Sony DVP-NS501PS Operating manual

CD/DVD Player

Operating Instructions

2-050-982-11(1)

DVP-NS501P

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

The AC power cord must be changed only at a qualified service shop.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this CD/DVD player is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

This symbol is intended to alert the user to the presence of uninsulated

within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

“dangerous voltage”

This symbol is intended to alert the user to the presence of important operating and

For customers in the U.S.A Owner’s Record

The model and serial numbers are located at the rear of the unit. Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product.

Model No. DVP-NS501P Serial No.______________

CAUTION

You are cautioned that any change or modifications not expressly approved in this manual could void your authority to operate this equipment.

Note

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the

receiving antenna.

– Increase the separation

between the equipment and receiver.

– Connect the equipment into an

outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an

experienced radio/TV technician for help.

Welcome!

Thank you for purchasing this Sony CD/DVD Player. Before operating this player, please read this manual thoroughly and retain it for future reference.

Important Safeguards

For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance, or the one described in the operating instructions and adhere to them.

Use

Power sources

This set should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of electrical power supplied to your home, consult your dealer or local power company. For those sets designed to operate from battery power, or other sources, refer to the operating instructions.

Grounding or Polarization

This set is equipped with a polarized ac power cord plug (a plug having one blade wider than the other), or with a three-wire grounding type plug (a plug having a third pin for grounding). Follow the instructions below:

For the set with a polarized ac power cord plug:

This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to have a suitable outlet installed. Do not defeat the safety purpose of the polarized plug by forcing it in.

For the set with a three-wire grounding type ac plug:

This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to have a suitable outlet installed. Do not defeat the safety purpose of the grounding plug.

Overloading

Do not overload wall outlets, extension cords or convenience receptacles beyond their capacity, since this can result in fire or electric shock.

Object and Liquid Entry

Never push objects of any kind into the set through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the set.

Attachments

Do not use attachments not recommended by the manufacturer, as they may cause hazards.

Cleaning

Unplug the set from the wall outlet before cleaning or polishing it. Do not use liquid cleaners or aerosol cleaners. Use a cloth lightly dampened with water for cleaning the exterior of the set.

Installation

Water and Moisture

Do not use power-line operated sets near water - for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.

Power-Cord Protection

Route the power cord so that it is not likely to be walked on or pinched by items placed upon or against them, paying particular attention to the plugs, receptacles, and the point where the cord exits from the appliance.

Accessories

Do not place the set on an unstable cart, stand, tripod, bracket, or table. The set may fall, causing serious injury to a child or an adult, and serious damage to the set. Use only a cart stand tripod, bracket, or table recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

S3125A

Ventilation

The slots and openings in the cabinet are provided for necessary ventilation. To ensure reliable operation of the set, and to protect it from overheating, these slots and openings must never be blocked or covered.

• Never cover the slots and openings with a cloth or other materials.

• Never block the slots and openings by placing the set on a bed, sofa, rug or other similar surface.

• Never place the set in a confined space, such as a bookcase, or built-in cabinet, unless proper ventilation is provided.

• Do not place the set near or over a radiator or heat register, or where it is exposed to direct sunlight.

Antennas Outdoor antenna grounding

If an outdoor antenna or cable system is installed, follow the precautions below.

An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits. WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM, EXTREME CARE SHOULD BE TAKEN TO KEEP FROM CONTACTING SUCH POWER LINES OR CIRCUITS AS CONTACT WITH THEM IS ALMOST INVARIABLY FATAL. Be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Antenna Grounding According to the National Electrical Code

Antenna Lead in Wire

Ground Clamp

Electric Service Equipment

NEC-NATIONAL ELECTRICAL CODE

Lightning

For added protection for this set during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and powerline surges.

Antenna Discharge unit (NEC Section 810-20)

Grounding Conductors (NEC Section 810-21)

Ground Clamps

Power Service Grounding Electrode System (NEC Art 250 Part H)

Service

Damage Requiring Service

Unplug the set from the wall outlet and refer servicing to qualified service personnel under the following conditions:

• When the power cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into the set.

• If the set has been exposed to rain or water.

• If the set has been subject to excessive shock by being dropped, or the cabinet has been damaged.

• If the set does not operate normally when following the operating instructions. Adjust only those controls that are specified in the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the set to normal operation.

• When the set exhibits a distinct change in performance - this indicates a need for service.

Servicing

Do not attempt to service the set yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

Replacement parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.

Safety Check

Upon completion of any service or repairs to the set, ask the service technician to perform routine safety checks (as specified by the manufacturer) to determine that the set is in safe operating condition.

Precautions

• The power requirements and power consumption of this player are indicated on the back of the player. Check that the player’s operating voltage is identical with your local power supply.

00V 00Hz

Power requirements and power consumption t

NO.

On safety

• To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.

• Should any solid object or liquid fall into the cabinet, unplug the player and have it checked by qualified personnel before operating it any further.

On power sources

• The player is not disconnected from the AC power source as long as it is connected to the wall outlet, even if the player itself has been turned off.

• If you are not going to use the player for a long time, be sure to disconnect the player from the wall outlet. To disconnect the AC power cord, grasp the plug itself; never pull the cord.

• Should the AC power cord need to be changed, have it done at a qualified service shop only.

On placement

• Place the player in a location with adequate ventilation to prevent heat build-up in the player.

• Do not place the player on a soft surface such as a rug that might block the ventilation holes.

• Do not place the player in a location near heat sources, or in a place subject to direct sunlight, excessive dust, or mechanical shock.

• Do not install the player in an inclined position. It is designed to be operated in a horizontal position only.

• Keep the player away from equipment with strong magnets, such as microwave ovens, or large loudspeakers.

• Do not place heavy objects on the player.

DVP–XXXX

00W

0-000-000-00

On operation

• If the player is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lenses inside the player. Should this occur, the player may not operate properly. In this case, remove the disc and leave the player turned on for about half an hour until the moisture evaporates.

• When you move the player, take out any

discs. If you don’t, the disc may be damaged.

On adjusting volume

Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speakers may be damaged when a peak level section is played.

On cleaning

Clean the cabinet, panel, and controls with a soft cloth slightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzine.

On cleaning discs

Do not use a commercially available cleaning disc. It may cause a malfunction.

IMPORTANT NOTICE

Caution: This player is capable of holding a still video image or on-screen display image on your television screen indefinitely. If you leave the still video image or on-screen display image displayed on your TV for an extended period of time you risk permanent damage to your television screen. Plasma display panel televisions and projection televisions are susceptible to this.

If you have any questions or problems concerning your player, please consult your nearest Sony dealer.

Table of Contents

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Welcome! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

This Player Can Play the Following Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Notes about the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Index to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Guide to the Control Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Hooking Up the Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Step 1: Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Step 2: Inserting Batteries into the Remote . . . . . . . . . . . . . . . . . . . . . . . . . 17

Step 3: Connecting the Video Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Step 4: Connecting the Audio Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Step 5: Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Step 6: Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Resuming Playback from the Point Where You Stopped the Disc

(Multi-disc Resume) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Using the DVD’s Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Selecting “ORIGINAL” or “PLAY LIST” on a DVD-RW Disc . . . . . . . . . . . . . 30

Playing VIDEO CDs with PBC Functions (PBC Playback) . . . . . . . . . . . . . . 31

Various Play Mode Functions (Program Play, Shuffle Play, Repeat Play, A-B

Repeat Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Searching for a Scene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Searching for a Particular Point on a Disc (Search, Scan, Slow-motion Play,

Freeze Frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Searching for a Title/Chapter/Track/Scene, etc. . . . . . . . . . . . . . . . . . . . . . . 38

Searching by Scene (PICTURE NAVIGATION) . . . . . . . . . . . . . . . . . . . . . . 40

Viewing Information About the Disc . . . . . . . . . . . . . . . . . . . . . . . 41

Checking the Playing Time and Remaining Time . . . . . . . . . . . . . . . . . . . . . 41

Sound Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Changing the Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

TV Virtual Surround Settings (TVS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Enjoying Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Changing the Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Displaying the Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Adjusting the Playback Picture (CUSTOM PICTURE MODE) . . . . . . . . . . . 48

Sharpening the Outline of an Image (SHARPNESS) . . . . . . . . . . . . . . . . . . 49

Playing a DATA CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

About MP3 Audio Tracks and JPEG Image Files . . . . . . . . . . . . . . . . . . . . . 50

Playing DATA CDs with MP3 Audio Tracks and JPEG Image Files . . . . . . . 51

Specifying the slideshow duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Selecting an effect for image files in the slideshow . . . . . . . . . . . . . . . . . . . 57

Using Various Additional Functions . . . . . . . . . . . . . . . . . . . . . . . 58

Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) 58

Controlling Your TV with the Supplied Remote . . . . . . . . . . . . . . . . . . . . . . . 62

Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Using the Setup Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Setting the Display or Sound Track Language (LANGUAGE SETUP) . . . . . 64

Settings for the Display (SCREEN SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . 65

Custom Settings (CUSTOM SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Settings for the Sound (AUDIO SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Self-diagnosis Function (When letters/numbers appear in the display) . . . . 73

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Language Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

About this Manual

Format of discs

Music CD

• Instructions in this manual describe the controls on the remote. You can also use the controls on the player if they have the same or similar names as those on the remote.

• “DVD” may be used as a general term for DVD VIDEOs, DVD+RWs/DVD+Rs, and DVD-RWs/DVD-Rs.

• The meaning of the icons used in this manual is described below:

Icon Meaning

Functions available for DVD VIDEOs and DVD+RWs/ DVD+Rs or DVD-RWs/ DVD-Rs in video mode

Functions available for DVDRWs in VR (Video Recording) mode

Functions available for VID EO CDs, Super VCDs, or CD-Rs/ CD-RWs in video CD format or Super VCD format

Functions available for DATA CDs (CD-ROMs/CD-Rs/CDRWs containing MP3* audio tracks and JPEG image files)

Functions available for music CDs or CD-Rs/CD-RWs in music CD format

* MP3 (MPEG 1 Audio Layer 3) is a standard format

defined by ISO (International Standard Organization) /MPEG which compresses audio data.

This Player Can Play the Following Discs

“DVD VIDEO” and “DVD-RW” are trademarks.

Notes about CDs

The player can play CD-ROMs/CD-Rs/CDRWs recorded in the following formats: – music CD format – video CD format – MP3 audio tracks and JPEG image files of

format conforming to ISO9660* Level 1/ Level 2, or its extended format, Joliet

– KODAK Picture CD format

* A logical format of files and folders on CD-

ROMs, defined by ISO (International Organization for Standardization).

Region code

Your player has a region code printed on the back of the unit and only will play DVD VIDEO discs (playback only) labeled with identical region codes. This system is used to protect copyrights.

0-000-000-00

ALL

Region code

DVD VIDEOs labeled will also play on this player.

If you try to play any other DVD VIDEO, the message “Playback prohibited by area limitations.” will appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be labeled even though playing the DVD VIDEO is prohibited by area restrictions.

DVP–XXXX

00W

NO.

00V 00Hz

Format of discs

DVD VIDEO (page 74)

DVD-RW (page 74)

VIDEO CD

Example of discs that the player cannot play

The player cannot play the following discs:

• CD-ROMs (including PHOTO CDs)/CDRs/CD-RWs other than those recorded in the formats listed on the previous page.

• Data part of CD-Extras

• DVD-ROMs

• DVD Audio discs

• HD layer on Super Audio CDs

Also, the player cannot play the following discs:

• A DVD VIDEO with a different region code.

• A disc recorded in a color system other than NTSC, such as PAL or SECAM (this player conforms to the NTSC color system).

• A disc that has a non-standard shape (e.g., card, heart).

• A disc with paper or stickers on it.

• A disc that has the adhesive of cellophane tape or a sticker still left on it.

Note on playback operations of DVDs and VIDEO CDs

Some playback operations of DVDs and VIDEO CDs may be intentionally set by software producers. Since this player plays DVDs and VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VIDEO CDs.

Copyrights

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Notes

• Notes about DVD+RWs/DVD+Rs, DVD-RWs/ DVD-Rs or CD-Rs/CD-RWs

Some DVD+RWs/DVD+Rs, DVD-RWs/DVDRs or CD-Rs/CD-RWs cannot be played on this player due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalized. For more information, see the operating instructions for the recording device. Note that some playback functions ma y not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs created in Packet Write format cannot be played.

• Music discs encoded with copyright protection technologies

This product is designed to playback discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product.

Notes about the Discs

• To keep the disc clean, handle the disc by its edge. Do not touch the surface.

• Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave it in a car parked in direct sunlight as the temperature may rise considerably inside the car.

• After playing, store the disc in its case.

• Clean the disc with a cleaning cloth. Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner, commercially available cleaners, or anti-static spray intended for vinyl LPs.

Index to Parts and Controls

For more information, refer to the pages indicated in parentheses.

Front panel

A [/1 (on/standby) button (27) B Disc tray (27) C Front panel display (11) D (remote sensor) (17) E A (open/close) button (27) F H (play) button (27, 37)

G X (pause) button (28) H x (stop) button (28) I ./> (previous/next) buttons (37) J PROGRESSIVE indicator (19)

Lights up when the player outputs progressive signals.

Front panel display

When playing back a DVD VIDEO/DVD-RW

Disc type

Lights up during Repeat Play (35)

Playing status

Current audio signal (45)

Lights up when you can change the angle (47)

Current title/chapter or playing time (42)

When playing back a VIDEO CD with Playback Control (PBC) (31)

Disc type

Playing status

Lights up during A-B Repeat Play (36)

Current scene or playing time (42)

When playing back a CD, DATA CD (MP3 audio), or VIDEO CD (without PBC)

Playing status

Lights up during Repeat Play (35)

Current track (42)

Disc type

Lights up when playing MP3 audio tracks (51)

Playing time (42)

,continued

Rear panel

COMPONENT

OUT

VIDEO

PCM/DTS/

DOLBY DIGITAL

COAXIAL

DIGITAL OUT

AUDIO

LINE OUT

VIDEO

NORMAL

PROGRESSIVE

S VIDEO OUT

A COMPONENT VIDEO OUT** jacks

(18)

B LINE OUT (VIDEO)* jack (18) C NORMAL/PROGRESSIVE switch

(66)

D S VIDEO OUT* jack (18)

E LINE OUT L/R (AUDIO) jack (21, 22,

23)

F DIGITAL OUT (COAXIAL) jack (22,

23, 24)

* Do not set the “NORMAL/PROGRESSIVE”

switch to “PROGRESSIVE” if you have connected the TV to these jacks (page 66)

** Set the “NORMAL/PROGRESSIVE” switch

to “PROGRESSIVE” only if you have connected a progressive signal compatible TV to the player (page 66, 70)

Remote

A TV [/1 (on/standby) button (62) B

Z OPEN/CLOSE button (27)

C Number buttons (30)

The number 5 button has a tactile dot.*

D CLEAR button (32) E SUBTITLE button (47) F AUDIO button (44) G ./> PREV/NEXT (previous/

next) buttons (28)

H m/M SCAN/SLOW

buttons (37)

I X PAUSE button (28) J H PLAY button (27)

The H button has a tactile dot.*

K C/X/x/c buttons (30) L DISPLAY button (14) M TOP MENU button (30) N [/1 (on/standby) button (27) O VOL (volume) +/– buttons (62)

The + button has a tactile dot.*

P TV/VIDEO button (62) Q TIME/TEXT button (41) R PICTURE MODE button (48) S ANGLE button (47) T SUR (surround) button (45) U PICTURE NAVI (picture navigation)

button (40, 53)

V ZOOM button (28, 54) W INSTANT ADVANCE/STEP

button (28, 37)

X INSTANT REPLAY/STEP

button (28, 37)

Y x STOP button (28) Z ENTER button (28)

wj O RETURN button (28) wk MENU button (30)

* Use the tactile dot as a reference when operating

the player.

Guide to the Control Menu Display

Use the Control Menu to select a function and to view related information. Press DISPLAY repeatedly to turn on or change the Control Menu display as follows.

Control Menu display 1

Control Menu Display

The Control Menu display 1 and 2 will show different items depending on the disc type. For details about each item, please refer to the pages in the parentheses.

Example: Control Menu display when playing a DVD VIDEO.

Control Menu display 2 (DATA CD only)

Control Menu display off

Control Menu items

1 2 ( 2 7 1 8 ( 3 4

Selected item

Function name of selected Control Menu item

Operation message

* Displays the scene number for VIDEO CDs

(PBC is on), track number for VIDEO CDs/ CDs, album number for DATA CDs.

** Displays the index number for VIDEO CDs,

MP3 audio track or JPEG image file number for DATA CDs.

*** Displays Super VCD as “SVCD.”

OFF OFF SET ON

PROGRAM

) )

1 : 3 2 : 5 5

ENTER DISPLAY

To turn off the display

Press DISPLAY repeatedly.

Currently playing chapter number

Currently playing title number*

Total number of titles*

Total number of chapters**

PLAY DVD VIDEO

Quit:

Playback status (N Playback,

X Pause, x Stop, etc.)

Type of disc being played***

Playing time Current setting

Options

List of Control Menu Items

Item Item Name, Function, Relevant Disc Type

TITLE (page 38)/SCENE (page 38)/TRACK (page 38)

Selects the title, scene, or track to be played.

CHAPTER (page 38)/INDEX (page 38)

Selects the chapter or index to be played.

ALBUM (page 38)

Selects the album to be played.

DATE

Displays the recorded date, etc of the current JPEG image.

FILE (page 38)

Selects the JPEG image file to be played.

ORIGINAL/PLAY LIST (page 30)

Selects the type of titles (DVD-RW) to be played, the ORIGINAL one, or an edited PLAY LIST.

TRACK (page 38)

Selects the track to be played.

TIME/TEXT (page 38)

Checks the elapsed time and the remaining playback time. Input the time code for picture and music searching. Displays the DVD/CD text or the DATA CD’s track name.

PROGRAM (page 32)

Selects the title, chapter, or track to play in the order you want.

SHUFFLE (page 34)

Plays the title, chapter, or track in random order.

REPEAT (page 35)

Plays the entire disc (all titles/all tracks/all albums) repeatedly or one title/chapter/ track/album repeatedly.

A-B REPEAT (page 36)

Specifies the parts you want to play repeatedly.

SHARPNESS (page 49)

Exaggerates the outline of the image to produce a sharper picture.

MODE(MP3,JPEG) (page 53)

Selects the data type; MP3 audio track (AUDIO), JPEG image file (IMAGE) or both (AUTO) to be played when playing a DATA CD.

INTERVAL (page 56)

Specifies the duration for which the slides are displayed on the screen.

EFFECT (page 57)

Selects the effect to be used for changing slides during a slide show.

PARENTAL CONTROL (page 58)

Set to prohibit playback on this player.

,continued

SETUP (page 63)

QUICK Setup (page 25) Use Quick Setup to choose the desired language of the on-screen display, the aspect ratio of the TV and the audio output signal. CUSTOM Setup In addition to the Quick Setup setting, you can adjust other various settings. RESET Returns the settings in “SETUP” to the default setting.

z Hint

The Control Menu icon indicator lights up in green

except “OFF.” (“PROGRAM,” “SHUFFLE,” “REPEAT,” “A-B REPEAT,” “SHARPNESS” only). The “ORIGINAL/PLAY LIST” indicator lights up in green when you select “PLAY LIST”.

when you select any item

Hookups Hookups

Hooking Up the Player

Follow Steps 1 to 6 to hook up and adjust the settings of the player.

Notes

• Plug cords securely to prevent unwanted noise.

• Refer to the instructions supplied with the components to be connected.

• You cannot connect this player to a TV that does not have a video input jack.

• Be sure to disconnect the power cord of each component before connecting.

Step 1: Unpacking

Check that you have the following items:

• Audio/video cord (pinplug × 3 y pinplug × 3) (1)

• Remote commander (remote) (1)

• Size AA (R6) batteries (2)

Step 2: Inserting Batteries into the Remote

You can control the player using the supplied remote. Insert two Size AA (R6) batteries by matching the 3 and # ends on the batteries to the markings inside the compartment. When using the remote, point it at the remote sensor on the player.

Hookups

Notes

• Do not leave the remote in an extremely hot or humid place.

• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.

• Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a malfunction.

• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion.

,continued

Step 3: Connecting the Video Cords

Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord. Select one of the patterns A through C. In order to view progressive signal (480p) pictures with a compatible TV, projector, or monitor, you must use connection C, according to the input jack on your TV monitor, projector, or AV amplifier (receiver).

INPUT

VIDEO

AUDIO

(yellow)

TV, projector or AV amplifier (receiver)

Audio/video cord (supplied)

(yellow)

S VIDEO cord (not supplied)

INPUT

S VIDEO

TV, projector or AV amplifier (receiver)

to LINE OUT (VIDEO)

COMPONENT VIDEO

OUT

PCM/DTS/

DOLBY DIGITAL

AUDIO

COAXIAL

LINE OUT

DIGITAL OUT

LINE OUT

VIDEO

NORMAL PROGRESSIVE

S VIDEO OUT

to COMPONENT

to S VIDEO OUT

CD/DVD player

VIDEO OUT

(green)

Component video cord (not supplied)

l : Signal flow

(blue)

(red)

COMPONENT

VIDEO IN

(green)

(blue)

(red)

TV, projector or AV amplifier (receiver)

A If you are connecting to a video input jack

Connect the yellow plug of the audio/video cord (supplied) to the yellow (video) jack. You will enjoy standard quality images.

Yellow (Video) White (L) Red (R)

Use the red and white plugs to connect to the audio input jacks (page 21).

Yellow (Video) White (L) Red (R)

B If you are connecting to an S VIDEO input jack

Connect an S VIDEO cord (not supplied). You will enjoy high quality images.

C If you are connecting to a monitor, projector, or AV amplifier (receiver) having component video input jacks (Y, P

Connect the component via the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or three video cords (not supplied) of the same kind and length. You will enjoy accurate color reproduction and high quality images. If your TV accepts progressive (480p) format signals, you must use this connection and set NORMAL/PROGRESSIVE switch to PROGRESSIVE (page 66). The PROGRESSIVE indicator lights up when the player outputs progressive signals.

B, PR)

Hookups

Green Blue Red

When connecting to a wide screen TV

Depending on the disc, the image may not fit your TV screen. If you want to change the aspect ratio, please refer to page 65.

Notes

• Connect the player directly to the TV. If you pass the player signals via the VCR, etc., you may not receive a clear image on the TV screen.

VCR

CD/DVD player

Connect directly

• Consumers should note that not all high definition television sets are fully compatib le with this product and may cause artifacts to be displayed in the picture. In the case of 480 progressive scan picture problems, it is recommended that t he user switch the connection to the ‘standard de finition’ output. If there are questions regarding our TV set compatibility with this model 480p DVD player, please contact our customer service center.

Step 4: Connecting the Audio Cords

Refer to the chart below to select the connection that best suits your system. Be sure to also read the instructions for the components you wish to connect.

Select a connection

Select one of the following connections, through .

Components to be connected Connection Your setup (example)

A D

(page 21)

Stereo amplifier (receiver)

MD deck/DAT deck

AV amplifier (receiver) having a Dolby Surround (Pro Logic) decoder and 3 to 6 speakers

AV amplifier (receiver) with digital input jacks having a Dolby Digital or DTS** decoder and 6 speakers

z Hint

If you connect an AV amplifier (receiver) that conforms to the 96 kHz sampling frequency, use connection .

and two speakers

(page 22)

(page 23)

(page 24)

* Manufactured under license from Dolby

Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories.

** “DTS” and “DTS Digital Out” are trademarks

of Digital Theater Systems, Inc.

Connecting to your TV

This connection will use your TV’s speakers for sound.

CD/DVD player

COMPONENT VIDEO

PCM/DTS/

DOLBY DIGITAL

DIGITAL OUT

OUT

COAXIAL

LINE OUT

VIDEO

NORMAL PROGRESSIVE

AUDIO

LINE OUT

S VIDEO OUT

Hookups

(yellow)*

AUDIO

LINE OUT

to LINE OUT L/R

(white)

(red)

Audio/video cord (supplied)

(AUDIO)

l : Signal flow

* The yellow plug is used for video signals (page

18).

z Hint

When connecting to a monaural TV, use a stereomono conversion cord (not supplied). Connect the LINE OUT L/R (AUDIO) jacks to the TV’s audio input jack.

(yellow)*

(white)

(red)

to audio input

,continued

Connecting to a stereo amplifier (receiver) and 2 speakers/Connecting to

an MD deck or DAT deck

If the stereo amplifier (receiver) has audio input jacks L and R only, use . If the amplifier (receiver) has a digital input jack, or when connecting to an MD deck or DAT deck, use . In this case, you can also connect the player directly to the MD deck or DAT deck without using your stereo amplifier (receiver).

B-1

B-2

PCM/DTS/

DOLBY DIGITAL

DIGITAL OUT

to DIGITAL OUT (COAXIAL)

[Speakers]

Front (L)

CD/DVD player

COMPONENT VIDEO

OUT

PCM/DTS/

DOLBY DIGITAL

AUDIO

COAXIAL

LINE OUT

DIGITAL OUT

Coaxial digital cord (not supplied)

COAXIAL

to coaxial digital input

LINE OUT

VIDEO

NORMAL PROGRESSIVE

S VIDEO OUT

Stereo audio cord (not supplied)

(white)

Stereo amplifier (receiver)

(red)

(white)

to LINE OUT L/R (AUDIO)

(red)

to audio input

MD deck/DAT deck

AUDIO

LINE OUT

B-1

l: Signal flow

Front (R)

Connecting to an AV amplifier (receiver) having a Dolby Surround (Pro

Logic) decoder and 3 to 6 speakers

You can enjoy the Dolby Surround effects only when playing Dolby Surround audio or multichannel audio (Dolby Digital) discs. If your amplifier (receiver) has L and R audio input jacks only, use . If your amplifier (receiver) has a digital input jack, use .

CD/DVD player

COMPONENT

OUT

VIDEO

PCM/DTS/

DOLBY DIGITAL

COAXIAL

AUDIO

LINE OUT

DIGITAL OUT

S VIDEO OUT

C-2

LINE OUT

VIDEO

NORMAL PROGRESSIVE

C-1

Hookups

C-2

Coaxial digital cord (not supplied)

PCM/DTS/

DOLBY DIGITAL

DIGITAL OUT

COAXIAL

to DIGITAL OUT (COAXIAL)

to coaxial digital input

[Speakers]

Rear (L)

Rear (R)

Subwoofer

l: Signal flow

Stereo audio cord (not supplied)

(white)

(red)

to audio input

Amplifier (receiver) with Dolby Surround decoder

Center

(red)

(white)

to LINE OUT L/R (AUDIO)

[Speakers]

Front (L)

Rear (mono)

AUDIO

LINE OUT

C-1

Front (R)

Note

When connecting 6 speakers, replace the monaural rear speaker with a center speaker, 2 rear speakers and a subwoofer.

,continued

Connecting to an AV amplifier (receiver) with a digital input jack having

a Dolby Digital or DTS decoder and 6 speakers

This connection will allow you to use the Dolby Digital or DTS decoder function of your AV amplifier (receiver).

CD/DVD player

COMPONENT VIDEO

OUT

PCM/DTS/

DOLBY DIGITAL

COAXIAL

AUDIO

LINE OUT

DIGITAL OUT

to DIGITAL OUT (COAXIAL)

Coaxial digital cord (not supplied)

to coaxial digital input

[Speakers]

LINE OUT

VIDEO

NORMAL PROGRESSIVE

S VIDEO OUT

PCM/DTS/

DOLBY DIGITAL

AV amplifier (receiver) having a decoder

DIGITAL OUT

COAXIAL

[Speakers]

Rear (L)

Subwoofer

Rear (R)

: Signal flow

z Hint

Use connection when connecting to 7 or

more speakers (6.1 ch or more).

Notes

• After you have completed the connection, be sure to set “DOLBY DIGITAL” to “DOLBY DIGITAL” and “DTS” to “ON” in Quick Setup (page 25).

Front (L)

Center

Front (R)

• In order to listen to DTS sound tracks, you must use this connection. DTS sound tracks are not output through the LINE OUT L/R (AUDIO) jacks, even if you set “DTS” to “ON” in Quick Setup (page 25).

• When you connect an amplifier (receiver) that conforms to the 96 kHz sampling frequency, set “48kHz/96kHz PCM” in “AUDIO SETUP” to “96kHz/24bit” (page 69).

+ 56 hidden pages
