SONIQ MB410 User Manual

MD140530-01

Instruction Manual

Printed in China

HOTLINE
AUSTRALIA :1300765 663
NEW ZEALAND:0800 100 236

www.soniq.com

Portable bluetooth speaker

MB410-AU

MB410

Picture 1:

Move switch to ‘ON’ position, the blue indicator light
will flash slowly. The speaker is ready to connect to
the last paired device automatically (when switched
‘on’)

Picture 2:

Turn on the blutooth device that you are pairing the
speaker to. Search for MB410 and select to pair.
Blue light will flash while pairing. Onced paired the
blue light will stop flashing when paired successfully.

Picture 3:

Turn on the mobile phone’s media player to play
music files via speaker.

1. Microphone

2. Charging indicator

3. Power switch

4. Previous track / Vol-

5. AUX input

6. Play/ Pause

7. Next track/ Vol+

8. Handsfree button

9. Micro USB interface

Note:Please deactivate the previously paired device
before you connect to another BT device.

Buttons:

key：Long press to decrease volume. Short
press to select previous track for music.
key：Short press to play music. Short press
again to pause music, and or resume.
key：Long press to increase volume. Short
press to select next track.
key：Short press to answer/hang up. Long press
to reject call. A long press during a call will
disconnect handsfree speaker.

AUX IN Mode:

The unit will automatically turn to AUX in mode to
start playing music when the 3.5MM AUX line is
inserted. At that time, the blue indicator light will
flash slowly. Bluetooth will stop automatically if the
AUX line is connected. The blue LED light will turn
red to indicate AUX function. Bluetooth will
reconnect automatically to the last paired device
when the AUX in line is removed.

USB Charging:

Please insert a micro USB cable into the micro USB
interface of the speaker to charge the built-in battery
when powering off the unit, and the red light will go
off once battery is fully charged. In the “Power on”
mode, charging the battery with a Micro USB cable,
the red charging indicator light will be lightening
unchangedly.

LED Indicators：

Status LED indicator

Power off the unit

Power on the unit to
enter into Bluetooth
mode

Successful Pairing

Bluetooth playing
status

Micro USB charging
status

AUX- in mode

All LED lights are off

Bluetooth blue LED light
flash until connected.

Blue LED light will remain on

Blue LED light will flash
slowly

The red light near the Micro
USB port will be on. The red
light will go off once battery
is fully charged.

The red light on the front
panel will be on in the AUX
in mode.
