White paper
January 2014
Xperia™ T2 Ultra
D5303/D5306
Note: Screen images are simulated.
White paper | Xperia™ T2 Ultra
Purpose of this document
Sony product White papers are intended to give an overview of a product and provide details in relevant
areas of technology.
Document history
Version
January 2014 First released version Version 1
May 2014 Second released version Version 2
May 2014 Third released version Version 3
Sony Mobile Developer World
For the latest technical documentation and development tools, go to www.sonymobile.com/developer.
This White paper is published by:
Sony Mobile Communications AB,
SE-221 88 Lund, Sweden
www.sonymobile.com
© Sony Mobile Communications AB, 2009-2014.
All rights reserved. You are hereby granted a
license to download and/or print a copy of this
document.
Any rights not expressly granted herein are
reserved.
First released version (January 2014)
Publication number: 1278-0975
This document is published by Sony Mobile
Communications AB, without any warranty*.
Improvements and changes to this text
necessitated by typographical errors,
inaccuracies of current information or
improvements to programs and/or equipment
may be made by Sony Mobile Communications
AB at any time and without notice. Such changes
will, however, be incorporated into new editions
of this document. Printed versions are to be
regarded as temporary reference copies only.
*All implied warranties, including without
limitation the implied warranties of
merchantability or fitness for a particular
purpose, are excluded. In no event shall Sony or
its licensors be liable for incidental or
consequential damages of any nature, including
but not limited to lost profits or commercial loss,
arising out of the use of the information in this
document.
2 January 2014
White paper | Xperia™ T2 Ultra
Table of contents
Product overview ..........................................................................................................2
Xperia™ T2 Ultra highlights ...................................................................................2
Facts – dimensions, weight, performance and networks ......................................4
Categorised feature list ..........................................................................................7
Technologies in detail .................................................................................................10
Device-to-device communications (local) ...........................................................10
ANT+™ wireless technology .............................................................................10
Device-to-device communications (local) ...........................................................11
Bluetooth® wireless technology .......................................................................11
Wi-Fi® ...............................................................................................................12
DLNA Certified® (Digital Living Network Alliance) ............................................13
Messaging ...........................................................................................................14
MMS (Multimedia Messaging Service)..............................................................14
Email .................................................................................................................14
Positioning – location based services .................................................................15
Provisioning (OMA CP) ........................................................................................15
Multimedia (audio, image and video) ...................................................................16
Synchronisation (OMA DS, EAS, Google Sync™) ...............................................18
Web browser .......................................................................................................18
Memory in Android™ devices .............................................................................19
Trademarks and acknowledgements ..................................................................23
1 January 2014
White paper | Xperia™ T2 Ultra
Product overview
Xperia™ T2 Ultra highlights
• 6-inch TFT-IPS HD screen with TRILUMINOS™ Display for mobile and Mobile BRAVIA® Engine 2
• 13MP smart social camera with Exmor RS™ for mobile and Xperia™ camera apps
• Powerful 3000 mAh battery with Battery STAMINA mode
• Super performance – LTE and Snapdragon quad-core 1.4 GHz processor
• NFC-based one-touch functions – connectivity made easy
Large screen, maximum portability
For a phone with a 6-inch screen, the Xperia™ T2 Ultra has a surprisingly sleek look and feel. This is
because of the extremely high ratio of screen to phone size – 73.6%, to be exact. And the Xperia™ T2
Ultra features an easy-toggle keyboard for one-handed input. Ideal when using its mini keypad, dial pads
and easy trigger notification tray.
True colours on the 6-inch display
The wide-viewing angle screen is a 6-inch HD TRILUMINOS™ Display for mobile. This means it’s built
with the same ground breaking technology as Sony BRAVIA® TVs. You can expect a wider palette and an
amazingly vivid reproduction of colours. The screen also includes Mobile BRAVIA® Engine 2, a Sony
display technology optimised to enhance sharpness and reduce noise.
Camera brilliance
Everyday life is full of memorable moments. With the Xperia™ T2 Ultra, you’ve got the means to catch
them all, and experience them again and again. This stylish smartphone has an impressive 13 megapixel
smart social camera with an Exmor RS™ for mobile image sensor. All this glorious technology results in
great picture quality, even in low-light situations.
Xperia™ camera apps take your camera further
The Xperia™ T2 Ultra comes loaded with Xperia™ camera apps designed to take your creativity to the
next level. Portrait retouch will make your subjects more photogenic than ever before. The app will let you
apply 8 different beauty styles to your portrait – and you can check the change in real time, before
capturing the shot. When in photo edit mode, you can also try the new Collage photo function. Choose
from 51 templates and 25 background options and combine several pictures into a collage.
Want to share your moments as they happen? Social live lets you broadcast videos live via Facebook. Get
responses right on the screen and let the communication flow in real time. With the Timeshift-burst
feature, you’ll always get the best shot. This intelligent app captures 31 frames in 2 seconds. Keep the
shots you want, scrap the rest. Or switch to AR Effect mode and liven up your pictures and videos with
anything from animated dinosaurs to ocean life.
Wireless NFC technology connects it all
Tired of tripping over cables? The Xperia™ T2 Ultra can be wirelessly connected to a large range of NFCenabled Sony devices – from headsets to BRAVIA® TVs. View photos or videos from your smartphone on
your TV. Or play your music through a wireless speaker or wireless headphones. You can easily and
wirelessly connect the NFC devices to your smartphone with just one touch. That’s it. No fiddling with
buttons, settings or – you’ve guessed it - cables. Just pure entertainment. Just so easy.
2 January 2014
White paper | Xperia™ T2 Ultra
Super speed and stamina
Does speed have to compromise stamina? The Xperia™ T2 Ultra proves the answer is no. This Sony
smartphone has support for lightning fast LTE networks. For super powerful performance, there’s the
quad-core 1.4 GHz Snapdragon processor. And thanks to Battery STAMINA Mode, you don’t have to
worry about wasted battery drain. This function can recognise when you’re not using your display and
automatically turns off certain functions. In short, that means your battery can last longer.
Sony Select – great content on your Xperia™ T2 Ultra
The best content from different applications and services, all accessible in one view. With Sony Select,
you get the cherries picked for you.
For more information about Sony Select, visit http://www.sonymobile.com/global-en/apps-services/sonyselect/.
3 January 2014
White paper | Xperia™ T2 Ultra
Facts – dimensions, weight, performance and networks
Operating system Google™ Android™ 4.3 (Jelly Bean MR2)
Processor 1.4 GHz Qualcomm MSM8928 Quad Core
GPU Adreno 305
Size 165.2 x 83.8 x 7.65mm
Weight 171.7 grams (D5303)
172.4 grams (D5306)
Available colours Black
White
Purple
SIM card micro SIM
Main screen
Colours 16,777,216 colour TFT
Resolution 720x1280 pixels
Size (diagonal) 6.0 inches
Input mechanisms
Text input On-screen QWERTY keyboard
Touch screen Capacitive
Touch gesture Yes – multi-touch, up to 10 fingers supported
Memory
RAM 1 GB
Flash memory 8 GB*
Expansion slot microSD™ card, up to 32 GB
Camera
Camera resolution 13 MP
Digital zoom 16x
Photo light Yes – Pulsed LED
Video recording Yes – HD 1080p
Front Camera Yes – HD 720p for video chat and 1.1 MP for camera capture
Sensors
Accelerometer Yes
Proximity sensor Yes
4 January 2014
White paper | Xperia™ T2 Ultra
Ambient light sensor Yes
Magnetometer Yes
Gyroscope Yes
Networks
D5303 UMTS HSPA+ 850 (Band V), 900 (Band VIII), 2100 (Band I) MHz
GSM GPRS/EDGE 850, 900, 1800, 1900 MHz
LTE (Bands 1, 3, 5, 7, 8, 20)
D5306 UMTS HSPA+ 850 (Band V), 900 (Band VIII), 1700 (Band IV),
1900 (Band II), 2100 (Band I) MHz
GSM GPRS/EDGE 850, 900, 1800, 1900 MHz
LTE (Bands 2, 4, 7, 17)
Data transfer speeds
GSM GPRS Up to 107 kbps
GSM EDGE Up to 296 kbps
HSUPA (upload) Cat 6, up to 5.76 Mbps
HSDPA (download) Cat 24, up to 42 Mbps
LTE (upload) Cat 4, up to 50 Mbps
LTE (download) Cat 4, up to 150 Mbps
Hearing Aid Compatibility (HAC)***
M-Rating M3
T-Rating T3
Talk time (GSM) Up to 14 hours**
Standby time (GSM) Up to 1071 hours**
Talk time (UMTS) Up to 24 hours**
Standby time (UMTS) Up to 1046 hours**
Standby time (LTE) Up to 897 hours**
Music listening time Up to 93 hours**
Video playback time Up to 10 hours**
Battery (Embedded) 3000 mAh minimum
* Memory comprises approximately 3.2 GB of firmware, plus 4.8 GB of “Internal storage” for music, pictures and movies, and downloaded applications and their data. For more details about memory, see
“Memory in Android™ devices” on page 19.
** Values are according to GSM Association Battery Life Measurement Technique as performed in controlled laboratory conditions. Actual time may vary.
*** HAC is only supported by the D5306 variant.
5 January 2014
White paper | Xperia™ T2 Ultra
NOTE: Battery performance may vary depending on network conditions and configurations, and device
usage.
NOTE: Performance metrics measured under laboratory conditions.
