Sony AITE260, AITE520, AITE90, AITE390, AITE130 Operating Instructions

AIT Drive

Operating Instructions

4-680-347-16(1)

AIT-4 TAPE DRIVE

AITe520

AIT-3 Ex TAPE DRIVE

AITe390

AIT-3 TAPE DRIVE

AITe260

AIT-2 TAPE DRIVE

AITe130

AIT-1 TAPE DRIVE

AITe90

©2003 Sony Corporation

Safety Regulations

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial
number in the space provided below.
Refer to them whenever you call upon your dealer regarding this product.

Model No. Serial No.
________________________ __________________________________

Information

WARNING

To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.

Model No. for Regulatory Compliance

Your AITe520, AITe390 is assigned a Model No. ATDEA4 for regulatory
compliance certifications. Your AITe260 is assigned a Model No.: ATDEA3
for regulatory compliance certifications. Your AITe130, AITe90 is assigned a
Model No.: ATDEA2 for regulatory compliance certifications. The number is
indicated on the model number label on your drive along with the rated
voltage and current.

For the customers in the USA

You are cautioned that any changes or modifications not expressly approved
in this manual could void your authority to operate this equipment.

WARNING
Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device requires shielded interface cables to comply with FCC emission
limits.

2 Safety Regulations

CAUTION

The mains plug on this equipment must be used to disconnect mains power.
Please ensure that the socket outlet is installed near the equipment and shall
be easily accessible.

ACHTUNG

Zur Trennung vom Netz ist der Netzstecker aus der Steckdose zu ziehen,
welche sich in der Nähe des Gerätes befinden muß und leicht zugänglich
sein soll.

Hinweis: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger
gemäß ISO 7779

NOTICE

Use the power cord set approved by the appropriate testing organization for
the specific countries where this unit is to be used.

HINWEIS

Die 3-adrige Geräteanschlußleitung muß Typ H05VV-F oder H05VVH2-F
sein und nach DIN VDE 0625 geprüft sein. Der Stecker und die
Gerätesteckdose müssen nach DIN VDE 0620 bzw DIN VDE 0625 geprüft
sein. Der Leitungsquerschnitt kann 0,5 mm2 betragen wenn die
Anschlußleitung eine Länge von 2 m nicht überschreitet. Anderenfalls muß
der Leitungsquerschnitt mindestens 0,75 mm2 betragen.

If you have any questions about this product, please refer to Sony contact in
the instruction manual.

DECLARATION OF CONFORMITY

Trade Name: SONY
Model: ATDEA2 or ATDEA3 or ATDEA 4
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo San Diego, CA.

92127 U.S.A.
Telephone number: 858-942-2230
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.

Für Kunden in Deutschland

Diese Ausrüstung erfüllt die Europäischen EMC-Bestimmungen für die
Verwendung in folgender/folgenden Umgebung(en):

– Wohngegenden
– Gewerbegebiete

– Leichtindustriegebiete
(Diese Ausrüstung erfüllt die Bestimmungen der Norm EN 55022, Klasse
B.)

Safety Regulations 3

4 Safety Regulations

IMPORTANT SAFEGUARDS

For your protection, please read these safety
instructions completely before operating the
appliance, and keep this manual for future
reference.

Carefully observe all warnings, precautions and
instructions on the appliance, or the one described
in the operating instructions and adhere to them.

USE

Power Sources – This unit should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type
of electrical power, consult your dealer or local
power company.

For the unit with a three-wire grounding type
ac plug:

If you are unable to insert the plug into the outlet,
contact your electrician to have a suitable plug
installed. Do not defeat the safety purpose of the
grounding plug.

AC Power cord:

The AC power cord should have appropriate safety
approvals or marking for the country in which the
equipment will be used. Consult your dealer or
local power company.

Cleaning – Unplug the unit from the wall outlet
before cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners.
Use a cloth lightly dampened with water for
cleaning the exterior of the unit.

Object and Liquid Entry – Never push objects of
any kind into the unit through openings as they
may touch dangerous voltage points or short out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the unit.

Safety Regulations 5

INSTALLATION

Water and Moisture – Do not use power-line
operated units near water - for example, near a
bathtub, washbowl, kitchen sink, or laundry tub, in
a wet basement, or near a swimming pool, etc.

Power-Cord Protection – Route the power cord
so that it is not likely to be walked on or pinched
by items placed upon or against them, paying
particular attention to the plugs, receptacles, and
the point where the cord exits from the appliance.

Accessories – Do not place the unit on an unstable
cart, stand, tripod, bracket, or table. The unit may
fall, causing serious injury to a child or an adult,
and serious damage to the unit. Use only a cart
stand tripod, bracket, or table recommended by the
manufacturer.

Ventilation – The slots and openings in the
cabinet are provided for necessary ventilation. To
ensure reliable operation of the unit, and to protect
it from overheating, these slots and openings must
never be blocked or covered.

• Never cover the slots and openings with a cloth
or other materials.

• Never block the slots and openings by placing
the unit on a bed, sofa, rug or other similar
surface.

• Never place the unit in a confined space, such as
a bookcase, or built-in cabinet, unless proper
ventilation is provided.

SERVICE

Damage Requiring Service – Unplug the unit
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:

• When the power cord or plug is damaged or
frayed.

• If liquid has been spilled or objects have fallen
into the unit.

• If the unit has been exposed to rain or water.

• If the unit has been subject to excessive shock by
being dropped, or the cabinet has been damaged.

• If the unit does not operate normally when
following the operating instructions. Adjust
only those controls that are specified in the
operating instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the unit to normal
operation.

• When the unit exhibits a distinct change in
performance - this indicates a need for service.

Servicing – Do not attempt to service the unit
yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer to all servicing to qualified service
personnel.

6 Safety Regulations

Table of Contents

How to Use this Guide ...................................................................... 8

Part 1.
Introduction

Part 2.
Preparation

Part 3.
Operation

Part 4.
Care and
Maintenance

About AIT Drives ............................................................................... 9

Features.................................................................................................... 9

Usable Cartridges .................................................................................. 11

System Components .............................................................................. 11

Part Names and Functions ............................................................. 12

Front Panel............................................................................................. 12

Rear Panel .............................................................................................. 13

Supplied Items................................................................................. 14

Interconnections ............................................................................. 15

SCSI ID Setting ................................................................................ 15

Option Switches (DIP Switch) ........................................................ 16

How to use the AIT Drive ................................................................ 19

Cartridge Removal................................................................................. 20

Attaching the Dust Cover ............................................................... 21

WORM Function .............................................................................. 23

Taking Care of the Drive ................................................................. 25

Safety Considerations ............................................................................25

Avoiding Damage .................................................................................. 25

Taking Care of Cartridges .............................................................. 27

Use Precautions ..................................................................................... 27

Storage Precautions ............................................................................... 27

Cleaning ........................................................................................... 28

How to Clean .........................................................................................28

Appendix

Specifications (AITe520)................................................................. 29

Specifications (AITe390)................................................................. 30

Specifications (AITe260)................................................................. 31

Specifications (AITe130)................................................................. 32

Specifications (AITe90)................................................................... 34

Sony Contacts ................................................................................. 36

• Sony cannot accept liability for data written to cartridges lost as a result of using this product.

• Sony bears no responsibility for any financial damages, lost profits, or claims made by third parties arising from the use of
this product.

Table of Contents 7

How to Use this Guide

This Guide describes the AIT Drive Unit AITe520/AITe390/AITe260/
AITe130/AITe90, and how to take care of it. Please read it carefully before
using the unit, and keep it handy for future reference.
The Guide consists of four parts, plus the specifications. Refer to the parts
that relate to your use of the drive.

Part 1 describes the features of the drive, its system components, and the
name and function of each part.

Part 2 describes the necessary connections between the drive and the host
computer. If other SCSI devices are being used, you may need to change the
SCSI ID setting. Read this part if you are installing the drive.

Part 3 describes how to use the drive, including how to turn it on, and how
to insert and remove cartridges. Read this part if you are going to operate the
drive.

Part 4 describes how to take care of the drive and cartridges, and how to
clean the drive. Read this part before using the drive.

Appendix provides the major specifications of the AITe520/AITe390/
AITe260/AITe130/AITe90.

8 How to Use this Guide

Part 1. Introduction

About AIT Drives

The AITe520 is an external AIT drive unit that uses data cartridges
conforming to the AIT-4 format. The AITe390 is an external AIT drive unit
that uses data cartridges conforming to the AIT-3 Ex format. The AITe260 is
an external AIT drive unit that uses data cartridges conforming to the AIT-3
format. The AITe130 is an external AIT drive unit that uses data cartridges
conforming to the AIT-2 format. The AITe90 is an external AIT drive unit
that uses data cartridges conforming to the AIT-1 format. The AITe520
supports AIT-4 format. The AITe390 supports the AIT-1 (Read only), AIT-2
(Read only), AIT-3 and AIT-3 Ex formats. The AITe260 supports the AIT-1,
AIT-2 and AIT-3 formats. The AITe130 supports the AIT-1 and AIT-2
formats. The AITe90 only supports the AIT-1 format.

Features

The AIT Drive Unit AITe520 has the following features:

• Supports reading and writing to data cartridges conforming to theAIT-4
format.

• The second-level error correction code guarantees high data reliability
writing to data cartridges conforming to the AIT-4 format.

• Data compression provides 520 gigabytes of storage on SDX4-200C.
The native capacity is 200 gigabytes of storage on SDX4-200C.

• Stored data are automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer
access.

*1

The AIT Drive Unit AITe390 has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-3
and AIT-3 Ex formats.

• Supports reading from data cartridges conforming to the AIT-1 and AIT-2
formats.

• The second-level error correction code guarantees high data reliability
writing to data cartridges conforming to the AIT-3 Ex format.

• The third-level error correction code guarantees high data reliability writing
to data cartridges conforming to the AIT-1, AIT-2 and AIT-3 formats.

• Data compression provides 390 gigabytes of storage on SDX3X-150C.

*1

The native capacity is 150 gigabytes of storage on SDX3X-150C.

• Stored data are automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer
access.

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

Part 1. Introduction 9

The AIT Drive Unit AITe260 has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-1,
AIT-2 and AIT-3 formats.

• Read After Write Function and third-level error correction code guarantee
high data reliability.

• Data compression provides 260 gigabytes of storage on SDX3-100C.

*1

The native capacity is 100 gigabytes of storage on SDX3-100C.

• Stored data is automatically checked for compression.

• Ultra 160 SCSI LVD/SE interface is fully supported for host computer
access.

The AIT Drive Unit AITe130 has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-1
and AIT-2 formats.

• Read After Write Function and third-level error correction code guarantee
high data reliability.

• Data compression provides 130 gigabytes of storage on SDX2-50C.

*1

The native capacity is 50 gigabytes of storage on SDX2-50C.

• Stored data is automatically checked for compression.

• Wide Ultra SCSI LVD/SE interface is fully supported for host computer
access.

The AIT Drive Unit AITe90 has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-1
format.

• Read After Write Function and third-level error correction code guarantee
high data reliability.

• Data compression provides 91 gigabytes of storage on SDX1-35C.

*1

The native capacity is 35 gigabytes of storage on SDX1-35C.

• Stored data is automatically checked for compression.

• Wide Ultra SCSI LVD/SE interface is fully supported for host computer
access.

10 Part 1. Introduction

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

Usable Cartridges

Data cartridges used with the AITe90 must be marked with the AIT-1 logo.
The AITe130 can be used with data cartridges marked with the AIT-1 or
AIT-2 logo. The AITe260 can be used with data cartridges marked with the
AIT-1, AIT-2, or AIT-3 logo. The AITe390 can be used with data cartridges
marked with the AIT-1 (read only), AIT-2 (read only), AIT-3 or AIT-3 Ex
logo. The AITe520 can be used with data cartridges marked with the AIT-4
logo.

AIT-1 LOGO AIT-2 LOGO AIT-3 LOGO

AIT-3 Ex LOGO AIT-4 LOGO

Caution

• Be sure to use only the cartridges designed specifically for AIT.

• Do not use anything but AIT cartridges with this system, as doing so can
damage the AIT drive. Although commercially available 8mm videotapes
resemble AIT cartridges in appearance, they have entirely different
specifications and cannot be used.

System Components

The AITe520/AITe390/AITe260/AITe130/AITe90 connects to the host
computer via on Ultra Wide LVD/SE SCSI interface.

Host Computer

AITe260/AITe130/

AITe90

Peripheral DevicesAITe520/AITe390/

Terminator

Part 1. Introduction 11

Part Names and Functions

6354

Front Panel

1 AIT Data Cartridge Receptacle

See page 19 to 20 for information on inserting and removing a AIT data
cartridge.

2 POWER Indicator

Lights while the drive is on.

12

Advanced
Intelligent
Tape

3 Dust Cover

This cover protects the AIT data cartridge receptacle.

4 LED Indication for Drive Status

The LED indicators are defined as follows.

LED

TAPE CLEANING REPLACE

MOTION REQUEST TAPE

Independent Independent Tape Loaded

Independent Independent

Independent Independent Tape Access in Progress (others)
Independent Independent Cleaning is requested
Independent Independent Cleaning is Not Completed
Independent Independent Media Error Occurred

on

Slow

1 pulse (0.9 sec on/0.3 sec off)

Fast

1 pulse (0.3 sec on/0.3 sec off)

Tape Access in Progress
(write/read)

H/W Error Occurred

Sense

12 Part 1. Introduction

Rear Panel

5 EJECT Button

Push to remove a data cartridge from the drive.

6 POWER Switch

Press to turn the drive on or off.

1

243

1 Rotary Selector Switch

SCSI ID selector.

2 AC IN Connector

Connect the supplied power cable here.

3 SCSI Connector

Connects to the SCSI bus connector of the host computer or another
SCSI peripheral.

4 Cooling Fan

Part 1. Introduction 13

Part 2. Preparation

After you confirm that you have all of the required accessories for your
installation, connect the drive to the host computer, and select the SCSI ID
with the rotary switch on the rear panel.

Supplied Items

When you first open the box, make sure it contains the following items.
Contact your supplier if anything is missing or broken.

• AIT Drive Unit

• Power cable

• Operating Instructions/Device Driver (CD-ROM)

• Quick Start Guide

• TapeCopy (CD-ROM)

• Terminator

• AIT data cartridge

• Cleaning cartridge

• Application software (CD-ROM)

• Contact information

• Safety Regulations

• Warranty card

14 Part 2. Preparation

Interconnections

The SCSI bus allows connection of up to fifteen peripherals to the host
computer. Use a SCSI cable with a half pitch 68 pin connector.

Precautions

• Switch off the host computer and peripherals before connecting the SCSI
cable.

• Make sure the SCSI connectors are pressed tightly together.

• If this unit is the last (or only) device on the Wide SCSI bus, make sure to
connect a terminator to the appropriate unused Wide SCSI connector. Using
an incompatible terminator may damage the unit.

• With an Ultra Wide SCSI bus, the total length of the SCSI cable(s)
connecting the host computer and the last device on the SCSI bus should be
less than 12 meters (39 feet). (If a SCSI single-end host adapter is at the end
of the SCSI bus, use less than 1.5 meters of SCSI cable.)

*1

*1

The cables should be less than 1.5 meter, if connected to single-ended SCSI host adaptor.

SCSI ID Setting

The SCSI ID is set by the rotary switch on the rear panel. Press the + or ­buttons to move the number up or down, respectively.
As shipped from the factory, the SCSI ID is set to 5. Press the switch buttons,
if necessary, to select the SCSI ID number you require. Because the host
adapter ID is usually set to 7, select some other value for the SCSI ID setting.

Precautions

• The SCSI ID must be different from IDs of the other peripherals on the
SCSI bus.

• When shipped from the factory, SCSI parity is enabled and Term power is
ON. Be sure to connect a terminator to the SCSI bus before use.

• Before changing the SCSI ID setting, be sure to turn off the power with the
POWER switch on the front panel.

Terminator

AC power

Part 2. Preparation 15

Option Switches (DIP Switch)

Remove the two slotted screws by using a slotted screwdriver. Remove the
access cover to change the DIP switch settings. (Refer to the following
figure for details changing the DIP switch settings.)
After changing the DIP switch settings, replace access cover and tighten the
two slotted screws using a slotted screwdriver.

CAUTION

Before removing the access cover to change DIP switch settings on the
drive, turn off the computer and disconnect the power cord from the unit.
Once the DIP switch settings have been changed, replace the access cover
using the two original slotted screws provided.

DIP Switch

DIP Switch Positions

Default (AITe260, AITe130, AITe90)

ON
OFF

12345678

Default (AITe520, AITe390)

ON
OFF

12345678

Access Cover

Slotted
Screws

1 Drive Mode (OFF)
2 Drive Mode (OFF)
3 Drive Mode (OFF)
4 Drive Mode (OFF)
5

Terminator Power (ON)
6 Periodic Cleaning Req (OFF)
7 DC Control (1) (ON)

8 DC Control (2) (OFF)

1 DR (Disaster Recovery) Mode

(OFF)
2 Emulation Mode (OFF)
3 AIT Library Interface Mode (ON)
4 Reserved (OFF)
5 Terminator Power (ON)
6 Periodic Cleaning Req (OFF)
7 DC Control (1) (ON)

8 DC Control (2) (OFF)

16 Part 2. Preparation

DR (Disaster Recovery*) Mode

ON
OFF

12345678

AITe260, AITe130, AITe90

1 Drive Mode (ON)
2 Drive Mode
3 Drive Mode
4 Drive Mode
5

Terminator Power
6 Periodic Cleaning Req
7 DC Control (1)
8 DC Control (2)

AITe520, AITe390

1 DR (Disaster Recovery) Mode (ON)
2 Emulation Mode
3 AIT Library Interface Mode
4 Reserved
5 Terminator Power
6 Periodic Cleaning Req
7 DC Control (1)

8 DC Control (2)

* In Disaster Recovery (DR) Mode, the drive enters the DR Standby Mode 15

seconds after you insert a write-protected tape into the drive, and all the drive LED
blink. If you restart the drive while the LEDs are blinking, it starts as a CD-ROM
device.
For details about the Disaster Recovery Mode, refer to the instruction manual that
came with the application software you are using.

Emulation Mode*
AITe260, AITe130, AITe90

1 Drive Mode (ON)

ON
OFF

12345678

2 Drive Mode (ON)
3 Drive Mode (ON)
4 Drive Mode (ON)
5

Terminator Power
6 Periodic Cleaning Req
7 DC Control (1)

8 DC Control (2)

* Emulation Mode returns the following in the Product Identification field of Inquiry

of the AITe260.

SDX-700C

* Emulation Mode returns the following in the Product Identification field of Inquiry

of the AITe130.

SDX-500C

* Emulation Mode returns the following in the Product Identification field of Inquiry

of the AITe90.

SDX-400C

Part 2. Preparation 17

AITe520, AITe390

1 DR (Disaster Recovery) Mode

ON
OFF

12345678

2 Emulation Mode (ON)
3 AIT Library Interface Mode
4 Reserved
5 Terminator Power
6 Periodic Cleaning Req
7 DC Control (1)

8 DC Control (2)

* Emulation Mode returns the following in the Product Identification field of Inquiry

of the AITe520.

SDX-700C

* Emulation Mode returns the following in the Product Identification field of Inquiry

of the AITe390.

SDX-700C

Cleaning Request Mode

Periodic cleaning requests can be enabled by a DIP switch.

ON
OFF

12345678

AITe260, AITe130, AITe90

1 Drive Mode
2 Drive Mode
3 Drive Mode
4 Drive Mode
5

Terminator Power
6 Periodic Cleaning Req (ON)
7 DC Control (1)
8 DC Control (2)

AITe520, AITe390

1 DR (Disaster Recovery) Mode
2 Emulation Mode
3 AIT Library Interface Mode
4 Reserved
5 Terminator Power
6 Periodic Cleaning Req (ON)
7 DC Control (1)
8 DC Control (2)

When switch 6 is ON, cleaning requests are enabled. When enabled, the “CLEANING
REQUEST” LED on the front panel lights after every 100 hours of operation.
When this LED lights, clean the drive with a cleaning cartridge.

Note

To maintain the drive in optimum condition in environments affected by dust
and other contaminants, we recommend keeping cleaning requests enabled.

Terminator Power Control DIP switch

This DIP switch determines whether terminator power is supplied to the
SCSI bus. To enable terminator power, set position 5 [Terminator Power]
switch to ON.

Data Compression Control DIP Switch

Data compression can be selected by DIP switches. Data compression is
enabled when position 7 [DC Control (1)] is ON. Control by host can be
disabled when position 8 [DC Control (2)] is ON.

18 Part 2. Preparation

Part 3. Operation

This section describes how to use the AIT drive, and how to handle data
cartridges.

How to use the AIT Drive

1 Press the POWER switch on the front panel.

The POWER indicator should light, and the TAPE MOTION,
CLEANING REQUEST, and REPLACE TAPE indicators should blink
as the self-test is performed.

2 When the three indicators stop blinking, open the dust cover and insert a

data cartridge as shown below. The TAPE MOTION indicator lights.

3 Computer software controls the reading and writing of tapes. While

reading or writing, the TAPE MOTION indicator blinks.

4 Close the dust cover.

Part 3. Operation 19

Cartridge Removal

1 Press the EJECT button.

2 Open the dust cover.

The cartridge is ejected automatically.

Caution

Do not push the EJECT button while the TAPE MOTION indicator is
blinking. To do so may destroy data on the tape.

3 Remove the cartridge from the receptacle, and then close the dust cover.

20 Part 3. Operation

Attaching the Dust Cover

If the dust cover comes loose, attach it as described below.

Note

We recommend that you use the drive with the dust cover.

1 Align the dust cover’s hinge clips (one on each side) with the pins of the

drive bezel.

• The dust cover should be positioned so that the magnets* on the cover’s
back face the drive bezel.

*

This magnet does not affect the tape of the cartridge.

• Holding the dust cover at an angle as shown in the figure below, set the
hinge clips on top of the bezel pins, positioning them so that they
bracket the pins.

Part 3. Operation 21

2 Press down at an angle on each side in turn until you hear the hinge clips

click into place.

Caution

Do not press the dust cover in horizontally from the front. Doing so
could cause the dust cover to break.

3 Close the dust cover.

This completes attachment of the dust cover.

22 Part 3. Operation

WORM Function

The AITe520, AITe260 and AITe130 support the WORM function. This
explains the WORM function.

What is “WORM”?

“WORM” is an acronym for “Write Once Read Many”, a function that allows
data to be written to the same place on a tape only once, but permits that data
to be read from the tape for any number of times. The AITe520, AITe260
and AITe130 support WORM cartridges. When a WORM cartridge is used
with an application that supports the WORM function, data that has been
written to a tape can not be accidentally deleted or overwritten.
A WORM drive operates in the same manner as a non-WORM drive when
used with a non-WORM cartridge (henceforth referred to as “regular
cartridge”).
The operation of a WORM drive and a non-WORM drive differs according
to the type of cartridge that is being used.

Non-WORM drive Read/Write Enabled Waiting for Eject
WORM drive Read/Write Enabled Read/

Tape Drive Cartridge

Regular Cartridge WORM Cartridge
(without WORM logo) (with WORM logo)

Append-Write Enabled

WORM Cartridges

WORM cartridges can be distinguished from regular cartridges by their
WORM logo and red shutters.

Red

WORM logo

AIT-2 WORM cartridge: SDX2-50W
AIT-3 WORM cartridge: SDX3-100W
AIT-4 WORM cartridge: SDX4-200W

Part 3. Operation 23

How to Write Data onto a WORM Cartridge

As with a regular cartridge, there is no limit on how many times data can be
read from a WORM cartridge. When writing data to a WORM cartridge, the
data cannot be written to a portion of the tape that data has already been
written.
When writing data onto a WORM cartridge, it is appended after data that has
already been written onto the cartridge. Accordingly, you must move to the
EOD area before writing data onto the cartridge.

SCSI Commands Supported by the WORM Drive

The WORM drives support the same SCSI commands that are supported by
non-WORM drives. However, if an attempt is made to write to a portion of a
tape where data has already been written, the following error information is
returned: “Sense Key = 07, ASC = 27h, ASCQ = 00: Persistent Write
Protect” or “Sense Key = 03, ASC = 27h, ASCQ = 04: Write Position Error.”

Note

• Sony cannot accept liability for data written onto a WORM cartridge that is
lost as a result of using this unit.

• Sony accepts no responsibility for any financial damages, lost profits, or
claims made by third parties arising from the use of this product.

24 Part 3. Operation

Part 4. Care and Maintenance

Taking Care of the Drive

Safety Considerations

■ Power

• Be sure to use only 100-240 V AC.

• Avoid plugging into the same outlet as high-current equipment like copiers
or shredders.

■ Power Cable Precautions

• Do not crush the cable or place heavy items on it. If the cable insulation
appears worn or broken, do not use the cable.

• Always unplug the cable by holding the plug. Never pull the cable itself, as
it will break.

• If the drive is not being used for a long time, unplug the cable from the
outlet.

Avoiding Damage

■ Avoid shock and vibration

Intense shock, such as from dropping the drive, will damage it.

■ Environmental considerations

Do not store or use the drive in locations subject to:

• high humidity • excessive dust

• high temperature • intense vibration

• direct sunlight • sudden changes in temperature

■ Proper ventilation

To avoid overheating, install the drive where it will have free air circulation
around the case, and do not cover it during operation. The drive can
malfunction if the internal temperature rises too high.

Part 4. Care and Maintenance 25

■ Avoid sudden changes in temperature

If the drive is moved from a cool place to a warm place, or if the room
temperature suddenly rises, moisture may condense inside the case. After a
sudden change in temperature, turn off the drive and wait at least one hour
before turning it on again.
Inserting a cartridge with condensation inside the drive can damage the drive
or the tape. Immediately remove cartridges in the drive if there is a possibility
that there is condensation inside.
Leaving the drive on without inserting cartridges, moreover, will quickly
evaporate any condensation.

■ Abnormal occurrences

If the drive behaves abnormally, or if it begins to smell or smoke,
immediately unplug it from the wall outlet and contact your supplier for
assistance.

■ Cabinet cleaning

Wipe the cabinet with a soft dry cloth. For heavy dirt, wipe with a soft cloth
moistened with a gentle liquid soap, then wipe again with a soft dry cloth. Do
not use alcohol, paint thinner, bug sprays or other volatile solvents, as they
can damage the finish.

26 Part 4. Care and Maintenance

Taking Care of Cartridges

Use Precautions

• Avoid heavy vibration and dropping.

• The shutter on the face of the cartridge is opened automatically when it is
inserted into the drive. Do not open the shutter by hand, as touching the tape
may damage it.

• The cartridge was carefully aligned during assembly at the factory. Please
do not try to open it or take it apart.

• The write-protect switch on the face of the cartridge prevents the tape from
being written to or accidentally erased. If you do not need to write to the
tape, move this switch to the write-protect position (in the direction of the
arrow).

• In case of a sudden change in temperature, condensation may interfere with

• Avoid unnecessary insertion and removal of cartridges if you do not need to

• When finished using the drive, remove the cartridge.

Storage Precautions

• Keep cartridges in their cases when not in the drive.

• Avoid storing cartridges in dusty places, in direct sunlight, near heaters or

• Do not place cartridges on the dashboard or in a storage tray in a car.

AIT-1

AIT-2
AIT-3
AIT-3 Ex
AIT-4

Using your fingernail, push the switch in the
direction of the arrow to protect the tape
from writing or accidental erasure.

Return the switch to its original position to
re-enable writing.

reading and writing to a tape.

write or read a tape.

air conditioners, or in humid locations.

Part 4. Care and Maintenance 27

Cleaning

How to Clean

To keep the AIT drive in top condition, clean the drive unit as needed using a
cleaning cartridge with the AIT logo. When the drive unit needs cleaning, the
CLEANING REQUEST indicator lights. (For the AITe390 and the AITe520,
use the AITe390 and AITe520 cleaning cartridge respectively.)

Use the cleaning cartridge made exclusively for each model.

Cleaning cartridge to use

AITe520 SDX4-CL

AITe390 SDX3X-CL

AITe260, AITe130, AITe90 SDX1-CL

1 Load the cleaning cartridge into the AIT drive.

Cleaning starts automatically.

2 Cleaning takes about 15 seconds and the cartridge is automatically

ejected when finished. (AITe260, AITe130, AITe90)
Cleaning takes from a few seconds to a minute for the AITe520 and the
AITe390,*1 and the cartridge is automatically ejected when finished.

*1

The cleaning time varies depending on the condition of the drive (AITe520 and AITe390).

Notice

Do not rewind the cleaning cartridge and reuse it. When you reach the end of
the cartridge, dispose it and buy a new cleaning cartridge with the AIT logo.

28 Part 4. Care and Maintenance

Appendix

Specifications (AITe520)

■ Performance

Storage Capacity 520 GB compressed (with SDX4-200C)

Bit Error Rate less than 10
Data Transfer Rate 24 MB/s uncompressed
(TAPE) 62.4 MB/s compressed
Burst Data Transfer Rate 12 MB/s maximum, asynchronous
(SCSI) 160 MB/s maximum, synchronous
Initialize Time less than 5 seconds
Load Time average of 14 seconds
Unload Time average of 24 seconds
Rewind Time average of 115 seconds (with SDX4-200C)

■ Operating Environment

Operating Temperature: 10 to 35°C (∆T<10°C / h)

Non-operating Temperature: –40 to 70°C (∆T<20°C / h)

■ Power Supply & Miscellaneous

*1

200 GB uncompressed (with SDX4-200C)

-17

*1

*2

*2

*2

(50 to 95°F (∆T<18°F / h))

Humidity: 30 to 80% (no condensing)
Maximum wet bulb temperature: 26°C (78.8°F)

(–40 to 158°F (∆T<36°F / h))

Humidity: 10 to 90% (∆RH<30% / h) Maximum wet
bulb temperature: 45°C (113°F)

Power Supply 100 to 240 V AC, 50/60 Hz

1.2 A

Case Dimensions 198 × 64.5 × 246 mm (W × H × D)

(excluding protruding parts)
Weight 2.4 kg
Accessories AIT Drive Unit (1)

Power cable (1)

Operating Instructions/Device Driver

(CD-ROM) (1)

Quick Start Guide (1)

TapeCopy (CD-ROM) (1)

Terminator (1)

AIT data cartridge (1)

Cleaning cartridge (1)

Application software (CD-ROM) (1)

Contact information (1)

Safety Regulations (1)

Warranty card (1)

Specifications may be subject to change, in the interest of technological improvement,
without notice or obligation.

Appendix 29

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

*2

No retries.

Specifications (AITe390)

■ Performance

Storage Capacity 390 GB compressed (with SDX3X-150C)

Bit Error Rate less than 10
Data Transfer Rate 18 MB/s uncompressed
(TAPE) 46.8 MB/s compressed
Burst Data Transfer Rate 12 MB/s maximum, asynchronous
(SCSI) 160 MB/s maximum, synchronous
Initialize Time less than 5 seconds
Load Time average of 14 seconds
Unload Time average of 24 seconds
Rewind Time average of 115 seconds

■ Operating Environment

Operating Temperature: 10 to 35°C (∆T<10°C / h)

Non-operating Temperature: –40 to 70°C (∆T<20°C / h)

■ Power Supply & Miscellaneous

150 GB uncompressed (with SDX3X-150C)

-17

*1

*2

*2

(with SDX3X-150C)

*2

(50 to 95°F (∆T<18°F / h))

Humidity: 30 to 80% (no condensing)

Maximum wet bulb temperature: 26°C (78.8°F)

(–40 to 158°F (∆T<36°F / h))

Humidity: 10 to 90% (∆RH<30% / h)

Maximum wet bulb temperature: 45°C (113°F)

*1

30 Appendix

Power Supply 100 to 240 V AC, 50/60 Hz

1.2 A

Case Dimensions 198 × 64.5 × 246 mm (W × H × D)

(excluding protruding parts)
Weight 2.4 kg
Accessories AIT Drive Unit (1)

Power cable (1)

Operating Instructions/Device Driver

(CD-ROM) (1)

Quick Start Guide (1)

TapeCopy (CD-ROM) (1)

Terminator (1)

Specifications may be subject to change, in the interest of technological
improvement, without notice or obligation.

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

*2

No retries.

Specifications (AITe260)

■ Performance

AIT data cartridge (1)

Cleaning cartridge (1)

Application software (CD-ROM) (1)

Contact information (1)

Safety Regulations (1)

Warranty card (1)

Storage Capacity 260 GB compressed (with SDX3-100C)

Bit Error Rate less than 10
Data Transfer Rate 12 MB/s uncompressed
(TAPE) 31.2 MB/s compressed
Burst Data Transfer Rate 12 MB/s maximum, asynchronous
(SCSI) 160 MB/s maximum, synchronous
Initialize Time less than 5 seconds
Load Time average of 14 seconds
Unload Time average of 24 seconds
Rewind Time average of 105 seconds (with SDX3-100C)

■ Operating Environment

Operating Temperature: 10 to 35°C (∆T<10°C / h)

Non-operating Temperature: –40 to 70°C (∆T<20°C / h)

*1

100 GB uncompressed (with SDX3-100C)

-17

*1

*2

*2

*2

(50 to 95°F (∆T<18°F / h))

Humidity: 30 to 80% (no condensing)

Maximum wet bulb temperature: 26°C (78.8°F)

(–40 to 158°F (∆T<36°F / h))

Humidity: 10 to 90% (∆RH<30% / h)

Maximum wet bulb temperature: 45°C (113°F)

Appendix 31

■ Power Supply & Miscellaneous

Power Supply 100 to 240 V AC, 50/60 Hz

Case Dimensions 198 × 64.5 × 246 mm (W × H × D)

Weight 2.4 kg
Accessories AIT Drive Unit (1)

Specifications may be subject to change, in the interest of technological
improvement, without notice or obligation.

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

*2

No retries.

1.2 A

(excluding protruding parts)

Power cable (1)

Operating Instructions/Device Driver

(CD-ROM) (1)

Quick Start Guide (1)

TapeCopy (CD-ROM) (1)

Terminator (1)

AIT data cartridge (1)

Cleaning cartridge (1)

Application software (CD-ROM) (1)

Contact information (1)

Safety Regulations (1)

Warranty card (1)

Specifications (AITe130)

■ Performance

Storage Capacity 130 GB compressed (with SDX2-50C)

Bit Error Rate less than 10
Data Transfer Rate 6 MB/s uncompressed
(TAPE) 15.6 MB/s compressed
Burst Data Transfer Rate 12 MB/s maximum, asynchronous
(SCSI) 40 MB/s maximum, synchronous
Initialize Time less than 5 seconds
Load Time average of 14 seconds
Unload Time average of 20 seconds
Rewind Time average of 105 seconds (with SDX2-50C)

32 Appendix

*1

50 GB uncompressed (with SDX2-50C)

-17

*1

*2

*2

*2

■ Operating Environment

Operating Temperature: 10 to 35°C (∆T<10°C / h)

Non-operating Temperature: –40 to 70°C (∆T<20°C / h)

■ Power Supply & Miscellaneous

Power Supply 100 to 240 V AC, 50/60 Hz

Case Dimensions 198 × 64.5 × 246 mm (W × H × D)

Weight 2.4 kg
Accessories AIT Drive Unit (1)

(50 to 95°F (∆T<18°F / h))

Humidity: 30 to 80% (no condensing)

Maximum wet bulb temperature: 26°C

(78.8°F)

(–40 to 158°F (∆T<36°F / h))

Humidity: 10 to 90% (∆RH<30% / h)

Maximum wet bulb temperature: 45°C (113°F)

1.2 A

(excluding protruding parts)

Power cable (1)

Operating Instructions/Device Driver

(CD-ROM) (1)

Quick Start Guide (1)

TapeCopy (CD-ROM) (1)

Terminator (1)

AIT data cartridge (1)

Cleaning cartridge (1)

Application software (CD-ROM) (1)

Contact information (1)

Safety Regulations (1)

Warranty card (1)

Specifications may be subject to change, in the interest of technological
improvement, without notice or obligation.

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

*2

No retries.

Appendix 33

Specifications (AITe90)

■ Performance

Storage Capacity 91 GB compressed (with SDX1-35C)

Bit Error Rate less than 10
Data Transfer Rate 4 MB/s uncompressed
(TAPE) 10.4 MB/s compressed
Burst Data Transfer Rate 12 MB/s maximum, asynchronous
(SCSI) 40 MB/s maximum, synchronous
Initialize Time less than 5 seconds
Load Time average of 14 seconds
Unload Time average of 20 seconds
Rewind Time average of 105 seconds (with SDX1-35C)

■ Operating Environment

Operating Temperature: 10 to 35°C (∆T<10°C / h)

Non-operating Temperature: –40 to 70°C (∆T<20°C / h)

■ Power Supply & Miscellaneous

*1

35 GB uncompressed (with SDX1-35C)

-17

*1

*2

*2

*2

(50 to 95°F (∆T<18°F / h))

Humidity: 30 to 80% (no condensing)

Maximum wet bulb temperature: 26°C (78.8°F)

(–40 to 158°F (∆T<36°F / h))

Humidity: 10 to 90% (∆RH<30% / h)

Maximum wet bulb temperature: 45°C (113°F)

34 Appendix

Power Supply 100 to 240 V AC, 50/60 Hz

1.2 A

Case Dimensions 198 × 64.5 × 246 mm (W × H × D)

(excluding protruding parts)
Weight 2.4 kg
Accessories AIT Drive Unit (1)

Power cable (1)

Operating Instructions/Device Driver

(CD-ROM) (1)

Quick Start Guide (1)

TapeCopy (CD-ROM) (1)

Terminator (1)

AIT data cartridge (1)

Cleaning cartridge (1)

Application software (CD-ROM) (1)

Contact information (1)

Safety Regulations (1)

Warranty card (1)

Specifications may be subject to change, in the interest of technological
improvement, without notice or obligation.

*1

This is assuming 2.6:1 compression ratio.
The degree of data compression attained while recording data varies according to system
environment and data type.

*2

No retries.

Appendix 35

Sony Contacts

For further information, please contact:

Sony Electronics Inc., Tape Storage Solutions (USA)

URL: http://www.storagebysony.com

Sony of Canada Ltd., AV/IT Marketing Group
Computer Peripherals Product Marketing

115 Gordon Baker Road Toronto, Ontario, M2H 3R6 Canada
TEL: [phone] or (1) 800-961-7669
FAX: [phone]

Sony Business Europe

URL: http://www.sonyisstorage.com/

Electronics Devices Marketing (Singapore)
(A division company of Sony Electronics (S) Pte. Ltd.)
Enterprise Storage Solutions Dept.

2 International Business Park, #01-10 Tower One, The Strategy,
Singapore 609930

TEL: [phone] FAX: [phone]

Sony Corporation of Hong Kong Ltd.
Computer Peripheral Sales & Marketing Division
Electronic Devices Marketing Hong Kong

45/F, The Lee Gardens, 33 Hysan Avenue, Causeway Bay, Hong Kong
TEL: [phone] FAX: [phone]

Sony Corporation of Hong Kong Ltd. Beijing Rep. Office
Computer Peripheral Div.

Full Link Plaza Tower A 11/F., No.18 Chaoyangmenwai Ave., Beijing
100020 P.R.C.
TEL: [phone] FAX: [phone]
URL: http://www.sony.com.cn/ed/cp/ait/

Sony Corporation of Hong Kong Ltd.,
Electronic Devices Marketing Hong Kong
Computer Peripherals Sales & Marketing Div.

8/F, One Corporate Avenue, 222 Hu Bin Road. Luwan District,
Shanghai. P.R.C. Postcode 200021
TEL: [phone]
URL: http://www.sony.com.cn/ed/cp/ait/

Sony Brasil Ltda.

Rua Inocéncio Tobias, 125, Barra Funda
São Paulo-SP, Brasil 01144-000

TEL: [phone] FAX: [phone]
URL: http://www.sonybrasil.com.br

36 Appendix

Sony Australia Limited

33-39 Talavera Rd.
NORTH RYDE, NSW 2113
TEL: [phone] FAX: [phone]
e-mail: [e-mail]

Sony New Zealand

Akoranga Business Park
NORTH SHORE, AUCKLAND
TEL: [phone] FAX: [phone]
e-mail: [e-mail]

Sony Chile Ltda

Av. Kennedy 8017, Las Condes, Santiago, Chile
TEL: [phone] FAX: [phone]

Sony Taiwan Limited
Optical Devices Storage Dept. Data Storage Section

5F, 145 Changchun Road, Taipei 104, Taiwan
TEL: [phone] FAX: [phone]

Sony Korea Corporation EDMK CP Sales & Marketing Team

34F, ASEM Tower, World Trade Center, 159-1, Samsung-Dong,
Kangnam-Ku, Seoul, 135-798, Korea
TEL: [phone] FAX: [phone]
URL: http://www.sony.co.kr/cp/

Sony Gulf FZE Computer Display & Peripheral Div.

P.O.BOX 16871, Jebel Ali, Dubai, U.A.E.
TEL: [phone] or 8816912 FAX: [phone] or 8816259

Sony Marketing of Japan

Business Solution Dept. Server Solution Marketing Section
URL: http://www.sony.co.jp/STORAGE

Appendix 37
