Sony SNC-EMX50 Specsheet

SNC-EMX50

Indoor minidome video security camera with 5-megapixel resolution and motorized zoom

Overview

Excellent image quality in all lighting conditions

Features

The SNC-EMX50 is a high-performance indoor minidome camera, combining Sony's advanced Exmor R CMOS sensor and advanced image processing technologies for high-quality 5-megapixel images with wide dynamic range, excellent low-light sensitivity, and true day/night capability.

With the additional benefits of smart analytics, convenient installation, and powerful security features, the SNC-EMX50 is an ideal choice for demanding security, surveillance, and monitoring applications.

1/2.9 in 5-MP Exmor R CMOS sensor

The camera's very-high-resolution 5-megapixel Exmor R CMOS sensor captures exceptionally smooth, detailed video images at 30fps.

Automatic Varifocal Lens

High-quality Automatic Varifocal lens provides 3–10-mm focal length range, and makes it easy for an installer to quickly and accurately adjust the image for best results.

Better images in high-contrast conditions

Wide dynamic range technology ensures evenly exposed video footage, even in harshly lit high-contrast scenes where ordinary cameras struggle to accommodate bright highlights and dark shadow detail.

Powerful video analytics

Advanced in-built video analytics allow the camera to reliably detect, track and analyze objects, providing alerts and alarm triggers in response to a comprehensive range of pre-defined rules.

Day & Night function

The camera's switchable IR cut filter ensures best color accuracy in daylight, while boosting sensitivity for exceptional night-time, while maintaining sharp focus under all lighting conditions.

Support Detect, Observe, Recognize and Identify

Complies with Detect, Observe, Recognize, and Identify standard, defining the camera's ability to distinguish persons or objects in a specified area.

Area-based encoding

Allows separate compression parameters to be set for up to eight user-definable image areas, reducing bandwidth while ensuring optimum quality for the most

without written permission is prohibited. Features and specifications are subject to change without notice. The values for mass and dimension are approximate. All trademarks are the property of their respective owners.

important parts of the scene.

Encoding Regions of Interest (ROI)

Up to eight regions of interest can be specified in the camera's field of view, with separate encoding quality settings for each area.

Content-Based Imaging Technology

Continually adjusts camera settings, taking into account changing lighting conditions and subject movement for optimized image quality, while significantly reducing bandwidth requirements.

Intelligent Dynamic Noise Reduction

Distinguishes between noise and relevant image information, reducing network bandwidth requirements without compromising video quality.

Intelligent Auto Exposure

Automatically adjusts camera exposure and compensates for backlighting, assuring accurately exposed images in changing lighting conditions.

Intelligent streaming

Advanced encoding technology is combined with the efficient H.265 compression codec and Intelligent Dynamic Noise Reduction, reducing network bandwidth requirements by up to 80% while maintaining excellent image quality compared with conventional streaming using H.264 compression.

Edge recording

Store up to 2 TB of local alarm recording on an optional microSD card. Pre-alarm recording in RAM reduces network bandwidth.

Cut through fog and haze

Intelligent Defog automatically optimizes picture quality in foggy, hazy, or misty conditions.

Latest data security technology

The camera's on-board Trusted Platform Module (TPM) and Public Key Infrastructure (PKI) offer superior protection against malicious attacks. 802.1x network authentication with EAP/TLS supports TLS 1.2 with updated cipher suites including AES 256 encryption.

Automatic calibration

Integration is simplified by the camera's internal gyro/accelerometer which automatically senses orientation, flipping the image in increments of 90 ° if the camera is mounted on its side or upside down.

Seamless system integration

Conformance to ONVIF Profile S, Profile T and Profile G specifications ensures interoperability with other network video products and systems. The camera's internal features can be accessed directly by third-party integrators.

Specifications	Camera

	Image Sensor	1/2.9-type progressive scan Exmor-R CMOS
	Image Sensor	sensor
		sensor

	Number of Effective Pixels	3072 x 1728 (5 MP)

	Minimum Illumination (30 IRE)	Color: 0.24 lx (F1.3)
	Minimum Illumination (30 IRE)	B/W: 0.03 lx (F1.3)


		IR mode: 0.0 lx (F1.3)

	Dynamic Range	119 dB

	S/N Ratio (Gain 0 dB)	More than 55 dB

	Gain	Auto

	Shutter Speed	1/25[30] s to 1/15,000 s

	Exposure Control	Automatic exposure, Fixed Shutter speed,
	Exposure Control	Default shutter, Automatic iris control
		Default shutter, Automatic iris control

	White Balance	2500 to 10,000K, 4 automatic modes (basic,
	White Balance	standard, sodium vapor, dominant color),
		Manual mode and Hold mode

	Lens	Automatic Varifocal (AVF)

	Horizontal Viewing Angle	29 °–92 °

	Vertical Viewing Angle	18 °–50 °

	Focal Length	f = 3 mm–10 mm

	F-Number	F1.3 — F360

Camera Features

	Day/Night	True D/N
	Day/Night linked with Easy	Yes
	Focus	Yes
	Focus

	Night Vision	No

	Auto-rotation Mode	No

	e-Flip	Yes

	Image Rotate	Yes

	Mirroring	Yes

	Wide-D	Yes

	Tone Correction	Global Tone Mapping

	Defog Image Processing	Yes

	Highlight Compensation	Yes

	Flicker Reduction	Yes

	Distortion Correction	No

	Noise Reduction	Yes

	Image Stabilizer	No

	Intelligent Scene Capture	Yes

	Privacy Masking (number)	Yes (8 areas)
