NTM-DA1
Compact and powerful, this 2.4 GHZ digital baby monitor lets you relax with
condence while your child rests. Better yet, it works up to 900 feet away
and features easy-to-use wall and table mounts. There’s also an out-ofrange warning if you venture too far and voice-activated LED lights that
display the severity of your baby’s stirrings.
Digital Audio Baby Monitor
Simple to use yet so compact and convenient, the NTM-DA1 lets you keep track of baby, while
tackling life’s daily chores.
Extended Range
2.4GHz digital broadcast with auto channel select delivers crystal clear audio up to 990 (270m).
1
Warning Alarms
Two alarms will illuminate and sound, even if the volume is set to zero, when:
•You are out of range.
•The battery is running out.
Water resistant
Enjoy the added reliability of built-in water resistance.
2
Voice-Activated Receiver
Selectable ON/OFF voice activation mode eliminates most background noise while saving battery
life. When active, the speaker sounds only when the baby stirs.
Sound Sensitive LED’s
Multiple LEDs on the receiver illuminate to indicate the intensity of your baby’s stirrings.
Rechargeable Battery
With a built-in rechargeable Lithium-Ion battery, you can keep an ear on your child for up to 16 hours
of battery life (Voice Activation O).
1
Convenient Belt-Clip/Stand
Keep the receiver by your side when attending to chores or ip out to stand up the receiver on a
counter or end table when taking a breather or relaxing with friends.
Mounting Flexibility
The microphone module can be mounted easily on the wall or set on at surface.
Specications
Audio
Antenna System PWB printed
Frequency Band Digital 2.4 GHz
Full Range
Speaker Size
Convenience
Alarm
Approximately 1.10 inches (28 mm) diameter
Activity Lights,
Out of Range Indicator,
and Low Battery Power
Page 2
General
Design Nursery Monitor with belt clip
Inputs and Outputs
DC-In 1 (receiver charging), 1 (transmitter module power)
Power
Battery Life
(Approx)
Battery Type Receiver: Ni-MH Rechargeable Battery (Built-In)
Power
Consumption (in
Operation)
Power
Requirements
Audio Playback: Approximately 16 hours
Charge Time: Approximately 7 hours
Transmitter: Maximum load: 0.85 W
Receiver: Maximum load: 2.5 W; Normal mode: 0.85 W
Input: 100-240 V AC, 50/60 Hz, 0.3 A
Output: 5 V, 0.4A
Weights and Measurements
Transmitter: W 2 1/8" x H 2 1/2" x D 2 1/4" (53 x 62.3 x
Dimensions
(Approx.)
Weight (Approx.)
56.1 mm);
Receiver: W 2 1/8" x H 4" x D 1 7/16" (51.1 x 99.1 x 36.1
mm);
AC Adaptor: W 2 1/2" x H 1 1/16" x D 2 3/4" (63 x 26.8 x
44 mm)
Transmitter: 1. 31 oz (41 g); Receiver: 3.21 oz (100 g);
AC Adaptor: 2.05 oz. (64 g)
Accessories
Transmitter (1)
Supplied
Accessories
Receiver (1)
AC Adaptor (x2)
Owner's Manual
Warranty Terms (included in manual)
1. Actual performance varies based on settings, environmental conditions, and usage.
2. Do not allow continuous contact with water
