HDR-
UX10
High Definition DVD Handycam
® Camcorder
Record high definition video directly to DVD or capture it on Memory Stick Duo™ media — it’s your choice with HDR
UX10. Plus, the ClearVid™ CMOS sensor (with Exmor™ technology) and BIONZ™ image processor delivers Full HD
1920 x 1080 video resolution for sharp detail, and also shoots 4 megapixel still images.
1920x1080 Recording
Record stunning, incredibly detailed
video footage in the clarity of 1920 x
1080 Full HD resolution.
Face Detection for Video Footage and
Digital Still Photos
Made possible by the BIONZ™ image
processing engine, Face Detection
technology recognizes up to 8 faces
anywhere in the frame and
automatically controls focus, exposure,
and color to help capture smiling faces
brightly and clearly. Face Detection
also helps make skin tones look natural
without affecting other colors in the
image.
2.3 Megapixel ClearVid™ CMOS
Sensor (with Exmor™ Technology) and
BIONZ
™ Image Processor
Sony's newly designed CMOS image
sensor with delivers bright, vivid, and
spectacularly detailed 2.3 megapixel
(effective) video footage, as well as 4
megapixel still images -- all with
prolonged battery life. Exmor™
technology captures images with high
resolution and high sensitivity. In
addition, the advanced Sony BIONZ™
image processor improves camera
response time and screens out noise so
the signal from each pixel is as pure as
possible.
BIONZ
™ Image Processor
The advanced Sony BIONZ™ Image
Processor uses hardware
-based Large
Scale Integrated (LSI) circuitry that
improves camera response time,
screens out noise before RAW data
conversion, handles Dynamic Range
Optimization processing, and prolongs
battery life.
Exmor™ Imaging Sensor
Exmor™ technology captures video
and still photo images with high
resolution, high sensitivity, and
exceptional detail. Advanced on-
sensor
A/D conversion yields rich tonal
reproduction with high signal-to-noise
ratio.
15X Optical / 180X Digital Zoom
The optical zoom helps to bring the
action close up from far away. In
addition, Digital Zoom Interpolation
means that extreme digital zooming is
clearer, with less distortion than
previous types of digital zoom.
2.7" Wide
(16:9) Hybrid Touch Panel
Clear Photo LCD Plus™ Display (211K
Pixels)
The 2.7" Wide
(16:9) LCD screen
provides exceptional viewing clarity
with improved resolution (211K pixels).
The display rotates up to 270 degrees
for multiple viewing angles, as well as
provides sharp, detailed images for
monitoring or playback. The
widescreen format makes shooting in
16:9 mode and composing shots even
easier.
1
1
Dual Record
While recording video in High Definition
you have the ability to capture still
images directly to Memory Stick Duo™
media (sold separately).
Hybrid Recording to DVD or Memory
Stick® Media
Hybrid recording technology delivers a
new level of flexibility for transferring
your video footage and digital photos
from the camcorder to compatible
viewing devices. Record to DVD media,
or choose instead to record to
removable Memory Stick Duo™ media
or Memory Stick PRO Duo™ media. You
can even select from various dubbing
functions to easily copy video or still
images from Memory Stick media to
DVD -- without using a PC. Images
recorded or transferred to DVD can then
be played directly most DVD Players
(SD), computers, Blu-ray Disc™ players,
and even PlayStation® 3 video game
consoles to share your memories with
friends and family.
DVD Format Video Recording
The DVD recording format, in both
MPEG2 (SD) and AVCHD™ format ,
delivers digital picture and sound
quality comparable to that of MiniDV
and High Definition, but on DVD.
Playback of these DVDs couldn't be
simpler (depending upon the playback
device used). After finalizing the disc in
the camcorder, the disc can play back
in most DVD Players (SD), computers,
Blu-ray Disc™ players, and even
PlayStation® 3 video game consoles.
2
DVD-R/-RW/+RW and +R DL (Dual
Layer) Compatible
Compatibility with a variety of DVD
formats allows the ease-of-
use and
simplicity found in DVD media. With
DVD+RW media there is no need to
finalize the disc (minimum recording
required); simply remove the finalized
disc and insert the media into a
compatible DVD or Blu-ray Disc™
Player.
3
3
Built
-in zoom microphone with 5.1ch
recording
Featuring Dolby® Ditigal 5.1 Creator,
the built
-in zoom microphone focuses
audio recording on your subjects in
sync with the camera's zoom lens,
helping memories ring true with clear
dialogue and crisp, discrete sounds.
Dolby® Digital 5.1ch Recording
Record in Dolby Digital 5.1ch surround
sound with the camcorder's built-in
microphone. Recording in 5.1 channel
surround sound allows you to
experience your home movies with
active sounds coming from all
directions, so you can enjoy your
personal home movies the way you
experienced them while recording.
Quick On
Missing an important scene can be
frustrating, especially if the reason is
because your camcorder is turned off.
With the Quick On feature, the touch of a
single button places that camcorder in
Sleep mode. Another push instantly
wakes the camcorder, so you'll always
be ready to capture special moments.
ADDITIONAL FEATURES
Dynamic Range Optimizer
Easy Handycam Button
Switchable HD/SD Format Recording
Professional Quality Carl Zeiss® VarioSonnar®
T Lens
Active Interface Shoe
HDMI™ Connection with BRAVIA®
Sync™ (CEC) Technology
USB 2.0 Interface
6
Page 2
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 11/24/2009
HDR-
UX10
High Definition DVD Handycam
® Camcorder
Please visit the Dealer Network for more
information at www.sony.com/dn
Specifications
General
Imaging Device:
1/5" ClearVid
™ CMOS sensor (with
Exmor™ technology)
Pixel Gross:
2300K
Recording Media: 3" (8cm) DVD (DVD-
R/DVD
RW/DVD+RW/DVD+R DL), Memory Stick Duo™ Media,
Memory Stick PRO Duo™ Media
Recording and Playback Times: High Definition: (Single
Layer/Dual Layer) HQ+ = 15/25 min., HQ = 20/35 min.,
SP = 25/45 min., LP = 30/60 min. Standard Definition:
(Single Layer/Dual Layer) HQ = 20/35 min., SP = 30/5
min., LP = 60/110 min. When using 8GB Memory Stick
PRO Duo™ Media (sold separately): High Definition:
FH = up to 55 min., HQ = up to 115 min. SP = up to 140
min., LP = up to 180 min. Standard Definition: HQ = up
to 115 min., SP = up to 170 min., LP = up to 5 hours 25
min.
Video Actual:
1120K Pixels (4:3), 1490K Pixels (16:9)
Still Actual:
1990K Pixels (4:3), 1490K Pixels (16:9)
Processor:
BIONZ
™ image processo
Video Resolution:
1920 x 1080
Still Picture Resolution:
4 megapixel
Audio
Audio Format:
Dolby® Digital 5.1
Microphone: Yes (Built-in Zoom)
Convenience
USB Streaming:
N/A
Accessory Shoe: Yes (Active Interface Shoe)
White Balance: Auto, Outdoor, Indoor, One-push
(touch panel)
Memory Stick PRO™
Media Compatibility:
Tested to
support up to 8GB media capacity; does not support
high speed transfer function; does not support
Access Control security function.
Still Image Mode(s):
JPEG
Face Detection: Yes
Hybrid:
Yes
Hybrid Plus:
N/A
Quick On: Yes
Dual Record: Yes
Dynamic Range Optimizer: Yes
Scene Mode(s): Auto, Twilight, Twilight Portrait (Still only),
Candle, Sunrise & Sunset, Fireworks, Landscape,
Portrait, Spotlight, Beach, Snow
Image Stabilization: O.I.S.
Convenience Features
Easy Operation: Yes
Multiple Language Display: Yes
Slide Show Mode: Yes
Picture Effect(s): Monotone, Sepia, Pastel
Digital Picture Effect(s): Old Movie
PictBridge Compatible: Yes
Low Light Capability:
Super NightShot®
Fader Effect(s): Black, White
Face Index: Yes
Film Roll Index: Yes
Photo Capture from Movie: Yes
Dubbing Button:
N/A
x.v.Color™ : Yes
BRAVIA® Sync™ : Yes
Video
Format(s) Supported:
HD: MPEG4 AVC/H.264 SD: MPEG2
Video Signal:
NTSC color, EIA standards
Video Features
PhotoTV HD: Yes
Inputs and Outputs
Analog Audio/Video Output(s): Included (via A/V
Remote Terminal)
Digital Audio/Video Output(s):
Yes (via USB)
USB Port(s): Hi-speed (2.0 compliant)
Component Video (Y/Pb/Pr) Output(s): Included (via
A/V Remote Terminal)
S
-Video Output(s): Available via A/V Remote (cable not
included)
HDMI™ Connection Output(s): Yes (mini)
Audio/Video Remote Terminal: Yes
Display
LCD Screen:
2.7" wide
touch panel Clear Photo™ plus
(211k pixels)
Viewfinder: Color Wide 16:9 (123K Pixels)
Hardware
Memory Stick slot: Memory Stick PRO Duo™ Media
Manual / Auto Lens Cover: Auto
Assignable Dial:
N/A
S/S & Zoom button on LCD: Yes
Light/Flash: Yes
Optics/Lens
35mm Equivalent:
49
- 735mm (4:3 Camera Mode), 40 -
600mm (16:9 Camera Mode)
Aperture:
F1.8-2.6
Exposure: Touch Panel
Filter Diameter:
30mm
Focal Distance:
3.1 - 46.5mm
Focus: Full range auto / Manual (Touch Panel)
Progressive Shutter Mode: Yes
Shutter Speed:
Auto, 1/30
- 1/250 (Scene Selection
Mode)
Optical Zoom:
15x
Digital Zoom:
180x
Lens Type: Carl Zeiss®
Vario
-Sonnar® T
Minimum Illumination: 5 lux (Auto Slow Shutter ON, 1/30
Shutter Speed )
Power
Battery Type: InfoLITHIUM® with AccuPower™ Meter
System (NP-
FH60)
Power Requirements: 7.2V (battery pack); 8.4V (AC
Adaptor)
Power Consumption (in Operation):
4.7W/5.0W/5.1W
(VF/LCD/VF+LCD)
Service and Warranty Information
Limited Warranty Term: Limited Warranty --- 1 Year Parts;
90 Days Labor
Software
Operating System Compatibility:
Microsoft® Windows®
2000 Professional, XP Home, XP Professional, Windows
Vista
Supplied Software: Picture Motion Browser Ver.3.0.00
Dimensions
Weight: 1 lb 3 oz (560g) with Battery
Measurements:
2 3/8 x 3 3/4 x 5 3/8 inch (58 x 93 x
134mm)
Supplied Accessories
Power Adapter/In-Camera Charger (AC-
L200)
InfoLITHIUM® Rechargeable Battery (NP-
FH60)
Remote Commander® Remote Control (RMT-
835)
Component Video Cable
Multi A/V Cable (Stereo)
Application CD
-ROM w/ Driver
USB Cable
Enjoy Handycam DVD
UPC Code:
027242727748
1. Viewable area measured diagonally.
2. Camcorder captures high definition footage in the AVCHD
™
format.
Using the enclosed PC software, high definition footage can be copied
onto DVD media. However, DVD media containing AVCHD footage
should not be used with DVD based players or recorders, as the DVD
player/recorder may fail to eject the media and may erase its
contents without warning. DVD media containing AVCHD footage
may be played on a compatible Blu-ray Disc™ player/recorder or
other compatible device.
3. DVD media/formats are not universally compatible.
4. HD viewing requires a Sony HD connector cable or HD Cyber-shot
Station®
cradle and HDTV. All sold separately.
5. i.LINK is a trademark of Sony used only to designate that a product
contains an IEEE1394 connection. The i.LINK connection may vary
depending on the software applications, operating system and
compatible i.LINK devices. All products with an i.LINK connection may
not communicate with each other
6. Not all products with USB connectors may communicate with each
other due to chipset variations.
7. Actual battery life will vary based on product settings, usage patterns,
battery and environmental conditions.
8. Compatible BRAVIA®
HDTV and special TV settings are required.
Further details are available in the BRAVIA® TV instruction manual.
10. Requires BRAVIA Sync feature in each product. Please refer to
owner's manual to determine compatibility.
©2007 Sony Electronics Inc. All rights reserved.
1
Reproduction in whole or in part without written permission is prohibited.
Sony, Clear Photo, ClearVid, Handycam, i.LINK, InfoLITHIUM, like.no.other,
Memory Stick Duo, Memory Stick PRO Duo, NightShot, Remote
Commander and SteadyShot are trademarks of Sony. Carl Zeiss and
Vario-Sonnar are trademarks of Carl Zeiss. HDMI is a trademark of HDMI
Licensing LLC. All other trademarks are property of their respective
owners.
Features and specifications subject to change without notice. Non-metric
weights and measures are approximate and may vary.
Screen Images Simulated
Loading...
