Professional LCD Monitor

LUMA Family Catalog

2007

A Comprehensive Line of
– the Sony LUMA Series

Since its introduction in 2003, the Sony LUMA™ Series of professional LCD monitors
has been offered in a variety of types and sizes, suiting applications in the studio and
in the field. As a leading company in the HD CRT monitor market, Sony extends the
LUMA Series by adding three new HD-compatible LCD monitors: the LMD-2450W,
LMD-2050W, and LMD-2030W.

The high-grade one-piece type LMD-2450W and LMD-2050W incorporate a newly
designed DSP (Digital Signal Processor) for high-end picture monitoring, while the
entry-level one-piece type LMD-2030W offers a cost-effective solution for wedding
and event videography applications.

Entry-level One-piece Type Page 8

Multi-display Type Page 12

True Professional LCD Monitors

All three monitors are SD/HD compatible, and the high-grade LUMA monitors accept PC
signals via a digital DVI-D or an analog HD-15 interface. The high-grade LMD-2450W and
LMD-2050W offer a variety of video interfaces up to HD-SDI, and the entry-level
LMD-2030W accommodates an HDMI interface as standard.

At the same time, the LUMA Series continues to support the well-accepted Sony hand-held
type and multi-display type monitors for a variety of picture monitoring needs and styles.

With the strength of Sony's video expertise, the Sony LUMA Series is sure to meet a variety
of picture monitoring applications from broadcast and postproduction to medical and
surveillance applications.

High-grade One-piece Type Page 4

Handheld Type

Page 10

High-grade One-piece Type

The LMD-2450W and LMD-2050W are positioned at the top of the LUMA Series. They offer the latest
DSP engine, the market-proven ChromaTRU™ color matching technology, and the high functionality
for which Sony professional video monitors are renowned.
These monitors accept a variety signals in both analog and digital, and HD and SD formats.
Digital HD-SDI and SD-SDI interfaces are provided as options. The LMD-2450W and LMD-2050W are the
best-suited LCD monitors in their class for broadcast and postproduction applications.

Two Panel Sizes

The high-grade one-piece type LUMA monitors are offered in two versions ­the 24-inch LMD-2450W and the 20-inch LMD-2050W. (Viewable area
measured diagonally.)

Model Types

Input Versatility

LMD-2450W

Multi-format Signal Support

The LMD-2450W and LMD-2050W both accept almost any SD or HD video
format, both analog and digital. These include composite NTSC and PAL,
component 480/60i and 575/50i, progressive 480/60P and 576/50P, and high­definition 1080/60i, 1080/50i, 720/60P, 1080/24P, 1080/25P, and 1080/30P.
They also accept 1080/24PsF and 1080/25PsF. Standard interfaces include
analog composite (NTSC/PAL), 525i/625i component and RGB, and Y/C.
Additional inputs can be added by using option boards. Digital interfaces
including HD-SDI and SD-SDI are also offered as optional boards, to meet
budgetary and user needs. The LMD-2450W and LMD-2050W also accept
various types of analog and digital computer signal via the standard HD-15 and
DVI-D interfaces respectively. With their high-performance scan converters, these
monitors can display PC signals from VGA to WUXGA*

*1 WUXGA images are not accepted by the LMD-2050W. Images ranging from WSXGA+ to

1920 x 1080 are down-converted for display on the LMD-2050W.

Input Signals/Input Adaptors

1

.

LMD-2050W

4

High-grade One-piece Type

LMD-2450W/LMD-2050W Connector Panel LMD-2450W/LMD-2050W Option Slots

Signal-interface Options

The LMD-2450W and LMD-2050W accept HD-SDI and
SD-SDI signals via the following optional input adaptors:

BKM-220D, SD-SDI 4:2:2 Input Adaptor*

• SD-SDI signal input (x2)

• SD-SDI monitor output (x1)

• Power consumption: 1.5 W

*1 Embedded audio is supported.

BKM-243HS, HD-SDI/SD-SDI Input Adaptor*

• HD-SDI/SD-SDI signal input (x2)

• HD-SDI/SD-SDI monitor output (x1)

• Power consumption: 2.0 W

• HD-SDI and SD-SDI signals are automatically detected

BKM-227W, NTSC/PAL Input Adaptor

• Composite input/output (x1)

• Y/C input/output (x1)

• Power consumption: 1.8 W

BKM-229X, Analog Component Adaptor

• RGB/ Y/PB/PR input connector (x3)

• EXT SYNC (x1)

• Power consumption: 4.0 W

1

1

Connector Panel

BKM-220D

SD-SDI Input

(BNC x 2)

SD-SDI Monitor Output
(BNC x 1)

Preset Computer Input Frequencies

The LMD-2450W and LMD-2050W are factory preset to accept 32 and
25 typical computer input signal frequencies respectively.

HD15 Input Signal Format

BKM-243HS

BKM-227W

BKM-229X

HD-SDI/SD-SDI Input

(BNC x 2)

COMPOSITE
Input (BNC)

Loop-through
Output (BNC)

R/PRInput (BNC)

HD-SDI/SD-SDI
Monitor Output (BNC x 1)

Y/C

Input

(4-pin mini-DIM)

Loop-through Output
(4-pin mini-DIM

B/P

B

Input (BNC)G/Y Input (BNC)

EXT SYNC (BNC)

)

5

High-grade One-piece Type

Superb Picture Performance

High Purity Color Filters

The LMD-2450W and LMD-2050W use precisely manufactured
RGB color filters, allowing the reproduction of colors with
stunning depth and saturation to create highly natural images.

Accurate Gamma and Stable White Balance
– ChromaTRU Color Processing

For an extra level of color reproduction accuracy, every LCD
panel used in the LMD-2450W and LMD-2050W is precisely
color calibrated at the factory, providing characteristics
consistent with those of CRT displays.
The colorimetry of an LCD display, by nature, can exhibit
inaccurate R, G, B color coordinates and unbalanced R, G, B
gamma curves, which can make precise color matching
between multiple monitors a challenge. These are also the
primary reasons why LCD color tone can slightly differ from
CRT tone.
The LMD-2450W and LMD-2050W solve this problem by
precisely calibrating each LCD panel's light output so that the
R, G, B color coordinates are virtually the same as those of a
CRT monitor. A second calibration is further applied so that
white balance is maintained at a consistent color temperature
throughout all grayscale levels. The result of these precise
calibrations is color reproduction reminiscent of Sony CRT
displays.

CIE Color Coordinates

The CIE u' v' chart is used to evaluate the light output of display
devices. In this diagram, the raw light output of a Sony LCD
panel is compared with that of a Sony CRT. The triangular areas
show their different color reproduction capabilities (Color Space).
The green and red dots indicate the color of light output from a
Sony LCD panel and from a Sony CRT for certain RGB input
signals. Note that the same light color is not obtained for the
same video input. The ChromaTRU process, on the other hand,
reproduces consistent light output extremely close to that of a CRT.

Sophisticated I/P Conversion

The LMD-2450W and LMD-2050W use a motion adaptive I/P
conversion process to achieve conversion results that are
optimized to the picture content - whether it is static or
dynamic. Highly accurate I/P conversion is provided regardless
of signal resolution, for example, whether the input is HD or SD.

Excellent Brightness and Contrast

The LMD-2450W and LMD-2050W both provide
high-brightness, high-contrast images by utilizing super-wide
aperture LCD panels.

Extremely Wide Viewing Angle

The LMD-2450W and LMD-2050W offer the most stable
images within the LUMA Series when viewed from various
angles. They offer a wide viewing angle of 178 degrees,
horizontally and vertically, with virtually no reduction in
picture contrast, color saturation, and hue shift. This allows
precise images to be clearly viewed from various positions and
angles – a critical requirement in professional video monitoring.

6

High-grade One-piece Type

Operational Convenience

Advanced Marker Settings

These monitors can display various area markers, including a
center marker, aspect markers, and a safety zone marker. The
brightness of these markers can be selected from three
different levels: white, gray, and dark gray. Users can also
select either a black or gray matte to fill the outer area of the
aspect markers. These flexible marker controls, together with
the choice of many different aspect markers, make the
LMD-2450W and LMD-2050W extremely convenient display
devices for a variety of shooting scenarios – from standard
video acquisition to digital cinematography.

Marker Variation

Color Temperature

Color temperatures of 9300k, or 6500k, or a user preset
setting can be selected.

Selectable Scan Size for Video Input and Aspect Ratio

The scan size can be selected between 5% over scan and 0%
scan modes. The aspect ratio can be switched between 16:9
and 4:3 according to the input signal.

Stereo Audio Monitoring

The LMD-2450W and LMD-2050W are equipped with stereo
speakers (0.5 W + 0.5 W), which enable the user to monitor
audio.

Protected Controls

The key-inhibit function helps prevent inadvertent operation
from the control panel.

Closed-Caption Decoder

The LMD-2450W and LMD-2050W are equipped with a
closed caption decoder. The closed caption information
embedded in the analog composite and component inputs
can be decoded for display.

Convenient Installation

Mounting Flexibility

Mountable in a 19-inch EIA Standard Rack (LMD-2050W)

The LMD-2050W (8U high) can be rack mounted using the
optional MB-529 Mounting Bracket, although wider than the
19-inch rack.

VESA Mounting

Complying with VESA standards, both the LMD-2450W and
LMD-2050W can easily be mounted (100 x 100 mm pitch) on a
wall or ceiling.

Three-color Tally

The LMD-2450W and LMD-2050W come equipped with a
tally lamp that can be lit via a parallel remote connector.
The status of the signal displayed on the monitor can be
identified by the tally color - red, green, or amber.

Smart APA (Auto Pixel Alignment) for Computer Input

The image size can be automatically adjusted to its optimal
setting with the one-touch APA key.

Parallel Remote Control

The LMD-2450W and LMD-2050W can be controlled
remotely via a parallel remote connector. There are 38
functions in the remote menu (such as the ability to switch
input signals), of which eight can be allocated to the
connector.

Other Features

• WFM and Audio* Level Meter Windows

* Only embedded audio is supported.

• Picture by Picture mode

• H/V Delay Function

• ACC Off

• DC Operation

• Setup Level for Analog Component and NTSC signal

• Sub Control on Contrast, Chroma, Phase, and Brightness

• Blue-Only Mode

• Monochrome Mode

• Auto Chroma/Phase Setup

• Serial Remote (Ethernet, RS-232C, Parallel Remote)

• DVI-D Input

• Power-saving Function (computer input only)

• DCC-2B

7

Entry-level One-piece Type

The LMD-2030W, LMD-1420 and LMD-1410 offer the best quality-per-cost balance for entry-level
applications. The LMD-2030W can accept HD signals via its HDMI interface or analog component
connectors. The LMD-1420 and LMD-1410 are exclusively designed for SD monitoring. All of these
models provide the user-friendly features proven in Sony professional monitors for convenient monitoring
in wedding and event videography, and many other applications.

Two Panel Sizes

The entry-level one-piece type LUMA monitors are offered in three versions:
the LMD-1410 which provides the basic features for SD professional picture
monitoring, the LMD-1420 for more advanced SD monitoring, and the
LMD-2030W with an HD monitoring capability.

Model Types

LMD-2030W

LMD-1420

Input Versatility

All entry-level one-piece type LUMA monitors come equipped with a full range
of analog SD inputs including analog composite NTSC and PAL,
Y/C (S-Video), and 525i/625i component and RGB.
The LMD-2030W and LMD-1420 further handle SD-SDI input by using the
optional BKM-320D SD-SDI input adaptor. Furthermore, the LMD-2030W
offers an HD signal input capability via its standard HDMI and Analog
Component interface.

LMD-1410

8

Entry-level One-piece Type

LMD-2030W Connector Panel

LMD-1420 Connector Panel

LMD-1410 Connector Panel

High Picture Performance

High Purity Color Filters

The entry-level one-piece type LUMA monitors come
equipped with high-purity RGB color filters, allowing the
reproduction of colors with stunning depth and saturation.

Excellent Brightness and Contrast

The entry-level one-piece type LUMA monitors provide high­brightness, high-contrast images.

Wide Viewing Angle

The LCD panels used in the entry-level one-piece type LUMA
monitors provide a wide viewing angle of 178 degrees for the
LMD-2030W, and 170 degrees for the LMD-1420 and
LMD-1410, both horizontally and vertically, with minimal
reduction in picture contrast. This allows images to be
viewed from various positions and angles.

Operational Convenience

Advanced Marker Settings

The LMD-2030W and LMD-1420 can display various area
markers, including a center marker and aspect markers.
The brightness of these markers can be selected from three
different levels: white, gray, and dark gray. Users can also
select either a black or gray matte to fill the outer area of the
aspect markers. These flexible marker controls, together with
the choice of many different aspect markers, make these
monitors extremely convenient display devices for a variety of
shooting scenarios.

Marker Variation

Color Temperature

The color temperature can be selected as 'high', 'low', or user preset.

Selectable Scan Size for Video Input and Aspect Ratio

The scan size can be selected between 5% over-scan and -3%
underscan modes. The aspect ratio can be switched between
16:9 and 4:3 according to the input signal.

Three-color Tally

The LMD-2030W and LMD-1420 come equipped with a tally
lamp that can be lit via a parallel remote connector.
The status of the signal displayed on the monitor can be
identified by the tally color - red, green, or amber.

Parallel Remote Control

The entry-level one-piece type LUMA monitors can be
controlled remotely via their parallel remote connectors. In
the remote menu, there are 17 functions for the LMD-2030W
and 25 for the LMD-1420 and LMD-1410 (such as the ability
to switch input signals), of which seven can be allocated to
the remote connector.

Monaural Audio Monitoring

All entry-level one-piece type LUMA monitors are equipped with
a speaker (0.5 W), which enables the user to monitor audio.

Protected Controls

The key-inhibit function helps prevent inadvertent operation
from the control panel.

Convenient Installation

Mounting Flexibility

Mountable in a 19-inch EIA Standard Rack (LMD-2030W)

All entry-level one-piece type LUMA monitors can be mounted
in a 19-inch EIA standard rack using optional mounting brackets.
The 9U-high LMD-2030W uses the MB-529 Mounting Brackets,
and the 7U-high LMD-1420 and LMD-1410 use the MB-526
Mounting Brackets.

VESA Mounting

Complying with VESA standards, these monitors can easily be
mounted (100 x 100 mm pitch) on a wall or ceiling.

Other Features

• Setup Level for Analog Component and NTSC signals

• Blue-Only Mode (LMD-2030W and LMD-1420 only)

• External Sync IN (LMD-2030W and LMD-1420 only)

• 4:3 Zoom (LMD-1420 only)

9

Handheld Type

The handheld type LUMA monitors offer a great level of monitoring convenience in the field and the
studio. Three models are available – the LMD-9050 with digital HD-SDI and SD-SDI input capability the
LMD-9030 focusing on SD-SDI video monitoring, and the LMD-9020, exclusively for analog video
monitoring. All three models can display HD images using their analog component inputs.
Incorporating high-purity 9-inch
can be hand-held, situated on a desk, or mounted in standard racks.

LMD-9050

*

panels, these monitors can be AC, DC, or battery driven so that they

*

8.4-inch viewable area measured diagonally.

Panel Type

Panel Aspect Ratio Panel Size

LMD-9050 4:3 8.4-inch Analog, HD-SDI/SD-SDI

LMD-9030 4:3 8.4-inch Analog, SD-SDI

LMD-9020 4:3 8.4-inch Analog

* Viewable area measured diagonally.

*

Acceptable Format

Input Versatility

To keep their units simple and clean, the handheld type LUMA monitors
provide all inputs built-in as standard, instead of using optional input
modules. For typical SD video monitoring, all three monitors offer interfaces
for analog composite (NTSC/PAL), analog component/RGB (525/60i and
625/50i) and analog Y/C (S-Video). The LMD-9030 additionally offers SD­SDI input capability. The top-of-the-line LMD-9050 further provides a
variety of digital progressive SD and HD formats through its HD-SDI
interface*. These include 480/60P and 576/50P, and high-definition
1080/60i, 1080/50i, 720/50P, 720/60P as well as 1080/24PsF.

* The SD-SDI and HD-SDI inputs share the same BNC connectors, which offer automatic signal-type

detection.

LMD-9030

LMD-9020

Input Signals

Input Signal Standard Interface

System Total Lines Active Line Aspect Ratio

Model

575/50i 625 575 16:9/4:3 O O O —

480/60i* 525 483 16:9/4:3 O O O —

480/60P 525 483 16:9/4:3 — O — —

576/50P 625 576 16:9/4:3 — O — —

1080/24PsF 1125 1080 16:9 — O — O

1080/50i 1125 1080 16:9 — O — O

1035/60i* 1125 1035 16:9 — O — O

1080/60i* 1125 1080 16:9 — O — O

720/50P 750 1080 16:9 — O — O

720/60P 750 720 16:9 — O — O

* Also accepts 59.94 Hz field rate.

Composite RGB SDI (x2)

Y/C (x 1)

LMD-9050 LMD-9050 LMD-9050 LMD-9050
LMD-9030 LMD-9030 LMD-9030
LMD-9020 LMD-9020

Component (x 1)

SD-SDI HD-SDI

High Picture Quality

Excellent Brightness and Contrast

The handheld type LUMA monitors provide high-brightness and high­contrast images by using wide aperture LCD panels. In addition, the use of
precisely manufactured RGB color filters allows these monitors to reproduce
colors with stunning depth and saturation – creating highly natural images.

10

Handheld Type

Wide Viewing Angle

The LCD panels used in the handheld type LUMA monitors
have a wide viewing angle of 170 degrees, both horizontally
and vertically, with minimal reduction in picture contrast.

AR (anti-reflection) Coated Protection Panel

The handheld type LUMA monitors use robust AR-coated
protection layers, which minimize the chance of their panels
being scratched during transportation – an extremely important
criteria for use in the field or in any mobile application. The AR
coating additionally has two unique characteristics: it provides a
high transmission rate of the internal light source to keep the
picture as bright as possible, and it keeps reflection from
ambient light to a minimum. As a result, when used in bright
lighting conditions, high contrast is still maintained even in dark
areas of the picture.

Operational Convenience

ENG Kit VF-509

The handheld type LUMA monitors are a strategic choice for
use in ENG and EFP field operations. When compared to CRT
displays, the picture contrast of these monitors is affected less
by ambient light, allowing clear images to be viewed even
under strong sunlight. For further protection, the optional
VF-509 ENG kit provides a Viewing Hood, Carrying Handle,
and Connector Protector.

4:3/16:9 Switchable Display

The scan aspect ratio can be switched between 4:3 and 16:9.

Selectable Scan Size

The scan size can be selected between 5% over-scan, 0%,
and -3% underscan modes.

LMD-9050, LMD-9030 and LMD-9020 Connector Panel

Advanced Marker Settings

The handheld type LUMA monitors can display various area
markers, including a center marker and aspect markers.

The brightness of these markers can be selected from three
different levels, white, gray, and dark gray, and their widths
can be selected from FINE, STANDARD, and BOLD. Users can
also select either a black or gray matte to fill the outer area of
the aspect markers. These flexible marker controls, together
with the choice of many different aspect markers, make the
handheld type LUMA monitors extremely convenient for a
variety of shooting scenarios.

16:9 Mode 4:3 Mode

Aspect Marker 4:3, 15:9, 14:9, 13:9, 16:9

1.85:1, 2.35:1, 1.85:1& 4:3

Center Marker O

Color Temperature/Gamma Selection

High/low color temperatures or user preset can be selected.
A variety of gamma modes can also be selected.

Three-color Tally

All handheld type LUMA monitors come equipped with a tally
lamp that can be lit up via a parallel remote connector.
The status of the signal displayed on the monitor can be
identified by the tally color – red, green, or amber.

Parallel Remote Control

The handheld type LUMA monitors can be controlled remotely
via their parallel remote connectors. There are 27 functions in
the remote menu (such as the ability to switch input signals),
of which seven can be allocated to the connector.

Monaural Audio Monitoring

All handheld type LUMA monitors are equipped with a speaker
(0.5 W), which enables the user to monitor audio.

Protected Controls

The key-inhibit function helps prevent inadvertent operations
from the control panel.

Convenient Installation

Mounting Flexibility

The handheld type LUMA monitors are 5U high and half-rack
wide. Using the optional MB-525 Mounting Bracket with a nine­step tilt capability, two units can be installed side-by-side in a 19­inch EIA standard rack.

Other Features

• Setup Level for Analog Component and NTSC signal

• Sub Control on Contrast, Chroma, Phase, and Brightness

• Blue-only mode

• Power-saving Function

• Monochrome mode

• 4:3 Zoom

11

Multi-display Type

The multi-display type LUMA monitors integrate high-quality LCD panels into an extremely thin and
lightweight, 19-inch rack-mountable chassis. They can be AC or DC powered. These monitors are particularly
handy for viewing multiple SD signal sources in space-confined environments – such as OB vehicles, machine
rooms, and desktops – or any general application where multiple pictures must be viewed.

Panel Types

1

*

LMD-7220W

Panel Aspect Ratio Number of Displays Display Size

LMD-4420 4:3 4 4-inch

LMD-5320 4:3 3 5.6-inch

LMD-7220W 16:9

*1Viewable area measured diagonally.

2

*

HD signals must be externally down-converted for display.

2

*

2 7-inch

Input Capability

All multi-display type LUMA monitors accept either composite
or SDI signals. Each LCD panel is equipped with a composite
connector as standard, while SDI input can be added simply
by installing the optional BKM-320D*.

* One BKM-320D is required per screen.

LMD-5320

LMD-4420

LMD-7220W Connector Panel

LMD-5320 Connector Panel

LMD-4420 Connector Panel

High Picture Quality

Although small in size, the multi-display type LUMA monitors
incorporate high-grade LCD panels with high brightness and
high contrast. These LCD panels also offer a wide viewing
angle, both vertically and horizontally.

Operational Convenience

Selectable Aspect Ratio (LMD-7220W only)

The scan aspect ratio of the displays on the LMD-7220W can
be switched between 16:9 and 4:3 by pressing a button on
the front panel.

Three-color Tally

The LMD-7220W, LMD-5320, and LMD-4420 come equipped
with a tally lamp that can be lit up via a parallel remote
connector. The status of the signal displayed on the monitor
can be identified by the tally color – red, green, or amber.

Parallel Remote Control

The multi-display type LUMA monitors can be controlled
remotely via their parallel remote connector. There are 5
functions (LMD-7220W)/4 functions (LMD-5320/LMD-4420) in
the remote menu (such as the ability to switch input signals),
which can be allocated to the connector.

12

Multi-display Type

Low Power Consumption

Compared to conventional CRT multiple monitors, multi­display type LUMA monitors offer drastic reductions in power
consumption and room-cooling requirements. This is a huge
bonus in applications where power consumption is critical,
such as OB van installations.

Slim and Light

Thanks to their thin and lightweight designs, the multi-display type
LUMA monitors are ideal for installations where space is limited.

All multi-display type LUMA monitors are mountable on a
19-inch EIA standard rack. For viewing convenience, the
LMD-7220W and LMD-5320 offer a 5-step tilt mechanism,
and the LMD-4420 offers a 3-step tilt mechanism.

Optional Accessories

• BKM-220D

SD-SDI 4:2:2 Input Adaptor
(for LMD-2450W and

LMD-2050W)

• BKM-243HS

HD-SDI/SD-SDI Input Adaptor
(for LMD-2450W and

LMD-2050W)

• BKM-227W

NTSC/PAL Input Adaptor
(for LMD-2450W and

LMD-2050W)

Convenient Installation

• BKM-229X

Analog Component Adaptor
(for LMD-2450W and

LMD-2050W)

• BKM-320D

SD-SDI Input Adaptor
(for LMD-2030W, LMD-1420,

LMD-7220W, LMD-5320, and
LMD-4420)

• MB-528

Mounting Panel
(for LMD-9050, LMD-9030

and LMD-9020)

• BP-GL95/BP-GL65

Rechargeable Lithium-ion
Battery Pack

• MB-526

Mounting Bracket
(for LMD-1420 and

LMD-1410)

• VF-509

ENG Kit (Viewing Hood,
Carrying Handle and
Connector Protector)
(for LMD-9050, LMD-9030

and LMD-9020)

• BC-L70

Lithium-ion Battery Charger

• MB-529

Mounting Bracket
(for LMD-2050W and

LMD-2030W)

• BC-L80S

Lithium-ion Battery Charger

• MB-525

Mounting Bracket
(for LMD-9050, LMD-9030

and LMD-9020)

• BC-L60S

Lithium-ion Battery Charger

13

Feature Comparison

High-grade One-piece Type

Monitor System

Picture Resolution 1920 x 1200 pixels 1680 x 1050 pixels 1680 x 1050 pixels 640 x 480 pixels
Picture Size 24-inch 20-inch 20-inch 14-inch
LCD Panel A-Si TFT Active Matrix a-Si TFT Active Matrix
Acceptable computer system upto WUXGA upto WSXGA+ No
Panel aspect Ratio 16:10 16:10 4:3
Protection Panel/AR Coating No No Yes No
16:9 Capability Yes Yes
HD/SD HD (analog/digital)/SD (analog/digital)
Composite Video Input/Output Yes Yes
Y/C Input/Output Yes Yes
Component (Y,R-Y,B-Y)/RGB Input Yes Yes
SD-SDI video input Yes 1x (with BKM-320D) No
HD-SDI video input Yes No
SDI with Audio decoding Yes No
Computer Input Yes No
HDMI No Yes No
Audio Input/Output Yes Yes
External Sync Input/Output Yes Yes No
EIA 19-inch Rack Mounting No MB-529 MB-529 MB-526
VESA Mounting Yes Yes
Desk-top Stand Supplied Stand Stand supplied
Overscan Yes Yes
Color Temperature Selectable Selectable
Blue Only Yes Yes No
H/V delay Yes No
Tally 3-Color 3-Color No
Area Marker Yes No Yes No
Li-Ion battery Operation No No
DC Operation No No

LMD-2450W LMD-2050W LMD-2030W LMD-1420 LMD-1410

HD (analog/digital)/SD (analog/digital)

Entry-level One-piece Type

HD (analog)/SD (analog/digital) HD (analog)/SD (analog)

Handheld Type

Monitor System
Picture Resolution 1024 x 768 pixels 640 x 480 pixels 480 x 234 pixels 481 x 234 pixels 482 x 234 pixels
Picture Size 8.4-inch 2x7-inch 3x5.6-inch 4x4-inch
LCD Panel a-Si TFT Active Matrix a-Si TFT Active Matrix
Acceptable computer system No No
Panel Aspect Ratio 4:3 16:9 4:3
Protection Panel/AR Coating Yes No
16:9 Capability Yes Yes No
HD/SD
Composite Video Input/Output Yes Yes
Y/C Input/Output Yes No
Component (Y,R-Y,B-Y)/RGB Input Yes No
SD-SDI Video Input
HD-SDI Video Input No No
SDI with Audio decoding Yes No No
Computer Input No No
HDMI No No
Audio Input/Output Yes No
External Sync Input/Output Yes No
EIA 19-inch Rack Mounting MB-525 Supplied
VESA Mounting No No
Desk-top Stand Stand supplied Not applicable
Overscan Yes No
Color Temperature Selectable Selectable
Blue Only Yes No
H/V delay No No
Tally 3-Color 3-Color
Area Marker Yes No
Li-Ion Battery Operation Yes No
DC Operation Yes Yes

LMD-9050 LMD-9030 LMD-9020 LMD-7220W LMD-5320 LMD-4420

HD (analog/digital)/SD (analog/digital)

2xHD or SD Auto detective

HD (analog)/SD (analog/digital)

Yes

HD (analog)/SD (analog) HD (analog)/SD (analog/digital)

No

Multi-display Type

Yes (with BKM-320D)

14

Specifications

High-grade
One-piece
Type

LMD-2450W

Picture Performance

Type A-Si TFT Active Matrix LCD A-Si TFT Active Matrix LCD
Resolution 1920 x1200 pixels (WUXGA) 1680 x1050 pixels (WSXGA+)
Picture Size (H x W) Approx. 518.4 x 324.0 mm Approx. 433.5 x 272.9 mm

(Viewable area) (Approx. 20
(Diagonal) Approx. 609.6 mm (24 inches) Approx. 511.1 mm (20 1/8inches)

Aspect 16:10
Colors Approx 1,677,000 colors (8bits)
Viewing Angle 89°/89°/89°/89° (typical) (up/down/left/right contrast>10:1)

Input

Standard Composite BNC x 1, 1.0 VP-p ±3dB sync negative

Y/C Y: 1.0 Vp-p ±3dB sync negative,

RGB, Component RGB : 0.7 Vp-p ±3dB (Sync On Green, 0.3 Vp-p sync negative)

External Sync

Audio RCA pin x 2 (L, R) -5 dBu 47 k Ω or higher

HD15

DVI TMDS signal link
Parallel remote Modular connector 8 pin x 1 (pin assignment at users' allocation)

Serial remote (LAN)

DC in XLR type 4pin x 1 DC24V (output impedance 0.005 Ω or less)

Optional Option input slot 2 slots (for HD-SDI, SDI capability and extra analog I/O's)

Output

Standard Composite BNC x 1, Loop-though, with 75 Ω automatic termination

Y/C 4pin mini DIN x 1 Loop-though, with 75 Ω automatic termination
RGB, Component BNC x 3, Loop-though, with with 75 Ω automatic termination
External Sync BNC x 1, Loop-though, with 75 Ω automatic termination
Audo monitor out RCA pin type x 2 (L, R)
Speaker (Built-in) 1 W + 1 W (stereo)

General

Power Requirement AC100V to 240V 50/60Hz 0.6A to 1.1A, DC24V 4.6A AC100V to 240V 50/60Hz 0.4A to 0.8A, DC24V 3.3A
Power Consumption Maximum Approx.115 W (with 2 x BKM-229X) Maximum Approx. 95 W (with 2 x BKM-229X)
Operating Temperature 0 to 35 °C (recommended operation temperature 20 to 30 °C)
Operating Humidity 30 to 85% (No condensation)
Storage & Transport Temperature -20 to 60 °C
Storage & Transport Humidity 0 to 90 %
Operating/Storage/Trans. Pressure 700 to 1060 hPa
Dimensions (W x H x D)

Dimension 602.4 x 497.9 x 269.9 mm 518.5 x 468.4 x 269.9 mm

Dimension without stand

Display Stand (W x H x D)
Mass With two option boards Approx. 11.4 kg ( 25 lb 2 oz) with BKM-229X x 2 Approx. 10.5 kg ( 23 lb 2 oz) with BKM-229X x 2

Without option boards Approx. 11.0 kg ( 24 lb 4 oz) Approx. 10.1 kg ( 22 lb 4 oz)

1

/2x 12 1/8inches) (Approx. 17 1/8x 10 3/4inches)

4pin Mini DIN x 1

C: 0.286 Vp-p ±3dB (NTSC burst signal level), 0.3 Vp-p ±3dB (PAL burst signal level)

Component : 0.7 Vp-p ±3dB (75% chrominance standard color bar signal)

0.3 to 4.0 Vp-p ±bipolarity ternary or negative polarity binary

R/G/B: 0.7 Vp-p sync positive (Sync On Green, 0.3 Vp-p sync negative)

Sync : Total level (polarity free, H/V separate and composite sync)

Plug & Play function : corresponds to DDC-2B

RJ-45 modular connector (ETHERNET) x 1 (10BASE-T/100BASE-TX)

(23 3/4x 19 5/8x 10 3/4inch) (20 1/2x 18 1/2x 10 3/4inch)

602.4 x 386.2 x 110.0 mm 518.5 x 328.7 x 104.7 mm

(23 3/4x 15 1/4x 4 3/8inch) (20 1/2x 13 x 4 1/8inch)

320.0 x 361.5 x 269.9 mm

BNC x 3

BNC x 1

D-sub 15 pin x 1,

D-sub 9-pin (RS232C) x 1,

(12 5/8x 14 1/4x 10 3/4inches)

LMD-2050W

Dimensions

LMD-2450W LMD-2050W

Unit: mm (inches)

15

Specifications

Entry-level
One-piece
Type

LMD-2030W LMD-1420 LMD-1410

Picture Performance

Type A-Si TFT Active Matrix LCD
Resolution 1680 x 1050 pixels (WSXGA+) 640 x 480 pixels (VGA)
Picture Size (H x W) Approx. 433 x 271 mm Approx. 283 x 212 mm

(Viewable area) (Approx. 17
(Diagonal) Approx. 511 mm (20.1-inch) Approx. 354 mm (14-inch)

Aspect 16:10 4:3
Colors Approx. 16,700,000 Approx. 16,200,000 colors
Viewing Angle 89°/89°/89°/89° (typical) (up/down/left/right contrast>10:1) 85°/85°/85°/85° (typical) (up/down/left/right contrast>10:1)

Input

Line A Composite BNC x 1, 1.0 Vp-p ±3dB, sync 0.3 Vp-p negative

Y/C

Audio in RCA pin x 1, -5 dBu 47 Ω or higher

Line B Composite – BNC x 1, 1.0 Vp-p ±3dB, sync 0.3 Vp-p negative

Audio in – RCA pin x 1, -5 dBu 47 Ω or higher

RGB/Component

RGB/Component BNC x 3, 0.7 Vp-p ±3 dB (Sync on Green 0.3 Vp-p, negative: RGB) (75% chrominance standard color bar signal: Component)
Audio in RCA pin x 1, -5 dBu 47 kΩ or higher

Option D1-SDI D-sub 9-pin x 1 –

Audio in AUDIO input (RCA pin x1), -5 dBu 47 kΩ or higher –
Exernal Sync BNC x1, 0.3 to 4 Vp-p negative polarity binary –
HDMI input HDMI x 1 –
Remote Parallel remote Modular connector 8-pin x1

Output

Line A Composite BNC x 1, Loop-through, with 75 Ω automatic termination

Y/C DIN 4 pin x 1, Loop-through, with 75 Ωautomatic termination

Audio out RCA pin x1, Loop-through
Line B Composite – BNC x 1, Loop-through, with 75 Ω automatic termination

Audio out – RCA pin x 1, Loop-through
RGB/Component

RGB/Component BNC x3, Loop-through, with 75 Ω automatic termination

Audio out RCA pin x 1, Loop-through
Exernal Sync
Built-in speaker output 0.5 W (mono)

General

Power Consumption Approx. 72 W Approx. 51 W Approx. 48 W
Power requirement AC100 to 240V, 50/60 Hz
Operating Temperature 0 to 35 °C (recommended operation temperature 20 to 30 °C)
Operating Humidity 30 to 85% (No condensation)
Storage & Transport Temperature -20 to 60 °C
Storage & Transport Humidity 0 to 90 %
Operating/Storage/Trans. Pressure 700 to 1060 hPa
Dimensions (W x H x D)

Dimension Approx. 493 x 408 x 264 mm Approx. 343 x 354 x 264 mm Approx. 343 x 354 x 264 mm

Dimension without stand

Mass Panel & Stand Approx. 9.6 kg (212 lb 3 oz) Approx. 6.8 kg (14 lb 16 oz) Approx. 6.5 Kg (14 lb 5 oz)

Panel only Approx. 7.9 kg (17 lb 6 oz) Approx. 5.1 kg (11 lb 4 oz) Approx. 4.8 kg (10 lb 9 oz)
Supplied Accessories Display Stand, AC power cord, AC plug holder, Operating Instructions, CD-ROM, Using the CD-ROM Manual,Warranty Card

1

/8x 10 3/4inches) (Approx. 11 1/4x 8 3/8inches)

BNC x1, Loop-through, with 75 Ω automatic terminal function

(19 1/2x 16 1/8x 10 1/2inch) (13 5/8x 14 x 10 1/2inch) (13 5/8x 14 x 10 1/2inch)

Approx. 493 x 361 x 87mm Approx. 343 x 304 x 87mm Approx. 343 x 304 x 87mm

(19 1/2x 14 1/4x 3 1/2inch) (13 5/8x 12 x 3 1/2inch) (13 5/8x 123 1/2inch)

A-Si TFT Active Matrix LCD with a multi-layer AR-coated protection panel

4-pin mini-DIN x 1

C: 0.286 Vp-p ±3 dB (NTSC), 0.3 Vp-p ±3 dB (PAL),

Y: 1. 0Vp-p ±3 dB

sync 0.3 Vp-p negative

A-Si TFT Active Matrix LCD

–

16

Dimensions

LMD-2030W

LMD-1420
LMD-1410

Unit: mm (inches)

Handheld Type

LMD-9050 LMD-9030 LMD-9020

Picture Performance

Type a-Si TFT Active Matrix LCD with a multi-layer AR-coated protection panel
Resolution 1024 x 768 pixels 640 x 480 pixels
Picture Size (H x W), (Viewable area) Approx. 170.5 x 127.9 mm, (Approx. 6

(Diagonal) Approx. 213 mm (8.4-inch) Approx. 213.6 mm (8.4-inch)
Aspect 4:3
Colors 16,770,000 colors
Viewing Angle 85°/85°/85°/85° (typical) (up/down/left/right contrast>10:1)

Input

Line A Composite BNC x 1, 1.0 Vp-p +3dB, -6 dB sync negative

Y/C

Line B Composite BNC x 1, 1.0 Vp-p +3 dB, -6 dB sync negative

RGB/Component

Ext.sync
SDI HD-SDI/D1-SDI: D1-SDI:

Remote

Output

Line A Composite BNC x 1,Loop-through, with 75 Ω automatic termination

Line B Composite BNC x 1, Loop-through, with 75 Ω automatic termination
Monitor output HD-SDI/D1-SDI: D1-SDI:

Audio output Mini jack x 1, Loop-through
Headphones output Mini jack x 1(Monaural), Loop-through
Speaker output 0.5 W (Monaural)

General

Power Consumption Monitor : Approx. 24 W,With AC Adaptor : Approx. 28 W Approx. 16 W, With AC Adaptor : Approx. 22 W Approx. 15 W, With AC Adaptor : Approx. 20 W
Power requirement AC 100 to 240 V, 50/60 Hz, 0.82 A, DC 12 V 2.2 A, AC 100 to 240 V,50/60 Hz, 0.82 to 0.42 A, DC 12 V 1.6 A, AC 100 to 240 V,50/60 Hz, 0.82 to 0.42 A, DC 12 V 1.5 A,

Operating Temparature 0 to 40 °C
Operating Humidity 30 to 85 % (No condensation)
Operating/Storage/Trans. Pressure 700 to 1060 hPa
Storage & Transport Temperature -20 to 60 °C
Storage & Transport Humidity 0 to 90 %
Dimensions (W x H x D) Approx. 216 x 206 x 136.1 mm (8 5/8x 8 1/8x 5 3/8inches)

Mass Approx. 3.0 Kg (6 lb 10 oz) Approx. 2.9 Kg (6 lb 6 oz) Approx. 2.8 Kg (6 lb 3 oz)

Supplied Accessories AC adaptor (1), AC Cord (1), AC plug holder (1), Operating instructions (1), CD-ROM (1), Warranty card (1), Using the CD-ROM Manual (1)

Audio Mini jack x 1, -5 dBu 47 kΩ or higher

Audio Mini jack x 1, -5 dBu 47 kΩ or higher
RGB/Component BNC x 3, 0.7 Vp-p ±3 dB (Sync on Green 0.3 Vp-p,negative:RGB) (75% chrominance standard color bar signal:Component)
Audio Mini jack x 1, -5 dBu 47 kΩ or higher

BNC x 2 (HD and D1 are automatically detected) BNC x 2,
Sampling frequency D1-SDI:Y/R-Y/B-Y 13.5 MHz, Sampling frequency :Y/R-Y/B-Y 13.5 MHz, —

HD-SDI:Y/PB/PR 74.25 MHz Quantization 10 bits/sample

Parallel remote Modular connector 8-pin x 1(Assignable)

Y/C 4-pin mini-DIN x 1, Loop-through, with 75 Ω automatic termination

Dimension with the supplied stand
Dimension

with the supplied stand

and AC adaptor

With the supplied stand Approx. 3.2 Kg ( 7 lb 1 oz) Approx. 3.1 Kg (6 lb 13 oz) Approx. 3.0 Kg (6 lb 10 oz)
With the supplied stand and AC adaptor

Quantization 10 bits/sample

BNC x 1, Output signal : amplitude 800 mVp-p ±10%, BNC x 1, Output signal amplitude : 800 mVp-p ±10%, —

Output impedance : 75 Ω umbalanced Output impedance : 75 Ω umbalanced

Rechargeable Battery Pack Rechargeable Battery Pack Rechargeable Battery Pack

Approx. 3.9 Kg (8 lb 10 oz) Approx. 3.8 Kg (8 lb 6 oz) Approx. 3.7 Kg (8 lb 3 oz)

3

/4x 5 1/8inches) Approx. 170.9 x 128.2 mm, (Approx. 6 3/4x 5 1/8inches)

4-pin mini-DIN x 1

Y : 1.0 Vp-p + 3dB, -6 dB sync negative

C : 0.286 Vp-p ±3 dB (NTSC), 0.3 Vp-p ±3 dB (PAL)

BNC x 1, 0.3 to 4 Vp-p ± bipolarity ternary or negative polarity binary

Approx. 216 x 230 x 159.5 mm (8 5/8x 9 1/8x 6 3/8inches)

Approx. 216 x 230 x 210 mm (8

5/8 x 9 1/8 x 8 3/8 inches)

Handheld Type

LMD-9050
LMD-9030
LMD-9020

Unit: mm (inches)

17

Specifications

Multi-display
Type

LMD-7220W LMD-5320 LMD-4420

Picture Performance

Type a-Si TFT Active Matrix
Resolution 480 x 234 pixels 320 x 234 pixels 480 x 234 pixels
Picture Size (H x W) Approx. 154.1 x 86.6 mm Approx. 113.3 x 84.7 mm Approx. 82.1 x 61.8 mm

(Viewable area) (Approx. 6
(Diagonal) Approx. 7 inches (176.7 mm) Approx. 5 5/8inches (141.5 mm) Approx. 4 1/8inches (102.8 mm)

Aspect 16:9 4:3
Colors Full color
Viewing Angle 40°/65°/65°/65° (typical) (up/down/left/right contrast>10:1) 50°/30°/50°/50° (typical) (up/down/left/right contrast>10:1)

Input/Output

Composite

Input BNC (x 2), 1.0 Vp-p ±2 dB, sync negative BNC (x 3), 1.0 Vp-p ±2 dB, sync negative BNC (x 4), 1.0 Vp-p ±2 dB, sync negative

Output BNC (x2), Loop through,Automatic 75 Ω termination BNC (x 3), Loop through, Automatic 75 Ω termination BNC (x 4), Loop through, Automatic 75 Ω termination
OPTION IN D-sub 9pin (x2) D-sub 9pin (x3) D-sub 9pin (x4)
Remote

Parallel Modular 8 pin (x2) Modular 8 pin (x3) Modular 8 pin (x4)

General

Power Consumption

Power requirement 12V DC (with the supplied AC power adaptor),AC power adaptor:AC 100 to 240 V, 50/60 Hz

Peak inrush current

Operating Temperature 0 to 35°C (32 to 95°F)
Operating Humidity 30 to 85 % (no condensation)
Storage & Transport Temperature -10 to 40°C (14 to 104°F)
Storage & Transport Humidity 0 to 90 %
Operating / Storage / Trans. Pressure 700 hPa to 1060 hPa
Dimensions (W x H x D) 482 x 133 x 47 mm (19 x 5 1/4x 1 7/8inches)* 482 x 133 x 47 mm (19 x 5 1/4x 1 7/8inches)* 482 x 88.1 x 47 mm (19 x 3 1/2x 1 7/8inches)*

Dimension including AC adaptor and

BKM-320D
Mass Approx. 2.3Kg (Approx. 5 lb 1 oz)** Approx. 2.3Kg (Approx. 5 lb 1 oz)** Approx. 1.9Kg (Approx. 4 lb 3 oz)**
Supplied Accessories AC power adaptor (1), AC Power Cord (1), AC plug holder (1), Screws for AC adaptor holder (2), Operating Instructions (1), Warranty Card (1)

* without the projection parts ** Excluding supplied accessories.

Maximum: Approx. 26 W (with 2 x BKM-320D) Maximum: Approx. 28 W (with 3 x BKM-320D) Maximum:Approx. 26 W (with 4 x BKM-320D)

Standard: Approx. 23 W (without optional input adaptor) Standard: Approx. 22 W (without optional input adaptor) Standard: Approx. 18 W (without optional input adaptor)

(1) Power on, current probe method:57A (230V) (1) Power on, current probe method:55A (230V) (1) Power on, current probe method:53A (230V)

482 x 133 x 116 mm (19 x 5

1

/8x 3 1/2inches) (Approx. 4 1/2x 3 3/8inches) (Approx. 3 1/4x 2 1/2inches)

(2) Hot switching inrush current, measured in accordance with European standard EN55103-1:8A (230V)

1/4 x 4 5/8 inches) 482 x 133 x 116 mm (19 x 5 1/4 x 4 5/8 inches) 482 x 88.1 x 116 mm (19 x 3 1/2 x 4 5/8 inches)

Multi-display Type

LMD-7220W

LMD-5320

LMD-4420

Unit: mm (inches)

18

19

Distributed by

©2007 Sony Corporation of Hong Kong Ltd. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.

All non-metric weights and measurements are approximate.

Images on monitors are simulated.

Sony, ChromaTRU and LUMA are trademarks of Sony Corporation.

VESA is a trademark of the Video Electronics Standards Association.

All other trademarks are the property of their respective owners.

MSD2007-608(10415V1)WEL00535

Printed in Hong Kong
