Sonicwall 08F Users Manual
wan
X1
lan
X0
lan
NSA 220
wireless-N
NSA 220
wireless-N
NSA 220
wireless-N
232-002003-50_Rev_A_SonicWALL_NSA_220_Series_Quick_Start_Poster_Inside.pdf 1 9/20/2011 7:50:50 PM
SonicWALL NSA Series Appliances
1
Check Package Contents
Verify that your package includes the following
contents:
SonicWALL NSA 220 or NSA 220W Series
Appliance
Ethernet Cable
Standard Power Adaptor and Cord
DB9 -> RJ45 (CLI) Cable
* Wireless Antennas (3) included with NSA 220W only
Power cords are included with units in North
Quick Start Guide
Network Security Appliance
U0/U1
2
10/100/1000
X2
X3 X4 X5 X6
X0W0
X1
security
on/act
wlan
lan wan
10/100/act
1000/act
Register
Registration MUST be completed prior to
connecting to the appliance.
In a Web browser, navigate to
http://192.168.168.168/
http://www.mysonicwall.com
http://www.mysonicwall.com/.
If you do not have a MySonicWALL account,
click the Not a Registered User? link to
create an account.
America only.
Under the Quick Register section of your
*
MySonicWALL account, enter the Activation
Key or Serial Number of the SonicWALL NSA
series appliance you are registering.
Conrm your serial number, enter a friendly
name for your appliance, and enter your
authentication code in the Quick Register >
Add New Product section.
Click Register.
C
M
Y
CM
MY
CY
CMY
K
3
Connect the SonicWALL NSA Appliance
4
Configure the Management Host &
Connect the SonicWALL NSA 220 series
appliance to the network using standard
Ethernet cables as shown in the illustration.
lan wan
Internet router
or modem
Internet
Service
Provider
Connect the included power cable and adaptor,
and plug into an appropriate outlet.
The NSA 220 series appliance powers on and
the orange “test” LED blinks during the boot
sequence. Continue to Step 4 when the “test”
LED is no longer lit.
This process may take up to 2 minutes.
2 min
Network Security Appliance
U0/U1
security
on/act
wlan
X0W0
lan wan
X1
10/100/1000
X2
X3 X4 X5 X6
10/100/act
1000/act
Setup Wizard
With your computer connected to the X0 port
on the SonicWALL appliance, congure your
IP with an address on the 192.168.168.0/24,
such as 192.168.168.20.
Using the computer connected to the LAN
port of the SonicWALL NSA 220 series
appliance, navigate to http://192.168.168.168/
in a Web browser.
The Setup Wizard takes you through several
basic steps to get your SonicWALL NSA series
appliance congured for your network.
After the Setup Wizard, the appliance may
reboot. Please wait a few minutes while the
appliance reboots to save the updated settings.
http://192.168.168.168/
http://192.168.168.168/
U0/U1
120V AC
(U.S.)
Network Security Appliance
security
on/act
wlan
X0W0
lan wan
X1
X2
10/100/1000
X3 X4 X5 X6
10/100/act
1000/act
NSA 220
NSA 220
wireless-N
232-002003-50_Rev_A_SonicWALL_NSA_220_Series_Quick_Start_Poster_Outside.pdf 1 9/20/2011 7:52:24 PM
SonicWALL NSA Series Appliances
5
Get the Latest Firmware
A valid support contract is required to
download the latest firmware.
Navigate to http://www.mysonicwall.com in your
Web browser and login.
Click Downloads. From the Download Center,
select “SonicWALL NSA 220 Firmware” from the
Software Type list.
Click the Add To My Downloads
rmware you wish to install for your SonicWALL
NSA 220 series appliance.
Quick Start Guide
button of the
http://www.mysonicwall.com
http://www.mysonicwall.com
Related Support Technical Documentation
The SonicWALL online library is located at :
http://www.sonicwall.com/us/support/3643.html
For detailed conguration information, refer to the following
technical documents:
SonicWALL UTM Appliance LED Reference Guide
SonicWALL NSA Expansion Modules Installation Guide
SonicOS Administrator’s Guide
SonicOS Route Based VPN Feature Guide
SonicOS WAN Acceleration Feature Guide
SonicOS Global Bandwidth Management Feature Guide
SonicOS Log Events Reference Guide
SonicOS Release Notes
Choose Save File to save the le locally, then click
OK.
Log into the SonicWALL NSA series appliance, and
navigate to the System > Settings page.
Click the Upload New Firmware button.
Click the Choose File button to select the rmware
C
M
Y
CM
MY
CY
CMY
K
Safety Information / Sicherheit Informationen
Regulatory Model/Type Product Name
APL24-08E NSA 220
APL24-08F NSA 220W
Mounting the SonicWALL
- Mount in a location away from direct sunlight and sources of heat. A maximum ambient temperature of 104º
F (40º C) is recommended.
- Route cables away from power lines, fluorescent lighting fixtures, and sources of noise such as radios,
transmitters, and
broadband amplifiers.
- The included power cord is intended for use in North America only. For European Union (EU) customers, a
power cord is not included.
- Ensure that no water or excessive moisture can enter the unit.
- Allow unrestricted airflow around the unit and through the vents on the side of the unit. A minimum of 1 inch
(25.44mm) clearance is recommended.
- Consideration must be given to the connection of the equipment to the supply circuit. The effect of
overloading the circuits has minimal impact on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings must be used when addressing this concern.
Lithium Battery Warning
The Lithium Battery used in the SonicWALL security appliance may not be replaced by the user. Return the
SonicWALL security appliance to a SonicWALL-authorized service center for replacement with the same or
equivalent type recommended by the manufacturer. If, for any reason, the battery or SonicWALL security
appliance must be disposed of, do so following the battery manufacturer's instructions.
Cable Connections
All Ethernet and RS232 (Console) cables are designed for intra-building connection to other equipment. Do not
connect these ports directly to communication wiring or other wiring that exits the building where the
SonicWALL is located.
Power Supply Information
If the power supply is missing from your SonicWALL product package, please contact SonicWALL Technical
Support at 408-752-7819 for a replacement. This product should only be used with a UL listed power supply
marked “I.T.E. LPS” with an output rated 12V DC, minimum 3.0 A, Tma: minimum 40 degree C.
Weitere Hinweise zur Montage
- Wählen Sie für die Montage einen Ort, der keinem direkten Sonnenlicht ausgesetzt ist und sich nicht in der
Nähe von Wärmequellen befindet. Die Umgebungstemperatur darf nicht mehr als 40 °C betragen.
- Achten Sie darauf, das sich die Netzwerkkabel nicht in der unmittelbaren Nähe von Stromleitungen,
Leuchtstoffröhren und Störquellen wie Funksendern oder Breitbandverstärkern befinden.
- Das beigefügte Netzkabel ist nur für den Gebrauch in Nordamerikas und Japan Vorgesehen. Für Kunden in
der Europaïschen Union (EU) ist ein Netzkabel nicht im Lieferumfang enthalten.
- Stellen Sie sicher, dass das Gerät vor Wasser und hoher Luftfeuchtigkeit geschützt ist.
- Stellen Sie sicher, dass die Luft um das Gerät herum zirkulieren kann und die Lüftungsschlitze an der Seite
des Gehäuses frei sind. Hier ist ein Belüftungsabstand von mindestens 26 mm einzuhalten.
- Prüfen Sie den Anschluss des Geräts an die Stromversorgung, damit der Überstromschutz sowie die
elektrische Leitung nicht von einer eventuellen Überlastung der Stromversorgung beeinflusst werden. Prüfen
Sie dabei sorgfältig die Angaben auf dem Aufkleber des Geräts.
Hinweis zur Lithiumbatterie
Die in der Internet Security Appliance von SonicWALL verwendete Lithiumbatterie darf nicht vom Benutzer
ausgetauscht werden. Zum Austauschen der Batterie muss die SonicWALL in ein von SonicWALL autorisiertes Service-Center gebracht werden. Dort wird die Batterie durch denselben oder entsprechenden, vom
Hersteller empfohlenen Batterietyp ersetzt. Beachten Sie bei einer Entsorgung der Batterie oder der
SonicWALL Internet Security Appliance die diesbezüglichen Anweisungen des Herstellers.
Kabelverbindungen
Alle Ethernet- und RS232-C-Kabel eignen sich für die Verbindung von Geräten in Innenräumen. Schließen Sie
an die Anschlüsse der SonicWALL keine Kabel an, die aus dem Gebäude in dem sich das Gerät befindet,
herausgeführt werden.
you just downloaded. Then, click Upload.
Informationen zur Stromversorgung
Wenn das Netzteil nicht im Lieferumfang des SonicWALL Produkts enthalten ist, wenden Sie sich bitte an den
Technischen SonicWALL Support unter +1-408-752-7819 für einen Ersatz. Dieses Produkt sollte nur mit einem
UL-konformen Netzteil mit dem Logo "I.T.E. LPS" und einer Ausgangsleistung von12 VDC, mind. 3,0 A, Tma:
mind. 40 Grad C.
Regulatory and Compliance
For complete regulatory compliance instructions and declaration of conformities, refer to the SonicWALL NSA
Series Safety & Product Regulatory Guide found on the SonicWALL support Web site:
http://www.sonicwall.com/us/support.html
Model APL24-08E only
Complies with EN55022 Class B and CISOR22 Class A.
Canadian Radio Frequency Emissions Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Model APL24-08F only
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Country and channel selection is made in software. Follow user documentation to make country and channel
setting.
Land und Kanalauswahl sind in Software gemacht. Folgen Sie Verbraucherdokumentation, um Land un Kanal zu
machen, setzed.
La sélection de pay et canal est faite dans le logiciel. Suivez la documntation d’utilisateur pour faire le pays es la
canal sélection.
Copyright Notice
© 2011 SonicWALL, Inc.
All rights reserved.
Under the copyright laws, this manual or the software described within cannot be copied, in whole or part, without the written
consent of the manufacturer, except in the normal use of the software to make a backup copy. The same proprietary and copyright
notices must be afxed to any permitted copies as were afxed to the original. This exception does not allow copies to be made
for others, whether or not sold, but all of the material purchased (with all backup copies) can be sold, given, or loaned to another
person. Under the law, copying includes translating into another language or format.
PN 232-002003-50 Rev. A
09/11
Network Security Series
Network Security Appliance
Network Security Appliance
SonicWALL NSA 220/220W Series
Quick Start Guide
U0/U1
security
on/act
wlan
U0/U1
X0W0
lan wan
X0
lan wan
X1
X1
10/100/1000
X2
X3 X4 X5 X6
10/100/1000
X2
X3 X4 X5 X6
10/100/act
1000/act
10/100/act
1000/act
Safety and Regulatory Information for the SonicWALL NSA 220W Wireless Appliance
Regulatory Model/Type Product Name
APL24-08F NSA 220W
Mounting the SonicWALL
Mount in a location away from direct sunlight and sources of heat. A maximum ambient temperature of 104º F (40º C) is recommended.
Route cables away from power lines, fluorescent lighting fixtures, and sources of noise such as radios, transmitters, and broadband
amplifiers
The included power cord is intended for use in North America only. For European Union (EU) customers, a power cord is not included.
Ensure that no water or excessive moisture can enter the unit.
Allow unrestricted airflow around the unit and through the events on the side of the unit. A minimum of 1 inch (25.44mm) clearance is
recommended.
Consideration must be given to the connection of the equipment to the supply circuit and the effect of overloading the circuits has minimal
impact on over current protection and supply wiring. Appropriate consideration of equipment nameplate ratings must be used when
addressing this concern.
Cable Connections
All Ethernet and RS232 (Console) cables are designed for intrabuilding connection to other equipment. Do not connect these ports directly to
communication wiring or other wiring that exits the building where the SonicWALL is located.
Power Supply Information for APL24-08F
If the power supply is missing from your SonicWALL product package, please contact SonicWALL Technical Support at408-752-7819 for a
replacement. This product should only be used with a UL listed power supply marked “Class 2” or “LPS”, with an output rated 12 VDC, minimum
3.0 A, Tma: minimum40 degrees C.
