Box Camera Selection Guide

Box Camera

Picture Model No. Feature Sensor TVL Min Illumination Lens Voltage Page

RYK-AF302A

Auto Focus Zoom

35x

1/4” CL WDR

470

0.01 Lux (Night / BW)

0.5 Lux (Day / Color)

35x Zoom

(ICR)

RYK-AF301A

1/4” CL

(EX-View)

RYK-AF204A

Auto Focus Zoom

22x

22x Zoom

(ICR)

RYK-AF203A

1/4" CL

330

0.1 Lux (Night / BW)

0.3 Lux (Day / Color)

RYK-AF201A 330 0.3 Lux

22x Zoom

RYK-AF202A 470 0.7 Lux

RYK-AF302

Auto Focus Zoom

35x

1/4” CL WDR

470

0.01 Lux (Night / BW)

0.5 Lux (Day / Color)

35x Zoom

(ICR)

RYK-AF301

1/4” CL

(EX-View)

RYK-200ZRX

Auto Focus Zoom

22x

22x Zoom

(ICR)

RYK-20AZR

1/4" CL

330

0.1 Lux (Night / BW)

0.3 Lux (Day / Color)

RYK-20AZ 330 0.3 Lux

22x Zoom

RYK-200Z 470 0.7 Lux

RYK-491DR WDR / ICR / OSD 1/3” CL 470

0.1 Lux (Night / BW)

0.001 Lux (DSS)

C/CS Mount

AC, Dual

RYK-493DR

ICR / OSD

Super HR

1/3” CL

550

0.05 Lux (Night / BW)

0.8 Lux (Day / Color) 08

RYK-493DRX

1/3” CL

(EX-View)

0.01 Lux (Night / BW)

0.5 Lux (Day / Color)

RYK-235LVR3

ICR / LED

Vari-Focal

1/3” CL

380 0.2 Lux

Vari Focal

(ICR)

DC, Dual 09

RYK-232LVR3 470 0.3 Lux

RYK-475ZM3(ZM9)

Vari-Focal

1/3” CL

380 0.2 Lux

Vari Focal AC, Dual 10

RYK-472ZM3(ZM9) 470 0.3 Lux

RYK-775ZM3(ZM9)

1/3” BW

420 0.1 Lux

RYK-777ZM3(ZM9) 600 0.2 Lux

RYK-213F

Super HR 1/3” CL 550 0.2 Lux C/CS Mount

RYK-413F AC, Dual

RYK-275F

Standard Type

1/3” CL

380 0.1 Lux

C/CS Mount

RYK-475F AC, Dual

RYK-272F

470 0.2 Lux

RYK-472F AC, Dual

RYK-277F

1/4” CL 330 0.2 Lux

RYK-477F AC, Dual

RYK-575F

1/3” BW

420 0.05 Lux

RYK-775F AC, Dual

RYK-577F

600 0.1 Lux

RYK-777F AC, Dual

RYK-572F

B/W DSP

510 0.05 Lux

RYK-772F AC, Dual

RYK-573F

710 0.1 Lux

RYK-773F AC, Dual

RYK-264K

Mini Size

All In One

(Kit)

1/4” CL 330 0.5 Lux

Board Lens DC 13

RYK-569K 1/3” BW 400 0.3 Lux

35x (ICR) Auto Focus Zoom Camera

Features

‧Sony EX-View HAD CCD sensor

‧35x optical zoom, 16x digital zoom

‧Day & Night (IR-Cut  lter Removable, ICR)

‧On Screen Display (OSD) set-up menu

‧Built-in 5 keys to control zooming, focusing function

and set-up menu adjustment

‧Support functions: AI, AWB, AGC, BLC, FL, Positive /

Negative, Auto Focus, Audio function

‧Support YOKO / PELCO D&P / LG protocol

DC 12V IN

REMOTE

FAR

AUDIO

VIDEO

WIDE

NEARMENU

TELE

GND

DNOT+R+

DNI

GNDT-R-

Focu s (+ : Far , - : N ear)

COM DC12 V IN

Zoom ( + : Tele , - : Wid e)

GND

A/D KE Y

REMO TE

126.1 mm

73 mm

64 mm

65.5 mm

64 mm

■

Option :

RYK-83 40

Wire Remote C ontroller

Model Name RYK-AF301A RYK-AF302A

Image Device 1/4” Color Sony EX-View HAD (Hi-Res.) 1/4" Color Sony EX-View HAD (WDR, Hi-Res.)

Picture Elements NTSC:768x494, PAL:752x582

Resolution 470 TVL

Min. Illumination 0.01 Lux (Night / BW), 0.5 Lux (Day / Color) / F1.6

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/30,000, PAL:1/50~1/30,000 NTSC:1/60~1/50,000, PAL:1/50~1/50,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Auto / Manual

Lens Furnished 35x (ICR) Auto Focus Zoom (3.6~126mm / F1.6~4.2), Video AF

Digital Zoom Ratio Basic 16x (Total Zoom Ratio 560x), 2x~16x variable Basic 10x (Total Zoom Ratio 350x), 2x~10x variable

Min. Shutting Distance 0.01m (WIDE), 1.5m (TELE)

Camera Control RS-485 / RS-422 (option: RS-232)

Remote Control 6-pin Circular Connect: Zoom, Focus, A/D key, DC12V IN

Key Control Tele (Up), Wide (Down), Near (+), Far (-), Menu

Protocol YOKO / PELCO D&P / LG

Zoom Speed 8 / 11 / 14 sec mode Slow / Normal / High

Zoom / Focus Preset 128 preset points

Focus Mode Auto / Manual / Push Auto

On Screen Display Set-up menu

Negative / Positive On / Off

Wide Dynamic Range (WDR)

－

On / Off

Day & Night (ICR) AE / Sensor / Day / Night / External

Day & Night Control Day & Night output / Day & Night External input

Brightness Control Manual

Wide Burst On / Off

－

White Balance Auto / Hue / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Motion Detection

－

On / Off

Privacy Masking

－

8 free areas (Area size adjustable)

Back Light Comp. On / Auto (Center / Up / Down / Left / Right) / Super / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms

－

Power Supply DC12V±10%

Power Consumption 340mA max. 440mA max.

Operating Temp. -10°C ~ 50°C

RYK-85 05L

IR Housing

35x (ICR) Auto Focus Zoom Module

Features

‧Sony EX-View HAD CCD sensor

‧35x optical zoom, 16x digital zoom

‧Day & Night (IR-Cut  lter Removable, ICR)

‧On Screen Display (OSD) set-up menu

‧Camera control via RS-232 (TTL Level)

‧Key control (Zooming function, Focusing function and set-up

menu adjustment) via 6-pin Dry Contact Connector

‧Support functions: AI, AWB, AGC, BLC, FL, Positive /

Negative and Auto Focus

‧Support YOKO / PELCD D&P / LG protocol

Box Camera

CN1: FCC Connector

CN2: Key Control

CN3: Reserved SW1: RS-232 Setting

CN4

CN4: Day & Night Connector

Output

Input

GND

57.4 mm

51.4 mm

90.3 mm

51.4 mm

Model Name RYK-AF301 RYK-AF302

Image Device 1/4” Color Sony EX-View HAD (Hi-Res.) 1/4" Color Sony EX-View HAD (WDR, Hi-Res.)

Picture Elements NTSC:768x494, PAL:752x582

Resolution 470 TVL

Min. Illumination 0.01 Lux (Night / BW), 0.5 Lux (Day / Color) / F1.6

S/N Ratio Mo re tha n 4 8dB

Electronic Shutter NTSC:1/60~1/30,000, PAL:1/50~1/30,000 NTSC:1/60~1/50,000, PAL:1/50~1/50,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Auto / Manual

Lens Furnished 35x (ICR) Auto Focus Zoom (3.6~126mm / F1.6~4.2), Video AF

Digital Zoom Ratio Basic 16x (Total Zoom Ratio 560x), 2x~16x variable Basic 10x (Total Zoom Ratio 350x), 2x~10x variable

Min. Shutting Distance 0.01m (WIDE), 1.5m (TELE)

Camera Control RS-232 (TTL Level)

Remote Control 6-pin Dry Contact Connector: Tele, Wide, Near, Far, Menu, GND

Protocol YOKO / PELCO D&P / LG

Zoom Speed 8 / 11 / 14 sec mode Slow / Normal / High

Zoom / Focus Preset 128 preset points

Focus Mode Auto / Manual / Push Auto

On Screen Display Set-up menu

Negative / Positive On / Off

Wide Dynamic Range (WDR)

－

On / Off

Day & Night (ICR) AE / Sensor / Day / Night / External

Day & Night Control Day & Night output / Day & Night External input

Brightness Control Manual

Wide Burst On / Off

White Balance Auto / Hue / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Motion Detection

－

On / Off

Privacy Masking

－

8 free areas (Area size adjustable)

Back Light Comp. On / Auto (Center / Up / Down / Left / Right) / Super / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms Power Supply DC12V±10%

Power Consumption 340mA max. 440mA max.

Operating Temp. -10°C ~ 50°C

‧Dry Contact is either open under normal status (Normal Open) or close to GND under active status (connected to GND).

22x (ICR) Auto Focus Zoom Camera

Features

‧22x optical zoom, 16x digital zoom

‧Day & Night (option: IR-Cut  lter Removable, ICR)

‧On Screen Display (OSD) set-up menu

‧Camera control via RS-485

‧Support functions: AI, AWB, AGC, BLC, FL,

Positive / Negative

‧Support YOKO / PELCO D&P / LG protocol

Model No. RYK-AF201A RYK-AF202A RYK-AF203A RYK-AF204A

Image Device

1/4” Color Sony

Super HAD

1/4” Color Sony

Super HAD (Hi-Res.)

1/4” Color Sony

Super HAD

1/4” Color Sony

EX-View HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

Resolution 330 TVL 470 TVL 330 TVL 470 TVL

Min. Illumination 0.3 Lux / F1.6 0.7 Lux / F1.6

0.1 Lux (Night / BW),

0.3 Lux (Day / Color) / F1.6

0.01 Lux (Night / BW),

0.5 Lux (Day / Color) / F1.6

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/30,000 , PAL:1/50~1/30,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Auto / Manual

Lens Furnished 22x Auto Focus Zoom (3.9~85.8mm / F1.6~3.7) 22x (ICR) Auto Focus Zoom (3.9~85.8mm / F1.6~3.7)

Digital Zoom Ratio Basic 16x (Total Zoom Ratio 352x), 2x~16x variable

Mini. Shutting Distance 0.01m (WIDE), 1.0m (TELE)

Camera Control RS-485 / RS-422 (option: RS-232)

Remote Control 6-pin Circular Connect: Zoom, Focus, A/D key, DC12V IN

Key Control Tele (Up), Wide (Down), Near (+), Far (-), Menu

Protocol YOKO / PELCO D&P / LG

Zoom Speed 5 / 7 / 9 sec mode

Zoom / Focus Preset 128 preset points

Focus Mode Auto / Manual / Push Auto

On Screen Display Set-up menu

Negative / Positive On / Off

Day& Night (ICR) On / Off AE / Sensor / Day / Night / External

Color Control On / Off

－

Brightness Control Manual

Wide Burst On / Off

White Balance Auto / Hue / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Back Light Comp. On / Auto (Center / Up / Down / Left / Right) / Super / Off

Sync. System Internal / External Line Lock

Video Output 1 Vp-p / 75 Ohms

Power Supply DC12V±10%

Power Consumption 340mA max.

Operating Temp. -10°C ~ 50°C

DC 12V IN

REMOTE

FAR

AUDIO

VIDEO

WIDE

NEARMENU

TELE

GND

DNOT+R+

DNI

GNDT-R-

Focu s (+ : Far , - : N ear)

COM DC12 V IN

Zoom ( + : Tele , - : Wid e)

GND

A/D KE Y

REMO TE

126.1 mm

73 mm

64 mm

65.5 mm

64 mm

■

Option :

RYK-83 40

Wire Remote C ontroller

RYK-85 05L

IR Housing

Box Camera

22x (ICR) Auto Focus Zoom Module

Features

‧22x optical zoom, 16x digital zoom

‧Day & Night (option: IR-Cut  lter Removable, ICR)

‧On Screen Display (OSD) set-up menu

‧Camera control via RS-232 (TTL Level)

‧Support functions: AI, AWB, AGC, BLC, FL,

Positive / Negative

‧Support LG protocol

57 mm

59.2 mm

47 mm

48.6 mm

82.5 mm

RYK-20AZ/200Z

RYK-20AZR/200ZRX

84.5 mm

47 mm

48.6 mm

CN4

CN1: FCC Connector

CN2: Key Control

CN3, SW1: Reserved SW2: RS-232 Setting

CN1: FCC Connector

CN2: Key Control

CN3: Reserved CN4: Day & Night Connector

Output

Input

GND

‧RYK-20AZR/200ZRX ‧RYK-20AZ/200Z

Model No. RYK-20AZ RYK-200Z RYK-20AZR RYK-200ZRX

Image Device

1/4” Color Sony

Super HAD

1/4” Color Sony

Super HAD (Hi-Res.)

1/4” Color Sony

Super HAD

1/4” Color Sony

EX-View HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

Resolution 330 TVL 470 TVL 330 TVL 470 TVL

Min. Illumination 0.3 Lux / F1.6 0.7 Lux / F1.6

0.1 Lux (Night / BW),

0.3 Lux (Day / Color) / F1.6

0.01 Lux (Night / BW),

0.5 Lux (Day / Color) / F1.6

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/30,000 , PAL:1/50~1/30,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Auto / Manual

Lens Furnished 22x Auto Focus Zoom (3.9~85.8mm / F1.6~3.7) 22x (ICR) Auto Focus Zoom (3.9~85.8mm / F1.6~3.7)

Digital Zoom Ratio Basic 16x (Total Zoom Ratio 352x), 2x~16x variable

Mini. Shutting Distance 0.01m (WIDE), 1.0m (TELE)

Camera Control RS-232 (TTL Level)

Remote Control 6-pin Dry Contact Connector: Tele, Wide, Near, Far, Menu, GND

Protocol LG

Zoom Speed 5 / 7 / 9 sec mode

Zoom / Focus Preset 128 preset points

Focus Mode Auto / Manual / Push Auto

On Screen Display Set-up menu

Negative / Positive On / Off

Day & Night (ICR) On / Off AE / Sensor / Day / Night / External

Color Control On / Off

－

Brightness Control Manual

Wide Burst On / Off

White Balance Auto / Hue / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Back Light Comp. On / Auto (Center / Up / Down / Left / Right) / Super / Off

Sync. System Internal / External Line Lock

Video Output 1 Vp-p / 75 Ohms

Power Supply DC12V±10%

Power Consumption 340mA max.

Operating Temp. -10°C ~ 50°C

‧Dry Contact is either open under normal status (Normal Open) or close to GND under active status (connected to GND).

Wide Dynamic Range (WDR) Camera

Model No. RYK-491DR

Image Device 1/3" Color Sony Vertical double-Density WD CCD (Hi-Res.)

Picture Elements NTSC:768x494, PAL:752x582

Resolution 470 TVL

Min. Illumination 0.1 Lux (Night / BW), 0.001 Lux (DSS) / F1.2

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/100,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Video / DC Drive

Lens Mount C / CS

Gamma 0.45

White Balance Auto / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Back Light Comp. On / Off (Level & Area adjustable)

Wide Dynamic Range (WDR) On / Off (Level adjustable)

Day & Night (ICR) AE / Sensor / Day / Night

Digital Zoom 3x

Camera ID 000~255

Camera Title Up to 16 characters

Mirror Off / Horizontal / Vertical / Rotate

Privacy Masking 8 free areas (Area size adjustable)

Freeze On / Off

Positive / Negative On / Off

Digital Slow Shutter (DSS) Off, 2~20, 40, 80, 160 FLD

Remote Control RS-485 / RS-422 (option: RS-232)

Protocol YOKO / PELCO D&P / LG

Sync. System Internal / External Line Lock

Video Output 1 Vp-p / 75 Ohms

Power Supply DC12V/AC24V Dual (option: AC110~240V)

Power Consumption Dual: 5.8W max., AC: 7W max.

Operating Temp. -10℃ ~ 50℃

Features

‧ Camera with 1/3" Color Sony Vertical double-Density WD CCD

‧ High sensitivity, low smear, high anti-blooming and high S/N ratio

‧ IR-Cut  lter Removable (ICR) provides change from color to B/W

mode automatically or manually for day and night 24-hour

surveillance

‧ On Screen Display (OSD) set-up menu

‧ Remote control via RS-485/422 (option: RS-232)

‧ Special functions: Flickerless, Mirror, Freeze, Line Lock,

Positive / Negative, Camera ID, Camera Title,

Privacy Masking, Digital Zoom, Digital Slow Shutter

■

Controller :

RYK-83 30

(RS- 485)

130.6 mm

66 mm

52 mm

Box Camera

Hi-Res. OSD Camera

Model No. RYK-493DR RYK-493DRX

Image Device 1/3” Color Sony Super HAD (Hi-Res.) 1/3” Color Sony EX-View HAD (Hi-Res.)

Picture Elements NTSC:768x494, PAL:752x582

Resolution 550 TVL

Min. Illumination 0.05 Lux (Night / BW), 0.8 Lux (Day / Color) / F2.0 0.01 Lux (Night / BW), 0.5 Lux (Day / Color) / F2.0

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/100,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Iris Control Video / DC Drive

Lens Mount C / CS

Gamma 0.45

White Balance Auto / Indoor / Outdoor / Manual / Push Auto

Gain Control Auto / Manual

Back Light Comp. On / Off (Level & Area adjustable)

Day & Night (ICR) AE / Sensor / Day / Night

Camera ID 000~255

Camera Title Up to 16 characters

Mirror On / Off

Privacy Masking 8 free areas (Area size adjustable)

Positive / Negative On / Off

Remote Control RS-485 / RS-422 (option: RS-232)

Protocol YOKO / PELCO D&P / LG

Sync. System Internal / External Line Lock

Video Output 1 Vp-p / 75 Ohms

Power Supply DC12V/AC24V Dual (option: AC100~240V)

Power Consumption Dual: 4.1W max., AC: 4.9W max.

Operating Temp. -10℃ ~ 50℃

Features

‧ Camera with 1/3" Color Sony Hi-Res. (550TVL)

EX-View HAD

‧ High sensitivity, low smear, high anti-blooming and

high S/N ratio

‧ IR-Cut  lter Removable (ICR) provides change from

color to B/W mode automatically or manually for day

and night 24-hour surveillance

‧ On Screen Display (OSD) set-up menu

‧ Special functions: Flickerless, Mirror, Line Lock,

Positive / Negative, Camera ID, Camera Title,

Privacy Masking

130.6 mm

66 mm

52 mm

■

Controller :

RYK-83 30

(RS- 485)

Vari-Focal IR Camera

Features

‧ Sony Super HAD CCD sensor

‧ Built-in Vari-Focal Lens

‧ Day & Night (IR-Cut lter Removable, ICR)

‧ DC or DC/AC Dual voltage

‧ Option Model:

RYK-232VF3/235VF3 – without IR LED & ICR

RYK-232VF9/235VF9 – without IR LED & ICR,

9~22mm VF Lens

66 mm

146 mm

58 mm

VIDEO

DC12V IN

Model No. RYK-235LVR3 RYK-232LVR3

Image Device 1/3” Color Sony Super HAD 1/3” Color Sony Super HAD (Hi-Res.)

Picture Elements NTSC:510x492, PAL:500x582 NTSC:768x494, PAL:752x582

Resolution 380 TVL 470 TVL

Min. Illumination 0.2 Lux / F2.0 (Day), 0 Lux (IR On) 0.3 Lux / F2.0 (Day), 0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

Gamma 0.45

Iris Control DC Drive

Lens Furnished Vari-Focal 3.7~12mm (ICR) / F1.6~3.0, Wide: 71.6°x55.8°, Tele: 23.8°x17.9° (HxV)

White Balance Auto

Gain Control High / Low

Back Light Comp. On / Off

Day & Night (ICR) Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms (option)

Infrared Luminary 10 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 10 M

Power Supply DC12V±10% (option: DC12V/AC24V Dual)

Power

Consumption

DC IR On: 320mA max., IR Off: 160mA max.

DUAL

IR On: DC12V/320mA, AC24V/4.0W max.

IR Off: DC12V/180mA, AC24V/3.2W max.

Operating Temp. -10°C ~ 50°C

Box Camera

Vari-Focal Camera

Features

‧ Sony Super HAD CCD sensor

‧ Built-in 3.7~12mm / 9.0~22mm Vari-Focal Lens

‧ AC or DC/AC Dual voltage

Color Camera

50 mm

140.5 mm

95 mm

46 mm

B/W Camera

Model No.

RYK-475ZM3 RYK-472ZM3 RYK-775ZM3 RYK-777ZM3

RYK-475ZM9 RYK-472ZM9 RYK-775ZM9 RYK-777ZM9

Image Device

1/3” Color Sony

Super HAD

1/3” Color Sony

Super HAD (Hi-Res.)

1/3” B/W Sony

Super HAD

1/3” B/W Sony

Super HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

EIA:510X492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

Resolution 380 TVL 470 TVL 420 TVL 600 TVL

Min. Illumination 0.2 Lux / F2.0 0.3 Lux / F2.0 0.1 Lux / F2.0 0.2 Lux / F2.0

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Flickerless Mode On / Off (NTSC:1/100, PAL:1/120)

－

Gamma 0.45

Iris Control DC Drive

Lens Furnished

ZM3 model: Vari-Focal 3.7~12mm / F1.6~3.0, Wide: 71.6°x55.8°, Tele: 23.8°x17.9° (HxV)

ZM9 model: Vari-Focal 9.0~22mm / F2.0~360, Wide:29.2°x21.7°, Tele:13.0°x9.7° (HxV)

White Balance Auto

－

Gain Control High / Low Auto

Back Light Comp. On / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Power Supply AC100~240V (option: AC24V, AC110V, DC12V/AC24V Dual)

Power Consumption 3.3W max. 4.6W max. 3.1W max. 3.3W max.

Operating Temp. -10℃ ~ 50℃

Color CCD Camera

Features

‧Sony Super HAD CCD sensor

‧Hi-Res. 550 TVL

Improvement of color-rolling suppression

(for RYK-213F/413F)

‧Video / DC Drive

‧DC, AC or DC/AC Dual voltage

112.5 mm

50 mm

130 mm

60 mm

100 mm

88 mm

46 mm

51 mm

RYK-275F/272F/277F RYK-213F

Model No.

DC RYK-275F RYK-272F RYK-213F

AC RYK-475F RYK-472F RYK-413F

Image Device 1/3" Color Sony Super HAD 1/3" Color Sony Super HAD (Hi-Res.) 1/3" Color Sony Super HAD (Hi-Res.)

Picture Elements NTSC:510x492, PAL:500x582 NTSC:768x494, PAL:752x582 NTSC:768x494, PAL:752x582

Resolution 380 TVL 470 TVL 550 TVL

Min. Illumination 0.1 Lux / F1.2 0.2 Lux / F1.2 0.2 Lux / F1.2

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000

Gamma 0.45

Iris Control Video / DC Drive

Lens Mount C / CS

White Balance Auto

Gain Control Auto

Back Light Comp. On / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms (option, for DC type only)

Power Supply

DC DC12V±10%

AC AC24V, AC110V, AC100~240V, DC12V/AC24V Dual (option)

Power

Consumption

DC 225mA max. 125mA max. 175mA max.

AC 3.2W max. 2.5W max. 3.2W max.

Operating Temp. -10°C ~ 50°C

■



Series Model:

Model No. Description

RYK-277F 1/4" Color Sony Super HAD, 330 TVL, 0.2 Lux / F1.2, DC12V (option: Audio function)

RYK-477F 1/4" Color Sony Super HAD, 330 TVL, 0.2 Lux / F1.2, AC or DC12V/AC24V Dual (option)

‧RYK-275F / 272F / 277F

‧RYK-213F

Box Camera

B/W CCD Camera

Features

‧Sony Super HAD CCD sensor

‧Employs DSP IC for image control

Provide high resolution, sharpness image quality

(for RYK-572F/772F/573F/773F)

‧Video / DC Drive

‧DC, AC or DC/AC Dual voltage

Model No.

DC RYK-575F RYK-577F RYK-572F RYK-573F

AC RYK-775F RYK-777F RYK-772F RYK-773F

Image Device

1/3" B/W Sony

Super HAD

1/3" B/W Sony

Super HAD (Hi-Res.)

1/3" B/W Sony Super HAD

(DSP IC)

1/3" B/W Sony Super HAD

(Hi-Res., DSP IC)

Picture Elements

EIA:510x492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

EIA:510x492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

Resolution 420 TVL 600 TVL 510 TVL 710 TVL

Min. Illumination 0.05 Lux / F1.2 0.1 Lux / F1.2 0.05 Lux / F1.2 0.1 Lux / F1.2

S/N Ratio More than 48dB

Electronic Shutter EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Gamma 0.45

Iris Control Video / DC Drive

Lens Mount C / CS

Gain Control Auto

Back Light Comp. On / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms (option, for DC type only)

Power Supply

DC DC12V±10%

AC AC24V, AC110V, AC100~240V, DC12V/AC24V Dual (option)

Power

Consumption

DC 110mA max. 138mA max. 109mA max. 115mA max.

AC 2.0W max. 2.5W max. 2.5W max. 2.6W max.

Operating Temp. -10°C ~ 50°C

112.5 mm

50 mm

46 mm

88 mm

Camera Kit

Features

‧Sony Super HAD CCD sensor

‧Camera kit with mini size

‧Built-in Audio function

‧Furnished with lens and mounting bracket

Model No. RYK-264K RYK-569K

Image Device 1/4" Color Sony Super HAD 1/3" B/W CCD

Picture Elements NTSC:510x492, PAL:500x582 EIA:510x492, CCIR:500x582

Resolution 330 TVL 400 TVL

Min. Illumination 0.5 Lux / F2.0 0.3 Lux / F2.0

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/120,000, CCIR:1/50~1/120,000

Gamma 0.45

Lens Furnished Board Lens 3.6mm / F2.0 (option:3.5~8mm / F1.4~C), CS mount

White Balance Auto

－

Gain Control Auto

Back Light Comp.

－

On / Off

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms

Mounting Bracket Metal

Power Supply DC12V±10%

Power Consumption 117mA max. 100mA max.

Operating Temp. -10°C ~ 50°C

50.2 mm

62 mm15.5 mm

43.2 mm

117.5 mm

99.5 mm

Color Camera B/W Camera

IR Camera Selection Guide

IR Camera

Picture Model No. Sensor

Illuminate

Distance

IR-LED IP TVL Min Illumination Lens Voltage Page

RYK-2F49L5

1/3” CL

50M 84 66

380 0.2 Lux

Board Lens DC, AC 15

RYK-2F85L5 470 0.3 Lux

RYK-3F41L5

1/3” BW

420 0.1 Lux

RYK-3F43L5 600 0.2 Lux

RYK-2V87C

1/3” CL

40M 56 66

380

0.1 Lux Board Lens DC, AC 16

1/3” BW DSP (EX-View) 420

RYK-2V85C

1/3” CL 470

1/3” BW DSP (EX-View) 420

RYK-2R49VF3(VF9)

1/3” CL

20M 24 66

380 0.2 Lux

Vari Focal

DC 17

RYK-2R85VF3(VF9) 470 0.3 Lux

RYK-2R49XVR3

1/3” CL

(EX-View)

380 0.05 Lux

Vari Focal

(ICR)

RYK-2R85XVR3 470 0.15 Lux

RYK-2L49

1/3” CL

20M 24 67

380 0.2 Lux

Board Lens DC, AC 18

RYK-2L85 470 0.3 Lux

RYK-3L41

1/3” BW

420 0.1 Lux

RYK-3L43 600 0.2 Lux

RYK-2Q49L2

1/3” CL

20M 24

380 0.2 Lux

Board Lens DC, AC 19

RYK-2Q49L3 30M 36

RYK-2Q85L2

20M 24

470 0.3 Lux

RYK-2Q85L3 30M 36

RYK-3Q41L2

1/3” BW

20M 24

420 0.1 Lux

RYK-3Q41L3 30M 36

RYK-3Q43L2 20M 24

600 0.2 Lux

RYK-3Q43L3 30M 36

RYK-2B49

1/3” CL

10M 12 67

380 0.2 Lux

Board Lens DC 20

RYK-2B85 470 0.3 Lux

RYK-3B41

1/3” BW

420 0.1 Lux

RYK-3B43 600 0.2 Lux

RYK-2A47L 1/4” CL 10M 8

－

330 0.5 Lux Board Lens DC 21

50M IR Camera

Features

‧Built-in 84 pieces IR-LED

‧Effective range up to 50M

‧ Weatherproong criterion IP 66

‧ AC type (option)

104.7 mm 182.5 mm

113 mm

Model No. RYK-2F49L5 RYK-2F85L5 RYK-3F41L5 RYK-3F43L5

Image Device

1/3" Color Sony

Super HAD

1/3" Color Sony

Super HAD (Hi-Res.)

1/3" B/W Sony

Super HAD

1/3" B/W Sony

Super HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

EIA:510x492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

Resolution 380 TVL 470 TVL 420 TVL 600 TVL

Min. Illumination

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

0.3 Lux / F2.0 (Day),

0 Lux (IR On)

0.1 Lux / F2.0 (Day),

0 Lux (IR On)

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Gamma 0.45

Lens Furnished Board Lens 12mm / F2.0 (option:16mm)

White Balance Auto

－

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Infrared Luminary 84 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 50 M

Waterproong Criterion IP 66

Power Supply DC12V±10%, AC24V, AC100~240V (option)

Power Consumption

IR On: 1458mA max.

IR Off: 125mA max.

IR On: 1050mA max.

IR Off: 200mA max.

IR On: 1450mA max.

IR Off: 117mA max.

IR On: 1450mA max.

IR Off: 117mA max.

Operating Temp. -10℃ ~ 50℃

■

Infrared Illuminator Model:

Model No. Description

RYK-8800 30M Infrared Illuminator, Built-in 98 pieces IR-LED, IP 66, DC or AC voltage (option)

RYK-8801 50M Infrared Illuminator, Built-in 98 pieces IR-LED, IP 66, DC or AC voltage (option)

Infrared Illuminator

RYK-88 00/8 801

IR Camera

40M IR Camera

Features

‧Dual CCD (Color & B/W) camera are exchanged

automatically in day time and night time

‧Hi-Res.colorcamerafordaytimetoprovidetrue

colorandclearpicture,EX-ViewBWcamerafor

nighttimetoenhancesensitivityoflowlight

‧Built-in 56 pieces IR-LED

‧Effective range up to 40M

‧Weatherproo ng criterion IP 66

‧AC type (option)

107 mm

183.4 mm

112.7 mm

Model No. RYK-2V87C RYK-2V85C

Image Device

Color 1/3” Color Sony Super HAD 1/3” Color Sony Super HAD (Hi-Res.)

B/W 1/3” B/W Sony EX-View HAD 1/3” B/W Sony EX-View HAD

Picture Elements NTSC/EIA:510x492, PAL/CCIR:500x582 NTSC/EIA:768x494, PAL/CCIR:752x582

Resolution

Color 380 TVL 470 TVL

B/W 420 TVL 420 TVL

Min. Illumination 0.1 Lux / F 2.0 (Day), 0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC/EIA:1/60~1/30,000, PAL/CCIR:1/50~1/30,000

Gamma 0.45

Lens Furnished Board Lens 8mm / F2.0 (option:12mm)

White Balance Auto

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Infrared Luminary 56 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 40 M

Waterproo ng Criterion IP 66

Power Supply DC12V±10%, AC24V, AC100~240V (option)

Power Consumption IR On: 700mA max. / IR Off: 140mA max.

Operating Temp. -10°C ~ 50°C

20M Vari-Focal IR Camera

Features

‧Built-in 24 pieces IR-LED

‧Effective range up to 20M

‧Built-in Vari-Focal Lens

‧Day & Night (option: IR-Cut lter Removable, ICR)

‧Weatherproong criterion IP 66

68.8 mm

87.9 mm75 mm

48.5 mm

118.5 / 56.5 mm

Model No. RYK-2R49VF3(VF9) RYK-2R49XVR3 RYK-2R85VF3(VF9) RYK-2R85XVR3

Image Device

1/3” Color Sony

Super HAD

1/3” Color Sony

EX-View HAD

1/3” Color Sony

Super HAD (Hi-Res.)

1/3” Color Sony

EX-View HAD (Hi-Res.)

Picture Elements NTSC:510x492, PAL:500x582 NTSC:768x494, PAL:752x582

Resolution 380 TVL 470 TVL

Min. Illumination

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

0.05 Lux / F2.0 (Day),

0 Lux (IR On)

0.3 Lux / F2.0 (Day),

0 Lux (IR On)

0.15 Lux / F2.0 (Day),

0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000

Gamma 0.45

Lens Furnished

VF3 model : Vari-Focal 3.7~12mm / F1.6~3.0, Wide:71.6°x55.8°, Tele:23.8°x17.9° (HxV)

VF9 model : Vari-Focal 9.0~22mm / F2.0~360, Wide:29.2°x21.7°, Tele:13.0°x9.7° (HxV)

VR3 model : Vari-Focal 3.7~12mm (ICR) / F1.6~3.0, Wide:71.6°x55.8°, Tele:23.8°x17.9° (HxV)

White Balance Auto

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Infrared Luminary 24 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 20 M

Waterproong Criterion IP 66

Power Supply DC12V±10%

Power Consumption IR On: 430mA max. / IR Off: 210mA max. IR On: 400mA max. / IR Off: 180mA max.

Operating Temp. -10°C ~ 50°C

IR Camera

20M IR Camera

Features

‧Built-in 24 pieces IR-LED

‧Effective range up to 20M

‧Weatherproong criterion IP 67

‧AC type (option)

82 mm

154 mm

110 mm

77 mm

Model No. RYK-2L49 RYK-2L85 RYK-3L41 RYK-3L43

Image Device

1/3" Color Sony

Super HAD

1/3" Color Sony

Super HAD (Hi-Res.)

1/3" B/W Sony

Super HAD

1/3" B/W Sony

Super HAD (Hi-Res.)

Picture Elements NTSC:510x492, PAL:500x582 NTSC:768x494, PAL:752x582 EIA:510x492, CCIR:500x582 EIA:768x494, CCIR:752x582

Resolution 380 TVL 470 TVL 420 TVL 600 TVL

Min. Illumination

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

0.3 Lux / F2.0 (Day),

0 Lux (IR On)

0.1 Lux / F2.0 (Day),

0 Lux (IR On)

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Gamma 0.45

Lens Furnished Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm)

White Balance Auto

－

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Infrared Luminary 24 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 20 M

Waterproong Criterion IP 67

Power Supply DC12V±10% (option: AC24V, AC110~240V)

Power Consumption

IR On: 567mA max.

IR Off: 125mA max.

IR On: 420mA max.

IR Off: 200mA max.

IR On: 542mA max.

IR Off: 108mA max.

IR On: 542mA max.

IR Off: 117mA max.

Operating Temp. -10°C ~ 50°C

20M / 30M IR Camera

Features

‧Built-in 24 / 36 pieces IR-LED

‧Effective range up to 20M / 30M

‧Weatherproong criterion IP 66

‧AC type (option)

68 mm

123 mm

105 mm

68 mm

118.5 / 56.5 mm

Model No.

RYK-2Q49L2 RYK-2Q85L2 RYK-3Q41L2 RYK-3Q43L2

RYK-2Q49L3 RYK-2Q85L3 RYK-3Q41L3 RYK-3Q43L3

Image Device

1/3" Color Sony

Super HAD

1/3" Color Sony

Super HAD (Hi-Res.)

1/3" B/W Sony

Super HAD

1/3" B/W Sony

Super HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

EIA:510x492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

Resolution 380 TVL 470 TVL 420 TVL 600 TVL

Min. Illumination

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

0.3 Lux / F2.0 (Day),

0 Lux (IR On)

0.1 Lux / F2.0 (Day),

0 Lux (IR On)

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Gamma 0.45

Lens Furnished

L2 model: Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm)

L3 model: Board Lens 6.0mm / F2.0 (option:8/12/16mm)

White Balance Auto

－

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Infrared Luminary L2 model: 24 pieces, L3 model: 36 pieces

Illuminate Distance L2 model: 20M, L3 model: 30M

Wavelength 850 nm

Waterproong Criterion IP 66

Power Supply DC12V±10% (option: AC24V, AC110~240V)

Power

Consumption

IR On: 567mA max.

IR Off: 125mA max.

IR On: 420mA max.

IR Off: 200mA max.

IR On: 542mA max.

IR Off: 108mA max.

IR On: 542mA max.

IR Off: 117mA max.

IR On: 692mA max.

IR Off: 125mA max.

IR On: 540mA max.

IR Off: 200mA max.

IR On: 667mA max.

IR Off: 108mA max.

IR On: 667mA max.

IR Off: 117mA max.

Operating Temp. -10℃ ~ 50℃

IR Camera

10M IR Camera

Features

‧Built-in 12 pieces IR-LED

‧Effective range up to 10M

‧Weatherproong criterion IP 67

(exclude Audio type)

67.6 mm

56.4 mm

70.5 mm

118.5 / 56.5 mm

55 mm

61.5~74.5 mm

37 mm

IR Camera Infrared Illuminator

Model No. RYK-2B49 RYK-2B85 RYK-3B41 RYK-3B43

Image Device

1/3" Color Sony

Super HAD

1/3" Color Sony

Super HAD (Hi-Res.)

1/3" B/W Sony

Super HAD

1/3" B/W Sony

Super HAD (Hi-Res.)

Picture Elements

NTSC:510x492,

PAL:500x582

NTSC:768x494,

PAL:752x582

EIA:510x492,

CCIR:500x582

EIA:768x494,

CCIR:752x582

Resolution 380 TVL 470 TVL 420 TVL 600 TVL

Min. Illumination

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

0.3 Lux / F2.0 (Day),

0 Lux (IR On)

0.1 Lux / F2.0 (Day),

0 Lux (IR On)

0.2 Lux / F2.0 (Day),

0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000 EIA:1/60~1/100,000, CCIR:1/50~1/110,000

Gamma 0.45

Lens Furnished Board Lens 3.6mm / F2.0 (option:4.3/6/8/12/16mm)

White Balance Auto

－

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms (option)

Infrared Luminary 12 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 10 M

Waterproong Criterion IP 67

Power Supply DC12V±10%

Power Consumption

IR On: 292mA max.

IR Off: 117mA max.

IR On: 230mA max.

IR Off: 150mA max.

IR On: 283mA max.

IR Off: 117mA max.

Operating Temp. -10°C ~ 50°C

■

Infrared Illuminator Model:

Model No. Description

RYK-9041 10M Infrared Illuminator, Built-in 24 pieces IR-LED, IP 67, DC voltage

Infrared Illuminator

RYK-90 41

2121

10M IR Camera

Features

‧Built-in 8 pieces IR-LED

‧Effective range up to 10M

‧DC voltage

‧Indoor use

‧Built-in mounting bracket and connecting cable

72 mm 96.6 mm

47.5 mm

50.4 mm

59.5 mm

Model Name RYK-2A47L

Image Device 1/4” Color Sony Super HAD

Picture Elements NTSC:510x492, PAL:500x582

Resolution 330 TVL

Min. Illumination 0.5 Lux / F2.0 (Day), 0 Lux (IR On)

S/N Ratio More than 48dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000

Gamma 0.45

Lens Furnished Board Lens 3.6mm / F2.0 (option:4.3/6/8/12mm)

White Balance Auto

Gain Control Auto

Sync. System Internal

Video Output 1 Vp-p / 75 Ohms

Audio Output 2 Vp-p / 50 Ohms (option)

Infrared Luminary 8 pieces IR-LED

Wavelength 850 nm

Illuminate Distance 10 M

Power Supply DC12V±10%

Power Consumption IR On: 250mA max. / IR Off: 125mA max.

Operating Temp. -10°C ~ 50°C

Dome Camera

Dome Camera Selection Guide

Picture Model No. Feature Sensor TVL Min Illumination Lens Voltage Page

RYK-2E00(A&B) Outdoor Speed Dome

1/4” CL

470 0.7 Lux 22x Zoom

DC, AC 23

RYK-2E01(A&B)

Outdoor Speed Dome

ICR

330

0.1 Lux (Night / BW)

0.3 Lux (Day / Color)

22x Zoom

(ICR)

RYK-2E02(A&B)

1/4” CL

(EX-View)

470

0.01 Lux (Night / BW)

0.5 Lux (Day / Color)

RYK-2E03(A&B)

35x Zoom

(ICR)

RYK-2E00 Indoor Speed Dome

1/4” CL

470 0.7 Lux 22x Zoom

DC 24

RYK-2E01

Indoor Speed Dome

ICR

330

0.1 Lux (Night / BW)

0.3 Lux (Day / Color)

22x Zoom

(ICR)

RYK-2E02

1/4” CL

(EX-View)

470

0.01 Lux (Night / BW)

0.5 Lux (Day / Color)

RYK-2E03

35x Zoom

(ICR)

RYK-2E49

Pan / Tilt 1/3” CL

380 0.2 Lux

Board Lens DC 26

RYK-2E85 470 0.3 Lux

RYK-2S90LVR3

Vandal-proof

WDR / ICR / LED

1/3” CL

470

0.1 Lux (Night / BW)

0.001 Lux (DSS)

Vari Focal

(ICR)

RYK-2S90LVF3

Vandal-proof

WDR / LED

Vari Focal

RYK-2S49LVF3

Vandal-proof

LED

380 0.2 Lux

RYK-2S85LVF3 470 0.3 Lux

RYK-2S49XLVR3

Vandal-proof

ICR / LED

1/3” CL

(EX-View)

380 0.05 Lux

Vari Focal

(ICR)

RYK-2S85XLVR3 470 0.15 Lux

RYK-2H49LVF3/1

Vandal-proof

LED

1/3” CL

380 0.2 Lux

Vari Focal

DC 29

RYK-2H85LVF3/1 470 0.3 Lux

RYK-2H49XLVR3/1

Vandal-proof

ICR / LED

1/3” CL

(EX-View)

380 0.05 Lux

Vari Focal

(ICR)

RYK-2H85XLVR3/1 470 0.15 Lux

RYK-2H49L

Vandal-proof

LED

1/3” CL

380 0.2 Lux

Board Lens

RYK-2H85L 470 0.3 Lux

RYK-2H49VF3(VF9)

Vandal-proof 1/3” CL

380 0.2 Lux

Vari Focal

DC, Dual 30

RYK-2H85VF3(VF9) 470 0.3 Lux

RYK-2H49 380 0.2 Lux

Board Lens

RYK-2H85 470 0.3 Lux

RYK-2K49LVF3/1

LED 1/3” CL

380 0.2 Lux

Vari Focal

DC 31

RYK-2K85LVF3/1 470 0.3 Lux

RYK-2K49XLVR3/1

ICR / LED

1/3” CL

(EX-View)

380 0.05 Lux

Vari Focal

(ICR)

RYK-2K85XLVR3/1 470 0.15 Lux

RYK-2G49L

LED

1/3” CL

380 0.2 Lux

Board Lens DC 32

RYK-2G85L 470 0.3 Lux

RYK-3G41L

1/3" BW

420 0.1 Lux

RYK-3G43L 600 0.2 Lux

RYK-2G49VF3(VF9)

Standard Type

1/3” CL

380 0.2 Lux

Vari Focal DC, Dual

RYK-2G85VF3(VF9) 470 0.3 Lux

RYK-2G49

1/3” CL

380 0.2 Lux

Board Lens DC

RYK-2G85 470 0.3 Lux

RYK-2449VF3(VF9)

Standard Type

1/3” CL

380 0.2 Lux

Vari Focal

DC 34

RYK-2485VF3(VF9) 470 0.3 Lux

RYK-2411

1/3” CL

380 0.2 Lux

Board Lens

RYK-2485 470 0.3 Lux

RYK-2J49

Vandal-proof

Mini Size

1/3” CL

380 0.2 Lux

Board Lens DC 35

RYK-2J85 470 0.3 Lux

RYK-3J41

1/3" BW

420 0.1 Lux

RYK-3J43 600 0.2 Lux

RYK-2311

Mini Size

1/3” CL

380 0.2 Lux

RYK-2385 470 0.3 Lux

RYK-3341

1/3” BW

420 0.1 Lux

RYK-3343 600 0.2 Lux

+ 50 hidden pages
