Page 1
CHANGING
THE WAY
BUSINESS
COMMUNICATES
Pocket Guide
www.sonybiz.net
Page 2
DIGITAL CAMCORDERS DIGITAL CAMCORDERS COMPACT DIGITAL CAMCORDERS STUDIO VTRs
• Compact & lightweight: 6.2 kg
(13 lb 10 oz) including viewfinder,
microphone, lens, battery and tape
• Low power consumption: 21 W
(without viewfinder)
• Three 1/2-inch type Power HAD
CCDs for high sensitivity (F13 at
2000 lx), Low smear level (-115 dB),
high S/N ratio (62 dB) and high
horizontal resolution (800 TV lines)
• Minimum illumination:
0.4 lx with F1.4
• Hyper Gain (36 dB)
• 4:3 aspect ratio
• Flexible Safety zone marker 4:3
mode: OFF, 13:9, 14:9, 15:9, 16:9
• SetupNavi™ function for camera
setup file storage
• Film-Like mode (Setup File)
• User friendly side panel design
• Silver Support supplied as standard
DSR-390P
• 16:9 / 4:3 Switchable Camcorder
• Compact and lightweight: 6.0 kg
(13 lb 4 oz) including viewfinder,
microphone, lens, battery and tape
• Low power consumption: 21 W
(without viewfinder)
• Three 2/3-inch Power HAD WS™
16:9 CCDs providing high quality
images with low smear level, high
sensitivity, high S/N ratio (61 dB)
and high horizontal resolution
(980/850 TV lines in 16:9/4:3 mode)
• Hyper Gain (36 dB or 42 dB
selectable)
• Sensitivity: F11 at 2000 lx
• Minimum illumination: 0.5 lx
• Flexible safety zone marker
In 4:3 mode: OFF, 13:9, 14:9, 15:9, 16:9
In 16:9 mode: OFF, 4:3, 13:9, 14:9, 15:9
• SetupNavi™ function for camera
setup file storage
• Film-Like mode (Setup File)
• User friendly side panel design
• Silver Support supplied as standard
One-piece
Camcorder
One-piece
Camcorder
DSR-570WSP DSR-250P DSR-PDX10P DSR-25
Page 3
• High-resolution 1.5-inch black
& white viewfinder
• 2.5-inch (200,000 dot) colour LCD
monitor
• 12x lens* with Super SteadyShot™
system
• 16:9 recording mode available
(electronically processed)
• Recording and playback capability
with standard and mini-size DVCAM
and DV tapes (SP mode only)
• Long recording time: 184 minutes
with a standard-size cassette in
DVCAM mode, or 270 minutes in DV
SP mode
• Digital still camera functions with
Memory Stick™
• Time code preset capability
• i.LINK (DV In/Out) interface providing
a single cable connection to
simultaneously transfer audio, video
and command signals
• Silver Support supplied as standard
* Digital zoom of 24x or 48x available via menu
selection.
• Compact and lightweight:
4.4 kg (9 lb 11 oz)
• 1/3-inch CCD for accurate
colour reproduction
• DSP (Digital Signal Processing)
• Combination of DXC-D50P Digital
Video Camera and DSR-1P
Dockable Recorder equivalent to
one-piece camcorder
• Newly developed 2/3-inch three
Power HAD EX CCDs
• 12 bit A/D conversion
• Advanced Digital Signal Processing
(DSP)
• Creative image control - Knee
Saturation Control, Adaptive
Highlight Control, Low Key
Saturation, Cross Colour
Suppression and Skin-Tone Detail
• Horizontal resolution : 920 TV lines
• Minimum illumination : 0.5 lx
• Sensitivity : F11 at 2000 lx
• S/N ratio: 63 dB
• EZ Functions for minimum setup
procedures
• Memory Stick system for
storage/recall of camera parameters
Two-piece Camcorder
One-piece
Camcorder
DXC-D50P & DSR-1P DSR-PD170P DSR-45P
NEW
Page 4
• Hybrid 2.5-inch colour LCD panel
(211,200 dots)
• Black & white viewfinder
(180,000 dots LCD)
• 12x zoom lens* with optical Super
SteadyShot system
• On-handle zoom lever and Rec
Start/Stop button
• 16:9 recording mode (electronically
processed)
• DVCAM and DV (SP mode) formats
recording and playback
• i.LINK and Analogue In/Out
interfaces
• Compact & lightweight : 1.5 kg
(excl. microphone, battery, tape)
• Wide Conversion lens (VCL-HG0758)
supplied as standard
• Silver Support supplied as standard
* Digital zoom of 24x or 48x available via menu
selection.
• Enhanced 16:9 capability
(real 16:9 shooting quality)
• 2 XLR audio input connectors
for professional microphones
• USB Streaming (capability to stream
Video and Audio through USB port)
available in camera and VCR mode
• 3.5 inch type 240,000 colour LCD
monitor with touch panel function
(Spot focus, Spot AE, Playback
Zoom, Memory play)
• 180,000 dot precision Black and
White LCD Viewfinder
• Optical Super SteadyShot™
• DVCAM and DV (SP mode)
recording and playback formats
• High resolution picture recording
(640 x 480 / 1152 x 864 dots)
• MPEG movie recording up to
85 minutes on a 128 MB Memory
Stick
• i.LINK and Analogue In/Out
interfaces
• Silver Support supplied as standard
• Very compact body (the smallest
3 CCD DVCAM camcorder)
• 1/4.7-inch Mega Pixel Advanced
HAD three CCD type
• 14 Bits DXP Processing
(Digital Extended Processor)
• 1/3-inch three CCDs with high
sensitivity and S/N ratio
• 2ch XLR audio inputs for
professional microphone
Compact
Camcorder
Handycam
®
-style
Camcorder
NEW
Page 5
• Recording and playback capability
of the DV format (SP mode only)*
1
• Long recording time: up to 184
minutes with a standard-size
cassette, 40 minutes with a mini-size
cassette
• Recording and playback capability
of both NTSC/PAL signals*
2
• i.LINK (DV) interface for simultaneous
transfer of audio, video, and
command signals
• LANC and Control S interface
• Time code/ User bit preset
• Time code IN through DV IN
• Built-in 2-inch type (123,200 dot)
colour LCD monitor
• Duplication function (Including the
duplication of Cassette Memory data)
• Power-on recording and playback
capabilities
• Compact size (half-rack size width,
2U height)
• Silver Support supplied as standard
*1 When recording in DV (SP) format, the transition
between cut to cut may not be smooth. In addition, when the recording format is switched
between DVCAM and DV, the transition may not
be recorded smoothly.
*2 The DSR-25 is not equipped to convert signals
from NTSC to PAL, or vice versa.
• Recording and playback capability
of the DV format (SP mode only)*
1
• Long recording time: up to 184
minutes with a standard-size
cassette, 40 minutes with a mini-size
cassette
• Full range of analogue Video IN/OUT:
Component, Composite, S-Video
• Four channel independent Audio
IN/OUT with XLR connectors for
Audio OUT
• i.LINK (DV) interface for
simultaneous transfer of audio,
video, and command signals
• RS-422A remote control interface*
2
• RS-232C interface for basic control
from a PC
• Built-in 2-inch type (123,200 dot)
colour LCD monitor
• Time code/ User bit preset
• Time code IN through DV IN
• Silver Support supplied as standard
*1 When recording in DV (SP) format, the transition
between cut to cut may not be smooth. In addition, when the recording format is switched
between DVCAM and DV, the transition may
not be recorded smoothly.
*2 The DSR-45P is not equipped with the synchro-
nisation capability, therefore is recommended
to be used only as a source feeder in A/B roll
editing.
Recorder
Recorder
Page 6
• Recording and playback of DV
format tapes (SP mode only)*
1
• Long recording time: up to 184
minutes with a standard-size
cassette and 40 minutes with a
mini-size cassette
• NTSC/PAL compatible*
2
in both Rec
and Play mode
• Composite and S Video inputs
• i.LINK (DV In/Out) interface providing
a single cable connection to
simultaneously transfer audio, video
and command signals
• Unique design enables both
horizontal and vertical installation
• LANC and Control S terminals
• Auto repeat function
• DC power operation
• Supplied RMT-DS11 Wireless
Remote Commander
• Silver Support supplied as standard
*1 When recording in DV (SP) format, the transition
between cut to cut may not be smooth. In addition, when the recording format is switched
between DVCAM and DV, the transition may
not be recorded smoothly.
*2 The DSR-11 does not convert signals from
NTSC to PAL, or vice versa.
• Wide range of digital slow speed
from -0.5 to +0.5 times normal speed
• Versatile digital interfaces*2: SDI,
SDTI (QSDI), i.LINK (DV In/Out) and
AES/EBU digital audio
• Excellent jog audio capability
• DMC (Dynamic Motion Control)
provides noiseless slow-motion
playback
• Built-in SMPTE/EBU time code and
VITC generator/reader
• Menu keys on front panel for picture
search
• RS-422A remote control interface
• Compact, half-rack size
• Silver Support supplied as standard
*1 When recording in DV (SP) format, the transition
between cut to cut may not be smooth. In addition, when the recording format is switched
between DVCAM and DV, the transition may not
be recorded smoothly.
*2 Optional Input/Output Boards required.
STUDIO VTRs
DSR-1500AP
Editing Recorder
DSR-11
Recorder
• Recording and playback capability
of the DV format (SP mode only)*
1
• Playback of DVCPRO format
• Long recording time: up to 184
minutes with a standard-size
cassette and 40 minutes with a
mini-size cassette
Page 7
• VTR-to-VTR editing without external
controllers
• Wide range of digital slow speed
from -1.0 to +1.0 times normal
speed
• Versatile digital interfaces : SDI,
SDTI (QSDI), i.LINK (DV In/Out)*
2
and AES/EBU digital audio
• Excellent jog audio capability
• DMC (Dynamic Motion Control)
provides noiseless slow-motion
playback
• Channel condition monitoring
• Built-in SMPTE/EBU time code
and VITC generator/reader
• RS-422A remote control interface
• Pre-read playback capability
to perform audio mix/swap and
over dubbing without delay between
video and audio signals
• Jog/Shuttle dial on front panel
• Silver Support supplied as standard
*1 Can cover mis-aligned tapes without picture
noise.
*2 Optional Input/Output board required.
DSR-2000P
Editing Recorder
• Playback capability of DV (SP and
LP mode) and DVCPRO format
without mechanical adaptor or menu
setting changes
• Non-tracking playback capability*
1
• Pre-read editing capability
• Wide range of digital slow speed
from -0.5 to +0.5 times normal
speed
• Channel condition monitoring
• Versatile digital interfaces* : SDI,
SDTI (QSDI), i.LINK (DV In/Out)
and AES/EBU digital audio
• Excellent jog audio capability
• DMC (Dynamic Motion Control)
provides noiseless slow-motion
playback
• Built-in SMPTE/EBU time code
and VITC generator/reader
• RS-422A remote control interface
• Pre-read playback capability
to perform audio mix/swap and
over dubbing without delay between
video and audio signals
• Jog/Shuttle dial on front panel
• Silver Support supplied as standard
* Optional Input/Output boards required.
DIGITAL VTRs
DSR-1800P/1600P
Editing
Recorder/Player
• Playback capability of DV (SP mode)
and DVCPRO format without
mechanical adaptor or menu setting
changes
Page 8
• Clip segment playback for playout
of designated video segment
• DMC playback with the range of
± x2 times normal speed
• Continuous loop recording
• Pre-alarm recording (automatic
recording triggered by an external
alarm signal)
• Interval recording
• i.LINK interface with AV/C and
SBP2 protocols
• Versatile interfaces (i.LINK, SDI,
Component, Y/C, Composite,
AES/EBU, Analogue audio, TC I/O,
RS-422A, Ethernet)
• Network capability (file transfer
using FTP via 100Base-T Ethernet)
• Silver Support supplied as standard
• DVCAM recording for over 6 hours
(80GB hard drive)
• Compact & lightweight (Half-rack
size, 6 kg)
• Simultaneous recording & playback
• Compact hard drive unit (2.5-inch,
40GB hard drive) for use with
DVCAM and Sony DV camcorders
• Camera output can be recorded to
the DSR-DU1’s hard drive in parallel
to the recordings made on the
camcorder’s tape via i.LINK (DV)
connection.
HARD DISK UNITS
DSR-DU1
Hard Disk Unit
DSR-DR1000P
Hard Disk
Recorder
• Recording in 25Mb/s DVCAM/DV
stream for up to three hours
• Capable of docking directly to the
rear of DVCAM camcorders*
1
by use
of the CA-DU1 optional Camera
Adaptor
• Can interface with a variety of
i.LINK(DV) equipped Sony hand-held
type DVCAM/DV camcorders via its
i.LINK(DV) connector
• The DSR-DU1’s DV video/audio files
can be accessed from a compatible
i.LINK equipped non-linear editor
• i.LINK interface with AV/C and SBP2
protocols
• Cache recording (8 seconds)
• Interval recording
• 525 (NTSC) / 625 (PAL) Switchable*
2
• Silver Support supplied as standard
*1 DSR-570WSP/370P/390P/500WSP/300AP/250P.
*2 Signal conversion from 525(NTSC) to 625(PAL),
or vice versa is not possible.
Page 9
5 additional reasons
to choose Sony DVCAM
Repair within 7 days
Sony will collect, repair and return the unit to the
customer’s preferred location within 7 working days. So,
minimum downtime, increased confidence and the ability
to plan your business are guaranteed.
Loan
If the faulty equipment cannot be repaired in time, the
DVCAM hotline will contact the customer and arrange to
have a loan unit delivered. Arrangements will be made to
collect the loan unit as soon as confirmation is received
that the repair has been carried out satisfactorily.
Collection Anywhere
In the event of equipment failure, Sony will arrange
collection of the faulty unit directly from, and delivery of
the repaired unit directly to the customer’s location - anywhere in mainland EU, Norway or Switzerland. That
makes it simpler, quicker and even more convenient for
the customer.
Operational Phone Call Centre
Operational phone support is provided to give advice and
help so that the user can get the most out of their DVCAM
equipment and maximise its performance. Our telephone
support is available from Monday to Friday and in 5
languages: English, French, German, Italian and Spanish.
2 Years Support
The Silver Support Pack extends the support period from
the standard 1-year warranty to two years. Not only that,
but extra features and services are also included.
Page 10
Sony address/contact details/dealer stamp
www.sonybiz.net/dvcam
SONY BUSINESS EUROPE
SONY IS A REGISTERED TRADEMARK OF THE SONY CORPORATION, JAPAN.
FEATURES AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
I.LINK, DVCAM, STEADYSHOT, HANDYCAM, MEMORYSTICK, POWER HAD WS,
POWER HAD EX AND SETUPNAVI ARE TRADEMARKS OF SONY CORPORATION.
CA DVCAM POCKET GUIDE/GB-15/10/2003
Loading...
