Page 1

VPL

-HS60

Home Theater Video Projector

Key Features

Cinema Black Pro (with Advanced Iris Function and Lamp Control)

Advanced Iris Function and Lamp Control

High Contrast Ratio of up to 10,000:1 (Advanced Iris Auto Mode ON)

Lens Shift Function

All Range Crisp Focus Lens (ARC-F Lens)

Quiet operation with low fan noise of 23dB

Real Color Processing Function

Three WXGA LCD Panels, .73" p-Si TFT Panels

Resolution: 1280 x 720 (x 3) or 2,764,800 Total Pixels

Lens: 1.6 Times Manual Zoom / Focus Lens (F2.4-3.1 / f2)

Key Technologies

Advanced Iris Function

This function reproduces bright images in bright scenes and deeper blacks in dark scenes by dynamically changing the opening according to the level of input signal. Working with the Micro Lens Array and WB (Wide View) film a 4.5 times improvement in contrast ratio can now be realized over previous models. In the "Auto" mode an awesome contrast ratio of up to 10,000:1 can now be achieved.

Lens Shift Function

This function adjusts the picture position both vertically (total shift of 2 picture heights maximum up to maximum down) and horizontally (total shift of 1 picture height maximum left to maximum right) to allow for off center positioning and very flexible installation options. The projector can be mounted above the top of the screen, or below the bottom of the screen, by up to

½ screen height. And it uses the full panel to maintain

the best possible resolution and highest possible picture quality.

ARC-F (All Range Crisp Focus) Lens

The All Range Crisp Focus Lens delivers an 8% improvement in focus to the

center of the screen and a 20% improvement in focus to the corner of the screen.

RCP (Real Color Processing)

Real Color Processing allows the user to target specific colors on the picture and fine adjust their color and hue without changing the overall picture's color and hue. For instance, the color of a strawberry can be fine adjusted without impacting the skin tones. Or the blue in a sky can be adjusted without affecting the color of water. And green grass can be adjusted without influencing the other colors in the picture.

Full Digital Processing

Sony's Full Digital Processing circuits include a number of processes designed to optimize picture performance of any input source. The 12-Bit Panel Driver achieves excellent gradation reproduction and a high level of detail. The I/P Converter attains a sharp image and superior diagonal line reproduction. It can also process HD I/P conversion resulting in a precise and high density image. A significant improvement in signal to noise ratio is also realized.

Page 2

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 800.222.7669 • www.sony.com

Last Updated: 03/06/2007

VPL

-HS60

Home Theater Video Projector

Please visit the Dealer Network for current

information at www.sony.com/dn

Features

General

Vertical Keystone:

Yes

Standby Mode: Yes High Altitude Mode: Off, On Information Menu: Horizontal and Vertical

frequency display

Acceptable Computer Signals: fH: 19 to 72 kHz,

fV: 48 to 92 Hz, fV: 60 Hz

Input A: Auto, Computer, Component, Video

GBR

Video

Video Processing: 10-bit processing Comb Filter: Yes (3DY) Vertical Position: Yes Wide Mode: Wide Mode (Full, Normal, Wide

Zoom, Zoom)

Display Technology: 3LCD Technology High Definition: Yes Horizontal Size: Yes Dot Phase: Yes Acceptable Video Signals: 15 kHz

(RGB/Component) 50/60Hz, Progressive component 50/60 Hz, DTV (480/60i, 575/50i, 480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24pSf, Composite video, Y/C video.

Micro Display Type: 0.73" TFT LCD chip (921,600

pixels per chip. 2,764,800 total pixels.)

Convenience

Multiple Language Display:

15 languages (including English, French, Spanish, German and Chinese)

Power Save Mode: On, Off Auto Input Search: Yes Image Flip:

HV, H, V, Off

Illumination: Off, On

Specifications

General

Lens: f21.3 to 33.7 mm/F2.4 to 3.16 mm Projection Picture Size: 40" to 200" measured

diagonally

Color System: Auto, NTSC, PAL, SECAM Television Type: Front Projection

Video

Native Resolution: 720p Contrast Ratio: Up to 10000:1 (with Advanced

Iris Auto ON)

Display Resolution: 1280 x 768

Inputs and Outputs

Component Video (Y/Pb/Pr ) Input(s): 1 (Rear) Composite Video Input(s): 1 (Rear) Vp-p+/-2 dB

sync negative (75 ohms terminated)

-Video Input(s): Y/C mini DIN 4-pin type, Y

(luminance): 1 Vp-p+/-2 dB sync negative (75 ohms terminated) C (chrominance): burst

0.286 1 Vp-p+/-2 dB (NTSC) sync negative (75 ohms terminated) burst 0.3 1 Vp-p+/-2 dB (PAL) sync negative (75 ohms terminated)

HDMI™ Connection(s): 1 (Rear) Digital

RGB/Y/Cb(Pb)Cr(Pr)

PC Input(s): 1 (Rear) fH: 19 to 72kHz / fV: 48 to

92 Hz / Maximum resolution: 1280 x 768 fV: 60Hz

Component/Progressive: DTV (480/60i, 575/50i,

480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i), 1080/60p (DVI and HDMI channel only), Composite video, Y/X video

12V Trigger Input(s): Yes

Power

Power Consumption (in Operation): 195W Power Consumption (in Standby): 3W Power Requirements: AC 100 to 240V, 0.8 to

1.95A, 50/60Hz

Service and Warranty Information

Limited Warranty:

Product Warranty - 2 Years Parts and Labor except the lamp. Lamp Warranty - 90 Days from date of purchase.

Dimensions

Weight:

12.57lbs (5.7kg)

Measurements: 13 3/4 x 5 3/8 x 14 1/8" (348 x

135 x 360mm)

Operating Conditions

Operating Temperature:

-20°C to 60°C (-4°F to

140°F)

Operating Humidity:

35% to 85% (no

condensation)

Supplied Accessories

Instruction Manual Remote Control (RM-

PJHS50) Air Filter (PK-HS10FL) AA Battery x 2

Optional Accessories

Replacement Lamp (LMP-

H130)

Replacement Air Filter (PK-

HS10FL) Suspension Support (PSS-610) - Black Suspension Support (PSS-

H10)

- White

UPC Code: 027242682498

Confidential Sony information. For internal use only.

1. ANSI lumen is a measuring method of the American National Standards Institute IT7.228. Since there is no uniform method of measuring brightness, specifications will vary among manufacturers.

2. Conditions: Lamp Control Low and Advanced Iris ON.

3. Based on Usage.

4. Limited to resolutions supported by both the PC and the Sony TV. See Sony TV users manual and PC documentation for supported resolutions
