Sony D117, D117CD User Manual
Specifications and Main Features
- Model No: LBT-D117CD
- Power requirements: 120V AC, 60 Hz
- Power consumption: 85W
- Weight: Approximately 8.6 Kg (18 lb 15 oz)
- Dimensions: Approximately 355 mm x 380 mm x 325 mm (with projections)
- Speaker system: Triaxial
- Range for FM tuner section: 87.5 MHz – 108 MHz
- Range for AM tuner section: 530 KHz – 1,710 KHz
- Tuner cassette deck: Four crisscrossed channels stereo
- Frequency response (DOLBY NR OFF) for Type II cassette: 40 Hz to 14 kHz (+3 dB)
- Frequency response (DOLBY NR OFF) for Type I cassette: 40 Hz to 13 kHz (+3 dB)
- Frequency response for CD: 2 to 20 kHz with de rating of 0.5
- Signal noise ratio: over 93 dB
- Range of Dynamics: over 90 dB
- Total harmonic distortion: Less than 0.008 % (1kHz)
- Channel separation at 90 dB(1 kHz): More than 90 dB
- RM-S171 remote commander: Included.
- Sensitivity of Input Jack type: VIDEO - 300 mV, PHONO - 3 mV
- Jack socket Outlet: - HEADPHONES - 8 ohm and over reduced.
- Wow and flutter: 0.1% (WRMS)
- Fade in/out duration: 2 – 10 seconds adjustable
- Time Fade feature: This functionality lets a particular recording fade out at set time.
- Memory station tuning capacity: Overall 30 frequency’s.
Frequently Asked Questions
Q: What should I do if there is no power?
A: AC Power cord to the device needs to be properly plugged.
Q: Why is there no sound from the speakers?
A: Firstly, the volume should be checked to make sure that it is up, also make sure that the speaker cords have been properly connected.
Q: How can I improve FM reception?
A: Try moving and rotating the antenna around or, can connect the antenna output to a better external antenna to improve reception.
Q: Can I make recordings using this system?
A: Yes, this system has a cassette deck which allows for recordings to be made: insert a blank cassette tape into the deck and select the source for recording.
Q: What kind of CDs can I use with this device?
A: This device accepts both normal 12 cm (5 inch) and 8 cm (3 inch) without adaptor and with adaptor CDs.
Q: What does the DOLBY NR switch do?
A: When playing back a tape that was recorded using a Dolby noise reduction system, it reduces the tape hiss noise during playback.
Q: Remote Commander, how do you use this? How do you use this?
A: Insert two size AA (R6) batteries correctly and point at the remote sensor of the device.
Q: So, moisture condenses, what do you do?
A: Turn on the unit and keep it for around 1 hour or until the moisture dries out.
Q: How do I do a factory reset or how do I clear the memory station?
A: To clear the entire program or memory, one can press the appropriate buttons as indicated in the manual when the device is in the stop or play mode.
