Sony SO-04F User Guide
INSTRUCTION MANUAL
14.5
Introduction
Thank you for your purchase of "SO-04F".
For proper use of the SO-04F, read this manual
carefully before and while you use the SO-04F.
About manuals of SO-04F
In addition to this manual, the operations of SO-04F
are described in "
Guide)" (in Japanese only) and "Instruction Manual"
application of the terminal (in Japanese only).
●"クイックスタートガイド
(Supplied accessories)
The initial operations and settings after purchasing
the terminal, screen view contents and operations of
main function are explained.
●
"Instruction Manual" (Application of the terminal)
Operations and settings of each function are
explained. To use "Instruction Manual" application,
from the Home screen,
When using for the first time, download and install
the application according to the onscreen
instructions. If you uninstall "Instruction Manual"
application, access to Google Play from Play Store to
download it again. From the Home screen, Tap [Play
Store], search "
application to select, then install it following the
onscreen instructions. You can use the application as
an electronic book. You can also shift to actual
operations by tapping the description in the contents
or view reference contents.
クイックスタートガイド
(Quick Start Guide)"
u
[Instruction Manual].
取扱説明書
(Instruction Manual)"
(Quick Start
●
"Instruction Manual" (PDF file)
Operations and settings of each function are
exp lain ed. It can b e down load ed fro m NTT DOCOM O
website.
https://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
* You can download the latest information of "
イックスタートガイド
URL and contents are subject to change
without prior notice.
❖
Note
･
Reproduction or reprint of all or part of this manual
without prior permission is prohibited.
･
Important information for SO-04F is posted in the
following website. Be sure to check before using.
http://www.sonymobile.co.jp/support/use_support/
product/so-04f/ (In Japanese only)
(Quick Start Guide)". The
ク
Operation descriptions
In this manual, each key (key icon) operation is
described with
selection operations of the icons or function items
on the touch screen are described as follows.
From the Home
screen,
u
[About phone].
Touch and hold an
icon.
❖
Information
･
In this manual, the instructions are described with
the default Home screen. If you set the other
application to the home screen, the operations may
differ from the descriptions.
･
Display examples and illustrations used in this
manual are just images for explanations and may be
different from actual ones.
･
In this manual, the easier procedure is described for
the functions and settings which have multiple
operating procedures.
･
Please note that "SO-04F" is called "the terminal" in
this manual.
･
In this manual, explanations for "docomo" as Home
screen are provided (P.59).
P, k, x, y, r
Description Operation
From the Home screen, tap
(Apps button), and then tap
u
[Settings]
"Settings" on the next screen and
"About phone" on the following
screen in order.
Keep touching an icon longer (12 seconds).
. And
1
Supplied accessories
･
SO-04F (with warranty)
･
Desktop Holder SO21 (with warranty)
･
クイックスタートガイド
(Quick Start Guide)
(In Japanese only)
･
のご利用にあたっての注意事項
SO-04F
安全上／取り扱い上のご注意
(Notes on usage Safety/Handling
precautions) (In Japanese only)
･
1Seg antenna cable SO01
For optional accessories compatible with the
terminal (optional) , refer to NTT DOCOMO
website.
https://www.nttdocomo.co.jp/product/
option/ (In Japanese only)
