Sony CBEH1300 User Manual

Safety and Support Sécurité et support technique Seguridad y soporte técnico

CECHJ01

Before using this product, carefully read all product documentation and retain it for future reference. Avant d'utiliser ce produit, lisez attentivement toute la documentation sur les produits et conservez-la pour pouvoir la consulter ultérieurement. Antes de utilizar este producto, lea detenidamente toda la documentación del producto y consérvela para consultarla en el futuro.

3-452-922-11(1)

WARNING

To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

Caution Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. The use of optical instruments with this product will increase eye hazard.

This appliance is classified as a CLASS 1 LASER product under IEC608251+A2:2001.

This equipment complies with FCC/IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated with at least 20 cm (8 in) and more between the radiator and person's body (excluding extremities: hands, wrists, feet and legs). This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. The wireless controller complies with FCC/IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR).

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

WARNING

If you have questions about this product, call our technical support line at 1-800-345-7669, or write to: Sony Computer Entertainment America Consumer Services/Technical Support PO Box 5888, San Mateo, CA 94402-0888 U.S.A.

Declaration of Conformity

Trade Name : Model No. : Responsible Party : Address :

Telephone No. : This device complies with Part 15 of the FCC Rules and RSS-Gen of IC

Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of this device.

SONY CECHJ01 Sony Electronics Inc. 16530 Via Esprillo San Diego, CA 92127 U.S.A. 858-942-2230

Photosensitivity/Epilepsy/Seizures

A very small percentage of individuals may experience epileptic seizures or blackouts when exposed to certain light patterns or flashing lights. Exposure to certain patterns or backgrounds on a television screen or when playing video games may trigger epileptic seizures or blackouts in these individuals. These conditions may trigger previously undetected epileptic symptoms or seizures in persons who have no history of prior seizures or epilepsy. If you, or anyone in your family, has an epileptic condition or has had seizures of any kind, consult your physician before playing.

IMMEDIATELY DISCONTINUE use and consult your physician before resuming gameplay if you or your child experience any of the following health problems or symptoms:

• dizziness,

• altered vision,

• eye or muscle twitches,

• loss of awareness,

• disorientation,

• seizures, or

• any involuntary movement or convulsion. RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR PHYSICIAN.

Use and handling of video games to reduce the likelihood of a seizure

• Use in a well-lit area and keep as far away as possible from the television screen.

• Avoid large screen televisions. Use the smallest television screen available.

• Avoid prolonged use of the PS3™ system. Take a 15-minute break during each hour of play.

• Avoid playing when you are tired or need sleep.

USUS

About the lithium coin memory back-up battery

The lithium coin memory back-up battery inside this product contains Perchlorate. The following statement is required by the State of California, USA: Perchlorate Material - special handling may apply, See http://www.dtsc.ca.gov/hazardouswaste/perchlorate

WARNING

Radio waves

Radio waves may affect electronic equipment or medical devices (for example, pacemakers), which may cause malfunctions and possible injuries.

• If you use a pacemaker or other medical device, consult your physician or the manufacturer of your medical device before using the wireless networking feature (Bluetooth and wireless LAN).

• Do not use the wireless networking feature in the following locations: – Areas where wireless network use is prohibited, such as in hospitals. Abide by

medical institution regulations when using the system on their premises.

– Areas near fire alarms, automatic doors and other types of automated equipment.

PlayStation® and PlayStation®2 format software

This model of the PLAYSTATION PLAYSTATION system is not compatible with and will not play PlayStation Some PlayStation visit www.us.playstation.com.

®3 format software and has limited backward compatibility. This

® format software may play on this system. For more information,

®3 system is designed to play

®2 format software.

About DNAS

Sony Computer Entertainment Inc. uses DNAS (Dynamic Network Authentication System), a proprietary authentication system, to help protect copyright and security in connecting the PS3™ system to a network. DNAS may retrieve information about a user's hardware and s oftware for authentication, copy protection, account blocking, system, rules, or game management and other purposes. The information collected does not identify the user personally. The unauthorized transfer, exhibition, export, import or transmission of programs and devices circumventing its authentication scheme may be prohibited by law.

System software

The system software included within this product is subject to a limited license from Sony Computer Entertainment Inc. Refer to http://www.scei.co.jp/ps3-eula for further details.

WARNING

Table of contents About the PS3™ system documentation

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

About the PS3™ system documentation . . . . . . . . . . . . . . . . . . . 5

x Before use

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

x Troubleshooting

Before requesting service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

x Limited warranty

LIMITED HARDWARE WARRANTY AND LIABILITY . . . . . . . . 14

x Additional information

Removing / replacing the hard disk . . . . . . . . . . . . . . . . . . . . . . 16

Reinstalling the system software . . . . . . . . . . . . . . . . . . . . . . . . 18

Caution on disposal of the PS3™ system . . . . . . . . . . . . . . . . . 20

Wireless controller battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Information about system functionality published in this document may vary from the information for your PS3™ system, depending on the system software version in use.

The PS3™ system documentation includes the following:

Safety and Support (this document)

This document contains safety information related to the use of the PS3™ system, troubleshooting, specifications and other information.

Quick Reference

This document contains information on setting up the PS3™ system, preparing for use and basic hardware operations.

User's Guide (http://manuals.playstation.net/document/)

This online document is accessed through the Internet and contains detailed information related to use of the PS3™ system software.

Notice

For up-to-date information regarding the PS3™ system, visit http://www.us.playstation.com.

Table of contents

Before use

Precautions

Safety

This product has been designed with the highest concern for safety. However, any electrical device, if used improperly, has the potential for causing fire, electrical shock or personal injury. To help ensure accident-free operation, follow these guidelines:

• Observe all warnings, precautions and instructions.

• Regularly inspect the AC power cord for damage.

• Stop use, unplug the AC power cord from the electrical outlet and disconnect any other cables immediately if the device functions in an abnormal manner, produces unusual sounds or smells or becomes too hot to touch.

• For more information on product safety and troubleshooting, visit http://www.us.playstation.com/Support. Contact SCEA Consumer Services at 1-800-345-7669 if the device does not operate properly.

Use and handling

• Use in a well-lit area and keep as far away as possible from the television screen.

• Avoid prolonged use of the PS3™ system and wireless controller.

• Stop using the system immediately if you begin to feel tired or if you experience discomfort or pain in your hands or arms while operating the wireless controller. If the condition persists, consult a doctor.

• If you experience any of the following health problems, discontinue use of the system immediately. If symptoms persist, consult with your physician. – Dizziness, nausea, fatigue or symptoms similar to motion sickness – Discomfort or pain in a part of the body, such as eyes, ears, hands or arms

• Keep the system and accessories, including cable ties and fasteners, out of the reach of small children.

• Do not connect cables other than a USB cable while the system is turned on (power indicator is lit solid green).

• Any TV or component connected to the system must be functioning properly and free of defects. If a TV or component connected to th e system is faulty or defective, it may cause damage to the TV or component, or to the system itself. As with all electrical products, connection to faulty or defective components, or the failure to connect to a properly wired outlet, may cause sparking and pose a fire hazard.

• Do not touch the system or connected cables or accessories during an electrical storm.

• Do not use the system or accessories near water.

• Do not allow liquid, small particles or other foreign objects to get into the system or accessories.

• Do not touch the connectors of the system or accessories.

• Do not expose the system or accessories to dust, smoke or steam. Also, do not place the system in an area subject to excessive dust or cigarette smoke. Dust build-up or cigarette smoke residue on the internal components (such as the lens) may cause the system to malfunction.

• Do not expose the system or accessories to high temperatures, high humidity or direct sunlight.

• Do not place the system or accessories on surfaces that are unstable, tilted or subject to vibration.

• Do not set the system other than in the vertical or horizontal position. Also, do not change the position while the system is turned on.

• Be careful when carrying the system. If you do not have a good grip, the system may drop causing potential damage or injury.

• Do not move or change the position of the system with a disc inserted. The vibration may result in scratching of the disc or the system.

• Do not turn off the system while data is being saved on or loaded from the hard disk.

• Do not stand on or put objects on the system, and do not stack the system with other devices.

• Do not place the system and connected accessories on the floor or in a place where they may cause someone to trip or stumble.

• Do not allow bodily contact with the system or air from the system vents for an extended period of time while in use. Extended contact under these conditions may cause low-temperature burns.

Precautions

• When connecting the system to a plasma or projection* TV, do not leave a still image on the TV screen for an extended period of time, as this may leave a faint image permanently on the screen. *

Except LCD screen types

• Parents are encouraged to monitor children in online activities to ensure safe and responsible Internet usage.

• When using the motion sensor function of the wireless controller, be cautious of the following points. If the controller hits a person or object, this may cause accidental injury or damage. – Before using, check that there is plenty of space around you. – When using the controller, grip it firmly to make sure it cannot slip out of your

hand.

– If using a controller that is connected to the PS3™ system with a USB cable,

make sure there is enough space for the cable so that the cable will not hit a person or object. Also, take care to avoid pulling the cable out of the PS3™ system while using the controller.

Vents

Do not block any vents. To maintain good ventilation, follow the guidelines below:

• Place the system at least 10 cm (4 in) away from a wall surface.

• Do not place on a carpet or rug with long fibers.

• Do not place in a narrow or cramped space.

• Do not cover with cloth.

• Do not allow dust to build up on the vents.

AC power cord use

• To avoid possible damage to the system or to a connected TV or component, the AC power cord must be plugged into a polarized, three-prong, electrical outlet that is properly wired and grounded. As with all electrical products, connection to faulty or defective components, or the failure to connect to a properly wired outlet, may cause sparking and pose a fire hazard.

• Do not plug the AC power cord for the system into an electrical outlet until you have made all other connections. Make sure the TV or other component is unplugged from the electrical outlet prior to connecting it to the system.

• To help ensure safe operation, regularly inspect the AC power cord. If damaged, stop use immediately and call SCEA Consumer Services at 1-800-345-7669 for assistance.

• Do not use a power cord other than the supplied AC power cord. Do not modify the cord.

• Do not touch the plug of the AC power cord with wet hands.

• Protect the AC power cord from being walked on or pinched particularly at plugs, expansion receptacles and the point where the cord exits from the system.

• Do not place heavy items on the cord.

• Do not place the AC po wer co rd near heating equipment and do not expose the cord to heat.

• Unplug the AC power cord from the electrical outlet before cleaning or moving the system, or when you do not intend to use the sys tem for an extended period of time. When disconnecting, grasp the power cord by the plug and pull straight out of the electrical outlet. Never pull by the cord and do not pull out at an angle.

• Do not connect the AC power cord to a voltage transformer or inverter. Connecting the AC power cord to a voltage transformer for overseas travel or an inverter for use in an automobile may cause heat to build up in the system and may cause burns or a malfunction.

Never disassemble or modify the system or accessories

Use the PS3™ system and accessories according to the instructions in the product documentation. No authorization for the analysis or modification of the system or accessories, or the analysis and use of its circuit configurations, is provided. Unauthorized modification of the system or accessories will void your warranty. There are no user serviceable components inside the PS3™ system (the supplied hard disk may be removed but not disassembled or modified). Additionally, there is a risk of exposure to laser radiation as well as to electrical shock.

Network

• A broadband connection is required to access the Internet. Note that dial-up connectivity is not supported.

• User is responsible for Internet service fees. For details, refer to the information provided in your service contract or contact your Internet service provider.

Before use

Precautions

• Use only an Ethernet cable compatible with 10BASE-T, 100BASE-TX or 1000BASE-T networks. Do not use a cord for a standard residential telephone line or cables of types other than those mentioned here. Using the wrong type of cord or cable can cause more electrical current than necessary to flow through the LAN connector, which may lead to heat build-up, fire or malfunction.

Wireless networking feature

• The 2.4 GHz range of radio waves used by the wireless networking feature of this product is a range shared by various devices. This product has been designed to minimize the effect of other devices using the same range. However, in some cases interference from other devices may reduce the connection speed, shorten the signal range or cause the connection to be terminated unexpectedly.

• When using the PS3™ system's scan function to select a wireless LAN access point, access points that are not intended for public use may be displayed. Only connect to an access point that you are authorized to use.

Moisture condensation

If the system or disc is brought directly from a cold location to a warm one, moisture may condense on the lens inside the system or on the disc. Should this occur, the system may not operate properly. In this case, remove the disc and turn off and unplug the system. Do not put the disc back in until the moisture e vaporates (this may take several hours). If the system still does not operate properly, call SCEA Consumer Services at 1-800-345-7669 for assistance.

Cleaning

For safety reasons, before cleaning the system or connected accessories, disconnect the AC power cord from the electrical outlet.

Exterior surfaces (plastic cover of system and wireless controller)

Follow the instructions below to help prevent the product exterior from deteriorating or becoming discolored.

• Wipe with a soft, dry cloth.

• Do not place any rubber or vinyl materials on the product exterior for an extended period of time.

• Do not use solvents or other chemicals. Do not wipe with a chemically-treated cleaning cloth.

Vents

When dust accumulates in the system vents, remove the dust with a low-powered vacuum cleaner.

Backing up data

It is recommended that you regularly back up data on the hard disk. If for any reason software or data loss or corruption occurs or the hard disk must be initialized during authorized service, it may not be possible to restore or repair the software or data. Sony Computer Entertainment Inc. and its subsidiaries and affiliates will not be held liable for damage or injury related to software or data loss or corruption.

Using the backup utility

You can back up data stored on the hard disk to a USB mass storage device and restore data that has been backed up. Select "Backup Utility" under (Settings)

(System Settings) and follow the on-screen instructions to perform this operation. Note that depending on the system's usage condition, you might not be able to back up or restore some data. It is recommended that you create a spare backup for important data in advance by copying or moving the data to a USB mass storage device. For details on the backup utility feature, refer to the user's guide ( page 5).

Precautions

Copying/moving files

The following file types saved on the system's hard disk can be copied or moved to a USB mass storage device. Select the file, press the button, and then select "Copy" or "Move" from the options menu. You may not be ab le to copy or move files that contain copyright-protected data.

File type Back up destination

Saved data from games; video, audio or image files

Hint

By using a commercially available card reader/writer (USB connector type), you can back up files saved on the hard disk to storage media such as a Memory Stick™ or an SD Memory Card.

USB mass storage device (USB flash drive, etc.)

Discs

Note on compatibility

Some media may have region or territorial restrictions and may not work with your system. See media packaging for details.

Handling

• Do not touch the disc surface when handling a disc; hold it by the edges.

• Do not stick paper or tape onto discs and do not write on discs.

• Fingerprints, dust, dirt or scratches on the disc can distort the picture or reduce sound quality. Always handle carefully and check that discs are clean before use.

Storage

• Do not expose discs to high temperatures, high humidity or direct sunlight.

• When discs will not be used for an extended period of time, store them in their cases. Stacking uncased discs or storing them at an angle can cause them to warp.

Cleaning method

• Clean discs with a soft cloth, lightly wiping from the center outwards.

• Do not use solvents, record cleaners, anti-static spray or other chemicals as these can damage the discs.

Before use

Precautions
