Sony SO-01G User Guide
INSTRUCTION MANUAL
14.10
Introduction
Thank you for your purchase of "SO-01G".
For proper use of the SO-01G, read this manual
carefully before and while you use the SO-01G.
About manuals of SO-01G
In addition to this manual, the operations of SO-01G
are described in "
Guide)" (in Japanese only) and "Instruction Manual"
application of the terminal (in Japanese only).
●"クイックスタートガイド
(Supplied accessories)
The initial operations and settings after purchasing
the terminal, screen view contents and operations of
main function are explained.
●
"Instruction Manual" (Application of the terminal)
Operations and settings of each function are
explained. To use "Instruction Manual" application,
from the Home screen,
When using for the first time, download and install
the application according to the onscreen
instructions. If you uninstall "Instruction Manual"
application, access to Google Play from Play Store to
download it again. From the Home screen, tap [Play
Store], search "
application to select, then install it following the
onscreen instructions. You can use the application as
an electronic book. You can also shift to actual
operations by tapping the description in the contents
or view reference contents.
クイックスタートガイド
(Quick Start Guide)"
u
[Instruction Manual].
取扱説明書
(Instruction Manual)"
(Quick Start
●
"Instruction Manual" (PDF file)
Operations and settings of each function are
exp lain ed. It can b e down load ed fro m NTT DOCOM O
website.
https://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
* You can download the latest information of "
イックスタートガイド
URL and contents are subject to change
without prior notice.
❖
Note
･
Reproduction or reprint of all or part of this manual
without prior permission is prohibited.
･
Important information for SO-01G is posted in the
following website. Be sure to check before using.
http://www.sonymobile.co.jp/support/use_support/
product/so-01g/ (In Japanese only)
(Quick Start Guide)". The
ク
Operation descriptions
In this manual, each key (key icon) operation is
described with
selection operations of the icons or function items
on the touch screen are described as follows.
Description Operation
From the Home
screen,
u
u
[About
phone].
Touch and hold
an icon.
❖
Information
･
In this manual, the instructions are described with
the default Home screen. If you set the other
application to the home screen, the operations may
differ from the descriptions.
･
Display examples and illustrations used in this
manual are just images for explanations and may be
different from actual ones.
･
In this manual, the easier procedure is described for
the functions and settings which have multiple
operating procedures.
･
Please note that "SO-01G" is called "the terminal" in
this manual.
･
In this manual, explanations for "docomo" as Home
application are provided (P.62).
P, k, x, y, r
From the Home screen, tap
(Apps button), and then tap
[Settings]
"Settings" on the next screen and
"About phone" on the following
screen in order.
Keep touching an icon longer (1-2
seconds).
. And
1
Supplied accessories
･
SO-01G (with warranty)
･
Desktop Holder SO23 (with warranty)
･
クイックスタートガイド
(Quick Start Guide) (In
Japanese only)
･
のご利用にあたっての注意事項
SO-01G
安全上／取り扱い上のご注意
(Notes on usage Safety/Handling
precautions) (In Japanese only)
･
TV/Mobacas antenna cable SO02
For optional accessories compatible with the
terminal (optional) , refer to NTT DOCOMO
website.
https://www.nttdocomo.co.jp/product/
option/ (In Japanese only)
2
Contents
■
Supplied accessories. . . . . . . . . . . . . . . . . 2
■
About using the terminal . . . . . . . . . . . . 5
■
Safety Precautions (Always follow these
directions) . . . . . . . . . . . . . . . . . . . . . . . . . . 7
■
Handling precautions. . . . . . . . . . . . . . . 17
■
Waterproofness/Dustproofness . . . . . 23
Before Using the Terminal . . . 29
Part names and functions................................................29
docomo nano UIM card.................................................... 30
Charging.....................................................................................32
Turning power on/off......................................................... 37
Initial settings........................................................................... 39
Basic operations.....................................................................40
Notification LED .....................................................................45
Status bar ................................................................................... 45
Notification panel .................................................................48
Home screen............................................................................ 49
Xperia™ Application screen .......................................... 55
Task manager...........................................................................61
Switching Home application.........................................62
Searching information in the terminal and web
pages ............................................................................................ 63
Character entry....................................................................... 64
Setting character entry...................................................... 70
docomo LIVE UX . . . . . . . . . . . . 71
Home screen............................................................................ 71
Managing the Home screen ..........................................71
Application screen................................................................ 73
Backing up and restoring the Home screen ........ 75
Using My Magazine ............................................................. 76
Checking Home application information.............. 76
Phone . . . . . . . . . . . . . . . . . . . . . . 77
Making/Receiving a call .................................................... 77
Operations during a call ................................................... 81
Call history................................................................................. 83
Call settings .............................................................................. 85
Phonebook ............................................................................... 87
Mail/Web browser . . . . . . . . . . . 91
docomo mail ........................................................................... 91
Message (SMS)........................................................................ 91
Email.............................................................................................. 94
Gmail............................................................................................. 98
Early Warning "Area Mail"................................................. 99
Browser..................................................................................... 100
Apps. . . . . . . . . . . . . . . . . . . . . . .103
dmenu...................................................................................... 103
dmarket.................................................................................... 103
Play Store ................................................................................ 103
Osaifu-Keitai .......................................................................... 105
Mobacas .................................................................................. 109
TV ................................................................................................. 114
FM radio................................................................................... 120
Camera ..................................................................................... 121
Album ....................................................................................... 134
YouTube .................................................................................. 136
Media Player.......................................................................... 137
Location services................................................................ 139
Schedule.................................................................................. 142
Alarm & clock........................................................................ 143
Content s/Precautio ns
3
docomo backup ................................................................. 144
Settings . . . . . . . . . . . . . . . . . . . 148
Viewing the setting menu............................................ 148
WIRELESS & NETWORKS ................................................. 148
DEVICE....................................................................................... 158
PERSONAL............................................................................... 164
ACCOUNTS............................................................................. 171
SYSTEM ..................................................................................... 173
File management . . . . . . . . . . 176
Storage structure................................................................ 176
File operation........................................................................ 178
Data communication . . . . . . . 180
Bluetooth function............................................................ 180
NFC communication........................................................ 182
External device connection . 185
Connecting to PC............................................................... 185
Connecting DLNA device ............................................. 187
Connecting to other devices...................................... 189
International roaming . . . . . . 190
Overview of International roaming (WORLD
WING)......................................................................................... 190
Available overseas service ............................................ 190
Checking before overseas use ................................... 191
Making/Receiving a call in the country you stay
....................................................................................................... 194
International roaming settings.................................. 196
After returning to Japan................................................. 198
Appendix/Index . . . . . . . . . . . .199
Troubleshooting................................................................. 199
あんしん遠隔サポート
....................................................................................................... 207
Warranty and After Sales Services ........................... 208
Software update................................................................. 211
Upgrade Android software.......................................... 215
Connecting to a PC to upgrade................................ 218
Main specification ............................................................. 218
Certificate and compliance ......................................... 224
Specific Absorption Rate of Mobile Phone, etc.
....................................................................................................... 224
End User Licence Agreement .................................... 236
Export Controls and Regulations ............................. 237
Intellectual Property Right ........................................... 237
SIM unlock.............................................................................. 241
Index .......................................................................................... 242
(Anshin Remote Support)
Content s/Precautio ns
4
Contents/Precautions
About using the terminal
･
The terminal supports LTE, W-CDMA, GSM/
GPRS and Wireless LAN Systems.
･
Because a terminal operates using radio
frequencies, it cannot be used inside a tunnel,
underground, in a building or other locations
where radio waves do not reach the terminal,
in locations with weak radio wave condition,
or out of Xi/FOMA service area. The services
may not be available on the upper floors of
high-rise apartments or buildings, even if
there are no obstructions around you. On
occasion, your calls may become
disconnected even in areas with strong radio
wave condition, even if you are not moving, or
even if there are 4-signal icon in the terminals
display.
･
Because your terminal uses radio waves to
communicate, it is possible that a third party
may attempt to tap your calls. However, the
LTE, W-CDMA, GSM/GPRS system
automatically scrambles all calls through a
private call feature. Therefore, even if the third
party successfully intercepts your call, they
will only hear noise.
･
The terminal operates on radio frequencies by
converting voice into digital signals. If the
caller moves into an area of adverse radio
wave condition, the digital signal may not be
restored accurately, and the voice received in
the call may differ slightly from the actual
voice.
･
Note down the information saved in the
terminal in a separate note on a regular basis
or save to an external recording medium such
as a microSD card or PC. Note that DOCOMO
assumes no responsibility for any loss of saved
contents of data resulting from malfunction,
repair, changing of the model or other
handling of the terminal.
･
As with PCs, some user-installed applications
may disrupt the stability of the terminal
performance, or unexpectedly transmit
information via the Internet causing improper
use of your location information as well as
personal information recorded on the
terminal. Therefore, verify the supplier and
operating conditions of the applications to be
used before using them.
･
This terminal has FOMA Plus-Area and FOMA
HIGH-SPEED Area support.
･
The terminal does not support i-mode sites
(programs) or i-
D
ppli.
Content s/Precautio ns
5
･
The terminal automatically performs
communication for synchronizing data,
checking the latest software version, and
maintaining a connection with the server, and
for other purposes. If you transmit a large
amount of data, such as when downloading
applications or watching video, a packet
communication charge becomes high.
Subscription to Packet Pack/packet flat-rate
service is highly recommended.
･
Depending on the applications or service you
use, packet communication charge may be
applied even in Wi-Fi communication.
･
Since Mobacas is a service linking
communication, using the service requires
packet communication charge. Subscription
to Packet Pack/packet flat-rate service is
recommended.
･
Public mode (Driving mode) is not supported.
･
Setting the terminal to silent mode does not
mute sounds for shutter, playback of video or
music, dialpad operation sound during a call,
sound emitted when [End call] is tapped, etc.
･
The name of the operator is displayed on the
lock screen (P.38).
･
To check your phone number (own number),
from the Home screen,
u
[Settings]u[About phone]u[Status] to
see "My phone number".
･
To check the software version, from the Home
screen,
u
[Settings]u[About phone].
･
If available memory in the microSD card or
the terminal is low, running applications may
not operate correctly. In that case, delete the
saved data.
･
You can update software on the terminal to
the latest one (P.211, P.218).
･
By upgrading Android software, the
operating system (OS) may be versionupgraded for improving the terminal quality.
For this reason, you always need to use the
latest OS version. And some applications that
used in the previous OS version may not be
available or some unintended bugs may
occur.
･
You can use the terminal only with a docomo
nano UIM card. If you have a docomo mini
UIM, docomo UIM, or FOMA card, bring it to a
docomo Shop to replace it with a docomo
nano UIM card.
･
Set password etc. for screen lock to ensure the
security of your terminal for its loss (P.168).
･
If your terminal is lost, change your each
account password to invalidate
authentication using a PC to prevent other
persons from using Google services such as
Gmail or Google Play, or SNS, etc.
･
For services provided by Google, refer to
Google Terms of Service. For other web
services, refer to each terms of service.
･
Applications and service contents are subject
to change without prior notice.
Contents/Precautions
6
･
The terminal supports only sp-mode, mopera
U and Business mopera Internet. Other
providers are not supported.
･
To use tethering, subscription of sp-mode is
required.
･
If you want to use tethering, subscription to
Packet Pack/packet flat-rate service is strongly
recommended.
･
For details on usage charge, etc., refer to the
following website.
https://www.nttdocomo.co.jp/english/
･
Display is manufactured by taking advantage
of highly advanced technology but some
dots may be always or never lit. Note that, this
shows characteristics of liquid crystal displays
and not defects in the terminals.
･
DOCOMO is not liable to any failures or
malfunctions for commercially available
optional equipment.
Safety Precautions (Always follow these directions)
■
For safe and proper use of the terminal, plea se
read the "Safety Precautions" prior to use.
Keep the Manual in a safe place for future
reference.
■
ALWAYS observe the safety precautions since
they intend to prevent personal injury or
property damage.
■
The following symbols indicate the different
levels of injury or damage that may result if
the guidelines are not observed and the
terminal is used improperly.
Failure to
observe these
DANGER
WARNING
CAUTION
guidelines may
immediately
result in death or
serious injury.
Failure to
observe these
guidelines may
result in death or
serious injury.
Failure to
observe these
guidelines may
result in injury
and property
damage.
Content s/Precautio ns
7
■
The following symbols indicate specific
directions.
Indicates prohibited actions.
Don’t
1. Handling the terminal, adapter,
desktop holder, docomo nano UIM
card, and TV/Mobacas antenna
cable (common)
Indicates not to disassemble.
No disassembly
Indicates not to use where it could
get wet.
No liquids
Indicates not to handle with wet
hands.
No wet hands
Indicates compulsory actions in
accordance with instructions.
Do
Indicates to remove the power plug
from the outlet.
Unplug
■
"Safety Precautions" are described in the
following categories:
1. Handling the terminal, adapter, desktop holder,
docomo nano UIM card, and TV/Mobacas
antenna cable (common). . . . . . . . . . . . . . . . . . . . 8
2. Handling the terminal . . . . . . . . . . . . . . . . . . . . . .10
3. Handling adapter or desktop holder. . . . . . . . . 13
4. Handling the docomo nano UIM card . . . . . . . 15
5. Handling the terminal near electronic medical
equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6. Material list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DANGER
Do not use, store or leave the equipment in
hot places (e.g. by the fire, near a heater,
Don’t
under a kotatsu, in direct sunlight, in a car in
the hot sun) (including wearing the
equipment by putting in a pocket of clothes
etc.).
Doing so may cause fire, burns or injury.
Do not place equipment inside cooking
appliance such as a microwave oven or high-
Don’t
pressure containers.
Doing so may cause fire, burns, injury or
electric shock.
Do not disassemble or modify the
equipment.
No disassembly
Doing so may cause fire, burns, injury or
electric shock.
Do not let the equipment get wet with
water, drinking water, urine of pet animals,
No liquids
sweat, etc.
Doing so may cause fire, burns, injury or
electric shock.
Waterproofness→P.23 "Waterproofness/
Dustproofness"
Content s/Precautio ns
8
Do not allow liquid (water, drinking water,
urine of pet animals, perspiration, etc.) to
No liquids
come into the charging jack or microUSB
jack.
Doing so may cause fire, burns, injury or
electric shock.
Waterproofness
Dustproofness"
Use optional devices specified by NTT
DOCOMO for the terminal.
Do
Failure to do so may cause fire, burns, injury or
electric shock.
→
P.23 "Waterproofness/
WARNING
Do not subject the equipment to excessive
force or throw it.
Don’t
Doing so may cause fire, burns, injury or
electric shock.
Do not allow the charging jack, microUSB
jack or headset jack to touch conducting
Don’t
foreign substances (a piece of metal, pencil
lead, etc.). Never allow these objects to get
inside.
Doing so may cause fire, burns, injury or
electric shock.
Do not cover or wrap the equipment with a
cloth or bedding in use or while charging.
Don’t
Doing so may cause fire or burns.
Power off the terminal before you step into a
place where flammable gas can leak, such as
Do
gas stations. Stop charging if you charge the
battery.
Gas may catch fire.
When using Osaifu-Keitai in a place such as a
gas station, turn OFF the terminal before using
it (When NFC/Osaifu-Keitai lock is activated,
deactivate it before turning OFF the terminal).
If you notice anything unusual about the
equipment such as an unusual odor,
Do
overheating, discoloration or deformation
during operation, charging or storage,
immediately perform the following
measures.
・
Remove the power plug from the power
outlet or cigarette lighter
・
Power off the terminal
Failure to do so may cause fire, burns, injury or
electric shock.
CAUTION
Do not place on an unstable or inclined
platform.
Don’t
Doing so may cause the device to fall and
cause injury.
Do not keep in a place that is very humid,
dusty, or subject to high temperature.
Don’t
Doing so may cause fire, burns or electric
shock.
If children use the terminal, parents or
guardians should give them the proper
Do
instructions for use. Make sure that they use
the terminal as instructed.
Failure to do so may cause injury.
Content s/Precautio ns
9
Keep the equipment out of the reach of
babies and infants.
Do
Failure to do so may cause accidental
ingestion, injury, or electric shock.
Be careful especially when using the
terminal connected to the adapter
Do
continuously for a long time.
If you play a game, watch videos or T V, etc. for
a long time while charging, the temperature
of the terminal and adapter may rise.
If you are directly in contact with hot parts for
a long perio d of time, it may caus e your skin to
become red, itchy, or develop a rash
depending on your physical condition and
also it may cause low-temperature burn.
2. Handling the terminal
■
Type of internal battery for the terminal is as
follows.
Display Type of Battery
Li-ion 00 Lithium Ion Battery
DANGER
Do not throw the terminal into fire or apply
heat.
Don’t
Doing so may cause internal battery to ignite,
burst, heat or leak.
Do not put excessive force such as sticking a
nail into the terminal, hitting it with a
Don’t
hammer, or stepping on it.
Doing so may cause internal battery to ignite,
burst, heat or leak.
If the internal battery fluid etc. contacts eyes,
immediately flush the eyes with clean water
Do
and see a doctor right away. Do not rub the
eyes.
Failure to do so may cause blindness.
WARNING
Do not turn on the light with the lighting
luminescence part close to the eyes.
Don’t
Especially to shoot infants or young
children, step away from them 1 m or more.
Doing so may cause blurred vision. Or injury
by dazzling eyes or surprising may occur.
Content s/Precautio ns
10
Do not allow a foreign substance such as
water and other liquids, metal parts, or
Don’t
flammables to get in the docomo nano UIM
card or microSD card slot on the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not turn on the light toward a driver of a
car etc.
Don’t
Doing so may disturb driving and cause an
accident.
Power off the terminal or put it in Airplane
mode before boarding an airplane.
Do
Use of mobile phones on board is restricted.
Follow the instructions of each airline.
Failure to do so may adversely affect on-board
electronic equipment.
Prohibited acts related to mobile phone usage
on an airplane may be punished by law.
If the microUSB cable is connected into the
microUSB jack for charging etc. with the
terminal powered off, the terminal is
automatically powered on although the
operations are not available. Be careful not to
connect the microUSB cable in a place where
the use is prohibited.
Follow the instructions of each medical
facility for the use of mobile phones on their
Do
premises.
Power off the terminal in a place where the
use is prohibited.
Failure to do so may affect electronic
equipment and electronic medical
equipment.
If the microUSB cable is connected into the
microUSB jack for charging etc. with the
terminal powered off, the terminal is
automatically powered on although the
operations are not available. Be careful not to
connect the microUSB cable in a place where
the use is prohibited.
Always keep the terminal away from your
ear when you talk setting the hands-free
Do
function.
Also, when you play game, play back music,
etc. connecting the Earphone/Microphone,
etc. to the terminal, adjust the volume
adequately.
If the volume is too loud, it may cause
difficulty in hearing.
Moreover, if you barely hear the surrounding
sounds, it may cause an accident.
If you have a weak heart, set the vibrator or
ringtone volume carefully.
Do
Failure to do so may affect your heart.
If you are wearing any electronic medical
equipment, check with the relevant medical
Do
electronic equipment manufacturer or
vendor whether the operation may be
affected by radio waves.
The radio waves from the terminal may affect
electronic medical equipment.
Content s/Precautio ns
11
Power off the terminal near electronic
devices or equipment operating on high
Do
precision control or weak signals.
Failure to do so may interfere with the
operation of electronic devices or equipment.
* The following are some electronic devices
or equipment that you should be careful of:
Hearing aids, implantable cardiac
pacemaker, implantable cardioverter
defibrillator, other electronic medical
equipment, fire detector, automatic door,
and other automatically controlled devices
or equipment.
If you use an implantable cardiac
pacemaker, implantable cardioverter
defibrillator, or other electronic medical
equipment, check with the relevant medical
electronic equipment manufacturer or
vendor whether the operation can be
affected by radio waves.
Be careful about broken glasses or exposed
internal from the terminal if the display or
Do
the camera lens is broken.
The display is made of toughened glass, and
the camera lens is made of acrylic resin to
prevent the glass from shattering when
broken. However, touching a cut surface or
exposed portion accidentally may result in
injury.
If the internal battery leaks or gives off a
strange smell, immediately remove it from
Do
the vicinity of open flames.
The leaking liquid may ignite fire, catch fire, or
explode.
CAUTION
Do not swing the terminal around by
holding strap, etc.
Don’t
The terminal may hit you or others and cause
accident such as injury.
Do not use damaged terminal.
Doing so may cause fire, burns, injury or
Don’t
electric shock.
When using the motion sensor, check the
safety around you, hold the terminal firmly,
Don’t
and do not shake it unnecessarily.
Failure to do so may cause accident such as
injuries.
If the display is mistakenly damaged and
when the liquid crystal runs out, do not get
Don’t
it on your skin such as face, hands, etc.
Doing so may cause blindness or injury on
your skin.
If the liquid crystal gets in your eye or mouth,
rinse with clean running water, and get
medical treatment immediately.
Also, if it gets on your skin or clothes, use
something such as alcohol to wipe off, and
wash it off with soap or something similar.
Do not discard the battery together with
other garbage.
Don’t
Doing so may cause igniting or environmental
destruction. Bring the unnecessary terminal
into a sales outlet such as docomo Shop. If
your local municipality has a battery recycling
program, dispose of them as provided for.
Content s/Precautio ns
12
To use the terminal in car, check with
automobile manufacturer or dealer to
Do
determine how the device is affected by
radio waves before using.
In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.
The use of the terminal may cause itching,
rashes, eczema, or other symptoms
Do
depending on the user's physical condition.
Immediately stop using and get medical
treatment in such a case.
For material of each part →P.16 "Material list"
When watching the display, take a certain
distance from the display in a fully bright
Do
place.
Failure to do so may reduce visual acuity.
If fluid etc. leaks out from the internal
battery, do not make the fluid contact with
Do
your skin of face or hands.
Doing so may cause blindness or injury on
your skin. If the fluid etc. gets into your eyes or
mouth, or contacts skin or clothes,
immediately flush the contacted area with
clean running water. If the fluid gets into the
eyes or mouth, immediately see a doctor after
flushing.
3. Handling adapter or desktop
holder
WARNING
Do not use the adapter cord if it gets
damaged.
Don’t
Doing so may cause fire, burns or electric
shock.
Do not use the AC adapter or desktop holder
in a very humid place such as bathroom.
Don’t
Doing so may cause fire, burns or electric
shock.
DC adapter is only for a negative ground
vehicle. Do not use DC adapter for a positive
Don’t
ground vehicle.
Doing so may cause fire, burns or electric
shock.
Do not touch the adapter if you hear
thunder.
Don’t
Doing so may cause electric shock.
Do not short-circuit the charging jack while
it is connected to the power outlet or
Don’t
cigarette lighter socket. Do not touch the
charging jack with your hands, fingers, or
any part of your body.
Doing so may cause fire, burns or electric
shock.
Do not place heavy objects on the adapter
cord.
Don’t
Doing so may cause fire, burns or electric
shock.
Content s/Precautio ns
13
When you insert and remove the AC adapter
from power outlet, do not contact a metal
Don’t
strap or other metal objects with the jack.
Doing so may cause fire, burns or electric
shock.
Do not put an excessive force up, down, left
or right when the adapter is connected to
Don’t
the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not touch the adapter cord, charging
jack or outlet with wet hands.
No wet hands
Doing so may cause fire, burns or electric
shock.
Use the adapter only on the specified power
supply and voltage.
Do
When charging the terminal overseas, use
AC adapter for global use.
Failure to do so may cause fire, burns or
electric shock.
AC adapter : 100V AC
DC adapter : 12V or 24V DC (only for a
negative-ground vehicle)
AC adapter for global use : 100V to 240V AC
(Make sure to connect the adapter to a
household AC power outlet.)
When the fuse in a DC adapter is blown,
make sure to use the specified fuse.
Do
Failure to do so may cause fire, burns or
electric shock. For the specified fuse, see the
users manuals that supplied with a DC
adapter.
Clean dust from the power plug.
Failure to do so may cause fire, burns or
Do
electric shock.
When you connect the AC adapter to the
power outlet, insert it firmly.
Do
Failure to do so may cause fire, burns or
electric shock.
When you disconnect the power plug from
the outlet or cigarette lighter socket, do not
Do
pull the adapter cord with excessive force.
Instead, hold the adapter to disconnect.
Failure to do so may cause fire, burns or
electric shock.
Remove or insert the adapter to the terminal
evenly without applying excessive force.
Do
Failure to do so may cause fire, burns, injury or
electric shock.
Always remove the power plug from the
outlet or cigarette lighter when not using
Unplug
the adapter for an extended period.
Failure to do so may cause fire, burns or
electric shock.
Immediately remove the power plug from
the outlet or cigarette lighter socket if water
Unplug
or other fluids get into the adapter.
Failure to do so may cause fire, burns or
electric shock.
Before cleaning, remove the power plug
from the power outlet or the cigarette
Unplug
lighter socket.
Failure to do so may cause fire, burns or
electric shock.
Content s/Precautio ns
14
4. Handling the docomo nano UIM
card
5. Handling the terminal near
electronic medical equipment
CAUTION
Be careful of the cut surface when handling
a docomo nano UIM card.
Do Do
Failure to do so may cause injury.
WARNING
If you use an implantable cardiac pacemaker
or implantable cardioverter defibrillator,
keep the terminal 15 cm or more away from
the implant at all times.
The radio waves from the terminal may affect
the performance of electronic medical
equipment.
If you need to use electronic medical
equipment other than implantable cardiac
Do
pacemaker or implantable cardioverter
defibrillator outside medical facilities such
as treating at home, check with the relevant
medical electronic equipment manufacturer
whether the operation may be affected by
radio waves.
The radio waves from the terminal may affect
the performance of electronic medical
equipment.
When you get close to other people within
15 cm just like not having enough space to
Do
turn around, set the radio wave of the
terminal to OFF beforehand ( Airplane mode,
to turn OFF, etc.).
A person in close proximity may put on
implanted a medical electrical equipment
such as pacemakers and ICDs. The radio waves
from the terminal may affect the performance
of electronic medical equipment.
Follow the instructions of each medical
facility for the use of the terminal on their
Do
premises.
Content s/Precautio ns
15
6. Material list
Part Material
Exterior case (4 corners) PA resin
Exterior case (strap hole) PA resin (with
Exterior case (top, bottom,
and side covers; microUSB
jack cover; and docomo
nano UIM card/microSD
card slot cover), power
key, volume key, camera
key
Exterior case (headset
jack)
Transparent plate
(camera)
Transparent plate (display,
back side)
Decoration ring (camera) Stainless alloy
Magnet connector (resin
part)
Magnet connector (sheet
metal)
Magnet connector
(electrode)
Desktop holder (upper
case, lower case)
glass)
Aluminum
alloy
Nylon resin
PMMA resin +
PC resin
Hardened
glass
PPS resin
(Black,
Copper)
Nylon resin
(White, Sliver
Green)
SUS Acrylic
Phosphor
bronze
ABS resin
Surface
treatment
―
―
Anodic
oxide
coating
―
AR
treatment
AFP
treatment
―
―
coating
Gold
plating
―
Part Material
Desktop holder
(attachment)
Desktop holder (magnet
connector)
Desktop holder (contacts,
charging jack)
Desktop holder (housing:
contacts)
Desktop holder (housing:
charging jack)
Desktop holder (shield:
charging jack)
Desktop holder
(nameplate)
Desktop holder (serial
number label)
Desktop holder (2D
barcode label)
Desktop holder
(immersion sensing label)
Desktop holder (rubber
foot)
TV/Mobacas antenna
cable (connector plug:
metal section)
TV/Mobacas antenna
cable (connector plug:
body, cable, headset jack:
body)
Surface
treatment
PC resin
Neodymium Nickel
Brass Gold
PA res in
Polyester resin
Stainless
PET
(aluminum
evaporation)
resin
PET resin
PS resin
Quality paper
Polyester resin
Brass Gold
Elastomer
resin
―
plating
plating
―
―
―
―
―
―
―
―
plating
―
Content s/Precautio ns
16
Handling precautions
■
Common precautions
･
SO-01G is waterproof/dustproof;
however, do not allow water or dust to
enter the terminal or come in contact
with accessories or optional devices.
The adapter, desktop holder, docomo nano UIM
card and TV/Mobacas antenna cable are not
waterproof/dustproof. Do not use in a bathroom
or other highly humid area or do not let rain
touch. Or putting them on your body, humidity
of sweat may cause internal corrosion and
malfunction. Note that malfunctions which are
determined to be caused by water as result of
inspections are outside the scope of the
warranty. Since these conditions are outside of
the scope of the warranty, a repair, if at all
possible, is charged.
･
Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
- Do not rub it roughly with a dry cloth. The
display may be damaged.
- Drops of water or dirt left on the display may
cause stains.
- Do not use alcohol, thinner, benzine, cleaning
detergent, etc. to clean the terminal. These
chemicals may erase the printing on the
terminal or cause discoloration.
･
Clean the terminals occasionally with a
dry cotton swab.
If the jack is soiled, connection gets worse and it
may cause power to be turned off or insufficient
battery charge, so clean the jack with a dry
cotton swab etc. When cleaning, be careful not
to damage the terminals.
･
Do not leave the terminal near the air
conditioning vent.
Extreme temperature changes may produce
condensation and corrode the internal parts of
the terminal, causing it to malfunction.
･
Make sure to use the terminal etc.
without excessive force.
If you put the terminal in a bag full of items or sit
down with the terminal in the pocket of your
cloth, it may damage the display, internal circuit
board, etc. and cause malfunction.
If doing so while the external device is connected
to the microUSB jack or headset jack, it may
cause damage or malfunction.
･
Do not rub or scratch the display with
metal.
The display may get scratched and it may cause
malfunction or damage.
･
Read the users manuals supplied with
individual optional devices.
■
The terminal precautions
･
Do not press touch screen surface
forcibly, or not operate with a sharppointed objects such as nail, ballpoint
pen, pin, etc.
Doing so may cause damage of touch screen.
Content s/Precautio ns
17
･
Do not use the terminal in extremely hot
or cold places.
Use the terminal where the temperature ranges
between 5℃ and 40℃ (limited to the temporary
use in a bathroom etc. when temperature is
above 36℃) and humidity ranges between 45%
and 85%.
･
Using the terminal near land-line phone,
television or radio may cause
interference i n these electric appliances.
Make sure to move far away from them
when using the terminal.
･
Note down the information saved in the
terminal in a separate note and keep it
safely.
Under no condition will DOCOMO be held liable
for any damaged or lost data saved in the
terminal.
･
Do not drop or give a strong impact to
the terminal.
Doing so may cause malfunction or damage.
･
Do not insert the plug of the external
device into the microUSB jack or
headset jack at the slant or pull it
obliquely while connecting.
Doing so may cause malfunction or damage.
･
The terminal could become warm while
in use and charging. This condition is
not abnormal. You can continue using
the terminal.
･
Do not leave the camera under direct
sunlight.
If you do so, some of the elements may melt or
become faded.
･
Usually, use the terminal with the
microUSB jack cover and docomo nano
UIM card/microSD card slot cover
closed.
Failure to do so may get dust or wate r inside and
cause malfunction.
･
While microSD card is being used, do
not take the card out and do not turn off
the terminal.
Doing so may cause data loss or malfunction.
･
Do not let magnetic cards, etc. close to
the terminal.
The magnetic data in cash cards, credit cards,
telephone cards, floppy disks, etc. may be erased.
･
Do not bring strong magnetic objects
close to the terminal.
Strong magnetic objects may cause
misoperation.
･
The internal battery is a consumable
part.
Replace the internal battery if the terminal has
extremely short operation time on a full charge,
though it may vary by operating conditions. For
replacing internal battery, contact "Repairs" on
the last page (in Japanese only) or DOCOMOspecified repair office.
･
Charge the battery in an environment
with the proper ambient temperature (5
℃
to 35℃).
Content s/Precautio ns
18
･
The operating time of the internal
battery varies depending on the
operating environment and the
degradation level of the internal
battery.
･
Be careful especially about the
following points when preserving the
terminal.
- The battery is fully charged (immediately after
the charging is complete)
- The battery has run out (the terminal cannot
power on)
The performance and life of the internal battery
may deteriorate.
It is recommended that you store the battery
with the remaining battery level of about 40% as
a guide.
■
Precautions on the adapter, desktop
holder
･
Charge the battery in an environment
with the proper ambient temperature (5
℃
to 35℃).
･
Do not charge in the following places.
- Places that are very humid, dusty or exposed to
strong vibrations
- Near land-line phone or TV/radio
･
The adapter or desktop holder could
become warm while charging. This
condition is not abnormal.
･
When using the DC adapter for
charging, do not turn off the vehicle
engine.
Doing so may cause the vehicle battery run out.
･
When you use the power outlet with a
mechanism to prevent the plug from
being removed, follow the instructions
on the outlet's user's manual.
･
Do not subject the equipment to a
strong impact. Do not deform the
charging jack.
Doing so may cause malfunction.
･
Magnet is used for magnet connector
that is between contacts of the desktop
holder. Make sure that any iron sands or
metal objects (clips etc.) are not
adhered before attaching the terminal.
Remove the foreign objects with a soft
cloth etc., if any.
･
Do not put a magnetic card such as a
cash card, commuter pass, etc. closer to
the magnet connector that is between
contacts of the desktop holder.
Magnetism of the desktop holder may
affect the magnetism of the card.
Content s/Precautio ns
19
･
Be sure to install the supplied
attachment to the desktop holder for
charging. The terminal cannot be
charged on the desktop holder without
attachment. Attachment 45A is
attached to the desktop holder by
default. Attachment 45B only supports
terminal covers with "
純正卓上ホルダ対応
(Compatible with genuine desktop
holders)" mark and the terminal can be
charged on the desktop holder with a
compatible cover attached.
■
docomo nano UIM card precautions
･
Do not use unnecessary force to insert/
remove the docomo nano UIM card.
･
Note that DOCOMO assumes no
responsibility for any malfunctions
resulting from inserting the docomo
nano UIM card into another IC card
reader/writer and using it.
･
Always keep the IC portion clean when
you use the card.
･
Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
･
Note down the information registered
in the docomo nano UIM card on a
separate sheet and keep it for future
reference.
Under no condition will DOCOMO be held liable
for any damaged or lost data saved in the
terminal.
･
Take an expended docomo nano UIM
card to a sales outlet such as docomo
Shop for proper disposal in order to
protect the environment.
･
Do not carelessly damage, contact, or
short-circuit an IC.
Doing so may cause data loss or malfunction.
･
Do not drop a docomo nano UIM card or
subject it to impact.
Doing so may cause malfunction.
･
Do not bend a docomo nano UIM card
or place a heavy object on it.
Doing so may cause malfunction.
･
Do not insert a docomo nano UIM card
into the terminal if a label or seal is
attached to the card.
Doing so may cause malfunction.
■
Bluetooth function precautions
･
To secure the Bluetooth communication
security, the terminal supports the
security function compliant with
Bluetooth standards, but the security
may not be sufficient depending on the
setting. Concern about the
communication using the Bluetooth
function.
･
Please be aware that DOCOMO is not
responsible for data leak when making
data communications using Bluetooth.
Content s/Precautio ns
20
･
Frequency band
The frequency band used by the terminal's
Bluetooth/wireless LAN function is written as
follows:
2.4 : This radio equipment uses the 2400 MHz
band.
Modulation scheme is the
FH/XX/DS/OF
4 : The estimated interference distance is 40
8 : The estimated interference distance is 80
Available channels vary depending on the
country.
For use in an aircraft, contact the airline
beforehand.
･
Bluetooth cautions
The operating frequency band of the terminal is
used by industrial, scientific, consumer and
medical equipment including microwave ovens,
premises radio stations for identifying mobile
units used in the manufacturing lines of plants
(radio stations requiring a license), specified low
power radio stations (radio stations requiring no
license) and amateur radio stations (hereinafter
referred to as "another station").
：
FH-SS, other system, DS-SS,
or OFDM system.
m or less.
m or less.
: The full band between 2400 MHz
and 2483.5 MHz is used and the
band of the mobile identification
device can be avoided.
- Before using this equipment, confirm that
"another station" is not being operated nearby.
- In the event of the terminal causing harmful
radio wave interference with "another station",
promptly change the operating frequency or
stop radio wave emission by turning off the
power, etc.
- If you have further questions, contact "General
Inquiries" on the last page.
■
Wireless LAN (WLAN) precautions
･
Wireless LAN (WLAN) exchanges
information using radio waves, and
allows you to freely establish LAN
connection if you are within an area
where radio wave reaches. On the other
side, if you communicate without
appropriate security settings,
communications may be intercepted or
hacked by malicious parties. It is
recommended to make necessary
security settings on your responsibility
and expense.
･
Wireless LAN
Do not use wireless LAN near magnetic devices
such as electrical appliances or AV/OA devices, or
in radio waves.
- Magnetism or radio waves may increase noises
or disable communications (especially when
using a microwave oven).
- When used near TV, radio, etc., reception
interference may occur, or channels on the TV
screen may be disturbed.
Content s/Precautio ns
21
- If there are multiple wireless LAN access points
nearby and the same channel is used, search
may not work correctly.
･
2.4GHz device cautions
The operating frequency band of the WLAN
device is used by industrial, scientific, consumer
and medical equipment including home electric
appliances such as microwave ovens, premises
radio stations for identifying mobile units used in
the manufacturing lines of plants (radio stations
requiring a license), specified low power radio
stations (radio stations requiring no license) and
amateur radio stations (radio stations requiring a
license).
- Before using the device, confirm that premises
radio stations for identifying mobile units,
specified low power radio stations and amateur
radio stations are not being operated nearby.
- If the device causes harmful radio interference
to premises radio stations for identifying
mobile units, immediately change the
frequency band or stop use, and contact
"General Inquiries" on the last page for crosstalk
avoidance, etc. (e.g. partition setup).
- If the device causes radio interference to
specified low power radio stations or amateur
radio stations, contact "General Inquiries" on
the last page.
･
5GHz device cautions
The terminal can use 3 frequency bands of
5.2GHz band (W52), 5.3GHz band (W53), 5.6 GHz
band (W56).
- 5.2GHz band (W52/36, 40, 44, 48 ch)
- 5.3GHz band (W53/52, 56, 60, 64 ch)
- 5.6GHz band (W56/100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140 ch)
Using wireless LAN built-into the terminal in 5.2/
5.3 GHz outside is prohibited by the Radio Law.
■
FeliCa® and NFC reader/writer function
precautions
･
FeliCa and NFC reader/writer, P2P
function of the terminal use weak waves
requiring no licenses for radio stations.
･
They use 13.56 MHz frequency band.
When using other reader/writer or P2P
function in your surroundings, keep the
terminal away sufficiently from them.
Before using the FeliCa and NFC reader/
writer, P2P function, confirm that there
are no radio stations using the same
frequency band nearby.
･
For use in an aircraft, contact the airline
beforehand. In some countries, usage
may be restricted. Confirm regulations
etc. for the country/area you stay before
using
Content s/Precautio ns
22
■
Note
･
Do not use a remodeled terminal. Using
a remodeled terminal violates the Radio
Law/Telecommunications Business Act.
The terminal is compliant with rules on the
technical standard conformance of specified
wireless equipment based on the Radio Law/
Telecommunications Business Act, and as a proof
of it, the "Technical Compliance Mark " is
depicted on the electronic nameplate of the
terminal. To check the certificate, from the Home
u
screen,
information]
If you remove the screws and alter the inside of
the terminal, the technical regulations
conformity certification becomes invalid.
Do not use the terminal with the certification
invalid, as it is a violation of the Radio Law and
Telecommunications Business Act.
･
Be careful when using the terminal
[Settings]u[About phone]u[Legal
u
[Certificates].
while driving.
Using a handheld mobile phone while driving
will result in a penalty.
However, absolutely necessary cases such as
rescue of a sick person or maintaining public's
safety are exempted.
･
Use the FeliCa reader/writer function
only in Japan.
FeliCa reader/writer function of the terminal
conforms to Japanese radio standards. If you use
this function overseas, you may be punished.
･
Do not alter the basic software illegally.
It is regarded as the software modification and
Repairs may be refused.
Waterproofness/ Dustproofness
SO-01G provides waterproofness property of
*1
*2,
, IPX8
IPX5
IP6X
docomo nano UIM card/microSD card slot
cover firmly attached.
*1 IPX5 means that a phone keeps functioning
after applying a jet flow of 12.5 L/min. from
every direction from a distance of
approximately 3 m for at least 3 minutes
using water nozzle in 6.3 mm inner
diameter.
*2 IPX8 means that a phone keeps functioning
after SO-01G is slowly submerged to depth
of 1.5m in static tap water at room
temperature, left there for approximately 30
minutes and then taken out.
*3 IP6X indicates that a phone has the ability
to prevent dust from entering it even when
it has been shaken for 8 hours in an
apparatus containing dust particles 75
or less in diameter.
and dustproofness property of
*3
with the microUSB jack cover and
μ
m
Content s/Precautio ns
23
What you can do with
waterproofness/dustproofness
of SO-01G
･
You can talk without an umbrella in the rain
(for rainfall of 20 mm or less per hour).
- Do not open or close the microUSB jack
cover or docomo nano UIM card/microSD
card slot cover with wet hands or with water
droplets on the terminal.
･
You can wash the terminal when it gets dirt or
stained with liquid other than tap water.
- Wash the terminal with tap water at normal
℃
temperature (5
flow (less than 6 L/min.) at distance of
approximately 10 cm away from the tap or
shower.
- When washing the terminal, hold the
microUSB jack cover and docomo nano UIM
card/microSD card slot cover to keep them
closed, and wash the terminal with your
hands, not using a brush or sponge. After
washing, drain the terminal before use
(P.27).
･
You can use at a poolside. Do not throw water
from the pool on the terminal, or soak it in
pool water.
-35℃) by weaker water
･
You can use the terminal in a bathroom.
- Do not immerse the terminal into a bathtub.
Also, do not use the terminal in hot water.
Doing so may cause malfunction. If you
should fall the terminal into the bathtub,
immediately pick it up to drain water in
specified procedure (P.27).
- Never put the terminal in hot spring water or
water containing soap, detergent or bath
powder. In case the terminal gets wet with
water other than tap water, wash it in the
procedure above.
- You can use the terminal within 2 hours in a
bathroom where the temperature ranges
℃
between 5 and 45
and humidity ranges
between 45 and 99%.
- Rapid temperature change may cause
condensation. If you bring the terminal from
a cold place to warm place such as a
bathroom, wait until the terminal reaches
the room temperature.
- Do not put hot water from a faucet or
shower.
Content s/Precautio ns
24
To ensure waterproofness/
dustproofness
To avoid water ingress, be sure to observe the
following points.
･
Do not throw any liquid other than room
temperature tap water on the terminal, or
soak it in such liquid.
･
Firmly close the microUSB jack cover and
docomo nano UIM card/microSD card slot
cover. Even a fine obstacle (one hair, one grain
of sand, tiny fiber, etc.) put between contact
surfaces may allow water to enter.
･
Do not poke the earpiece/speaker,
microphone/speaker, second microphone,
headset jack, or strap hole with a sharp object.
･
Do not let the terminal fall. It may become
scratched causing the waterproof/dustproof
performance to degrade.
･
The rubber gaskets on the inner side of the
microUSB jack cover and docomo nano UIM
card/microSD card slot cover play an
important role in keeping waterproof/
dustproof performance. Do not remove or
damage them. Also, prevent dust from
adhering to them.
■
Opening the microUSB jack cover and
docomo nano UIM card/microSD card
slot cover
Open the covers with your fingertip by the
grooves.
Groove
microUSB jack cover
Groove
docomo nano UIM card/
microSD card slot cover
Content s/Precautio ns
25
■
Closing the microUSB jack cover and
docomo nano UIM card/microSD card
slot cover
Put the cover back in the direction of the
arrow and push the parts in, then ensure
there are no gaps.
Important precautions
Do not perform actions shown in the
illustrations below.
<Example>
microUSB jack cover
It is recommended to replace the parts for
maintaining waterproof/dustproof property once
every two years regardless of whether any
abnormality is present. DOCOMO replaces the
parts as a chargeable service. Bring the terminal to
a sales outlet such as a DOCOMO-specified repair
office.
docomo nano UIM card/
microSD card slot cover
Using in hot
spring
Machine-
washing
Applying strong
Attaching
sand/mud
water ow
Using Soap/Detergent/
Bath powder
Soaking in
ocean water
Washing with
brush/sponge
Observe the following precautions to use the
terminal properly.
･
Accessories and optional devices are not
waterproof/dustproof.
･
Do not apply water flow stronger than
allowed (water flow of 6L/min. or more : e.g.,
such water flow that gives you pain when
applied to your skin directly from a faucet or
shower). SO-01G provides IPX5
waterproofness, but doing so may cause
malfunction.
･
If the terminal gets wet with salt water, sea
water, refreshing beverage or mud or sand
adhered, wash it immediately. If they dry out,
it is hard to remove the dirt and it may cause
damage or malfunction.
Content s/Precautio ns
26
･
Do not put the terminal in hot water, use it in
a sauna or apply hot airflow (from a hair dryer
etc.) to it.
･
Do not move the terminal in water or slam the
terminal against the surface of water.
･
If you put the terminal in tap water, be sure to
have it within 30 minutes.
･
When you use the terminal in swimming pool,
obey rules of the facility.
･
The terminal does not float on water.
･
Do not leave water on the terminal. In cold
region, the terminal freezes up and may cause
malfunction.
･
Do not leave water on the earpiece/speaker,
microphone/speaker, second microphone,
and headset jack. Such water may interfere
with talking.
･
If the terminal gets splashed with water or
other liquid while the microUSB jack cover or
docomo nano UIM card/microSD card slot
cover is open, the liquid may get inside the
terminal, causing electric shock or
malfunction. Stop using the terminal, turn off
the power and contact a DOCOMO-specified
repair office.
･
If any of the rubber gaskets on the inner side
of the microUSB jack cover or docomo nano
UIM card/microSD card slot cover is damaged
or deformed, have it replaced at a DOCOMOspecified repair office.
･
Do not connect TV/Mobacas antenna cable,
earphones, etc. with the terminal wet with
water. Doing so may cause malfunction.
DOCOMO does not guarantee actual operations
under all states. Malfunctions deemed to be caused
by inappropriate operation by the customer are
not covered by the warranty.
Draining water from the
terminal
When the terminal is wet, water may flow out
after wiping it off; drain the water in the
following steps.
a
Hold the terminal firmly and wipe off moisture on
the terminal surface and back side with dry, clean
cloth etc.
b
Shake the terminal approximately 20 times, firmly
holding it, until there is no more water splattering.
Content s/Precautio ns
27
c
Swing the terminal about 10 times against a dry,
clean cloth etc. to wipe off any water remaining in
the earpiece/speaker, microphone/speaker, second
microphone, headset jack, power/screen lock key,
volume/zoom key, camera key, contacts for the
desktop holder, covers (microUSB jack cover and
docomo nano UIM card/microSD card slot cover),
etc.
d
Wipe off water drained from the terminal with dry,
clean cloth etc., and dry naturally.
･
Wipe off water drained from the terminal with
dry, clean cloth etc., and dry naturally.
･
Do not wipe off water remaining in gaps directly
with a cotton swab etc.
･
Dry the terminal naturally for about 3 hours at
room temperature.
Notes on charging
Check the following before and after
charging.
･
Check if the terminal is not wet. Never charge
the battery when the terminal is wet.
･
Accessories and optional devices are not
waterproof/dustproof.
･
When charging the battery when or after the
terminal is wet, adequately drain it and wipe
off water with a dry, clean cloth etc., before
connecting the supplied desktop holder or
opening the microUSB jack cover.
･
When the microUSB jack cover is opened for
charging, close the cover firmly after charging.
It is recommended to use the desktop holder
for charging to prevent water or dust from
seeping inside through the microUSB jack.
･
Do not use the AC adapter or desktop holder
in a bathroom, shower room, kitchen, lavatory
or other highly humid area. Doing so may
cause fire or electric shock.
･
Do not touch the AC adapter or desktop
holder with wet hands. Doing so may cause
electric shock.
Content s/Precautio ns
28
Loading...
