1998 AUTOSOUND PRODUCT GUIDE – PART 1
26
CDX-715
CD Changer
Ω 110 CD Custom File
Memory
Ω Memo List, Program Play
Ω Digital Dynamic Bass
Ω Super Suspension System, 5-way Mounting
Ω 8X Oversampling, 1-Bit D/A
Ω Advanced Electronic Shock Protection
Ω Digital Servo Control
Ω Rapid Change 10 CD Mechanism
General
Output Terminals
Current Drain
Operating Temperature
Dimensions
Mass
Supplied Accessories
UniLink BUS Control Output (8 Pin)
Analog audio output (RCA)
800 mA (CD playback); 800 mA (during loading or ejecting a disc)
-10° C to 55° C (14° F - 131° F)
Approx. 262 x 90 x 181.5 mm (103/8x 35/8x 71/4in.) (w/h/d)
Approx. 2.1 kg (4 lb. 10 oz.)
Disc magazine (XA-250) (1)
Mounting hardware (1 set)
5.5-meter UniLink BUS cable (1)
5.5-meter RCA pin cord (1)
Design and specifications subject to change without notice.
Connector Panel Configuration
CD Player Section
Mechanism Type
Optical Pickup Name
System
Frequency Response
Signal-to-Noise Ratio
Wow and Flutter
Laser Diode Properties:
Material
Wavelength
Emiss. Duration
Laser out Power
MG-250B-137
KSS-521A/J2RP
Compact Disc Digital Audio System
10 - 20,000 Hz
94dB
Below Measurable Limit
GaAlAs
780 nm
Continuous
Less than 44.6 uW
(Measured at a distance of 200 mm
from objective lens surface on
Optical Pickup)
Page 2
1998 AUTOSOUND PRODUCT GUIDE – PART 1
27
181.5mm, approx 71/4"
90mm, approx 3
5
/
8
"
262mm, approx 103/8"
CDX-715
CD Changer
158mm, approx 63/4"
50mm, approx 2"
VERTICAL
