Page 1
Sony public displays
the picture of perfection
Simulated images
sony.com/digitalsignage
Page 2
Sony Public Displays Specification Comparison Chart
Category Name Standard
Slim-Bezel Slim-Bezel New Model
Model Name FWD-S42H2 FWD-S46H2 FWD-S55H2
Picture Performance
LCD Panel
Color System NTSC, PAL NTSC, PAL NTSC, PAL
Sampling Rate 13.5 to 162 MHz 13.5 to 162 MHz 13.5 to 162 MHz
Interface
Video
HD15 (RGB/Component)
DVI
®
HDMI
Audio Out L/R RCA x2 L/R RCA x2 L/R RCA x2
Remote
Speaker out (L/R) Grip Connector x4, 7W + 7W, 6 ohms Grip Connector x4, 7W + 7W, 6 ohms Grip Connector x4, 7W + 7W, 6 ohms
General
Dimensions WxHxD (excluding protruding parts) 38 1/8 x 22 1/8 x 3 1/2" 41 1/2 x 24 x 3 3/8" 49 3/8 x 28 1/2 x 4 3/4"
Weight (approx.) 44 lb 8 oz 50 lb 0 oz 82 lb 11 oz
Power Requirements
Power Consumption
Operating Temperature 32 to 104 F degrees 32 to 104 F degrees 32 to 104 F degrees
Storage Temperature 14 to 104 F degrees 14 to 104 F degrees 14 to 104 F degrees
VESA Standard Mount Holes 400 x 400 mm 400 x 400 mm 400 x 400 mm
Humidity 20 to 90%, no condensation 20 to 90%, no condensation 20 to 90%, no condensation
Warranty 3 years 3 years 3 years
Functions
Bezel Width 16.1 mm 16.1 mm 19.4 mm
Picture-In-Picture Yes Yes Yes
Multi-display up to 4x4 up to 4x4 up to 4x4
Portrait Mode Yes Ye s Yes
24 x 7 Operation Yes Yes Yes
DICOM-simulated gamma Yes Yes Yes
True Color Control Yes Yes Yes
On/Off Timer Yes Ye s Yes
Control panel lock Yes Yes Yes
Option Card Slot Ye s Yes Yes
Touch Screen Version Available Ye s Ye s Ye s
Optional Accessories
Speaker System SS-SPG02 SS-SPG02 SS-SPG02
Display Stand SU-S02 SU-S02 SU-S02
HDSDI/SDI Input Card BKM-FW16 BKM-FW16 BKM-FW16
Panel Size (diagonal)* 42" 46" 55"
Resolution Full HD: 1920 x 1080 Full HD: 1920 x 1080 Full HD: 1920 x 1080
Pixel pitch 0.48 x 0.48 mm 0.54 x 0.54 mm 0.63 x 0.63 mm
Backlight Edge LED Edge LED Direct LED
Contrast ratio 4,000 : 1 (typical) 4,000 : 1 (typical) 4,000 : 1 (typical)
Brightness 700 cd/m2 (typical) 700 cd/m2 (typical) 1,000 cd/m2 (typical)
Viewing angle** 178 degrees (typical) 178 degrees (typical) 178 degrees (typical)
Type
Video IN BNC BNC BNC
Video OUT BNC BNC BNC
Component IN RCA x3 RCA x3 RCA x3
Audio IN Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
Video IN D-sub 15 pin D-sub 15 pin D-sub 15 pin
Video OUT D-sub 15 pin D-sub 15 pin D-sub 15 pin
Audio IN Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
DVI IN w/ HDCP support DVI-D 24 pin DVI-D 24 pin DVI-D 24 pin
Audio IN Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
HDMI IN w/ HDCP support HDMI HDMI HDMI
Network port RJ45 RJ45 RJ45
RS-232C RS232C, Straight RS232C, Straight RS232C, Straight
HDMI CEC CEC CEC
Max 140W 145W 290W
Typical 108W 100W 250W
a-Si TFT Active Matrix LCD
Edge lit LED Backlight
AC 100 V to 240 V, 50/60 Hz,
1.45 A (maximum)
a-Si TFT Active Matrix LCD
Edge lit LED Backlight
AC 100 V to 240 V, 50/60 Hz,
1.4 A (maximum)
a-Si TFT Active Matrix LCD
Direct lit LED Backlight
AC 100 V to 240 V, 50/60 Hz,
2.9 A (maximum)
* Viewable area, measured diagonally
** Measured at the contrast ratio more than 10:1
Page 3
Sony Public Displays Specification Comparison Chart
Basic
New Model New Model New Model New Model
FWD-32B1 FWD-42B2 FWD-46B2 FWD-55B2
32" 42" 46" 55"
WXGA: 1366 x 768 Full HD: 1920 x 1080 Full HD: 1920 x 1080 Full HD: 1920 x 1080
0.51 x 0.51 mm 0.48 x 0.48 mm 0.53 x 0.53 mm 0.63 x 0.63 mm
CCFL Edge LED Edge LED Edge LED
3,000 : 1 (typical) 4,000 : 1 (typical) 4,000 : 1 (typical) 4,000 : 1 (typical)
450 cd/m2 (typical) 500 cd/m2 (typical) 500 cd/m2 (typical) 450 cd/m2 (typical)
178 degrees (typical) 178 degrees (typical) 178 degrees (typical) 178 degrees (typical)
a-Si TFT Active Matrix LCD
CCFL Backlight
NTSC, PAL NTSC, PAL NTSC, PAL NTSC, PAL
13.5 to 162 MHz 13.5 to 162 MHz 13.5 to 162 MHz 13.5 to 162 MHz
BNC BNC BNC BNC
BNC BNC BNC BNC
RCA x3 RCA x3 RCA x3 RCA x3
Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
D-sub 15 pin D-sub 15 pin D-sub 15 pin D-sub 15 pin
D-sub 15 pin D-sub 15 pin D-sub 15 pin D-sub 15 pin
Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
DVI-D 24 pin DVI-D 24 pin DVI-D 24 pin DVI-D 24 pin
Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack Stereo Mini Jack
HDMI HDMI HDMI HDMI
L/R RCA x2 L/R RCA x2 L/R RCA x2 L/R RCA x2
RJ45 RJ45 RJ45 RJ45
RS232C, Straight RS232C, Straight RS232C, Straight RS232C, Straight
CEC CEC CEC CEC
Internal 7W + 7W, 6 ohms Grip Connector x4, 7W + 7W, 6 ohms Grip Connector x4, 7W + 7W, 6 ohms Grip Connector x4, 7W + 7W, 6 ohms
a-Si TFT Active Matrix LCD
Edge lit LED Backlight
a-Si TFT Active Matrix LCD
Edge lit LED Backlight
a-Si TFT Active Matrix LCD
Edge lit LED Backlight
30 1/8 x 18 1/8 x 4 5/8" 38 1/8 x 22 1/8 x 3 1/2" 41 1/2 x 24 x 3 3/8" 49 1/8 x 28 1/4 x 3 3/8"
29 lb 8 oz 44 lb 8 oz 49 lb 6 oz 65 lb 0 oz
AC 100 V to 240 V, 50/60 Hz,
1.1 A (maximum)
110W 135W 130W 150W
85W 120W 110W 130W
32 to 104 F degrees 32 to 104 F degrees 32 to 104 F degrees 32 to 104 F degrees
14 to 104 F degrees 14 to 104 F degrees 14 to 104 F degrees 14 to 104 F degrees
200 x 200 mm 400 x 400 mm 400 x 400 mm 400 x 400 mm
20 to 90%, no condensation 20 to 90%, no condensation 20 to 90%, no condensation 20 to 90%, no condensation
3 years 3 years 3 years 3 years
31.3 mm 16.1 mm 16.1 mm 16.1 mm
- - - -
up to 4x4 up to 4x4 up to 4x4 up to 4x4
Yes Yes Yes Yes
Yes Yes Yes Ye s
- - - -
- - - -
Yes Yes Yes Ye s
Yes Ye s Ye s Yes
- - - -
Yes Ye s Ye s Yes
SS-SPG02 SS-SPG02 SS-SPG02 SS-SPG02
SU-S02 SU-S02 SU-S02 SU-S02
N/A N/A N/A N/A
AC 100 V to 240 V, 50/60 Hz,
1.4 A (maximum)
AC 100 V to 240 V, 50/60 Hz,
1.3 A (maximum)
AC 100 V to 240 V, 50/60 Hz,
1.5 A (maximum)
Page 4
simple signage and touch screen options
The Sony Simple Signage Bundle is the ideal digital signage solution for small businesses.
Available Bundles
FWD-S55H2/DS
FWD-S46H2/DS
FWD-S42H2/DS
FWD-55B2/DS
FWD-46B2/DS
FWD-42B2/DS
FWD-32B1/DS
As a simple solution for digital signage, Sony has put together Simple Signage Bundles – easy-touse digital signage packages that allow small businesses, whether houses of worship, doctors’ and
lawyers’ office, mom-and-pop restaurants, or retail stores, to utilize effective signage quickly
and easily.
There is a choice of seven high-performance displays of various sizes, plus a Hyper Media Player
(HMP) containing user-friendly templates and management software, and the required connecting
cable. No fuss, no bother, no need for extensive IT configuration.
This affordable, flexible digital signage solution means that small businesses can get a big bump in
visibility from one reliable package. It’s just a few simple steps to getting information and
graphics up and running on one of Sony’s accurate, clear displays. Simple,
economical, dependable: you might call it a bundle of joy.
This simple solution makes it easy to add sophisticated digital signage to an
establishment. Screens can have multiple zones, each containing a variety of
content, such as a clock, real-time weather, traffic, or other news feed via RSS,
pictures, and/or video from files or streaming video content, freeform text, or
bulleted lists. The built-in drag-and-drop interface makes it simple to create pages
and programs quickly and easily. Because it runs in a browser, signs can even be
updated from a wireless tablet or smartphone, or from a remote location.*
*Requires devices connected to the same wireless network.
Touch screen displays – one touch, infinite possibilities.
The Sony touch screen displays are a full line of large-format integrated touch screens that connect you with your market
via the power of touch by changing the digital signage experience from passive to active. Touch screen interaction
deepens the users’ interaction with the product or service as they drill down to select their interests. Designed for high-use
environments, these field-proven touch enabled LCD panels allow the full display viewing area to be used as an interactive
single touch interface with infinite touch points. In addition, the touch system also performs seamlessly with objects resting on
the touch screen surface, and gives the users the ability to interact with the touch screen using virtually any object, including
finger, fingernail, prosthetic or car key.
Available Models
FWD-S55H2TOUCH
FWD-S46H2TOUCH
FWD-S42H2TOUCH
FWD-55B2TOUCH
FWD-46B2TOUCH
FWD-42B2TOUCH
FWD-32B1TOUCH
Features of the Sony touch screen displays:
• Incorporates 3M DST
®
(Dispersive Signal Technology)
Touch System making performance unimpaired by
on-screen contaminants, surface scratches or direct
ambient light
• Thin bezel design
• USA service and technical support
• Compatible with Mac
®
, Linux®, and Windows®
operating systems
• 3-year warranty on the touch sensor and touch controller (Display Werks)
For more information on this simple solution to your digital signage needs, go to sony.com/digitalsignage.
