm that premises radio stations for identifying mobile units, specified low power radio stations and amateur radio stations are not being operated nearby.

- If the device causes harmful radio interference to premises radio stations for identifying mobile units, immediately change the frequency band or stop use, and contact "General Inquiries" on the last page for crosstalk avoidance, etc. (e.g. partition setup).

Content s/Precautio ns

- If the device causes radio interference to specified low power radio stations or amateur radio stations, contact "General Inquiries" on the last page.

･

5GHz device cautions

The terminal can use 3 frequency bands of

5.2GHz band (W52), 5.3GHz band (W53), 5.6 GHz

band (W56).

- 5.2GHz band (W52/36, 40, 44, 48 ch)

- 5.3GHz band (W53/52, 56, 60, 64 ch)

- 5.6GHz band (W56/100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 ch)

Using wireless LAN built-into the terminal in 5.2/

5.3 GHz outside is prohibited by the Radio Law.

■

FeliCa® and NFC reader/writer function precautions

･

FeliCa and NFC reader/writer, P2P function of the terminal use weak waves requiring no licenses for radio stations.

･

They use 13.56 MHz frequency band. When using other reader/writer or P2P function in your surroundings, keep the terminal away sufficiently from them. Before using the FeliCa and NFC reader/ writer, P2P function, confirm that there are no radio stations using the same frequency band nearby.

･

For use in an aircraft, contact the airline beforehand. Some countries may restrict the use of the function. Check the regulations of the country/region before using it.

■

Note

･

Do not use a remodeled terminal. Using a remodeled terminal violates the Radio Law/Telecommunications Business Act.

The terminal is compliant with rules on the technical standard conformance of specified wireless equipment based on the Radio Law/ Telecommunications Business Act, and as a proof of it, the "Technical Compliance Mark " is depicted on the electronic nameplate of the terminal. To check the certificate, from the Home

screen, information] If you remove the screws and alter the inside of the terminal, the technical regulations conformity certification becomes invalid. Do not use the terminal with the certification invalid, as it is a violation of the Radio Law and Telecommunications Business Act.

･

Be careful when using the terminal

[Settings]u[About phone]u[Legal

[Certificates].

while driving.

Using the terminal with holding with your hand while driving will result in a penalty. However, absolutely necessary cases such as rescue of a sick person or maintaining public's safety are exempted.

･

Use the FeliCa reader/writer function only in Japan.

FeliCa reader/writer function of the terminal conforms to Japanese radio standards. If you use this function overseas, you may be punished.

･

Do not alter the basic software illegally.

It is regarded as the software modification and Repairs may be refused.

Content s/Precautio ns

Waterproofness/ Dustproofness

SO-04G provides waterproofness property of

*2,

, IPX8

IPX5 IP6X cover, microUSB jack/microSD card slot cover firmly attached.

*1 IPX5 means that a phone keeps functioning

after applying a jet flow of 12.5 L/min. from every direction from a distance of approximately 3 m for at least 3 minutes using water nozzle in 6.3 mm inner diameter.

*2 IPX8 means that a phone keeps functioning

after SO-04G is slowly submerged to depth of 1.5m in static tap water at room temperature, left there for approximately 30 minutes and then taken out.

*3 IP6X indicates that a phone has the ability

to prevent dust from entering it even when it has been shaken for 8 hours in an apparatus containing dust particles 75 or less in diameter.

and dustproofness property of

with the docomo nano UIM card slot

What you can do with waterproofness/dustproofness of SO-04G

･

You can talk without an umbrella in the rain (for rainfall of 20 mm or less per hour).

- Do not open or close the docomo nano UIM card slot cover or microUSB jack/microSD card slot cover with wet hands or with water droplets on the terminal.

･

You can w ash the te rmi nal w hen it g ets d irt o r stained with liquid other than tap water.

- Wash the terminal with tap water at normal

℃

temperature (5 flow (less than 6 L/min.) at distance of

approximately 10 cm away from the tap or shower.

- When washing the terminal, hold the docomo nano UIM card slot cover and microUSB jack /microSD card slot cover to keep them closed, and wash the terminal with your hands, not using a brush or sponge. After washing, drain the terminal before use (P.28).

･

You can use at a poolside. Do not throw water from the pool on the terminal, or soak it in pool water.

-35℃) by weaker water

Content s/Precautio ns

･

You can use the terminal in a bathroom.

- Do not immerse the terminal into a bathtub. Also, do not use the terminal in hot water. Doing so may cause malfunction. If you should fall the terminal into the bathtub, immediately pick it up to drain water in specified procedure (P.28).

- Never put the terminal in hot spring wate r or water containing soap, detergent or bath powder. In case the terminal gets wet with water other than tap water, wash it in the procedure above.

- You can use the terminal within 2 hours in a bathroom where the temperature ranges

℃

between 5 and 45

and humidity ranges

between 45 and 99%.

- Rapid temperature change may cause condensation. If you bring the terminal from a cold place to warm place such as a bathroom, wait until the terminal reaches the room temperature.

- Do not put hot water from a faucet or shower.

To ensure waterproofness/ dustproofness

To avoid water ingress, be sure to observe the following points.

･

Do not throw any liquid other than room temperature tap water on the terminal, or soak it in such liquid.

･

Firmly close the docomo nano UIM card cover and microUSB jack/microSD card slot cover. Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between contact surfaces may allow water to enter.

･

Do not poke the earpiece/speaker, microphone, speaker, second microphone, headset jack, or strap hole with a sharp object.

･

Do not let the terminal fall. It may become scratched causing the waterproof/dustproof performance to degrade.

･

The rubber gaskets on the inner side of the docomo nano UIM card slot cover and microUSB jack/microSD card slot cover play an important role in keeping waterproof/ dustproof performance. Do not remove or damage them. Also, prevent dust from adhering to them.

Content s/Precautio ns

■

Opening the docomo nano UIM card slot cover, microUSB jack/microSD card slot cover

Open the covers with your fingertip by the grooves.

■

Closing the docomo nano UIM card slot cover, microUSB jack/microSD card slot cover

Put the cover back in the direction of the arrow and push the parts in, then ensure there are no gaps.

Groove

docomo nano UIM card

slot cover

Groove

microUSB jack/

microSD card slot cover

docomo nano UIM card

slot cover

It is recommended to replace the parts for maintaining waterproof/dustproof property once every two years regardless of whether any abnormality is present. DOCOMO replaces the parts as a chargeable service. Bring the terminal to a sales outlet such as a DOCOMO-specified repair office.

microUSB jack/

microSD card slot cover

Content s/Precautio ns

Important precautions

Do not perform actions shown in the illustrations below.

Using in hot

spring

Machinewashing

Applying strong

Attaching

sand/mud

water ow

Bath powder

Washing with brush/sponge

Soaking in

ocean water

Using Soap/Detergent/

Observe the following precautions to use the terminal properly.

･

Accessories and optional devices are not waterproof/dustproof.

･

Do not apply water flow stronger than allowed (P.24). SO-04G provides IPX5 waterproofness, but doing so may cause malfunction.

･

If the terminal gets wet with salt water, sea water, refreshing beverage or mud or sand adhered, wash it immediately. If they dry out, it is hard to remove the dirt and it may cause damage or malfunction.

･

Do not put the terminal in hot water, use it in a sauna or apply hot airflow (from a hair dryer etc.) to it.

･

Do not move the terminal in water or slam the terminal against the surface of water.

･

If you put the terminal in tap water, be sure to have it within 30 minutes.

･

When you use the terminal in swimming pool, obey rules of the facility.

･

The terminal does not float on water.

･

Do not leave water on the terminal. In cold region, the terminal freezes up and may cause malfunction.

･

Do not leave water on the earpiece/speaker, microphone, speaker, second microphone, and headset jack. Such water may interfere with talking.

･

If the terminal gets splashed with water or other liquid while the docomo nano UIM card slot cover, or microUSB jack/microSD card slot cover is open, the liquid may get inside the terminal, causing electric shock or malfunction. Stop using the terminal, turn off the power and contact a DOCOMO-specified repair office.

･

If any of the rubber gaskets on the inner side of the docomo nano UIM card slot cover or microUSB jack/microSD card slot cover is damaged or deformed, have it replaced at a DOCOMO-specified repair office.

･

Do not connect 1Seg antenna cable, earphones, etc. with the terminal wet with water. Doing so may cause malfunction.

Content s/Precautio ns

DOCOMO does not guarantee actual operations under all states. Malfunctions deemed to be caused by inappropriate operation by the customer are not covered by the warranty.

Draining water from the terminal

When the terminal is wet, water may flow out after wiping it off; drain the water in the following steps.

Hold the terminal firmly and wipe off moisture on the terminal surface and back side with dry, clean cloth etc.

(1) Shake the terminal about 20 times, firmly holding it, until no more drops of water come out. (2) Do the same with the terminal upside down.

（1）（2）

To wipe any water off the gaps or the following parts, tap the terminal against a dry, clean cloth or similar material about 10 times.

･

Earpiece/Speaker

･

Microphone

･

Speaker

･

Second microphone

･

Headset jack

･

Power key/Screen lock key

･

Volume key/Zoom key

･

Camera key

･

Contacts for Desktop holder

･

docomo nano UIM card slot cover

･

microUSB jack/microSD card slot cover

Wipe off water drained from the terminal with dry, clean cloth etc., and dry naturally.

･

Wipe off water drained from the terminal with dry, clean cloth etc., and dry naturally.

･

Do not wipe off water remaining in gaps directly with a cotton swab etc.

･

Dry the terminal naturally for about 3 hours at room temperature.

Content s/Precautio ns

Notes on charging

Check the following before and after charging.

･

Check if the terminal is not wet. Never charge the battery when the terminal is wet.

･

Accessories and optional devices are not waterproof/dustproof.

･

When charging the battery when or after the terminal is wet, adequately drain it and wipe off water with a dry, clean cloth etc., before connecting the supplied desktop holder or opening the microUSB jack cover.

･

When the microUSB jack cover is opened for charging, close the cover firmly af ter charging. It is recommended to use the desktop holder for charging to prevent water or dust from seeping inside through the microUSB jack.

･

Do not use the AC adapter or desktop holder in a bathroom, shower room, k itchen, lavatory or other highly humid area. Doing so may cause fire or electric shock.

･

Do not touch the AC adapter or desktop holder with wet hands. Doing so may cause electric shock.

Content s/Precautio ns

Part names and functions

ghab cd

v w

a b

c d e f g h i j k l m

Notification LED Proximity sensor : Detect the face to get close during a call and turn on or off the touch screen to prevent misoperation, or help auto brightness control. Earpiece/Speaker Front camera lens Tou ch s creen Speaker Camera lens Flash/Photo light FOMA/Xi/GPS antenna section FOMA/Xi antenna section

mark

Nameplate

microUSB jack/microSD card slot

Contacts for Desktop holder

docomo nano UIM card slot

Wi-Fi/Bluetooth antenna section

q P

Power key/Screen lock key

Volume key/Zoom key

s k

Camera key

Headset jack

Second microphone : Reduce noise to make voice to be listened easily.

Strap hole

Microphone

*1 The antenna is built into the terminal. Covering

around the antenna with your hand may affect the quality of communications.

Before Using the Terminal

*2 Do not remove the nameplate with stickers of CE

mark, FCC ID and IMEI information printed.

❖

Note

･

Do not put a sticker etc. on the proximity sensor.

･

The back cover cannot be removed. Attempting to remove the back cover with excessive force may cause damage or malfunction.

･

The battery is built into the terminal and not removal.

docomo nano UIM card

The docomo nano UIM card is an IC card recorded user information such as your phone number etc.

･

You can use the terminal with a docomo nano UIM card. If you have a docomo mini UIM card, UIM, or FOMA card, bring it to a docomo Shop to replace it with a docomo nano UIM card.

･

When docomo nano UIM card is not inserted to the terminal, making calls, packet communication, etc. are not available.

･

For details on the docomo nano UIM card, refer to the docomo nano UIM card manual.

･

When inserting/removing the docomo nano UIM card, make sure to power off the terminal (P.39).

･

Opening/closing docomo nano UIM card slot cover (P.25).

■

Security codes of the docomo nano UIM card

The docomo nano UIM card has a security code called a PIN code. The code is set to "0000" at subscription, which you can change by yourself (P.167).

❖

Information

･

Please be careful not to touch or scratch the IC when you handle the docomo nano UIM card. Doing so may cause malfunction or damage.

Before Using the Terminal

Inserting docomo nano UIM card

Open the docomo nano UIM card

slot cover, then hook your fingertip on the projection part of the tray ( ) to pull the tray straight out and remove it from the terminal.

Tray

Set docomo nano UIM card into

the tray with IC facing up ( ), then insert the tray with the card and press it all the way into the terminal.

･

Make sure the orientation of the corner cut and direction to insert.

Corner cut

Tray

Close the docomo nano UIM card

cover, firmly press parts and make sure that there are no gaps between the terminal and cover.

Before Using the Terminal

Removing docomo nano UIM card

Open the docomo nano UIM card

slot cover, then hook your fingertip on the projection part of the tray to pull the tray straight out and remove it from the terminal.

Remove the docomo nano UIM

card from the tray ( ), then insert the tray into the terminal and press it straight all the way.

･

Be careful about the direction to insert of the tray.

docomo nano UIM card

Tray

Close the docomo nano UIM card

slot cover, firmly press the cover, and make sure that there are no gaps between the terminal and cover (P.32).

Charging

The internal battery is not fully charged at the time of purchase.

･

Estimated charging time (P.212)

Operation time on full charge (estimate)

The charging time varies by the internal battery condition or operating environment.

･

"Continuous standby time", "Continuous call time" (P.214)

Continuous stand-by time

Continuous call time

FOMA/3G

GSM

LTE

FOMA/3G GSM VoLTE call

(voice)

Stationary (Auto) : Approx. 760 hours

Stationary (Auto) : Approx. 590 hours

Stationary (Auto) : Approx. 620 hours

Approx. 700 min. Approx. 650 min. Approx. 990 min.

Before Using the Terminal

Life of the internal battery Before charging

･

The internal battery is a consumable part. Each time the internal battery is recharged, the battery usage time per one charge gradually decreases.

･

When the battery usage time per one charge becomes about half of that at the time of purchased, replacing the internal battery is recommended because the internal batter y is near the end of life.

･

Watching 1Seg etc. for a long time while charging may shorten the lifetime of the internal battery.

･

To check the charging performance, from the Home screen, tap

[Status]u[Battery life].

phone]

[Settings]u[About

･

It is recommended to use the AC Adapter 05 (optional) for charging. For details on the AC Adapter 05, refer to the AC Adapter 05 manual.

･

The AC Adapter 05 is compatible with 100V to 240V AC. For using the terminal overseas, a plug adapter that fits the electrical outlets in the country you stay is needed. Do not use an electrical transformer for overseas use to charge the terminal.

･

Use a compatible AC adapter or microUSB cable for charging. If you use a charger other than compatible ones, charging may not be available or operations may not be per formed correctly.

･

Insert and remove the AC adapter cable or microUSB cable slowly and evenly so that excessive force is not applied.

･

When charging starts, notification LED of the terminal turns on (P.45).

･

To check the batter y level, see the status bar at the top of the screen or from the Home

screen, tap

[Settings]u[About phone]

[Status] to see "Battery level".

･

If you start charging with the terminal powered off, the power turns on, although you cannot operate the terminal. Therefore, do not charge the battery in a place where the use of the terminal is prohibited.

Before Using the Terminal

Charging with desktop holder

When using supplied Desktop Holder SO26 and AC Adapter 05 (optional) for charging, do the following procedures.

･

Be sure to mount the supplied attachment (Attachment 53A/53B) on the desktop holder when charging the battery (P.36). The terminal cannot be charged on the desktop holder without attachment.

AC adapter

Install the terminal to the desktop

holder and move it left or right until it clicks.

･

When the terminal and the desktop holder are correctly connected, the notification LED of the terminal turns on (P.45).

Notication LED

Desktop holder

Charging jack

microUSB plug

Insert a microUSB plug of the AC adapter into the charging jack on the back side of the desktop holder with the engraved side (B) facing up ( ).

Unfold the power plug of the AC

adapter and insert it into an outlet.

When charging is complete,

holding the desktop holder, lift the terminal up to remove.

Remove the power plug of the AC

adapter from the power outlet.

Remove the microUSB plug of the

AC adapter from the desktop holder.

Before Using the Terminal

Attaching/Removing the attachment

Attachment 53A

Pit

Attachment 53B

■

Attaching

Check the shape of front/back of

the attachment and the attaching part of the desktop holder, then fit the attachment with the desktop holder.

Firmly press the attachment

straight and make sure that there are no gaps between the attachment and the desktop holder.

■

Removing

Put your fingertip into the groove

on the one side of the attachment, lift it up at a slant while pressing the desktop holder, then remove it ().

❖

Note

･

You cannot charge the battery by connecting the desktop holder to a PC.

･

Check the connecting direction to connect correctly. Wrong connection may cause damage.

･

Attachment 53A is attached to the desktop holder by default.

･

Attachment 53B only supports terminal covers with

純正卓上ホルダ対応

" desktop holders)" mark and the terminal can be charged on the desktop holder with a compatible cover attached.

(Compatible with genuine

Before Using the Terminal

Charging with AC adapter

When using AC Adapter 05 (optional) for charging, do the following procedures.

･

Opening or closing the microUSB jack/ microSD card slot cover (P.25)

Notication LED

microUSB plug

AC adapter

Open the microUSB jack/microSD

card slot cover and insert the microUSB plug of the AC adapter horizontally into the microUSB jack of the terminal with the engraved side (B) facing up.

Unfold the power plug of the AC

adapter and insert it into an outlet.

･

Notification LED of the terminal turns on (P.45).

When charging is complete,

remove the power plug of the AC adapter from the power outlet.

Remove the microUSB plug of the

AC adapter evenly from the terminal.

Close the microUSB jack/microSD

card slot cover, firmly press it and make sure that there are no gaps between the terminal and cover.

❖

Note

･

Check the connecting direction to connect correctly. Wrong connection may cause damage.

Charging with DC adapter

DC Adapter 04 (optional) supplies power from a car cigarette lighter socket (12V/24V). For details, refer to the DC Adapter 04 manual.

Before Using the Terminal

Charging with a PC

When using Micro USB Cable 01 (optional) for charging, do the following procedures.

･

Opening or closing the microUSB jack/ microSD card slot cover (P.25)

Notication LED

microUSB plug

USB plug

Open the microUSB jack/microSD

card slot cover and insert the microUSB plug of the microUSB cable horizontally into the microUSB jack of the terminal with the engraved side ( ) facing up.

Insert the USB plug of the

microUSB cable into a USB port of a PC.

･

Notification LED of the terminal turns on (P.45).

microUSB cable

･

When "Install software" screen appears on the terminal, tap [SKIP].

･

When a screen for new hardware detection etc. appears on the PC, select

キャンセル

When the charging is complete,

remove the USB plug of the

(Cancel)".

microUSB cable from the USB port of the PC.

Remove the microUSB plug of the

microUSB cable evenly from the terminal.

Close the microUSB jack/microSD

card slot cover, firmly press it and make sure that there are no gaps between the terminal and cover.

❖

Note

･

Check the connecting direction to connect correctly. Wrong connection may cause damage.

Before Using the Terminal

Turning power on/off

Turning power on

Press and hold P for over a

second.

･

The terminal vibrates and lock screen appears after a while.

･

When you first turn on the terminal after purchasing, follow the onscreen instructions to make initial settings (P.40).

Cancel the screen lock.

･

Canceling the screen lock (P.40).

❖

Information

･

If P is pressed to turn the power on when the battery level is low, the notification LED flashes in red 3 times, or an icon appears indicating that the battery level is low. Charge the terminal (P.33).

･

When SIM card lock (P.166) is set, enter PIN code on the PIN code entry screen (P.166).

Turning power off

Press and hold P for over a

second.

[Power off].

Setting sleep mode

When the sleep mode is set, the screen backlight turns off so that you can avoid misoperations of the touch screen and keys, and lock the screen.

Press P.

･

Press P again to cancel sleep mode and turn on the screen backlight.

❖

Information

･

Also, when the screen backlight goes off after a specified time elapses, the terminal goes into sleep mode. You can change the time-out period for turning off the screen backlight (P.157).

Before Using the Terminal

Canceling the screen lock

The lock screen appears when turning the power on or the sleep mode is canceled by

pressing

❖

Information

･

On the lock screen, swipe to open the "Phone" application, or swipe to open the "Camera" application.

･

You can change screen unlock method (P.167).

Swipe (or flick) up on the lock screen.

Initial settings

When you first turn on the terminal after purchasing, follow the onscreen instructions to make initial settings for language, services, etc.

Select [English (United States)]

[DONE]u.

･

After this step, follow the onscreen instructions to make the following settings, and tap or [FINISH].

- Set your Google account

- Join the world of Sony (Connect to Sony Entertainment Network)

- Set accounts and auto-sync

- Select the home application you want to use

[OK]u[OK]u[OK].

When the initial settings screen for

docomo services appears, mark [Agree to all]

･

After this step, follow the onscreen

[Start settings].

instructions and tap [Next].

-Set docomo ID

- Set docomo cloud

- Set docomo apps password

- Set whether to provide location information

- Set Remote Initialization Service

- Select whether to install all applications now or later

* It does not appear if docomo apps password is

not set.

[Start using].

･

The operation guide of the Home screen appears. Tap [Do not show again]/[OK] to display the Home screen.

❖

Information

･

Some settings can be changed later (P.162, P.169).

･

Make sure that the data connection is available (LTE/ 3G/GPRS) or the terminal is connected to a Wi-Fi network before setting up online services (P.45).

･

You can use the terminal without setting your Google account, however the Google services such as Gmail, Google Play, etc. are not available.

Before Using the Terminal

Basic operations

Using the touch screen

Precautions on using touch screen

･

Touch screen is designed for being touched lightly with fingers. Do not push the touch screen hard with a finger or press sharp objects (nail, ballpoint pen, pin, etc.) against the screen.

･

Touching the touch screen may not work in the following cases. Note that it may cause malfunction.

- Operation with tip of fingernail

- Operation with foreign object on the screen

- Operation with protective sheet or seal on the screen

- Operation on the wet touch screen

- Operation with fingers wet with sweat or water

- Operation under water

Operations on the touch screen

■

Tap

Touch an item such as icon or menu with your finger lightly and release it.

･

Double-tap means tapping twice quickly.

■

Touch and hold

Touch and hold an icon or menu item long.

■

Flick (Swipe)

Touch the screen and flick up/down or left/ right.

■

Drag

Touch the screen, drag to the desired position and release the finger.

■

Scroll

When whole content cannot be displayed, flick up/down/left/right displayed content to scroll (move) the display position.

■

Pinch

Touch the screen with two fingers and widen (pinch-out) or narrow (pinch-in) the fingers' distance. On some screens, pinchout to zoom in and pinch-in to zoom out.

Before Using the Terminal

Basic key icon operation

b h

Back Go back to the previous screen. Or

Home Go to the Home screen.

Recently used apps

* In this manual, each key icon operation is described

b, h

with

close a dialog box, an option menu, the Notification panel, etc.

Touch and hold the icon and drag it to to open the "Google" application.

Display thumbnails of recently used applications. You can open or quit them here (P.62). Small apps are also available (P.62).

, and n.

Switching portrait or landscape view automatically

You can set the screen orientation to switch between landscape and portrait view automatically according to the terminal orientation.

From the Home screen,

[Settings]u[Display].

[Screen rotation].

In "Auto-rotate screen", tap or

drag it right.

❖

Information

･

Even when you change the orientation of the terminal, the screen may not change to landscape view depending on what is displayed.

･

While charging with the desktop holder, the screen view may change regardless of the auto rotate screen setting.

･

Changing orientation of the terminal in nearly horizontal state against the ground does not switch to portrait view/landscape view automatically.

･

Set Auto-rotate screen to ON. Then, from the Home

screen,

feature that automatically determines whether to rotate the screen according to the movement of the terminal.

[Settings]u[Display]u[Screen rotation]

Tap [Smart screen rotation] to turn on or off a

Before Using the Terminal

Setting silent mode Capturing a still image or video

･

Setting the terminal to silent mode does not mute sounds for shutter, playback of video or music, dialpad operation sound during a call or sound emitted when is tapped, etc.

･

While silent mode is set, adjusting the "Ring volume" in "Sound & notification" (P.158) or turning up the volume by pressing the volume up key cancels silent mode.

Setting silent mode (with vibration)

Press the volume up or down key.

1 2

･

The icon in the volume control bar will change to , with silent mode (with vibration) turned on.

･

Tap to cancel silent mode (with vibration).

Setting silent mode (without vibration)

Press the volume down key for

over a second.

･

The icon in the volume control bar will change to , with silent mode (without vibration) turned on.

displayed on the screen

You can capture what is displayed on the screen. (Take screenshot/Record screen)

Capturing a still image (Take screenshot)

On the screen you want to capture,

press and hold down key for over a second at the same time.

･

Screenshot is captured and appears in the status bar.

❖

Information

･

Alternatively, press and hold P for over a second Tap [Take screenshot] to capture screenshot.

･

Drag the status bar downwardsuTap [Screenshot captured.] to check captured images in the "Album" or "Photos" application. Also, tap [SHARE] to attach captured images to an application to send or to share them.

and volume

Before Using the Terminal

Recording a video (Record screen)

Press and hold P for over a

2 3

❖

Information

･

The control panel allows you to:

- Tap to display an image from the front camera

and capture the video together with that image.

- Tap to change the image quality or orientation

of the video.

･

Drag the status bar downwardsuTap [Sc reen recording saved] to check recorded video. Tap [SHARE] to send by attaching recorded video to app, or tap [EDIT] to edit video.

second

[Record screen].

A control panel is displayed.

･

If terms of use are displayed, read them and then tap [AGREE].

Tap to start recording.

Tap the recording time button Tap to finish recording.

･

Screen recording is recorded and appears in the status bar.

･

Tap to close the control panel.

Setting Emergency mode

In case of emergency such as disaster, restrict functions to save the battery power.

Press and hold P for over a

second.

[Emergency mode]uConfirm

"IMPORTANT INFORMATION" Mark "I have read the important information"

･

All running applications end and the

[TURN ON].

terminal restarts.

❖

Information

･

To cancel Emergency mode, press and hold P for over a second or drag the status bar down on] the terminal restarts.

･

For details on available applications in emergency mode, from the Home screen,

[Emergency mode]u[IMPORTANT INFORMATION] Tap [Available apps] to see the information.

･

If you set/cancel emergency mode, you may need to reconfigure widgets or small apps (displayed in a small window) on the Home screen.

[Emergency mode]uTap [T URN OFF]

[TURN OFF]. Emergency mode is canceled and

[Settings]u[Power management]

[Emergency mode is

Before Using the Terminal

Notification LED

Notification LED provides information on the terminal status, incoming calls, mail reception, etc.

･

Notification LED when STAMINA® mode is set (P.160)

Status Indication

Red

Orange

Green

Flashing red

Flashing pale purple

* The LED blinks when the backlight is off.

❖

Information

･

If the battery level is low, the notification LED flashes in red 3 times when on.

･

When charging starts with the power off, notification LED turns on in red first.

Indicate that the battery level is 14% or less while the battery is being charged

Indicate that the battery level is 15% - 89% while the battery is being charged

Indicate that the battery level is 90% or more while the battery is being charged

Indicate that the battery level is 14% or less

Indicate missed calls, new

messages (SMS), or new Gmails exist

is pressed to turn the power

Status bar

A status bar appears at the top of the screen. In the status bar, the terminal status and notification are displayed. Notification icons appear on the left side, and status icons appear on the right side of the status bar.

Status bar

Status icon

The main status icons displayed on the status bar are as follows.

Signal strength International roaming enabled Out of service HSPA available Communicating in HSPA 3G (packet) available Communicating in 3G (packet) LTE available Communicating in LTE Connecting to Wi-Fi Communicating in Wi-Fi Connected to a Wi-Fi network with no

access to the Internet. The Wi-Fi signal is poor.

Before Using the Terminal

Bluetooth function ON Connecting to Bluetooth device Airplane mode activated Silent mode (with vibration) ON Silent mode (without vibration) ON Speakerphone ON Microphone put on mute Alarm is set NFC Reader/Writer, P2P function ON Positioning with GPS Connecting to a VPN Battery status The battery is charging

％

Battery is low (4 PUK code locked, or docomo nano UIM card

not inserted STAMINA mode ON Low battery mode ON

❖

Information

･

Status icons displayed in the status bar can be changed (P.156).

or less)

Notification icon

The main notification icons displayed on the status bar are as follows.

New email message New Gmail message New message (SMS) Problem with message (SMS) delivery New Area Mail Screenshot or screen recording saved Uploading data to Facebook Uploading data to Facebook completed Facebook setting request notification Receiving/downloading data Sending/uploading data Notification of data reception etc. via Bluetooth

communication Unmount microSD card (reading/writing

unavailable) microSD card removed Update notification Installation completed Application update notification Software update notification NFC/Osaifu-Keitai lock set on the terminal and

docomo nano UIM card NFC/Osaifu-Keitai lock set on the terminal or

docomo nano UIM card Omakase Lock set on the terminal and docomo

nano UIM card

Before Using the Terminal

Omakase Lock set on the terminal or docomo nano UIM card

Receiving a call Making a call

/during a call

Incoming call on hold*/ongoing call on hold Missed call Message is recorded in Answering Machine New voice mail Event notification for Schedule Stopwatch is running Timer in use Alarm in snooze mode Playing a track with Media Player Playing a truck in Music Watching 1Seg

/notification of reserved

watching Recording 1Seg*/notification of reserved

recording FM radio in use

USB connected MHL connected Screen mirroring connected Mobile data communication invalid Wi-Fi open network available The terminal set as media server/connection

request notification received Error message/caution message

Problem with sync

Setup guide unchecked Some notifications are hidden Notification from docomo LIVE UX

Setting USB tethering Wi-Fi tethering ON Bluetooth tethering is set 2 or more devices are set for tethering AUTO- GPS is set Omakase Lock is set Available memory on the terminal is low Notification of data transfer to microSD card

exists (available internal storage decrease) Authentication failed in docomo ID setting

Appears when switched to the Home screen etc.

Before Using the Terminal

Notification panel

When notification icons appear on the status bar, you can open the Notification panel to check the notifications, activate corresponding application, etc.

Drag the status bar downwards.

Notification

Clear

･

Clear contents on the Notification panel. Some notifications may not be cleared.

❖

Information

･

Tap b to close the Notification panel.

･

Flick left or right a notification on the Notification panel to delete from the list.

･

For some notifications, pinch in/out (P.41) the Notification panel to show/hide screen for operation such as "SHARE" and "CALL BACK".

･

You can also view notifications on the lock screen. Alternatively, you can set the terminal to hide notifications from the lock screen (P.158). Unlocking the screen shows notifications that are not displayed on the lock screen.

Quick settings panel

You can open the quick settings panel to enable or disable functions.

Drag the status bar downwards

with two fingers.

ba cde

Name of network operator

Power mana gement

･

Display "Power management" in the Settings menu (P.160).

Edit

･

Add or delete the quick settings. You can also rearrange them.

Settings

･

Display the Settings menu (P.146).

My profile

･

Display the My profile screen (P.92).

Before Using the Terminal

Quick settings

Brightness level Wi-Fi Bluetooth NFC

Hotspot

Location Airplane mode Auto-rotate

Sound

Adjust the screen brightness. Enable/disable Wi-Fi function. Enable/disable Bluetooth function. Enable/disable NFC Reader/Writer,

P2P function. Enable/disable Tethering & portable

hotspot function. Enable/disable location information. Enable/disable Airplane mode. Set whether to switch portrait/

landscape view automatically according to the terminal orientation.

Set to sound/silent mode (with vibration)/silent mode (without vibration).

Glove mode Cast screen

Enable/disable Glove mode. Set whether to display the terminal's

screen on a device that supports Google Cast.

❖

Information

･

You can also drag the Notification panel downwards to display the quick settings panel.

･

Tap b to close the quick settings panel.

Home screen

You can switch the Home screen of the terminal to "docomo LIVE UX", "Xperia Home" or "Simple Home".

･

"docomo LIVE UX" (P.71)

･

"Simple Home" (P.52)

･

Switching home applications (P.63)

Xperia™ Home screen

This section describes the Home screen displayed when the home application is set to "Xperia

a b c d

e f

™

Home".

d c

Widget : Google Search Widget : Clock Shortcuts (applications) Current home screen position

･

Flick the home screen left or right to switch. Wallpaper Apps button

™

c f

Before Using the Terminal

❖

Information

･

To change the initial home screen for operations, switch the home screen you want to change to, touch and hold the area of the Home screen where no icons are displayed

Tap .

Adding a home screen

Up to 7 home screens can be displayed.

Touch and hold an area of the

Home screen where no icons are displayed.

･

Alternatively, pinch-in on the Home screen.

Flick the Home screen left or

❖

･

right

Information

To return to the Home screen, tap h or b, or tap any home screen. To delete home screen, switch to the home screen you want to delete and then touch and hold the area of the Home screen where no icons are

displayed

Tap .

Adding a widget to the Home screen

Widget is an application which can be added to the Home screen to use. Use a widget to start an application easily.

Touch and hold an area of the

Home screen where no icons are displayed.

･

Alternatively, pinch-in on the Home screen.

[Widgets & Apps]uSelect the

widget you want to add.

･

When a settings screen appears, follow the onscreen instructions.

❖

Information

･

To return to the Home screen, tap h or b, or tap any home screen.

･

To change displaying widget size, touch and hold a

widget

Drag the blue frame. Display size for some

widgets may not be changed.

･

To delete a widget, on the Home screen, touch and hold a widget to delete displayed at the top of the screen.

Drag it to "Remove"

Before Using the Terminal

Adding a shortcut to the Home screen

You can add shortcuts of application, bookmark, etc.

Touch and hold an area of the

Home screen where no icons are displayed.

･

Alternatively, pinch-in on the Home screen.

[Widgets & Apps].

[Apps]/[Shortcuts]uSelect the

application/shortcut you want to add.

･

When a data selection screen or setting screen appears, follow the onscreen instructions.

❖

Information

･

To return to the Home screen, tap h or b, or tap any home screen.

･

To delete a shortcut, from the Home screen, touch and hold the shortcut to delete displayed at the top of the screen.

Drag it to "Remove"

Adding folders on the Home screen

You can put applications, shortcuts, etc. added to the Home screen into a folder to manage them.

From the Home screen, touch and

hold an icon

Drag it over another

icon.

❖

Information

･

To move an icon to a folder, on the Home screen, touch and hold an icon you want to move over a folder.

･

To change a folder name, tap a folderuTap the folder

Enter a folder nameuTap [DO NE].

name

･

To delete a folder, on the Home screen, touch and hold a folder to delete displayed at the top of the screen Applications, shortcuts, etc. in the folder are also deleted.

Drag it to "Remove"

Tap [DELETE].

Drag it

Changing wallpaper

You can change wallpaper of the Home screen.

Touch and hold an area of the

Home screen where no icons are displayed.

･

Alternatively, pinch-in on the Home screen.

[Wallpapers].

Before Using the Terminal

Tap any of [Album]/[Live

Wallpapers]/[Photos]/an image.

･

If you tapped [Album]/[Live Wallpapers]/[Photos], select an image and follow the onscreen instructions to set the wallpaper.

❖

Information

･

To return to the Home screen, tap h or b, or tap any home screen.

Changing theme

You can change themes for the Home screen, wallpaper of the lock screen, etc.

Touch and hold an area of the

Home screen where no icons are displayed.

･

Alternatively, pinch-in on the Home screen.

[Themes]uSelect an image.

[OK].

Simple Home screen

Set Simple Home to use Home screen and the setting menu limited to basic functions.

From the Home screen,

[Settings]u[Home]u[Simple

Home]

[OK].

･

■

Applications on the Simple Home screen

Maps Browser Settings My Apps Tools Contacts

[OK].

To set the font size to "Extra large", mark "Set font size to Extra large".

P. 1 3 9 P. 1 0 3

P. 5 4 P. 5 4

Calendar Alarm & clock Calculator Osaifu-Keitai Gmail Play Store dmenu dmarket

しゃべってコンシェル

(Shabette concier)

ｉコンシェル

(i-concier)

P. 5 6 P. 5 6

P. 1 4 1

P. 5 7 P. 1 0 8 P. 1 0 1 P. 1 0 6 P. 1 0 6 P. 1 0 6

P. 5 7

Before Using the Terminal

Media Music

Album Video 1Seg FM radio

Camera docomo mail Messaging Dial Apps Speed dial

* Applications such as "Anshin Scan", "docomo

backup", etc. appear.

❖

Information

･

To change to the standard Home screen, from the Simple Home screen, tap [Settings] Home]

You Tu be

[OK]u[docomo LIVE UX]/[Xperia™ Home].

[Exit Simple

Using speed dials

P. 5 6

P. 1 3 3

Save frequently used contacts to "Speed dial"

P. 5 6

to easily make a call or send a message.

P. 1 1 2

■

P. 1 1 8 P. 1 3 5 P. 1 1 9

P. 9 4 P. 9 4 P. 5 6

―

P. 5 3

Saving contacts

Save phone numbers and mail addresses to "Contacts" beforehand.

On the Simple Home screen,

[Speed dial]

Select a contact to save.

･

The name "Speed dial" on the Simple

[OK].

Home screen will change to the name saved in the "Contacts" application.

■

Making a call

On the Simple Home screen, select

a speed dial

･

Operation during a call (P.83)

■

Sending messages (SMS)/mail

On the Simple Home screen, select

a speed dial

[Call].

[Send message]/

[Send email].

･

How to send a message (SMS) (P.94)

･

How to send email (P.98)

･

How to send Gmail (P.101)

❖

Information

･

To change/delete/edit contacts saved in the speed dials, select a contact saved in the speed dial [MENU]uTap any of [Edit entry]/[Delete entry]/[Edit contact].

Before Using the Terminal

Using Settings

On the Simple Home screen,

[Settings].

My profile

Display Wallpaper

Themes

Brightness

Auto-rotate screen

Font s ize

Sleep

Screen lock

Check your own phone number and mail address, etc.

Set the wallpaper for the Simple Home screen or the lock screen.

Set the theme for the wallpaper on the Simple Home screen or the lock screen.

Adjust the screen brightness.

Set whether to switch portrait/landscape view automatically according to the terminal orientation.

Set font size for the "Contacts" application, etc.

Select a time duration before the screen back light turns off.

Set screen unlock method.

Sound Silent/Vibrate

Customiz e Home

More settings

Exit Simple Home

mode Ringtone Vibrate on

touch

Touch sounds

Vibrate when ringing

Change apps Reorder apps Reset

Set silent mode.

Set ringtone. Set whether to vibrate

the terminal for some operations such as specified software key operation.

Set whether to emit sound when selecting menu.

Set whether to vibrate the terminal when receiving a call.

P. 5 5

Display Settings menu on the standard Home screen (P.146).

Change to the standard Home screen.

Saving applications in My Apps

If frequently used applications, etc are saved in the "My Apps" folder, the applications can easily be activated

On the Simple Home screen, [My

Apps]

[EDIT]u[OK].

Before Using the Terminal

Mark applications to save

[DONE].

❖

Information

･

To delete applications saved in the "My Apps" folder, in Step 2, unmark applications to delete [DONE].

Tap

Changing applications on the Simple Home screen

On the Simple Home screen,

[Settings]

[Change apps]/[Reorder apps].

Select applications to change

Select applications to display/ select a location to move to.

･

[OK].

❖

Information

･

In Step 2, tap [Reset]u[OK] to restore the defaults. Note that contacts saved in the speed dials and applications saved in "My Apps" folder are not restored.

[Customize Home].

Grayout applications cannot be changed.

Xperia™ Application screen

This section describes the application screen displayed when the home application is set to "Xperia

･

a b

c d

❖

･

™

Home".

Switching Home application (P.63)

From the Home screen, .

Option menu Current displayed position of the application screen

･

Flick the application screen left or right to switch. Search for applications Application icon list

･

Some application icons are displayed with a

number of missed calls, unread mails, etc.

Information

You can also flick right from the left edge of an application screen to open the option menu. On the leftmost application screen sheet, you can flick right anywhere on the screen to open the option menu.

Before Using the Terminal

Application list

Applications displayed on the application screen are as follows.

･

For usage of some applications, separate subscription (Charged) is required.

Contacts

Open the Xperia™ phonebook application to manage contact information for your friends and family.

Dial

Open the Xperia™ phone application to make/ receive calls.

Messaging

Send and receive messages (SMS).→P. 9 4

Browser

View web pages in Browser.→P.103

Music

Play music files stored on your internal storage or microSD card.

Album

Play still pictures or videos.→P. 1 3 3

Videos

Play videos that have been downloaded or transferred to the terminal. The Wi-Fi feature allows the terminal to play videos stored on other devices.

PSN

Use the PlayStation™ Network services.

Camera

Shoot photos or videos.→P. 1 1 9

Alarm & clock

Use alarm, world clock, stop watch and timer. P. 1 4 1

Calendar

Display a calendar and manage your schedule.

Maps

Use Google Maps services, such as viewing current location, finding another location and

→

calculating routes.

P. 1 3 9

Lifelog

Keep track of your daily activities, including your number of steps and calorie consumption. This application also records your actions on the terminal, such as shooting photos and videos and listening to music.

Movie Creator

An application that automatically edits photos and videos taken with the camera.

1Seg

Watch 1Seg.→P. 1 1 2

YouTube

Play YouTube videos.→P. 1 3 5

Osaifu-Keitai

Use Osaifu-Keitai services.→P. 1 0 8

Play Store

Download or purchase various applications

→

from Google Play.

P.106

Settings

Configure settings for the terminal.→P.146

Before Using the Terminal

→

ツール

(Tools)

This contains the following applications:

Calculator

Perform basic arithmetic operations and other various calculations.

Audio Recorder

Record speech, music, and other audio with high sound quality.

Sketch

An application that allows you to create drawings or illustrations by touching the screen or to import photos and modify them.

File Commander

Search for still pictures, videos, music files,

→

downloaded files, and so on.

P.176

Send and receive emails. Multiple accounts

→

are available.

OfficeSuite

P.97

View/edit Word, Excel, and other files.

FM radio

Listen to FM radio.→P.118

TrackID

™

This application recognizes music around you and allows you to search for its title and artist.

TrackID™ TV

Use a service that provides information about the TV program you are watching.

dmenu

An application shortcut for "dmenu". In "dmenu", you can easily find contents you used in i-mode and joyful and convenient contents

→

for smartphones.

P.106

dmarket

There are various products such as music, ebooks, etc. You can purchase them that suits

→

your needs.

しゃべってコンシェル

P. 1 0 6

(Shabette concier)

Tell the character what you want to know or what you want him/her to do, and the application will interpret your words and display an answer that serves your purpose.

ｉコンシェル

(i-concier)

An application for using i-concier. i-concier is a service in which a mobile phone supports your life like a "butler" or "concierge".

IC Tag/Barcode Reader

An application that can read information written in IC tag or bar code.

docomo backup

An application for backing up to/restoring from

データ保管

your " "microSD card".

BOX (Data Storage BOX)" or

→

P. 1 4 3

Instruction Manual

Display the terminal instruction manual. You can directly start a function you want to use from the explanation (in Japanese only). * See "About manuals of SO-04G" in

"Introduction".

Before Using the Terminal

ドコモクラウド

(docomo cloud)

This contains the following applications:

docomo phonebook

A phonebook application provided by docomo. It allows you to manage your "docomo account" phonebook data in the

→

P.89

cloud.

docomo mail

Send/receive mails using DOCOMO mail address

(@docomo.ne.jp)

. Sent/received mails are saved in cloud. You can view the same mail on the multiple devices or transfer mail data easily when changing model. Pictograms and Deco-mail can be used, and

→

automatic reception also is supported.

フォトコレクション

(Photo collection)

P.94

A service for backing up photos or videos up to 5GB to cloud free of charge, then accessing the backup data from smartphones, tablets or PCs.

データ保管

BOX (Data Storage Box)

An application for using Data Storage Box. Data Storage Box is a service which allows you to upload files to easily manage them in the cloud.

Memo

An application for creating/managing memos whose data is shared with Memo application. It supports i-concier service.

Schedule

An application for creating/managing schedule whose data is shared with Memo application. It supports i-concier service. P.140

ドコモのおすすめ

(docomo's

recommendations)

This contains the following applications:

アプリ

(iD application)

An application for using "iD", electronic money offered by docomo. Once you have set up "iD" on your Osaifu-Keitai, you can hover the terminal over an IC card reader at various shops to make your shopping easier

→

and more comfortable.

Anshin Scan

P.111

An application that allows you to use your smartphone with peace of mind. It detects viruses, helps you understand which applications use your personal data, and alerts you if you are attempting to access potentially dangerous websites.

遠隔サポート

An application for using "

ト

(Anshin Enkaku Support)". "

ポート

(Anshin Enkaku Support)" is a service

(Enkaku support)

あんしん遠隔サポー

あんしん遠隔サ

that allows staff of the Call center to support the terminal operations by remote-checking

→

the display of your own terminal.

P.203

→

Before Using the Terminal

Disaster kit

An application for using Disaster Message Board, Disaster Voice Messaging Service and

→

Early Warning "Area Mail".

Visa prepaid

P.102

An application for readily issuing Visa prepaid card that is dedicated to Internet shopping. You can use it for Internet shopping instantly.

ToruCa

An application for collecting saving coupons/ convenient information from your favorite

→

P.112

shops.

shoplat

An application for obtaining points or coupons by checking in at shoplat stores. You can exchange the points for vouchers or points of shoplat stores.

docomodake 30color

A simple mini game in which docomodake

appears.7

Tap pieces in the 7-square board

to clear.

My Magazine

A search service for displaying articles in the

→

category of your choice.

Phone

P.76

An application for using phone features and

→

configuring call settings.

Media Player

P.78

Play music and videos.→P.135

Sony

This contains the following applications:

What's New

Find the latest news about music, videos, and other media and check for application updates.

電子書籍

Reader by Sony (e-books

Reader by Sony)

Purchase books or other content at the "Reader Store", Sony's eBooks store.

PS Video

You can rent or purchase desired videos.

TV SideView

View the TV program guide or use your terminal as a remote for Sony televisions or other devices.

News from Socialife

View social networking sites, news sites, and other websites in one place.

PlayStation

Connect to PlayStation to operate.

Xperia™ Lounge Japan

An application that provides information about products and campaigns from Sony Mobile Communications, Inc.

Evernote

Create memos, images, audio files, and other content and manage them in one place.

Before Using the Terminal

Instagram

An application that allows you to freely edit photos and videos taken with your terminal and share them easily with people around the world.

Twitter

Official Twitter client application. Post a short message on the website and communicate with someone else.

Facebook

Facebook is a social networking service that allows you to build closer relationships with your friends, family, colleagues, or classmates and to know what is going on in the world.

Messenger

A chat application that allows you to send messages and stickers to your Facebook friends or cellphone contacts.

Google

Search information in the terminal and web

→

pages by keywords.

P. 6 4

Voice Search

Use Google Voice Search.→P. 6 4

Chrome

View web pages in Google Chrome.

Gmail

Send and receive mails from/to a Google

→

account.

P.101

Google+

The client application for the SNS offered by Google.

Play Movies & TV

Rent movies from Google Play.

Play Books

Download books from Google Play.

Play Games

Download games from Google Play.

Drive

View/edit files stored in Google Drive.

Photos

Play photos and videos. You can also backthem up to Google accounts.

Hangouts

Send and receive messages with photos, emoji, and more. You can also make voice and video calls.

Google Settings

Configure settings for Google applications.

❖

Information

･

Some pre-installed applications can be uninstalled. Even if uninstalled, some applications can be downloaded from "Play Store" (P.106) etc. again.

･

Some applications require downloading and installation. If downloading an application is not available, set to allow to download (P.164).

･

Having multiple applications running can consume more battery power, resulting in fewer hours of use. For this reason, it is recommended to quit applications that you are not using. To quit an application, nuFlick left or right on its thumbnail.

Before Using the Terminal

Adding an application to the Home screen

Add shortcuts of application to the Home screen.

On the application screen, touch

and hold an icon you want to add to the Home screen.

･

For the application icons in a folder, drag out from the folder.

Drag it to "Add to Home screen"

displayed at the top of the screen.

･

When the Home screen is displayed, drag it to a position to locate the shortcut.

Uninstalling an application

･

Before uninstalling application, back up contents related to the application that you want to save including data saved in the application.

･

Some applications may not be uninstalled.

On the application screen, tap

or flick right from the left edge of the screen

Tap an application icon with .

[OK].

[Uninstall].

Adding a folder to the application screen

When the order of application icons is set to "Custom order" in the option menu (P.55), you can manage your application icons on the application screen by putting them in folders.

On the application screen, touch

and hold an application icon

Drag it over another one.

❖

Information

･

To move an icon to a folder, on the application screen, touch and hold an icon you want to

Drag it over a folder.

move

･

To take out an application icon from a folder, tap the

Touch and hold the application iconuDrag it

folder to a place you want to locate.

･

To change a folder name, tap a folderuTap the folder

Enter a folder nameuTap [DO NE].

name

Rearranging application icons

When the order of application icons is set to "Custom order" in the option menu (P.55), you can rearrange your application icons as you like.

On the application screen, touch

and hold an iconuDrag it to any position you like.

Before Using the Terminal

❖

Information

･

While sorting application icons, drag an icon to the right edge of the application screen to add an application screen.

･

Set "Alphabetical", "Most used", or "Installed" to automatically rearrange the icons.

Task manager

You can check the recently-used applications and end them. You can activate a small app (application displayed in a small window) which can be used while using another application.

Opening recently-used application window

Display recently used applications in thumbnail list and activate.

❖

･･

･

Information

Tap a thumbnail of application to activate. Flick left or right a thumbnail of application to delete it from the list. To quit all applications and delete them from the thumbnail list, tap .

Small apps

You can use a small app (application displayed in a small window) such as Browser while using another application. Applications downloaded from Google Play or widgets can be added to small apps.

Using small apps

❖

･

Your set small apps will appear in the Favorites bar at the bottom of the screen.

Select a small app to use.

Information

If several small apps are set, flick left or right on the Favorites bar to see them. To close a running small app, tap .

Before Using the Terminal

Adding small apps

･

Touch and hold the small app or

widget you want to add the Favorites bar.

❖

Information

･

Alternatively, select an app/widget in the small app list to activate a small app.

･

In the small app list, tap u[Play Store]/[Widgets] to install a new small app from Google Play or add a widget to small apps.

･

To delete a small app from the Favorites bar, touch and hold that small app outside the Favorites bar

･

To delete a widget or small app, in the small app list, tap Select a widget or small app to deleteu[OK].

Small apps list appears.

Drag it to displayed

Tap [O K].

[Delete widget]/[Uninstall small app]

Drag it to

Switching Home application

You can switch the Home application of the terminal to "docomo LIVE UX", "Xperia Home" or "Simple Home".

From the Home screen,

[Settings]u[Home].

Tap any of [Simple Home]/

[docomo LIVE US]/[Xperia Home]u[OK].

･

When you tap [SImple Home], confirm the content and tap [OK].

･

Home application, lock screen,

phonebook application and player application for videos or music are set all at once to "docomo" or "Xperia

❖

Information

･

When the home application is switched, widgets or shortcuts on the screen may not be displayed correctly depending on home screen layout etc.

･

To set the home application, phonebook application, or player application for videos or music indivdually, from the Home screen,

[Setting]u[Personalization]uTap [Prefe rred

apps settings].

™

Before Using the Terminal

Searching information in the terminal and web pages

Enter a word in the search box to browse the information in the terminal or on the Internet.

From the Home screen, tap the

Google search widget.

Enter a search word.

･

Character entry (P.64)

･

The search candidate list appears.

Tap an item or of software

keyboard.

❖

Information

･

Alternatively, from the Home screen, u[Google] to activate the "Google" application.

･

In Step 1, the explanation screen for Google Now may appear. Follow the onscreen instructions.

･

When applications appear in Step 2, select an application to activate.

Using Google Voice Search

Enter a search word by voice.

From the Home screen, of the

Google Search widget.

Speak a search word to the

microphone.

❖

Information

･

Alternatively, from the Home screen, tap u[Voice Search] to activate the "Voice Search" application.

Search settings

You can set the language to use for searching and the type of data you want to find when searching your terminal.

From the Home screen, tap the

Google Search widget.

Flick right from the left edge of the

screen

[Settings].

Select an item.

Character entry

Enter characters using the software keyboard which appears when you tap the character input box in a mail, phonebook, etc.

❖

Information

･

To hide software keyboard, tap displayed at the lower left of the screen.

･

Touch and hold a text on the character entry screen to display the enlarged text.

Before Using the Terminal

POBox Plus

ド

(Xperia™ Japanese keyboard

日本語入力使い方ガイ

Online help)

Character input method for the terminal is set to"Xperia default when the language is set to (Japanese). Details on using Xperia Japanese keyboard are explained in "POBox Plus

ガイド

™

Japanese keyboard" by

日本語

使い方

(Online help)".

On the character entry screen, of the quick tool bar.

･

Details of the quick tool bar (P.67)

･

If the quick tool bar does not appear, tap (for character mode of "Alphabet" and "Numeric", tap /

to switch to "Kana", then

appears).

[Help & Tips].

Selecting keyboard

From the Home screen,

[Settings].

[Language & input]u[Current

Keyboard]

Tap any of [Xperia™ Chinese

keyboard]/[Xperia™ keyboard]/

™

[Xperia

Japanese keyboard].

❖

Information

･

When the language is set to English, the default input method is set to "International keyboard". To use the Japanese keyboard, tap [Xperia keyboard] in Step 3. In this manual, explanations are given only for "Xperia

･

You can also select a keyboard by tapping displayed at the lower right of the screen when entering characters.

™

Japanese keyboard".

™

Japanese

Software keyboard

For Xperia™ Japanese keyboard, the following software keyboard can be used.

･

Character input method (P.67)

Keypad

QWERTY

❖

Information

･

Besides using the software keyboards, handwriting input and voice input are available for entering characters.

Keyboard with the same key arrangement as a mobile phone. Repeatedly tap a key to select a character (multi-tap input). Flick input is also available.

Keyboard with characters allocated in the same arrangement as general PCs. Enter Japanese in Roman character. Flick input is also available.

Before Using the Terminal

Switching software keyboard or changing the settings

Display the tool list to switch between software keyboard and handwriting/voice input, use plug-in applications (extensions), or change the settings.

On the character entry screen,

of the quick tool bar.

･

Details of the quick tool bar (P.67)

･

If the quick tool bar does not appear, tap (for character mode of "Alphabet" and "Numeric", tap /

to switch to "Kana", then

appears).

Keyboard layout

Switch to QWERTY/ Switch to keypad

One-handed keyboard

My Words Settings

Keyboard skins Online help

Set software keyboard (Keypad or QWERTY ) for each character mode.

Switch to QWERTY/keypad.

Change the keyboard size for onehanded operation.

P. 7 0 Change Xperia™ Japanese

keyboard settings. Change software keyboard skin. P. 6 5

For beginners

Handwriting docomo voice

input Google voice

typing Download

Contact Picker

2.3

Select "Online help" to display "POBox Plus

(Online help for Xperia keyboard)" (Japanese) (P.65). Select "Simple keyboard" to switch to an easy-to-see software keyboard. Select "Reset" to restore the settings and design of the software keyboard to their factory defaults.

Switch to handwriting input. Switch to docomo voice input.

Switch to Google voice typing.

Download plug-in applications (extensions) from website.

P. 6 9

日本語入力使い方ガイド

™

Japanese

Before Using the Terminal

Character input method

When you tap a key on the software keyboard, candidates list for the entered characters appears. Tap a word you want to enter from the candidate list, text can be input one after another.

a b

Keypad

e h

h d

j c

Quick tool bar

Display shortcuts of frequently-used functions. Tap

to display the tool list (P.66).

QWERTY

Handwriting input

i c

i g

Show/hide the quick tool bar.

Characters assigned to a key appear in reverse order.

/ Appears when entering numbers, tap to switch onebyte/two-byte character.

/ / Appears in alphanumerics input mode, t ap to switch lower case, capitalization and upper case.

Move the cursor to the left.

Show/hide list of symbols, facemarks, etc.

/ / Appears before fixing character in Kana mode and switches among (conversion) candidate list/ katakana) conversion candidate list.

The character mode switches "Kana" "Numeric" in order.

/ / Touch and hold Display the tool list (P.66).

Delete the character before the cursor.

Move the cursor to the right. When there is an unfixed character string with the cursor at the right end, tap to enter the same character as the one at the end (Except for Handwriting input).

/ /

予測

(prediction) candidate list/変換

英数カナ

(alphanumeric/

→

"Alphabet"

Enter spaces.

In Kana mode, highlight and select word in the candidate list.

Before Using the Terminal

→

Enter a line feed.

Appears before fixing character and fixes the character. * In some screens, , "

Return to keypad/QWERTY.

❖

Information

･

To return to the display before conversion after the conversion is fixed, tap displayed in

(associative) candidate (except in handwriting input mode) etc.

･

To enlarge the display area, tap in the candidate list. To display the software keyboard, tap or [

る

･

For Handwriting input, tap an icon at the upper left of entered character to display candidates for the entered character. Recognized character is displayed in light blue and characters are displayed at the bottom of candidate list in different colors by type.

･

For Handwriting input, the following operations are available.

- When entering 2 or more characters and tapping

- When entering characters, tap to delete

･

Note the following when you use Handwriting input.

- For voiced sound and semi voiced sound mark,

- For punctuation mark and lower case, enter in the

実行

(Done)", "

(Close)].

the icon at the upper left, appears. Tap to combine entered 2 characters to 1 character.

entered characters.

enter in the right upper part of the input screen.

lower part from the center of the input screen.

(Go)", etc. appear.

(Next)", "完了

つながり予測

Flick input

Flick up/down/left/right to enter characters in each column of kana syllabary.

な

Ex: Entering characters in " You can ent e r "

に

", up for "ぬ", right for "ね" and down

for "

の

for "

閉じ

な

" only by tapping. Flick left

" column

Multi-tap input

Tap the same key continuously to enter the assigned character. To enter a character assigned to the same key, wait for changing color of tapped key to the original (approx. 1 second), then enter the next character (for entering the next character soon, tap to move the cursor). With the key in the original color, tap to enter the last entered character again.

あお

Ex: Entering "

Tap "あ" onceuWait approximately

1 second (until the key color returns to the original).

Before Using the Terminal

Tap "あ" 5 times.

Tap "あ" onceu(Immediately) .

Tap "あ" 5 times.

❖

Information

･

To switch the input method between "Flick input" and "Multi-tap input", tap in the quick tool bar on the character entry screen

[Input method], then select the desired

method] item.

[Settings]u[Input

Editing text

On the character entry screen, double-tap character you want to edit so that text edit menu appears at the top of the screen. Drag

or to change the character string to

select.

(Select all) (Cut) (Copy) (Paste)

(Complete)

❖

Information

･

To paste a copied or cut character string, touch and hold a position where you want to insert [PASTE]. When text is already entered, tap a position where you want to insert

Select all text. Cut a selected character string. Copy a selected character string. Paste a copied/cut character

string. Close the edit menu.

Tap

Tap [PASTE].

･

Edit menu icons vary by applications.

･

In the landscape screen, editing menu may not be displayed.

･

On some applications, the function may not be available.

Quoting contacts

If contacts are registered to the Contacts, you can use "Contact Picker 2.3" to enter contact information when entering characters.

On the character entry screen,

of the quick tool bar.

･

Details of the quick tool bar (P.67)

･

If the quick tool bar does not appear, tap (for character mode of "Alphabet" and "Numeric", tap /

to switch to "Kana", then

appears).

[Contact Picker 2.3]uTap

"CONTACTS" tab.

Tap the contact to pick up.

Mark items you want to

❖

Information

･

"HISTORY" tab displays contacts that are picked up when entering characters.

quote

[OK].

Before Using the Terminal

My Words

On the character entry screen,

of the quick tool bar.

･

Details of the quick tool bar (P.67)

･

If the quick tool bar does not appear, tap (for character mode of "Alphabet" and "Numeric", tap /

to switch to "Kana", then

appears).

[My Words].

Tap the character input box for

"Reading"

Tap the character input box for

"Word"

[OK].

❖

Information

･

To delete, in Step 3, mark words in My Words to

delete

Fill it out.

Tap [DELETE].

Setting character entry

For each input method, you can make settings related to character entry.

From the Home screen,

[Settings]u[Language &

input].

Tap any of [Xperia™ Chinese

keyboard]/[Xperia [Google voice typing]/[MojiHenshu]/[Xperia keyboard].

･

Tap an item displayed on the screen to set.

❖

Information

･

The items vary depending on the input method.

･

When entering characters with Xperia™ Japanese keyboard, on the character entry screen, tap of the quick tool bar screen for Xperia

™

keyboard]/

™

Japanese

[Settings] to display the settings

Japanese keyboard.

Before Using the Terminal

docomo LIVE UX

Home screen

Tapping h displays Home screen which consists of up to 7 screens you can use flicking left and right.

d e

Widget : Google Search

Machi-chara

Application icon

Apps button

･

Display the application list screen (P.73).

Application icons

･

This icons are always displayed even when the Home screen is switched.

Wallpaper

Current home screen position

･

Flick the Home screen left or right to switch.

My Magazine button

･

Display My Magazine (P.76).

ひつじのしつじくん®

(Butler Sheep)"

©NTT DOCOMO

Managing the Home screen

Adding/Moving applications etc. to the Home screen

Move application icons or add widgets or folders to the Home screen.

Touch and hold an area of the

Home screen where no icons are displayed.

Any of [Show apps]/[Show

widgets]/[Create folder]/[MachiChara display setting].

･

To move/add applications or widgets, touch and hold the icon Home screen display area at the bottom of the screen.

･

When you tap [Machi-Chara display setting], make basic settings/Machichara setting.

❖

Information

･

To move applications into a folder, touch and hold an

icon

Drag it over a folder.

･

Tap a fold eruTap a folder name to changer the folder name.

Drag it to the

docomo LIVE UX

Moving an icon on the Home screen

From the Home screen, touch and

hold an icon you want to move.

Drag it anywhere.

･

To move to another Home screen, keep touching the icon and drag it to left or right.

Deleting an icon from the Home screen

From the Home screen, touch and

hold an icon you want to delete.

Drag to "Back to apps list"/

"Remove from Home".

Uninstalling an application or widget from the Home screen

･

Before uninstalling application, back up contents related to the application or widget that you want to save including data saved in the application or widget.

･

Some applications or widgets may not be uninstalled.

From the Home screen, touch and

hold an icon you want to uninstall.

Drag to "Uninstall"u[OK].

❖

Information

･

You can disable some applications or widgets which cannot be uninstalled by dragging to "Disable app" in Step 2 (P.161).

Changing Kisekae

Touch and hold an area of the

Home screen where no icons are displayed.

[Change Kisekae].

Tap a Kisekae you want to

❖

Information

･

Alternatively, from the Home screen, [Kisekae].

･

You can add Kisekae contents by tapping [Search on the web] to download from website. To delete added Kisekae contents, tap a Kisekae to delete

[Delete].

change

[SET].

[DELETE]

docomo LIVE UX

Changing wallpaper

Touch and hold an area of the

Home screen where no icons are displayed.

[Change wallpaper].

Tap a wallpaper you want to

change.

･

Tap [See more wallpapers] to select from "Album", "Photos", "Live Wallpapers", or "Xperia

Follow the onscreen instructions

to set wallpaper.

™

Adding a home screen

Touch and hold an area of the

Home screen where no icons are displayed.

[Home screens].

･

To delete home screen, tap of the home screen thumbnail you want to delete.

･

To sort home screens, touch and hold a home screen thumbnail you want to

Drag it to any position.

sort

❖

Information

･

Alternatively, pinch-in on the Home screen to display the home screen list.

･

Up to 7 home screen can be set.

･

To return to the Home screen, tap h or b, or pinch-out.

Application screen

From the Home screen, .

･

Flick the Home screen downwards to

display the application screen.

Apps/Widgets/Wallpapers tab

･

Display application icons/widgets/wallpaper list.

Application icon list

･

Applications on the Home screen are not displayed in the list.

Home screen display area

･

Flick left or right to switch.

Option menu

･

View optional menu such as Settings.

Recommends button

･

Install applications recommended by DOCOMO (P.74).

d e

docomo LIVE UX

Current position in the list screen

･

Display by application icon/widget list.

❖

Information

･

To close the application screen, tap b or h, or flick up the Home screen display area at the bottom of the screen.

Customizing the application screen

Moving/Adding an application or widget to the Home screen

On the application screen, touch

and hold an icon you want to add to the Home screen.

Drag it to the Home screen display

area at the bottom of the screen.

Uninstalling an application or widget

Some application icons and widgets can be deleted from the application screen.

･

Before uninstalling an application or widget, see "Uninstalling an application or widget from the Home screen" (P.72).

On the application screen, touch

and hold an icon of application you want to uninstall.

Drag to "Uninstall"u[OK].

❖

Information

･

You can disable some applications or widgets which cannot be uninstalled by dragging to "Disable app" in Step 2 (P.161).

Moving application in the application icon list

On the application screen, touch

and hold an icon to move.

Drag it anywhere.

Installing "Recommends" applications

Install applications recommended by DOCOMO.

On the application screen,

[Recommends].

おすすめアプリを見る

[

recommended apps)].

Select an application to use.

･

Download screen appears. Follow the onscreen instructions.

(See

docomo LIVE UX

Display all apps

It is a function to search where an application is located.

From the Home screen,

･

Tap an application.

･

[Display all apps].

All applications are displayed in a list.

The screen such as the Home screen, application list, or the folder where the tapped application icon is located appears. The application icon is selected in the screen.

Backing up and restoring the Home screen

You can use docomo LIVE UX data backed up on the docomo cloud to restore the layout of applications, widgets, and other items on the Home screen. Once it is restored, a page for docomo services is added to the bottom of the Home screen.

･

To use the backup and restore features, you need to set up your "docomo ID" (P.162).

Backing up the Home screen

On the Home screen,

Restore].

･

[Layout backup and

For the first activation, confirm the Application Privac y Policy, Precautions, and Software License Agreement, then tap [AGREE].

[BACKUP].

Restoring the Home screen

On the Home screen,

Restore].

[Restore the latest backup data]/

[Restore from backup data list].

･

[Restore].

[Layout backup and

If you selected [Restore from backup data list], select the data you want to

Tap [Re store].

restore

docomo LIVE UX

Backup settings

On the Home screen,

Restore].

Backup automatically

Multi-Device Sync

Sync on Wi-Fi only

Sync while Roaming

Delete backup data

Open source licenses

Ter ms of use Help About

[Layout backup and

Set whether to periodically back up the home screen information for the docomo LIVE UX.

Set whether to send a notification to your other devices when an application has been installed.

Set whether to back up or sync data only when the terminal is connected via Wi-Fi.

Set whether to back up or sync data during international roaming.

Delete your backup information from the server.

View open source licenses.

View the terms of use. View the operation guide. View the application's version and

other information.

Using My Magazine

My Magazine is a search service for displaying articles for categories you selected. It helps to set search words depending on your tendency of read articles or profile information to come close to your preference.

From the Home screen, .

･

When you activate for the first time, select categories on the selection screen for categories then tap [OK].

･

Flick the article list screen left or right to switch categories.

･

Tap [See more info] to show other articles in the category.

Tap an article you want to read.

❖

Information

･

Alternatively, flick the Home screen up to display the article list.

Setting a category

From the Home screen,

setting].

Mark the category you want to

display

[Display category

[OK].

docomo LIVE UX

Changing My Magazine use setting

From the Home screen,

[My Magazine use setting].

[Use]/[Not use]u[OK].

❖

Information

･

You can also set by tapping on the application screen

[My Magazine settings]

[My Magazine use setting].

Checking Home application information

On the application screen,

[About].

docomo LIVE UX

Phone

Making/Receiving a call

Making a call/video call

From the Home screen, u"Dial"

tab.

Enter a phone numberu.

･

To make a video call, enter a phone

number

･

Tap to delete the number.

When the call is finished, .

･

To end a video call, tap the screenuTap

❖

Information

･

In Step 2, tap without entering a phone number to enter the phone number registered as the latest call in Recent calls.

･

To a cti vate X per ia™ phone application, from the Home screen, tap

･

You can display contact, create message (SMS), or make call again from the call end screen.

･

With VoLTE, you can make high-quality voice and video calls. You can also switch between voice and video calls. To use VoLTE, both parties must meet the following requirements.

- Both terminals support VoLTE.

- Both parties are in a Xi service area. (VoLTE is not available outside a Xi service area or during international roaming.)

Tap [Video cal l].

[Dial].

- "Preferred network type" in "Mobile networks" is set to "LTE (preferred)/3G/GSM" or "LTE/3G" (P.190), and "Call mode" is set to "VoLTE/3G" (P.88).

･

On a video call, both speakers can see each other while talking.

- When you make a video call, voice call and packet communication charges will apply. When you receive a video call, packet communication charges will apply.

- Video calls are based on best-effort communication (which optimizes transmission speed depending on how busy your network is), so the quality of video images varies depending on your network environment.

- If your terminal fails to switch to a video call while on a voice call, a massage appears on the screen, and the voice call continues.

- Since imaging for video call varies by terminal model, your terminal and the other party's terminal may show different image in scope.

Phone

Emergency call

Emergency call Phone

Police call Fire and emergency rescue Coast guard

❖

Note

･

This terminal supports "Emergency call location information". If you use the terminal to place a call to emergency numbers such as 110, 119, or 118, the information of a location where you are calling from (location information) is automatically notified to the Emergency call acceptance organization such as the Police Station. The Emergency call acceptance organ ization may not be able to figure out your exact location depending on the location where you place a call or radio wave condition. If you make a call hiding your caller ID, such as by entering a phone number with "184" for each call, the location information and phone number are not notified. However, the Emergency call acceptance organization may decide to obtain the location information and phone number regardless of your settings when they consider it is necessary for lifesaving, etc. Note that the areas/time for which the "Emergency call location information" is ready to be used vary depending on the preparatory state of each Emergency call acceptance organization.

number

110 119 118

･

When calling 110, 119 or 118 for emergency from the terminal, tell that you are calling from a mobile phone, and give your phone number and your current location precisely for checking callback from the police/fire department. Also, make a point to call in a stationary position to prevent the call from being dropped. Do not power off the terminal for at least 10 minutes after the emergency call just in case the Police or Fire/Ambulance may have to get in contact with you.

･

Note that you may not connect to the local Fire Department or Police Station depending on where you are calling from.

❖

Information

･

If docomo nano UIM card is not inserted to the terminal, emergency calls (110, 119, 118) cannot be made in Japan.

･

You ca n mak e an e merg en cy cal l by t appi ng [Emergency call] on the lock screen. In Japan, however, on the PIN code entry screen, while PIN code locked or while PUK locked, emergency calls (110, 119, 118) cannot be made.

･

If you call to emergency numbers with Call Blocking is ON, the setting turns off automatically.

･

Emergency calls may not be available on some networks.

･

The video call feature does not support emergency calls to 110, 119, and 118.

Entering pause (,)/(;) to send

For using services requiring entry of number during a call such as check of the balance of a bank account, reservation of tickets, etc., enter an additional number to a phone number beforehand and make a call.

Phone

■

Using 2-second pause (,)

Added number will automatically be sent approximately 2 seconds after the call is made.

From the Home screen, u"Dial"

tab.

Enter a phone number

2–sec pause]uEnter an additional

number

When the call is finished, .

■

Using a wait (;)

Sending is automatically on standby when the call is made and a confirmation screen asking if you send the additional number appears.

From the Home screen, u"Dial"

tab.

Enter a phone number

wait]

On a confirmation screen, [YES].

When the call is finished, .

Enter an additional number

Making an international call (WORLD CALL)

For details on the WORLD CALL, refer to NTT DOCOMO website.

･

Send replacing "+" by an international access code.

[Add

From the Home screen, u"Dial"

tab.

Dial + (touch and hold [0])uEnter

Country code, Area code (City code), recipient number in the

order

･

When "Auto conversion" in International dial assist is marked (P.194), the international dial assist screen appears when sending. Tap [Call original] or [Call].

When the call is finished, .

❖

Information

･

If the area code begins with "0", omit "0". However, "0" may be required to dial to some countries or areas such as Italy.

Phone

Receiving a phone/video call

･

When a phone or video call comes in, the incoming call screen appears. If the backlight is on (except on the lock screen) or an application is running, a notification appears at the top of the screen (P.82).

On the incoming call screen, drag

(left) to (right).

･

To accept a video call, drag (left) to

(right). To answer a call with voice

only, drag (left) for "Voice only" to

(right).

When the call is finished, .

Answering a video call with the camera turned off

You can answer a video call without sending your image to the other party.

On the incoming call screen, drag

"Response options" up.

[Answer without video].

Putting a call on hold

If you are not available to answer a call, you can put the call on hold.

On the incoming call screen, drag

"Response options" up.

[Put caller on hold].

The other party will hear a message saying that the call is on hold.

When you are ready to answer the

call, drag (left) to (right).

･

The call will be put on hold until you drag (right) to (left) or the other party ends the call.

Answering an incoming call with Answering Machine

Even when Answering Machine is not set, you can activate Answering Machine manually.

On the incoming call screen, drag

"Response options" up.

[Reject with Answering Machine].

❖

Information

･

If there is a recorded message, is displayed in the status bar. Drag the status bar downwards [Answering Machine] to display the Messages screen, where you can check the recorded message.

Tap

Phone

Muting the ringtone for an incoming call

While receiving a call, press the

volume key or

❖

Information

･

You can stop vibration by pressing the volume key or

when silent mode (with vibration) is set.

･

On the Home screen etc., press the volume key to adjust the ringtone volume.

Declining a call

When receiving a call, drag

(right) to (left).

Rejecting an incoming call and sending a message (SMS)

If you are not available to answer a phone or video call, you can decline the call and send a message (SMS). Message to send is registered in advance, and you can edit it if necessary.

On the incoming call screen, drag

"Response options" up.

[Reject with message].

Tap a message to send.

･

Tap [Write new message] to create and send a message.

❖

Information

･

To edit existing message, from the Home screen, tap

[Call settings]u[Reject call with message]

Select an existing message and edit itu[OK] in

advance.

Receiving a phone/video call when an application is running

If the backlight is on (except on the lock screen) or an application is running when a call comes in, a notification appears at the top of the screen.

(Accept).

You can start a voice conversation.

･

You can answer an incoming video call with voice only.

･

To accept a video call, tap .

･

To decline a call, tap (Decline).

･

Tap a notification that appears, and you can see the incoming call screen.

When the call is finished, .

Phone

Operations during a call

On the Calling screen, you can set speakerphone or mute, or enter a phone number to make a call to another party.

■

Screen displayed during a voice call

a b

■

Screen displayed during a video call

While on a video call, you will see the other party's image in a parent window, and your image in a child window, with the operation area hidden. Tap the screen to show the operation area.

e b

a d

c d e

f g

h i j

b c d e f g

High-quality call

･

Displayed during a VoLTE call.

･

Displayed during outgoing and incoming video

calls and during incoming voice calls. Call duration time Photo/image set in the phonebook entry Number of the other party Name of the other party Dial key : Send a push signal while on a call. Audio output : Turn the speakerphone on/off.

･

Other party's voice can be heard from the speaker

and handsfree call can be made.

･

Video calls are made or received with the

speakerphone turned on.

･

If your terminal is connected to a Bluetooth

device or the like, you can tap the icon to switch

between audio output devices. Mute : Turn the microphone on/off during a call.

m n

o p k

Phone

Video call : Switch from a voice call to a video call.

･

When you tap this icon, the other party will see a message asking for permission to switch to a video call. If the other party accepts it, you can switch to a video call.

･

If the other party has declined to switch to a video call, is outside a Xi service area, or is using a terminal that does not support VoLTE, a message appears indicating that the call cannot be switched. Tap [OK] to continue the voice call.

･

"Hold" is displayed during a 3G voice call.

Option menu (voice call)

･

Add call

[More options]

･

Hold call [More options] put a voice call on hold or cancel the hold.

･

To add a call, "Call waiting" subscription is

required (P.87).

･

"Add call" is displayed during a 3G voice call.

End a call

Parent window for a video call (other party's image)

･

the other party's image.

Child window for a video call (your image)

･

Switching between cameras for sending your image

･

Tap this icon to switch between cameras for

shooting your image.

Tap [Add call] to add a voice call.

Tap [Hold call]/[Resume call] to

is displayed if your terminal cannot receive

is displayed if the camera is off.

Option menu (video call)

･

Dialpad

Open a dialpad while on a video call.

･

Change to voice

Tap [Change to voice] to switch to a voice

call.

･

Switch videos

Tap [Switch videos] to switch the display area between the parent window (showing the other party's image) and the child window (showing your image).

Camera on/off

･

Select whether to send your image to the other party or hide it.

❖

Note

･

Do not bring the terminal close to your ear with the speakerphone on to avoid from hearing damage.

❖

Information

･

If you switch to a different screen, such as the Home screen, while talking on the phone, making a call, or putting a call on hold, the status bar will change color. Drag the status bar downwards notification to return to the phone application screen.

･

Switching to a different screen, such as the Home screen, while on a video call, turns the camera off.

Tap th e

Adjusting the earpiece volume

Press the volume key during a call.

Phone

Call history

Incoming call and outgoing call are displayed by chronological order in the Recent calls screen. Up to 500 items can be displayed.

Showing call history

From the Home screen, uTap

"Recent calls" tab.

■

Recent calls screen

b c

Phonebook

･

The phonebook list screen appears.

All tab

Phone number/name

Incoming tab

Outgoing tab

Voice call button

･

Tap this button to make a voice call to the corresponding phone number in the call log.

Date

d e

History

･

The details of an incoming or outgoing call (Outgoing, Incoming, or Missed call) are displayed.

Adding a number from the Recent calls to Phonebook

From the Home screen, uTap

"Recent calls" tab

number

･

Alternatively, on the Recent calls screen, touch and hold a phone number number before call]

[Add new contact]/[Add to the

existing contact].

･

When “Add to the existing contact” is selected, select a contact to save to.

On the profile edit screen, enter

necessary information such as name.

･

To add items, tap [Add other items].

[Save].

[Register].

Tap a phone

[Register].

[Edit

Phone

Deleting a call history

From the Home screen,

"Recent calls" tabuTouch and hold an incoming/outgoing history you want to delete.

[Delete from call log]u[OK].

❖

Information

･

To delete all the entries in the call log, on the Recent calls screen, tap the "All" tab Mark "Select all"u[Delete]uTap [Delete].

･

Voice and video calls are not distinguished in the call log.

[Delete log]

Displaying missed calls

When you have missed calls, appears in the status bar.

Drag the status bar downwards.

[Missed call].

･

If an application selection screen is displayed, select the application you want to use, then tap [JUST ONCE]/ [ALWAYS].

❖

Information

･

When there is a missed call, you can make a call or send message (SMS) to the caller of the missed call from "CALL BACK"/"MESSAGE" below "Missed call" in the Notification panel. For multiple missed calls, number of calls appears below "Missed call".

･

A missed call notification and the number of missed calls are displayed on the lock screen. Double-tap the notification to see the Recent calls screen.

Answering Machine

When Answering Machine is set, the answering message is played when you cannot answer an incoming call and message from the caller can be recorded even if you are not subscriber of Voice Mail Service. Up to approximately 60 seconds per one can be recorded.

･

Answering Machine is not available for video calls.

From the Home screen,

[Call settings]u[Answering

Machine].

Answering Machine

Pick up after Use while

roaming

Set whether to use Answering Machine.

Set a ringing time for answering. Set whether to use Answering

Machine when you stay abroad.

Phone

Greetings

Messages

❖

Information

･

If there is a recorded message, is displayed in the status bar. Drag the status bar downwards [Answering Machine] to display the [Messages] screen, where you can check the recorded message.

･

To delete recorded message, touch and hold a message

･

The number of messages that can be stored depends on the amount of available memory on your terminal.

Switch the answering message language to Japanese or English or record a message. To record message, tap [Record new greeting] and follow the onscreen instructions.

Check recorded messages.

Tap [Delete]/[Delete All]u[OK].

Tap

Call settings

You can set the network services, register call rejection or edit Reject call with message.

From the Home screen,

[Call settings].

Network

Voice mail

service

Call forwarding

service Call

Waiting

Caller ID notification

Nuisance call blocking service

Record caller's message when you cannot answer an incoming call.

Forward a call when you cannot answer an incoming call.

Put the current call on hold and answering an incoming call or making a call to another party.

Notify the display of the recipient phone of your phone number.

Phone

Network

Caller ID

service

display request service

Second call settings

Call notification

English guidance

Remote operation settings

Public mode (power OFF) setting

Roaming settings

Phone ringtone Also vibrate for calls

Dialpad tones

Answering Machine

Request number notification for calls without phone number with guidance.

Notify you when a call comes

in during another call. Notify incoming calls by

message (SMS) while the power is off or you are out of service area.

Switch the voice guidance to English or Japanese.

Set to operate Voice Mail Service or Call forwarding Service using land-line phone, public phone or DOCOMO mobile phone, etc.

While the terminal is OFF or in Airplane mode, a guidance message indicating that the receiver cannot answer the call is heard on the caller's terminal and then the call ends.

Set to reject incoming calls overseas or use roaming guidance (P.193).

Set ringtone (P.159). Set whether to vibrate the

terminal when receiving a call.

Set whether to emit dialpad operation sound.

P. 8 6

Call Blocking

Set whether to reject incoming calls for numbers not in the phonebook, private, pay phone and unknown.

Reject call with message

Sub address settings

Prefix settings

Edit/set a message (SMS) to be sent when rejecting an incoming call (P.82).

Set whether " " in phone number is identified as a sub address separator.

Microphone noise suppression

Equalizer

Speaker voice enhancement

Slow talk

Call mode Contact docomo*2Make a call to General

Make the voice clear to understand for the other party during a call.

Adjust sound quality during a call.

Make a voice clear to understand during a call.

Slow the caller’s talking speed to make the call to be heard slowly.

Set a network mode.

Inquiries, inquiries for damage, theft or loss overseas or damage overseas.

Phone account settings

Set Internet phone (SIP) account.

*1 Not available for video calls. *2 Not displayed if a docomo nano UIM card is not

inserted.

Phone

Phonebook

On the phonebook, you can enter various information for contacts, for example, phone numbers, mail addresses and various service accounts.

Displaying phonebook

From the Home screen, [

ウド

(docomo cloud)]u[docomo

phonebook]

･

The phonebook list screen appears.

❖

Information

･

To use cloud service for the phonebook, "docomo phonebook" application is needed. When you use the "docomo phonebook" for the first time (including after resetting the application) or log in to cloud from the "docomo phonebook", the "Use of Cloud" screen appears and you can start using cloud.

･

From the Home screen, uTap [Phonebook] to display the phonebook list.

･

Phonebook data can be backed up to/restored from a microSD card using the "docomo backup" application (P.144).

･

From the Home screen, uTap [Con ta cts] to activate Xperia

™

phonebook.

"Contacts" tab.

ドコモクラ

■

Phonebook list screen

On the phonebook list screen, you can view details of your contacts. You can add a photo or image to a phonebook entry, and display phonebook entries by group.

d e

g h

Group tab

･

Display the phonebook group.

Cloud

･

Option menu

Contacts tab

Name registered in the phonebook entry

Photo/image set in the phonebook entry

･

Tap a photo/image to make a call/video call or send a message (SMS) or mail.

My profile tab

･

Check your own phone number.

Index character area

･

Tap index character to display phonebook entries allocated to the index character.

Phone

Index

･

Display the index character to search entries in the order of Japanese syllabary, alphabet, etc.

Managing phonebook

Adding a new phonebook entry

From the Home screen, [

ウド

(docomo cloud)]

[docomo phonebook]uTap "Contacts" tab

On the profile edit screen, enter

necessary information such as

name.

･

To add items, tap [Add other items].

[Save].

❖

Information

･

When the language is set to Japanese, if you saved phonebook entries with the "Phonetic name (last/ first)" field filled in, the phonebook list screen shows them in Japanese syllabary order or alphabetical order of the "Phonetic name" entries. If you did not fill in the "Phonetic name" field, the entr y is displayed

他

in the "

(Others)" section on the phonebook list screen only when you entered the last and first names in Kanji using Japanese "Kana" characters.

ドコモクラ

[Register].

Making a call using the phonebook

From the Home screen, [

ウド

(docomo cloud)]

[docomo phonebook]uTap "Contacts" tab

phonebook entry you want to make a call to.

On the Profile screen, tap a phone

number.

[Call]/[Video call].

ドコモクラ

Select a

Editing a phonebook entry

From the Home screen, [

ウド

(docomo cloud)] [docomo phonebook]uTap "Contacts" tab

phonebook entry to edit.

On the Profile screen, [Edit].

Select a required item and edit.

[Save].

❖

Information

･

You cannot edit contacts for the Facebook account.

ドコモクラ

Select a

Phone

Registering a phonebook entry to Favorites

From the Home screen, [

ウド

(docomo cloud)]

[docomo phonebook]uTap "Contacts" tab

phonebook entry to add to Favor ites .

On the Profile screen, tap .

❖

Information

･

To display phonebook entries added to Favorites, on the phonebook list screen, tap "Group"

[Favorites].

tab

ドコモクラ

Select a

Using optional menu

From the Home screen, [

ウド

(docomo cloud)]u[docomo

phonebook]

on the contacts list screen/

profile screen.

"Contacts" tabuTap

ドコモクラ

■

Phonebook list screen

Delete

Cloud menu Import/Export Settings International use

Help

About

*1 Log-in to cloud is needed. *2 Subscription to i-concier is required.

setting for docomo phonebook

docomo ID/Wi-Fi settings

Contacts display order

Accounts to display

i-concier menu*2Set a function for

Select and delete several/all phonebook entries.

Display cloud menu. P. 9 3 Set for using docomo

phonebook overseas.

Set for using docomo services via Wi-Fi.

Set display order of phonebook entries.

Set a phonebook to be displayed in the phonebook list screen.

supporting phonebook with i-concier.

Display Help of docomo phonebook.

Display version etc. of docomo phonebook.

Phone

■

Profile screen

Delete

Set ringtone

Join/Separate

Send a displayed phonebook entry with Bluetooth function, Email, etc.

Delete a displayed phonebook entry.

Set a ringtone for displayed phonebook entry.

Join/separate displayed phonebook entry.

Setting phonebook entries to Group

From the Home screen, [

ウド

(docomo cloud)]u[docomo

phonebook]

Tap a gr oup.

[Add member]uMark phonebook

entries to add

❖

Information

･

To cancel group setting, in Step 3, [Delete member]

Mark phonebook entries to deleteu[OK]u[OK].

･

When you set Google account etc., display groups by account. You can set/cancel group in the same account.

Tap "Gr oup " tab.

[OK]u[OK].

ドコモクラ

Creating a new group in the phonebook

From the Home screen, [

ウド

(docomo cloud)]u[docomo phonebook]

[Add group].

On the group adding screen, enter

account, group name, icon, color

･

The items vary depending on the account type.

❖

Information

･

Groups in docomo account can be sorted. To do so, tap [Sort] in Step 2 and follow the onscreen instructions.

･

Groups in docomo account can be edited/deleted. To edit/delete a group, touch and hold a group [Edit group]/[Delete group].

Tap "Gr oup " tab.

[OK].

ドコモクラ

Checking My profile and editing information

From the Home screen,

[docomo phonebook]uTap "My profile" tab

On the My profile screen, enter

necessary information such as

[Edit].

name.

[Save].

Phone

Importing/Exporting phonebook entries

You can export/import phonebook entries from/to a microSD card or docomo nano UIM card. This is useful, for example, when you want to move the contact information to another phone.

･

You can also use a synchronization service for synchronizing your phonebook (P.169).

･

Insert a microSD card in advance (P.175).

From the Home screen, [

ウド

(docomo cloud)]u[docomo

phonebook]

Select an item.

･

After this step, follow the onscreen

Tap "Contac ts" tab

[Import/Export].

instructions.

･

When [Share phonebook data] is tapped, select an application to send.

❖

Information

･

To export phonebook entries to docomo nano UIM card, use "Contacts" app of Xperia the name and the first phone number and email address are saved for each contact because of the limited memory on the docomo nano UIM card. For some phonebook entries, a part of data may not be exported.

ドコモクラ

™

. Note that only

Phone

Mail/Web browser

docomo mail Message (SMS)

Send/receive mails using DOCOMO mail address (@docomo.ne.jp). Pictograms and Deco-mail can be used, and automatic reception also is supported. Sent/received mails are stored to the docomo mail server. Mails can be transferred readily in case the terminal is lost or you change the model. Also, with a docomo ID, you can use mail on your PC, tablet, and other devices. For details of docomo mail, refer to NTT DOCOMO website.

From the Home screen, .

･

After this step, follow the onscreen instructions.

❖

Information

･

docomo mail (local mail) data can be backed up in a microSD card using "docomo backup" application (P.144).

You can send/receive text message to/from a mobile phone number as a recipient. For details of available number of characters etc., refer to "Short Message Service (SMS)" on NTT DOCOMO website.

Sending message (SMS)

From the Home screen,

[Messaging].

･

When using this application for the first time, tap [GET STARTED] to proceed to Step 3.

(Write new message).

Enter the recipient's phone

number.

･

Tap u[Add recipients] to select from registered contacts. Enter in the search box at the top of the screen to display the contact list.

[Write message]uEnter a message.

･

Tap u[Select message template] to enter by selecting message template (P.96).

Mail/Web browser

･

When the number of entered characters comes close to a limit, a number of enterable characters appears on the right of the text box.

(Send).

❖

Information

･

You can change default messaging application to Hangouts. From the Home screen,

[Settings]u[More]u[Default SMS app]

[Hangouts].

･

You can also send/receive text messages to/from customers of overseas network operators. Refer to NTT DOCOMO website for details on the countries and overseas network operators that provide this service.

･

To send SMS to users of overseas network operators, enter "+", "Countr y code" and then "the recipient mobile phone number". Enter the phone number without a leading "0", if any. Alternatively, enter "010", "Country code" then "the recipient mobile phone number" in order.

Reading message (SMS)

Sent/received message (SMS) is displayed in thread by recipient/sender.

From the Home screen,

[Messaging].

･

Senders with unread messages (SMS) are displayed in bold font.

Select a sender whose messages

(SMS) you want to read.

❖

Information

･

When you receive a message (SMS), appears on the status bar. Drag the status bar downwards to read the received message (SMS).

･

Touch and hold a message (SMS)uTap [Add st ar] t o add a star. To check starred messages (SMS) in a list, from the Home screen, tap

[Messaging]

[Starred messages].

Saving phone number of message (SMS) to phonebook

From the Home screen,

[Messaging].

Tap of a phone number to

❖

･

save

[SAVE].

[Add new contact]/[Add to the existing contact].

･

If you selected "Add to the existing contact", select the contact.

On the profile edit screen, enter necessary information such as

name

[Save].

Information

If the sender is already saved in the phonebook, you can tap or the photo (image) in Step 2 to make a call or see the phonebook entry.

Mail/Web browser

Deleting a message (SMS)

From the Home screen,

[Messaging].

Tap a sender/recipient whose

messages (SMS) to delete.

Touch and hold a message (SMS) to

delete.

[Delete message]u[DELETE].

❖

Information

･

To delete several messages (SMS), in Step 3,

[Delete messages]uMark messages (SMS) you

want to delete

[DELETE].

Deleting messages (SMS) by sender/recipient

From the Home screen,

[Messaging].

Touch and hold a sender/recipient

you want to delete.

❖

･

[DELETE].

Information

To delete messages (SMS) from several senders and recipients, in Step 3, mark senders/recipients to

delete

[DELETE].

Changing settings for Messaging (SMS)

From the Home screen,

[Messaging].

Notification tone

Notifications

Notification vibration

Notification light

Delivery report

Message templates

Default SMS app

SIM messages

Push settings

Cell Broadcast SMS

SMS center number

[Settings].

Set notification tone for receiving.

Set whether to show message (SMS) arrival notification in the status bar.

Set whether to notify with vibration

when receiving. Set whether to notify with the

notification LED for receiving when the backlight is turned off.

Set whether to display a delivery report (checkmark) in your message (SMS) when the recipient receives it.

Set a default messaging application.

Manage messages (SMS) saved to a docomo nano UIM card.

Set a message (SMS) sent from the provider.

Set whether to receive Cell Broadcast SMS with Messaging application.

Check SMS center number.

Mail/Web browser

* While the silent mode (without vibration) is set, the

terminal does not vibrate when receiving a message (SMS).

Email

You can create a POP3 or IMAP compatible email account provided by general ISP (provider), or an Exchange ActiveSync account to send or receive email. You can set multiple Email accounts.

Making initial setting for Email

Set an Email account following the onscreen instructions.

From the Home screen,

[Email].

･

If the "Welcome to Email" screen appears, tap [GET STARTED].

･

To set a second or subsequent email account, from the Home screen,

[Email]

account].

Enter your email address and

password.

[NEXT].

･

To set up an email account manually, tap [Manual setup] and follow the onscreen instructions.

[Settings]uTap [Add

Configure necessary settings

[NEXT].

･

If a screen for selecting type of account appears, tap an email account type and follow the onscreen instructions to set.

Enter your account name and the

name to be displayed in your outgoing emails

･

Inbox for set email account appears.

❖

Information

･

If you need to make the settings manually, contact your email service provider or system administrator for the correct email account settings.

･

If you set an Exchange ActiveSync account as an email account, and if server manager sets Remote wipe, the data saved in the terminal may be deleted.

[FINISH SETUP].

Mail/Web browser

Creating and sending email Receiving and reading email

From the Home screen,

[Email].

(Compose).

Enter the email address of

recipient.

･

When you enter a name or email address in the email address field, contacts matched to the entered numbers or letters are listed.

･

To enter multiple email addresses directly, separate with a comma (,) and then enter the next email address.

･

To add Cc or Bcc recipients, uMark "Show Cc"/"Show Bcc".

Enter a subject and message.

[SEND].

❖

Information

･

To attach a file, when creating an email, tap

[Attach file] and select the file.

･

To save an email as draft, when creating an email, tap

[Save as draft] or display other screen.

･

Email is handled as an email from a PC. Your email cannot be received if rejecting emails from PCs is set on a recipient terminal.

From the Home screen,

[Email].

･

If you have set up more than one email account, tap at the upper left of the

Tap the email account you

screen want to use for receiving emails.

On the Inbox, flick the screen.

Tap an email you want to read.

❖

Information

･

The sender name of a received email is the name set on sender's terminal.

･

If you specified "Notification" in the email account settings (P.100) and set "Check frequency" to an option other than "Manual", appears in the status bar to notify you when you have received a new email. Drag the status bar downwards to read the received email.

･

Tap an address of received email to register the address to the phonebook. For addresses already registered, displaying phonebook entries, creating mail, etc. are available.

･

You can tap the star icon in the Inbox or the email message window to highlight the star and add the email to the "Starred" folder. To see a list of starred emails, tap at the upper left of the Inbox

screen

Tap the desired email accountu at the

upper left of the screen

Tap [Starred].

Mail/Web browser

Sony SO-04G User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

About manuals of SO-04G

Operation descriptions

Supplied accessories

Contents

Content s/Precautio ns

About using the terminal

Safety Precautions (Always follow these directions)

Handling precautions

Waterproofness/ Dustproofness

Part names and functions

Before Using the Terminal

docomo nano UIM card

Charging

Turning power on/off

Initial settings

Basic operations

Notification LED

Status bar

Notification panel

Quick settings panel

Home screen

Task manager

Switching Home application

Searching information in the terminal and web pages

Character entry

Setting character entry

docomo LIVE UX

Home screen

Managing the Home screen

Application screen

Display all apps

Backing up and restoring the Home screen

Using My Magazine

Checking Home application information

Phone

Making/Receiving a call

Operations during a call

Call history

Call settings

Phonebook

Mail/Web browser

docomo mail Message (SMS)

Email
