INSTRUCTION MANUAL
14.10
Introduction
Thank you for your purchase of "SO-02G".
For proper use of the SO-02G, read this manual
carefully before and while you use the SO-02G.
About manuals of SO-02G
In addition to this manual, the operations of SO-02G
are described in "
Guide)" (in Japanese only) and "Instruction Manual"
application of the terminal (in Japanese only).
●"クイックスタートガイド
(Supplied accessories)
The initial operations and settings after purchasing
the terminal, screen view contents and operations of
main function are explained.
●
"Instruction Manual" (Application of the terminal)
Operations and settings of each function are
explained. To use "Instruction Manual" application,
from the Home screen,
When using for the first time, download and install
the application according to the onscreen
instructions. If you uninstall "Instruction Manual"
application, access to Google Play from Play Store to
download it again. From the Home screen, tap [Play
Store], search "
application to select, then install it following the
onscreen instructions. You can use the application as
an electronic book. You can also shift to actual
operations by tapping the description in the contents
or view reference contents.
クイックスタートガイド
(Quick Start Guide)"
u
[Instruction Manual].
取扱説明書
(Instruction Manual)"
(Quick Start
●
"Instruction Manual" (PDF file)
Operations and settings of each function are
exp lain ed. It can b e down load ed fro m NTT DOCOM O
website.
https://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
* You can download the latest information of "
イックスタートガイド
URL and contents are subject to change
without prior notice.
❖
Note
･
Reproduction or reprint of all or part of this manual
without prior permission is prohibited.
･
Important information for SO-02G is posted in the
following website. Be sure to check before using.
http://www.sonymobile.co.jp/support/use_support/
product/so-02g/ (In Japanese only)
(Quick Start Guide)". The
ク
Operation descriptions
In this manual, each key (key icon) operation is
described with
selection operations of the icons or function items
on the touch screen are described as follows.
Description Operation
From the Home
screen,
u
u
[About
phone].
Touch and hold
an icon.
❖
Information
･
In this manual, the instructions are described with
the default Home screen. If you set the other
application to the home screen, the operations may
differ from the descriptions.
･
Display examples and illustrations used in this
manual are just images for explanations and may be
different from actual ones.
･
In this manual, the easier procedure is described for
the functions and settings which have multiple
operating procedures.
･
Please note that "SO-02G" is called "the terminal" in
this manual.
･
In this manual, explanations for "docomo" as Home
application are provided (P.63).
P, k, x, y, r
From the Home screen, tap
(Apps button), and then tap
[Settings]
"Settings" on the next screen and
"About phone" on the following
screen in order.
Keep touching an icon longer (1-2
seconds).
. And
1
Supplied accessories
･
SO-02G (with warranty)
･
Desktop Holder SO24 (with warranty)
･
クイックスタートガイド
(Quick Start Guide) (In
Japanese only)
･
のご利用にあたっての注意事項
SO-02G
安全上／取り扱い上のご注意
(Notes on usage Safety/Handling
precautions) (In Japanese only)
･
1Seg antenna cable SO02
For optional accessories compatible with the
terminal (optional) , refer to NTT DOCOMO
website.
https://www.nttdocomo.co.jp/product/
option/ (In Japanese only)
2
Contents
■
Supplied accessories. . . . . . . . . . . . . . . . . 2
■
About using the terminal . . . . . . . . . . . . 5
■
Safety Precautions (Always follow these
directions) . . . . . . . . . . . . . . . . . . . . . . . . . . 7
■
Handling precautions. . . . . . . . . . . . . . . 17
■
Waterproofness/Dustproofness . . . . . 24
Before Using the Terminal . . . 30
Part names and functions................................................30
docomo nano UIM card.................................................... 31
Charging.....................................................................................33
Turning power on/off......................................................... 39
Initial settings........................................................................... 40
Basic operations.....................................................................41
Notification LED .....................................................................46
Status bar ................................................................................... 46
Notification panel .................................................................49
Home screen............................................................................ 50
Xperia™ Application screen .......................................... 56
Task manager...........................................................................62
Switching Home application.........................................63
Searching information in the terminal and web
pages ............................................................................................ 63
Character entry....................................................................... 64
Setting character entry...................................................... 70
docomo LIVE UX . . . . . . . . . . . . 71
Home screen............................................................................ 71
Managing the Home screen ..........................................71
Application screen................................................................ 73
Backing up and restoring the Home screen ........ 75
Using My Magazine ............................................................. 76
Checking Home application information.............. 77
Phone . . . . . . . . . . . . . . . . . . . . . . 78
Making/Receiving a call .................................................... 78
Operations during a call ................................................... 82
Call history................................................................................. 84
Call settings .............................................................................. 87
Phonebook ............................................................................... 88
Mail/Web browser . . . . . . . . . . . 93
docomo mail ........................................................................... 93
Message (SMS)........................................................................ 93
Email.............................................................................................. 96
Gmail.......................................................................................... 100
Early Warning "Area Mail".............................................. 101
Browser..................................................................................... 102
Apps. . . . . . . . . . . . . . . . . . . . . . .105
dmenu...................................................................................... 105
dmarket.................................................................................... 105
Play Store ................................................................................ 105
Osaifu-Keitai .......................................................................... 107
1Seg............................................................................................ 111
FM radio................................................................................... 117
Camera ..................................................................................... 118
Album ....................................................................................... 131
YouTube .................................................................................. 133
Media Player.......................................................................... 133
Location services................................................................ 135
Schedule.................................................................................. 138
Alarm & clock........................................................................ 139
docomo backup................................................................. 141
Content s/Precautio ns
3
Settings . . . . . . . . . . . . . . . . . . . 144
Viewing the setting menu............................................ 144
WIRELESS & NETWORKS ................................................. 144
DEVICE....................................................................................... 154
PERSONAL............................................................................... 160
ACCOUNTS............................................................................. 168
SYSTEM ..................................................................................... 170
File management . . . . . . . . . . 172
Storage structure................................................................ 172
File operation........................................................................ 174
Data communication . . . . . . . 176
Bluetooth function............................................................ 176
NFC communication........................................................ 178
External device connection . 181
Connecting to PC............................................................... 181
Connecting DLNA device ............................................. 183
Connecting to other devices...................................... 185
International roaming . . . . . . 186
Overview of International roaming (WORLD
WING)......................................................................................... 186
Available overseas service ............................................ 186
Checking before overseas use ................................... 187
Making/Receiving a call in the country you stay
....................................................................................................... 189
International roaming settings.................................. 192
After returning to Japan................................................. 193
Appendix/Index . . . . . . . . . . . .194
Troubleshooting................................................................. 194
あんしん遠隔サポート
....................................................................................................... 202
Warranty and After Sales Services ........................... 203
Software update................................................................. 206
Upgrade Android software.......................................... 210
Connecting to a PC to upgrade................................ 212
Main specification ............................................................. 213
Certificate and compliance ......................................... 218
Specific Absorption Rate of Mobile Phone, etc.
....................................................................................................... 218
End User Licence Agreement .................................... 230
Export Controls and Regulations ............................. 231
Intellectual Property Right ........................................... 231
SIM unlock.............................................................................. 235
Index .......................................................................................... 236
(Anshin Enkaku Support)
Content s/Precautio ns
4
Contents/Precautions
About using the terminal
･
The terminal supports LTE, W-CDMA, GSM/
GPRS and Wireless LAN Systems.
･
Because a terminal operates using radio
frequencies, it cannot be used inside a tunnel,
underground, in a building or other locations
where radio waves do not reach the terminal,
in locations with weak radio wave condition,
or out of Xi/FOMA service area. The services
may not be available on the upper floors of
high-rise apartments or buildings, even if
there are no obstructions around you. On
occasion, your calls may become
disconnected even in areas with strong radio
wave condition, even if you are not moving, or
even if there are 4-signal icon in the terminals
display.
･
Because your terminal uses radio waves to
communicate, it is possible that a third party
may attempt to tap your calls. However, the
LTE, W-CDMA, GSM/GPRS system
automatically scrambles all calls through a
private call feature. Therefore, even if the third
party successfully intercepts your call, they
will only hear noise.
･
The terminal operates on radio frequencies by
converting voice into digital signals. If the
caller moves into an area of adverse radio
wave condition, the digital signal may not be
restored accurately, and the voice received in
the call may differ slightly from the actual
voice.
･
Note down the information saved in the
terminal in a separate note on a regular basis
or save to an external recording medium such
as a microSD card or PC. Note that DOCOMO
assumes no responsibility for any loss of saved
contents of data resulting from malfunction,
repair, changing of the model or other
handling of the terminal.
･
As with PCs, some user-installed applications
may disrupt the stability of the terminal
performance, or unexpectedly transmit
information via the Internet causing improper
use of your location information as well as
personal information recorded on the
terminal. Therefore, verify the supplier and
operating conditions of the applications to be
used before using them.
･
This terminal has FOMA Plus-Area and FOMA
HIGH-SPEED Area support.
･
The terminal does not support i-mode sites
(programs) or i-
D
ppli.
Content s/Precautio ns
5
･
The terminal automatically performs
communication for synchronizing data,
checking the latest software version, and
maintaining a connection with the server, and
for other purposes. If you transmit a large
amount of data, such as when downloading
applications or watching video, a packet
communication charge becomes high.
Subscription to Packet Pack/packet flat-rate
service is highly recommended.
･
Depending on the applications or service you
use, packet communication charge may be
applied even in Wi-Fi communication.
･
Public mode (Driving mode) is not supported.
･
Setting the terminal to silent mode does not
mute sounds for shutter, playback of video or
music, dialpad operation sound during a call,
sound emitted when [End call] is tapped, etc.
･
The name of the operator is displayed on the
lock screen (P.40).
･
To check your phone number (own number),
from the Home screen,
u
[Settings]u[About phone]u[Status] to
see "My phone number".
･
To check the software version, from the Home
screen,
･
If available memory in the microSD card or
u
[Settings]u[About phone].
the terminal is low, running applications may
not operate correctly. In that case, delete the
saved data.
･
You can update software on the terminal to
the latest one (P.206, P.212).
･
By upgrading Android software, the
operating system (OS) may be versionupgraded for improving the terminal quality.
For this reason, you always need to use the
latest OS version. And some applications that
used in the previous OS version may not be
available or some unintended bugs may
occur.
･
You can use the terminal only with a docomo
nano UIM card. If you have a docomo mini
UIM card, UIM, or FOMA card, bring it to a
docomo Shop to replace it with a docomo
nano UIM card.
･
Set password etc. for screen lock to ensure the
security of your terminal for its loss (P.165).
･
If your terminal is lost, change your each
account password to invalidate
authentication using a PC to prevent other
persons from using Google services such as
Gmail or Google Play, or SNS, etc.
･
For services provided by Google, refer to
Google Terms of Service. For other web
services, refer to each terms of service.
･
Applications and service contents are subject
to change without prior notice.
･
The terminal supports only sp-mode, mopera
U and Business mopera Internet. Other
providers are not supported.
Contents/Precautions
6
･
To use tethering, subscription of sp-mode is
required.
･
If you want to use tethering, subscription to
Packet Pack/packet flat-rate service is strongly
recommended.
･
For details on usage charge, etc., refer to the
following website.
https://www.nttdocomo.co.jp/english/
･
Display is manufactured by taking advantage
of highly advanced technology but some
dots may be always or never lit. Note that, this
shows characteristics of liquid crystal displays
and not defects in the terminals.
･
DOCOMO is not liable to any failures or
malfunctions for commercially available
optional equipment.
Safety Precautions (Always follow these directions)
■
For safe and proper use of the terminal, plea se
read the "Safety Precautions" prior to use.
Keep the Manual in a safe place for future
reference.
■
ALWAYS observe the safety precautions since
they intend to prevent personal injury or
property damage.
■
The following symbols indicate the different
levels of injury or damage that may result if
the guidelines are not observed and the
terminal is used improperly.
Failure to
observe these
guidelines may
DANGER
WARNING
CAUTION
immediately
result in death
or serious
injury.
Failure to
observe these
guidelines may
result in death
or serious
injury.
Failure to
observe these
guidelines may
result in injury
and property
damage.
Content s/Precautio ns
7
■
The following symbols indicate specific
directions.
Indicates prohibited actions.
Don’t
1. Handling the terminal, adapter,
desktop holder, docomo nano UIM
card, and 1Seg antenna cable
(common)
Indicates not to disassemble.
No disassembly
Indicates not to use where it could
get wet.
No liquids
Indicates not to handle with wet
hands.
No wet hands
Indicates compulsory actions in
accordance with instructions.
Do
Indicates to remove the power plug
from the outlet.
Unplug
■
"Safety Precautions" are described in the
following categories:
1. Handling the terminal, adapter, desktop holder,
docomo nano UIM card, and 1Seg antenna
cable (common). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Handling the terminal . . . . . . . . . . . . . . . . . . . . . .10
3. Handling adapter or desktop holder. . . . . . . . . 13
4. Handling the docomo nano UIM card . . . . . . . 15
5. Handling the terminal near electronic medical
equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6. Material list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DANGER
Do not use, store or leave the equipment in
hot places (e.g. by the fire, near a heater,
Don’t
under a kotatsu, in direct sunlight, in a car in
the hot sun) (including wearing the
equipment by putting in a pocket of clothes
etc.).
Doing so may cause fire, burns or injury.
Do not place equipment inside cooking
appliance such as a microwave oven or high-
Don’t
pressure containers.
Doing so may cause fire, burns, injury or
electric shock.
Do not disassemble or modify the
equipment.
No disassembly
Doing so may cause fire, burns, injury or
electric shock.
Do not let the equipment get wet with
water, drinking water, urine of pet animals,
No liquids
sweat, etc.
Doing so may cause fire, burns, injury or
electric shock.
Waterproofness→P.24 "Waterproofness/
Dustproofness"
Content s/Precautio ns
8
Do not allow liquid (water, drinking water,
urine of pet animals, perspiration, etc.) to
No liquids
come into the charging jack or microUSB
jack.
Doing so may cause fire, burns, injury or
electric shock.
Waterproofness
Dustproofness"
Use optional devices specified by NTT
DOCOMO for the terminal.
Do
Failure to do so may cause fire, burns, injury or
electric shock.
→
P.24 "Waterproofness/
WARNING
Do not subject the equipment to excessive
force or throw it.
Don’t
Doing so may cause fire, burns, injury or
electric shock.
Do not allow the charging jack, microUSB
jack or headset jack to touch conducting
Don’t
foreign substances (a piece of metal, pencil
lead, etc.). Never allow these objects to get
inside.
Doing so may cause fire, burns, injury or
electric shock.
Do not cover or wrap the equipment with a
cloth or bedding in use or while charging.
Don’t
Doing so may cause fire or burns.
Power off the terminal before you step into a
place where flammable gas can leak, such as
Do
gas stations. Stop charging if you charge the
battery.
Gas may catch fire.
When using Osaifu-Keitai in a place such as a
gas station, turn OFF the terminal before using
it (When NFC/Osaifu-Keitai lock is activated,
deactivate it before turning OFF the terminal).
If you notice anything unusual about the
equipment such as an unusual odor,
Do
overheating, discoloration or deformation
during operation, charging or storage,
immediately perform the following
measures.
・
Remove the power plug from the power
outlet or cigarette lighter
・
Power off the terminal
Failure to do so may cause fire, burns, injury or
electric shock.
CAUTION
Do not place on an unstable or inclined
platform.
Don’t
Doing so may cause the device to fall and
cause injury.
Do not keep in a place that is very humid,
dusty, or subject to high temperature.
Don’t
Doing so may cause fire, burns or electric
shock.
If children use the terminal, parents or
guardians should give them the proper
Do
instructions for use. Make sure that they use
the terminal as instructed.
Failure to do so may cause injury.
Content s/Precautio ns
9
Keep the equipment out of the reach of
babies and infants.
Do
Failure to do so may cause accidental
ingestion, injury, or electric shock.
Be careful especially when using the
terminal connected to the adapter
Do
continuously for a long time.
If you play a game, watch videos or 1Seg, etc.
for a long time while charging, the
temperature of the terminal and adapter may
rise.
If you are directly in contact with hot parts for
a long perio d of time, it may caus e your skin to
become red, itchy, or develop a rash
depending on your physical condition and
also it may cause low-temperature burn.
2. Handling the terminal
■
Type of internal battery for the terminal is as
follows.
Display Type of Battery
Li-ion 00 Lithium Ion Battery
DANGER
Do not throw the terminal into fire or apply
heat.
Don’t
Doing so may cause internal battery to ignite,
burst, heat or leak.
Do not put excessive force such as sticking a
nail into the terminal, hitting it with a
Don’t
hammer, or stepping on it.
Doing so may cause internal battery to ignite,
burst, heat or leak.
If the internal battery fluid etc. contacts eyes,
immediately flush the eyes with clean water
Do
and see a doctor right away. Do not rub the
eyes.
Failure to do so may cause blindness.
WARNING
Do not turn on the light with the lighting
luminescence part close to the eyes.
Don’t
Especially to shoot infants or young
children, step away from them 1 m or more.
Doing so may cause blurred vision. Or injury
by dazzling eyes or surprising may occur.
Content s/Precautio ns
10
Do not allow a foreign substance such as
water and other liquids, metal parts, or
Don’t
flammables to get in the docomo nano UIM
card or microSD card slot on the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not turn on the light toward a driver of a
car etc.
Don’t
Doing so may disturb driving and cause an
accident.
Power off the terminal or put it in Airplane
mode before boarding an airplane.
Do
Use of mobile phones on board is restricted.
Follow the instructions of each airline.
Failure to do so may adversely affect on-board
electronic equipment.
Prohibited acts related to mobile phone usage
on an airplane may be punished by law.
If the microUSB cable is connected into the
microUSB jack for charging etc. with the
terminal powered off, the terminal is
automatically powered on although the
operations are not available. Be careful not to
connect the microUSB cable in a place where
the use is prohibited.
Follow the instructions of each medical
facility for the use of mobile phones on their
Do
premises.
Power off the terminal in a place where the
use is prohibited.
Failure to do so may affect electronic
equipment and electronic medical
equipment.
If the microUSB cable is connected into the
microUSB jack for charging etc. with the
terminal powered off, the terminal is
automatically powered on although the
operations are not available. Be careful not to
connect the microUSB cable in a place where
the use is prohibited.
Always keep the terminal away from your
ear when you talk setting the hands-free
Do
function.
Also, when you play game, play back music,
etc. connecting the Earphone/Microphone,
etc. to the terminal, adjust the volume
adequately.
If the volume is too loud, it may cause
difficulty in hearing.
Moreover, if you barely hear the surrounding
sounds, it may cause an accident.
If you have a weak heart, set the vibrator or
ringtone volume carefully.
Do
Failure to do so may affect your heart.
If you are wearing any electronic medical
equipment, check with the relevant medical
Do
electronic equipment manufacturer or
vendor whether the operation may be
affected by radio waves.
The radio waves from the terminal may affect
electronic medical equipment.
Content s/Precautio ns
11
Power off the terminal near electronic
devices or equipment operating on high
Do
precision control or weak signals.
Failure to do so may interfere with the
operation of electronic devices or equipment.
* The following are some electronic devices
or equipment that you should be careful of:
Hearing aids, implantable cardiac
pacemaker, implantable cardioverter
defibrillator, other electronic medical
equipment, fire detector, automatic door,
and other automatically controlled devices
or equipment.
If you use an implantable cardiac
pacemaker, implantable cardioverter
defibrillator, or other electronic medical
equipment, check with the relevant medical
electronic equipment manufacturer or
vendor whether the operation can be
affected by radio waves.
Be careful about broken glasses or exposed
internal from the terminal if the display or
Do
the camera lens is broken.
The display is made of toughened glass, and
the camera lens is made of acrylic resin to
prevent the glass from shattering when
broken. However, touching a cut surface or
exposed portion accidentally may result in
injury.
If the internal battery leaks or gives off a
strange smell, immediately remove it from
Do
the vicinity of open flames.
The leaking liquid may ignite fire, catch fire, or
explode.
CAUTION
Do not swing the terminal around by
holding strap, etc.
Don’t
The terminal may hit you or others and cause
accident such as injury.
Do not use damaged terminal.
Doing so may cause fire, burns, injury or
Don’t
electric shock.
When using the motion sensor, check the
safety around you, hold the terminal firmly,
Don’t
and do not shake it unnecessarily.
Failure to do so may cause accident such as
injuries.
If the display is mistakenly damaged and
when the liquid crystal runs out, do not get
Don’t
it on your skin such as face, hands, etc.
Doing so may cause blindness or injury on
your skin.
If the liquid crystal gets in your eye or mouth,
rinse with clean running water, and get
medical treatment immediately.
Also, if it gets on your skin or clothes, use
something such as alcohol to wipe off, and
wash it off with soap or something similar.
Do not discard the battery together with
other garbage.
Don’t
Doing so may cause igniting or environmental
destruction. Bring the unnecessary terminal
into a sales outlet such as docomo Shop. If
your local municipality has a battery recycling
program, dispose of them as provided for.
Content s/Precautio ns
12
To use the terminal in car, check with
automobile manufacturer or dealer to
Do
determine how the device is affected by
radio waves before using.
In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.
The use of the terminal may cause itching,
rashes, eczema, or other symptoms
Do
depending on the user's physical condition.
Immediately stop using and get medical
treatment in such a case.
For material of each part →P.16 "Material list"
When watching the display, take a certain
distance from the display in a fully bright
Do
place.
Failure to do so may reduce visual acuity.
If fluid etc. leaks out from the internal
battery, do not make the fluid contact with
Do
your skin of face or hands.
Doing so may cause blindness or injury on
your skin. If the fluid etc. gets into your eyes or
mouth, or contacts skin or clothes,
immediately flush the contacted area with
clean running water. If the fluid gets into the
eyes or mouth, immediately see a doctor after
flushing.
3. Handling adapter or desktop
holder
WARNING
Do not use the adapter cord if it gets
damaged.
Don’t
Doing so may cause fire, burns or electric
shock.
Do not use the AC adapter or desktop holder
in a very humid place such as bathroom.
Don’t
Doing so may cause fire, burns or electric
shock.
DC adapter is only for a negative ground
vehicle. Do not use DC adapter for a positive
Don’t
ground vehicle.
Doing so may cause fire, burns or electric
shock.
Do not touch the adapter if you hear
thunder.
Don’t
Doing so may cause electric shock.
Do not short-circuit the charging jack while
it is connected to the power outlet or
Don’t
cigarette lighter socket. Do not touch the
charging jack with your hands, fingers, or
any part of your body.
Doing so may cause fire, burns or electric
shock.
Do not place heavy objects on the adapter
cord.
Don’t
Doing so may cause fire, burns or electric
shock.
Content s/Precautio ns
13
When you insert and remove the AC adapter
from power outlet, do not contact a metal
Don’t
strap or other metal objects with the jack.
Doing so may cause fire, burns or electric
shock.
Do not put an excessive force up, down, left
or right when the adapter is connected to
Don’t
the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not touch the adapter cord, charging
jack or outlet with wet hands.
No wet hands
Doing so may cause fire, burns or electric
shock.
Use the adapter only on the specified power
supply and voltage.
Do
When charging the terminal overseas, use
AC adapter for global use.
Failure to do so may cause fire, burns or
electric shock.
AC adapter : 100V AC
DC adapter : 12V or 24V DC (only for a
negative-ground vehicle)
AC adapter for global use : 100V to 240V AC
(Make sure to connect the adapter to a
household AC power outlet.)
When the fuse in a DC adapter is blown,
make sure to use the specified fuse.
Do
Failure to do so may cause fire, burns or
electric shock. For the specified fuse, see the
users manuals that supplied with a DC
adapter.
Clean dust from the power plug.
Failure to do so may cause fire, burns or
Do
electric shock.
When you connect the AC adapter to the
power outlet, insert it firmly.
Do
Failure to do so may cause fire, burns or
electric shock.
When you disconnect the power plug from
the outlet or cigarette lighter socket, do not
Do
pull the adapter cord with excessive force.
Instead, hold the adapter to disconnect.
Failure to do so may cause fire, burns or
electric shock.
Remove or insert the adapter to the terminal
evenly without applying excessive force.
Do
Failure to do so may cause fire, burns, injury or
electric shock.
Always remove the power plug from the
outlet or cigarette lighter when not using
Unplug
the adapter for an extended period.
Failure to do so may cause fire, burns or
electric shock.
Immediately remove the power plug from
the outlet or cigarette lighter socket if water
Unplug
or other fluids get into the adapter.
Failure to do so may cause fire, burns or
electric shock.
Before cleaning, remove the power plug
from the power outlet or the cigarette
Unplug
lighter socket.
Failure to do so may cause fire, burns or
electric shock.
Content s/Precautio ns
14
4. Handling the docomo nano UIM
card
5. Handling the terminal near
electronic medical equipment
CAUTION
Be careful of the cut surface when handling
a docomo nano UIM card.
Do Do
Failure to do so may cause injury.
WARNING
If you use an implantable cardiac pacemaker
or implantable cardioverter defibrillator,
keep the terminal 15 cm or more away from
the implant at all times.
The radio waves from the terminal may affect
the performance of electronic medical
equipment.
If you need to use electronic medical
equipment other than implantable cardiac
Do
pacemaker or implantable cardioverter
defibrillator outside medical facilities such
as treating at home, check with the relevant
medical electronic equipment manufacturer
whether the operation may be affected by
radio waves.
The radio waves from the terminal may affect
the performance of electronic medical
equipment.
When you get close to other people within
15 cm just like not having enough space to
Do
turn around, set the radio wave of the
terminal to OFF beforehand ( Airplane mode,
Power off, etc.).
A person in close proximity may put on
implanted a medical electrical equipment
such as pacemakers and ICDs. The radio waves
from the terminal may affect the performance
of electronic medical equipment.
Follow the instructions of each medical
facility for the use of the terminal on their
Do
premises.
Content s/Precautio ns
15
6. Material list
Part Ma terial
Exterior case (front and
back sides of cover)
Exterior case (side
periphery, microUSB
jack/microSD card slot
cover, and docomo nano
UIM card slot cover)
Power key, volume key,
camera key, and
decoration ring (headset
jack)
Transparent plate
(camera)
Transparent plate
(display, back side)
Decoration ring (camera) Stainless
Magnet connector (resin
part)
Magnet connector (sheet
metal)
Magnet connector
(electrode)
Desktop holder (upper
case, lower case)
PA r es in
(with glass)
PC resin UV coating
Aluminum
alloy
PMMA resin
+ PC resin
Hardened
glass
alloy
PPS resin
(Black,
Orange,
Green)
Nylon resin
(White)
SUS Acrylic
Phosphor
bronze
ABS resin
Surface
treatment
UV coating
Anodic oxide
coating
AR
treatment
AFP
treatment
―
―
coating
Gold plating
―
Part Ma terial
Desktop holder
(attachment)
Desktop holder (magnet
connector)
Desktop holder
(contacts, charging jack)
Desktop holder (housing:
contacts)
Desktop holder (housing:
charging jack)
Desktop holder (shield:
charging jack)
Desktop holder
(nameplate)
Desktop holder (serial
number label)
Desktop holder (2D
barcode label)
Desktop holder
(immersion sensing
label)
Desktop holder (rubber
foot)
1Seg antenna cable
(headset jack: top side;
connector plug: top side)
Surface
treatment
PC resin
Neodymium Nickel
―
plating
Brass Gold plating
PA r es in
Polye ster
resin
Stainless
PET
(aluminum
evaporation)
resin
PET resin
PS resin
Quality
paper
Polye ster
resin
PP resin
―
―
―
―
―
―
―
―
―
Content s/Precautio ns
16
Part Ma terial
1Seg antenna cable
(headset jack: body,
cable, connector plug:
body)
1Seg antenna cable
(connector plug: metal
section)
Surface
treatment
Elastomer
resin
Brass Gold plating
―
Handling precautions
■
Common precautions
･
SO-02G is waterproof/dustproof;
however, do not allow water or dust to
enter the terminal or come in contact
with accessories or optional devices.
The adapter, desktop holder, docomo nano UIM
card and 1Seg antenna cable are not waterproof/
dustproof. Do not use in a bathroom or other
highly humid area or do not let rain touch. Or
putting them on your body, humidity of sweat
may cause internal corrosion and malfunction.
Note that malfunctions which are determined to
be caused by water as result of inspections are
outside the scope of the warranty. Since these
conditions are outside of the scope of the
warranty, a repair, if at all possible, is charged.
･
Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
- Do not rub it roughly with a dry cloth. The
display may be damaged.
- Drops of water or dirt left on the display may
cause stains.
- Do not use alcohol, thinner, benzine, cleaning
detergent, etc. to clean the terminal. These
chemicals may erase the printing on the
terminal or cause discoloration.
Content s/Precautio ns
17
･
Clean the terminals occasionally with a
dry cotton swab.
If the jack is soiled, connection gets worse and it
may cause power to be turned off or insufficient
battery charge, so clean the jack with a dry
cotton swab etc. When cleaning, be careful not
to damage the terminals.
･
Do not leave the terminal near the air
conditioning vent.
Extreme temperature changes may produce
condensation and corrode the internal parts of
the terminal, causing it to malfunction.
･
Make sure to use the terminal etc.
without excessive force.
If you put the terminal in a bag full of items or sit
down with the terminal in the pocket of your
cloth, it may damage the display, internal circuit
board, etc. and cause malfunction.
If doing so while the external device is connected
to the microUSB jack or headset jack, it may
cause damage or malfunction.
･
Do not rub or scratch the display with
metal.
The display may get scratched and it may cause
malfunction or damage.
･
Read the users manuals supplied with
individual optional devices.
■
The terminal precautions
･
Do not press touch screen surface
forcibly, or not operate with a sharppointed objects such as nail, ballpoint
pen, pin, etc.
Doing so may cause damage of touch screen.
･
Do not use the terminal in extremely hot
or cold places.
Use the terminal where the temperature ranges
between 5℃ and 40℃ (limited to the temporary
use in a bathroom etc. when temperature is
above 36℃) and humidity ranges between 45%
and 85%.
･
Using the terminal near land-line phone,
television or radio may cause
interference in these electric appliances.
Make sure to move far away from them
when using the terminal.
･
Note down the information saved in the
terminal in a separate note and keep it
safely.
Under no condition will DOCOMO be held liable
for any damaged or lost data saved in the
terminal.
･
Do not drop or give a strong impact to
the terminal.
Doing so may cause malfunction or damage.
･
Do not insert the plug of the external
device into the microUSB jack or
headset jack at the slant or pull it
obliquely while connecting.
Doing so may cause malfunction or damage.
･
The terminal could become warm while
in use and charging. This condition is
not abnormal. You can continue using
the terminal.
Content s/Precautio ns
18
･
Do not leave the camera under direct
sunlight.
If you do so, some of the elements may melt or
become faded.
･
Usually, use the terminal with the
docomo nano UIM card slot cover and
microUSB jack/microSD card slot cover
closed.
Failure to do so may get dust or water inside and
cause malfunction.
･
While microSD card is being used, do
not take the card out and do not turn off
the terminal.
Doing so may cause data loss or malfunction.
･
Do not let magnetic cards, etc. close to
the terminal.
The magnetic data in cash cards, credit cards,
telephone cards, floppy disks, etc. may be erased.
･
Do not bring strong magnetic objects
close to the terminal.
Strong magnetic objects may cause
misoperation.
･
The internal battery is a consumable
part.
Replace the internal battery if the terminal has
extremely short operation time on a full charge,
though it may vary by operating conditions. For
replacing internal battery, contact "Repairs" on
the last page (in Japanese only) or DOCOMOspecified repair office.
･
Charge the battery in an environment
with the proper ambient temperature (5
℃
to 35℃).
･
The operating time of the internal
battery varies depending on the
operating environment and the
degradation level of the internal
battery.
･
Be careful especially about the
following points when preserving the
terminal.
- The battery is fully charged (immediately after
the charging is complete)
- The battery has run out (the terminal cannot
power on)
The performance and life of the internal battery
may deteriorate.
It is recommended that you store the battery
with the remaining battery level of about 40% as
a guide.
■
Precautions on the adapter, desktop
holder
･
Charge the battery in an environment
with the proper ambient temperature (5
℃
to 35℃).
･
Do not charge in the following places.
- Places that are very humid, dusty or exposed to
strong vibrations
- Near land-line phone or TV/radio
･
The adapter or desktop holder could
become warm while charging. This
condition is not abnormal.
Content s/Precautio ns
19
･
When using the DC adapter for
charging, do not turn off the vehicle
engine.
Doing so may cause the vehicle battery run out.
･
When you use the power outlet with a
mechanism to prevent the plug from
being removed, follow the instructions
on the outlet's user's manual.
･
Do not subject the equipment to a
strong impact. Do not deform the
charging jack.
Doing so may cause malfunction.
･
Magnet is used for magnet connector
that is between contacts of the desktop
holder. Make sure that any iron sands or
metal objects (clips etc.) are not
adhered before attaching the terminal.
Remove the foreign objects with a soft
cloth etc., if any.
･
Do not put a magnetic card such as a
cash card, commuter pass, etc. closer to
the magnet connector that is between
contacts of the desktop holder.
Magnetism of the desktop holder may
affect the magnetism of the card.
･
Be sure to install the supplied
attachment to the desktop holder for
charging. The terminal cannot be
charged on the desktop holder without
attachment. Attachment 34A is
attached to the Desktop Holder by
default. Attachment 34B only supports
terminal covers with "
純正卓上ホルダ対応
(Compatible with genuine desktop
holders)" mark (commercially available)
and the terminal can be charged on the
desktop holder with a compatible cover
attached.
■
docomo nano UIM card precautions
･
Do not use unnecessary force to insert/
remove the docomo nano UIM card.
･
Note that DOCOMO assumes no
responsibility for any malfunctions
resulting from inserting the docomo
nano UIM card into another IC card
reader/writer and using it.
･
Always keep the IC portion clean when
you use the card.
･
Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
･
Note down the information registered
in the docomo nano UIM card on a
separate sheet and keep it for future
reference.
Content s/Precautio ns
20
Under no condition will DOCOMO be held liable
for any damaged or lost data saved in the
terminal.
･
Take an expended docomo nano UIM
card to a sales outlet such as docomo
Shop for proper disposal in order to
protect the environment.
･
Do not carelessly damage, contact, or
short-circuit an IC.
Doing so may cause data loss or malfunction.
･
Do not drop a docomo nano UIM card or
subject it to impact.
Doing so may cause malfunction.
･
Do not bend a docomo nano UIM card
or place a heavy object on it.
Doing so may cause malfunction.
･
Do not insert a docomo nano UIM card
into the terminal if a label or seal is
attached to the card.
Doing so may cause malfunction.
■
Bluetooth function precautions
･
To secure the Bluetooth communication
security, the terminal supports the
security function compliant with
Bluetooth standards, but the security
may not be sufficient depending on the
setting. Concern about the
communication using the Bluetooth
function.
･
Please be aware that DOCOMO is not
responsible for data leak when making
data communications using Bluetooth.
･
Frequency band
The frequency band used by the terminal's
Bluetooth/wireless LAN function is written as
follows:
2.4 : This radio equipment uses the 2400 MHz
band.
Modulation scheme is the
FH/XX/DS/OF
4 : The estimated interference distance is 40
8 : The estimated interference distance is 80
Available channels vary depending on the
country.
For use in an aircraft, contact the airline
beforehand.
･
Bluetooth cautions
The operating frequency band of the terminal is
used by industrial, scientific, consumer and
medical equipment including microwave ovens,
premises radio stations for identifying mobile
units used in the manufacturing lines of plants
(radio stations requiring a license), specified low
power radio stations (radio stations requiring no
license) and amateur radio stations (hereinafter
referred to as "another station").
：
FH-SS, other system, DS-SS,
or OFDM system.
m or less.
m or less.
: The full band between 2400 MHz
and 2483.5 MHz is used and the
band of the mobile identification
device can be avoided.
Content s/Precautio ns
21
- Before using this equipment, confirm that
"another station" is not being operated nearby.
- In the event of the terminal causing harmful
radio wave interference with "another station",
promptly change the operating frequency or
stop radio wave emission by turning off the
power, etc.
- If you have further questions, contact "General
Inquiries" on the last page.
■
Wireless LAN (WLAN) precautions
･
Wireless LAN (WLAN) exchanges
information using radio waves, and
allows you to freely establish LAN
connection if you are within an area
where radio wave reaches. On the other
side, if you communicate without
appropriate security settings,
communications may be intercepted or
hacked by malicious parties. It is
recommended to make necessary
security settings on your responsibility
and expense.
･
Wireless LAN
Do not use wireless LAN near magnetic devices
such as electrical appliances or AV/OA devices, or
in radio waves.
- Magnetism or radio waves may increase noises
or disable communications (especially when
using a microwave oven).
- When used near TV, radio, etc., reception
interference may occur, or channels on the TV
screen may be disturbed.
- If there are multiple wireless LAN access points
nearby and the same channel is used, search
may not work correctly.
･
2.4GHz device cautions
The operating frequency band of the WLAN
device is used by industrial, scientific, consumer
and medical equipment including home electric
appliances such as microwave ovens, premises
radio stations for identifying mobile units used in
the manufacturing lines of plants (radio stations
requiring a license), specified low power radio
stations (radio stations requiring no license) and
amateur radio stations (radio stations requiring a
license).
- Before using the device, confirm that premises
radio stations for identifying mobile units,
specified low power radio stations and amateur
radio stations are not being operated nearby.
- If the device causes harmful radio interference
to premises radio stations for identifying
mobile units, immediately change the
frequency band or stop use, and contact
"General Inquiries" on the last page for crosstalk
avoidance, etc. (e.g. partition setup).
- If the device causes radio interference to
specified low power radio stations or amateur
radio stations, contact "General Inquiries" on
the last page.
Content s/Precautio ns
22
･
5GHz device cautions
The terminal can use 3 frequency bands of
5.2GHz band (W52), 5.3GHz band (W53), 5.6 GHz
band (W56).
- 5.2GHz band (W52/36, 40, 44, 48 ch)
- 5.3GHz band (W53/52, 56, 60, 64 ch)
- 5.6GHz band (W56/100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140 ch)
Using wireless LAN built-into the terminal in 5.2/
5.3 GHz outside is prohibited by the Radio Law.
■
FeliCa® and NFC reader/writer function
precautions
･
FeliCa and NFC reader/writer, P2P
function of the terminal use weak waves
requiring no licenses for radio stations.
･
They use 13.56 MHz frequency band.
When using other reader/writer or P2P
function in your surroundings, keep the
terminal away sufficiently from them.
Before using the FeliCa and NFC reader/
writer, P2P function, confirm that there
are no radio stations using the same
frequency band nearby.
･
For use in an aircraft, contact the airline
beforehand. In some countries, usage
may be restricted. Confirm regulations
etc. for the country/area you stay before
using
■
Note
･
Do not use a remodeled terminal. Using
a remodeled terminal violates the Radio
Law/Telecommunications Business Act.
The terminal is compliant with rules on the
technical standard conformance of specified
wireless equipment based on the Radio Law/
Telecommunications Business Act, and as a proof
of it, the "Technical Compliance Mark " is
depicted on the electronic nameplate of the
terminal. To check the certificate, from the Home
u
screen,
information]
If you remove the screws and alter the inside of
the terminal, the technical regulations
conformity certification becomes invalid.
Do not use the terminal with the certification
invalid, as it is a violation of the Radio Law and
Telecommunications Business Act.
･
Be careful when using the terminal
[Settings]u[About phone]u[Legal
u
[Certificates].
while driving.
Using a handheld mobile phone while driving
will result in a penalty.
However, absolutely necessary cases such as
rescue of a sick person or maintaining public's
safety are exempted.
･
Use the FeliCa reader/writer function
only in Japan.
FeliCa reader/writer function of the terminal
conforms to Japanese radio standards. If you use
this function overseas, you may be punished.
･
Do not alter the basic software illegally.
It is regarded as the software modification and
Repairs may be refused.
Content s/Precautio ns
23
Waterproofness/ Dustproofness
SO-02G provides waterproofness property of
*1
and IPX8*2 and dustproofness
IPX5
property of IP6X
UIM card slot cover and microUSB jack/
microSD card slot cover firmly attached.
*1 IPX5 means that a phone keeps functioning
after applying a jet flow of 12.5 L/min. from
every direction from a distance of
approximately 3 m for at least 3 minutes
using water nozzle in 6.3 mm inner
diameter.
*2 IPX8 means that a phone keeps functioning
after SO-02G is slowly submerged to depth
of 1.5m in static tap water at room
temperature, left there for approximately 30
minutes and then taken out.
*3 IP6X indicates that a phone has the ability
to prevent dust from entering it even when
it has been shaken for 8 hours in an
apparatus containing dust particles 75
or less in diameter.
*3
with the docomo nano
μ
m
What you can do with
waterproofness/dustproofness
of SO-02G
･
You can talk without an umbrella in the rain
(for rainfall of 20 mm or less per hour).
- Do not open or close the docomo nano UIM
card slot cover or microUSB jack/microSD
card slot cover with wet hands or with water
droplets on the terminal.
･
You can w ash the te rmi nal w hen it g ets d irt o r
stained with liquid other than tap water.
- Wash the terminal with tap water at normal
℃
temperature (5
flow (less than 6 L/min.) at distance of
approximately 10 cm away from the tap or
shower.
- When washing the terminal, hold the
docomo nano UIM card slot cover and
microUSB jack/microSD card slot cover to
keep them closed, and wash the terminal
with your hands, not using a brush or
sponge. After washing, drain the terminal
before use (P.28).
･
You can use at a poolside. Do not throw water
from the pool on the terminal, or soak it in
pool water.
-35℃) by weaker water
Content s/Precautio ns
24
･
You can use the terminal in a bathroom.
- Do not immerse the terminal into a bathtub.
Also, do not use the terminal in hot water.
Doing so may cause malfunction. If you
should fall the terminal into the bathtub,
immediately pick it up to drain water in
specified procedure (P.28).
- Never put the terminal in hot spring wate r or
water containing soap, detergent or bath
powder. In case the terminal gets wet with
water other than tap water, wash it in the
procedure above.
- You can use the terminal within 2 hours in a
bathroom where the temperature ranges
℃
between 5 and 45
and humidity ranges
between 45 and 99%.
- Rapid temperature change may cause
condensation. If you bring the terminal from
a cold place to warm place such as a
bathroom, wait until the terminal reaches
the room temperature.
- Do not put hot water from a faucet or
shower.
To ensure waterproofness/
dustproofness
To avoid water ingress, be sure to observe the
following points.
･
Do not throw any liquid other than room
temperature tap water on the terminal, or
soak it in such liquid.
･
Firmly close the docomo nano UIM card slot
cover and microUSB jack/microSD card slot
cover. Even a fine obstacle (one hair, one grain
of sand, tiny fiber, etc.) put between contact
surfaces may allow water to enter.
･
Do not poke the earpiece/speaker,
microphone, speaker, second microphone,
headset jack, or strap hole with a sharp object.
･
Do not let the terminal fall. It may become
scratched causing the waterproof/dustproof
performance to degrade.
･
The rubber gaskets on the inner side of the
docomo nano UIM card slot cover and
microUSB jack/microSD card slot cover play
an important role in keeping waterproof/
dustproof performance. Do not remove or
damage them. Also, prevent dust from
adhering to them.
Content s/Precautio ns
25
■
Opening the docomo nano UIM card
slot cover and microUSB jack/microSD
card slot cover.
Open the covers with your fingertip by the
grooves.
■
Closing the docomo nano UIM card
slot cover and microUSB jack/microSD
card slot cover.
Put the cover back in the direction of the
arrow and push the parts in, then ensure
there are no gaps.
Groove
docomo nano UIM card
slot cover
Groove
microUSB jack/microSD
card slot cover
docomo nano UIM card
slot cover
It is recommended to replace the parts for
maintaining waterproof/dustproof property once
every two years regardless of whether any
abnormality is present. DOCOMO replaces the
parts as a chargeable service. Bring the terminal to
a sales outlet such as a DOCOMO-specified repair
office.
microUSB jack/microSD
card slot cover
Content s/Precautio ns
26
Important precautions
Do not perform actions shown in the
illustrations below.
<Example>
Using in hot
spring
Machinewashing
Applying strong
Attaching
sand/mud
water ow
Bath powder
Washing with
brush/sponge
Soaking in
ocean water
Using Soap/Detergent/
Observe the following precautions to use the
terminal properly.
･
Accessories and optional devices are not
waterproof/dustproof.
･
Do not apply water flow stronger than
allowed (water flow of 6L/min. or more : e.g.,
such water flow that gives you pain when
applied to your skin directly from a faucet or
shower). SO-02G provides IPX5
waterproofness, but doing so may cause
malfunction.
･
If the terminal gets wet with salt water, sea
water, refreshing beverage or mud or sand
adhered, wash it immediately. If they dry out,
it is hard to remove the dirt and it may cause
damage or malfunction.
･
Do not put the terminal in hot water, use it in
a sauna or apply hot airflow (from a hair dryer
etc.) to it.
･
Do not move the terminal in water or slam the
terminal against the surface of water.
･
If you put the terminal in tap water, be sure to
have it within 30 minutes.
･
When you use the terminal in swimming pool,
obey rules of the facility.
･
The terminal does not float on water.
･
Do not leave water on the terminal. In cold
region, the terminal freezes up and may cause
malfunction.
･
Do not leave water on the earpiece/speaker,
microphone, speaker, second microphone,
and headset jack. Such water may interfere
with talking.
･
If the terminal gets splashed with water or
other liquid while the docomo nano UIM card
slot cover or microUSB jack/microSD card slot
cover is open, the liquid may get inside the
terminal, causing electric shock or
malfunction. Stop using the terminal, turn off
the power and contact a DOCOMO-specified
repair office.
･
If any of the rubber gaskets on the inner side
of the docomo nano UIM card slot cover or
microUSB jack/microSD card slot cover is
damaged or deformed, have it replaced at a
DOCOMO-specified repair office.
Content s/Precautio ns
27
･
Do not connect 1Seg antenna cable,
earphones, etc. with the terminal wet with
water. Doing so may cause malfunction.
DOCOMO does not guarantee actual operations
under all states. Malfunctions deemed to be caused
by inappropriate operation by the customer are
not covered by the warranty.
Draining water from the
terminal
When the terminal is wet, water may flow out
after wiping it off; drain the water in the
following steps.
a
Hold the terminal firmly and wipe off moisture on
the terminal surface and back side with dry, clean
cloth etc.
b
Shake the terminal approximately 20 times, firmly
holding it, until there is no more water splattering.
c
Swing the terminal about 10 times against a dry,
clean cloth etc. to wipe off any water remaining in
the earpiece/speaker, microphone, speaker, second
microphone, headset jack, power/screen lock key,
volume/zoom key, camera key, contacts for the
desktop holder, covers (docomo nano UIM card slot
cover and microUSB jack/microSD card slot cover),
etc.
d
Wipe off water drained from the terminal with dry,
clean cloth etc., and dry naturally.
･
Wipe off water drained from the terminal with
dry, clean cloth etc., and dry naturally.
･
Do not wipe off water remaining in gaps directly
with a cotton swab etc.
･
Dry the terminal naturally for about 3 hours at
room temperature.
Content s/Precautio ns
28
Notes on charging
Check the following before and after
charging.
･
Check if the terminal is not wet. Never charge
the battery when the terminal is wet.
･
Accessories and optional devices are not
waterproof/dustproof.
･
When charging the battery when or after the
terminal is wet, adequately drain it and wipe
off water with a dry, clean cloth etc., before
connecting the supplied desktop holder or
opening the microUSB jack cover.
･
When the microUSB jack cover is opened for
charging, close the cover firmly af ter charging.
It is recommended to use the desktop holder
for charging to prevent water or dust from
seeping inside through the microUSB jack.
･
Do not use the AC adapter or desktop holder
in a bathroom, shower room, kitchen, lavatory
or other highly humid area. Doing so may
cause fire or electric shock.
･
Do not touch the AC adapter or desktop
holder with wet hands. Doing so may cause
electric shock.
Content s/Precautio ns
29
Part names and functions
abfcd
g
i
u
h
n
q
k
v
w x
e
j
a
Notification LED
b
Proximity sensor : Detect the face to get close
during a call and turn on or off the touch screen to
prevent misoperation, or help auto brightness
control.
c
Earpiece/Speaker
d
Front camera lens
e
Tou ch s creen
f
Speaker
g
Camera lens
h
Flash/Photo light
i
FOMA/Xi/GPS antenna section
j
FOMA/Xi antenna section
k
mark
l
docomo nano UIM card
Nameplate
*2
m
*1
*1
r
o
s
l
m
n
o
p
q
r
s
t
u
v
w
x
*1 The antenna is built into the terminal. Covering
around the antenna with your hand may affect the
quality of communications.
p
t
microUSB jack/microSD card slot
Contacts for Desktop holder
docomo nano UIM card slot
Wi-Fi/Bluetooth antenna section
Power key/Screen lock key
Volume key/Zoom key
Camera key
Headset jack
Second microphone : Reduce noise to make voice
to be listened easily.
Strap hole
*1
Microphone
Before Using the Terminal
30
*2 Do not remove the nameplate with stickers of CE
mark, FCC ID and IMEI information printed.
❖
Note
･
Do not put a sticker etc. on the proximity sensor.
･
The back cover cannot be removed. Attempting to
remove the back cover with excessive force may
cause damage or malfunction.
･
The battery is built into the terminal and not removal.
docomo nano UIM card
The docomo nano UIM card is an IC card
recorded user information such as your
phone number etc.
･
You can use the terminal with a docomo nano
UIM card. If you have a docomo mini UIM,
docomo UIM, or FOMA card, bring it to a
docomo Shop to replace it with a docomo
nano UIM card.
･
When docomo nano UIM card is not inserted
to the terminal, making calls, packet
communication, etc. are not available.
･
For details on the docomo nano UIM card,
refer to the docomo nano UIM card manual.
･
When inserting/removing the docomo nano
UIM card, make sure to power off the terminal
(P.39).
･
Opening/closing docomo nano UIM card slot
cover (P.25)
■
Security codes of the docomo nano
UIM card
The docomo nano UIM card has a security
code called a PIN code. The code is set to
"0000" at subscription, which you can
change by yourself (P.165).
❖
Information
･
Please be careful not to touch or scratch the IC when
you handle the docomo nano UIM card. Doing so
may cause malfunction or damage.
Inserting docomo nano UIM
card
Open the docomo nano UIM card
1
slot cover, then hook your
fingertip on the projection part of
the tray ( ) to pull the tray
straight out and remove it from
the terminal.
Tray
Before Using the Terminal
31
Set docomo nano UIM card into
2
the tray with IC facing up ( ), then
insert the tray with the card and
press it all the way into the
terminal.
･
Make sure the orientation of the corner
cut and direction to insert.
Close the docomo nano UIM card
3
cover, firmly press parts and
make sure that there are no gaps
between the terminal and cover.
Tray
IC
Corner
cut
Removing docomo nano UIM
card
Open the docomo nano UIM card
1
slot cover, then hook your
fingertip on the projection part of
the tray to pull the tray straight
out and remove it from the
terminal.
Before Using the Terminal
32
Remove the docomo nano UIM
2
card from the tray ( ), then insert
the tray into the terminal and
press it straight all the way.
･
Be careful about the direction to insert
of the tray.
Charging
The internal battery is not fully charged at the
time of purchase.
･
Estimated charging time (P.213)
docomo nano
UIM card
Tray
Close the docomo nano UIM card
3
slot cover, firmly press the cover,
and make sure that there are no
gaps between the terminal and
cover (P.32).
Operation time on full charge
(estimate)
The charging time varies by the internal
battery condition or operating environment.
･
"Continuous standby time", "Continuous call
time" (P.215)
Continuous
stand-by
time
Continuous
call time
FOMA/3G
GSM
LTE
FOMA/3G
GSM
VoLTE call
(voice)
Stationary (Auto) : Approx.
800 hours
Stationary (Auto) : Approx.
620 hours
Stationary (Auto) : Approx.
650 hours
Approx. 700 min.
Approx. 650 min.
Approx. 990 min.
Before Using the Terminal
33
Life of the internal battery Before charging
･
The internal battery is a consumable part.
Each time the internal battery is recharged,
the battery usage time per one charge
gradually decreases.
･
When the battery usage time per one charge
becomes about half of that at the time of
purchased, replacing the internal battery is
recommended because the internal batter y is
near the end of life.
･
Watching 1Seg etc. for a long time while
charging may shorten the lifetime of the
internal battery.
･
To check the charging performance, from the
Home screen, tap
u
[Status]u[Battery life].
phone]
u
[Settings]u[About
･
It is recommended to use the AC Adapter 04/
05 (optional) for charging. For details on the
AC Adapter 04/05, see the AC Adapter 04/05
manual.
･
The AC Adapter 03/04/05 is compatible with
100V to 240V AC. For using the terminal
overseas, a plug adapter that fits the electrical
outlets in the country you stay is needed. Do
not use an electrical transformer for overseas
use to charge the terminal.
･
Use a compatible AC adapter or microUSB
cable for charging. If you use a charger other
than compatible ones, charging may not be
available or operations may not be per for med
correctly.
･
Insert and remove the AC adapter cable or
microUSB cable slowly and evenly so that
excessive force is not applied.
･
When charging starts, notification LED of the
terminal turns on (P.46).
･
To check the battery level, see the status bar at
the top of the screen or from the Home
u
screen, tap
[Settings]u[About phone]
[Status] to see "Battery level".
･
If you start charging with the terminal
powered off, the power turns on, although
you cannot operate the terminal. Therefore,
do not charge the battery in a place where
the use of the terminal is prohibited.
Before Using the Terminal
u
34
Charging with Desktop Holder
When using supplied Desktop Holder SO24
and AC Adapter 05 (optional) for charging, do
the following procedures.
･
Be sure to attach the supplied attachment
(Attachment 34A or Attachment 34B) to the
desktop holder when charging (P.36). The
terminal cannot be charged on the desktop
holder without attachment.
AC adapter
Install the terminal to the desktop
3
holder and move it left or right
until it clicks.
･
When the terminal and the desktop
holder are correctly connected, the
notification LED of the terminal turns
on (P.46).
Notication
LED
Desktop holder
Charging jack
microUSB plug
Insert a microUSB plug of the AC
1
adapter into the charging jack on
the back side of the desktop
holder with the engraved side (B)
facing up ( ).
Unfold the power plug of the AC
2
adapter and insert it into an outlet.
When charging is complete,
4
holding the desktop holder, lift the
terminal up to remove.
Remove the power plug of the AC
5
adapter from the power outlet.
Remove the microUSB plug of the
6
AC adapter from the desktop
holder.
Before Using the Terminal
35
Attaching/Removing the
attachment
Attachment 34A
Groove
Attachment 34B
■
Attaching
Check the shape of front/back of
1
the attachment and the attaching
part of the desktop holder, then fit
the attachment with the desktop
holder.
Firmly press the attachment
2
straight and make sure that there
are no gaps between the
attachment and the desktop
holder.
■
Removing
Put your fingertip into the groove
1
on the one side of the attachment,
lift it up at a slant while pressing
the desktop holder, then remove it
().
❖
Note
･
You cannot charge the battery by connecting the
desktop holder to a PC.
･
Check the connecting direction to connect correctly.
Wrong connection may cause damage.
･
Attachment 34A is attached to the Desktop Holder
by default.
･
Attachment 34B only supports terminal covers with "
純正卓上ホルダ対応
desktop holders)" mark (commercially available) and
the terminal can be charged on the desktop holder
with a compatible cover attached.
(Compatible with genuine
Before Using the Terminal
36
Charging with AC adapter
When using AC Adapter 05 (optional) for
charging, do the following procedures.
･
Opening/closing microUSB jack cover (P.25)
Notication LED
When charging is complete,
3
remove the power plug of the AC
adapter from the power outlet.
Remove the microUSB plug of the
4
AC adapter evenly from the
terminal.
Close the microUSB jack cover,
5
firmly press it and make sure that
there are no gaps between the
terminal and cover.
❖
Note
･
Check the connecting direction to connect correctly.
Wrong connection may cause damage.
microUSB plug
AC adapter
Open the microUSB jack cover and
1
insert the microUSB plug of the AC
adapter horizontally into the
microUSB jack of the terminal with
the engraved side (B) facing up.
Unfold the power plug of the AC
2
adapter and insert it into an outlet.
･
Notification LED of the terminal turns
on (P.46).
Charging with DC adapter
DC Adapter 03/04 (optional) supplies power
from a car cigarette lighter socket (12V/24V).
For details, refer to the DC Adapter 03/04
manual.
Before Using the Terminal
37
Charging with a PC
When using Micro USB Cable 01 (optional) for
charging, do the following procedures.
･
Opening/closing microUSB jack cover (P.25)
Notication LED
microUSB plug
USB plug
Open the microUSB jack cover and
1
insert the microUSB plug of the
microUSB cable horizontally into
the microUSB jack of the terminal
with the engraved side ( )
facing up.
Insert the USB plug of the
2
microUSB cable into a USB port of
a PC.
･
Notification LED of the terminal turns
on (P.46).
･
When "Install software" screen appears
on the terminal, tap [Skip] or [Cancel].
microUSB cable
･
When a screen for new hardware
detection etc. appears on the PC, select
キャンセル
"
When the charging is complete,
3
remove the USB plug of the
(Cancel)".
microUSB cable from the USB port
of the PC.
Remove the microUSB plug of the
4
microUSB cable evenly from the
terminal.
Close the microUSB jack cover,
5
firmly press it and make sure that
there are no gaps between the
terminal and cover.
❖
Note
･
Check the connecting direction to connect correctly.
Wrong connection may cause damage.
Before Using the Terminal
38
Turning power on/off
Turning power on
Press and hold P for over a
1
second.
･
The terminal vibrates and lock screen
appears after a while.
･
When you first turn on the terminal
after purchasing, follow the onscreen
instructions to make initial settings
(P.40).
Cancel the screen lock.
2
･
Canceling the screen lock (P.40).
❖
Information
･
If P is pressed to turn the power on when the
battery level is low, the notification LED flashes in red
3 times, or an icon appears indicating that the
battery level is low. Charge the terminal (P.33).
･
When SIM card lock (P.164) is set, enter PIN code on
the PIN code entry screen (P.164).
Turning power off
Press and hold P for over a
1
second.
[Power off]u[OK].
2
Setting sleep mode
When the sleep mode is set, the screen
backlight turns off so that you can avoid
misoperations of the touch screen and keys,
and lock the screen.
Press P.
1
･
Press P again to cancel sleep mode.
❖
Information
･
Also, when the screen backlight goes off after a
specified time elapses, the terminal goes into sleep
mode. You can change the time-out period for
turning off the screen backlight (P.156).
Before Using the Terminal
39
Canceling the screen lock
The lock screen appears when turning the
power on or the sleep mode is canceled by
P
pressing
1
❖
Information
･
On the lock screen, tap to activate "Google"
application.
･
On the lock screen, tap to activate the camera.
･
You can change screen unlock method (P.165).
･
When the Home screen is set to "Simple Home" (P.53)
or Preferred apps settings is set to "Xperia
flick (or swipe) the screen left, right, up, or down to
cancel the screen lock.
.
On the lock screen, .
™
" (P.154),
Adding widgets on the lock
screen
You can add widgets such as calendar, clock,
etc. on the lock screen.
･
Enable the widget on the lock screen in
advance (P.162).
On the lock screen, drag the digital
1
clock widget right.
u
2
Tap a widget to add.
･
Flick the screen to the right in a
u
Tap to set up to 5 widgets.
row
❖
Information
･
To delete a widget, on the lock screen, touch and
hold a widget to delete
displayed at the top of the screen.
u
Drag it to "Delete"
Initial settings
When you first turn on the terminal after
purchasing, follow the onscreen instructions
to make initial settings for language, services,
etc.
Select [English (United States)]
1
[Done]u.
･
After this step, follow the onscreen
instructions to make the following
settings, and tap or [Finish].
- Set your Google account
- Join the world of Sony (Connect to
Sony Entertainment Network)
- Set accounts and auto-sync
- Select the home application you
want to use
[OK]u[OK].
2
u
Before Using the Terminal
40
When the initial settings screen for
3
docomo services appears, mark
[Agree to all]
･
After this step, follow the onscreen
u
[Start settings].
instructions and tap [Next].
-Set docomo ID
- Set docomo cloud
- Set docomo apps password
- Set whether to provide location
information
- Set Remote Initialization Service
- Select whether to install all
applications now or later
* It does not appear if docomo apps password is
not set.
[Start using].
4
･
The operation guide of the Home
screen appears. Tap [Do not show
again]/[OK] to display the Home screen.
❖
Information
･
Some settings can be changed later (P.160, P.166).
･
Make sure that the data connection is available (LTE/
3G/GPRS) or the terminal is connected to a Wi-Fi
network before setting up online services (P.46).
･
You can use the terminal without setting your
Google account, however the Google services such
as Gmail, Google Play, etc. are not available.
Basic operations
Using the touch screen
Precautions on using touch screen
･
Touch screen is designed for being touched
lightly with fingers. Do not push the touch
screen hard with a finger or press sharp
*
objects (nail, ballpoint pen, pin, etc.) against
the screen.
･
Touching the touch screen may not work in
the following cases. Note that it may cause
malfunction.
- Operation with tip of fingernail
- Operation with foreign object on the screen
- Operation with protective sheet or seal on
the screen
- Operation on the wet touch screen
- Operation with fingers wet with sweat or
water
- Operation under water
Before Using the Terminal
41
Operations on the touch screen
■
Tap
Touch an item such as icon or menu with
your finger lightly and release it.
･
Double-tap means tapping twice quickly.
■
Touch and hold
Touch and hold an icon or menu item long.
■
Flick (Swipe)
Touch the screen and flick up/down/left/
right.
■
Drag
Touch the screen, drag to the desired
position and release the finger.
■
Scroll
When whole content cannot be displayed,
flick up/down/left/right displayed content
to scroll (move) the display position.
■
Pinch
Touch the screen with two fingers and
widen (pinch-out) or narrow (pinch-in) the
fingers' distance. On some screens, pinchout to zoom in and pinch-in to zoom out.
Before Using the Terminal
42
Basic key icon operation
xx y
x
Back Go back to the previous screen. Or
y
Home Go to the Home screen.
r
Recently
used apps
* In this manual, each key icon operation is described
x, y, r
with
close a dialog box, an option
menu, the Notification panel, etc.
Touch and hold the icon and drag
to to activate "Google"
application, or drag to to
activate "What's New".
Display recently used applications
in thumbnail list to activate or
delete applications from the list
(P.62). Also, use or set small apps
(P.62).
r
.
Switching portrait or landscape
view automatically
You can set the screen orientation to switch
between landscape and portrait view
automatically according to the terminal
orientation.
Drag the status bar downwards.
1
[Quick settings]u[Auto rotate].
2
･
When the setting is ON, it changes to
(white).
❖
Information
･
Even when you change the orientation of the
terminal, the screen may not change to landscape
view depending on the screen such as Home screen,
etc.
･
While charging with the desktop holder, the screen
view may change regardless of the auto rotate
screen setting.
･
Changing orientation of the terminal in nearly
horizontal state against the ground does not switch
to portrait view/landscape view automatically.
･
Set [Auto rotate] to ON. Then, from the Home screen,
u
[Settings]u[Display]u[Screen rotation]uTap
[Smart screen rotation] to turn on or off a feature that
automatically determines whether to rotate the
screen according to the movement of the terminal.
Before Using the Terminal
43
Setting silent mode Capturing a still image or video
Press and hold P for over a
1
second.
Tap / / .
2
: Mute (Ringtone 0)
: Vibrate
: Cancel silent mode
❖
Information
･
Press and hold the volume down key to set vibrator
and press the volume down key while the vibrator is
set to set mute. On the lock screen, during a call, in
some applications such as Camera and Walkman,
silent mode cannot be set even if the volume down
key is pressed.
･
Setting the terminal to silent mode does not mute
sounds for shutter, playback of video or music,
dialpad operation sound during a call or sound
emitted when [End call] is tapped, etc.
･
While silent mode is set, adjusting volume for
"Ringtone & notifications" from "Volumes" (P.156) in
Sound or turning up the volume by pressing the
volume up key cancels silent mode.
displayed on the screen
You can capture what is displayed on the
screen. (Take screenshot/Record screen)
Capturing a still image (Take
screenshot)
On the screen you want to capture,
1
press and hold
down key for over a second at the
same time.
･
Screenshot is captured and appears
in the status bar.
❖
Information
･
Alternatively, press and hold P for over a second
Tap [Take screenshot] to capture screenshot.
･
Drag the status bar downwardsuTap [Screenshot
captured.] to check captured images in the "Album"
or "Photos" application. Also, tap [Share] to attach
captured images to an application to send or to
share them.
P
and volume
u
Before Using the Terminal
44
Capturing a video (Record screen)
Press and hold P for over a
1
2
3
❖
Information
･
The control panel allows you to:
- Tap to display an image from the front camera
and capture the video together with that image.
- Tap to change the image quality or orientation
of the video.
･
Drag the status bar downwardsuTap [Sc reen
recording saved] to check recorded video. Tap
[Share] to send by attaching recorded video to app,
or tap [Edit] to edit video.
u
second
[Record screen].
A control panel is displayed.
･
If terms of use are displayed, read them
and then tap [Agree].
Tap to start recording.
Tap the recording time button
Tap to fini sh c apt uri ng.
･
Screen recording is recorded and
appears in the status bar.
･
Tap to close the control panel.
Setting Emergency mode
In case of emergency such as disaster, restrict
functions to save the battery power.
Press and hold P for over a
1
second.
[Emergency mode]uConfirm
2
u
"Important information"
have read the important
information"
･
All running applications end and the
u
[Turn on].
terminal restarts.
❖
Information
･
To cancel Emergency mode, press and hold P for
over a second
or drag the status bar down
on]
the terminal restarts.
･
For details on available applications in emergency
mode, from the Home screen,
[Power management]u[Emergency mode]
[Important information]uTap [Available apps] to see
the information.
･
If you set/cancel emergency mode, you may need to
reconfigure widgets or small apps (displayed in a
small window) on the Home screen.
u
[Emergency mode]uTap [ Turn o ff ]
u
[Turn off]. Emergency mode is canceled and
u
u
Mark "I
[Emergency mode is
u
u
[Settings]
u
Before Using the Terminal
45
Notification LED
Notification LED provides information on the
terminal status, incoming calls, mail
reception, etc.
･
Notification LED when STAMINA® mode is set
(P.158)
Status Indication
Red
Orange
Green
Flashing red
Flashing pale
purple
* Flashing while the backlight turns off or the lock
screen is displayed.
❖
Information
･
If the battery level is low, the notification LED flashes
in red 3 times when
on.
･
When charging starts with the power off, notification
LED turns on in red first.
Indicate that the battery level is
14% or less while the battery is
being charged
Indicate that the battery level is
15% - 89% while the battery is
being charged
Indicate that the battery level is
90% or more while the battery is
being charged
Indicate that the battery level is
14% or less
Indicate missed calls, new
*
messages (SMS), or new Gmails
exist
P
is pressed to turn the power
Status bar
A status bar appears at the top of the screen.
In the status bar, the terminal status and
notification are displayed. Notification icons
appear on the left side, and status icons
appear on the right side of the status bar.
Status bar
Status icon
The main status icons displayed on the status
bar are as follows.
Signal strength
International roaming available
International roaming connected
Out of service
HSPA available
Communicating in HSPA
3G (packet) available
Communicating in 3G (packet)
LTE available
Communicating in LTE
Connecting to Wi-Fi
Communicating in Wi-Fi
Connecting to Wi-Fi using Auto IP function
Bluetooth function ON
Before Using the Terminal
46
Connecting to Bluetooth device
Airplane mode activated
Silent mode (vibration) ON
Silent mode (mute) ON
Speakerphone ON
Microphone put on mute
Alarm is set
NFC Reader/Writer, P2P function ON
Positioning with GPS
Battery status
The battery is charging
％
Battery is low (4
PUK code locked, or docomo nano UIM card
not inserted
STAMINA mode ON
Low battery mode ON
❖
Information
･
Status icons displayed in the status bar can be
changed (P.154).
or less)
Notification icon
The main notification icons displayed on the
status bar are as follows.
New email message
New Gmail message
New message (SMS)
Problem with message (SMS) delivery
New Area Mail
Screenshot or screen recording saved
Uploading data to Facebook
Uploading data to Facebook completed
Facebook setting request notification
Receiving/downloading data
Sending/uploading data
Notification of data reception etc. via Bluetooth
communication
Unmount microSD card (reading/writing
unavailable)
microSD card removed
Preparing microSD card
Update notification
Installation completed
Application update notification
Software update notification
Downloading software update completed
Installation of software update completed
Software update interrupted, stopped
Android software upgrade notification
Before Using the Terminal
47
NFC/Osaifu-Keitai lock set on the terminal and
docomo nano UIM card
NFC/Osaifu-Keitai lock set on the terminal or
docomo nano UIM card
Omakase Lock set on the terminal and docomo
nano UIM card
Omakase Lock set on the terminal or docomo
nano UIM card
Receiving a call
Making a call
Incoming call on hold*/ongoing call on hold
*
/during a call
*
*
Missed call
Message is recorded in Answering Machine
New voice mail
Event notification for Schedule
Stopwatch is running
Timer in use
Alarm sounding
Playing a track with Media Player
Playing a track with Walkman
Watching 1Seg
*
/notification of reserved
watching
Recording 1Seg*/notification of reserved
recording
FM radio in use
*
USB connected
MHL connected
Available to activate TV launcher
Screen mirroring connected
Mobile data communication invalid
Wi-Fi open network available
Connecting to a VPN
The terminal set as media server/connection
request notification received
Error message/caution message
Problem with sync
Setup guide unchecked
Some notifications are hidden
Notification from docomo LIVE UX
USB tethering is set
Wi-Fi tethering is set
Bluetooth tethering is set
2 or more devices are set for tethering
AUTO- GPS is set
Omakase Lock is set
Available memory on the terminal is low
Notification of data transfer to microSD card
exists (available internal storage decrease)
Authentication failed in docomo ID setting
*
Appears when switched to the Home screen etc.
Before Using the Terminal
48
Notification panel
When notification icons appear on the status
bar, you can open the Notification panel to
check the notifications, activate
corresponding application, etc. Open the
Notification panel and then tap [Quick
settings] to set Silent mode, enable/disable
Wi-Fi function, etc.
Drag the status bar downwards.
1
a
Quick settings
･
Enable/disable functions. Tap [Edit] to change
number of tools or sort order.
･
You can also drag the status bar downwards with
two fingers to display the Quick settings.
Wi-Fi
Bluetooth
NFC
Sound
Enable/disable Wi-Fi function.
Enable/disable Bluetooth function.
Enable/disable NFC Reader/Writer,
P2P function.
Enable/disable silent mode (Vibrate/
Mute).
a
b
Wi-Fi hotspot
Location
Auto rotate
Brightness
Airplane mode
STAMINA
Glove mode
Settings
b
Clear
･
Clear contents on the Notification panel. Some
notifications may not be cleared.
❖
Information
･
Tap x to close the Notification panel.
･
Flick left or right a notification on the Notification
panel to delete from the list.
･
For some notifications, pinch in/out (P.42) the
Notification panel to show/hide screen for operation
such as "Share" and "Call back".
･
Touch and hold a notification on the Notification
panel
information.
Enable/disable Wi-Fi tethering
function.
Enable/disable location information.
Set whether to switch portrait/
landscape view automatically
according to the terminal
orientation.
Adjust screen brightness.
Enable/disable Airplane mode.
Enable/disable STAMINA mode.
Enable/disable Glove mode.
Display Settings menu (P.144).
u
Tap [App info] to check the application
Before Using the Terminal
49
Home screen
You can switch the Home screen of the
terminal to "docomo LIVE UX", "Xperia
Home" or "Simple Home".
･
"docomo LIVE UX" (P.71)
･
"Simple Home" (P.53)
･
Switching home applications (P.63)
Xperia™ Home screen
The Home screen displayed when "Home" is
set to "Xperia
is explained here.
a
b
c
d
e
d
a
Widget : Google Search
b
Widget : Clock
c
Machi-chara
d
Shortcuts (applications)
e
Current home screen position
･
f
Wallpaper
g
Apps button
™
Home" in the initial settings
f
"ひつじのしつじくん®
d
(Butler Sheep)"
g
©NTT DOCOMO
Flick the home screen left or right to switch.
™
❖
Information
･
To change the initial home screen for operations,
switch the home screen you want to change to,
touch and hold the area of the Home screen where
no icons are displayed
u
Tap .
Adding a home screen
Up to 7 home screens can be displayed.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
･
Alternatively, pinch-in on the Home
screen.
Flick the Home screen left or
2
❖
･
･
u
right
.
Information
To return to the Home screen, tap y or x, or
tap any home screen.
To delete home screen, switch to the home screen
you want to delete and then touch and hold the area
of the Home screen where no icons are
u
displayed
Tap .
Before Using the Terminal
50
Adding a widget to the Home screen
Widget is an application which can be added
to the Home screen to use. Use a widget to
start an application easily.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
･
Alternatively, pinch-in on the Home
screen.
[Widgets]uSelect a widget to add.
2
･
When a settings screen appears, follow
the onscreen instructions.
❖
Information
･
To return to the Home screen, tap y or x, or
tap any home screen.
･
To change displaying widget size, touch and hold a
u
Drag the blue frame. Display size for some
widget
widgets may not be changed.
･
To delete a widget, on the Home screen, touch and
hold a widget to delete
displayed at the top of the screen.
u
Drag it to "Remove"
Adding a shortcut to the Home
screen
You can add shortcuts of application,
bookmark, etc.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
･
Alternatively, pinch-in on the Home
screen.
[Apps].
2
Select [Shortcuts] or an
3
application you want to add.
･
If you tapped [Shortcuts], select from
the stored shortcuts.
･
When a data selection screen or setting
screen appears, follow the onscreen
instructions.
❖
Information
･
To return to the Home screen, tap y or x, or
tap any home screen.
･
To delete a shortcut, from the Home screen, touch
and hold the shortcut to delete
displayed at the top of the screen.
u
Drag it to "Remove",
Before Using the Terminal
51
Adding folders on the Home screen
You can put applications, shortcuts, etc.
added to the Home screen into a folder to
manage them.
From the Home screen, touch and
1
hold an icon
u
Drag it over another
icon.
❖
Information
･
To move an icon to a folder, on the Home screen,
touch and hold an icon you want to move
over a folder.
･
To change a folder name, tap a folderuTap the folder
u
Enter a folder nameuTap [Do ne].
name
･
To delete a folder, on the Home screen, touch and
hold a folder to delete
displayed at the top of the screen
Applications, shortcuts, etc. in the folder are also
deleted.
u
Drag it to "Remove"
u
Tap [Delete].
u
Drag it
Changing wallpaper
You can change wallpaper of the Home
screen.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
･
Alternatively, pinch-in on the Home
screen.
[Wallpapers].
2
Tap any of [Album]/[Live
3
Wallpapers]/[Photos]/an image.
･
When you tap [Album], select an image
u
[Crop photo]/[Crop picture]
u
[Always]/[Just once]uAdjust cropping
u
frame by dragging etc.
･
When you tap [Live Wallpapers], select
u
a content
･
When you tap [Photos], select a photo
u
❖
Information
･
To return to the Home screen, tap y or x, or
tap any home screen.
Tap [Set wallpaper].
Tap [SE T WALLPAPE R].
[Done]/[Crop].
Changing theme
You can change themes for the Home screen,
wallpaper of the lock screen, etc.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
･
Alternatively, pinch-in on the Home
screen.
[Themes]uSelect an image.
2
[Apply theme]u[OK].
3
Before Using the Terminal
52
Simple Home screen
Set Simple Home to use Home screen and
setting menu limited to basic functions.
From the Home screen,
1
u
[Settings]u[Home]u[Simple
u
Home]
[OK].
2
･
■
Applications on the Simple Home
screen
Maps
Google
Settings
My Select
Tools Contacts
[OK].
To set the font size to "Extra large", mark
"Set font size to Extra large".
P. 1 3 7
P. 6 3
P. 5 4
P. 5 5
Calendar
Alarm & clock
Calculator
Osaifu-Keitai
Gmail
Play Store
dmenu
dmarket
しゃべってコンシェル
(Shabette concier)
ｉコンシェル
(i-concier)
P. 5 6
P. 5 7
P. 1 3 9
P. 5 8
P. 1 0 7
P. 1 0 0
P. 1 0 5
P. 1 0 5
P. 1 0 5
P. 5 9
P. 5 9
Media Walkman
Album
Movies
1Seg
FM radio
Camera
docomo mail
Messaging
Dial
Apps
Browser
Speed dial 1/Speed dial 2/Speed dial 3
* Applications such as "Anshin Scan", "docomo
backup", etc. appear.
❖
Information
･
To change to the standard Home screen, from the
Simple Home screen, tap [Settings]
Home]
You Tub e
*
u
[OK]u[docomo LIVE UX]/[Xperia™ Home].
u
[Exit Simple
P. 5 6
P. 1 3 1
P. 5 7
P. 1 1 1
P. 1 1 7
P. 1 3 3
P. 1 1 8
P. 9 3
P. 9 3
P. 5 6
―
P. 1 0 2
P. 5 3
Using speed dials
Save frequently used contacts to "Speed dial
1", "Speed dial 2", and "Speed dial 3" to easily
make a call or send a message.
Before Using the Terminal
53
■
Saving contacts
Save phone numbers and mail addresses to
"Contacts" beforehand.
On the Simple Home screen, tap
1
any of [Speed dial 1]/[Speed dial
2]/[Speed dial 3]
Select a contact to save.
2
･
The name "Speed dial 1", etc. is changed
u
[OK].
into the name saved in the "Contacts"
application.
■
Making a call
On the Simple Home screen, select
1
a speed dialu[Call].
･
Operation during a call (P.82)
■
Sending messages (SMS)/mail
On the Simple Home screen, select
1
a speed dial
u
[Send message]/
[Send email].
･
How to send a message (P.93)
･
How to send email (P.97)
･
How to send Gmail (P.100)
❖
Information
･
To change/delete/edit contacts saved in the speed
dials, select a contact saved in the speed dial
[Menu]uTap any of [Edit entry]/[Delete entry]/[Edit
contact].
u
Using Settings
On the Simple Home screen,
1
[Settings].
My profile
Display Sleep
Brightness
Auto-
rotate
screen
Wallpaper
Lock
screen
wallpaper
Font s ize
Screen lock
Check your own phone
number and mail address,
etc.
Select a time duration
before the screen back
light turns off.
Adjust screen brightness.
Set whether to switch
portrait/landscape view
automatically according to
the terminal orientation.
Set wallpaper for Simple
Home screen.
･
To set "Custom", unmark
"Default" and tap
[Custom].
Set wallpaper for lock
screen.
Set font size for the
"Contacts" application, etc.
Set screen unlock method.
Before Using the Terminal
54
Sound Silent/
Customiz e
Home
More settings
Exit Simple Home
Vibrate
mode
Ringtone
Vibrate on
touch
Tou ch
sounds
Vibrate
when
ringing
Change
apps
Reorder
apps
Reset
Set silent mode.
Set ringtone.
Set whether to vibrate the
terminal for some
operations such as
specified software key
operation.
Set whether to emit sound
when selecting menu.
Set wether to vibrate the
terminal when receiving a
call.
P. 5 5
Display Settings menu on
the standard Home screen
(P.144).
Change to the standard
Home screen.
Saving applications in My Select
If frequently used applications, etc are saved
in the "My Select" folder, the applications can
easily be activated
On the Simple Home screen, [My
1
2
❖
Information
･
To delete applications saved in the "My Select" folder,
in Step 2, unmark applications to delete
u
Select]
[Edit]u[OK].
Mark applications to saveu[Done].
u
Tap [D one] .
Changing applications on the
Simple Home screen
On the Simple Home screen,
1
[Settings]
[Change apps]/[Reorder apps].
2
Select applications to change
3
Select applications to display/
select a location to move to.
･
[OK].
4
❖
Information
･
In Step 2, tap [Reset]u[OK] to restore the defaults.
Note that contacts saved in the speed dials and
applications saved in "My Select" folder are not
restored.
u
[Customize Home].
Grayout applications cannot be
changed.
u
Before Using the Terminal
55
Xperia™ Application
screen
The application screen displayed when
"Home" is set to "Xperia
settings is explained here.
･
Switching Home application (P.63)
From the Home screen, .
1
c
a
Current displayed position of the application screen
･
b
Machi-chara
c
Option menu
･
d
Application icons
･
a
Flick the application screen left or right to switch.
Flick the left edge of the application screen to
right or tap in the top of the screen to display
"Search apps", "Uninstall" (P.61), menu to change
order of the application icons on the application
screen or "Play Store".
Some application icons are displayed with a
number of missed calls, unread mails, etc.
b
™
Home" in the initial
d
"ひつじのしつじくん®
(Butler Sheep)"
©NTT DOCOMO
❖
Information
･
On the leftmost application screen, flick to the right
the screen (except for the left edge) to open the
optional menu.
Application list
Applications displayed on the application
screen are as follows.
･
For usage of some applications, separate
subscription (Charged) is required.
Contacts
Activate Xperia™ phonebook application to
manage contacts of your friends or colleagues.
Dial
Activate Xperia™ phone application to make/
receive calls, and switch between calls.
Messaging
Send and receive messages (SMS).→P. 9 3
Browser
Browse web pages with Browser.→P.102
Walkman
Playback music data stored on the internal
storage or microSD card.
Album
View photos and videos you took, and images
→
posted on Facebook or Picasa.
P. 1 3 1
Before Using the Terminal
56
Movies
Play back videos downloaded from Video
Unlimited or transferred from your PC or other
devices. With the Wi-Fi function, your terminal
allows you to play back videos stored on a
DLNA device, and TV programs recorded by a
Blu-ray Disc recorder that supports the TV
transfer feature.
PlayStation
Log in to a PlayStation Network account to use
various services.
Camera
Take still pictures and record video clips.→P.118
1Seg
Watch 1Seg programs.→P. 1 1 1
Play Store
Access to the Google Play, download and buy
→
new applications.
P. 1 0 5
Facebook
Activate Facebook client application.
Twitter
Official Twitter client application. Post a short
message on the website and communicate
with someone else.
Lifelog
An application for recording the usage history
of the terminal as well as your physical
activities. You can see them in chronological
order.
Email
Send and receive emails (multiple accounts are
→
available).
P. 9 6
Calendar
Display a calendar and manage schedule.
Maps
Use Google Maps services, such as viewing
current location, finding another location and
→
calculating routes.
P. 1 3 7
docomo mail
Send/receive mails using DOCOMO mail
address
(@docomo.ne.jp)
. Sent/received mails
are saved in cloud. You can view the same mail
on the multiple devices or transfer mail data
easily when changing model. Pictograms and
Deco-mail can be used, and automatic
→
reception also is supported.
P. 9 3
Osaifu-Keitai
Use Osaifu-Keitai.→P. 1 0 7
Settings
Make the terminal settings.→P. 1 4 4
Sony Entertainment
The folder contains the "
電子書籍
Reader by
Sony (e-books Reader by Sony)", "TV SideView",
"Video Unlimited", "News from Socialife", and
"What's New" applications.
Xperia™ Lounge Japan
Website for smartphones introducing products
of Sony Mobile Communications, Inc. and
campaign information
Before Using the Terminal
57
Sony Select
Connect Sony Select to obtain applications,
games, etc.
Chrome
Connect to the Internet with Google Chrome.
Google
Search information in the terminal and web
→
pages by keywords.
P. 6 3
Google+
Activate SNS client application Google+
provided by Google.
Google Settings
Make settings for Google applications.
Voice Search
Use Google Voice Search.→P. 6 4
YouTube
Play back videos in the world or upload
→
recorded videos.
P.133
Drive
View/edit files stored in Google Drive.
Gmail
Send and receive mails from/to a Google
→
account.
P.100
Photos
View photos or videos. Sign in to Google+ to
back up the data.
Play Movies & TV
An application for accessing movie rental
service of Google Play. Select a movie you want
to watch and rent it.
Play Books
Download new books, bestsellers, etc. from
Google Play to read.
Play Games
Download games, from Google Play and play
them.
Hangouts
Chat using photos, pictograms, and videos.
Alarm & clock
Set alarms or display clock.→P. 1 3 9
Calculator
Perform basic arithmetic operations and other
various calculations.
Instruction Manual
Display the terminal instruction manual. You
can directly start a function you want to use
from the explanation (in Japanese only).
* See "About manuals of SO-02G" in
"Introduction".
ツール
(Tools)
The folder contains the "Sketch", "FM radio", "File
Commander", "OfficeSuite", "Evernote",
™
"TrackID
", " Trac k ID™ TV" and "Movie Creator"
applications.
docomo phonebook
Manage contacts using phonebook
→
application provided by DOCOMO.
P. 8 8
Phone
An application for using phone features and
→
configuring call settings.
P. 7 8
Before Using the Terminal
58
dmenu
An application shortcut for "dmenu". In
"dmenu", you can easily find contents you used
in i-mode and joyful and convenient contents
→
for smartphones.
P. 1 0 5
dmarket
There are various products such as music, ebooks, etc. You can purchase them that suits
→
your needs.
ｉコンシェル
P. 1 0 5
(i-concier)
An application for using i-concier. i-concier is a
service in which a mobile phone supports your
life like a "butler" or "concierge".
しゃべってコンシェル
(Shabette concier)
Speak what you want to search or what you
want to do to the terminal. The application
recognizes your words and display the most
suitable answer.
アプリ
iD
(iD application)
An application for using "iD", electronic money
offered by docomo. Once you have set up "iD"
on your Osaifu-Keitai, you can hover the
terminal over an IC card reader at various shops
to make your shopping easier and more
→
comfortable.
P. 1 1 0
Tor uCa
An application for collecting saving coupons/
convenient information from your favorite
→
P.110
shops.
フォトコレクション
(Photo collection)
A service for backing up photos or videos up to
5GB to cloud free of charge, then accessing the
backup data from smartphones, tablets or PCs.
Media Player
Play music and videos.→P.133
IC Tag/Barcode Reader
An application that can read information
written in IC tag or bar code.
Hanashite Hon'yaku
An application for translating spoken words
into the listener's native language. This allows
you to enjoy talking with people who speak
languages other than your own.
Schedule
An application for creating/managing schedule
whose data is shared with Memo application. It
→
supports i-concier service.
P.138
Memo
An application for creating/managing memos
whose data is shared with Memo application. It
supports i-concier service.
docomo backup
An application for backing up to/restoring from
→
"Data Storage BOX" or "microSD card".
データ保管
BOX (Data Storage Box)
P.141
An application for using Data Storage Box. Data
Storage Box is a service which allows you to
upload files to easily manage them in the
cloud.
Before Using the Terminal
59
Anshin Scan
An application for protecting your terminal
from virus attacks. This feature detects potential
viruses in installed applications or on microSD
cards or other media.
Disaster kit
An application for using Disaster Message
Board, Disaster Voice Messaging Service and
→
Early Warning "Area Mail".
遠隔サポート
(Enkaku support)
An application for using "
(Anshin Enkaku Support)". "
ト
(Anshin Enkaku Support)" is a service that
P. 1 0 1
あんしん遠隔サポート
あんしん遠隔サポー
allows staff of the Call center to support the
terminal operations by remote-checking the
→
display of your own terminal.
P.202
My Magazine
A search service for displaying articles in the
→
category of your choice.
❖
Information
･
Some pre-installed applications can be uninstalled.
Even if uninstalled, some applications can be
downloaded from "Play Store" (P.105) etc. again.
･
Some applications require downloading and
installation. If downloading an application is not
available, set to allow to download (P.162).
P. 7 6
･
Activating two or more applications may increase
battery consumption and the operation time may
become short. For this reason, it is recommended to
end applications when not used. To end an
application, on the screen of application you are
x
using, tap
ru
to display the Home screen, or tap
[Close all].
Adding an application to the
Home screen
Add shortcuts of application to the Home
screen.
On the application screen, touch
1
and hold an icon you want to add
to the Home screen.
･
For the application icons in a folder,
drag out from the folder.
Drag it to "Add to Home screen"
2
displayed at the top of the screen.
･
When the Home screen is displayed,
drag it to a position to locate the
shortcut.
Before Using the Terminal
60
Uninstalling an application
･
Before uninstalling application, back up
contents related to the application that you
want to save including data saved in the
application.
･
Some applications may not be uninstalled.
On the application screen, flick
1
right the left edge of the screen
u
[Uninstall].
Tap an application icon with .
2
[Uninstall].
3
Adding a folder to the
application screen
When the order of application icons is set to
"Own order" in the option menu (P.56), you
can manage application icons on the
application screen by putting them in folders.
On the application screen, touch
1
and hold an icon
another icon.
u
Drag it over
❖
Information
･
To move an icon to a folder, on the application
screen, touch and hold an icon you want to move
Drag it over a folder.
･
To take out an application icon from a folder, tap the
u
folder
Touch and hold the application iconuDrag it
to a place you want to locate.
･
To change a folder name, tap a folderuTap the folder
u
name
Enter a folder nameuTap [Do ne].
Rearranging application icons
When the order of application icons is set to
"Own order" in the option menu (P.56), you
can rearrange application icons as you like.
On the application screen, touch
1
and hold an icon
position you like.
❖
Information
･
While sorting application icons, drag an icon to the
right edge of the application screen to add an
application screen.
･
Set "Alphabetical", "Most used", or "Installed" to
automatically rearrange the icons.
u
Drag it to any
u
Before Using the Terminal
61
Task manager
You can check the recently-used applications
and end them. You can activate a small app
(application displayed in a small window)
which can be used while using another
application.
Opening recently-used
application window
Display recently used applications in
thumbnail list and activate.
r
1
❖
･
･
･
･
.
Information
Tap a thumbnail of application to activate.
Flick left or right a thumbnail of application to delete
it from the list.
To end all applications and delete from thumbnail
list, tap [Close all].
To check application information, touch and hold a
thumbnail of application
u
Tap [App info].
Small apps
You can use a small app (application
displayed in a small window) such as Browser
while using another application.
Applications downloaded from Google Play
or widgets can be added to small apps.
Using small apps
r
1
.
･
The set small apps appear in the small
apps bar (Favorites) at the bottom of
the screen.
Select a small app to use.
2
❖
Information
･
When several small apps are set, flick the small apps
bar (Favorites) left or right to display them.
･
To close a running small app, tap .
Adding small apps
ru
1
･
Touch and hold a small app or
2
widget to adduDrag it to the small
apps bar (Favorites).
❖
Information
･
Alternatively, select an app/widget in the small app
list to activate a small app.
.
Small apps list appears.
Before Using the Terminal
62
･
In the small app list, tap u[Play Store]/[Widgets]
to install a new small app from Google Play or add a
widget to small apps.
･
To delete a small app from the small apps bar
(Favorites), touch and hold a small app to delete
Drag it to displayed out of the frame of the small
apps bar (Favorites)
･
To delete a widget or small app, in the small app list,
u
tap
u
Select a widget or small app to deleteu[OK].
app]
u
[OK].
[Delete widget]/[Uninstall small
Switching Home application
In the terminal, you can switch the Home
screen between "docomo" or "Xperia
From the Home screen,
1
u
[Settings]u[Personalization]
u
[Preferred apps settings].
[Set all to]/[Home screen].
2
･
When "Set all to" is selected, you can set
home application, lock screen,
phonebook application and application
for playing videos or music all at once.
[docomo]/[Xperia™].
3
[OK].
4
❖
Information
･
When the home application is switched, widgets or
shortcuts on the screen may not be displayed
correctly depending on home screen layout etc.
™
Searching information in
the terminal and web
u
pages
Enter a word in the search box to browse the
information in the terminal or on the
Internet.
From the Home screen, tap the
1
Google search widget.
Enter a search word.
2
･
Character entry (P.64)
･
The search candidate list appears.
".
Tap an item or of software
3
keyboard.
❖
Information
･
Alternatively, from the Home screen, uTap
[Google] to activate [Google] application.
･
In Step 1, the explanation screen for Google Now
may appear. Follow the onscreen instructions.
･
When applications appear in Step 2, select an
application to activate.
Before Using the Terminal
63
Using Google Voice Search
Enter a search word by voice.
From the Home screen, of the
1
Google Search widget.
Speak a search word to the
2
microphone.
❖
Information
･
Alternatively, from the Home screen, u[Voice
Search] to activate [Voice Search] application.
Search settings
You can set to use for search box or set search
objectives in the terminal.
From the Home screen, tap the
1
Google Search widget.
2
3
❖
･
at the lower left of the
uu
screen
[Settings].
Select an item.
Information
Alternatively, from the Home screen, uTap
[Google] to activate [Google] application.
Character entry
Enter characters using the software keyboard
which appears when you tap the character
input box in a mail, phonebook, etc.
❖
Information
･
When the software keyboard is displayed,
appears on the status bar.
･
To hide software k eyboard, tap displayed at the
lower left of the screen.
･
Touch and hold a text on the character entry screen
to display the enlarged text.
POBox Plus
Tips for Xperia
keyboard)
Character input method for the terminal is
set to"Xperia
default when the language is set to
(Japanese). Details on using Xperia
Japanese keyboard are explained in "POBox
使い方ガイド
Plus
Japanese keyboard)". (In Japanese only)
使い方ガイド
™
Japanese
™
Japanese keyboard" by
(Tips & Help for Xperia™
(Help &
日本語
™
Before Using the Terminal
64
On the character entry screen,
1
of the quick tool bar.
･
If the quick tool bar does not appear,
tap (for character mode of
"Alphabet" and "Numeric", tap /
to switch to "Kana", then
appears).
[Help & Tips].
2
Selecting input method
™
Japanese
u
™
Japanese
From the Home screen,
1
[Settings].
[Language & input]u[Default].
2
Tap any of [Xperia™ Chinese
3
keyboard]/[Xperia
keyboard]/[International
keyboard].
❖
Information
･
When the language is set to English, the default
input method is set to "International keyboard". To
use the Japanese keyboard, tap [Xperia
keyboard] in Step 3. In this manual, explanations are
given only for "Xperia
･
Alternatively, while entering characters, drag the
status bar downwards
to select input method.
™
Japanese keyboard".
u
Tap [Choose input method]
Software keyboard
For Xperia™ Japanese keyboard, the
following software keyboard can be used.
･
Character input method (P.66)
Keypad
QWERTY
❖
Information
･
Besides using software keyboard, handwriting input
and voice input are available for entering characters.
Keyboard with the same key
arrangement as a mobile phone.
Input methods available include
flick input as well as multi-tap
input—selecting a character by
repeatedly tapping a key.
Keyboard with characters allocated
in the same arrangement as general
PCs. Enter Japanese in Roman
character.
Before Using the Terminal
65
Switching software keyboard
or changing the settings
Display the tool list to switch between
software keyboard and handwriting/voice
input, use plug-in applications (extensions),
or change the settings.
On the character entry screen,
1
of the quick tool bar.
･
If the quick tool bar does not appear,
tap (for character mode of
"Alphabet" and "Numeric", tap /
to switch to "Kana", then
appears).
Keyboard
layout
Switch to
QWERTY/
Switch to
keypad
One-handed
keyboard
My Words
Settings
Keyboard skins
Help & Tips
Handwriting
docomo voice
input
Set software keyboard (Keypad or
QWERTY ) for each character mode.
Switch to QWERTY/keypad.
Change the keyboard size for onehanded operation.
P. 7 0
Change Xperia™ Japanese
keyboard settings.
Change software keyboard skin.
P. 6 4
Switch to handwriting input.
Switch to docomo voice input.
Google voice
typing
Download
Contact Picker
2.3
Switch to Google voice typing.
Download plug-in applications
(extensions) from website.
P. 6 9
Character input method
When you tap a key on the software
keyboard, candidates list for the entered
characters appears. Tap a word you want to
enter from the candidate list, text can be
input one after another.
a
b
c
d
e
Keypad
a
d
b
e
h
QWERTY
f
g
h
i
g
f
i
c
Before Using the Terminal
66
h
d
j
c
a
Quick tool bar
Display shortcuts of frequently-used functions. Tap
b
Handwriting input
to display the tool list (P.66).
f
i
g
Show/hide the quick tool bar.
Characters assigned to a key appear in reverse order.
/
Appears when entering numbers, tap to switch onebyte/two-byte character.
/ /
Appears in alphanumerics input mode, t ap to switch
lower case, capitalization and upper case.
c
Move the cursor to the left.
d
/
Show/hide list of symbols, facemarks, etc.
/ /
Appears before fixing character in Kana mode and
switches among
(conversion) candidate list/
katakana) conversion candidate list.
e
The character mode switches "Kana"
"Numeric" in order.
Display the tool list (P.66).
f
予測
(prediction) candidate list/変換
英数カナ
/ /
/ / Touch and hold
(alphanumeric/
→
"Alphabet"
Delete the character before the cursor.
g
Move the cursor to the right.
When there is an unfixed character string with the
cursor at the right end, tap to enter the same
character as the one at the end (Except for
Handwriting input).
h
Enter spaces.
In Kana mode, highlight and select word in the
candidate list.
i
Enter a line feed.
*
Appears before fixing character and fixes the
character.
* In some screens, , "
j
(Done)", "
実行
次へ
(Go)", etc. appear.
(Next)", "完了
Return to keypad/QWERTY.
❖
Information
･
To return to the display before conversion after the
conversion is fixed, tap displayed in
(associative) candidate (except in handwriting input
mode) etc.
･
To enlarge the display area, tap in the candidate
list. To display the software keyboard, tap or [
じる
(Close)].
･
For Handwriting input, tap an icon at the upper left
of entered character to display candidates for the
entered character. Recognized character is displayed
→
in light blue and characters are displayed at the
bottom of candidate list in different colors by type.
つながり予測
閉
Before Using the Terminal
67
･
For Handwriting input, the following operations are
available.
- When entering 2 or more characters and tapping
the icon at the upper left, appears. Tap to
combine entered 2 characters to 1 character.
- When entering characters, tap to delete
entered characters.
･
Note the following when you use Handwriting input.
- For voiced sound and semi voiced sound mark,
enter in the right upper part of the input screen.
- For punctuation mark and lower case, enter in the
lower part from the center of the input screen.
Character entry with keypad
■
Flick input
Flick up/down/left/right to enter characters
in each column of kana syllabary.
･
Ex: Entering characters in "な" column
You can enter "な" only by tapping. Flick
に
", up for "ぬ", right for "ね" and
left for "
down for "
の
".
■
Multi-tap input
Tap the same key continuously to enter the
assigned character.
To enter a character assigned to the same
key, wait for changing color of tapped key
to the original (approx. 1 second), then
enter the next character (for entering the
next character soon, tap to move the
cursor). With the key in the original color,
tap to enter the last entered character
again.
･
Ex: To enter "あお"
a
Tap "あ" onceuWait approximately 1
second (until the key color returns to
the original).
b
Tap "あ" 5 times.
or
a
Tap "あ" onceu(immediately) .
b
Tap "あ" 5 times.
Before Using the Terminal
68
Editing text
On the character entry screen, double-tap
character you want to edit so that text edit
menu appears at the top of the screen. Drag
or to change the character string to
select.
(Select all)
(Cut)
(Copy)
(Paste)
(Complete)
❖
Information
･
To paste a copied or cut character string, touch and
hold a position where you want to insert
[PASTE]. When text is already entered, tap a position
where you want to insert
･
Edit menu icons vary by applications.
･
In the landscape screen, editing menu may not be
displayed.
･
On some applications, the function may not be
available.
Select all text.
Cut a selected character string.
Copy a selected character string.
Paste a copied/cut character
string.
Close the edit menu.
u
Tap
uu
Tap [PAST E].
Quoting contacts
If contacts are registered to the Contacts, you
can use "Contact Picker 2.3" to enter contact
information when entering characters.
On the character entry screen,
1
of the quick tool bar.
･
If the quick tool bar does not appear,
tap (for character mode of
"Alphabet" and "Numeric", tap /
to switch to "Kana", then
appears).
[Contact Picker 2.3]uTap
2
"Contacts" tab.
Tap the contact to pick up.
3
Mark items you want to
4
❖
Information
･
"History" tab displays contacts that are picked up
when entering characters.
quote
u
[OK].
Before Using the Terminal
69
My Words
Register words to My Words beforehand to
display the words as the preferred candidates
when entering characters.
On the character entry screen,
1
of the quick tool bar.
･
If the quick tool bar does not appear,
tap (for character mode of
"Alphabet" and "Numeric", tap /
to switch to "Kana", then
appears).
[My Words].
2
3
Tap the character input box for
4
"Reading"
Tap the character input box for
5
"Word"
[OK].
6
❖
Information
･
To delete, in Step 3, mark words in My Words to
uu
delete
u
Fill it out.
u
Fill it out.
Tap [Delete].
Setting character entry
For each input method, you can make
settings related to character entry.
From the Home screen,
1
u
[Settings]u[Language &
input].
of "Xperia™ Chinese
2
keyboard"/"Xperia
"Google voice typing"/"MojiHenshu"/"Xperia
keyboard".
･
Tap an item displayed on the screen to
set.
❖
Information
･
The items vary depending on the input method.
･
Alternatively, while entering characters, drag the
status bar downwards
u
[Set up input methods]u for each input
method to display.
･
When entering characters with Xperia™ Japanese
keyboard, on the character entry screen, tap of
the quick tool bar
screen for Xperia
u
™
™
keyboard"/
™
Japanese
u
Tap [Choose input method]
[Settings] to display the settings
Japanese keyboard.
Before Using the Terminal
70
docomo LIVE UX
Home screen
Tapping y displays Home screen which
consists of up to 7 screens you can use
flicking left and right.
a
b
c
d
c
a
Widget : Google Search
b
Machi-chara
c
Application icon
d
Apps button
･
View the application screen (P.73).
e
Wallpaper
f
Current home screen position
･
Flick the Home screen left or right to switch.
g
My Magazine button
･
View My Magazine (P.76).
e
f
"ひつじのしつじくん®
(Butler Sheep)"
g
©NTT DOCOMO
Managing the Home screen
Adding/Moving applications
etc. to the Home screen
Move application icons or add widgets or
folders to the Home screen.
Touch and hold an area of the
1
Home screen where no icons are
displayed.
Any of [Show apps]/[Show
2
widgets]/[Create folder]/[MachiChara display setting].
･
To move/add applications or widgets,
touch and hold the icon
Home screen display area at the
bottom of the screen.
･
When you tap [Machi-Chara display
setting], make basic settings/Machichara setting.
❖
Information
･
To move applications into a folder, touch and hold an
u
icon
Drag it over a folder.
･
Tap a fold eruTap a folder name to changer the folder
name.
u
Drag it to the
docomo LIVE UX
71
Moving an icon on the Home
screen
From the Home screen, touch and
1
hold an icon you want to move.
Drag it anywhere.
2
･
To move to another Home screen, keep
touching the icon and drag it to left or
right.
Deleting an icon from the
Home screen
From the Home screen, touch and
1
hold an icon you want to delete.
Drag to "Back to apps list"/
2
"Remove from Home".
Uninstalling an application or widget
from the Home screen
･
Before uninstalling application, back up
contents related to the application or widget
that you want to save including data saved in
the application or widget.
･
Some applications or widgets may not be
uninstalled.
From the Home screen, touch and
1
hold an icon you want to uninstall.
Drag to "Uninstall"u[OK].
2
❖
Information
･
You can disable some applications or widgets which
cannot be uninstalled by dragging to "Disable app"
in Step 2 (P.159).
Changing Kisekae
Touch and hold an area of the
1
Home screen where no icons are
displayed.
[Change Kisekae].
2
Tap a Kisekae you want to
3
❖
Information
･
Alternatively, from the Home screen,
[Kisekae].
･
You can add Kisekae contents by tapping [Search on
the web] to download from website. To delete added
Kisekae contents, select a Kisekae to delete
u
[Delete].
change
u
[Set].
uu
u
[Delete]
Changing wallpaper
Touch and hold an area of the
1
Home screen where no icons are
displayed.
[Change wallpaper].
2
docomo LIVE UX
72
Tap a wallpaper you want to
3
change.
･
Tap [See more wallpapers] to select
from "Album", "Photos", "Live
Wallpapers", or "Xperia
[For all screens]/[Just for this
4
screen]
u
[OK].
™
wallpapers".
Application screen
From the Home screen, .
1
･
Flick the Home screen downwards to
display the application screen.
a
d
e
Adding a home screen
Touch and hold an area of the
1
Home screen where no icons are
displayed.
[Home screens].
2
3
･
To delete home screen, tap of the
home screen thumbnail you want to
delete.
･
To sort home screens, touch and hold a
home screen thumbnail you want to
u
Drag it to any position.
sort
❖
Information
･
Alternatively, pinch-in on the Home screen to display
the home screen list.
･
Up to 7 home screen can be set.
･
To return to the Home screen, tap y or x or
pinch-out.
b
f
c
a
Apps/Widgets/Wallpapers tab
･
Display application icons/widgets/wallpaper list.
b
Application icon list
･
Applications on the Home screen are not
displayed in the list.
c
Home screen display area
･
Flick left or right to switch.
d
Option menu
･
View optional menu such as Settings.
e
Recommends button
･
Install applications recommended by DOCOMO
(P.74).
f
Current position in the list screen
･
Display by application icon/widget list.
❖
Information
･
To close the application screen, tap x or y, or
flick up the Home screen display area at the bottom
of the screen.
docomo LIVE UX
73
Customizing the application
screen
Moving/Adding an application or
widget to the Home screen
On the application screen, touch
1
and hold an icon you want to add
to the Home screen.
Drag it to the Home screen display
2
area at the bottom of the screen.
Uninstalling an application or widget
Some application icons and widgets can be
deleted from the application screen.
･
Before uninstalling an application or widget,
see "Uninstalling an application or widget
from the Home screen" (P.72).
On the application screen, touch
1
and hold an icon of application
you want to uninstall.
Drag to "Uninstall"u[OK].
2
❖
Information
･
You can disable some applications or widgets which
cannot be uninstalled by dragging to "Disable app"
in Step 2 (P.159).
Moving application in the
application icon list
On the application screen, touch
1
and hold an icon to move.
Drag it anywhere.
2
Installing "Recommends"
applications
Install applications recommended by
DOCOMO.
On the application screen,
1
[Recommends].
おすすめアプリを見る
[
2
recommended apps)].
Select an application to use.
3
･
Download screen appears. Follow the
onscreen instructions.
(See
docomo LIVE UX
74
Backing up and restoring the Home screen
You can use docomo LIVE UX data backed up
on the docomo cloud to restore the layout of
applications, widgets, and other items on the
Home screen. Once it is restored, a page for
docomo services is added to the bottom of
the Home screen.
･
To use the backup and restore features, you
need to set up your "docomo ID" (P.160).
Backing up the Home screen
On the Home screen,
1
uu
Restore].
･
2
[Layout backup and
For the first activation, confirm the
Application Privacy Policy, Precautions,
and Software License Agreement, then
tap [Agree].
u
[Backup]
Restoring the Home screen
On the Home screen,
1
uu
Restore].
[Restore the latest backed up
2
data]/[Restore from backup data
list].
･
[Restore].
3
[Layout backup and
If you selected [Restore from backup
data list], select the data you want to
u
Tap [Re store].
restore
docomo LIVE UX
75
Backup settings
On the Home screen,
1
uu
[Layout backup and
Restore].
2
Backup
automatically
Multi-Device
Sync
Sync on Wi-Fi
only
Sync while
Roaming
Delete backup
data
Open source
licenses
Ter ms of use
Help
About
Set whether to periodically back up
the home screen information for
the docomo LIVE UX.
Set whether to send a notification
to your other devices when an
application has been installed.
Set whether to back up or sync
data only when the terminal is
connected via Wi-Fi.
Set whether to back up or sync
data during international roaming.
Delete your backup information
from the server.
View open source licenses.
View the terms of use.
View the operation guide.
View the application's version and
other information.
Using My Magazine
My Magazine is a search service for
displaying articles for categories you
selected. It helps to set search words
depending on your tendency of read articles
or profile information to come close to your
preference.
From the Home screen, .
1
･
When you activate for the first time,
select categories on the selection
screen for categories then tap [OK].
･
Flick the article list screen left or right to
switch categories.
･
Tap [See more info] to show other
articles in the category.
Tap an article you want to read.
2
❖
Information
･
Alternatively, flick the Home screen up to display the
article list.
Setting a category
From the Home screen,
1
uu
setting].
Mark the category you want to
2
display
[Display category
u
[OK].
docomo LIVE UX
76
Changing My Magazine use
setting
From the Home screen,
1
uu
u
[Use]/[Not use]u[OK].
2
❖
Information
･
You can also set by tapping on the application
screen
[My Magazine settings]
[My Magazine use setting].
u
[My Magazine use setting].
Checking Home application information
On the application screen,
1
u
[About].
docomo LIVE UX
77
Phone
Making/Receiving a call
Making a call/video call
From the Home screen, u"Dial"
1
tab.
Enter a phone numberu.
2
･
To make a video call, enter a phone
uu
number
･
Tap to delete the number.
When the call is finished, tap [End
3
call].
･
To end a video call, tap the screenuTap
[End call].
❖
Information
･
In Step 2, tap without entering a phone number
to enter the phone number registered as the latest
call in Recent calls.
･
To a cti vate X per ia™ phone application, from the
Home screen, tap
･
You can display contact, create message (SMS), or
make call again from the call end screen.
Tap [Video cal l].
u
[Dial].
･
With VoLTE, you can make high-quality voice and
video calls. You can also switch between voice and
video calls.
To use VoLTE, both parties must meet the following
requirements.
- Both terminals support VoLTE.
- Both parties are in a Xi service area. (VoLTE is not
available outside a Xi service area or during
international roaming.)
- "Network mode" in "Mobile networks" is set to
"LTE(preferred)/3G/GSM" or "LTE/3G" (P.188), and
"Network mode" is set to "VoLTE/3G" (P.88).
･
On a video call, both speakers can see each other
while talking.
- When you make a video call, voice call and packet
communication charges will apply. When you
receive a video call, packet communication
charges will apply.
- Video calls are based on best-effort
communication (which optimizes transmission
speed depending on how busy your network is),
so the quality of video images varies depending on
your network environment.
- If your terminal failed to switch to a video call
during a voice call, a massage appears on the
screen indicating that the failure occurred, and the
voice call is maintained.
- Since imaging for video call varies by terminal
model, your terminal and the other party's
terminal may show different image in scope.
Phone
78
Emergency call
Emergency call Phone
Police call
Fire and emergency rescue
Coast guard
❖
Note
･
This terminal supports "Emergency call location
information". If you use the terminal to place a call to
emergency numbers such as 110, 119, or 118, the
information of a location where you are calling from
(location information) is automatically notified to the
Emergency call acceptance organization such as the
Police Station.
The Emergency call acceptance organ ization may not
be able to figure out your exact location depending
on the location where you place a call or radio wave
condition.
If you make a call hiding your caller ID, such as by
entering a phone number with "184" for each call, the
location information and phone number are not
notified. However, the Emergency call acceptance
organization may decide to obtain the location
information and phone number regardless of your
settings when they consider it is necessary for
lifesaving, etc. Note that the areas/time for which the
"Emergency call location information" is ready to be
used vary depending on the preparatory state of each
Emergency call acceptance organization.
number
110
119
118
･
When calling 110, 119 or 118 for emergency from the
terminal, tell that you are calling from a mobile
phone, and give your phone number and your
current location precisely for checking callback from
the police/fire department. Also, make a point to call
in a stationary position to prevent the call from being
dropped. Do not power off the terminal for at least
10 minutes after the emergency call just in case the
Police or Fire/Ambulance may have to get in contact
with you.
･
Note that you may not connect to the local Fire
Department or Police Station depending on where
you are calling from.
❖
Information
･
If docomo nano UIM card is not inserted to the
terminal, emergency calls (110, 119, 118) cannot be
made in Japan.
･
You ca n mak e an e merg en cy cal l by t appi ng
[Emergency call] on the lock screen. In Japan,
however, on the PIN code entry screen, while PIN
code locked or while PUK locked, emergency calls
(110, 119, 118) cannot be made.
･
If you call to emergency numbers with Call Blocking
is ON, the setting turns off automatically.
･
Emergency call may not be available via some
networks.
･
The video call feature does not support emergency
calls to 110, 119, and 118.
Phone
79
Entering pause (,)/(;) to send
For using services requiring entry of number
during a call such as check of the balance of a
bank account, reservation of tickets, etc.,
enter an additional number to a phone
number beforehand and make a call.
■
Using 2-second pause (,)
Added number will automatically be sent
approximately 2 seconds after the call is
made.
From the Home screen, u"Dial"
1
tab.
Enter a phone number
2
2–sec pause]
number
When the call is finished, [End call].
3
■
Using a wait (;)
Sending is automatically on standby when
the call is made and a confirmation screen
asking if you send the additional number
appears.
From the Home screen, u"Dial"
1
tab.
Enter a phone number
2
wait]
u
On a confirmation screen, [Yes].
3
u
u
.
u
Enter an additional number
.
uu
[Add
Enter an additional
uu
[Add
When the call is finished, [End call].
4
Making an international call (WORLD
CALL)
For details on WORLD CALL, refer to
DOCOMO International Services website.
･
Send replacing "+" by an international access
code.
From the Home screen, u"Dial"
1
tab.
Dial + (touch and hold [0])uEnter
2
Country code, Area code (City
code), recipient number in the
u
order
･
When "Auto conversion" in
International dial assist is marked
(P.192), the international dial assist
screen appears when sending. Tap [Call
original] or [Call].
When the call is finished, [End call].
3
❖
Information
･
If the area code begins with "0", omit "0". However, "0"
may be required to dial to some countries or areas
such as Italy.
.
Phone
80
Receiving a phone/video call
･
Even when the screen is locked, you can still
operate the terminal to respond to an
incoming call.
While receiving a call, drag
1
(left) to (right).
･
To accept a video call, drag (left) to
(right). To answer a call with voice
only, drag (left) for "Voice only" to
(right).
When the call is finished, [End call].
2
･
To end a video call, tap the screenuTap
[End call].
Putting a call on hold
If you are not available to answer a call, you
can put the call on hold.
Drag upwards when
1
receiving a voice call.
[Put caller on hold]
2
The other party will hear a message
saying that the call is on hold.
When you are ready to answer the
3
call, drag (left) to (right).
･
The call will be put on hold until you
drag (right) to (left) or the other
party ends the call.
Answering an incoming call with
Answering Machine
Even when Answering Machine is not set, you
can activate Answering Machine manually.
Drag upwards when
1
receiving a voice call.
[Reject with Answering Machine].
2
❖
Information
･
If there is a recorded message, is displayed in the
status bar. Drag the status bar downwards
[Answering Machine] to display the Messages screen,
where you can check the recorded message.
u
Tap
Muting the ringtone for an incoming
call
While receiving a call, press the
1
volume key or
❖
Information
･
You can stop vibration by pressing the volume key or
P
when silent mode (vibration) is set.
･
On the Home screen etc., press the volume key to
adjust the ringtone volume.
P
.
Declining a call
While receiving a call, drag
1
(right) to (left).
Phone
81
Rejecting an incoming call and
sending a message (SMS)
When you cannot answer a call, you can
reject the call and send a message (SMS).
Message to send is registered in advance, and
you can edit it if necessary.
Drag upwards when
1
receiving a voice call.
･
If it is a video call, drag
upwards and proceed to Step 3.
[Reject with message].
2
Tap a message to send.
3
･
Tap [Write new message] to create and
send a message.
❖
Information
･
To edit existing message, from the Home screen, tap
uu
[Call settings]u[Reject call with
u
message]
Select an existing message and edit
u
[OK] in advance.
it
Operations during a call
On the Calling screen, you can set
speakerphone or mute, or enter a phone
number to make a call to another party.
■
Screen displayed during a voice call
a b
c
d
e
f
g
h
i
j
k
l
Phone
82
■
Screen displayed during a video call
While on a video call, you will see the other
party's image in a parent window, and your
image in a child window, with the operation
area hidden. Tap the screen to show the
operation area.
a b
c
d
f
h
a
Name of the other party
b
Number of the other party
c
High-quality call
･
Displayed during a VoLTE call.
･
Displayed during both outgoing and incoming
VoLTE calls.
d
Call duration time
e
Photo/image set in the phonebook entry
f
Speaker : Set speakerphone on/off.
･
Other party's voice can be heard from the speaker
and handsfree call can be made.
･
Video calls are made or received with the
speakerphone turned on.
g
Dial key : Send a push signal while on a call.
h
Mute : Turn the microphone on/off during a call.
m
n
o
p
g
l
i
Switching to video call : Switch from a voice call to a
video call.
･
When you tap this icon, the other party will see a
message asking for permission to switch to a
video call. If the other party accepts it, you can
switch to a video call.
･
If the other party has declined to switch to a
video call, is outside a Xi service area, or is using a
terminal that does not support VoLTE, a message
appears indicating that the call cannot be
switched. Tap [OK] to continue the voice call.
j
Hold : Put a call on hold/cancel hold.
k
Phonebook : View the dial screen while on a voice
call.
･
You can add a voice call by entering a phone
number or selecting a phone number from your
call log or phonebook and then making a call.
･
To add a call, "Call waiting" subscription is
required (P.87).
l
End a call
･
Tap when in landscape view.
m
Option menu : Switch from a video call to a voice
call.
･ u
Tap [Change to voice] to switch to a voice
call. Tap when in landscape view.
n
Parent window for a video call (other party's image)
･
When the other party's image is not received,
is displayed.
o
Child window for a video call (your image)
p
Switching between cameras for sending your
･
Tap this icon to switch between cameras for
shooting your image.
❖
Note
･
Do not bring the terminal close to your ear with the
speakerphone on to avoid from hearing damage.
Phone
83
❖
Information
･
If you switch to a different screen, such as the Home
screen, while talking on the phone, making a call, or
putting a call on hold, the status bar will change
color. Drag the status bar downwards and then tap
the notification to return to the phone application
screen.
･
Switching to a different screen, such as the Home
screen, while on a video call, turns the camera off.
Adjusting the earpiece volume
Press the volume key during a call.
1
Call history
Incoming call and outgoing call are displayed
by chronological order in the Recent calls
screen. Up to 500 items can be displayed.
Showing call history
From the Home screen, uTap
1
"Recent calls" tab.
■
Recent calls screen
a
b
c
a
Phonebook
･
The phonebook list screen appears.
b
All tab
c
Phone number/name
d
Incoming tab
e
Outgoing tab
f
Voice call button
･
Tap this button to make a voice call to the
corresponding phone number in the call log.
g
Date
d
e
f
g
h
Phone
84
h
History
･
The details of an incoming or outgoing call
(Outgoing, Incoming, or Missed call) are
displayed.
Adding a number from the Recent
calls to Phonebook
From the Home screen, uTap
1
"Recent calls" tab
u
number
･
Alternatively, on the Recent calls screen,
touch and hold a phone number
number before call]
[Add new contact]/[Add to the
2
existing contact].
･
When “Add to the existing contact” is
selected, select a contact to save to.
On the profile edit screen, enter
3
necessary information such as
name.
･
To add items, tap [Add other items].
[Save].
4
u
[Register].
u
Tap a phone
u
[Register].
Deleting a call history
From the Home screen,
1
u
"Recent calls" tabuTouch and
hold an incoming/outgoing
history you want to delete.
[Delete from call log]u[OK].
2
❖
Information
･
To delete all the entries in the call log, on the Recent
calls screen, tap the "All" tab
Mark "Select all"u[Delete]uTap [Delete].
[Edit
･
Voice and video calls are not distinguished in the call
log.
uu
Displaying missed calls
When you have missed calls, appears in
the status bar.
Drag the status bar downwards.
1
[Missed call].
2
❖
Information
･
When there is a missed call, you can make a call or
send message (SMS) to the caller of the missed call
from "Call back"/"Message" below "Missed call" in the
Notification panel.
For multiple missed calls, number of calls appears
below "Missed call".
･
When the lock screen application is set to "docomo"
and the unlock method is set to "Swipe/Touch", an
icon indicating missed calls and the number appears
on the lock screen.
[Delete log]
u
Phone
85
Answering Machine
When Answering Machine is set, the
answering message is played when you
cannot answer an incoming call and message
from the caller can be recorded even if you
are not subscriber of Voice Mail Service. Up to
approximately 60 seconds per one can be
recorded.
･
Answering Machine is not available for video
calls.
From the Home screen,
1
[Call settings]u[Answering
2
Machine].
Answering
Machine
Pick up after
Use while
roaming
Greetings
Messages
Set whether to use Answering
Machine.
Set a ringing time for answering.
Set whether to use Answering
Machine when you stay abroad.
Switch the answering message
language to Japanese or English or
record a message.
To record message, tap [Record
new greeting] and follow the
onscreen instructions.
Check recorded messages.
u
.
❖
Information
･
If there is a recorded message, is displayed in the
status bar. Drag the status bar downwards
[Answering Machine] to display the Messages screen,
where you can check the recorded message.
･
To delete recorded message, touch and hold a
u
Tap [Delete]/[Delete all]u[OK].
message
u
Tap
Phone
86
Call settings
You can set the network services, register call
rejection or edit Reject call with message.
From the Home screen,
1
[Call settings].
2
Network
Koe-noTakuhaibin
Voice mail
*1
service
Call
forwarding
*1
service
Call
*1
Waiting
Caller ID
notification
Nuisance
call blocking
service
*1
service
Record voice messages for
you.
Record caller's message
when you cannot answer an
incoming call.
Forward a call when you
cannot answer an incoming
call.
Put the current call on hold
and answering an incoming
call or making a call to
another party.
Notify the display of the
recipient phone of your
phone number.
Register phone numbers of
nuisance call to reject.
u
.
Network
Caller ID
service
display
request
service
Second call
settings
Call
notification
English
guidance
Remote
operation
settings
Public mode
(power OFF)
setting
Roaming settings
Phone ringtone
Request number notification
for calls without phone
number with guidance.
Notify you when a call
*1
comes in during another
call.
Notify incoming calls by
message (SMS) while the
power is off or you are out of
service area.
Switch the voice guidance
to English or Japanese.
Set to operate Voice Mail
Service or Call forwarding
Service using land-line
phone, public phone or
DOCOMO mobile phone,
etc.
While the terminal is OFF or
in Airplane mode, a
guidance message
indicating that the receiver
cannot answer the call is
heard on the caller's
terminal and then the call
ends.
Set to reject incoming calls
overseas or use roaming
guidance (P.192).
Set ringtone (P.156).
Phone
87
Vibrate when ringing
Dial pad touch tones
Answering Machine
Call Blocking
Reject call with
message
Sub address settings
Prefix settings
Microphone noise
suppression
Equalizer
Speaker voice
enhancement
Slow talk
Network mode
Set whether to sound
ringtone and vibrate the
terminal when there is an
incoming call.
Set whether to emit dialpad
operation sound.
P. 8 6
Set whether to reject
incoming calls for numbers
not in the phonebook,
private, pay phone and
unknown.
Edit/set a message (SMS) to
be sent when rejecting an
incoming call (P.82).
Set whether " " in phone
number is identified as a sub
address separator.
Register a prefix number
added before phone
number when making a call.
Make the voice clear to
understand for the other
party during a call.
Adjust sound quality during
a call.
Make a voice clear to
understand during a call.
Slow the caller’s talking
speed to make the call to be
heard slowly.
Set the network mode for
VoLTE call service.
Contact docomo
Accounts
Use Internet calling
*1 Not available for video calls.
*2 Not displayed if a docomo nano UIM card is not
inserted.
*2
Make a call to General
Inquiries, inquiries for
damage, theft or loss
overseas or damage
overseas.
Set Internet phone (SIP)
account.
Set Internet phone (SIP) call
method.
Phonebook
On the phonebook, you can enter various
information for contacts, for example, phone
numbers, mail addresses and various service
accounts.
Displaying phonebook
From the Home screen,
1
[docomo phonebook]u"Contacts"
tab.
･
The phonebook list screen appears.
u
Phone
88
❖
Information
･
To use cloud service for the phonebook, "docomo
phonebook" application is needed. When you use
the "docomo phonebook" for the first time
(including after resetting the application) or log in to
cloud from the "docomo phonebook", the "Use of
Cloud" screen appears and you can start using cloud.
･
From the Home screen, uTap [Phonebook] to
display the phonebook list.
･
Phonebook data can be backed up to/restored from
a microSD card using "docomo backup" application
(P.142).
･
From the Home screen, uTap [Con ta cts] to
activate Xperia
■
Phonebook list screen
™
phonebook.
On the phonebook list screen, you can view
details of your contacts. You can add a
photo or image to a phonebook entry, and
display phonebook entries by group.
a
b c
d
e
f
g
h
i
a
Group tab
･
Display the phonebook group.
j
k
l
b
Timeline
･
Display tweet or message on SNS/blog. To
display, log in to Cloud and set "My SNS" function.
c
Cloud
･
Log in to cloud ("Use of Cloud" screen is
displayed) or log out of cloud ("Suspend sync"
screen is displayed).
d
Option menu
e
Contacts tab
f
Photo/image set in the phonebook entry
･
Tap a photo/image to make a call/video call or
send a message (SMS) or mail.
g
Name registered in the phonebook entry
h
Search
i
Register
j
My profile tab
･
Check your own phone number.
k
Index character area
･
Tap index character to display phonebook entries
allocated to the index character.
l
Index
･
Display the index character to search entries in
the order of Japanese syllabary, alphabet, etc.
Managing phonebook
Adding a new phonebook entry
From the Home screen,
1
[docomo phonebook]u"Contacts"
u
tab
[Register].
On the profile edit screen, enter
2
necessary information such as
name.
･
To add items, tap [Add other items].
u
Phone
89
[Save].
3
❖
Information
･
When the language is set to Japanese, if you saved
phonebook entries with the "Phonetic name (last/
first)" field filled in, the phonebook list screen shows
them in Japanese syllabary order or alphabetical
order of the "Phonetic name" entries. If you did not
fill in the "Phonetic name" field, the entr y is displayed
in the "他 (Others)" section on the phonebook list
screen only when you entered the last and first
names in Kanji using Japanese "Kana" characters.
･
If docomo account is selected as saving location
when registering phonebook entries, SNS/blog
accounts can be set.
Making a call using the phonebook
From the Home screen,
1
[docomo phonebook]u"Contacts"
u
Select a phonebook entry
tab
you want to make a call to.
On the Profile screen, tap a phone
2
number.
[Call]/[Video call].
3
u
Editing a phonebook entry
From the Home screen,
1
[docomo phonebook]u"Contacts"
tabuSelect a phonebook entry to
edit.
On the Profile screen, [Edit].
2
u
Select a required item and edit.
3
[Save].
4
❖
Information
･
You cannot edit contacts for the Facebook account.
Registering a phonebook entry to
Favorites
From the Home screen,
1
[docomo phonebook]u"Contacts"
u
tab
Select a phonebook entry to
add to Favorites.
On the Profile screen, tap .
2
❖
Information
･
To display phonebook entries added to Favorites, on
the phonebook list screen, tap "Group"
u
tab
[Favorites].
u
Using optional menu
From the Home screen,
1
[docomo phonebook]u"Contacts"
tabuPhonebook list screen/Profile
u
screen
■
Phonebook list screen
Delete
Cloud menu
Import/Export
.
Select and delete
several/all phonebook
entries.
Display cloud menu.
P. 9 2
u
Phone
90
Settings International use
setting for
docomo
phonebook
docomo ID/Wi-Fi
settings
Contacts display
order
Accounts to
display
Help
About
■
Profile screen
Share
Delete
Set ringtone
Join/Separate
SNS/contacts link
settings
Send a displayed phonebook
entry with Bluetooth function,
Email, etc.
Delete a displayed phonebook
entry.
Set a ringtone for displayed
phonebook entry.
Join/separate displayed
phonebook entry.
When My SNS is set, link a
displayed phonebook entry
with friends on SNS.
Set for using docomo
phonebook overseas.
Set for using docomo
services via Wi-Fi.
Set display order of
phonebook entries.
Set a phonebook to be
displayed in the
phonebook list screen.
Display Help of docomo
phonebook.
Display version etc. of
docomo phonebook.
Setting phonebook entries to Group
From the Home screen,
1
u
[docomo phonebook]
u
"Group" tab.
Tap a gr oup.
2
[Add member]uMark phonebook
3
entries to add
❖
Information
･
To cancel group setting, in Step 3, [Delete member]
u
Mark phonebook entries to deleteu[OK]u[OK].
･
When you set Google account etc., display groups by
account. You can set/cancel group in the same
account.
u
[OK]u[OK].
Creating a new group in the
phonebook
From the Home screen,
1
u
[docomo phonebook]
"Group" tab.
[Add group].
2
On the group adding screen, enter
3
account, group name, icon,
u
color
[OK].
･
The items vary depending on the
account type.
u
Phone
91
❖
Information
･
Groups in docomo account can be sorted. In Step 2,
tap [Sort] and follow the onscreen instructions.
･
Groups in docomo account can be edited/deleted.
To edit/delete a group, touch and hold a group
[Edit group]/[Delete group].
Checking My profile and editing
information
From the Home screen,
1
[docomo phonebook]u"My
profile" tab
On the My profile screen, enter
2
necessary information such as
u
[Edit].
name.
[Save].
3
u
Importing/Exporting
phonebook entries
You can export/import phonebook entries
u
from/to a microSD card or docomo nano UIM
card. This is useful, for example, when you
want to move the contact information to
another phone.
･
You can also use a synchronization service for
synchronizing your phonebook (P.169).
･
Insert a microSD card in advance (P.173).
From the Home screen,
1
[docomo phonebook]u"Contacts"
uu
tab
Select an item.
2
･
･
❖
Information
･
To export phonebook entries to docomo nano UIM
card, use "Contacts" app of Xperia
name and the first phone number can be saved
because of memory space of docomo nano UIM
card. For some phonebook entries, a part of data may
not be exported.
[Import/Export].
After this step, follow the onscreen
instructions.
When [Share phonebook data] is
tapped, select an application to send.
u
™
. Note that only
Phone
92
Mail/Web browser
docomo mail Message (SMS)
Send/receive mails using DOCOMO mail
address (@docomo.ne.jp).
Pictograms and Deco-mail can be used, and
automatic reception also is supported.
Sent/received mails are stored to the docomo
mail server. Mails can be transferred readily in
case the terminal is lost or you change the
model. Also, with a docomo ID, you can use
mail on your PC, tablet, and other devices.
For details of docomo mail, refer to NTT
DOCOMO website.
From the Home screen, .
1
･
After this step, follow the onscreen
instructions.
❖
Information
･
docomo mail (local mail) data can be backed up in a
microSD card using "docomo backup" application
(P.142).
You can send/receive text message to/from a
mobile phone number as a recipient.
For details of available number of characters
etc., refer to "Short Message Service (SMS)"
on NTT DOCOMO website.
Sending message (SMS)
From the Home screen,
1
u
[Messaging].
(Compose).
2
Enter the recipient's phone
3
number.
･
Tap u[Edit recipients] to select from
registered contacts. Enter in the search
box at the top of the screen to display
the contact list.
[Write message]uEnter a message.
4
･
Tap u[Select message template] to
enter by selecting message template
(P.95).
･
When the number of entered
characters comes close to a limit, a
number of enterable characters
appears on the right of the text box.
[Send].
5
Mail/Web browser
93
❖
Information
･
You can change default messaging application to
Hangouts.
From the Home screen,
[Default SMS app]u[Hangouts].
･
You can also send/receive text messages to/from
customers of overseas network operators. For details,
see "Mobile Phone User's Guide [International
Services]" or the DOCOMO International Services
website.
･
To send SMS to users of overseas network operators,
enter "+", "Country code" and then "the recipient
mobile phone number". Enter the phone number
without a leading "0", if any. Alternatively, enter "010",
"Country code" then "the recipient mobile phone
number" in order.
To reply to the received message (SMS) overseas, you
need to create a new message (SMS). To send a
message, in Step 3, enter "010", "Country code" then
"the recipient mobile phone number" in order.
u
[Settings]u[More...]
Reading message (SMS)
Sent/received message (SMS) is displayed in
thread by recipient/sender.
From the Home screen,
1
u
[Messaging].
･
Senders with unread messages (SMS)
are displayed in bold font.
Select a sender whose messages
2
(SMS) you want to read.
❖
Information
･
When you receive a message (SMS), appears on
the status bar. Drag the status bar downwards to
u
read the received message (SMS).
･
Tap at a bottom of message (SMS) field to add
star. To check starred messages (SMS) in a list,
from the Home screen, tap
u
[Starred messages].
u
Saving phone number of
message (SMS) to phonebook
From the Home screen,
1
u
[Messaging].
Tap of a phone number to
2
3
4
❖
･
u
[Save].
save
[Add new contact]/[Add to the
existing contact].
･
If you selected "Add to the existing
contact", select the contact.
On the profile edit screen, enter
necessary information such as
u
name
[Save].
Information
For a sender registered to the phonebook, tap or
photo (image) in Step 2 to make a call or display the
phonebook entry.
[Messaging]
u
Mail/Web browser
94
Deleting a message (SMS)
From the Home screen,
1
u
[Messaging].
Tap a sender/recipient whose
2
messages (SMS) to delete.
Touch and hold a message (SMS) to
3
delete.
[Delete message]u[Delete].
4
❖
Information
･
To delete several messages (SMS), in Step 3,
u
[Delete messages]uMark messages (SMS) you
uu
want to delete
[Delete].
Deleting messages (SMS) by
sender/recipient
From the Home screen,
1
u
[Messaging].
Touch and hold a sender/recipient
2
you want to delete.
u
3
❖
･
[Delete].
Information
To delete messages (SMS) from several senders and
recipients, in Step 3, mark senders/recipients to
uu
delete
[Delete].
Changing settings for
Messaging (SMS)
From the Home screen,
1
u
[Messaging].
u
2
Notification
tone
Notifications
Notification
vibration
Notification
light
Delivery report
Message
templates
SIM messages
Push settings
Geotag
SMS center
number
* While the silent mode (mute) is set, t he terminal does
[Settings].
Set notification tone for receiving.
Set whether to show message (SMS)
arrival notification in the status bar.
Set whether to notify with vibration
*
when receiving.
Set whether to notify with the
notification LED for receiving when
the backlight is turned off.
Set whether to mark a message
(SMS) you sent when the recipient
receives.
Register/edit phrase to be inserted
when entering message.
Manage messages (SMS) saved to a
docomo nano UIM card.
Set a message (SMS) sent from the
provider.
Set whether to include a geotag
when sending geotagged media.
Check SMS center number.
not vibrate when receiving a message (SMS).
Mail/Web browser
95
You can create a POP3 or IMAP compatible
email account provided by general ISP
(provider), or an Exchange ActiveSync
account to send or receive email.
You can set multiple Email accounts.
Making initial setting for Email
Set an Email account following the onscreen
instructions.
From the Home screen,
1
u
[Email].
･
To set a second or subsequent email
account, from the Home screen,
u
uu
[Email]
account].
Enter your email address and
2
password.
[Next].
3
･
To set up an email account manually,
tap [Manual setup] and follow the
onscreen instructions.
[Settings]uTap [Add
Set check frequencyuMark
4
required items
･
If a screen for selecting type of account
appears, tap an email account type and
follow the onscreen instructions to set.
Enter account name and name
5
displayed on emails you send
u
[Next].
[Next].
･
Inbox for set email account appears.
❖
Information
･
If you need to make the settings manually, contact
your email service provider or system administrator
for the correct email account settings.
･
If you set an Exchange ActiveSync account as an
email account, and if server manager sets Remote
wipe, the data saved in the terminal may be deleted.
u
Mail/Web browser
96
Creating and sending email Receiving and reading email
From the Home screen,
1
u
[Email].
(Compose).
2
Enter the email address of
3
recipient.
･
Tap to select from the registered
contacts. Enter in the search box at the
top of the screen to display the contact
list.
･
To enter multiple email addresses
directly, separate with a comma (,) and
then enter the next email address.
･
To add Cc or Bcc recipients, tap
u
[Show Cc/Bcc].
Enter a subject and message.
4
[Send].
5
❖
Information
･
To attach a file, while creating an email, tap and
select a file.
･
To save an email as draft, when creating an email, tap
u
[Save as draft] or display other screen.
･
Email is handled as an email from a PC. Your email
cannot be received if rejecting emails from PCs is set
on a recipient terminal.
From the Home screen,
1
u
[Email].
･
If you have set up more than one email
account, [Inbox]
u
Tap the email
account you want to use for incoming
emails.
On the Inbox, flick the screen.
2
Tap an email you want to read.
3
❖
Information
･
The sender name of a received email is the name set
on sender's terminal.
･
If you specified "Notification" in the email account
settings (P.99) and set "Check frequency" to an option
other than "Manual", appears in the status bar to
notify you when you have received a new email.
Drag the status bar downwards to read the received
email.
･
Tap an address of received email to register the
address to the phonebook. For addresses already
registered, displaying phonebook entries, creating
mail, etc. are available.
･
In the Inbox or the email message screen, tap to
add star and the email is added to "Starred"
folder. To see a list of starred emails, in the Inbox,
u
[Inbox]
Tap the desired email accountu[Inbox]
Tap [Starred].
u
Mail/Web browser
97
Setting preview of Inbox
From the Home screen,
1
u
[Email].
u
2
3
4
❖
･
･
[Settings]u[Sprit view].
Mark a screen to preview.
[OK].
Information
If you have two or more accounts, change made in
any of the accounts applies to all accounts.
To switch to the landscape view, turn Auto rotate
screen on beforehand (P.43).
Saving attachment file of email
From the Home screen,
1
u
[Email].
Tap an email with attached files.
2
･
When attached file is not loaded, tap
[Load].
Tap [Save] of file you want to save.
3
･
The attached file is saved on the
internal storage.
Replying/Forwarding email
From the Home screen,
1
u
[Email].
Tap an email to reply or forward
2
Tap [Reply]/[Reply all]/[Forward].
･
When you tap [Forward], enter an email
address to forward to.
Enter a message.
3
[Send].
4
❖
Information
･
To quote original message text, tap [Respond inline].
･
When you forward an email, the attachment file of
the original message is attached. To delete attached
file, tap .
Deleting email
From the Home screen,
1
u
[Email].
Tap an email to delete.
2
u
3
❖
･
[Delete].
Information
To delete more than one email, in Step 2, touch and
hold the emails you want to delete
u
Tap [Delete].
u
Mark them
u
u
Mail/Web browser
98
Loading...
