1 Introduction

The CWR300ND is an ADSL access device that supports multiple line modes. It

provides one 10/100Base-T Ethernet interface at the user end. The device

provides high-speed ADSL broadband connection to the Internet or Intranet for

high-end users, such as net cafes and office users. The device provides high

performance access to the Internet, downlink up to 24 Mbps and uplink up to 1

Mbps.

The device supports WLAN access. It can connect to the Internet through a WLAN

AP or WLAN device. It complies with IEEE 802.11, 802.11b/g/n specifications, WEP,

WPA, and WPA2 security specifications.

1.1 Packing List

 1 x CWR300ND

 1 x external splitter

 1 x power adapter

 2 x telephone cables (RJ11)

 1 x Ethernet cable (RJ45)

 1 x CD

 1 x WARRANTY CARD

1.2 Safety Precautions

Follow the following instructions to prevent the device from risks and damage

caused by fire or electric power:

 Use volume labels to mark the type of power.

 Use the power adapter packed within the device package.

 Pay attention to the power load of the outlet or prolonged lines. An

overburden power outlet or damaged lines and plugs may cause electric

shock or fire accident. Check the power cords regularly. If you find any

damage, replace it at once.

- 3 -

 Proper space left for heat dissipation is necessary to avoid damage caused

by overheating to the device. The long and thin holes on the device are

designed for heat dissipation to ensure that the device works normally. Do

not cover these heat dissipation holes.

 Do not put this device close to a place where a heat source exists or high

temperature occurs. Avoid the device from direct sunshine.

 Do not put this device close to a place where it is over damp or watery. Do

not spill any fluid on this device.

 Do not connect this device to any PCs or electronic products, unless our

customer engineer or your broadband provider instructs you to do this,

because any wrong connection may cause power or fire risk.

 Do not place this device on an unstable surface or support.

1.3 LEDs and Interfaces

Front Panel

The following table describes the LEDs of the device:

LED Color Status Description

Power

ADSL Green

Green

Red On The device is self-testing or self-testing is

On The device is powered on and the

initialization is normal.

Off The power is off.

failed.

Slow

Blinks

Fast

Blinks

On The device is connected to the physical layer

No signal is detected.

The device is handshaking with the physical

layer of the office.

of the office.

- 4 -

LED Color Status Description

Internet

LAN4-1 Green

WLAN Green

WPS Green

Green

Red On The Internet connection fails after successful

On The Internet connection is normal in the

routing mode (for example: PPP dial-up is

successful), and no Internet data is being

transmitted.

Blinks Internet data is being transmitted in the

routing mode.

Off The device is in bridged mode.

synchronization in the routing mode (for

example: PPP dial-up is failed).

On The LAN connection is normal.

Blinks Data is being transmitted through the LAN

interface, or the Internet data is being

transmitted in bridged mode.

Off The LAN connection is not established.

On The WLAN connection has been activated.

Blinks Data is being transmitted through the WLAN

interface.

Off The WLAN connection is not activated.

Blinks WPS is activated and the device is waiting

for negotiation with the clients.

Off WPS is not activated.

Rear Panel

- 5 -

The following table describes the interfaces of the device:

Interface/Button Description

 Press the button silently less than 1s to enable

WLAN function.

WPS/WLAN

ADSL

LAN4/3/2/1

Power

Power switch, power on or off the device.

Reset

 Press the button for more than 5s to enable WPS

function.

If you press the button between 1s and 5s, no function

takes effect.

RJ-11 interface, for connecting to the ADSL interface or

a splitter through a telephone cable.

RJ-45 interface, for connecting to the Ethernet interface

of a PC or the Ethernet device through an Ethernet

cable.

Power interface for connecting to the power adapter of

12 V DC ,1A.

Reset to the factory defaults. To restore factory defaults,

keep the device powered on and insert a needle into the

hole for 3 to 6 seconds and then release.The device is

reset to the factory default configuration.

1.4 System Requirements

Recommended system requirements are as follows:

 A 10/100 base-T Ethernet card is installed on your PC

 A hub or Switch. (connected to several PCs through one of Ethernet

interfaces on the device)

 Operating system: Windows 98SE, Windows 2000, Windows ME, Windows

XP

 Internet Explorer V5.0 or higher, Netscape V4.0 or higher, or Firefox 1.5 or

higher

- 6 -

1.5 Features

The device supports the following features:

 Various line modes

 External PPPoE dial-up access

 Internal PPPoE/PPPoA dial-up access

 1483Briged/1483Routed/MER/IPoA access

 Multiple PVCs (up to eight) and these PVCs can be isolated from each other

 A single PVC with multiple sessions

 Multiple PVCs with multiple sessions

 802.1Q and 802.1P protocol

 DHCP server

 NAPT

 Static route

 Firmware upgrading through Web, TFTP, or FTP

 Resetting to the factory defaults through Reset button or Web

 DNS

 Virtual server

 DMZ

 Two-level passwords and usernames

 Web interface

 Telnet CLI

 System status display

 PPP session PAP/CHAP

 IP filter

 IP quality of service (QoS)

 Remote access control

 Line connection status test

 Remote managing through Telnet or HTTP

 Backup and restoration of configuration file

 Ethernet interface supporting crossover detection, auto-correction, and

polarity correction

 Universal plug and play (UPnP)

- 7 -

2 Hardware Installation

Step 1 Connect the ADSL interface of the device and the Modem interface of

the splitter through a telephone cable. Connect the phone to the Phone

interface of the splitter through a cable. Connect the incoming line to the

Line interface of the splitter.

The splitter has three interfaces:

 Line: Connect to a wall phone jack (RJ-11 jack).

 Modem: Connect to the ADSL jack of the device.

 Phone: Connect to a telephone set.

Step 2 Connect the LAN interface of the device to the network card of the PC

through an Ethernet cable (MDI/MDIX).

Note:

Use twisted-pair cables to connect with the hub or switch.

Step 3 Plug one end of the power adapter to the wall outlet and connect the

other end to the Power interface of the device.

Connection 1

Figure 1 shows the application diagram for the connection of the router, PC, splitter

and the telephone sets, when no telephone set is placed before the splitter.

- 8 -

Figure 1 Connection diagram (Without connecting telephone sets before the splitter)

Connection 2

Figure 2 shows the connection when the splitter is installed close to the router.

Figure 2 Connection diagram (Connecting a telephone set before the splitter)

- 9 -

Note:

When connection 2 is used, the filter must be installed close to the telephone

cable. See Figure2. Do not use the splitter to replace the filter.

Installing a telephone directly before the splitter may lead to failure of connection

between the device and the central office, or failure of Internet access, or slow

connection speed. If you really need to add a telephone set before the splitter, you

must add a microfilter before a telephone set. Do not connect several telephones

before the splitter or connect several telephones with the microfilter.

- 10 -

3 Web Configuration

This chapter describes how to configure the router by using the Web-based

configuration utility.

3.1 Access the Router

The following is the detailed description of accesing the router for the first time.

Step 1 Open the Internet Explorer (IE) browser and enter http://192.168.1.1

Step 2 In the Login page that is displayed, enter the username and password.

 The username and password of the super user are admin and admin.

 The username and password of the common user are user and user.

If you log in as a super user, the page shown in the following figure appears. You

can check, configure and modify all the settings.

.

- 11 -

When you log in as a common user, you can check the status of the router, but can

not configure the most of the settings.

Note:

In the Web configuration page, you can click Apply Changes to save the

settings temporarily. If you want to save the settings of this page permanently,

click Save of Attention that appears at the bottom of the Web page after the

configuration.

3.2 Wizard

When subscribing to a broadband service, you should be aware of the method by

which you are connected to the Internet. Your physical WAN device can be either

PPP, ADSL, or both. The technical information about the properties of your Internet

connection is provided by your Internet Service Provider (ISP). For example, your

ISP should inform you whether you are connected to the Internet using a static or

dynamic IP address, and the protocol that you use to communicate on the Internet.

The Wizard page guides fast and accurate configuration of the Internet connection

and other important parameters. The following sections describe these various

configuration parameters. Whether you configure these parameters or use the

default ones, click NEXT to enable your Internet connection.

- 12 -

In the navigation bar, choose Wizard. The page shown in the following figure

appears.

You may change the password by entering a new one, or enter the current

password and then click NEXT. The page shown in the following figure appears. In

this page, you can set the system time and Network Time Protocol (NTP) server.

- 13 -

The following table describes the parameters of this page:

Field

You can disable or enable NTP function. You have to

State

Server IP Enter the IP address of the specified time server manually.

Interval

Time Zone Choose the time zone of your country.

GMT time It displays the Greenwich mean time.

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

enable it if you want to configure the parameters in this

page.

Set the interval that the router obtains the time from the

time server and verifies it with the server.

Description

- 14 -

The following table describes the parameters of this page:

Field

Country Select the Country from the drop-down list.

Select the ISP according to the country from the

ISP

Protocol

Connection

Type

VPI/VCI

User name The correct user name that your ISP provides to you.

Password The correct password that your ISP provides to you.

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

drop-down list. If you do not find the ISP that matches

the country, you can select Others.

Select the WAN connection type. You can select from

the drop-down list.

You can select LLC or VC-Mux.

 VPI:Virtual path between two points in an ATM

network. Its valid value range is from 0 to 255.

 VCI: The virtual channel between two points in an

ATM network, ranging from 32 to 65535 (0 to 31 is

reserved for local management of ATM traffic).

Description

- 15 -

The following table describes the parameters of this page:

Field

WLAN

Interface

Band

SSID

Encryption

You can choose Enable or Disable. By default, WAN

interface is enabled.

You need to enable WAN interface, and then you can

set the parameters in this page.

Choose the working mode of the router. You can choose

24 GHz(B), 24 GHz(G), 24 GHz(B+G), 24 GHz(N), 24

GHz(G+N) or 24 GHz(B+G+N).

The service set identification (SSID) is a unique name to

identify the router in the wireless LAN. Wireless stations

associating to the router must have the same SSID.

Enter a descriptive name that is used when the wireless

client connecting to the router.

Configure the wireless encryption mode. You can

choose None, WEP, WPA (TKIP), WPA (AES), WPA2

(AES), WPA2 (TKIP) or WPA2 Mixed.

 Wired equivalent privacy (WEP) encrypts data

Description

- 16 -

Field

frames before transmitting over the wireless

network.

 Wi-Fi protected access (WPA) is a subset of the

IEEE802.11i security specification draft.

 WPA2 Mixed is the collection of WPA and WPA2

encryption modes. The wireless client establishes

the connection between the router through WPA or

WPA2.

Key differences between WPA and WEP are user

authentication and improved data encryption.

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

Description

- 17 -

Note:

If the WAN connection type is set to PPPoA, the parameters of the WAN

connection type are the same as those of PPPoE. For the parameters in these

pages, refer to the parameter description of PPPoE.

1483 Bridged

In the WAN Interface Setup page, set the WAN connection type to 1483 Bridged.

The page shown in the following figure appears.

Click NEXT. The page shown in the following figure appears.

- 18 -

The following table describes the parameters of this page:

Field

WLAN

Interface

Band

SSID

Encryption

You can choose Enable or Disable. By default, WAN

interface is enabled.

You need to enable WAN interface, and then you can

set the parameters in this page.

Choose the working mode of the router. You can choose

24 GHz(B), 24 GHz(G), 24 GHz(B+G), 24 GHz(N), 24

GHz(G+N) or 24 GHz(B+G+N).

The service set identification (SSID) is a unique name to

identify the router in the wireless LAN. Wireless stations

associating to the router must have the same SSID.

Enter a descriptive name that is used when the wireless

client connecting to the router.

Configure the wireless encryption mode. You can

choose None, WEP, WPA (TKIP), WPA (AES), WPA2

(AES), WPA2 (TKIP), or WPA2 Mixed.

 Wired equivalent privacy (WEP) encrypts data

Description

- 19 -

Field

frames before transmitting over the wireless

network.

 Wi-Fi protected access (WPA) is a subset of the

IEEE802.11i security specification draft.

 WPA2 Mixed is the collection of WPA and WPA2

encryption modes. The wireless client establishes

the connection between the router through WPA or

WPA2.

Key differences between WPA and WEP are user

authentication and improved data encryption.

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

Description

1483 MER: DHCP

In the WAN Interface Setup page, set the WAN connection type to be 1483 MER:

DHCP. The page shown in the following figure appears.

- 20 -

The following table describes the parameters of this page:

Field Description

Country Select the Country from the drop-down list.

Select the ISP according to the country from the

ISP

Protocol

drop-down list. If you do not find the ISP that matches

the country, you can select Others

Select the WAN connection type. You can select from

the drop-down list.

- 21 -

Connection

Type

VPI/VCI

Click NEXT, the page shown in the following figure appears.

You can select LLC or VC-Mux.

 VPI: Virtual path between two points in an ATM

network. Its valid value range is from 0 to 255.

 VCI: The virtual channel between two points in an

ATM network, ranging from 32 to 65535 (0 to 31 is

reserved for local management of ATM traffic).

The following table describes the parameters of this page:

- 22 -

Field

You can choose Enable or Disable. By default, WAN

WLAN

Interface

Band

SSID

Encryption

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

interface is enabled.

You need to enable WAN interface, and then you can

set the parameters in this page.

Choose the working mode of the router. You can choose

24 GHz(B), 24 GHz(G), 24 GHz(B+G), 24 GHz(N), 24

GHz(G+N) or 24 GHz(B+G+N).

The service set identification (SSID) is a unique name to

identify the router in the wireless LAN. Wireless stations

associating to the router must have the same SSID.

Enter a descriptive name that is used when the wireless

client connecting to the router.

Configure the wireless encryption mode. You can

choose None, WEP, WPA (TKIP), WPA (AES), WPA2

(AES), WPA2 (TKIP), or WPA2 Mixed.

 Wired equivalent privacy (WEP) encrypts data

frames before transmitting over the wireless

network.

 Wi-Fi protected access (WPA) is a subset of the

IEEE802.11i security specification draft.

 WPA2 Mixed is the collection of WPA and WPA2

encryption modes. The wireless client establishes

the connection between the router through WPA or

WPA2.

Key differences between WPA and WEP are user

authentication and improved data encryption.

Description

- 23 -

1483 Routed/1483 MER: Static IP

- 24 -

The following table describes the parameters of this page:

Field Description

Country Select the Country from the drop-down list.

Select the ISP according to the country from the

ISP

Protocol

drop-down list. If you do not find the ISP that matches

the country, you can select Others

Select the WAN connection type. You can select from

the drop-down list.

- 25 -

Connection

Type

VPI/VCI

WAN IP

Address

Subnet Mask

Default

Gateway

Primary DNS

Server

Click NEXT, the following page appears.

You can select LLC or VC-Mux.

 VPI: Virtual path between two points in an ATM

network. Its valid value range is from 0 to 255.

 VCI: The virtual channel between two points in an

ATM network, ranging from 32 to 65535 (0 to 31 is

reserved for local management of ATM traffic).

Enter the IP address of the WAN interface provided by

your ISP.

Enter the subnet mask concerned to the IP address of

the WAN interface provided by your ISP.

Enter the default gateway of the WAN interface provided

by your ISP.

Enter the primary DNS server of the WAN interface

provided by your ISP.

- 26 -

The following table describes the parameters of this page:

Field

WLAN

Interface

Band

SSID

Encryption

You can choose Enable or Disable. By default, WAN

interface is enabled.

You need to enable WAN interface, and then you can

set the parameters in this page.

Choose the working mode of the router. You can choose

24 GHz(B), 24 GHz(G), 24 GHz(B+G), 24 GHz(N), 24

GHz(G+N) or 24 GHz(B+G+N).

The service set identification (SSID) is a unique name to

identify the router in the wireless LAN. Wireless stations

associating to the router must have the same SSID.

Enter a descriptive name that is used when the wireless

client connecting to the router.

Configure the wireless encryption mode. You can

choose None, WEP, WPA (TKIP), WPA (AES), WPA2

(AES), WPA2 (TKIP), or WPA2 Mixed.

 Wired equivalent privacy (WEP) encrypts data

frames before transmitting over the wireless

Description

- 27 -

Field

network.

 Wi-Fi protected access (WPA) is a subset of the

IEEE802.11i security specification draft.

 WPA2 Mixed is the collection of WPA and WPA2

encryption modes. The wireless client establishes

the connection between the router through WPA or

WPA2.

Key differences between WPA and WEP are user

authentication and improved data encryption.

After finishing the configuration, click NEXT. The page shown in the following figure

appears.

Description

- 28 -

Note:

If the WAN connection type is set to 1483 Routed, the parameters of the WAN

connection type are the same as those of 1483 MER: Static IP. For the

parameters in these pages, refer to the parameter description of 1483 MER:

Static IP.

Click BACK to modify the settings.

Click FINISH to save the settings.

Click RESET to cancel the settings.

3.3 Status

In the navigation bar, choose Status. In the Status page that is displayed contains:

System, LAN, WLAN, WAN, Port Mapping, Statistics and ARP Table.

3.3.1 System

Choose Status > System. The page that is displayed shows the current status and

some basic settings of the router, such as software version, DSP version, uptime,

upstream speed and downstream speed.

- 29 -

3.3.2 LAN

Choose Status > LAN. The page that is displayed shows basic LAN settings of the

router. In this page, you can view the LAN IP address, DHCP server status, MAC

address and DHCP client table. If you want to configure the LAN network, refer to

chapter 3.4.1.1 LAN IP.

3.3.3 WLAN

Choose Status > WLAN. The page that is displayed shows basic settings of

wireless LAN (WLAN).

- 30 -

3.3.4 WAN

Choose Status > WAN. The page that is displayed shows some basic WAN

settings of the router. In this page, you can view basic status of WAN and DNS

server. If you want to configure the WAN network, refer to chapter 3.4.2.1 WAN.

- 31 -

3.3.5 Port Mapping

Choose Status > Port Mapping. In this page, you can view the mapping relation

and the status of port mapping.

3.3.6 Statistics

Choose Status > Statistics. The Statistics page that is displayed contains Traffic

Statistic and ADSL Statistic.

- 32 -

3.3.6.1 Traffic Statistic

Click Traffic Statistic in the left pane. The page shown in the following figure

appears. In this page, you can view the statistics of each network port.

3.3.6.2 ADSL Statistic

Click ADSL Statistic in the left pane. The page shown in the following figure

appears. In this page, you can view the ADSL line status, upstream rate,

downstream rate and other information.

- 33 -

3.3.7 ARP Table

Choose Status > ARP Table. In the ARP Table page, you can view the table that

shows a list of learned MAC addresses.

- 34 -

3.4 Network

In the navigation bar, click Network. The Network page displayed contains LAN,

WAN and WLAN.

3.4.1 LAN

Choose Network > LAN. The LAN page that is displayed contains LAN IP, DHCP

and DHCP Static IP.

3.4.1.1 LAN IP

Click LAN IP in the left pane, the page shown in the following figure appears.

In this page, you can change IP address of the router. The default IP address is

192.168.1.1, which is the private IP address of the router.

The following table describes the parameters of this page:

- 35 -

Field Description

IP Address

Subnet Mask

Secondary IP

LAN Port

Link Speed/Duplex

Mode

MAC Address

Control

Add

Enter the IP address of LAN interface. It is

recommended to use an address from a block that

is reserved for private use. This address block is

192.168.1.1- 192.168.255.254.

Enter the subnet mask of LAN interface. The range

of subnet mask is from

255.255.0.0-255.255.255.254.

Select it to enable the secondary LAN IP address.

The two LAN IP addresses must be in the different

network.

You can choose the LAN interface you want to

configure.

You can select the following modes from the

drop-downlist:100Mbps/FullDuplex,100Mbps/Half

Duplex,10Mbps/FullDuplex,10Mbps/Half

Duplex,Auto Negotiation.

It is the access control based on MAC address.

Select it, and the host whose MAC address is listed

in the Current Allowed MAC Address Table can

access the modem.

Enter MAC address, and then click it to add a new

MAC address.

3.4.1.2 DHCP

Dynamic Host Configuration Protocol (DHCP) allows the individual PC to obain the

TCP/IP configuration from the centralized DHCP server. You can configure this

router as a DHCP server or disable it. The DHCP server can assign IP address, IP

default gateway, and DNS server to DHCP clients. This router can also act as a

surrogate DHCP server (DHCP Relay) where it relays IP address assignment from

an actual real DHCP server to clients. You can enable or disable DHCP server.

Click DHCP in the left pane, the page shown in the following figure appears.

- 36 -

The following table describes the parameters of this page:

Field Description

If set to DHCP Server, the router can assign IP

DHCP Mode

IP Pool Range

Show Client

Default Gateway Enter the default gateway of the IP address pool.

Max Lease Time The lease time determines the period that the host

addresses, IP default gateway and DNS Servers to

the host in Windows95, Windows NT and other

operation systems that support the DHCP client.

It specifies the first and the last IP address in the IP

address pool. The router assigns IP address that is in

the IP pool range to the host.

Click it, the Active DHCP Client Table appears. It

shows IP addresses assigned to clients.

- 37 -

Field Description

retains the assigned IP addresses before the IP

addresses change.

Enter the domain name if you know. If you leave this

blank, the domain name obtained by DHCP from the

Domain Name

DNS Servers

Set VendorClass

IP Range

Click Show Client in the DHCP Mode page, the page shown in the following figure

appears. You can view the IP address assigned to each DHCP client.

ISP is used. You must enter host name (system

name) on each individual PC. The domain name can

be assigned from the router through the DHCP

server.

You can configure the DNS server ip addresses for

DNS Relay.

Click it, the Device IP Range Table page appears.

You can configure the IP address range based on the

device type.

The following table describes the parameters and buttons in this page:

Field

IP Address

MAC Address

Description

It displays the IP address assigned to the DHCP

client from the router.

It displays the MAC address of the DHCP client.

Each Ethernet device has a unique MAC address.

The MAC address is assigned at the factory and it

consists of six pairs of hexadecimal character, for

- 38 -

Field

Expiry (s)

Refresh Click it to refresh this page.

Close Click it to close this page.

Click Set VendorClass IP Range in the DHCP Mode page, the page as shown in

the following figure appears. In this page, you can configure the IP address range

based on the device type.

Description

example, 00-A0-C5-00-02-12.

It displays the lease time. The lease time determines

the period that the host retains the assigned IP

addresses before the IP addresses change.

In the DHCP Mode field, choose None. The page shown in the following figure

appears.

- 39 -

In the DHCP Mode field, choose DHCP Relay. The page shown in the following

figure appears.

- 40 -

The following table describes the parameters and buttons of this page:

Field Description

If set to DHCP Relay, the router acts a surrogate

DHCP Mode

Relay Server Enter the DHCP server address provided by your ISP.

Apply Changes Click it to save the settings of this page.

Reset Click it to refresh this page.

DHCP Server and relays the DHCP requests and

reponses between the remote server and the client.

3.4.1.3 DHCP Static IP

Click DHCP Static IP in the left pane, the page shown in the following figure

appears. You can assign the IP addresses on the LAN to the specific individual

PCs based on their MAC address.

The following table describes the parameters and buttons of this page:

Field Description

IP Address Enter the specified IP address in the IP pool

range, which is assigned to the host.

MAC Address Enter the MAC address of a host on the LAN.

Add After entering the IP address and MAC address,

click it. A row will be added in the DHCP Static IP

- 41 -

Field Description

Tab le.

Delete Selected Select a row in the DHCP Static IP Table, then

click it, this row is deleted.

Reset Click it to refresh this page.

DHCP Static IP Table It shows the assigned IP address based on the

MAC address.

3.4.2 WAN

Choose Network > WAN. The WAN page that is displayed contains WAN, AT M

Setting and ADSL Setting.

3.4.2.1 WAN

Click WAN in the left pane, the page shown in the following figure appears.

In this page, you can configure WAN interface of your router.

- 42 -

The following table describes the parameters of this page:

Field Description

Default Route Selection You can select Auto or Specified.

VPI

VCI

Encapsulation You can choose LLC and VC-Mux.

Channel Mode

Enable NAPT

Enabel IGMP

PPP Settings

User Name

Password

Type

Idle Time (min)

WAN IP Settings

The virtual path between two points in an

ATM network, ranging from 0 to 255.

The virtual channel between two points in an

ATM network, ranging from 32 to 65535 (1 to

31 are reserved for known protocols)

You can choose 1483 Bridged, 1483 MER,

PPPoE, PPPoA, 1483 Routed or IPoA.

Select it to enable Network Address Port

Translation (NAPT) function. If you do not

select it and you want to access the Internet

normally, you must add a route on the uplink

equipment. Otherwise, the access to the

Internet fails. Normally, it is enabled.

You can enable or disable Internet Group

Management Protocol (IGMP) function.

Enter the correct user name for PPP dial-up,

which is provided by your ISP.

Enter the correct password for PPP dial-up,

which is provided by your ISP.

You can choose Continuous, Connect on

Demand, or Manual.

If set the type to Connect on Demand, you

need to enter the idle timeout time. Within the

preset minutes, if the router does not detect

the flow of the user continuously, the router

automatically disconnects the PPPoE

connection.

- 43 -

Field Description

You can choose Fixed IP or DHCP.

 If select Fixed IP, you should enter the

local IP address, remote IP address and

Type

Local IP Address

Netmask

Unnumbered

Add

Modify

Current ATM VC Table

Click

this page, you can configure parameters of this PPPoE PVC.

in the PPPoE mode, the page shown in the following figure appears. In

subnet mask.

 If select DHCP, the router is a DHCP

client, the WAN IP address is assigned

by the remote DHCP server.

Enter the IP address of WAN interface

provided by your ISP.

Enter the subnet mask of the local IP

address.

Select this checkbox to enable IP

unnumbered function.

After configuring the parameters of this page,

click it to add a new PVC into the Current

ATM VC Ta b l e .

Select a PVC in the Current ATM VC Table,

then modify the parameters of this PVC. After

finishing, click it to apply the settings of this

PVC.

This table shows the existed PVCs. It shows

the interface name, channel mode, VPI/VCI,

encapsulation mode, local IP address,

remote IP address and other information. The

maximum item of this table is eight.

- 44 -

The following table describes the parameters and buttons of this page:

Field Description

Protocol It displays the protocol type used for this WAN

connection.

ATM VCC The ATM virtual circuit connection assigned for

this PPP interface (VPI/VCI).

Login Name The user name provided by your ISP.

Password The password provided by your ISP.

Authentication Method You can choose AUTO, CHAP, or PAP .

Connection Type You can choose Continuous, Connect on

Demand, or Manual.

- 45 -

Field Description

Idle Time (s) If choose Connect on Demand, you need to

enter the idle timeout time. Within the preset

minutes, if the router does not detect the flow of

the user continuously, the router automatically

disconnects the PPPoE connection.

Bridge You can select Bridged Ethernet, Bridged

PPPoE, or Disable Bridge.

AC-Name The accessed equipment type.

Service-Name The service name.

802.1q You can select Disable or Enable. After enable

it, you need to enter the VLAN ID. The value

ranges from 1 to 4095.

Apply Changes Click it to save the settings of this page

temporarily.

Return Click it to return to the Channel Configuration

page.

Reset Click it to refresh this page.

Source Mac address The MAC address you want to clone.

MAC Clone Click it to enable the MAC Clone function with

the MAC address that is configured.

3.4.2.2 ATM Setting

Click ATM S e t t i ng in the left pane, the page shown in the following figure appears.

In this page, you can configure the parameters of the ATM, including QoS, PCR,

CDVT, SCR and MBS.

- 46 -

The following table describes the parameters of this page:

Field Description

VPI The virtual path identifier of the ATM PVC.

VCI The virtual channel identifier of the ATM PVC.

QoS The QoS category of the PVC. You can choose

UBR, CBR, rt-VBR, or nrt-VBR.

PCR Peak cell rate (PCR) is the maximum rate at

which cells can be transmitted along a connection

in the ATM network. Its value ranges from 1 to

65535.

CDVT Cell delay variation tolerance (CDVT) is the

amount of delay permitted between ATM cells (in

microseconds). Its value ranges from 0 to

4294967295.

SCR Subtain cell rate (SCR) is the maximum rate that

traffic can pass over a PVC without the risk of cell

loss. Its value ranges from 0 to 65535.

MBS Maximum burst size (MBS) is the maximum

number of cells that can be transmitted at the

PCR. Its value ranges from 0 to 65535.

- 47 -

3.4.2.3 ADSL Setting

Click ADSL Setting in the left pane, the page shown in the following figure appears.

In this page, you can select the DSL modulation. Mostly, you need to remain this

factory default settings. The router supports these modulations: G. L it e , G.D m t ,

T1.413, ADSL2, ADSL2+, AnnexL and AnnexM. The router negotiates the

modulation modes with the DSLAM.

3.4.3 WLAN

3.4.3.1 Basic Setting

Choose WLAN > Basic Setting and the following page appears. In this page, you

can configure the parameters for wireless LAN clients that may connect to the

modem.

- 48 -

The following table describes the parameters of this page:

Field Description

Choose the working mode of the modem. You can

choose from drop-down list.

Band

Choose the network model of the modem, which

Mode

SSID

is varied according to the software. By default, the

network model of the modem is AP.

The service set identification (SSID) is a unique

name to identify the modem in the wireless LAN.

Wireless stations associating to the modem must

have the same SSID. Enter a descriptive name

that is used when the wireless client connecting to

- 49 -

Field Description

Channel Number

Radio Power

Show Active Clients

Apply Changes

the modem.

A channel is the radio frequency used by

802.11b/g/n wireless devices. There are 13

channels (from 1 to 13) available depending on

the geographical area. You may have a choice of

channels (for your region) and you should use a

different channel from an adjacent AP to reduce

the interference. Interference and degrading

performance occurs when radio signal from

different APs overlap.

Choose a channel from the drop-down list box.

You can choose the transmission power of the

radio signal. The default one is 100%. It is

recommended to choose the default value100%.

Click it to view the information of the wireless

clients that are connected to the modem.

Click it to apply the settings temporarily. If you

want to save the settings of this page

permanently, click Save in the lower left corner.

3.4.3.2 Security

Choose Wireless > Security and the following page appears.

- 50 -

The following table describes the parameters of this page:

Field Description

Configure the wireless encryption mode. You can

choose None, WEP, WPA (TKIP), WPA (AES),

WPA2 (AES), WPA2 (TKIP), or WPA2 Mixed.

 Wired equivalent privacy (WEP) encrypts

data frames before transmitting over the wireless

Encryption

network.

 Wi-Fi protected access (WPA) is a subset of

the IEEE802.11i security specification draft.

 WPA2 Mixed is the collection of WPA and

WPA2 encryption modes. The wireless client

establishes the connection between the modem

through WPA or WPA2.

- 51 -

Field Description

Key differences between WPA and WEP are user

authentication and improved data encryption.

It is available when you set the encryption mode

Set WEP Key

WPA Authentication

Mode

Click Set WEP Key, and the following page appears.

to WEP. Click it, the Wireless WEP Key Setup

page appears.

 Select Personal (Pre-Shared Key), enter the

pre-shared key in the Pre-Shared Key field.

 Select Enterprise (RADIUS), enter the port,

IP address, and password of the Radius server.

You need to enter the username and password

provided by the Radius server when the wireless

client connects the modem.

If the encrypton is set to WEP, the modem uses

802.1 X authentication, which is Radius

authentication.

- 52 -

The following describes the parameters of this page:

Field Description

Key Length

Key Format

Default Tx Key

Encryption Key 1

to 4

Apply Changes

Choose the WEP key length. You can Choose

64-bit or 128-bit.

 If you choose 64-bit, you can choose ASCII (5

characters) or Hex (10 characters).

 If you choose 128-bit, you can choose ASCII

(13 characters) or Hex (26 characters).

Choose the index of WEP Key. You can choose Key

1, Key 2, Key 3, or Key 4.

The Encryption keys are used to encrypt the data.

Both the modem and wireless stations must use the

same encryption key for data transmission.

 If you choose 64-bit and ASCII (5 characters),

 If you choose 64-bit and Hex (10 characters),

 If you choose 128-bit and ASCII (13

 If you choose 128-bit and Hex (26 characters),

Click it to apply the settings temporarily. If you want

to save the settings of this page permanently, click

Save in the lower left corner.

3.4.3.3 Access Control

enter any 5 ASCII characters.

enter any 10 hexadecimal characters.

characters), enter any 13 ASCII characters.

enter any 26 hexadecimal characters.

Choose WLAN > Access Control and the following page appears. In this page,

you can configure the access control of the wireless clients.

- 53 -

Choose Allow Listed as the access control mode to enable white list function.

Only the devices whose MAC addresses are listed in the Current Access Control

List can access the modem.

Choose Deny Listed as the access control mode to to enable black list function.

The devices whose MAC addresses are listed in the Current Access Control List

are denied to access the modem.

3.4.3.4 Multi-SSID

Choose WLAN > Multi-SSID and the following page appears. In this page, you can

set virutal access points (VAP)，enable/disable virtual AP, and set its SSID and

authentication type.

- 54 -

- 55 -

The following describes the parameters of this page:

Field Description

Enable

VAP0/1/2/3

SSID

Broadcast SSID

Relay Blocking

Authentication

Type

Tick to enable VAP0 /1/2/3, or untick the check box

to disable it.

Set a wireless SSID of VAP0 /1/2/3.

Choose to enable or disable VAP0 /1/2/3 SSID

broadcast.

Choose to enable or disable access blocking

between two wireless points.

Set the authentication type of VAP0 /1/2/3.

3.4.3.5 Advanced Setting

Choose Wireless > Advanced Setting and the following page appears. In this

page, you can configure the wireless advanced parameters. It is recommended to

use the default parameters.

Note:

The parameters in the Advanced Settings are modified by the professional

personnel, it is recommended to keep the default values.

- 56 -

The following table describes the parameters of this page:

Field Description

Select the modem operating in the open system or

encryption authentication. You can choose Open

Authentication

System, Shared Key or Auto.

 In the open system, the wireless client can

directly connect to the device.

- 57 -

Field Description

Data Rate

PreambleType

Broadcast SSID

Relay Blocking

Ethernet to

Wireless Blocking

Wifi Multicast to

Unicast

Aggregation

Short GI

Apply Changes

 In the encryption authentication, the wireless

client connects to the modem through the shared

key.

Choose the transmission rate of the wireless data.

You can choose Auto, 1 M, 2 M, 5.5 M, 11 M, 6 M,

9 M, 12 M, 18 M, 24 M, 36 M, 48 M, 54M,

MSC0-MSC15.

 Long Preamble: It means this card always

use long preamble.

 Short Preamble: It means this card can

support short preamble capability.

Select whether the modem broadcasts SSID or not.

You can select Enable or Disable.

 Select Enable, the wireless client searches the

modem through broadcasting SSID.

 Select Disable to hide SSID, the wireless

clients can not find the SSID.

Wireless isolation. Select Enable, the wireless

clients that are connected to the modem can not

intercommunication.

Whether the wireless network can communicate

with the Ethernet network or not.

Enable it to using unicast to transmit multicast

packet

It is applied when the destination end of all MPDU

are for one STA.

It is not recommended to enable GI in obvious

environment of Multi-path effect.

Click it to apply the settings temporarily. If you want

to save the settings of this page permanently, click

Save in the lower left corner.

- 58 -

3.4.3.6 WPS

Choose WLAN > WPS and the following page appears.

There are two ways for the wireless client to establish the connection with the

modem through WPS. The modem generates PIN, see the above figure. Click

Regenerate PIN to generate a new PIN, and then click Start PBC, In the wireless

client tool, enter the PIN which is generated by the modem，start connection. The

client will automatically establish the connection with the modem through the

encryption mode, and you need not to enter the key. The other way is the wireless

client generates PIN. In the above figure, enter PIN of the wireless client in the

Client PIN Number field, then click Start PIN to establish the connection.

Note:

The wireless client establishes the connection with the modem through WPS

negotiation.The wireless client must support WPS.

- 59 -

3.5 Service

In the navigation bar, click Service. In the Service page that is displayed contains

DNS, Firewall, UPNP, IGMP Proxy, TR-069 and ACL.

3.5.1 DNS

Domain Name System (DNS) is an Internet service that translates the domain

name into IP address. Because the domain name is alphabetic, it is easier to

remember. The Internet, however, is based on IP addresses. Every time you use a

domain name, DNS translates the name into the corresponding IP address. For

example, the domain name www.example.com might be translated to

198.105.232.4. The DNS has its own network. If one DNS server does not know

how to translate a particular domain name, it asks another one, and so on, until the

correct IP address is returned.

Choose Service > DNS. The DNS page that is displayed contains DNS and DDNS.

3.5.1.1 DNS

Click DNS in the left pane, the page shown in the following figure appears.

The following table describes the parameters and buttons of this page:

Field Description

Obtain DNS

Automatically

Select it, the router accepts the first received DNS

assignment from one of the PPPoA, PPPoE or MER

- 60 -

Field Description

enabled PVC(s) during the connection establishment.

Set DNS

Manually

Apply Changes Click it to save the settings of this page.

Reset Click it to start configuring the paremters in this page.

Select it, enter the IP addresses of the primary and

secondary DNS server.

3.5.1.2 DDNS

Click DDNS in the left pane, the page shown in the following figure appears. This

page is used to configure the dynamic DNS address from DynDNS.org or TZO.

You can add or remove to configure dynamic DNS.

- 61 -

The following table describes the parameters of this page:

Field Description

DDNS provider

Host Name The DDNS identifier.

Interface The WAN interface of the router.

Enable Enable or disable DDNS function.

Username The name provided by DDNS provider.

Password The password provided by DDNS provider.

Email The email provided by DDNS provider.

Key The key provided by DDNS provider.

Choose the DDNS provider name. You can choose

DynDNS.org or TZO.

3.5.2 Firewall

Choose Service > Firewall. The Firewall page that is displayed contains IP/Port

Fileter, MAC Filter, URL Blocking, Virtual Server, IP Address Mapping, DMZ

Setting, NAT EXCLUDE IP, ALG Setting and Anti-DoS.

3.5.2.1 IP/Port Filter

Click IP/Port Filter in the left pane, the page shown in the following figure appears.

Entries in the table are used to restrict certain types of data packets through the

gateway. These filters are helpful in securing or restricting your local network.

- 62 -

3.5.2.2 MAC Filter

Click MAC Filter in the left pane, the page shown in the following figure appears.

Entries in the table are used to restrict certain types of data packets from your local

network to Internet through the gateway. These filters are helpful in securing or

restricting your local network.

- 63 -

3.5.2.3 URL Blocking

Click URL Blocking in the left pane, the page shown in the following figure

appears. This page is used to block a fully qualified domain name, such as

tw.yahoo.comand and filtered keyword. You can add or delete FQDN and filtered

keyword.

- 64 -

The following table describes the parameters and buttons of this page:

Field Description

URL Blocking

Capability

Keyword Enter the keyword to block.

AddKeyword Click it to add a keyword to the URL Blocking Table.

Delete Selected

Keyword

URL Blocking

Table

You can choose Disable or Enable.

 Select Disable to disable URL blocking function

and keyword filtering function.

 Select Enable to block access to the URLs and

keywords specified in the URL Blocking Table.

Select a row in the URL Blocking Table and click it to

delete the row.

A list of the URL (s) to which access is blocked.

3.5.2.4 Virtual Server

Click Virtual Server in the left pane, the page shown in the following figure

appears.

- 65 -

The following table describes the parameters of this page:

Field Description

You can select the common service type, for

example, AUTH, DNS, or FTP. You can also define

a service name.

Service Type

Protocol

WAN Setting You can choose Interface or IP Address.

WAN Interface

WAN Port Choose the access port on the WAN.

 If you select Usual Service Name, the

corresponding parameter has the default settings.

 If you select User-defined Service Name, you

need to enter the corresponding parameters.

Choose the transport layer protocol that the service

type uses. You can choose TCP or UDP.

Choose the WAN interface that will apply virtual

server.

- 66 -

Field Description

LAN Open Port Enter the port number of the specified service type.

Enter the IP address of the virtual server. It is in the

LAN IP Address

same network segment with LAN IP address of the

router.

3.5.2.5 IP Address Mapping

NAT is short for Network Address Translation. The Network Address Translation

Settings window allows you to share one WAN IP address for multiple computers

on your LAN.

Click IP Address Mapping in the left pane, the page shown in the following figure

appears.

Entries in this table allow you to configure one IP pool for specified source IP

address from LAN, so one packet whose source IP is in range of the specified

address will select one IP address from the pool for NAT.

- 67 -

3.5.2.6 DMZ Setting

Demilitarized Zone (DMZ) is used to provide Internet services without sacrificing

unauthorized access to its local private network. Typically, the DMZ host contains

devices accessible to Internet traffic, such as web (HTTP) servers, FTP servers,

SMTP (e-mail) servers and DNS servers.

Click DMZ Setting in the left pane, the page shown in the following figure appears.

The following describes how to configure DMZ.

Step 1 Select Enable DMZ to enable this function.

Step 2 Enter an IP address of the DMZ host.

Step 3 Click Apply Changes to save the settings of this page temporarily.

3.5.2.7 NAT EXCLUDE IP

Click NAT EXCLUDE IP in the left pane, the page shown in the following figure

appears.

In the page, you can configure some source IP addresses which use the purge

route mode when accessing internet through the specified interface.

- 68 -

3.5.2.8 ALG Setting

Click ALG Setting in the left pane, the page shown in the following figure appears.

- 69 -

3.5.2.9 Anti-DoS

Denial-of-Service Attack (DoS attack) is a type of attack on a network that is

designed to bring the network to its knees by flooding it with useless traffic.

Click Anti-DoS in the left pane, the page shown in the following figure appears. In

this page, you can prevent DoS attacks.

- 70 -

- 71 -

3.5.3 UPNP

Choose Service > UPnP, the page shown in the following figure appears. This

page is used to configure UPnP. The system acts as a daemon after you enable it.

3.5.4 IGMP Proxy

Choose Service > IGMP Proxy, the page shown in the following figure appears.

IGMP proxy enables the system to issue IGMP host messages on behalf of hosts

that the system discovered through standard IGMP interfaces. The system acts as

a proxy for its hosts after you enable it.

- 72 -

3.5.5 TR-069

Choose Service > TR-069, the page shown in the following page appears. In this

page, you can configure the TR-069 CPE.

- 73 -

- 74 -

The following table describes the parameters of this page:

Field Description

ACS

URL The URL of the auto-configuration server to

connect to.

User Name The user name for logging in to the ACS.

Password The password for logging in to the ACS.

Periodic Inform Enable Select Enable to periodically connect to the

ACS to check whether the configuration

updates.

Periodic Inform

Interval

Connection Request

User Name The connection usrname provided by TR-069

Password The connection password provided by TR-069

Debug

Show Message Select Enable to display ACS SOAP messages

CPE sends GetRPC Select Enbale, the router contacts the ACS to

Skip MReboot Specify whether to send an MReboot event

Delay Specify whether to start the TR-069 program

Auto-Execution Specify whether to automatically start the

Specify the amount of time between

connections to ACS.

service.

service.

on the serial console.

obtain configuration updates.

code in the inform message.

after a short delay.

TR-069 after the router is powered on.

3.5.6 ACL

Choose Service > ACL, the page shown in the following figure appears. In this

page, you can permit the data packets from LAN or WAN to access the router. You

- 75 -

can configure the IP address for Access Control List (ACL). If ACL is enabled, only

the effective IP address in the ACL can access the router.

Note:

If you select Enable in ACL capability, ensure that your host IP address is in

ACL list before it takes effect.

The following table describes the parameters and buttons of this page:

Field Description

Direction Select

LAN ACL Switch Select it to enable or disable ACL function.

IP Address

Select the router interface. You can select LAN or

WAN. In this example, LAN is selected.

Enter the IP address of the specified interface. Only

the IP address that is in the same network segment

with the IP address of the specified interface can

- 76 -

Field Description

access the router.

You can choose the following services from LAN:

Services Allowed

Add

Reset Click it to refresh this page.

Set direction of the data packets to WAN, the page shown in the following figure

appears.

Web, Telnet, FTP, TFTP, SNMP, or PING. You can

also choose all the services.

After setting the parameters, click it to add an entry

to the Current ACL Table.

- 77 -

The following table describes the parameters and buttons of this page:

Field Description

Direction Select

WAN Setting You can choose Interface or IP Address.

WAN Interface

IP Address

Services Allowed

Add

Reset Click it to refresh this page.

Select the router interface. You can select LAN or

WAN. In this example, WAN is selected.

Choose the interface that permits data packets from

WAN to access the router.

Enter the IP address on the WAN. Only the IP

address that is in the same network segment with

the IP address on the WAN can access the router.

You can choose the following services from WAN:

Web, Telnet, FTP, TFTP, SNMP, or PING. You can

also choose all the services.

After setting the parameters, click it to add an entry

to the Current ACL Table.

3.6 Advance

In the navigation bar, click Advance. In the Advance page that is displayed

contains Bridge Setting, Routing, Port Mapping, QoS, SNMP and Others.

3.6.1 Bridge Setting

Choose Advance > Bridge Setting, the page shown in the following figure

appears. This page is used to configure the bridge parameters. You can change

the settings or view some information on the bridge and its attached ports.

- 78 -

The following table describes the parameters and button of this page:

Field Description

Aging Time If the host is idle for 300 seconds (default value), its

entry is deleted from the bridge table.

802.1d Spanning

Tree

Show MACs Click it to show a list of the learned MAC addresses

Click Show MACs, the page shown in the following figure appears. This table

shows a list of learned MAC addresses for this bridge.

You can select Disable or Enable.

Select Enable to provide path redundancy while

preventing undesirable loops in your network.

for the bridge.

- 79 -

3.6.2 Routing

Choose Advance > Routing, the page shown in the following figure appears. The

page that is displayed contains Static Route and RIP.

3.6.2.1 Static Route

Click Static Route in the left pane, the page shown in the following figure appears.

This page is used to configure the routing information. You can add or delete IP

routes.

The following table describes the parameters and buttons of this page:

Field Description

Enable Select it to use static IP routes.

Destination Enter the IP address of the destination device.

Subnet Mask Enter the subnet mask of the destination device.

Next Hop Enter the IP address of the next hop in the IP route to the

destination device.

Metric The metric cost for the destination.

- 80 -

Field Description

Interface The interface for the specified route.

Add Route Click it to add the new static route to the Static Route

Tab le.

Update Select a row in the Static Route Table and modify the

parameters. Then click it to save the settings temporarily.

Delete

Selected

Show

Routes

Static Route

Table

Click Show Routes, the page shown in the following figure appears. The table

shows a list of destination routes commonly accessed by your network.

Select a row in the Static Route Table and click it to

delete the row.

Click it, the IP Route Table appears. You can view a list

of destination routes commonly accessed by your

network.

A list of the previously configured static IP routes.

3.6.2.2 RIP

Click RIP in the left pane, the page shown in the following figure appears. If you are

using this device as a RIP-enabled router to communicate with others using

Routing Information Protocol (RIP), enable RIP. This page is used to select the

interfaces on your devices that use RIP, and the version of the protocol used.

- 81 -

The following table describes the parameters and buttons of this page:

Field Description

RIP Select Enable, the router communicates with other

RIP-enabled devices.

Apply Changes Click it to save the settings of this page.

Interface Choose the router interface that uses RIP.

Receive Version Choose the interface version that receives RIP

messages. You can choose RIP1, RIP2, or Both.

 Choose RIP1 indicates the router receives RIP

v1 messages.

 Choose RIP2 indicates the router receives RIP

v2 messages.

 Choose Both indicates the router receives RIP

v1 and RIP v2 messages.

Send Version The working mode for sending RIP messages. You

can choose RIP1 or RIP2.

 Choose RIP1 indicates the router broadcasts

- 82 -

Field Description

RIP1 messages only.

 Choose RIP2 indicates the router multicasts

RIP2 messages only.

Add Click it to add the RIP interface to the Rip

Configration List.

Delete Select a row in the Rip Configration List and click

it to delete the row.

3.6.3 Port Mapping

Choose Advance > Port Mapping. The page shown in the following figure

appears. In this page, you can bind the WAN interface and the LAN interface to the

same group.

- 83 -

- 84 -

The procedure for manipulating a mapping group is as follows:

Step 1 Select Enable to enable this function.

Step 2 Select a group from the table.

Step 3 Select interfaces from the WAN and LAN interface list and add them to

the grouped interface list using the arrow buttons to manipulate the

required mapping of the ports.

Click Apply Changes to save the changes.

3.6.4 QoS

Choose Advance > QoS, the page shown in the following figure appears. Entries

in the QoS Rule List are used to assign the precedence for each incoming packet

based on physical LAN port, TCP/UDP port number, source IP address, destination

IP address and other information.

Step 1 Enable IP QoS and click Apply to enable IP QoS function.

Step 2 Click add rule to add a new IP QoS rule.

The page shown in the following figure appears.

- 85 -

- 86 -

The following table describes the parameters and buttons of this page:

Field Description

IP QoS Select to enable or disable IP QoS function. You need

to enable IP QoS if you want to configure the

parameters of this page.

QoS Policy You can choose stream based, 802.1p based, or

DSCP based.

Schedule Mode You can choose strict prior or WFQ (4:3:2:1).

Source IP The IP address of the source data packet.

Source Mask The subnet mask of the source IP address.

Destination IP The IP address of the destination data packet.

Destination

Mask

Source Port The port of the source data packet.

Destination Port The port of the destination data packet.

Protocol The protocol responds to the IP QoS rules. You can

Physical Port The LAN interface responds to the IP QoS rules.

Set priority The priority of the IP QoS rules. P0 is the highest

IP Precedence You can choose from 0 to 7 define the priority in the

IP ToS The type of IP ToS for classifying the data package

802.1p You can choose from 0 to 7.

Delete Select a row in the QoS rule list and click it to delete

Delete all Select all the rows in the QoS rule list and click it to

The subnet mask of the destination IP address.

choose TCP, UDP, or ICMP.

priority and P3 is the lowest.

ToS of the IP data packet.

You can choose Normal Service, Minimize Cost,

Maximize Reliability, Maximize Throughput, or

Minimize Delay.

the row.

delete the rows.

- 87 -

3.6.5 SNMP

Choose Advance > SNMP, the page shown in the following figure appears. You

can configure the SNMP parameters.

The following table describes the parameters of this page:

Field

Enable SNMP

Trap IP Address

Community Name

(Read-only)

Community Name

(Read-Write)

Select it to enable SNMP function. You need to

enable SNMP, and then you can configure the

parameters of this page.

Enter the trap IP address. The trap information is

sent to the corresponding host.

The network administrators must use this password

to read the information of this router.

The network administrators must use this password

to configure the information of the router.

Description

- 88 -

3.6.6 Others

Choose Advance > Others, the page shown in the following figure appears.

3.7 Admin

In the navigation bar, click Admin. The Admin page that is displayed contains

Commit/Reboot, Upgrade, System Log, Password, Time Zone and Logout.

3.7.1 Commit/Reboot

Choose Admin > Commit/Reboot, the page shown in the following figure appears.

You can set the router reset to the default settings or set the router to commit the

current settings.

- 89 -

The following table describes the parameters and button of this page:

Field Description

You can choose Save the current

configuration or Restore to the factory

default configuration.

Reboot from

Reboot Click it to reboot the router.

 Save the current configuration: Save

the current settings, and then reboot the router.

 Restore to the factory default

configuration: Reset to the factory default

settings, and then reboot the the router.

3.7.2 Upgrade

Choose Admin > Upgrade. The Upgrade page that is displayed contains

Upgrade Firmware and Backup/Restore.

Caution:

Do not turn off the router or press the Reset button while the procedure is

in progress.

3.7.2.1 Upgrade Firmware

Click Upgrade Firmware in the left pane, the page shown in the following figure

appears. In this page, you can upgrade the firmware of the router.

- 90 -

The following table describes the parameters and button of this page:

Field Description

Select File Click Browse to select the firmware file.

Upload

Reset Click it to starting selecting the firmware file.

After selecting the firmware file, click Upload to

starting upgrading the firmware file.

3.7.2.2 Backup/Restore

Click Backup/Restore in the left pane, the page shown in the following figure

appears. You can backup the current settings to a file and restore the settings from

the file that was saved previously.

The following table describes the parameters and button of this page:

Field Description

Save Settings to File

Load Settings from File Click Browse to select the configuration file.

Upload

Click it, and select the path. Then you can save

the configuration file of the router.

After selecting the configuration file of the

router, click Upload to start uploading the

configuration file of the router.

3.7.3 System Log

Choose Admin > System Log, the page shown in the following figure appears. In

this page, you can enable or disable system log function and view the system log.

- 91 -

3.7.4 Password

Choose Admin > Password, the page shown in the following figure appears. By

default, the user name and password are admin and admin respectively. The

common user name and password are user and user respectively.

- 92 -

The following table describes the parameters of this page:

Field Description

User Name

Privilege Choose the privilege for the account.

Old Password Enter the old password

New Password

Confirm Password Enter the new password again.

Choose the user name for accessing the

router. You can choose admin or user.

Enter the password to which you want to

change the old password.

- 93 -

3.7.5 Time Zone

Choose Admin > Time Zone, the page shown in the following figure appears. You

can configure the system time manually or get the system time from the time

server.

- 94 -

The following table describes the parameters of this page:

Field Description

System Time Set the system time manually.

NTP Configuration

Select enable or disable NTP function. You need

State

Primary Server Set the primary NTP server manually.

Secondary Server Set the secondary NTP server manually.

Time Zone

to enable NTP if you want to configure the

parameters of NTP.

Choose the time zone in which area you are from

the drop down list.

3.7.6 Logout

Choose Admin > Logout, the page shown in the following figure appears. You can

click the link to log out and you will be redirected to the login page.

3.8 Diagnostic

In the navigation bar, click Diagnostic. The Diagnostic page that is displayed

contains Ping, ATM Loopback, ADSL and Diagnostic Test.

3.8.1 Ping

Choose Diagnostic > Ping. The page shown in the following figure appears.

- 95 -

The following table describes the parameter and button of this page:

Field Description

Host Enter the valid IP address or domain name.

Run Ping Click it to start to Ping.

3.8.2 ATM Loopback

Choose Diagnostic > ATM Loopback. The page shown in the following figure

appears. In this page, you can use VCC loopback function to check the

connectivity of the VCC. The ATM loopback test is useful for troubleshooting

problems with the DSLAM and ATM network.

- 96 -

Click Run Loopback to start testing.

3.8.3 ADSL

Choose Diagnostic > ADSL. The page shown in the following figure appears. It is

used for ADSL tone diagnostics.

Click Start to start ADSL tone diagnostics.

3.8.4 Diagnostic Test

Choose Diagnostic > Diagnostic Test, the page shown in the following figure

appears. In this page, you can test the DSL connection. You can also view the LAN

status connection and ADSL connection.

- 97 -

Click Run Diagnostic Test to start testing.

- 98 -
