Television
Reference Guide
KD-75X8500C / 65X8500C / 55X8500C / 49X8500C / 49X8300C / 43X8300C
Table of Contents
Safety information . . . . . . . . . . . . . . . . . . . . .2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts and Controls . . . . . . . . . . . . . . . . . . . 6
Controls and Indicators . . . . . . . . . . . . . . . . . 6
Inputs and Outputs . . . . . . . . . . . . . . . . . . . . 7
Using Remote Control . . . . . . . . . . . . . . . 10
Remote Control Parts Description. . . . . . . . 10
Using the Touchpad Remote Control . . . . . 12
Launching the Touchpad Remote Control
Introduction/Tutorial . . . . . . . . . . . . . . . . . . 12
Connecting the TV . . . . . . . . . . . . . . . . . . 12
Installing the TV to the Wall . . . . . . . . . . 16
SU-WL500 (KD-75X8500C) . . . . . . . . . . . . . . 17
SU-WL450 (KD-65/55/49X8500C,
KD-49/43X8300C). . . . . . . . . . . . . . . . . . . . .20
Troubleshooting. . . . . . . . . . . . . . . . . . . . 23
Troubles and Solutions . . . . . . . . . . . . . . . .23
Specifications . . . . . . . . . . . . . . . . . . . . . . 24
Introduction
Thank you for choosing this Sony product.
Before operating the TV, please read this manual thoroughly and
retain i t for future reference.
Note
• Before operating the TV, please read “Safety information”
(page 2).
• Instructions about “Installing the TV to the Wall” are included
within this TV’s instructions manual.
• Images and illustrations used in Startup Guide and this manual
are for referenc e only and ma y differ from actual product
appearance.
Location of the identification label
Labels for the TV Model No. and Power Supply rating are located
on the rear of the TV.
Notice for customers in Thailand
This telecommunication equipment conforms to NTC technical
requirement.
Notes for Australia and New Zealand model
This product is ENERGY RATING qualified in the default mode.
ENERGY RATING is a programme designed to promote energy
efficient products and practices.
• When the TV is initially set up, it is designed to meet ENERGY
RATING requirements while maintaining optimum picture
quality.
• Changes to certain features, settings and functionalities of this
TV (e.g. TV Guide, Picture/So und, Eco setting) can slightly
change the power consumption.
Depending upon such changed settings (e.g. Shop mode), the
power consumption may vary which possibly could exceed the
stated energy rating.
To reset the TV to ENERGY RATING qualified settings, complete
the initial set-up procedure in [Auto Start-up] under the settings
menu.
IMPORTANT INFORMATION
If a television is not positioned in a sufficiently stable location, it
can be potentially hazardous due to falling. Many injuries,
particularly to children, can be avoided by taking simple
precautions such as:
• Using cabinets or stands recommended by the manufacturer of
the television.
• Only using furniture that can safely support the television.
• Ensuring the television is not overhanging the edge of the
supporting furniture.
• Not placing the television on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture
and the television to a suitable support.
• Not standing the televisions on cloth or other materials placed
between the television and supporting furniture.
• Educating children about the dangers of climbing on furniture
to reach the television or its control s.
Safety information
WARNING
Batteries must not be exposed to excessive heat such as
sunshine, fire or the like.
Installation/Set-up
Install and use the TV set in accordance with the instructions
below in order to avoid any risk of fire, electrical shock or damage
and/or injuries.
Installation
• The TV set should be installed near an easily accessible AC
power outlet (mains socket).
• Place the TV set on a stable, level surface to avoid it from falling
down and cause personal injury or damage to the TV.
• Install the TV where it cannot be pulled, pushed, or knocked
over.
GB
2
• Only qualified service personnel should carry out wall
Screw
Wall-Mount Bracket
8 mm - 12 mm
TV’s rear cover
30 cm
10 cm
10 cm
10 cm
Leave at least this space around the set.
30 cm
10 cm
10 cm
Leave at least this space around the set.
6 cm
Air circulation is blocked.
Wall Wall
installations.
• For safety reasons, it is strongly recommended that you use
Sony accessories, including:
Wall-Mount Bracket SU-WL500 (KD-75X8500C)
Wall-Mount Bracket SU-WL450 (KD-65/55/49X8500C, KD-49/
43X8300C)
• Be sure to use the screws supplied with the Wall-Mount Bracket
when attaching the Wall-Mount Bracket to the TV set. The
supplied screws are designed as indicated by illustration when
measured from the attaching surface of the Wall-Mount Bracket.
The diameter and length of the screws differ depending on the
Wall-Mount Bracket model.
Use of screws other than those supplied may result in internal
damage to the TV set or cause it to fall, etc.
Tran spo rti ng
• Before transporting the TV set, disconnect all cables.
• Two or three people are needed to transport a large TV set.
• When transporting the TV set by hand, hold it as shown below.
Do not put stress on the LCD panel and the frame around the
screen.
• When transporting the TV set, do not subject it to jolts or
excessive v ibration.
• When transporting the TV set for repairs or when moving, pack
it using the original carton and packing material.
Ventilation
• Never cover the ventilation holes or insert anything in the
cabinet.
• Leave space around the TV set as shown below.
• It is strongly recommende d that you use a Sony Wall-Mount
Bracket in order to provide adequate air circulation.
Installed on the wall
• To ensure proper ventilation and prevent the collection of dirt or
dust:
Do not lay the TV set flat, install upside down, backwards, or
sideways.
Do not place the TV set on a shelf, rug, bed or in a closet.
Do not cover the TV set with a cloth, such as curtains, or items
such as newspapers, etc.
Do not install the TV set as shown below.
AC power cord (mains lead)
Handle the AC power cord (mains lead) and outlet (mains socket)
as follows in order to avoid any risk of fire, electrical shock or
damage and/or injuries:
Insert the plug fully into the AC power outlet (mains socket).
Operate the TV set on a 110–240 V AC supply only.
When wiring cables, be sure to unplug the AC power cord
(mains lead) for your safety and take care not to catch your feet
on the cables.
Disconnect the AC power cord (mains lead) from the AC power
outlet (mains socket) before working on or moving the TV set.
Keep the AC power cord (mains lead) away from heat sources.
Unplug the AC power plug (mains plug) and clean it regularly. If
the plug is covered with dust and it picks up moisture, its
insulation may deteriorate, which could result in a fire.
Note
• Do not pinch, bend, or twist the AC power cord (mains lead)
excessively. The core conductors may be exposed or broken.
• Do not modify the AC power cord (mains lead).
• Do not put anything heavy on the AC power cord (mains lead).
• Do not pull on the AC power cord (mains lead) itself when
disconnecting the AC power cord (mains lead).
• Do not connect too many appliances to the same AC power
outlet (mains socket).
• Do not use a poor fitting AC power outlet (mains socket).
Prohibited Usage
Do not install/use the TV set in locations, environments or
situations such as those listed below, or the TV set may
malfunction and cause a fire, electrical shock, damage and/or
injuries.
Location:
• Outdoors (in direct sunlight), at the seashore, on a ship or other
vessel, inside a vehicle, in medical institutions, unstable
locations, near water, rain, moisture or smoke.
• If the TV is placed in the changing room of
a public bath or hot spring, the TV may be
damaged by airborne sulfur, etc.
GB
Installed with stand
• For best picture quality, do not expose the screen to direct
illumination or sunlight.
• Avoid moving the TV from a cold area to a warm area. Sudden
room temperature changes may cause moisture condensation.
This may cause the TV to show poor picture and/or poor colour.
Should this occur, allow moisture to evaporate completely
before powering the TV on.
Environment:
Places that are hot, humid, or excessively dusty; where insects
may enter; where it might be exposed to mechanical vibration,
near flammable objects (candles, etc). The TV set shall not be
exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the TV.
3
GB
Do not place the TV in a humid or
dusty space, or in a room with oily
smoke or steam (near cooking tables
or humidifiers). Fire, electric shock, or
warping may result.
Do not install the TV in places subject to extreme temperature,
such as in direct sunlight, near a radiator or a heating vent. The
TV may overheat in such conditions which can cause
deformation of the enclosure and/or TV malfunction.
Situation:
• Do not use when your hands are wet, with the cabinet removed,
or with attachments not recommended by the manufacturer.
Disconnect the TV set from AC power outlet (mains socket) and
antenna (aerial) during lightning storms.
• Do not install the TV so that it sticks out
into an open space. Injury or damage
from a person or object bumping into
the TV may result.
Broken pieces:
• Do not throw anything at the TV set. The screen glass may break
by the impact and cause serious injury.
• If the surface of the TV set cracks, do not touch it until you have
unplugged the AC power cord (mains lead). Otherwise electric
shock may result.
When not in use
• If you will not be using the TV set for several days, the TV set
should be disconnected from the AC power (mains) for
environmental and safety reasons.
• As the TV set is not disconnected from the AC power (mains)
when the TV set is just turned off, pull the plug from the AC
power outlet (mains socket) to disconnect the TV set
completely.
• However, some TV sets may have features that require the TV
set to be left in standby to work correctly.
For children
• Do not allow children to climb on the TV set.
• Keep small accessories out of the reach of children, so that they
are not mistakenly swallowed.
If the following problems occur...
Turn off the TV set and unplug the AC power cord (mains lead)
immediately if any of the following problems occur.
Ask your dealer or Sony service centre to have it checked by
qualified service personnel.
When:
AC power cord (mains lead) is damaged.
Poor fitting of AC power outlet (mains socket).
TV set is damaged by being dropped, hit or having something
thrown at it.
Any liquid or solid object falls through openings in the cabinet.
About LCD Monitor Temperature
When the LCD Monitor is used for an extended period, the panel
surrounds become warm. You may feel hot when touching there
by the hand.
Precautions
Viewing the TV
• View the TV in moderate light, as viewing the TV in poor light or
during long period of time, strains your eyes.
• When using headphones, adjust the volume so as to avoid
excessive levels, as hearing damage may result.
(3D compatible models only)
• Some people may experience discomfort (such as eye strain,
fatigue, or nausea) while watching 3D video images or playing
stereoscopic 3D games. Sony recommends that all viewers take
regular breaks while watching 3D video images or playing
stereoscopic 3D games. The length and frequency of necessary
breaks will vary from person to person. You must decide what
works best. If you experience any discomfort, you should stop
watching the 3D video images or playing stereoscopic 3D
games until the discomfort ends; consult a doctor if you believe
necessary. You should also review (i) the instruction manual of
any other device or media used with this television and (ii) our
website (http://www.sony-asia.com/support) for the latest
information. The vision of young children (especially those
under six years old) is still under development. Consult your
doctor (such as a pediatrician or eye doctor) before allowing
young children to watch 3D video images or play stereoscopic
3D games. Adults should supervise young children to ensure
they follow the recommendations listed above.
• Do not use, store, or leave the 3D Glasses or battery near a fire,
or in places with a high temp erature, e.g., in direct sunlight, or
in sun-heated cars.
LCD Screen
• Although the LCD screen is made with high-precision
technology and 99.99% or more of the pixels are effective, black
dots may appear or bright points of light (red, blue, or green)
may appear constantly on the LCD screen. This is a structural
property of the LCD screen and is not a malfunction.
• Do not push or scratch the front filter, or place objects on top of
this TV set. The image may be uneven or the LCD screen may be
damaged.
• If this TV set is used in a cold place, a smear may occur in the
picture or the picture may become dark. This does not indicate a
failure. These phenomena disappear as the temperature rises.
• Ghosting may occur when still pictures are displayed
continuously. It may disappear after a few moments.
• The screen and cabinet get warm when this TV set is in use. This
is not a malfunction.
• The LCD screen contains a small amount of liquid crystal. Follow
your local ordinances and regulations for disposal.
Handling and cleaning the screen surface/
cabinet of the TV set
Be sure to unplug the AC power cord (mains lead) connected to
the TV set from AC power outlet (mains socket) before cleaning.
To avoid material degradation or screen coating degradation,
observe the following precautions.
• To remove dust from the screen surface/cabinet, wipe gently
with a soft cloth. If dust is persistent, wipe with a soft cloth
slightly moistened with a diluted mild detergent solution.
• Never spray water or detergent directly on
the TV set. It may drip to the bottom of the
screen or exterior parts and enter the TV set,
and may cause damage to the TV set.
• Never use any type of abrasive pad, alkaline/acid cleaner,
scouring powder, or volatile solvent, such as alcohol, benzene,
thinner or insecticide. Using such materials or maintaining
prolonged contact with rubber or vinyl materials may result in
damage to the screen surface and cabinet material.
• Periodic vacuuming of the ventilation openings is
recommended to ensure to proper ventilation.
• When adjusting the angle of the TV set, move it slowly so as to
prevent the TV set from moving or slipping off from its table
stand.
GB
4
Optional Equipment
Keep optional components or any equipment emitting
electromagnetic radiation away from the TV set. Otherwise
picture distortion and/or noisy sound may occur.
Wireless Function of the unit
• Do not operate this unit near medical equipment (pacemaker,
etc.), as malfunction of the medical equipment may result.
• Although this unit transmits/receives scrambled signals, be
careful of unauthorised interception. We cannot be responsible
for any trouble as a result.
Caution about handling the remote control
• Observe the correct polarity when inserting batteries.
• Do not use different types of batteries together or mix old and
new batteries.
• Dispose of batteries in an environmentally friendly way. Certain
regions may regulate the disposal of batteries. Please consult
your local authority.
• Handle the remote control with care. Do not drop or step on it,
or spill liquid of any kind onto it.
• Do not place the remote control in a location near a heat source,
a place subject to direct sunlight, or a damp room.
Disposal of the TV set
Disposal of Old Electrical &
Electronic Equipment (Applicable in
the European Union and other
European countries with separate
collection systems)
This symbol is on the remote control.
Disposal of the TV set
Disposal of Old Electrical &
Electronic Equipment (Applicable
in Republic of India)
This symbol indicates that this product shall
not be treated as household waste and may
not be dropped in garbage bins. Product
owners are advised to deposit their product at
the nearest collection point for the recycling of
operation shall facilitate proper disposal & help prevent potential
negative consequences/hazards to the environment and human
health, which could otherwise be caused by inappropriate waste
disposal including improper handling, accidental breakage,
damage and/or improper recycling of e-waste. The recycling of
materials will help to conserve natural resources. For more
detailed information about recycling of this product, please
contact your local civic office, your household waste disposal
service provider or the store where you made the purchase. You
may contact our company’s toll free number in India for
assistance.
This product complies with the “India E-waste Rule 2011”. The
E-waste Rules, 2011 is an Indian directive aimed at reducing
the harmful environmental impact of waste electrical
equipment by restricting the use of known hazardous
substances. As of 1st May 2012, new electrical and electronic
equipment introduced into the market may no longer contain
the following chemicals or its specified maximum
concentration levels:
Lead, Mercury, Hexavalent Chromium, Polybrominated
Biphenyls (PBB) or Polybrominated Diphenylethers (PBDE) - in
concentrations exceeding 0.1 weight % and Cadmium - 0.01
weight %, except of exemptions set in Schedule 2 of the
aforesaid Rule.
electrical and electronic equipment. Your co-
Notice for customer in UAE
TRA
REGISTERED No: ER35215/14
DEALER No: DA0065531/11
GB
GB
5
Parts and Controls
Ȫ
ȫ
Ȭ
ȭ
Controls and Indicators
Remote Control sensor*1 / Light
1
sensor*
Transmi tter*
The illumination LED lights up or blinks
according to the status of the TV.
•White
•Cyan
• Pink*
•Amber
/ Illumination LED / 3D Sync
1*3
When turning on the TV/picture off
mode/software update, etc.
When connecting with a mobile device
wirelessly.
2
Recording mode.
Timer is set.
(Power)
CH +/- (Channel)
+/- (Volume)
TV
Switch to a TV channel or input from other
applications.
(Input select)
Display and select the input source.
*1 Do not place anything near the sensor.
*2 Only on limited region/country/TV model.
*3 3D compatible models only.
GB
6
Inputs and Outputs
KD-75/65/55X8500C
GB
GB
7
KD-49X8500C, KD-49/43X8300C
LAN
HDMI 3 AUDIO IN
For HDMI 3 analogue audio connection.
DIGITAL AUDIO OUT (OPTICAL)
VIDEO IN 2, / COMPONENT IN
• For a composite connection:
Use VIDEO IN 2, and (L/R) of /
COMPONENT IN*1.
• For a component connection:
Use Y, PB, PR, and (L/R).
/ VIDEO IN 1
For a composite connection, use the
supplied Analogue Extension Cable*1.
CABLE/ANTENNA
Connect to your cable or antenna (aerial).
GB
8
(USB 1/2), (USB 3)
(except Australia and New Zealand model)
(USB 1/2), (USB 3 (HDD
3
*2*
REC))
(Australia and New Zealand model only)
• Connecting a large USB device may
interfere with other connected devices
beside it.
• When connecting a large USB device,
connect to the USB 1 jack.
HDMI IN 1/3/4
• If the device has a DVI jack, connect it to
HDMI IN 3 through a DVI - HDMI adaptor
interface (not supplied), and connect the
device's audio out jack to HDMI 3 AUDIO
IN.
• If connecting a digital audio system that is
compatible with Audio Return Channel
(ARC) technology, use HDMI IN 4. If not, an
additional connection with DIGITAL AUDIO
OUT (OPTICAL) is necessary.
AUDIO OUT /
To listen to the TV's sound through the
connected equipment, press HOME. Select
[Settings] [Sound] [Headphone/Audio
out] and then select the desired item.
HDMI IN 2/MHL
You can connect your MHL (Mobile Highdefinition Link) device using an HD quality
MHL cable.
*1 When connecting mono equipment, connect to the L
(MONO) audio jack.
*2 Only on limited region/country/TV model.
*3 HDD REC function will be available from mid 2015.
You will receive HDD REC function automatically as a
sof tware upgra de. Ma ke sur e your TV is conne cted t o
the Internet. If you do not have a network
connection, you will be able to download the
software from the Sony support website using your
PC. For details on how to upgrade, please visit the
Sony support website. To stay informed about the
exact release date, please subscribe at
http://www.sony.com.au/braviausbrecording
http://www.sony.co.nz/braviausbrecording
GB
GB
9
Using Remote Control
Ȫ
ȩ
ȫ
Ȭ
ȭ
Ȯ
ȯ
IR (infrared) Remote Control Touchpad Remote Control
For models with supplied Touchpad Remote
Control.
Remote Control Parts Description
/ (Input select/Text hold)
In TV mode: Display and select the input
source.
In Text mode: Hold the current page.
SYNC MENU*
Display the BRAVIA Sync Menu.
1
(TV standby)
Turn on or turn off the TV (standby mode).
DIGITAL/ANALOG
Switch between digital and analogue mode.
EXIT
Return to the previous screen or exit from
the menu. When an Interactive Application
service is available, press to exit from the
service.
FOOTBALL*
Turn Live Football Mode on or off (when the
feature is available).
1
Number buttons
(Twin picture/PIP)*
Display two pictures simultaneously.
(Text)
Display text information.
Colour buttons
Execute correspondent function at that time.
/ (Info/Text reveal)*
Display information.
GB
10
1*3
1
NETFLIX*
1
Access the “NETFLIX” online service.
HELP
Display Help Menu
ACTION MENU
Display a list of contextual functions.
You can also display it by slide down your
finger from ACTION MENU on the Touchpad
Remote Control.
1
TV*
Switch to a TV channel or input from other
applications.
GUIDE/ *
1
Display the digital programme guide.
BACK
Return to previous screen.
HOME
Display the TV Home Menu.
DISCOVER
Bring up the Content Bar to search for
content.
You can also launch Content Bar by slide up
your finger from DISCOVER on the
Touchpad Remote Control.
//// (Item select/Enter)
+/– (Volume)
Adjust the volume.
(Jump)
Jump back and forth between two channels
or inputs. The TV alternates between the
current channel or input and the last
channel or input that was selected.
(Muting)
Mute the sound. Press again to restore the
sound.
PROG +/–//
In TV mode: Select the channel.
In Text mode: Select the next () or
previous () page.
AUDIO
Change the language for the programme
currently being viewed.
(Subtitle setting)
Turn subtitles on or off (when the feature is
available).
(Wide mode)*
1
Change the screen format.
//////
Operate media contents on TV and
connected BRAVIA Sync-compatible device.
REC*1*
2
Record the current programme with the USB
HDD recording function.
TITLE LIST*
1
Display the Title list.
(Microphone)
Use Voice Function. (e.g., Search various
content by voice.)
Touchpad
Operate the TV with the touchpad.
(NFC)
Touch the device (e.g. some models of
Xperia) corresponding to the One-touch
mirroring function, then its screen is
displayed on the TV.
*1 The location, availability and function of remote
control button may vary depending on your country/
region/TV model .
*2 HDD REC function will be available from mid 2015.
You will receive HDD REC function automatically as a
sof tware upgra de. Make s ure yo ur TV is con necte d to
the Internet. If you do not have a network
connection, you will be able to download the
software from the Sony support website using your
PC. For details on how to upgrade, please visit the
Sony support website. To stay informed about the
exact release date, please subscribe at
http://www.sony.com.au/braviausbrecording
http://www.sony.co.nz/braviausbrecording
*3 Twin Picture function will be available from July 2015.
You will receive Twin Picture function automatically
as a n etwor k software u pgrade. Ma ke sure your TV is
connected to the Internet. If you do not have a
network connection, you will be able to download
the software from the Sony support website using
your PC. For details on how to upgrade, please visit
the Sony support website.
GB
GB
11
Using the Touchpad Remote Control
To H DMI OUT
< 12 mm
< 21 mm
Touchpad Remote Control can only be used
after pairing with the TV.
To pair, follow the pairing screen instruction.
Pairing screen can be displayed by pressing the
button on the TV for 5 seconds, or select
[Settings] - [Touchpad Remote Control settings]
- [Pair Touchpad Remote Control].
Launching the Touchpad Remote Control Introduction/Tutorial
1 Press HOME.
2 Select [Settings] - [Touchpad Remote
Control settings] - [Start Introduction/
Tutor ial ].
Connecting the TV
Note
• To select an input device connected to the TV, press
.
To connect with an HDMI cable
KD-75/65/55X8500C
GB
12
KD-49X8500C, KD-49/43X8300C
To H DMI OUT
< 12 mm
< 21 mm
To AUDIO
OUT
To C OM PON EN T
OUT (P
R/PB/Y)
To connect with component cables
GB
GB
13
To connect with Analogue Extension
To VIDEO OUT
To VIDEO OUT
Use authorized MHL
CABLE with MHL
logo (not supplied)
MHL device
Use authorized MHL
CABLE with MHL
logo (not supplied)
MHL device
Cable
KD-75/65/55X8500C
KD-49X8500C, KD-49/43X8300C
To connect MHL device
KD-75/65/55X8500C
KD-49X8500C, KD-49/43X8300C
14
GB
The TV simultaneously charges the MHL-
Picture Quality
• AV composite cable
• Antenna (aerial) cable
Standard definition (SD) videos have picture signals with a
vertical resolution of 480 (NTSC) or 576 (PAL/SECAM) lines.
•Component cable •HDMI cable
High definition (HD) videos have picture signals
with a vertical resolution of 720 or 1,080 lines.
(For 4K vertical resolution: 2,160 lines)
compatible connected device while playing
photo/music/video files. You can use the TV
remote control to control the connected MHLcompatible device.
Note
• If [MHL charging during standby] is set to [On], you
can continue charging the MHL-compatible device
even when the TV is in standby mode.
• Use authorized MHL 3 CABLE with MHL logo for 4K
smartphone or mobile devices.
GB
GB
15
Installing the TV to the Wall
This TV’s instruction manual only shows the steps on preparing the installation of the TV before
installing to the wall.
To Customers:
For product protection and safety reasons, Sony strongly recommends that installation of your
TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the installation, periodic maintenance and examination of
this product.
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for
withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers
or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for
any damage or injury caused by mishandling or improper installation.
Use the Wall-Mount Bracket SU-WL500 (not supplied) (KD-75X8500C) and SU-WL450 (not
supplied) (KD-65/55/49X8500C, KD-49/43X8300C) to install the TV to the wall.
When installing the Wall-Mount Bracket, also refer to the Operating Instructions and Installation Guide
supplied with the Wall-Mount Bracket.
Note
• Be sure to store the removed screws in a safe place, keeping them away from children.
To remove the screws from the rear of the TV (KD-75/65X8500C)
GB
16
To change the cable management (KD-55/49X8500C, KD-49/43X8300C)
Mounting Hook
Screw (+PSW 6 × 16)
SU-WL500 (KD-75X8500C)
1 Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket.
GB
GB
17
2 Make sure that the wall has enough space for the TV and is capable of supporting a
Screen centre point
weight of at least four times that of the TV. Refer to the following table on installing the TV
to the wall. See page 24-26 (Specifications) for the TV’s weight.
Model Name
Display dimensions
KD-
75X8500C 1,675 970 21 131 471 427 497
Note
• Figures in the table may differ slightly depending on the installation.
Screen centre
dimension
Length for mounting
Angle (0°) Angle (20°)
3 Connect necessary cables to the TV.
4 Detach the Table-Top Stand from the TV.
Unit: mm
Note
• When attaching the Table-Top Stand again, be sure to fasten the screws (previously removed) to the original
holes on the rear of the TV.
GB
18
5 Install the TV on the wall.
Hook location
When installing the TV onto the Base Bracket.
Screw location
When installing the Mounting Hook on the TV.
a
Model Name
KD-
75X8500C e, j a
Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
Screw location Hook location
GB
GB
19
SU-WL450 (KD-65/55/49X8500C, KD-49/43X8300C)
Screen centre point
Standard
mounting
Slim
mounting
1 Make sure that the wall has enough space for the TV and is capable of supporting a
weight of at least four times that of the TV.
Refer to the following table on installing the TV to the wall. See page 24-26 (Specifications)
for the TV’s weight.
Display dimensions
Model Name
KD-
65X8500C 1,453 844 21 450 133 91
55X8500C 1,236 722 116 485 115 73
49X8500C 1,093 643 206 536 107 65
49X8300C 1,093 643 206 536 107 65
43X8300C 961 568 191 483 107 65
Note
• Figures in the table may differ slightly depending on the installation.
• When your TV is installed on the wall, the upper side of the TV slightly leans forward.
Screen
centre
dimension
Length for mounting
Standard
mounting
mounting
Unit: mm
Slim
GB
20
2 Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by
Screw (+PSW 6 x 20)
Pulley
Screw (+PSW 6 x 50)
Belt
Spacer (60 mm)
referring to “1” of the Wall-Mount Bracket Installation Guide.
Note
• If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}.
• Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference.
Standard mounting
Slim mounting
Note
• You cannot use some of the terminals on the rear of the TV when using this mounting style.
Connect the Analogue Extension Cable (Availability depends on countries/regions/TV models) if you need to
use the / VIDEO IN 1 jack.
GB
GB
21
3 Connect necessary cables to the TV.
Screw (+PSW 6 x 20)
Pulley
Screw (+PSW 6 x 20)
Belt
Spacer (20 mm)
a
b
c
d
Note
• You cannot access to any terminal after installing the TV to the wall.
4 Detach the Table-Top Stand from the TV.
5 Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the
Wall” of Operating Instructions supplied with the Wall-Mount Bracket.
Model Name KD- Hook location
65X8500C a
55X8500C
49X8500C
49X8300C
43X8300C c
Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
b
22
GB
Rear of TV
Troubleshooting
In order to keep your TV software up-to-date, it
is necessary to download the latest software
information via the digital broadcasting system
or internet and to update the software. Select
[Update Now] to start a software update. The
illumination LED flashes white while the
software is updating. Do not unplug the AC
power cord (mains lead) during the software
update. If you do, the software update may not
finish completely, and it may cause a software
malfunction. Software updates can take up to
30 minutes. If you do not wish to update the
software automatically, press HOME and select
[Help] [System software update]
[Automatic software download] [Off].
When you unplug the TV and plug it in again,
the TV may not be able to turn on for a while
even if you press the power button on the
remote control or the TV because it takes time
to initialize the system. Wait for about 10 to 20
seconds, then operate it again.
When the illumination LED is flashing in red,
count how many times it flashes (interval
time is three seconds).
If the illumination LED flashes red, reset the TV
by disconnecting the mains lead from the TV for
two minutes, then turn on the TV.
If the problem persists, contact your dealer or
Sony service centre with the number of times
the illumination LED flashes red (interval time is
three seconds). Disconnect the mains lead, and
inform your dealer or Sony service centre.
When the illumination LED is not flashing,
check the items as follows.
You can also refer to [Troubleshooting] in the
Help Guide or perform self-diagnosis by
selecting [Help] [Self diagnostics]. If the
problem persists, have your TV serviced by
qualified service personnel.
Troubles and Solutions
There is no picture (screen is dark) and no
sound.
Check the antenna (aerial)/cable connection.
Connect the TV to the AC power (mains), and
press on the TV or remote control.
Some programmes cannot be tuned.
Check the antenna (aerial)/cable connection.
The remote control does not function.
Replace the batteries.
The [Parental lock] password has been
forgotten.
Enter 9999 for the PIN code. (PIN code 9999 is
always accepted.)
The TV surrounds become warm.
When the TV is used for an extended period, the
TV surrounds become warm.
You may feel hot when touching there by the
hand.
Frozen audio or video, a blank screen, or the
TV does not respond to TV or remote control
buttons.
Perform a simple reset of the TV by unplugging
the AC power cord (mains lead) for two minutes,
then plug it in again.
The , CH+/–, +/–, and TV buttons
cannot be located on the TV.
See below illustration for location of the buttons
on the TV.
The illumination LED is turned on.
If you do not wish to light up the illumination LED,
you can turn it off.
Press HOME, then select
[Illumination LED] t [Off].
[Settings] t
Cannot connect to a wireless router by WPS
(Wi-Fi Protected Setup).
• If you use WEP security, select [Easy] t [Wi-Fi] t
[Connect by scan list]. Then, select the network
name (SSID) you want to connect.
Cannot find the required network name in
network setup.
• Select [[Manual entry]] and press to enter
network name.
GB
23
GB
Specifications
System
Pane l system
LCD (Liquid Crystal Display) Panel, LED Backlight
TV system
Analogue: B/G, I, D/K, M : Depend on your
country/area selection.
Digital: DVB-T/DVB-T2 : Depend on your country/
area selection.
Colour/video system
Analogue: PAL, SECAM, NTSC3.58, NTSC4.43
Digital: Refer to the Help Guide
Channel coverage
Analogue: UHF/VHF/Cable, Depending on your
country/area selection.
Digital: UHF/VHF, Depending on your country/
area selection.
Sound output
10 W + 10 W
Wireless technology
Protocol IEEE802.11ac/a/b/g/n
(IEEE802.11ac may not be available depending on
countries/regions.)
Bluetooth Version 4.1
Input/Output jacks
Antenna (aerial)/cable
75 ohm external terminal for VHF/UHF
/ VIDEO IN 1
Video/Audio input (mini jack)
/ COMPONENT IN
YPBPR (Component Video): 1080p (50, 60 Hz),
1080i (50, 60 Hz), 720p (50, 60 Hz), 576p, 576i,
480p, 480i
Audio input (phono pin jack)
VIDEO IN 2
Video input (common phono pin with Y input)
HDMI IN 1, 2, 3, 4 (support 4K resolution)
Video (2D):
4096 × 2160p (50, 60 Hz)*
2
Hz)*
, 3840 × 2160p (50, 60 Hz)*1, 3840 × 2160p
(24, 25, 30 Hz), 1080p (30, 50, 60 Hz), 1080/24p,
1080i (50, 60 Hz), 720p (30, 50, 60 Hz), 720/24p,
576p, 576i, 480p, 480i, PC Formats
*1 YCbCr 4:2:0 / 8bit only
*2 3840 × 2160p is displayed when 4096 × 2160p is
input
Video (3D) (3D compatible models only):
Frame Packing: 1080p (30 Hz), 1080/24p,
1080i(50, 60 Hz), 720p (30, 50, 60 Hz), 720/24p
Side-by-Side: 1080p (50, 60 Hz), 1080/24p,
1080i(50, 60 Hz), 720p (50, 60 Hz)
1*2
, 4096 × 2160p (24
Over-Under: 1080p (30, 50, 60 Hz), 1080/24p,
1080i (50, 60 Hz), 720p (50, 60 Hz)
Audio: 5.1 channel linear PCM: 32, 44.1, 48, 88.2,
96, 176.4 and 192 kHz, 16, 20 and 24 bits, Dolby
Digital and DTS
ARC (Audio Return Channel) (HDMI IN 4 only)
MHL (HDMI IN 2)
Video (2D):
4096 × 2160p (24 Hz)*, 3840 × 2160p (24, 25, 30
Hz), 1080p (30, 50, 60 Hz), 1080/24p, 1080i (50,
60 Hz), 720p (30, 50, 60 Hz), 720/24p, 576p, 576i,
480p, 480i
* 3840 × 2160p is displayed when 4096 × 2160p is
input
Video (3D) (3D compatible models only):
Frame Packing: 1080p (30 Hz), 1080/24p, 1080i
(50, 60 Hz), 720p (30, 50, 60 Hz), 720/24p
Side-by-Side: 1080p (50, 60 Hz), 1080/24p,
1080i (50, 60 Hz), 720p(50, 60 Hz)
Over-Under: 1080p (50, 60 Hz), 1080p (30 Hz),
1080/24p, 1080i (50, 60 Hz), 720p (50, 60 Hz)
Audio: 5.1 channel linear PCM: 32, 44.1, 48, 88.2,
96, 176.4 and 192 kHz, 16, 20 and 24 bits, Dolby
Digital and DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM,
Dolby Digital, DTS)
HDMI 3 AUDIO IN
Analogue audio input (Stereo mini jack)
AUDIO OUT / (Stereo mini jack)
Headphone, Audio Output, Subwoofer
1, 2, 3 (Except Australia and
New Zealand model)
USB port 1 and 2 support High Speed USB
(USB2.0).
USB port 3 supports Super Speed USB (USB3.0)
1, 2, 3 (HDD REC)*4, (Australia
and New Zealand model only)
USB device port. ( 3 USB HDD device for
REC feature)
USB port 1 and 2 support High Speed USB
(USB2.0).
USB port 3 supports Super Speed USB (USB3.0)
LAN
10BASE-T/100BASE-TX connector (Depending on
the operating environment of the network,
connection speed may differ. 10BASE-T/100BASETX communication rate and communication
quality are not guaranteed for this TV.)
24
GB
Others
Optional accessories
Touchpad Remote Control: RMF-TX100E (KD-49/
43X8300C)
Wall-Mount Bracket: SU-WL500 (KD-75X8500C),
SU-WL450 (KD-65/55/49X8500C, KD-49/
43X8300C)
Wireless subwoofer: SWF-BR100
MHL cable: DLC-MC10, DLC-MC20, DLC-MC30
Active 3D Glasses: TDG-BT500A (KD-75/65/
55X8500C)
Operating temperature
0 ºC – 40 ºC
Operating humidity
10 % – 80 % RH (non-condensing)
Power and others
Power requirements
110 V - 240 V AC, 50/60 Hz
Energy Efficiency Class (For Jordan Only)
KD-65X8500C: A
KD-55X8500C: A
Screen size (measured diagonally) (Approx.)
KD-75X8500C: 75 inches / 189.3 cm
KD-65X8500C: 65 inches / 163.9 cm
KD-55X8500C: 55 inches / 138.8 cm
KD-49X8500C: 49 inches / 123.2 cm
KD-49X8300C: 49 inches / 123.2 cm
KD-43X8300C: 43 inches / 108.0 cm
Display resolution
3,840 pixels (horizontal) × 2,160 lines (vertical)
Power consumption
Indicated on the rear of the TV
Power Consumption (For Jordan Only)
In [Standard] mode
KD-65X8500C: 149 W
KD-55X8500C: 115 W
In [Vivid] mode
KD-65X8500C: 261 W
KD-55X8500C: 202 W
Average annual energy consumption*1 (For
Jordan Only)
KD-65X8500C: 207 kWh
KD-55X8500C: 160 kWh
Standby power consumption*2*3 (For Jordan
Only)
KD-65X8500C: 0.50 W
KD-55X8500C: 0.50 W
* This information is for EU and other countries whose
relevant regulation is based on EU energy labelling
regulation.
Output Rating
USB 1/2: 5 V, 500 mA MAX
USB 3: 5 V, 900 mA MAX
MHL (HDMI IN 2): 5 V, 1.5 A MAX
Dimensions (Approx.) (w × h × d)
with Table-Top Stand
KD-75X8500C: 1,675 × 1,019 × 323 mm
KD-65X8500C: 1,453 × 892 × 265 mm
KD-55X8500C: 1,236 × 759 × 222 mm
KD-49X8500C: 1,093 × 679 × 201 mm
KD-49X8300C: 1,093 × 679 × 201 mm
KD-43X8300C: 961 × 604 × 189 mm
without Table-Top Stand
KD-75X8500C: 1,675 × 970 × 79 mm
KD-65X8500C: 1,453 × 844 × 78 mm
KD-55X8500C: 1,236 × 722 × 60 mm
KD-49X8500C: 1,093 × 643 × 60 mm
KD-49X8300C: 1,093 × 643 × 60 mm
KD-43X8300C: 961 × 568 × 60 mm
Mass (Approx.)
with Table-Top Stand
KD-75X8500C: 36.3 kg
KD-65X8500C: 25.5 kg
KD-55X8500C: 21.0 kg
KD-49X8500C: 16.1 kg
KD-49X8300C: 15.4 kg
KD-43X8300C: 12.8 kg
without Table-Top Stand
KD-75X8500C: 34.8 kg
KD-65X8500C: 24.1 kg
KD-55X8500C: 19.9 kg
KD-49X8500C: 15.1 kg
KD-49X8300C: 14.4 kg
KD-43X8300C: 11.8 kg
*1 Energy consumption per year, based on the power
consumption of the television operating 4 hours per
day for 365 days. The actual energy consumption will
depend on how the television is used.
*2 Specified standby power is reached after the TV
finishes necessary internal processes.
*3 Standby power consumption will increase when
network connected.
*4 Only on limited region/country/TV model.
Note
• Optional accessories availability depends on
countries/region/TV model/stock.
• Design and specifications are subject to change
without notice.
•This TV set incorporates MHL 3.
GB
25
GB
Notes on Digital TV function
• Any functions related to Digital TV () will only
work in countries or areas where DVB-T/DVB-T2
(MPEG-2 and H.264/MPEG-4 AVC) digital terrestrial
signals are broadcast. Please confirm with your local
dealer if you can receive a DVB-T/DVB-T2 signal where
you live.
• This TV set complies with DVB-T/DVB-T2
specifications, but compatibility with future DVB-T/
DVB-T2 digital terrestrial broadcasts are not
guaranteed.
• Some Digital TV functions may not be available in
some countries/areas.
Trademark information
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of
HDMI Licensing LLC in the United States
and other countries.
• Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
• “BRAVIA” and are trademarks of
Sony Corporation.
• Gracenote, Gracenote eyeQ, Gracenote
VideoID, Gracenote Video Explore, the
Gracenote logo and logotype, and the
“Powered by Gracenote” logo are either
registered trademarks or trademarks of
Gracenote in the United States and/or
other countries.
• Opera® Devices SDK from Opera Software
ASA. Copyright 1995-2014 Opera Software
ASA. All rights reserved.
• Wi-Fi, Wi-Fi Direct, Miracast and Wi-Fi
Protected Setup are trademarks or
registered trademarks of
Wi-Fi Alliance.
• MHL, Mobile High-Definition Link and the
MHL Logo are trademarks or registered
trademarks of MHL Licensing, LLC.
• For DTS patents, see
http://patents.dts.com. Manufactured
under license from DTS, Inc.
DTS, the Symbol, & DTS and the Symbol
together are registered trademarks, and
DTS Digital Surround is a trademark of DTS,
Inc. © DTS, Inc. All Rights Reserved.
• Designed with UEI Technology
Under License from Universal Electronics
Inc. Portions © UEI 2000 – 2014
TM
• The Bluetooth® word mark and logos are
owned by the Bluetooth SIG, Inc. and any
use of such marks by Sony Corporation is
under license. Other trademarks and trade
names are those of their respective
owners.
• TUXERA is a registered trademark of Tuxera
Inc. in the US and other countries.
• USB-IF SuperSpeed USB Trident logo is a
registered trademark of USB Implementers
Forum, Inc.
26
GB
For models with supplied Touchpad
Remote Control:
• The N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
GB
GB
27
