LCD Digital Colour TV

Operating Instructions

KDL-52EX1

KDL-46EX1

KDL-40EX1

NOTICE FOR CUSTOMERS IN THE UNITED KINGDOM

A moulded plug complying with BS1363 is fitted to this equipment for your safety and convenience.

Should the fuse in the plug supplied need to be replaced with the same rating of fuse approved by ASTA or BSI to BS 1362 (i.e., marked with or ) must be used.

When an alternative type of plug is used it should be fitted with the same rating of fuse, otherwise the circuit should be protected by a 13 AMP FUSE at the distribution board.

If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

FUSE

How to replace the fuse

Open the fuse compartment with a blade screwdriver, and replace the fuse.

Please refer to the illustration that actually equipped with the product.

Introduction

Thank you for choosing this Sony product.

Before operating the TV, please read this manual thoroughly and retain it for future reference.

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.

2. TV wireless system can only be used in the following countries:

Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, The Netherlands, Norway, Poland, Portugal, Slovak Republic, Romania, Slovenia, Spain, Sweden, Switzerland, Turkey, and The United Kingdom.

When using the TV wireless system, channels 36 to 48 (5.15-

5.25GHz) are selectable for indoor use only.

Trademark information

s is a registered trademark of the DVB Project s Manufactured under license from Dolby Laboratories. Dolby

and the double-D symbol are trademarks of Dolby Laboratories.

s HDMI, the HDMI logo and High-Definition Multimedia

Interface are trademarks or registered trademarks of HDMI Licensing LLC.

s “BRAVIA” and are trademarks of Sony

Corporation.

s “XMB” and “xross media bar” are the trademarks of Sony

Corporation and Sony Computer Entertainment Inc.

Notice for Digital TV function

s Any functions related to Digital TV ( ) will only work in

countries or areas where DVB-T (MPEG-2 and H.264/MPEG-4 AVC) digital terrestrial signals are broadcast or where you have access to a compatible DVB-C (MPEG-2 and H.264/MPEG-4 AVC) cable service. Please confirm with your local dealer if you can receive a DVB-T signal where you live or ask your cable provider if their DVB-C cable service is suitable for integrated operation with this TV.

s The cable provider may charge an additional fee for such a

service and you may be required to agree to their terms and conditions of business.

s Although this TV set follows DVB-T and DVB-C

specifications, compatibility with future DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.

s Some Digital TV functions may not be available in some

countries/regions and DVB-C cable may not operate correctly with all providers.

s For more information about DVB-C functionality please see

our cable support site: http://support.sony-europe.com/TV/DVBC/

Notice for Wireless Signal

1. Hereby, Sony, declares that this unit is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

To obtain the declaration of conformity (DoC) for R&TTE Directive, please access the following URL address.

http://www.compliance.sony.de/

Table of Contents

Start-up Guide 4

Safety Information.......................................................................................................................... 12

Precautions..................................................................................................................................... 14

Remote and Unit Controls/Indicators........................................................................................... 15

Watching TV

Watching TV.................................................................................................................................... 20

Using the Digital Electronic Programme Guide (EPG) ..................................................... 22

Using the Digital Favourite list ........................................................................................... 23

Using Optional Equipment

Connecting Chart ........................................................................................................................... 24

Viewing Pictures from Connected Equipment............................................................................. 26

Using USB Photo Viewer ............................................................................................................... 27

Using BRAVIA Sync with Control for HDMI ................................................................................. 28

Using MENU Functions

Navigating through Media Receiver Home Menu (XMB™)......................................................... 29

Settings ........................................................................................................................................... 30

Navigating through Monitor Home Menu..................................................................................... 38

Additional Information

Installing the Accessories (Wall-Mount Bracket) ........................................................................ 44

Specifications ................................................................................................................................. 46

Troubleshooting ............................................................................................................................. 49

: for digital channels only

Before operating the TV, please read the “Safety information” section of this manual. Retain this manual for future reference.

Start-up Guide

1: Checking the unit and accessories

Monitor (1)

Media receiver (1)

Mains lead for monitor (1)

Mains lead for mains adaptor (1)

Mains adaptor for media receiver (1)

Mains lead holder (1)

Screws (PSW 4×8) (2)

2: Connecting an aerial/Set Top Box/recorder (e.g. DVD recorder) to the media receiver

Connecting a Set Top Box/recorder (e.g. DVD recorder) with SCART

Media receiver

Scart lead

Remote RMF-ED001W (1)

Size AA batteries (R6 type) (2)

IR Blaster (Y-cable) (2)

Stand for media receiver (1)

Set Top Box/recorder (e.g. DVD recorder)

Connecting a Set Top Box/recorder (e.g. DVD recorder) with HDMI

Media receiver

HDMI cable

Set Top Box/recorder (e.g. DVD recorder)

• You can also connect equipment to the HDMI input on the left side of the monitor.

3: Preventing the monitor from toppling over

Start-up Guide

1 Install a wood screw (4 mm in diameter,

not supplied) in the monitor stand.

2 Install a machine screw (M6 x 12-15, not

supplied) into the screw hole of the monitor.

3 Tie the wood screw and the machine

screw with a strong cord.

4: Connecting the mains

18V

lead

5: Performing the initial setup

• Make sure to secure the mains lead.

• To ensure compliance with current EMC legislation, ensure the following conditions are met.

• Fix the mains lead holder (supplied) after checking the mains lead is in the groove of the mains lead holder (supplied) to avoid scratching the mains lead.

Monitor

to mains socket

Screws (supplied)

Inserting batteries into the remote

Push and lift the cover to open.

• Observe the correct polarity when inserting batteries.

• Do not use different types of batteries together or mix old and new batteries.

• Dispose of batteries in an environmentally friendly way. Certain regions may regulate the disposal of batteries. Please consult your local authority.

• Handle the remote with care. Do not drop or step on it, or spill liquid of any kind onto it.

• Do not place the remote in a location near a heat source, a place subject to direct sunlight, or a damp room.

Establishing the wireless communication between the unit

• Keep about 30 cm to 20 m distance between the monitor and media receiver when installing.

• Keep clear the area between the monitor and

Mains lead holder (supplied)

Media receiver

to mains socket

media receiver. Otherwise the picture may deteriorate.

• Rearrange the installation position of the monitor and media receiver in case of fuzzy picture.

• Do not place either unit on a metallic rack.

• Do not use two units or more at the same time in an area of radio interference.

1 Press 1 to turn on the unit power.

POWER button

Media receiver

POWER button

COMPO-

NENTMONITOR

AV1 AV2

HDMI 2HDMI 1

HDMI

HDMI 3

DIGITAL/ ANALOG

THEATRE

SYNC MENU

AUDI O

Monitor

2 Check the LINK indicator on the media

receiver. If wireless communication between the media receiver and monitor is established, this indicator lights up.

• If the remote does not work, press F/f/G/g/ on the media receiver (page 18) to select the language.

2 Select “OK” then press .

Next, the Media Receiver Initial Set-up will start.

Please make sure the Media Receiver is on.

Start-up Guide

LINK indicator

LINK

Performing the initial set-up

EXT

1-10

3 Press F/f to select the country in which

you will operate the unit, then press .

Country

Select country

United Kingdom

Ireland

Nederland

België/Belgique

Luxembourg

France

Italia

If the country in which you want to use the unit does not appear in the list, select “-” instead of a country.

4 Press F/f to select the location type in

which you will operate the unit, then press

• Select “Home” for the best monitor settings to use the monitor in the home.

Location

Select location

Home

Shop

When you switch on the unit for the first time, the Language menu appears on the screen.

1 Press F/f/G /g to select the language

displayed on the menu screens, then press

Language

English

Nederlands

Français

Italiano

Deutsch

Türkçe

Español

Català

Português

Polski

Česky

Magyar

Русский

ББлгарски

Suomi

Dansk

Svenska

Norsk

Slovenčina

Română

5 Select “OK” then press .

Auto Tuning

Do you want to start Auto Tuning?

OK Cancel

(Continued)

6 Press F/f to select “Antenna” or “Cable”,

then press .

If you select “Cable”, the screen for selecting the scan type appears. See “To tune the unit for Cable connection” (page 8). The unit starts searching for all available digital channels, followed by all available analogue channels. This may take some time, so do not press any buttons on the unit or remote while proceeding.

If a message appears for you to confirm the aerial connection

No digital or analogue channels were found. Check all the aerial/cable connection and then press to start autotuning again.

7 When the “Programme Sorting” menu

appears on the screen, follow the steps of “Programme Sorting” (page 34).

If you do not change the order in which the analogue channels are stored on the unit, press RETURN to go to step 8.

Quick Start

Do you want to ena ble Quick Start?

TV turns on more quickly but standby power

consumption is increas ed.

Yes No

For details, see page 30.

Control for HDMI

Do you want to enable control for compatible

HDMI devices?

Choosing "Yes" will increase

standby power consumption.

Yes No

• When a digital broadcast channel cannot be received, or when selecting a country in which there are no digital broadcasts in step 3, the time must be set after performing step 7.

To tune the unit for Cable connection

1 Press . 2 Press F/f to select “Quick Scan” or “Full

Scan”, then press .

“Quick Scan” : channels are tuned according to the cable operator information within the broadcast signal. Recommended setting for “Frequency”, “Network ID” and “Symbol Rate” is “Auto.” This option is recommended for fast tuning when supported by your cable operator. If the “Quick Scan” does not tune, please use the “Full Scan” method below. “Full Scan” : All available channels are tuned and stored. This procedure may take some time. This option is recommended when “Quick Scan” is not supported by your cable provider. For further information about supported cable providers, refer to support web site: http://support.sony-europe.com/TV/ DVBC/

3 Press f to select “Start”, then press .

The unit starts searching for channels. Do not press any buttons on the unit or remote.

• Some cable providers do not support “Quick Scan.” If no channels are detected using “Quick Scan”, perform “Full Scan.”

For details, see page 28.

10 Press .

The unit has now tuned in all the available channels.

6: Operating optional equipment using the remote

Connecting IR Blaster to the optional equipment

Turn the power of the media receiver off before connecting the IR Blaster. Attach the IR Blaster near the remote sensor (IR) of the equipment.

Media receiver

IR BLASTER

4 Press F/f to select “IR Blaster Set-up”,

then press . The “IR Blaster Set-up” screen appears.

IR Blaster Set-up

Inputs Type Make Code

AV1

AV2

HDMI 1 HDMI 2 HDMI 3 Component

Blu-ray Disc

Sony

5 Press F/f to select “Inputs” to register the

remote, then select the following items:

Type: Connected equipment category. Make: Maker of the equipment. Code: IR code. Test: Tests the power of the equipment

currently being set. Make sure the power of the equipment turns on and off.

Start-up Guide

IR Blaster

Optional equipment

Performing the IR Blaster Set-up

By setting “IR Blaster Set-up”, this remote can control most Sony Blu-ray Disc players, DVD players, DVD recorders, and AV receivers, or those of other manufacturers. Follow the steps below to programme the remote.

1 Press HOME on the remote. 2 Press F/f to select “Settings”, then press

3 Press F/f to select “Media Receiver Set-

up”, then press .

If the equipment is not working, or some of the functions do not work

Enter the correct code or its alternatives (if available) shown in the list in step 5. Note that the list may not include codes for all models of all brands.

• Only Sony equipment is guaranteed to properly operate.

(Continued)

Using optional equipment

For details, refer to the operating instructions supplied with the connected equipment. Some buttons may not work depending on the connected equipment.

1 Press HDMI 1, HDMI 2, HDMI 3, AV1,

AV2 or COMPONENT.

2 Press EXT. 3 While the EXT button lights up, press \/1

to turn the equipment on, then operate the equipment using the following buttons.

HDMI 2HDMI 1

HDMI 3

EXT

COMPO-

AV1 AV2

DIGITAL/ ANALOG

2 5 8 0

NENTMONITOR

AUDIO

3 6 9

PROG

HDMI

SYNC MENU

THEATRE

1 4 7

Item Description

1 BD/DVD

operating buttons

• ./>: Goes to the

beginning of the previous/ next title/chapter/scene/ track.

• / : Replays the scene/ briefly fast forwards the scene.

• m/M: Fast reverses/fast forwards the disc when pressed during playback.

• N: Plays a disc at normal speed.

• X: Pauses the playback.

• x: Stops the playback.

2 F/f/G/g/3 Selects / confirms an item. 3 HOME Opens the menu. 4 DVD record

buttons

• z REC: Starts the recording.

• X REC PAUSE: Pauses the recording.

• x REC STOP: Stops the recording.

5 F1/F2 Selects a function when using

a combination unit (e.g. a DVD/HDD).

6 BD/DVD

7 BD/DVD

TOP MENU

Displays the BD/DVD disc menu.

Displays the top menu of the BD/DVD disc.

REC

TOP MENU

REC PAUSE REC STOP

BD/DVD

WIRELESS MENU

F1 F2

4 5

•The N button has a tactile dot. Use the tactile dot

as a reference when operating other equipment.

Detaching the Table-Top Stand from the Monitor

Disconnect the mains lead from the monitor before detaching the Table-Top Stand.

• Remove the screws guided by the arrow marks of the monitor. Do not remove the Table-Top Stand for any reason other than listed below. – To wall-mount the monitor.

Attaching the Stand for Media Receiver

The media receiver can also be used vertically with the supplied stand.

1 Match the lug on the centre of the stand

and the hole on the right side of the media receiver.

Start-up Guide

Do not remove the plastic cover on the Table-Top Stand.

Stand

Safety Information

Installation/Set-up

Install and use the TV set in accordance with the instructions below in order to avoid any risk of fire, electrical shock or damage and/or injuries.

Installation

s The TV set should be installed near an easily accessible mains

socket.

s Place the TV set on a stable, level surface. s Only qualified service personnel should carry out wall

installations.

s For safety reasons, it is strongly recommended that you use

Sony accessories, including: – Wall-mount bracket SU-WL500/SU-WL700

s Be sure to use the screws supplied with the Wall-mount bracket

when attaching the mounting hooks to the TV set. The supplied screws are designed so that they are 8 mm to 12 mm in length when measured from the attaching surface of the mounting hook. The diameter and length of the screws differ depending on the Wall-mount bracket model. Use of screws other than those supplied may result in internal damage to the TV set or cause it to fall, etc.

8mm – 12mm

Ventilation

s Never cover the ventilation holes or insert anything in the

cabinet.

s Leave space around the TV set as shown below. s It is strongly recommended that you use a Sony wall-mount

bracket in order to provide adequate air-circulation.

Monitor

Installed on the wall

30 cm

10 cm

Leave at least this space around the set.

Installed with stand

30 cm

10 cm

10 cm10 cm

10 cm

6 cm

Screw (supplied with the Wallmount bracket)

Mounting Hook Hook attachment on rear

of TV set

Transporting

s Before transporting the TV set,

disconnect all cables.

s Two or three people are needed to

transport a large TV set.

s When transporting the TV set by

hand, hold it as shown on the right. Do not put stress on the LCD panel and the frame around the screen.

s When lifting or moving the TV set,

hold it firmly from the bottom.

s When transporting the TV set, do n ot

subject it to jolts or excessive vibration.

s When transporting the TV set for

repairs or when moving, pack it using the original carton and packing material.

Be sure to hold the bottom of the panel, not the front part.

Leave at least this space around the set.

Media receiver

Installed horizontally

Top Front

8 cm 8 cm

Installed vertically

Top Front

6 cm 6 cm

s To ensure proper ventilation and prevent the collection of dirt

or dust: – Do not lay the TV set flat, install upside down, backwards,

or sideways. – Do not place the TV set on a shelf, rug, bed or in a closet. – Do not cover the TV set with a cloth, such as curtains, or

items such as newspapers, etc. – Do not install the TV set as shown below.

20 cm

10 cm

8 cm 8 cm

Leave at least this space around the set.

20 cm

10 cm

6 cm 6 cm

Leave at least this space around the set.

Air circulation is blocked.

Wall

Air circulation is blocked.

Wall

Mains lead

Handle the mains lead and socket as follows in order to avoid any risk of fire, electrical shock or damage and/or injuries:

– Connect the TV set using a three-wire grounding type mains

plug to a mains socket with a protective earthing connection. – Use only mains leads supplied by Sony, not other suppliers. – Insert the plug fully into the mains socket. – Operate the TV set on a 220-240 V AC supply only. – When wiring cables, be sure to unplug the mains lead for your

safety and take care not to catch your feet on the cables. – Disconnect the mains lead from the mains socket before

working on or moving the TV set. – Keep the mains lead away from heat sources. – Unplug the mains plug and clean it regularly. If the plug is

covered with dust and it picks up moisture, its insulation may

deteriorate, which could result in a fire.

Notes

s Do not use the supplied mains lead on any other equipment. s Do not pinch, bend, or twist the mains lead excessively. The

core conductors may be exposed or broken.

s Do not modify the mains lead. s Do not put anything heavy on the mains lead. s Do not pull on the mains lead itself when disconnecting the

mains lead.

s Do not connect too many appliances to the same mains socket. s Do not use a poor fitting mains socket.

Prohibited Usage

Do not install/use the TV set in locations, environments or situations such as those listed below, or the TV s et may malfunction and cause a fire, electrical shock, damage and/or injuries.

Location:

Outdoors (in direct sunlight), at the seashore, on a ship or other vessel, inside a vehicle, in medical institutions, unstable locations, near water, rain, moisture or smoke.

Environment:

Places that are hot, humid, or excessively dusty; where insects may enter; where it might be exposed to mechanical vibration, near flammable objects (candles, etc).

The TV set shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the TV.

Situation:

Do not use when your hands are wet, with the cabinet removed, or with attachments not recommended by the manufacturer. Disconnect the TV set from mains socket and aerial during lightning storms.

When not in use

s If you will not be using the TV set for several days, the TV set

should be disconnected from the mains for environmental and safety reasons.

s As the TV set is not disconnected from the mains when the TV

set is just turned off, pull the plug from the mains to disconnect the TV set completely.

s However, some TV sets may have features that require the TV

set to be left in standby to work correctly.

For children

s Do not allow children to climb on the TV set. s Keep small accessories out of the reach of children, so that they

are not mistakenly swallowed.

If the following problems occur...

Turn off the TV set and unplug the mains lead immediately if any

of the following problems occur.

Ask your dealer or Sony service centre to have it checked by qualified service personnel.

When:

– Mains lead is damaged. – Poor fitting of mains socket. – TV set is damaged by being dropped, hit or having something

thrown at it.

– Any liquid or solid object falls through openings in the cabinet.

NOTE ON MAINS ADAPTOR

Warning

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.

Do not install this equipment in a confined space, such as a bookshelf or similar unit.

s Please ensure that the mains socket is installed near the

equipment and shall be easily accessible.

s Be sure to use the supplied mains adaptor and mains lead. s Do not use any other mains adaptor. It may cause a malfunction. s Connect the mains adaptor to an easily accessible mains socket. s Do not coil the mains lead around

the mains adaptor. The core wire may be cut and/or it may cause a malfunction of the media receiver.

s Do not touch the mains adaptor

with wet hands.

s If you notice an abnormality in the

mains adaptor, disconnect it from the mains socket immediately.

s The set is not disconnected from the mains source as long as it

is connected to the mains socket, even if the set itself has been turned off.

Broken pieces:

s Do not throw anything at the TV set. The screen glass may

break by the impact and cause serious injury. s If the surface of the TV set cracks, do not touch it until you have

unplugged the mains lead. Otherwise electric shock may result.

Precautions

Viewing the TV

s View the TV in moderate light, as viewing the TV in poor light

or during long period of time, strains your eyes. s When using headphones, adjust the volume so as to avoid

excessive levels, as hearing damage may result.

LCD Screen

s Although the LCD screen is made with high-precision

technology and 99.99% or more of the pixels are effective,

black dots may appear or bright points of light (red, blue, or

green) may appear constantly on the LCD screen. This is a

structural property of the LCD screen and is not a malfunction. s Do not push or scratch the front filter, or place objects on top of

this TV set. The image may be uneven or the LCD screen may

be damaged. s If this TV set is used in a cold place, a smear may occur in the

picture or the picture may become dark. This does not indicate

a failure. These phenomena disappear as the temperature rises. s Ghosting may occur when still pictures are displayed

continuously. It may disappear after a few moments. s The screen and cabinet get warm when this TV set is in use.

This is not a malfunction. s The LCD screen contains a small amount of liquid crystal.

Some fluorescent tubes used in this TV set also contain

mercury. Follow your local ordinances and regulations for

disposal.

Handling and cleaning the screen surface/ cabinet of the TV set

Be sure to unplug the mains lead connected to the TV set from mains socket before cleaning.

To avoid material degradation or screen coating degradation, observe the following precautions.

s To remove dust from the screen surface/cabinet, wipe gently

with a soft cloth. If d ust is persistent, wipe with a soft cloth

slightly moistened with a diluted mild detergent solution. s Never use any type of abrasive pad, alkaline/acid cleaner,

scouring powder, or volatile solvent, such as alcohol, benzene,

thinner or insecticide. Using such materials or maintaining

prolonged contact with rubber or vinyl materials may result in

damage to the screen surface and cabinet material. s Periodic vacuuming of the ventila tion opening is recommended

to ensure to proper ventilation.

Optional Equipment

s Keep optional components or any equipment emitting

electromagnetic radiation away from the TV set. Otherwise

picture distortion and/or noisy sound may occur. s This equipment has been tested and found to comply with the

limits set out in the EMC Directive using a connection signal

cable shorter than 3 meters.

Wireless Function of the unit

s If wireless equipment using the same frequency (5GHz band) as

the unit is working near the unit, noise may appear in pictures

or sound, or no picture may result. Also, other wireless or radio

equipment may cause interference. Keep 5GHz band wireless

equipment, such as a wireless LAN or cordless phones, away

from the unit. s The picture may be influenced depending on the installation

environment or situation of the monitor and media receiver

(page 4). s As the media receiver and monitor communicate wirelessly,

pictures from the media receiver may deteriorate compared to

those from the equipment connected to the monitor with HDMI. s It may take time to transmit pictures depending on the types of

signal, fast motion, such as game pictures, etc. s If pictures from a PC or still images, such as EPG, are

displayed, flickering or blurring may occur. s This unit can be used only in combination with the supplied

monitor and media receiver.

RF Remote

s If wireless equipment using the same frequency (2.4GHz band)

as the unit is working near the unit, the remote may not operate properly. Also, microwave ovens or radio equipment may cause interference. Keep 2.4 GHz band wireless equipment away from the unit.

Disposal of the TV set

Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

This symbol on the product or on its packaging

as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

of correctly, you will help prevent potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment. For all other batteries, please view the section on how to remove the battery from the pr oduct safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

indicates that this product shall not be treated

Disposal of waste batteries (applicable in the European Union and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste. By ensuring these batteries are disposed

Remote and Unit Controls/Indicators

Remote

As the unit and the supplied remote communicate by radio frequency, you can operate the unit without aiming the remote at the unit.

HDMI

SYNC MENU

THEATRE

1 4 7

REC

BD/DVD

TOP MENU

WIRELESS MENU

HDMI 2HDMI 1

HDMI 3

AV1 AV2

DIGITAL/ ANALOG

2 5 8 0

PROG

REC PAUSE REC STOP

F1 F2

EXT

COMPO-

NENTMONITOR

AUDI O

3 6 9

1 2

3 4 5

6 7

Button Description

1 TV "/1

(TV standby)

Press to turn the unit on and off from standby mode.

2 EXT Press to operate equipment with the IR

Blaster attached, by the remote (page 10).

(Subtitle

Press to change the subtitle language (page 36) (in digital mode only).

setting)

4 AUDIO In analogue mode: Press to change the dual

sound mode (page 32). In digital mode: Press to change the language to be used for the programme currently being viewed (page 36).

5 /

(Info/Text reveal)

In digital mode: Displays details of the programme currently being viewed. In analogue mode: Displays information. Press once to display the current channel number and screen mode. Press again to display clock information. Press a third time to remove the display from the screen. In Text mode (page 21): Reveals hidden information (e.g. answers to a quiz).

6 /

(Input select/

Press to display a list of inputs (page 25). In Text mode: Press to hold the current page.

Text hold)

7 F/f/G/g/ Press F/f/G/g to move the on-screen cursor.

Press to select/confirm the highlighted item. When playing a photo file: Press to pause/start a slideshow. Press F/G to select the previous file. Press f/g to select the next file.

8 OPTIONS Press to display a list that contains “Device

Control”, or shortcuts to some setting menus. Use the “Device Control” menu to operate equipment that is compatible with control for HDMI. The listed options vary depending on the input source.

• The number 5, PROG +, AUDIO and buttons

have tactile dots. Use the tactile dots as references when operating the TV.

(Continued)

qk qj

HDMI

SYNC MENU

THEATRE

1 4 7

REC

BD/DVD

TOP MENU

WIRELESS MENU

HDMI 2HDMI 1

HDMI 3

AV1 AV2

DIGITAL/ ANALOG

2 5 8 0

PROG

REC PAUSE REC STOP

F1 F2

EXT

COMPO-

NENTMONITOR

AUDI O

3 6 9

Button Description

9 HOME Press to display the media receiver Home

menu in the media receiver mode (page 29), or monitor Home menu in the monitor mode (page 38).

0 Coloured

buttons

When the coloured buttons are available, an operation guide appears on the screen. Follow the operation guide to perform a selected operation (page 21, 22, 23).

qz Number

buttons

In TV mode: Press to select channels. For channel numbers 10 and above, press the second and third digits in quick succession. In Text mode: Press to enter a page number.

qs (Favourite) Press to display the digital favourite list that

qd PROG+/–/ / In TV mode: Press to select the next (+) or

you have specified (page 23).

previous (–) channel. In Text mode: Press to select the next or previous page.

qf (Previous

channel)

qg WIRELESS

qs qd

qh % (Mute) Press to mute the sound. Press again to

Press to return to the channel that was last viewed (for more than five seconds).

Press to display “Wireless Channel Set-up” (page 43).

restore the sound.

• In standby mode, if you want to turn on the monitor without sound, press this button.

qj 2/+/–

Press to adjust the volume.

(Volume)

qk / (Text) Press to display text information (page 21). ql RETURN / Press to return to the previous screen of the

displayed menu. When playing a photo file: Press to stop the playback. (The display returns to the file or folder list.)

w; GUIDE /

(EPG)

Press to display the Digital Electronic Programme Guide (EPG) (page 22).

wj wf wh

wg wd

ws wa

HDMI

SYNC MENU

THEATRE

1 4 7

REC

BD/DVD

TOP MENU

WIRELESS MENU

HDMI 2HDMI 1

HDMI 3

AV1 AV2

DIGITAL/ ANALOG

2 5 8 0

PROG

REC PAUSE REC STOP

F1 F2

EXT

COMPO-

NENTMONITOR

AUDI O

3 6 9

Button Description

wa ANALOG/

DIGITAL

Press to display the analogue or digital channel that was last viewed.

ws THEATRE You can set Theatre Mode to on or off. When

Theatre Mode is set to on, the optimum audio output (if the unit is connected with an audio system using an HDMI cable) and picture quality for film-based contents are automatically set.

• If you turn the unit off, Theatre Mode is also turned off.

• “Control for HDMI” (BRAVIA Sync) is only available with the connected Sony equipment that has the BRAVIA Sync or BRAVIA Theatre Sync logo or is compatible with control for HDMI.

wd SYNC MENU Displays the menu of connected HDMI

equipment. While viewing other input screens or TV programmes, “HDMI Device Selection” is displayed when the button is pressed.

• “Control for HDMI” (BRAVIA Sync) is only available with the connected Sony equipment that has the BRAVIA Sync logo or is compatible with control for HDMI.

Press to change the screen format (page 21).

(Screen mode)

wg Buttons for

using optional

You can operate the equipment connected to the unit (page 10).

equipment

wh HDMI1/2/3,

Press to select the input source.

MONITOR HDMI, AV1/2, COMPONENT

wj "/1 Press to turn equipment connected to the unit

on or off (page 10).

(Continued)

Media Receiver Buttons and Unit Indicators

43 5 67

7 6 8 9 0 q

Monitor

Media Receiver

PROG

LINK

Item Description

1 Remote control sensor Receives IR signals from the remote (if using an IR remote, not

supplied). Do not put anything over the sensor, as its function may be affected.

2 1 (Power) Turns the unit on or off.

HOME

PROG

• To disconnect the unit completely, pull the plug from the mains.

3 Light Sensor Do not put anything over the sensor, as its function may be affected. 4 (Timer indicator) Lights up in orange when the reminder is set (page 22) or the timer is set

(page 30).

Item Description

5 (Picture Off indicator) Lights up in green when the picture is switched off (page 43). 6 1 (Standby indicator) Lights up in red when the unit is in standby mode. 7 " (Power indicator) Lights up in green when the unit is turned on. 8 LINK indicator Lights up when the wireless connection between the media receiver and

monitor is stable.

HOME

9 (HOME) Displays the media receiver Home menu in the media receiver mode

0 / (Input select/OK) In monitor mode: Selects the input source from equipment connected to

qa 2 +/–/ / In monitor mode: Increases (+) or decreases (–) the volume.

qs PROG +/–/ / In TV mode: Selects the next (+) or previous (–) channel.

(page 29), or monitor Home menu in the monitor mode (page 38).

the unit sockets (page 24). In unit menu: Selects the menu or option, and confirms the setting.

In unit menu: Moves through the options right ( ) or left ( ).

In unit menu: Moves through the options up ( ) or down ( ).

• Make sure that the unit is completely turned off before unplugging the mains lead. Unplugging the mains lead while the unit is turned on may cause the indicator to remain lit or may cause the unit to malfunction.

• Do not put anything over the indicators as their functions may be affected.

• When the media receiver is used vertically with the stand attached, the qa and qs button functions (in the unit menu) are exchanged.

COMPO-

NENTMONITOR

AV1 AV2

HDMI 2HDMI 1

HDMI

HDMI 3

EXT

DIGITAL/ ANALOG

THEATRE

SYNC MENU

AUDI O

1 4 7

2 5 8 0

3 6 9

PROG

Watching TV

1 Press 1 on the media receiver or monitor

to switch on.

• When either unit is switched on, the other is also switched on in tandem.

When the unit is in standby mode (the 1 (standby) indicator on the unit (front) is red), press TV "/1 on the remote to switch on the unit.

2 Press DIGITAL/ANALOG to toggle

between digital mode and analogue mode.

The channels available vary depending on the mode.

3 Press the number buttons or PROG +/– to

select a TV channel.

To select channel numbers 10 and above using the number buttons, enter the second and third digits within two seconds. To select a digital channel using the Guide, see page 22.

In digital mode

An information banner appears briefly. The following icons may be indicated on the banner.

: Radio service : Scrambled/Subscription service : Multiple audio languages available : Subtitles available : Subtitles available for the hearing

impaired

: Recommended minimum age for current

programme (from 4 to 18 years)

: Parental Lock

Additional operations

To Do this

Turn on the monitor from standby mode without sound

Adjust the volume Press 2 + (increase)/

Press %. Press 2 +/– to set the volume level.

– (decrease).

To access Text

Press /. Each time you press /, the display changes cyclically as follows: Text t Text over the TV picture (mix mode) t No Text (exit the Text service) To select a page, press the number buttons or PROG +/–. To hold a page, press / . To reveal hidden information, press / .

• When four coloured items appear at the bottom of the Text page, Fastext is available. Fastext allows you to access pages quickly and easily. Press the corresponding coloured button to access the page.

To change the screen format manually

Press repeatedly to select the desired screen format.

Smart*

Displays conventional 4:3 broadcasts with an imitation wide screen effect. The 4:3 picture is stretched to fill the screen.

4:3

Displays conventional 4:3 broadcasts (e.g. non-wide screen TV) in the correct proportions.

Wide

Displays wide screen (16:9) broadcasts in the correct proportions.

• Some characters and/or letters at the top and the bottom of the picture may not be visible in “Smart” mode. In such a case, you can select “Vertical Size” using the “Screen Settings” (page 31) menu and adjust vertical size to make it visible.

• When “Auto Format” is set to “On”, the unit will automatically select the best mode to suit the broadcast (page 31).

• You can adjust the position of the picture when selecting “Smart”, “14:9” or “Zoom.” Press F/f to move up or down (e.g. to read subtitles).

Using the Options menu

Press OPTIONS to display the following options when viewing a TV programme.

Options Description

Picture Mode See page 39.

Sound Mode See page 41.

Speaker See page 32.

Motionflow See page 40.

Subtitle Setting (in digital mode only)

Sleep Timer See page 30.

Power Saving See page 43.

Use MONITOR HDMI

System Information (in digital mode only)

See page 36.

Switch to MONITOR HDMI input.

See page 37.

Watching TV

Zoom*

Displays cinemascopic (letter box format) broadcasts in the correct proportions.

14:9* (for media receiver inputs only)

Displays 14:9 broadcasts in the correct proportions. As a result, black border areas are visible on the screen.

* Parts of the top and bottom of the picture may be cut off.

Using the Digital Electronic Programme Guide (EPG) *

All Categories

Tod ay

001 BBC ONE

002 BBC TWO

003 ITV1

004 Channel 4

005 Five

006 ITV2

007 BBC THREE

008 BBC FOUR

009 ITV3

010 SKY THREE

Fri 16 Mar 11:35

Homes Under the Hammer Neighbours Afterlife

Ready Steady Cook Extraordinary People: Britains Iden... CSI: Crime Scene Inv...

Dancing On Ice Exclusive Cracker

Sign Zone: Ancient Rome: The Rise a... The Jeremy Kyle... Homes Under th...

House Law and Order: Special Victims U... PartyPoker.com Worl...

Crime Hour: Midsomer Murders Vodafone TBA: L...

BBC Learning Zone: Schools: World P... A Picture of Brit... Eastenders

ER Real Crime: The Truth About the... This is BBC FOUR

body Loves Raymond The Sharon Osb...

Past Every

Racing from Chepstow and Ascot Baseball Wedne... Trans World Sport

13: 0012: 3012: 0011: 30

Category30 min ViewNextPrevious

1 In digital mode, press GUIDE. 2 Perform the desired operation as shown in

the following table or displayed on the screen.

* This function may not be available in some countries.

To Do this

Watch a programme Press F/f/G/g to select the programme, then press .

Turn off the Guide Press GUIDE.

Sort the programme information by category – Category list

Set a programme to be displayed automatically on the screen when it starts – Reminder

1 Press the blue button. 2 Press F/f to select a category, then press .

1 Press F/f/G/g to select the future programme you want to

display, then press / .

2 Press F/f to select “Reminder”, then press .

A c symbol appears by that programme’s information. The

indicator on the monitor front panel lights up in orange.

• If you switch the monitor to standby mode, it will automatically turn itself on when the programme is about to start.

Cancel a reminder – Timer list

1 Press / . 2 Press F/f to select “Timer list”, then press . 3 Press F/f to select the programme you want to cancel, then

press .

4 Press F/f to select “Cancel Timer”, then press .

A display appears to confirm that you want to cancel the programme.

5 Press G/g to select “Yes”, then press to confirm.

• If an age restriction for programmes has been selected, a message asking for a PIN Code will appear on the screen. For details, see “Parental Lock” (page 36).

Using the Digital Favourite list *

Favourite Set-up

Favourites 1

001 BBC ONE

002 BBC TWO

003 ITV1

004 Channel 4

005 Five

006 BBC Three

007 ITV2

008 Sky Sports

009 UKTV History

010 Channel 4+1

Enter Programme Number: - - -

011 More 4

012 abc1

013 QVC

014 UKTV Gold

015 The HITS

016 UKTV Bright Ideas

017 ftn

018 TMF

019 E4

020 E4+1

Favourites 2NextPrevious

Digital

Digital Favourite list

* This function may not be available in some countries.

To Do this

Create your Favourite list for the first time

1 Press F/f/G/g to select the channel you want to add, then press

Channels that are stored in the Favourite list are indicated by a

symbol.

2 Press yellow key to select “Favourites 2” or “Favourites 3”.

Watch a channel

1 Press yellow key to navigate through favourite lists. 2 Press F/f to select the channel, then press .

Turn off the Favourite list Press RETURN.

Add or remove channels in the currently edited Favourite list

1 Press the blue button. 2 Press the yellow button to choose the list you want to edit. 3 Press F/f/G/g to select the channel you want to add or remove,

then press .

Remove all channels from the current Favourite list

1 Press the blue button. 2 Press the yellow button to select the favourite list you want to

edit.

3 Press the blue button. 4 Press G/g to select “Yes”, then press to confirm.

1 In digital mode, press . 2 Perform the desired operation as shown in

the following table or displayed on the screen.

Watching TV

Using Optional Equipment

9876

0 q

Connecting Chart

You can connect a wide range of optional equipment to your unit. Connecting cables are not supplied.

Media receiver

Monitor

Rear

Front

12 345

AV2

DC IN 18V

COMPONENT IN

LINK

LPR/CRPB/CBY

(RGB)

PC IN

AV1

32 1

HOME

IR BLASTER

DIGITAL AUDIO OUT (OPTICAL)

PROG

Left side

ONLY

SERVICE

MONITOR

Connect to Input symbol on

screen

1 / AV2 AV2 When connecting mono equipment, connect to the L

2 /

COMPONENT IN

3 / AV1 AV1 When you connect a decoder, the TV tuner outputs scrambled

DIGITAL AUDIO OUT (OPTICAL)

5 8 6 ! DC IN 18V Connects the supplied mains adaptor. 7 (RGB)/

PC IN

8 HDMI IN 1/2/3,

MONITOR HDMI IN

Component The component video sockets support the following video

PC It is recommended to use a PC cable with ferrites, such as the

HDMI 1/ HDMI 2/ HDMI 3/ Monitor

HDMI

Description

socket.

inputs only: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p.

signals to the decoder, and the decoder unscrambles the signals before outputting them.

Use an optical audio cable.

RF input that connects to your cable TV system or VHF/UHF.

“Connector, D-sub 15” (ref. 1-793-504-13, available in Sony Service Centre) or equivalent.

Digital video and audio signals are input from the connected equipment. In addition, when you connect the equipment that is compatible with control for HDMI, communication with the connected equipment is supported. Refer to page 33 to set up this communication.

• The HDMI sockets support the following video inputs only: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p and 1080/24p (1080/24p is for MONITOR HDMI only). For PC video inputs, see page 48.

• Be sure to use only an authorised HDMI cable bearing the HDMI logo.We recommend that you use a Sony HDMI cable (high speed type).

• For HDMI 1/2/3, when connecting an audio system that is compatible with control for HDMI, be sure to also connect it to the DIGITAL AUDIO OUT (OPTICAL) socket.

9 IR BLASTER Connects the supplied IR Blaster cables. 0 CAM

(Conditional Access Module)

To use Pay Per View services. For details, refer to the instruction manual supplied with your CAM. To use the CAM, remove the “dummy” card from the CAM slot, then turn off the monitor and insert your CAM card into the slot. When you are not using the CAM, we recommend that you keep the “dummy” card in the CAM slot.

• CAM is not supported in all countries. Please check with your authorised dealer.

• If the CAM card becomes jammed while inserting, try again. Do not insert forcefully.

qa i Headphones You can listen to monitor sound through headphones. qs USB You can enjoy photo files stored in a Sony digital still camera

or camcorder through a USB cable or USB storage device on your unit (page 27).

qd SERVICE ONLY For service use only.

Using Optional Equipment

Viewing Pictures from Connected Equipment

Switch on the connected equipment, then perform one of the following operation.

For equipment connected to the scart sockets using a fully-wired 21-pin scart lead

Start playback on the connected equipment. The picture from the connected equipment appears on the screen.

For an auto-tuned VCR/ DVD recorder

In analogue mode, press PROG +/–, or the number buttons, to select the video channel.

Option Description

Sleep Timer (except PC/HDMI PC input mode)

Power Saving See page 43.

Use MONITOR HDMI

Auto Adjustment (in PC/HDMI PC input mode only)

Horizontal Shift (in PC/HDMI PC input mode only)

Device Control (in HDMI input mode only)

See page 30.

Switch to MONITOR HDMI input.

See page 31.

See page 28.

For equipment connected to MONITOR HDMI socket

Press MONITOR HDMI.

For other connected equipment

Press / to display a list of connected equipment. Press F/f to select the desired input source, then press . The highlighted item is automatically selected if you do not perform any operation for two seconds after pressing F/f. If you have set an input source to “Skip” in the “AV Preset” menu (page 32), that input source does not appear in the list.

• To return to normal TV mode, press DIGITAL/ ANALOG.

Using the Options menu

Press OPTIONS to display the following options when viewing pictures from connected equipment.

When equipment is connected to the media receiver sockets

Option Description

Picture Mode (except PC/HDMI PC input mode)

Sound Mode See page 41.

Speaker See page 32.

Motionflow (except PC/HDMI PC input mode)

See page 39.

See page 40.

When equipment is connected to the MONITOR HDMI socket

Option Description

Picture Adjustment See page 39.

Sound See page 41.

Power Saving See page 43.

Motionflow (except HDMI PC input mode)

Horizontal Shift (in HDMI PC input mode only)

Vertical Shift (in HDMI PC input mode only)

Device Control See page 28.

HDMI Device Selection

Use Media Receiver Switch to media receiver

If wireless communication is not successful

Option Description

Wireless Channel Set-up

Use MONITOR HDMI

See page 40.

See page 42.

See page 17.

inputs.

See page 43.

Switch to MONITOR HDMI input.

Using USB Photo Viewer

You can enjoy photo files stored in a Sony digital still camera or camcorder through a USB cable or USB storage media on your unit.

1 Connect a supported USB device to the

media receiver.

2 Press HOME. 3 Press G/g to select “Photo”, then press F/

f to select “USB Photo Viewer” and press

The thumbnail screen appears.

4 Press F/f/G /g to select a file or folder,

then press .

When you select a folder, select a file, then press . Playback starts.

5 Press RETURN to go back to the

thumbnail screen.

Additional operations

Option Description

Device Selection Press G/g to select a

device when multiple devices are connected. BRAVIA images are predefined device.

Slideshow Displays the photographs

one by one.

Set-up You can make advanced

settings for a slide show, and set the display sequence of the thumbnails.

(Photo) Available Options

Option Description

Picture Mode See page 39.

Sleep Timer See page 30.

Power Saving See page 43.

• Picture quality may appear coarse when using (Photo) because images may be enlarged depending on the file. Also, images may not fill the entire screen depending on the image size and aspect ratio.

• Some photo files may take some time to be displayed when using (Photo).

• While the unit is accessing the data on the USB device, observe the following: – Do not turn off the unit or connected USB

device. – Do not disconnect the USB cable. – Do not remove the USB device. The data on the USB device may be damaged.

• Sony will not be held liable for any damage to, or loss of, data on the recording media due to a malfunction of any connected devices or the unit.

• USB photo viewer supports DCF-compliant JPEG photographs only.

• When you connect a Sony digital still camera, set the camera’s USB connection mode to Auto or “Mass Storage.” For more information about USB connection mode, refer to the instructions supplied with your digital camera.

• USB Photo Viewer supports FAT32 file system only.

• Depending on the exact file specifications, some files, including those modified on a PC, cannot be played even if the file format is supported.

• Check the website below for updated information about compatible USB devices. http://support.sony-europe.com/TV/compatibility/

To display a photograph — Picture Frame

You can display a photograph on the screen for a selected period of time. After that period, the unit automatically switches itself into standby mode.

1 Press HOME. 2 Press G/g to select “Photo”, then press F/

f to select “Picture Frame” and press .

To select a photograph

Press OPTIONS, then select “Image Selection” and press . Then, select a photograph, and press to set.

To set the duration of displaying a photograph

Press OPTIONS, then select “Duration” and press . Then, select the duration, and press . The counter appears on the screen.

To return to the XMB™

Press RETURN.

• If the photograph is selected from a USB device, it must remain connected to the unit.

• If “Sleep Timer” is activated, the unit automatically will switch into standby mode.

Using Optional Equipment

Using BRAVIA Sync with Control for HDMI

The control for HDMI function enables the unit to communicate with the connected equipment that is compatible with the function, using HDMI CEC (Consumer Electronics Control). For example, by connecting Sony equipment that is compatible with control for HDMI (with HDMI cables), you can control them together. Be sure to connect the equipment correctly, and make the necessary settings.

Control for HDMI

• Automatically turns the connected equipment off when you switch the unit to standby mode using the remote.

• Automatically turns the unit on and switches the input to the connected equipment when the equipment starts to play.

• If you turn on a connected audio system while the unit is on, the sound output switches from the monitor speaker to the audio system.*

• Adjusts the volume (2 +/–) and mutes the sound (%) of a connected audio system.*

• You can operate the connected Sony equipment that has the BRAVIA Sync logo by the supplied remote by pressing:

– N/x/X/m/M to operate the connected

equipment directly.

– SYNC MENU to display the menu of the connected

HDMI equipment on the screen. After displaying the menu, you can operate the menu screen by using F/f/G/g and .

– OPTIONS to display “Device Control”, then select

options from “Menu”, “Options”, and “Content List” to operate the equipment.

– Refer to the instruction manual of the equipment for

available control.

To make the control for HDMI settings

The control for HDMI settings must be set on both the unit side and connected equipment side. See “HDMI Set-up” on page 33 for the unit side settings. For settings on the connected equipment, refer to the operating instructions for that equipment.

* Function only available when connected to HDMI 1/2/3.

To connect the equipment that is compatible with control for HDMI

Connect the compatible equipment and the unit with an HDMI cable. When connecting an audio system*, be sure to also connect the DIGITAL AUDIO OUT (OPTICAL) socket of the media receiver and the audio system using an optical audio cable. For details, see page 25.

Using MENU Functions

Navigating through Media Receiver Home Menu (XMB™)

For setting the menu of the media receiver, switch to the media receiver mode by pressing one of the function buttons (page 10). The XMB™ (XrossMediaBar) is a menu of BRAVIA features and input sources displayed on the monitor screen. The XMB™ is an easy way to select programming and adjust settings on your media receiver.

1 Press HOME.

The media receiver Home menu appears on the screen.


Sound

Settings

Features

Media Receiver Set-up

Monitor

Set-up

Analogue Set-up

Category Object Bar

2 Press G/g to select the category.

Media category icon Description

Settings You can make advanced settings and adjustments. For details about

settings, see page 30.

Photo You can enjoy photo files via USB devices (page 27).

Digital You can select a digital channel, Favourite list (page 23), or Guide

Analogue You can select an analogue channel.

External Inputs You can select equipment connected to the media receiver.

(page 22). You can also select a channel using the number buttons or PROG +/–.

You can also select a channel using the number buttons or PROG +/–. To hide the list of analogue channels, set “Programme List Display” to “Off” (page 33).

To assign a label to an external input, see “AV Preset” (page 32).

Media Category Bar

Using MENU Functions

3 Press F/f to select the item, then press .

4 Follow the instructions on the screen.

5 Press HOME to exit.

• The options you can adjust vary depending on the situation.

• Unavailable options are greyed out or not displayed.

Settings


See the “Picture” setting for monitor (page 39).

Sound

See the “Sound” setting for monitor (page 41).

Features

Quick Start The unit turns on faster than usual within two hours after switching to standby

Timer Settings Sets the timer to turn on/off the unit.

mode. However, power consumption in standby mode is 38 watt higher than usual.

Sleep Timer Sets a period of time after which the unit automatically

On Timer Settings

Clock Set Allows you to adjust the clock manually. When the unit is

switches itself into standby mode. When the “Sleep Timer” is activated, the (Timer) indicator on the monitor (front panel) lights up in orange.

• If you turn off the unit and turn it on again or switch to the monitor mode from the media receiver mode, “Sleep Timer” is reset to “Off.”

• A notification message appears on the screen one minute before the unit switches to standby mode.

On Timer Sets the timer to turn on the unit from

standby mode.

Timer Mode Sets the desired day(s) of the week you

want the timer to turn on the unit.

Time Sets the time to turn on the unit.

Duration Sets how long you want the unit to stay

on before switching to standby mode again.

• If you switch to the monitor mode from the media receiver mode, “Duration” is cancelled.

receiving digital channels, the clock cannot be adjusted manually since it is set to the time code of the broadcasted signal.

Media Receiver Set-up

Auto Start-up Starts the “first time operation menu” to select the language, country and location,

Screen Settings Screen Format See “To change the screen format manually” on page 21.

PC Settings Screen Format Selects a screen format for displaying input from your PC.

and tune in all available digital and analogue channels. Usually, you do not need to do this operation because the language and country will have been selected and channels already tuned when the unit was first installed (page 7). However, this option allows you to repeat the process (e.g., to retune the unit after moving house, or to search for new channels that have been launched by broadcasters).

Auto Format Automatically changes the screen format according to the

Display Area Adjusts the picture display area in 1080i/p and 720p sources

Horizontal Shift Adjusts the horizontal position of the picture. Vertical Shift Adjusts the vertical position of the picture when “Screen

Vertical Size Adjusts the vertical size of the picture when “Screen Format”

Reset Resets the PC screen settings to the factory settings. Auto Adjustment Automatically adjusts the display position, phase and pitch of

Phase Adjusts the phase when the screen flickers. Pitch Adjusts the pitch when the picture has unwanted vertical

Horizontal Shift Adjusts the horizontal position of the picture. Power

Management

input signal. To keep your setting, select “Off.”

when “Screen Format” is set to “Wide.” Auto During digital broadcasts, displays

pictures in accordance with the settings recommended by the broadcast station.

Full Pixel Displays pictures in their original size.

Normal Displays pictures in their recommended

size.

Format” is set to “Smart”, “Zoom” or “14:9.”

is set to “Smart”, “Zoom” or “14:9.”

Full 1 Enlarges the picture to fill the vertical

display area, keeping its original horizontal-to-vertical aspect ratio.

Full 2 Enlarges the picture to fill the display

area.

the picture when the unit receives an input signal from the connected PC.

• “Auto Adjustment” may not work well with certain input signals. In such cases, manually adjust “Phase”, “Pitch” and “Horizontal Shift.”

stripes.

Switches the unit to standby mode if no signal is received for 30 seconds in the PC input.

Using MENU Functions

(Continued)

AV Set-up AV Preset Assigns a name to any equipment connected to the media

receiver. The name will be displayed briefly on the screen when the equipment is selected. You can skip an input source that is not connected to any equipment.

1 Press F/f to select the desired input source, then press

2 Press F/f to select the desired option below, then press

-, CABLE, SAT,

VCR, DVD/BD, GAME, AUDIO SYSTEM, CAM, PC

Edit: Creates your own label.

Uses one of the preset labels to assign a name to connected equipment.

1 Press F/f to select the desired letter

or number (“_” for a blank space), then press g.

If you input a wrong character

Press G/g to select the wrong character. Then, press F/f to select the correct character.

2 Repeat the procedure in step 1 until

the name is completed.

3 Select “OK”, then press .

Skip Skips an input source that is not

connected to any equipment when you press F/f to select the input source.

Speaker Turns on/off the monitor’s internal speakers.

TV Speaker The monitor speakers are turned on in

order to listen to the TV’s sound through the monitor speakers.

Audio System The monitor speakers are turned off in

order to listen to the TV’s sound only through your external audio equipment connected to the audio output sockets. When connected with “Control for HDMI” compatible equipment, you can turn the connected equipment on interlocked with the monitor. This setting must be made after connecting the equipment.

Dual Sound Selects the sound from the speaker for a stereo or bilingual broadcast.

Stereo/Mono For a stereo broadcast.

A/B/Mono For a bilingual broadcast, select “A” for sound channel 1, “B”

• If you select other equipment connected to the unit, set “Dual Sound” to “Stereo”, “A” or “B.”

IR Blaster Set-up See page 9 for the “IR Blaster Set-up” setting.

for sound channel 2, or “Mono” for a mono channel, if available.

HDMI Set-up This is used to set the “Control for HDMI” compatible equipment connected to the

HDMI sockets. Note that the interlock setting must also be made on the connected “Control for HDMI” compatible equipment side.

Control for HDMI This sets whether to interlock the “Control for HDMI”

compatible equipment and the unit. When set to “On”, the following menu items can be performed. However, power consumption in standby mode is higher than usual. If the specific Sony equipment that is compatible with “Control for HDMI” is connected, this setting is applied to the connected equipment automatically when the “Control for HDMI” is set to “On” using the unit.

Auto Devices Off When this is set to “On”, the “Control for HDMI” compatible

equipment turns off when you switch the unit to standby mode using the remote.

Auto TV On When this is set to “On” and if the connected HDMI control

compatible equipment is turned on, the unit automatically turns on, and the displays the HDMI input from the connected equipment.

Device List Update

HDMI Device List Displays the connected “Control for HDMI” compatible

Product Information Displays your media receiver’s product information.

Select “Monitor Product Information” to display your monitor’s product information.

All Reset Resets all settings to the factory settings and then displays the “Auto Start-up”

screen.

• Be sure not to turn the unit off during this period (it takes about 30 seconds) or press any buttons.

• All settings, including digital favourite list, country, language, auto tuned channels, etc. will be reset.

Creates or updates the “HDMI Device List.” Up to 14 “Control for HDMI” compatible equipment can be connected, and up to 4 equipment can be connected to a single socket. Be sure to update the “HDMI Device List” when you change the “Control for HDMI” compatible equipment connections or settings. Select them manually one by one until getting a correct picture for several seconds.

equipment.

Using MENU Functions

Monitor Set-up

See the “Monitor Set-up” setting for monitor (page 43).

Analogue Set-up

Programme List Display

Auto Tuning Tunes in all the available analogue channels.

Select “Off” to hide the list of analogue channels from the XMB™ (XrossMediaBar).

This option allows you to retune the unit after moving house, or to search for new channels that have been launched by broadcasters.

(Continued)

Programme Sorting Changes the order in which the analogue channels are stored on the unit.

1 Press F/f to select the channel you want to move to a new position, then press

2 Press F/f to select the new position for your channel, then press .

Manual Programme Preset

Before selecting “Label/AFT/Audio Filter/LNA/Skip”, press PROG +/– to select the programme number with the channel. You cannot select a programme number that is set to “Skip” (page 32).

Programme/ System/Channel

Presets programme channels manually.

1 Press F/f to select “Programme”, then press . 2 Press F/f to select the programme number you want to

manually tune (if tuning a VCR/ DVD recorder, select channel 00), then press RETURN.

3 Press F/f to select “System”, then press . 4 Press F/f to select one of the following TV broadcast

systems, then press RETURN.

B/G: For western European countries I: For the United Kingdom D/K: For eastern European countries L: For France

5 Press F/f to select “Channel”, then press . 6 Press F/f to select “S” (for cable channels) or “C” (for

terrestrial channels), then press g.

7 Tune the channels as follows:

If you do not know the channel number (frequency)

Press F/f to search for the next available channel. When a channel has been found, the search will stop. To continue searching, press F/f.

If you know the channel number (frequency)

Press the number buttons to enter the channel number of the broadcast you want or your VCR/DVD recorder channel number.

8 Press to jump to “Confirm”, then press . 9 Press f to select “OK”, then press .

Repeat the procedure above to preset other channels manually.

Label Assigns a name of your choice, up to five letters or numbers,

AFT Allows you to fine-tune the selected programme number

to the selected channel. This name will be displayed briefly on the screen when the channel is selected. To input characters, follow steps 1 to 3 of “Edit:” (page 32).

manually if you feel that a slight tuning adjustment will improve the picture quality. You can adjust the fine tuning over a range of –15 to +15. When “On” is selected, the fine tuning is performed automatically.

Audio Filter Improves the sound for individual channels in the case of

distortion in mono broadcasts. Sometimes a non-standard broadcast signal can cause sound distortion or intermittent sound muting when watching mono programmes. If you do not experience any sound distortion, we recommend that you leave this option set to the factory setting “Off.”

• You cannot receive stereo or dual sound when “Low” or “High” is selected.

LNA Improves the picture quality for individual channels in the

case of very weak broadcast signals (noisy picture). If you cannot see any improvement in the picture quality even if you set to “On”, set this option to “Off” (factory setting).

Skip Skips unused analogue channels when you press PROG +/–

Confirm Saves changes made to the “Manual Programme Preset”

to select channels. (You can still select a skipped channel using the number buttons.)

settings.

Digital Set-up

Digital Tuning Digital Auto

Tuning

Programme Sorting

Digital Manual Tuning

Using MENU Functions

Tunes in the available digital channels. This option allows you to retune the unit after moving house, or to search for new channels that have been launched by broadcasters. For details, see step 6 of “Performing the initial set-up” (page 8).

Removes any unwanted digital channels stored on the unit, and changes the order of the digital channels stored on the unit.

1 Press F/f to select the channel you want to remove or

move to a new position.

You can also select a channel by pressing the number buttons to enter its three-digit channel number.

2 Remove or change the order of the digital channels as

follows:

To remove the digital channel

Press . After a confirmation message appears, press G to select “Yes”, then press .

To change the order of the digital channels

Press g, then press F/f to select the new position for the channel and press G.

3 Press RETURN.

Tunes the digital channels manually. This feature is available when “Digital Auto Tuning” is set to “Antenna.”

1 Press the number button to select the channel number

you want to manually tune, then press F/f to tune the channel.

2 When the available channels are found, press F/f to

select the channel you want to store, then press .

3 Press F/f to select the programme number where you

want to store the new channel, then press .

Repeat the above procedure to manually tune other channels.

(Continued)

Subtitle Set-up Subtitle Setting When “For Hard Of Hearing” is selected, some visual aids

may also be displayed with the subtitles (if TV channels broadcast such information).

Subtitle Language

Audio Set-up Audio Type Switches to broadcast for the hearing impaired when “For

Audio Language Selects the language used for a programme. Some digital

Audio Description

Mixing Level* Adjusts the unit main audio and Audio Description output

Dynamic Range Compensates for differences in the audio level between

Optical Out Selects the audio signal that is output from the DIGITAL

* This option is only available when “Audio Description” is set to “On.”

Radio Display Displays the screen wallpaper when you listen to a radio broadcast after 20 seconds

without pressing any buttons. You can select the screen wallpaper colour, display a random colour or view a slide show (page 27). To cancel the screen wallpaper display temporarily, press any button.

Parental Lock Sets an age restriction for programmes. Any programme that exceeds the age

restriction can only be watched after a PIN Code is entered correctly.

Allows you to select the language of the subtitles.

Hard Of Hearing” is selected.

channels may broadcast several audio languages for a programme.

Provides audio description (narration) of visual information if TV channels broadcast such information.

levels.

different channels. Note that this function may have no effect for some channels.

AUDIO OUT (OPTICAL) terminal on the rear of the media receiver. Set to “Auto” when equipment compatible with Dolby Digital is connected, and set to “PCM” when noncompatible equipment is connected.

1 Press the number buttons to enter your existing PIN Code.

If you have not previously set a PIN, a PIN Code entry screen appears. Follow the instructions of “PIN Code” below.

2 Press F/f to select the age restriction or “None” (for unrestricted watching),

then press .

3 Press RETURN.

PIN Code To set your PIN for the first time

1 Press the number buttons to enter the new PIN Code. 2 Press RETURN.

To change your PIN

1 Press the number buttons to enter your existing PIN Code. 2 Press the number buttons to enter the new PIN Code. 3 Press RETURN.

• PIN Code 9999 is always accepted.

Technical Set-up Auto Service

Update

Enables the unit to detect and store new digital services as they become available.

• For the service update to be able to take place the unit should be left in standby mode from time to time.

Software Download

Enables the unit to automatically receive software updates free through your existing aerial/cable (when issued). We recommend that you leave the setting to “On” at all times. If you do not want your software to be updated, set this option to “Off.”

• For the software upgrade to be able to take place the unit should be left in standby mode from time to time.

System Information

Displays the current software version and the signal level.

• If signal bar is red (no signal) or amber (low signal), check the aerial/cable connection.

Time Zone Allows you to manually select the time zone you are in, if it is

Auto DST Sets whether or not to automatically switch between summer

CA Module Set-up Allows you to access a pay TV service once you obtain a Conditional Access

Module (CAM) and a view card. See page 25 for the location of the (PCMCIA) socket.

not the same as the default time zone setting for your country.

time and winter time. On Automatically switches between summer

time and winter time according to the calendar.

Off The time is displayed according to the

time difference set by “Time Zone.”

Using MENU Functions

Navigating through Monitor Home Menu

For setting the menu of the monitor, switch to the monitor mode by pressing MONITOR HDMI on the remote.

1 Press HOME.

The monitor Home menu appears on the screen.

Monitor Menu


Sound

Screen

HDMI Set-up

Monitor Set-up

PC Settings

2 Press F/f to select the item, then press .

3 Follow the instructions on the screen.

4 Press HOME to exit.

• The options you can adjust vary depending on the situation.

• Unavailable options are greyed out or not displayed.


Picture Adjustment Picture Mode Selects the picture mode except for PC input source. “Picture

Reset Resets all picture settings except “Picture Mode” to the

Backlight Adjusts the brightness of the backlight.

Contrast Increases or decreases picture contrast. Brightness Brightens or darkens the picture.

Colour Increases or decreases colour intensity. Hue Increases or decreases the green and red tones.

Colour Temperature

Sharpness Sharpens or softens the picture.

Mode” includes options best suited for video and photographs, respectively. The options that can be selected differ depending on the input source.

Vivid For enhanced picture contrast and

sharpness.

Standard For standard picture. Recommended for

home entertainment.

Cinema For viewing film-based content. Most

suitable for viewing in a theatre-like environment.

Custom Allows you to store your preferred

settings.

Photo-Vivid For viewing photographs. Enhances

picture contrast and sharpness.

Photo-Standard For viewing photographs. Provides the

optimum picture quality for viewing in the home.

Photo-Original For viewing photographs. Represents the

picture quality used when imaging developed photographs.

Photo-Custom Allows you to store your preferred

settings.

factory settings.

• “Hue” can only be adjusted for an NTSC colour signal (e.g., U.S.A. video tapes).

Adjusts the whiteness of the picture.

Cool Gives the white colours a blue tint. Neutral Gives the white colours a neutral tint.

Warm 1/Warm 2 Gives white colours a red tint. “Warm 2”

gives a redder tint than “Warm 1.”

• “Warm 1” and “Warm 2” are not available when “Picture Mode” is set to “Vivid” (or “Photo-Vivid”).

Using MENU Functions

(Continued)

Noise Reduction Reduces the picture noise (snowy picture) in a weak

broadcast signal.

MPEG Noise Reduction

Advanced Settings

Auto Automatically reduces the picture noise

High/Medium/ Low

Off Turns off the “Noise Reduction” feature.

Reduces picture noise in MPEG-compressed videos. This is effective when viewing a DVD or digital broadcast.

Allows you to set “Picture” settings in more detail. These settings are not available when “Picture Mode” is set to “Vivid” (or “Photo-Vivid”).

Reset Resets all the advanced settings to the

Black Corrector Enhances black areas of the picture for

Adv. Contrast Enhancer

Gamma Adjusts the balance between light and

Clear White Emphasises white and light colours. Colour Space Changes the colour reproduction gamut.

Live Colour Makes colours more vivid. White Balance Adjusts the colour temperature in detail.

(in analogue mode only).

Modifies the effect of the noise reduction.

factory settings.

stronger contrast.

Automatically adjusts “Backlight” and “Contrast” to the most suitable settings judging from the brightness of the screen. This setting is especially effective for dark images scenes. It will increase the contrast distinction of the darker picture scenes.

dark areas of the picture.

“Wide” reproduces the vivid colour and “Standard” reproduces the standard colour.

• “Live Colour” is not available when “Colour Space” is set to “Standard.”

Motionflow Provides smoother picture movement and reduces picture blur.

High Provides smoother picture movement such as for film-based

Standard Provides smooth picture movement. Use this setting for

Off Use this setting when the “High” and “Standard” settings

contents.

standard use.

result in noise.

• Depending on the video, you may not see the effect visually, even if you have changed the setting.

Film Mode Provides an improved picture quality which is optimised for film when playing

DVD images taken on film. Auto 1/Auto 2 “Auto 1” provides smoother picture movement than the

original film-based content. “Auto 2” provides the original film-based content as is.

Off Turns off the “Film Mode” feature.

• If the image contains irregular signals or too much noise, “Film Mode” will be automatically turned off even if “Auto 1/Auto 2” is selected.

• “Film Mode” is not available when “Video/Photo” is set to “Photo” or when photograph is detected if “Video-A” is set.

Game Mode Provides the optimum screen for viewing images with fine lines and characters that

are input from video game equipment and PCs. Set to “On” for the sharp display of fine lines or characters.

Video/Photo Provides suitable image quality by selecting the option depending on the input

source (video or photograph data).

Video-A Sets suitable image quality, depending on the input source,

video data or photograph data when directly connecting Sony HDMI output-capable equipment that supports “Video-A” mode.

Video Produces suitable image quality for moving pictures.

Photo Produces suitable image quality for still images.

• The setting is fixed to “Video” when “Video-A” mode is not supported on the connected equipment, even if “Video-A” is selected.

• Only available for HDMI 1, HDMI 2, HDMI 3, MONITOR HDMI and Component in format 1080i or 1080p.

Using MENU Functions

• Some options are not available in PC/HDMI PC input mode.

Sound

Sound Mode Selects the sound mode.

Dynamic Enhances the treble and bass sounds. Standard For standard sounds.

Clear Voice Makes voice sound clearer. Reset Resets all the sound settings to the factory settings excluding “Dual Sound.”

Treble Adjusts higher-pitched sounds. Bass Adjusts lower-pitched sounds.

Balance Emphasises left or right speaker balance. Surround S-FORCE Front

Surround

Off Selects for normal stereo or mono reception.

Voice Zoom Adjusts the sound level of human voices. For example, if the voice of a news

announcer is indistinct, you can turn up this setting to make the voice louder.

Conversely, if you are watching a sports programme, you can turn down this

setting to soften the voice of the commentator. Sound Booster Produces a fuller sound for more impact, by emphasising the treble and bass

sounds.

Provides a virtual surround sound experience made possible using just two front speakers.

(Continued)

Auto Volume Keeps a constant volume level even when volume level gaps occur (e.g., adverts

tend to be louder than programmes). Volume Offset Adjusts the volume level of the current input relative to other inputs.

• Some options are not available when “Speaker” is set to “Audio System” or headphones are connected.

Screen

Screen Format See “To change the screen format manually” on page 21.

Auto Format Automatically changes the screen format according to the input signal. To keep

4:3 Default Selects the default screen format for use with 4:3 broadcasts.

Display Area Adjusts the picture display area in 1080i/p and 720p sources when “Screen

Horizontal Shift Adjusts the horizontal position of the picture.

Vertical Shift Adjusts the vertical position of the picture when “Screen Format” is set to “Zoom.” Vertical Size Adjusts the vertical size of the picture when “Screen Format” is set to “Smart” or

your setting, select “Off.”

Smart Displays conventional 4:3 broadcasts with an imitation wide

screen effect.

4:3 Displays conventional 4:3 broadcasts in the correct

proportions.

Off Keeps the current “Screen Format” setting when the channel

or input is changed.

Format” is set to “Wide.”

Full Pixel Displays pictures in their original size if the input source is

1080i/p.

Normal Displays pictures in their recommended size.

-1/-2 Enlarges the picture to hide the edges of the picture.

“Zoom.”

HDMI Set-up

This is used to set the “Control for HDMI” compatible equipment connected to the HDMI sockets. Note that the interlock setting must also be made on the connected “Control for HDMI” compatible equipment side.

Control for HDMI This sets whether to interlock the “Control for HDMI” compatible equipment and

the unit. When set to “On”, the following menu items can be performed. However,

power consumption in standby mode is higher than usual. Auto Devices Off When this is set to “On”, the “Control for HDMI” compatible equipment turns off

when you switch the unit to standby mode using the remote. Auto TV On When this is set to “On” and if the connected HDMI, control compatible

equipment is turned on, the unit automatically turns on, and the displays the HDMI

input from the connected equipment. Device List Update Creates or updates the “HDMI Device List.” Up to 14 “Control for HDMI”

compatible equipment can be connected, and up to 4 equipment can be connected

to a single socket. Be sure to update the “HDMI Device List” when you change the

“Control for HDMI” compatible equipment connections or settings. Select them

manually one by one until getting a correct picture for several seconds. HDMI Device List Displays the connected “Control for HDMI” compatible equipment.

Monitor Set-up

Power Saving Reduces the power consumption by adjusting the backlight brightness. This also

Light Sensor On Automatically optimises the picture settings according to the

enhances the black level. Select from “Off”, “Low”, “High” and “Picture Off”.

ambient light in the room.

Off Turns off the “Light Sensor” feature.

• Be sure not to put anything over the sensor, as its function may be affected. See page 18 for the location of the light sensor.

Product Information Displays your monitor’s product information. Remote Control Set-upRegisters a remote to the unit, otherwise the remote cannot be used with the unit.

Instruction screens appear if you register or delete a remote. Follow the instructions to register or delete.

• The remote can only be registered to only one unit.

Wireless Channel Set-up

Language Selects the language in which the menus are displayed.

Logo Illumination Lights up and turns off the Sony logo on the front of the monitor.

Wireless Channel Selection

Wireless Information

Selects a wireless channel from “Auto”, “36ch”, “40ch”, “44ch” or “48ch”. If the wireless channel is uncertain, select “Auto” to search an available channel.

Displays information about the current wireless channel.

Using MENU Functions

PC Settings

Screen Format Selects a screen format for displaying input from your PC.

Normal Displays the picture in its original size. Full 1 Enlarges the picture to fill the vertical display area, keeping

its original horizontal-to-vertical aspect ratio.

Full 2 Enlarges the picture to fill the display area.

Reset Resets the PC screen settings to the factory settings. Horizontal Shift Adjusts the horizontal position of the picture.

Vertical Shift Adjusts the vertical position of the picture.

Additional Information

Installing the Accessories (Wall-Mount Bracket)

To Customers:

For product protection and safety reasons, Sony strongly recommends that installing of your monitor be performed by Sony dealers or licenced contractors. Do not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation, periodic maintenance and examination of this product.

Your monitor can be installed using the Wall-Mount Bracket SU-WL500/SU-WL700 (sold separately). For SU-WL500, install as illustrated below. For SU-WL700, see the manual supplied with SU-WL700.

• Refer to the Instructions supplied with the Wall-Mount Bracket to properly carry out the installation.

• Refer to “Detaching the Table-Top Stand from the Monitor” (page 11).

• Refer to “Monitor installation dimensions table” (page 45).

• Refer to “Screw and Hook locations diagram/table” (page 45).

Screw (+PSW6 × 16)

Screw

Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the monitor’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licenced contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.

Mounting Hook

Square hole

Monitor installation dimensions table

320

Screen centre point

Model Name

KDL-52EX1 1,312 806 80 486 114 351 76 5 508

KDL-46EX1 1,156 709 107 464 110 321 674 486

KDL-40EX1 1,024 635 144 464 110 296 604 486

Display dimensions

AB C DEFGH

Screen centre

dimension

Figures in the above table may differ slightly depending on the installation.

Length for each mounting angle

Angle (0°) Angle (20°)

Unit: mm

WARNING

The wall that the monitor will be installed on should be capable of supporting a weight of at least four times that of the monitor. Refer to “Specifications” on page 46 for its weight.

Screw and Hook locations diagram/table

Model Name Screw location Hook location

KDL-52EX1/46EX1/40EX1 e, j b

* Hook position “a” and “c” cannot be used for the models in the table above.

Screw location Hook location

a* b c*

Additional Information

Specifications

Media receiver

Model name MBT-W1

System

TV system

Colour/video system

Channel coverage

Input/Output jacks

Aerial

/ AV1

AV2

COMPONENT IN

HDMI IN 1, 2, 3

PC IN

Power and others

Power requirements

Power consumption

Standby power consumption*

Dimensions (Approx.) (w × h × d)

for vertical placement with stand

for horizontal placement

Mass (Approx.) for vert ical

placement with stand

for horizontal placement

Analogue: Depending on your country selection: B/G/H, D/K, L, I Digital: DVB-T/DVB-C

Analogue: PAL, SECAM NTSC 3.58, 4.43 (only Video In) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC HP@L4.0, MP@L3.0

Analogue: VHF: E2–E12/UHF: E21–E69/CATV: S1–S20/HYPER: S21–S41 D/K: R1–R12, R21–R69/L: F2–F10, B–Q, F21–F69/I: UHF B21–B69 Digital: VHF/UHF

75 ohm external terminal for VHF/UHF

21-pin Scart connector (CENELEC standard) including audio/video input, RGB input and unit audio/video output.

Video input (phono jack)

Audio input (phono jacks)

DIGITAL AUDIO OUT (OPTICAL)(digital optical jack)

Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Y: 1 Vp-p, 75 ohms, 0.3V negative sync PB/CB: 0.7 Vp-p, 75 ohms PR/CR: 0.7 Vp-p, 75 ohms

Audio input (phono jacks) 500 mVrms

Video: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24 bits PC Input (see page 48)

PC Input (D-sub 15-pin) G: 0.7 Vp-p, 75 ohms, non Sync on Green B: 0.7 Vp-p, 75 ohms, non Sync on Green R: 0.7 Vp-p, 75 ohms, non Sync on Green HD: 1-5 Vp-p VD: 1-5 Vp-p

PC audio input (minijack)

CAM (Conditional Access Module) slot

Headphones jack

USB port

220–240 V AC, 50 Hz

20 W

3.5 W or less (19 W when Quick Start is ON)

13.1 × 30.2 × 28.6 cm

28.0 × 7.2 × 28.6 cm

2.5 kg

2.4 kg

Monitor

Model name LDM-E521 LDM-E461 LDM-E401

System

Panel system

Sound output

Input/Output jacks

MONITOR HDMI IN

Power and others

Power requirements

Screen size (measured diagonally)

Display resolution

Power consumption

in “Home”/ “Standard” mode

in “Shop”/“Vivid” mode

Standby power consumption*

Dimensions (Approx.) (w × h × d)

with Table-Top Stand

without Table-Top Stand

Mass (Approx.) with Table-Top

Stand

without Table-Top Stand

Supplied accessories

Optional accessories

* Specified standby power is reached after the unit finishes necessary internal processes.

LCD (Liquid Crystal Display) Panel

8 W + 8 W

Video: 1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24 bits PC Input (see page 48)

220–240 V AC, 50 Hz

52 inches (Approx. 132.2 cm) 46 inches (Approx. 116.8 cm) 40 inches (Approx. 101.6 cm)

1,920 dots (horizontal) × 1,080 lines (vertical)

295 W 220 W 180 W

324 W 247 W 221 W

0.5 W or less (19 W when Quick Start is ON)

131.2 × 83.9 × 34.4 cm 115.6 × 74.2 × 25.5 cm 102.4 × 66.8 × 25.5 cm

131.2 × 80.6 × 5.7 cm 115.6 × 70.9 × 5.7 cm 102.4 × 63.5 × 5.7 cm

43.0 kg 26.0 kg 24.0 kg

33.0 kg 19.0 kg 17.0 kg

See “1: Checking the unit and accessories” on page 4.

SU-WL500/SU-WL700 Wall-Mount Bracket

Additional Information

Wireless system

Transmission system

Carrier frequency

Transmission distance

OFDM

5.15 to 5.25 GHz

30 cm to 20 m (depending on installation / usage)

(Continued)

PC Input Signal Reference Chart for PC

Resolution

Signals Horizontal

(Pixel)

VGA 640 × 480 31.5 60 VGA

640 × 480 37.5 75 VESA

720 × 400 31.5 70 VGA-T

SVGA 800 × 600 37.9 60 VESA Guidelines

800 × 600 46.9 75 VESA

XGA 1024 × 768 48.4 60 VESA Guidelines

1024 × 768 56.5 70 VESA

1024 × 768 60.0 75 VESA

WXGA 1280 × 768 47.4 60 VESA

1280 × 768 47.8 60 VESA

1280 × 768 60.3 75

1360 × 768 47.7 60 VESA

SXGA 1280 × 1024 64.0 60 VESA

× Vertical (Line) Horizontal

frequency (kHz)

Vertical frequency (Hz)

Standard

• This unit’s PC input does not support Sync on Green or Composite Sync.

• This unit’s PC input does not support interlaced signals.

• This unit’s PC input supports signals in the above chart with a 60 Hz vertical frequency. For other signals,

you will see the message “No signal.”

PC Input Signal Reference Chart for HDMI IN 1, 2, 3

Resolution

Signals Horizontal

(Pixel)

VGA 640 × 480 31.5 60 VGA

SVGA 800 × 600 37.9 60 VESA Guidelines

XGA 1024 × 768 48.4 60 VESA Guidelines

WXGA 1280 × 768 47.4 60 VESA

WXGA 1280 × 768 47.8 60 VESA

SXGA 1280 × 1024 64.0 60 VESA

× Vertical (Line) Horizontal

frequency (kHz)

Vertical frequency (Hz)

Standard

Troubleshooting

Check whether the 1 (standby) indicator is flashing in red.

When it is flashing

The self-diagnosis function is activated.

1 Count how many 1 (standby) indicator flashes between each two second break.

For example, the indicator flashes three times, then there is a two second break, followed by another three flashes, etc.

2 Press 1 on the unit to turn it off, disconnect the mains lead, and inform your dealer or Sony

service centre of how the indicator flashes (number of flashes).

When it is not flashing

1 Check the items in the tables below.

2 If the problem still persists, have your unit serviced by qualified service personnel.

Condition Explanation/Solution


No picture (screen is dark) and no sound

No picture or no menu information from equipment connected to the scart connector

Double images or ghosting (only in analogue mode)

Only snow and noise appear on the screen (only in analogue mode)

Picture or sound noise when viewing a TV channel (only in analogue mode)

Some tiny black points and/or bright points appear on the screen

No colour on programmes • Select “Reset” (page 39).

No colour or irregular colour when viewing a signal from the / COMPONENT IN sockets

Picture freezes or contains blocks on the screen

Sound

No sound, but good picture • Press 2 +/– or % (Mute).

• Check the aerial/cable connection.

• Connect the unit to the mains, and press 1 on the unit.

• If the 1 (standby) indicator lights up in red, press TV "/1.

• Press / to display the connected equipment list, then select the desired input.

• Check the connection between the optional equipment and the unit.

• Check the aerial/cable connection.

• Check the aerial location and direction.

• Check if the aerial is broken or bent.

• Check if the aerial has reached the end of its serviceable life (three to five years in normal use, one to two years at the seaside).

• Adjust “AFT” (Automatic Fine Tuning) to obtain better picture reception (page 34).

• The picture of a display unit is composed of pixels. Tiny black points and/or bright points (pixels) on the screen do not indicate a malfunction.

• Check the connection of the / COMPONENT IN sockets and check if each sockets are firmly seated in their respective sockets.

• Check signal level (page 37). If signal bar is red (no signal) or amber (low signal), check the aerial/cable connection.

• Remove the connected USB device. It can be damaged or not supported by the unit. Check the website below for updated information about compatible USB devices: http://support.sony-europe.com/TV/compatibility/

• Check if the “Speaker” is set to “TV Speaker” (page 32).

• When using HDMI input with Super Audio CD or DVD-Audio, DIGITAL AUDIO OUT (OPTICAL) may not output audio signals.

Additional Information

(Continued)

Condition Explanation/Solution

Channels

The desired channel cannot be selected

Some channels are blank • Scrambled/Subscription only channel. Subscribe to the pay TV service.

Digital channels are not displayed

• Switch between digital and analogue mode and select the desired digital/ analogue channel.

• Channel is used only for data (no picture or sound).

• Contact the broadcaster for transmission details.

• Contact a local installer to find out if digital transmissions are provided in your area.

• Upgrade to a higher gain aerial.

Wireless communication

Delay pictures • Wireless communication takes time to establish after turning the power

“Wireless communication in progress.” does not disappear, or “Wireless communication failed.” is displayed

Noisy or interrupted picture or sound

on. About 20 seconds are needed to display pictures. Selecting “Quick Start” may shorten the waiting time (page 30).

• When the wireless communication is disturbed, it takes about 15 seconds to display pictures again. “Wireless communication in progress.” is displayed until pictures come back. Check the installation situation of the monitor and media receiver (page 4).

•

• Check whether wireless equipment using the same radio frequency as this unit is working near by, or something disturbing wireless communication of this unit is close to the unit. In such cases, keep such equipment away from the unit or turn off the power of that equipment.

Check the installation situation of the monitor and media receiver (page 4).

•

• Pictures may be distorted if somebody walks across between the monitor and media receiver.

General

Distorted picture and/or sound • Keep the unit away from electrical noise sources such as cars,

The unit turns off automatically (the unit enters standby mode)

The unit turns on automatically

Some input sources cannot be selected

The remote does not function • Replace the batteries.

A channel cannot be added to the Favourite list

HDMI equipment does not appear on “HDMI Device List”

Not all channels are tuned • Check support web site for cable provide information.

You cannot select “Off” in “Control for HDMI”

The “Store Display Mode: On” message appears on the screen

motorcycles, hair-dryers or optical equipment.

• When installing optional equipment, leave some space between the optional equipment and the unit.

• Check the aerial/cable connection.

• Keep the aerial/cable TV cable away from other connecting cables.

• Check if the “Sleep Timer” is activated, or confirm the “Duration” setting of “On Timer Settings” (page 30).

• If no signal is received and no operation is performed in the TV mode for 10 minutes, the monitor automatically switches to standby mode.

• Check if the “On Timer” is activated (page 30).

• Select “AV Preset” and cancel “Skip” of the input source (page 32).

• Up to 999 channels can be stored in the Favourite list.

• Check that your equipment is “Control for HDMI” compatible equipment.

http://support.sony-europe.com/TV/DVBC/

• If any “Control for HDMI” compatible audio equipment is connected to the unit, you cannot select “Off” in this menu. If you want to change the audio output to the monitor speaker, select “TV Speaker” in the “Speaker” menu (page 32).

• Select “All Reset” in the “Media Receiver Set-up” menu (page 33).

Printed in Spain

4-115-568-11(1)

For useful information about Sony products

LCD Digital Colour TV

Operating Instructions

KDL-52EX1

KDL-46EX1

KDL-40EX1

Sony 4-115-568-11-1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Start-up Guide

Safety Information

Precautions

Remote and Unit Controls/Indicators

Watching TV

Watching TV

Using the Digital Electronic Programme Guide (EPG) *

Using the Digital Favourite list *

Using Optional Equipment

Connecting Chart

Viewing Pictures from Connected Equipment

Using USB Photo Viewer

Using BRAVIA Sync with Control for HDMI

Using MENU Functions

Navigating through Media Receiver Home Menu (XMB™)

Settings

Navigating through Monitor Home Menu

Additional Information

Installing the Accessories (Wall-Mount Bracket)

Specifications

Troubleshooting
