Page 1

3-213-721-12 (1)

Tr initron Color TV

Operating Instructions

• Before operating the unit, please read this manual thoroughly and retain it for future reference.

KV-SZ292

KV-SZ252

M50

Page 2

A Specifications

Power requirements

Power consumption (W)

Television system

Color system

Channel coverage

B/G

D/K

8 (Antenna)

Audio output (Speaker)

Number of terminal

(Video)

(Audio)

(Component Video)

i (Headphone)

Picture tube

Tube size (cm)

Screen size (cm)

Dimensions (w/h/d, mm)

Mass (kg)

KV-SZ292M50

110-240 V AC, 50/60 Hz

Indicated on the rear of the TV

B/G, I, D/K, M

PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43

VHF : E2 to E12 /UHF : E21 to E69 / CATV : S01 to S03, S1 to S41

UHF : B21 to B68 /CATV : S01 to S03, S1 to S41

VHF : C1 to C12, R1 to R12 / UHF : C13 to C57, R21 to R60 / CATV : S01 to S03, S1 to S41, Z1 to Z39

VHF : A2 to A13 /UHF : A14 to A79 / CATV : A-8 to A-2, A to W+4, W+6 to W+84

75-ohm external terminal

6 W + 6 W

Input: 2 Output: 1 Phono jacks; 1 Vp-p, 75 ohms

Input: 3 Output: 1 Phono jacks; 500 mVrms

Input: 1 Phono jacks;

Output: 1 Stereo minijack

29 in. 25 in.

774 × 590 × 506 704 × 530 × 506

46 35

KV-SZ252M50

Y: 1 Vp-p, 75 ohms, sync negative C

B: 0.7 Vp-p, 75 ohms

R: 0.7 Vp-p, 75 ohms

64 Measured diagonally

60 Measured diagonally

Note

Design and specifications are subject to change without notice.

Page 3

B WARNING

• Dangerously high voltages are present inside the TV.

• TV operating voltage: 110 – 240 V AC.

• Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.

•To avoid battery leakage and damage to the remote, remove the batteries from the remote if you are not going to use it for several days. If any liquid leaks from the batteries and touches your skin, immediately wash it away with water.

For your own safety, do not touch any part of the TV, the power cord and the antenna cable during lightning storms.

Do not place any objects on the TV. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

Do not block the ventilation openings of the TV. Do not install the TV in a confined space, such as a bookcase or built-in cabinet.

Do not open the cabinet and the rear cover of the TV as high voltages and other hazards are present inside the TV. Refer servicing and disposal of the TV to qualified personnel.

For children’s safety, do not leave children alone with the TV. Do not allow children to climb onto it.

Do not operate the TV if any liquid or solid object falls into it. Have it checked immediately by qualified personnel only.

Your TV is recommended for home use only. Do not use the TV in any vehicle or where it may be subject to excessive dust, heat, moisture or vibrations.

Clean the TV with a dry and soft cloth. Do not use benzine, thinner, or any other chemicals to clean the TV. Do not attach anything (e.g., adhesive tape, cellophane tape, glue) on the painted cabinet of the TV. Do not scratch the picture tube.

To prevent fire or shock hazard, do not expose the TV to rain or moisture.

Install the TV on a stable TV stand and floor which can support the TV set weight. Ensure that the TV stand surface is flat and its area is larger than the bottom area of the TV.

Do not plug in too many appliances to the same power socket. Do not damage the power cord.

Pull the power cord out by the plug. Do not pull the power cord itself. Even if your TV is turned off, it is still connected to the AC power source (mains) as long as the power cord is plugged in. Unplug the TV before moving it or if you are not going to use it for several days.

Page 4

C Securing the TV

To prevent the TV from falling, use the supplied screws and band to secure the TV.

20 mm

3.8 mm

screws band

Screw the band to the TV stand and to the provided hole at the rear of your TV.

(1) Screw one end of the band to the

provided hole at the rear of your TV.

(2) Securely fix the attached band to a wall

or pillar using an attachment which can hold the TV.

(1) Attach each end of a cord or chain to

the provided holders at the rear of your TV.

(2) Securely fix the attached cord or chain

to a wall or pillar using an attachment which can hold the TV.

• Use only the supplied screws. Use of other screws may damage the TV.

Page 5

D Getting Started

Step 1

Initial Setup Language:

Insert the batteries (supplied) into the remote.

• Do not use old or different types of batteries together.

Step 2

Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV.

• You can also connect your TV to other optional

components (see F).

Step 3

Plug in the power cord, then press 1 on the TV to turn it on.

• The 1 (standby) indicator flashes green for a few seconds

when turning on the TV. This does not indicate a malfunction.

Step 4

English

Set up the TV by following the instructions of the “Initial Setup” menu (see E).

Select

Confirm

End

Page 6

Select

Confirm

Initial Setup

Display this menu next time?

Yes

Setting up your TV (“Initial Setup”)

When you turn on your TV for the first time, the “Initial Setup” menu will appear. You can adjust settings below using the buttons on the remote control or TV front panel. Press V , v , B or b to select or adjust items, then press

Select the desired menu language.

Select “Yes” to preset the channels automatically.

To skip automatic channel presetting, select “No”.

The “Program Sorting/Edit” menu enables

you to sort and edit the channels (see L).

Adjust the bars on the top and bottom of the

menu if they are slanted.

Adjust the upper and lower bars if they are not

equally positioned to the top and bottom of the screen.

Initial Setup Language:

Select

Confirm

Initial Setup First please connect cable/ antenna

Start Auto Program now?

Select

Program Sorting/Edit

PROG

Sorting:

Select

01 02 03 04

Select

Edit:

Yes

Confirm

SkipLabel

Confirm

Off Off Off Off

English

End

Exit

End

To prevent this “Initial Setup” menu from appearing

again when you turn on the TV by pressing 1, select “No”.

To allow this menu to appear again, select “Yes”.

•You can immediately go to the end of the “Initial Setup” menu by pressing WEGA GATE.

Page 7

F Connecting optional components

You can connect a wide range of optional components to your TV. Connecting cables are not supplied.

Connecting to the TV (front)

Audio/Video

cable

Camcorder

Headphones

Connecting to the TV (rear)

Audio System

Audio/

Video

cable

Audio

cable

Component Video cable

VCR

Antenna

cable

VCR DVD Player

• If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the

program number 0 on the TV (see L).

• If your DVD player can output interlace and progressive mode signals, select the interlace output when connecting to (component video input) on your TV. Your TV can receive either 525i/60Hz or 625i/50Hz interlace signals.

• The component video terminals on your DVD player are sometimes labeled Y/CB/CR, Y/PB/PR, Y/Cb/Cr or Y/B-Y/R-Y.

• If you select “DVD” on your TV screen, the signal from the (monitor output) terminals will not be output properly. This does not indicate a malfunction.

Audio/Video

cable

DVD Player

Page 8

G Troubleshooting

If you find any problem while viewing your TV, you can either use the “Factory Settings” function (see M) or check the Troubleshooting guide below. If the problem persists, contact your Sony dealer.

Snowy picture, noisy sound

• Check the antenna setup and other connections.

•Preset the channel manually again (see L).

• Set the “Signal Booster” to “Auto” (see L) or try using an external booster.

Distorted picture, noisy sound

• Set the “Signal Booster” to “Off” (see L), or turn off or disconnect any external booster in

use.

Good picture, noisy sound

• Select the appropriate “TV System” (see L).

No picture, no sound

• Check the power cord, antenna setup and other connections.

•Press 4/1 (power) to turn on the TV.

•Press 1 (main power) on the TV to turn off the TV for about five seconds, then turn it on

again.

Good picture, no sound

•Press 2 + to increase the volume level or press to cancel the muting.

Dotted lines or stripes

• Do not use a hair dryer or other equipment near the TV.

• Check the antenna setup.

Double images or “ghosts”

• Use the fine tuning (“Fine”) function (see L).

• Check the antenna setup or use a highly directional antenna.

•Turn off or disconnect any external booster in use.

No color

• Adjust the “Color” level from “Picture Adjustment” (see J).

• Select the appropriate “Color System” (see M).

• Check the antenna setup.

Picture slant

• Keep external speakers or other electrical equipment away from the TV.

• Adjust the “Picture Rotation” or “Picture V-Position” (see M).

Abnormal color patches

• Keep external speakers or other equipment away from the TV. Do not move the TV while

the TV is turned on. Press 1 (main power) on the TV to turn off the TV for about 15 minutes, then turn it on again to demagnetize the TV.

The 1 (standby) indicator on your TV flashes red several times after every three seconds.

• Count the number of times the 1 (standby) indicator flashes. Press 1 on the TV to turn it

off, disconnect the AC power cord and inform your dealer or Sony service center of how the indicator flashes (duration and interval).

The TV screen sometimes goes blank for slightly longer than usual during channel change.

• The “Signal Booster” is functioning to detect a weak signal. This does not indicate a malfunction.

TV cabinet creaks.

• Changes in room temperature sometimes make the TV cabinet expand or contract, causing a noise. This does not indicate a malfunction.

A small “boom” sound is heard when the TV is turned on.

• The TV’s demagnetizing function is working. This does not indicate a malfunction.

Page 9

H TV buttons and remote control

1 1 Turn off or turn on the TV.

Wake Up indicator.

Remote control sensor.

Select or adjust items.

Confirm selected items.


MODE

2 2 1 Standby indicator. 3 4 PROG +/– Select program number. 5 2 +/– Adjust volume. 6 t Select TV or video input.

WEGA GATE menu operations (see I)

4,5

PROG

, , ,

6 7 WEGA GATE Display or cancel WEGA GATE menu.

12345678

8 PICTURE MODE Select picture mode option (see J).

qa qs

qk ql

A/B

RETURN

1 ?/1 Turn off temporarily or turn on the

TV.

2 a Display the TV program.

3 Jump to last program number that

PROG

4 PROG +/– Select program number. To select

5 2 +/– Adjust volume.

8 Change the picture size:

9 Not function for your TV.

0 Display on-screen information.

has been watched for at least five seconds.

quickly, press and hold until the desired program number appears.

“On” (16:9 wide mode), “Off”.

qa Mute the sound. qs A/B Not function for your TV. qd t Select TV or video input.

WEGA GATE

qf 0-9 Input numbers. For program

7 8

numbers 10 and above, enter the second digit within two seconds.

Page 10

TV buttons and remote control (continued)

ql Not function for your TV. w; Select picture mode options: “Vivid”, “Standard”, “Custom”* (see J).

* When the “Custom” mode is selected, you can receive the last adjusted

picture settings from the “Picture Adjustment” option in the menu.

WEGA GATE menu operations (see I)

6 Confirm selected items. 7 WEGA GATE Display or cancel WEGA GATE menu. qj V, v, B , b Select or adjust items. qk RETURN Return to the previous level.

Timer operations

qg Set TV to turn on automatically according to the desired period of time

(Wake Up Timer) (max. of 12 hours). The indicator on TV lights up amber once you set

the wake up timer. If no buttons or controls are pressed for more than three hours after the TV is turned on using the wake up timer, the TV automatically goes into standby mode.

qh Set TV to turn off automatically according to the desired period of time

(Sleep Timer) (max. of one hour and 30 min.).

Teletext operations (green icon)

, , , ,

(red, green,

yellow, blue)

Not function for your TV.

PIP operations

, , V, v, B, b Not function for your TV.

Page 11

I WEGA GATE navigator

Confirm

Select

WEGA GATE

Settings

External Inputs

WEGA GATE is a gateway that allows you access to preset TV channels, connected external inputs and “Settings” menu.

WEGA GATE TV

Select

External Inputs

Settings

Confirm

“TV”

“External Inputs”

“Settings”

How to use WEGA GATE

WEGA GATE TV

External Inputs Settings

Select

(1) Press WEGA GATE to display or cancel

the WEGA GATE menu.

01 02 03 04 05

Select

End

Confirm

Select

End

External Inputs

Video 1

Video 2

DVD

watch the preset TV channels (see E)

Confirm

select the inputs for the connected equipment (see F)

Select End

Picture Mode: Vivid

Picture Adjustment Color Temperature: Cool VM: High Intelligent Picture: On Signal Level Indicator:

Select


Confirm

End

change the settings of your TV (see J,K,L,M)

01 02 03 04 05

Select

End

Confirm

(2) Press (or b) to confirm your selection

or go to the next level.

(3) Press V or v to select the desired item.

(4) Press RETURN to move to the previous

level.

• When a feature is dimmed in the menu, it is not selectable.

• The WEGA GATE, and

, , ,

buttons on the front panel can also be used for

the operations above.

Page 12

J “Picture” setting

Confirm

End


Color Temperature: Cool

Picture Adjustment

Picture Mode: Vivid

VM: High Intelligent Picture: On Signal Level Indicator:

Select

Press WEGA GATE and select “Settings”. Make sure the “Picture” icon ( then press

) is selected,

“Picture Mode” Choose either “Vivid” (bright, contrast and sharp),

“Color Temperature” Adjust white color tint.

“VM” Sharpen the edges of each object. (Velocity Modulation) Choose either “High”, “Low” or “Off”.

“Intelligent Picture” Optimize picture quality.

“Signal Level Indicator” Display the signal level when the “Intelligent Picture” is

*You can adjust the setting to your personal preference in the “Picture Adjustment”,

“Color Temperature” and “VM” options only when the “Custom” mode is selected.

“Standard” (normal) or “Custom”*.

Choose either “Cool” (blue tint), “Neutral” (neutral tint) or “Warm” (red tint).

Press V or v to select “On”, then press .

To cancel, select “Off”, then press .

functioning. “Intelligent Picture Signal Level” indicator will be displayed, followed by picture improvement when you change the program number or the input mode.

red amber green

(weak) (average)(fair ................. good)

Press V or v to select “On”, then press . To cancel, select “Off”, then press . “Intelligent Picture” is

still functioning.

Adjusting the “Picture Adjustment” items under “Custom” mode

2 3

Press V or v to select either “Picture” (contrast), “Brightness”, “Color”, “Hue” (color tones) or “Sharpness”, then press

Selecting “Reset” will set your TV to the factory settings.

Press V,v,B or b to adjust the setting of your selected item, then press .

Repeat the above steps to adjust other items.

The adjusted settings will be received when you select “Custom”.

• “Hue” can be adjusted for the NTSC color system only.

• Reducing “Sharpness” can also reduce picture noise.

Page 13

K “Sound” setting

Press WEGA GATE and select “Settings”. Press V or v to select the “Sound” icon ( then press .

Sound

Balance

Select

“Balance” Press v or B to emphasize the left speaker.

Press V or b to emphasize the right speaker.

Confirm

End

Page 14

“Channel Setup” setting

Press WEGA GATE and select “Settings”. Press V or v to select the “Channel Setup” icon (

), then press .

Channel Setup

Auto Program Manual Program Program Sorting/Edit

Select

“Auto Program” Preset channels automatically.

“Manual Program” Manually preset desired channels and channels that cannot

“Program Sorting/Edit”

be preset automatically (see Presetting channels manually).

Sort and edit the channels. (a) If you wish to keep the channels in the current condition,

press WEGA GATE to exit.

(b) Press

(d) If you wish to edit the channels, press to change to

characters for the label. Then press .

(e) Repeat step (b) to (d) if you wish to change other

V or v to select the program number with the channel you wish to change. The selected channel will appear on the screen.

(1) Press b to enter sorting mode. (2) Press V or v to select the new program number position for your selected channel, then press B.

edit mode. Press b until the mode that you wish to edit is

highlighted: Label, Skip, (block symbol). Then press

(1) To label, press V or v to select the alphanumeric

(2) To skip the program number, press V or v to select “On”. Then press . You can skip this program number when using

PROG +/–. (3) To block unwanted program number, press V or v to

select . Then press .

channels.

Confirm

End

Press WEGA GATE to exit.

• If you preset a blocked program number, that program number will be unblocked automatically.

• If you sort a blocked program, that program will remain blocked.

Page 15

“Channel Setup” setting (continued)

Presetting channels manually

After selecting “Manual Program”, select the program

number to which you want to preset a channel.

(1) Make sure “Program” is selected, then press .

(2) Press V or v

to preset appears on the menu, then press

Select the desired channel.

(1) Make sure either “VHF Low”, “VHF High” or “UHF” is selected, then press

(2) Press V or v until the desired channel’s broadcast appears on the TV screen,

then press .

If the sound of the desired channel is abnormal, select the appropriate TV

system.

(1) Press V or v

(2) Press V or v

If you are not satisfied with the picture and sound quality, you may be able

to improve them by using the “Fine” tuning feature.

(1) Press V or v

(2) Press V or v to select “Manual”, then press .

Press V,v,B or b until the picture and sound quality are optimal, then press .

(3)

The + or – icon on the menu flashes while tuning.

until the program number you want

to select “TV System”, then press .

until the sound becomes normal, then press .

to select “Fine”, then press .

If the TV signal is too strong (picture distorted; picture with lines; signal

interference) or weak (snowy picture), you may be able to improve the picture quality by setting the “Signal Booster” feature.

(1) Press V or v

(2) Press V or v

signal interference) or “Auto” (for snowy picture), then press .

to select “Signal Booster”, then press .

to select either “Off” (for picture distorted; picture with lines;

Page 16

“Setup” setting

Press WEGA GATE and select “Settings”. Press V or v to select the “Setup” icon (

then press .

Setup

Language:

Picture Position

Video Label Color System: Auto

Factory Settings

Select

“Language” Change the menu language.

Press V or v to select either “English” or “ ” (Chinese), then press .

“Picture Position” Adjust the picture position when it is not aligned with the TV

screen. Press V or v to select “Picture Rotation” or “Picture V-Position”, then press .

Press V,v,B or b to adjust the picture position, then press .

“Video Label” Label the connected equipment.

(1) Select “Video Input” and press . Press V or v to select the

input you want to label, then press .

(2) Select “Label” and press , then press V or v to select

the label options: “Video 1”/“Video 2”/”DVD”, “VCR”,

“SAT”, “Game” or “Edit”*. * You may edit the video label to your favorite name. Press V or v to select alphanumeric characters for the label, then press .

“Color System” Select the color system.

Press V or v to select either “Auto”, “PAL”, “SECAM”, “NTSC3.58” or “NTSC4.43”, then press . Normally, set this to “Auto”.

“Factory Settings”

Reset your TV to factory settings. Press and press V or v to select “Yes”. Then press . Your TV will go blank for a few seconds, then the “Initial Setup”

menu will appear. To cancel, select “No”, then press .

Confirm

English

End
