Page 1
Digital Hard Disk Recor dersDigital Hard Disk Recor ders
HSR-X Series
Page 2
1
* 1-channel input, 1 picture/s
** See section on HDD Mirroring Function.
HSR-X200 Single Channel Recorder (with 80/160 GB HDD)
HSR-X200/16 Single Channel Recorder (with 160/320 GB HDD)
HSR-X216/32
Multi Channel Recorder (with 320 GB HDD, 16 Camera Inputs)
Sony’s HSR-X Series of digital hard disk time-lapse recorders deliver superb quality images, outstanding
reliability and greater flexibility to your surveillance systems. Incorporating the Motion-JPEG compression
format, these recorders provide high-quality, high-resolution images and high refresh rates. With each of
these recorders, you get all the benefits associated with a digital format – clear, crisp, undistorted images and
quick access to images.
An added advantage of these HSR-X recorders is their network capability. Users can remotely access, review
and control the recorded information via a network using an optional LAN PC Card*. In addition, these
recorders offer the added benefit of being able to download archived data to Memory Stick
®
media, Compact
Flash Card or Micro Drive with a PC Card Adaptor. These remarkably reliable recorders also reduce
maintenance costs due to their hard disk technology, since there are no tape transport and/or head service
costs compared to analog time-lapse recorders.
The HSR-X Series offers a choice of three recorders to suit a variety of surveillance applications and systems.
The HSR-X200 is a single channel recorder with an 80 GB HDD (Hard Disk Drive) whereas the
HSR-X200/16 is also a single channel recorder but with an e x p a n d e d hard drive capacity of 160 GB.
The HSR-X216/32 is our new multi channel recorder with an extremely large 320GB HDD and a built-in 16
channel multiplexer, all in one compact unit.
The HSR-X200 and HSR-X200/16 single channel digital recorders can be easily installed in existing
surveillance systems as a powerful alternative to analog time-lapse VCRs. The HSR-X200 and HSR-X200/16
recorders are drop-in replacements for analog time-lapse VCRs that are typically used with multiplexers**.
The HSR-X216/32 is a high quality, multi channel recorder that combines the functions of a recorder and
multiplexer into one unit. This recorder includes versatile functions to allow live and recorded images from
one to sixteen camera inputs to be shown on a monitor in single-camera, four-camera, nine-camera or sixteencamera displays. The HSR-X216/32 can display live images that are being recorded by a monitoring camera
in a split-screen or playback images in a split-screen. Due to the large capacity 320 GB HDD, the HSR-X216/32
recorder dramatically extends recording times.
With this broad reaching, feature-rich lineup, Sony’s HSR-X Series of recorders offer choice and flexibility –
making them ideal for a wide variety of surveillance applications.
* Contact your local Sony sales office for compatible LAN card information.
** Drop-in replacement for multiplexers that accept external switch pulse.
HSR-X Series Digital Hard Disk Recorders
Features
High-Capacity HDDs (ATA/ATAPI-5 Standard)
Two optional HDDs (HSBK-X201: 80 GB for HSR-X200 only,
and HSBK-X201/16:160 GB for HSR-X200 & HRS-X200/16)
can be installed to increase record time or provide mirroring
**
function for the HSR-X200 and HSR-X200/16.
HSR-X216/32
Built-in HDD capacity 320 GB
High mode 2686 hours, 112 days
Hyper mode 1653 hours, 69 days
Maximum recording time in field recording mode*
HSR-X200 HSR-X200/16
Built-in HDD capacity 80 GB 160 GB 80 GB
with the HSBK-X201 160 GB N/AQ 160 GB
with the HSBK-X201/16 240 GB 320 GB 240 GB
High mode*
with the built-in HDD 671 hours, 28 days 1343 hours, 56 days 671 hours, 28
with the HSBK-X201 1343 hours, 56 days N/A 1343 hours, 5
with the HSBK-X201/16 2014 hours, 84 days 2686 hours, 112 days 2014 hours, 8
Hyper mode*
with the built-in HDD 413 hours, 17 days 826 hours, 34 days 413 hours, 17
with the HSBK-X201 826 hours, 34 days
N/A
826 hours, 34
with the HSBK-X201/16 1239 hours, 52 days 1652 hours, 69 days 1239 hours, 5
Page 3
2
High Refresh Rate
By incorporating the Motion-JPEG compression format, the
HSR-X Series can record images at high refresh rates so
crucial moments are not missed.
• Max. 60 fields/s real-time recording and playback
• 27-level recording cycle: 60 fields/s to 1 field every 30 secs.
Field Recording Frame Recording
Picture Quality
Mode Mode
LOW MID HIGH SUPER HYPER
17 KB/field 24 KB/field 32 KB/field 44 KB/field 52 KB/field
Compression ratio
1/22.5 1/15.3 1/11.3 1/8.0 1/6.0
Recording Recording Recording Recording
Speed Interval Speed Interval
Hours Days Hours Days Hours Days Hours Days Hours Days
(field/sec) (sec) (field/sec) (sec)
60.00 0.02 30.0 0.03 21 0.9 15 0.6 11 0.5 8 0.3 7 0.3
30.00 0.03 15.0 0.07 42 1.8 30 1.3 22 0.9 16 0.7 14 0.6
15.00 0.07 7.5 0.13 84 3.5 60 2.5 45 1.9 33 1.4 28 1.2
7.50 0.13 3.8 0.27 169 7.0 119 5.0 90 3.8 65 2.7 55 2.3
1.00 1 0.50 2 1,264 52.7 895 37.3 671 28.0 488 20.3 413 17.2
0.03 30 0.02 60 37,914 1579.8 26,855 1119.0 20,142 839.3 14,648 610.3 12,395 516.4
HSR-X200 (80 GB HDD)
Field Recording Frame Recording
Picture Quality
Mode Mode
LOW MID HIGH SUPER HYPER
17 KB/field 24 KB/field 32 KB/field 44 KB/field 52 KB/field
Compression ratio
1/22.5 1/15.3 1/11.3 1/8.0 1/6.0
Recording Recording Recording Recording
Speed Interval Speed Interval
Hours Days Hours Days Hours Days Hours Days Hours Days
(field/sec) (sec) (field/sec) (sec)
HSR-X200/16 (160 GB HDD)
60.00 0.02 30.0 0.03 42 1.8 30 1.3 22 0.9 16 0.7 14 0.6
30.00 0.03 15.0 0.07 84 3.5 60 2.5 45 1.9 33 1.4 28 1.2
15.00 0.07 7.5 0.13 169 7.0 119 5.0 90 3.8 65 2.7 55 2.3
7.50 0.13 3.8 0.27 337 14.0 239 10.0 179 7.5 130 5.4 110 4.6
1.00 1 0.50 2 2,528 105.3 1,790 74.6 1,343 56.0 977 40.7 826 34.4
0.03 30 0.02 60 75,827 3159.5 53,711 2238.0 40,283 1678.5 29,297 1220.7 24,790 1032.9
1 Channel Input 16 Channel Input
Picture Quality
LOW MID HIGH SUPER HYPER
17 KB/field 24 KB/field 32 KB/field 44 KB/field 52 KB/field
Compression ratio
1/22.5 1/15.3 1/11.3 1/8.0 1/6.0
Recording Recording Recording Recording
Speed Interval Speed Interval
Hours Days Hours Days Hours Days Hours Days Hours Days
(field/sec) (sec) (field/sec) (sec)
60.00 0.02 3.750 0.27 84 3.5 60 2.5 45 1.9 33 1.4 28 1.2
30.00 0.03 1.875 0.53 169 7.0 119 5.0 90 3.8 65 2.7 55 2.3
15.00 0.07 0.938 1.07 337 14.0 239 10.0 179 7.5 130 5.4 110 4.6
7.50 0.13 0.469 2.13 674 28.1 477 19.9 358 14.9 260 10.8 220 9.2
1.00 1 0.063 16 5,055 210.6 3,581 149.2 2,686 111.9 1,953 81.4 1,653 68.9
0.03 30 0.002 480 151,654 6318.9 107,422 4475.9 80,566 3356.9 58,594 2441.4 49,579 2065.8
HSR-X216/32 (320 GB HDD)
These charts show only 6 levels of the 27-level recording cycle.
Audio recording can be performed in colored modes.
Condition: 1% of the HDD is set as archive area and the remaining 99% is set as normal recording area.
High Resolution & High Picture Quality
The HSR-X Series of recorders deliver high-resolution,
high-quality images using the Motion-JPEG compression
format. These recorders capture high-resolution pictures
of 720 x 240 pixels in field recording mode. In addition,
the HSR-X200 and HSR-X200/16 can acquire higher
resolution images of 720 x 480 pixels in frame recording mode.
These recorders also give you the flexibility to select a
balance between picture quality and recording time to meet
your application requirements. You can select from five
levels of picture quality recording modes: Hyper, Super,
High, Middle and Low.
HSR-X200 HSR-X200/16 HSR-X216/32
Field recording mode
720 x 240 720 x 240 720 x 240
(H x V pixels)
Frame recording mode
720 x 480 720 x 480 NA
Picture resolution
Recording time
Hyper 52 KB/picture
Super 44 KB/picture
High 32 KB/picture
Mid 24 KB/picture
Low 17 KB/picture
Picture quality mode
Page 4
3
With the HSR-X216/32’s built-in multiplexing capability, up
to 16 camera images can be recorded and monitored
independently. By combining the functions of a digital
recorder and multiplexer into one unit, the need for an
external multiplexer or switcher is eliminated.
With this
recorder, multiple monitoring patterns such as full screen,
4-division split screen, 9-division split screen, and 16-division
split screen are available, and camera live images can be
sequentially switched at intervals of 1 to 30 seconds. In
addition to these four monitoring patterns, Option Screen*
on the lower right corner can display a camera live image
at the rate of 60 field/s for secure monitoring. Monitoring
patterns in each view can be freely assigned, allowing you
to create your optimum monitoring environment.
(See figure A.)
* Monitoring a camera live image in Option Screen is not available when you
playback images in split screens.
Built-in Multiplexing Capability
(HSR-X216/32)
Compatible with Existing Sony Multiplexers
(HSR-X200 and HSR-X200/16)
Multiple monitoring patterns: HSR-X216/32 only
Single camera system
Multiplexer system
The HSR-X200 and the HSR-X200/16 recorders can easily be
installed in an existing surveillance system as an alternative to
analog time-lapse VCRs that are typically used with Sony
multiplexers (e.g., YS-DX516 or YS-DX504).
By inserting an optional network card (10BASE-T or
100BASE-TX Ethernet)*
1
into any one of the HSR-X Series
of recorders, you can remotely monitor and control a
surveillance system over a TCP/IP network using networked
PCs running a web browser.*
2
Image data can also be
transferred and downloaded via a network. With the HSR-X
recorders, up to four users can simultaneously monitor or
view camera images.*
3
There are three levels of password
protection to qualify the controllable functions: one for only
browsing images, one for both browsing and downloading
images, and one for all controls and settings. In addition,
with the HSR-X216/32, users can view quad, 3 x 3 as well
as 4 x 4*
4
displays via the web browser.
(See figure B.)
*1: Please contact your nearest Sony office or authorized reseller for
compatible network cards.
*
2
: Internet Explorer 5.0 or later recommended.
*
3
: Ver. 1.07 or later (Main firmware) and ver. 1.02 or later (Sub firmware) are
required for the HSR-X200 and HSR-X200/16.
*
4
: HSR-X216/32 only.
Network Capability
* With the HSR-X200 and HSR-X200/16 recorders, the system must
be configured with Sony multiplexers (e.g., YS-DX516 or YS-DX504).
* An optional network card is required.
Figure A
Figure B
Full screen 4-division split screen 9-division split screen
Option
screen
16-division split screen
(HSR-X216/X216P only)
Option screen in
9-division mode
Option screen in16-division mode
(HSR-X216/X216P only)
Option
screen
Camera
VIDEO IN
(COMPOSITE)
MONITOR OUT
Example 1
Multiplexer
(e.g., YS-DX516)
NETWORK
HSR-X200/16
Camera
VIDEO IN (COMPOSITE)
MONITOR OUT
VIDEO OUTVIDEO INSW OUT
MONITOR OUT
Monitor
Monitor
PC
Example 2
Multiplexer
SW OUT
HSR-X200/16
Camera
VIDEO IN (COMPOSITE)
MONITOR OUT
VIDEO OUTVIDEO IN
HSR-X200/16
Monitor
Monitor
Page 5
4
Multiple Data Storage & Backup
Three Storage Areas on the HDD
The HDD of the HSR-X Series of recorders are divided into
three areas – a normal recording area, an alarm recording
area, and an archive area. The recording capacity for the
normal recording and alarm recording areas can be freely
allocated depending on your preferences, and images
recorded in these areas can be copied to the archive
recording area. A maximum of 9999 images can be stored
in the archive recording area.
Various Backup Features
Data copied to the archive area on the HDD can be easily
backed up to various media. A built-in PC card slot on the
front panel of HSR-X recorders enables you to download
images onto a Memory Stick media using a PC card adaptor.
Furthermore, data can be backed up to DDS-2/3* or CD-R*
with an optional SCSI card* via the PC card slot on the rear panel.
* Please contact your nearest Sony office or authorized dealer for compatible
DDS-2/3, CD-Rs, or SCSI cards.
Pre-reverse Play (Playback-during-recording)
The Pre-reverse Play function of HSR-X recorders allows you to
view previously recorded images without having to stop
recording. By setting the pre-reverse time (1 to 99 minutes) on
the setup menu in advance, these recorders instantly playback
images at just the touch of a button while continuing to record.
This feature provides outstanding operation flexibility.
Four Preset Program Recording Modes
(HSR-X216/32 only)
With four types of program recording modes to choose from,
the HSR-X216/32 recorder allows you the flexibility to select
the preferred number of camera inputs and recording speed.*
By registering a particular program recording mode, you can
easily select it again. These modes can be used in conjunction
with timer-recording mode or alarm recording mode.
* Program recording mode supports a maximum of 30 fields/s recording rate.
Independent Record Refresh
(HSR-X216/32 only)
The HSR-X216/32 recorder provides the added benefit of
allowing users to choose recording refresh rates for each
input, up to maximum refresh total of 30 images/second.
Timer Recording
Timer recording can be activated on a weekly or daily basis
with a maximum of eight timer settings.
Alarm Recording
With their flexible alarm-recording settings, the HSR-X
recorders provide a high level of functionality during alarm
incidents. When the recorder detects an alarm internally
generated by the built-in Activity Detection sensor, or an
external alarm input, or both, it automatically switches to alarm
recording mode.
* Alarm recording mode supports a maximum of 30 fields/s recording rate.
• ONLY Mode
When an alarm signal is received, the HSR-X recorders
continuously record the specific camera image that detected the
alarm event.
• SW Mode
This mode prioritizes the recording cycle of the camera that
detected the alarm event.
• Pre-alarm Mode
Images recorded prior to an alarm input are stored on the hard
disk and can be played back when in pre-alarm mode. This mode
helps to verify how alarm incidents have occurred. You can set the
pre-alarm time within the range of 5 seconds to 15 minutes.
* When pre-alarm mode is set to ON, the recording rate is fixed to 15 fields/s
in normal/pre-alarm recording.
Activity Detection Function
The HSR-X recorders are is equipped with an activity detection
sensor that is designed to recognize changes in luminance.
The sensor is based on a 10 x 16 grid (HSR-X216/32)
or 8 x 10 grid (HSR-X200 and HSR-X200/16) on the monitor,
and ten levels of sensitivity are selectable. If a change in
luminance is detected in the assigned area of the grid, an
alarm is triggered. The system allows the user to set the
alarm to begin recording upon activation. In addition, the
HSR-X recorders have an activity detection search function
that allows the user to search recorded material for scenes in
which a change in luminance was detected.
• A and B mode
(HSR-X216/32 only)
The alarm is triggered when a moving object is detected at both
the A point and the B point.
• B to A mode
(HSR-X216/32 only)
The alarm is triggered when an object is detected moving
from the B point to the A point.
Audio Single Channel Recording and Playback
One-channel audio recording and playback is available
within the range of 10 to 60 fields/s.
Normal recording
CAM 2
Alarm recording Normal recording
Alarm input Alarm cancel
Pre-alarm time
(Max. 15 min)
CAM 1 CAM 2 CAM 3 CAM 4 CAM 2 CAM 5 CAM 2 CAM 6 CAM 2 CAM 7 CAM 2 CAM 8 CAM 9
CAM 10
Alarm input
(CAM2)
Alarm cancel
(CAM2)
Alarm recording (SW)
CAM 1 CAM 2 CAM 3 CAM 4 CAM 2 CAM 2 CAM 2 CAM 2 CAM 2 CAM 2 CAM 5 CAM 6 CAM 7 CAM 8
Alarm input
(CAM2)
Alarm cancel
(CAM2)
Alarm recording (ONLY) Normal recordingNormal recording
Comprehensive Recording &
Playback Features
A
B
A
B
A
A
B
B
No alarm
A
A
B
B
Alarm triggered
A BAB
No alarm
ABA
Alarm triggered
B
Page 6
5
Other Convenient Features
2x Digital Zoom
The 2x digital zoom function enlarges a specific area of an
image, allowing you to check the image in greater detail.
RS-232C/RS-485 Interface
The HSR-X recorders are equipped with an RS-232C/RS-485
interface. This enables communication from the recorder to
personal computers, facilitating remote monitoring, playback,
status settings and parameter preset.
Series Recording (HSR-X200 and HSR-X200/16 only)
Multiple recorders can be cascaded to extend the total
recording time. The series recording function allows
sequential recording from deck to deck without interruption.
As soon as the hard disk of one unit reaches capacity, the
next unit is automatically activated.
Video Loss Alarm
(HSR-X200/32 only)
A "video loss" message can be displayed on the monitor
when the signal from a camera is lost during recording or
monitoring, as well as when playing back recorded images.
Power-Failure Protection
In the event of a power failure, a built-in lithium battery
supplies back-up power to the HSR-X recorders to retain
time and setting modes in memory for up to 30 days.
Two Security Lock Levels (User/Administrator Level)
Two levels of security protection can be activated by setting
passwords:
• User level for only playing back images
• Administrator level for both recording and playing back
HDD Mirroring Function
The HSR-X216/32 recorder is equipped with two built-in
hard disks (160 GB x 2). The mirroring function allows the
same data to be recorded on both disks. By installing an
optional HSBK-X201 or HSBK-X201/16 hard disk, you can
activate the same mirroring function for the HSR-X200 and
HSR-X200/16.*
* The maximum HDD mirroring capacity is qualified by the capacity of the
built-in HDD.
* When the HDD mirroring function is set to ON, it supports a maximum of
30 fields/s recording rate.
Various Languages
The HSR-X recorders offer English, French and Spanish
language options.
Intelligent Search Function
The HSR-X recorders feature five types of search functions
to allow you to quickly locate and review required segments:
Alarm Search, Alarm Thumbnail Search, Time/Date Search,
Archive Area Search and Activity Detection Search.
For example, in Alarm Search mode, data on the latest eight
alarm events can be displayed on the monitor. This data
includes alarm number, date, time and the corresponding
camera number. In addition, a thumbnail image of a
specified alarm event can be displayed in the preview zone.
With the Activity Search function, users can search for
activity on previously recorded images on the hard disk.
Variable Speed Picture Search
The HSR-X recorders are equipped with a "no noise" variablespeed picture search function. Simply use the jog/shuttle dial
on the front panel to perform search operations.
<ALARM SEARCH>
Preview zone
MOVE:JOG SELECT:SHUTTLE
Zone cursor
17-11-01
02:36:00 HI-0.12SEC
Page 7
6
System Configuration (HSR-X216/32)
Dimensions
Panel Layout
Multiple camera operation Network operation (e.g., LAN application)
unit: mm (inches)
HSR-X200 & HSR-X200/16
HSR-X216/32
Camera
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
Max.
16 cameras
PC
RS-232C
HSR-X216/32
MONITOR OUT
MONITOR OUT
Monitor
Monitor
Camera
Max.
16 cameras
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
VIDEO IN
(Coaxial)
MONITOR OUT
/32)
13
10 (
/8)
/4)
7
3
376 (14
349 (13
Monitor
HSR-X216/32
LAN
card
ETHERNET
10/100BASE
PC
PC
420 (16
1
/2)
5
/8)
86 (3
96 (3 7/8)
/16)
11
17 (
Page 8
Specifications
HSR-X200 HSR-X200/16 HSR-X216/32
General Weight 5.5 kg (12 lb 2 oz) 7.0 kg (15 lb 7 oz)
Dimensions (W x H x D) 420 x 96 x 376 mm (16 5/8
x 3
7
/8
x 14
7
/8
inches)
Power requirements AC 120 V ±10%, 60 Hz ±10%:
Power consumption 30 W 38 W
Operating temperature 5 to 40 ˚C (41 to 104 ˚F)
Operating humidity Less than 80%
Built-in HDD capacity 80 or 160 GB 160 GB 320 GB
with the HSBK-X201 160 or 240 GB NA NA
with the HSBK-X201/16 240 or 320 GB 240 GB NA
Video Input
1 channel, VBS, VS (BNC), 1.0 Vp-p,75 Ω, unbalanced
16 channels, VBS, VS (BNC), 1.0 Vp-p,75 Ω, unbalanced
1 channel, S-VIDEO (Mini DIN 4-pin)
Loop-out connector: BNC (1)/S-VIDEO (1)
Output
1 channel, VBS, VS (BNC), 1.0 Vp-p,75 Ω, unbalanced
16 channels, VBS, VS (BNC), 1.0 Vp-p,75 Ω, unbalanced
1 channel, S-VIDEO (Mini DIN 4-pin)
Monitor output
—
2 channels, VBS, VS (BNC), 1.0 Vp-p, 75 Ω, unbalanced
1 channel, S-VIDEO (Mini DIN 4-pin)
Video compression Motion-JPEG
Picture quality mode Hyper 52 KB/picture
Super 44 KB/picture
High 32 KB/picture
Mid 24 KB/picture
Low 17 KB/picture
Picture resolution 720 x 240 pixels (Field mode) 720 x 288 pixels (Field mode)
720 x 480 pixels (Frame mode) 720 x 240 pixels (Field mode)
Horizontal resolution More than 500 TV lines (Hyper mode)
Signal-to-noise ratio 48 dB (typical, Hyper mode)
Audio MIC input 1 channel Monaural (Mini jack), -60 dBs, 10 kΩ, unbalanced
Line input 1 channel Monaural (Phono Jack), -8 dBs, 27 kΩ, unbalanced
Line output 1 channel Monaural (Phono Jack), -8 dBs, 600 Ω, unbalanced
Signal-to-noise ratio 40 dB (typical)
Distortion Less than 4% at 1 kHz
Alarm and control input/output RS-232C: D-sub 9-pin RS-232C: D-sub 9-pin
RS-485 (A, B, GND): Push-lock terminals RS-485 (A, B): RJ-11
Alarm in: Normal open (Low active) Alarm in:
Normal open (Low active), x16
Alarm reset in: Normal open (Low active) Sensor alarm out:
5 V, 5.7 kΩ (Low active), x16
Alarm out: 5 V, 5.7 kΩ (Low active) R1/R2: Push-lock terminal
Non rec out: 5 V, 5.7 kΩ (Low active) All: 5 V, 5.7 kΩ (Low active)
Clock set out: 5 V, 5.7 kΩ (Low active) Alarm out: 5 V, 5.7 kΩ (Low active)
Clock set in: Normal open (Low active) Alarm reset out: Normal open (Low active)
Warning out: 5 V, 5.7 kΩ (Low active) Non rec out: 5 V, 5.7 kΩ (Low active)
Disk full out: 5 V, 5.7 kΩ (Low active) Warning out: 5 V, 5.7 kΩ (Low active)
Alarm full out: 5 V, 5.7 kΩ (Low active) Disk full out: 5 V, 5.7 kΩ (Low active)
Remote control input: Push-lock terminals Alarm full out: 5 V, 5.7 kΩ (Low active)
Series out: 5 V, 5.7 kΩ (Low active)
Series in: Low level
Switch out: 5 V, 4.8 kΩ (Low active)
Supplied accessories AC power cord (1), Power cord tie (1), Rack mount kit (1), Operation manual (1)
Optional accessories HSBK-X201 80 GB HDD (HSR-X200 only)
HSBK-X201/16 160 GB HDD (HSR-X200/16 only)
MSA-8A/16A/32A/64A/128A Memory Stick
MSX-256/512/1G Memory Stick PRO
MSAC-PC2 Memory Stick Adaptor
MSAC-PC3 Memory Stick/Memory Stick PRO Adaptor
S-HSR-XFamily
MK10019V1TC03MAR
Printed in USA 5/03
Sony Electronics Inc.
One Sony Drive
Park Ridge, NJ 07656
www.sony.com/security
201-358-4954
©2003 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Design, features and specifications are subject to change without notice.
All non-metric weights and measures are approximates.
Sony, Memory Stick and Memory Stick PRO are trademarks of Sony Corporation.
Loading...
