IS6T
INVISIBLE SERIES COMMERCIAL LOUDSPEAKER
INVISIBLE SERIES
Sonance Invisible Series Commercial
Loudspeakers are the ultimate expression of
architectural audio, delivering uncompromising
aesthetics combined with unequaled sonic
performance.
The IS6T, is a ground-up design, utilizing
completely new technologies that deliver a level
of delity that is unheard of in this category. High
frequencies are achieved with Sonance’s “Motion
Flex Technology”, which consists of a “Wave
Flex Drive Unit” with a bending wave diaphragm,
utilizing a 1.75” (44mm) voicecoil, while the low
frequencies are generated by an “Air Flex” Woofer
with an air pulse diaphragm driven by an 6.5”
(165mm) carbon ber woofer.
The IS6T feature Sonance’s Laminated Core
Technology transformer (SLCT), delivering fulldelity sonic performance in either 70V or 100V
mode.
The IS6T is designed to install ush into a ceiling
or wall and be nished over with up to 1/8” (3mm)
of exible material such as topping compound
venetian plaster, wood veneer or wallpaper, to
provide a completely invisible aesthetic.
Sonance’s proprietary “D.I.S.C. System”, allows
the installer to accurately measure the thickness
of topping material over the diaphragm to ensure
optimum sonic performance is always achieved.
Certication includes UL2043, NFPA90, NFPA70
S7232 and UL1480.
FEATURES AND BENEFITS
PERFORMANCE
• Frequency response of 50Hz – 30KHz @ -3dB
• 170 degrees dispersion up to 10kHz
• Full-delity transformer for uncompromised
tonality
AESTHETICS
• Zero visual impact to space
• Compatible with topping compound, wood
veneer, venetian plaster, wallpaper
INSTALLATION
• Installs under up to 1/8” (3mm) of any exible
material
• D.I.S.C. system to ensure accurate topping
measurement
• Optional zip rings and space savers
APPLICATIONS
• Luxury Retail Boutiques
• Luxury Automotive Showrooms
• Museums and Galleries
• Fine Dining Restaurants
• Hotels
1
TECHNICAL SPECIFICATIONS
LOUDSPEAKER
SKU
Wave Flex Drive Unit
Air Flex Woofer
Frequency Response (+/- 3dB)
Nominal Impedance (Ohms)
Power Handling (RMS)
Sensitivity (2.83V/1m)
Dispersion
Transformer
Transformer Taps
Dimensions (WxHxD)
Mounting Depth
Attachment
Overload Protection
Weight
Certications
40198
20in²(127cm²) bending wave diaphragm | 1.75in (44mm) voice coil
98in²(633cm²) air pulse diaphragm | 6.5in (165mm) carbon ber woofer
50Hz–30kHz
4
100W
84dB
170º hemispherical up to 10kHz
30W with Sonance Laminated Core Technology
30W, 15W, 7.5W, (3.8W @ 70V), 4 Ohms
16.10” x 16.10” x 3.86” (409mm x 409mm x 98mm)
3.39” (86mm)
Screw Terminals with strain relief
Two independent self-resetting poly switches
18.41 lbs. (8.35 kg) per unit
UL 2043, UL 1480
SONANCE LAMINATED CORE TRANSFORMER TECHNOLOGY
The Sonance Laminated Core Transformer is built into the IS8T to deliver distortion-free, wide-bandwidth audio
for uncompromising performance in 70V/100V commercial applications.
OPTIONAL ACCESSORIES
• 93492 Space Saver - Small (IS6T)
• 93491 DG-1 DISC System Depth Gauge
2
IS6T
1 METER ON AXIS FREQUENCY RESPONSE
IMPEDANCE vs FREQUENCY
Frequency / Hz
PERFORMANCE MEASUREMENTS
1 METER ON AXIS FREQUENCY RESPONSE IMPEDANCE VS FREQUENCY
95
90
85
80
75
70
65
60
55
Sound Pressure Level / dB (re 20 µPa/V)
50
45
1 METER HORIZONTAL FREQUENCY RESPONSE 1 METER VERTICAL FREQUENCY RESPONSE
95
90
85
80
75
70
65
60
55
Sound Pressure Level / dB (re 20 µPa/V)
50
45
KLIPPEL
20 50 100 200 500 1 k 2 k 5 k 10 k 20 k
Frequency / Hz
1 METER HORIZONTAL FREQUENCY RESPONSE
KLIPPEL
20 50 100 200 500 1 k 2 k 5 k 10 k 20 k
Frequency / Hz
IS6T On Axis
IS6T +10°
IS6T +20°
IS6T +30°
IS6T +40°
40
35
30
25
[Ohm]
20
15
10
5
95
90
85
80
75
70
65
60
55
Sound Pressure Level / dB (re 20 µPa/V)
50
45
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency [Hz]
1 METER VERTICAL FREQUENCY RESPONSE
20 50 100 200 500 1 k 2 k 5 k 10 k 20 k
Frequency / Hz
KLIPPEL
KLIPPEL
IS6T On Axis
IS6T +10°
IS6T +20°
IS6T +30°
IS6T +40°
DIRECTIVITY INDEX VS FREQUENCY
DIRECTIVITY INDEX vs FREQUENCY
70
60
50
40
30
Directivity Index / dB
20
10
0
20 50 100 200 500 1 k 2 k 5 k 10 k 20 k
KLIPPEL
3
HORIZONTAL POLAR PLOTS
Polar Plot IS6T
Polar Plot IS6T
Polar Plot IS6T
100-200 250-500
Down
Top
* 250Hz
* 100Hz
* 125Hz
r = 1 m
Front
* 200Hz
0°
-30°
* 160Hz
+30°
KLIPPEL
* 315Hz
+30°
Polar Plot IS6T
r = 1 m
* 400Hz
0°
Front
* 500Hz
KLIPPEL
-30°
+60°
+90°
Left Right
+120°
+150°
Rear
+/-180°
-30
-20
-25
-60°
-90°
-5
-10
-15
-120°
-150°
630-1250 1600-3150
* 630Hz
r = 1 m
Front
* 1250Hz
0°
-30
-20
-25
* 800Hz
+60°
+90°
Left Right
+120°
* 1000Hz
+30°
-30°
-60°
-5
-10
-15
-120°
KLIPPEL
-90°
* 1600Hz
+60°
+90°
Left Right
+120°
+150°
Rear
+/-180°
-30
-20
-25
r = 1 m
* 2000Hz
+60°
+90°
Left Right
+120°
* 2500Hz
+30°
Front
0°
-30
-20
-25
-15
-150°
* 3150Hz
-30°
-15
-60°
-90°
-5
-10
-120°
KLIPPEL
-60°
-90°
-5
-10
-120°
+150°
Rear
+/-180°
-150°
4000-8000 10000-20000
Polar Plot IS6T
r = 1 m
* 4kHz * 5kHz * 6.2kHz * 8kHz
+30°
+60°
+90°
Left Right
+120°
+150°
0°
Front
-30
-25 -20 -15 -10 -5
Rear
+/-180°
-30°
-60°
-120°
-150°
KLIPPEL
-90°
* 10kHz
+60°
+90°
Left Right
+120°
4
* 12.5kHz
+150°
+30°
+150°
Rear
+/-180°
Polar Plot IS6T
r = 1 m
* 16kHz
0°
Front
-30
-25
Rear
+/-180°
-20
* 20kHz
-150°
KLIPPEL
-30°
-60°
-90°
-5
-10
-15
-120°
-150°
VERTICAL POLAR PLOTS
Left
Right
Polar Plot IS6T
Polar Plot IS6T
100-200 250-500
Polar Plot IS6T
* 100Hz
* 125Hz
r = 1 m
Front
* 200Hz
0°
-30°
* 160Hz
+30°
KLIPPEL
* 250Hz
* 315Hz
IS6T
r = 1 m
Front
* 500Hz
0°
-30°
* 400Hz
+30°
KLIPPEL
+60°
+90°
Top Down-30
+120°
+150°
Rear
+/-180°
-20
-25
-60°
-90°
-5
-10
-15
-120°
-150°
+90°
630-1250 1600-3150
* 630Hz
r = 1 m
Front
* 1.25kHz
0°
-30
-20
-25
* 800Hz
+60°
+90°
Top Down
+120°
* 1kHz
+30°
-30°
-60°
-5
-10
-15
-120°
KLIPPEL
-90°
* 1.6kHz
+60°
Top Down-30
+120°
+150°
Rear
+/-180°
-15
-20
-25
r = 1 m
Front
* 3.15kHz
0°
-30
-20
-25
* 2kHz
+60°
+90°
Top Down
+120°
* 2.5kHz
+30°
-60°
-90°
-5
-10
-120°
-150°
KLIPPEL
-30°
-60°
-90°
-5
-10
-15
-120°
+150°
Rear
+/-180°
-150°
4000-8000 10000-20000
LeftRight
* 4kHz
* 5kHz * 6.3kHz
+30°
+60°
+90°
Top Down-30
+120°
+150°
Polar Plot IS6T
r = 1 m
0°
Front
-25
Rear
+/-180°
* 8kHz
-20 -15
KLIPPEL
-30°
-60°
-90°
-5
-10
-120°
-150°
LeftRight
* 10kHz * 12.5kHz
5
+150°
+30°
+60°
+90°
Top Down-30
+120°
+150°
Rear
+/-180°
Polar Plot IS6T
r = 1 m
* 16kHz
0°
Front
Rear
+/-180°
-150°
* 20kHz
-30°
-60°
-5
-10
-20 -15
-25
-120°
-150°
KLIPPEL
-90°
DIMENSIONAL SKETCHES SPECIFICATIONS
IS6T Loudspeaker
Width: 16.10” (409mm)
Height: 16.10” (409mm)
Depth: 3.86” (98mm)
Width
Depth
Height
6
ASSOCIATED PRODUCTS
ARCHITECTURAL SPECIFICATIONS
INVISIBLE SERIES SPEAKERS
IS8T Speaker 40197
PROFESSIONAL SERIES
IN-CEILING SPEAKERS
PS-C41RT In-Ceiling Speaker 45165
PS-C61RT In-Ceiling Speaker 45166
PS-C43RT In-Ceiling Speaker 45130
PS-C63RT In-Ceiling Speaker 45131
PS-C83RT In-Ceiling Speaker 45132
PS-C83RWT In-Ceiling Speaker 40133
PS-C43RTLP In-Ceiling Speaker 45181
PS-C63RTLP In-Ceiling Speaker 45182
PROFESSIONAL SERIES
PENDANT SPEAKERS
PS-P43T Pendant Speaker White 45134
PS-P63T Pendant Speaker White 45135
PS-P83T Pendant Speaker White 45136
PS-P83WT Pendant Speaker White 40137
PS-P43T Pendant Speaker Black 45138
PS-P63T Pendant Speaker Black 45139
PS-P83T Pendant Speaker Black 45140
PS-P83WT Pendant Speaker Black 40141
PROFESSIONAL SERIES
SURFACE MOUNT SPEAKERS
PS-S43T Surface Mount Speaker White 45142
PS-S53T Surface Mount Speaker White 45143
PS-S63T Surface Mount Speaker White 45144
PS-S83T Surface Mount Speaker White 45145
PS-S83WT Surface Mount Speaker White 40146
PS-S43T Surface Mount Speaker Black 45147
PS-S53T Surface Mount Speaker Black 45148
PS-S63T Surface Mount Speaker Black 45149
PS-S83T Surface Mount Speaker Black 45150
PS-S83WT Surface Mount Speaker Black 40151
The loudspeaker shall be of the two-way type comprising a
single cabinet that is designed to install ush into a ceiling
or wall and be nished over with up to 1/8” (3mm) of exible
material to provide a completely invisible installation. It shall
feature Motion Flex Technology, consisting of a Wave Flex
Drive Unit with a 20in (127cm) bending wave diaphragm
utilizing a 1.75” (44mm) voicecoil, combined with an Air Flex
Woofer with a 98in (633cm) air pulse diaphragm utilizing
a 6” (165mm) carbon ber woofer. Frequency range shall
be 50Hz – 30KHz (-3dB). Total power handling shall be
100 Watts RMS program. Sensitivity measured with 2.83
volts input at 1 meter on axis averaged between 50Hz –
30KHz shall be 84dB. The unit shall be supplied with a line
matching laminated core transformer suitable for 100 volt or
70 volt with rear-mounted control allowing user selectable
power taps of 30W, 15W, 7.5W and 3.8W (70V) and a 6 Ohm
bypass. Protection shall be provided by two independent,
self-resetting poly switches. It shall provide 170 degrees of
dispersion up to 10kHz. The back can shall be constructed
from metal. The speaker shall be suitable for use in air
handling spaces per UL2043, NFPA90 and NFPA70 S7232
as well as UL1480, UL Rated signaling speaker. Wire shall
be terminated in an enclosed area on the rear of the back
can via a knock-out with internal strain relief. It shall feature
the proprietary Sonance D.I.S.C. System, allowing the
installer to accurately measure the thickness of topping
material over the diaphragm to ensure optimum sonic
performance. External dimensions shall be 16.10” Wide x
16.10” High x 3.86” Depth (409mm x 409mm x 98mm). The
total enclosure shall weigh 18.41 lbs. (8.35 kg) per unit. The
loudspeaker shall be the Sonance Invisible Series IS6T. No
other system shall be acceptable unless the above combined
performance specications are equaled or exceeded.
DSP AMPLIFIER
Sonamp DSP 2-750 Amplier 93095
7
SAFETY AGENCY COMPLIANCE
Sonance Invisible Series IS6T is compliant with:
UL 2043
Standard For Safety For Speakers for Fire Alarm,
Emergency, and Commercial and Professional Use.
Suitable for use in air-handling spaces.
UL 1480
Standard For Safety For Speakers for Fire Alarm,
Emergency, and Commercial and Professional Use.
TECHNICAL ASSISTANCE
AND SERVICE
The Technical Assistance Department at Sonance is
available at (949) 492-7777 to answer any questions
concerning the operation and installation of your
speakers between the hours of 7:00 AM and 5:00 PM
Pacic time, Monday through Friday, except holidays.
In the event your unit should need repair or service, you
may return the unit to your authorized dealer or use the
following guidelines:
NFPA 70
2002 National Electrical Code
NFPA 90A
Installation of Air Conditioning and Ventilation
Systems, Section 2-3.10.1(A)
PLEASE KEEP ORIGINAL PACKAGING WHEN POSSIBLE.
1. Be prepared to state the model number and / or
serial number, date of purchase, and dealer’s name
and address when calling.
2. Contact Sonance directly at (949) 492-7777
or at www.sonance.com. YOU MUST HAVE PRIOR
AUTHORIZATION TO RETURN YOUR UNIT.
3. If you are returning the product directly to Sonance,
call us to obtain a return authorization number
before shipping.
4. Ship the product via United Parcel Service, Federal
Express, or other package delivery service. Please do
not use the U.S. Postal Service.
5. Include the return authorization number on the
shipping label.
6. Ship to:
Attn: Quality Assurance Department,
RMA#(include RMA number here)
Sonance
11016 Mulberry Ave.
Suite B
Fontana, CA 92337
8
WARRANTY, REMEDY, EXCLUSIONS
AND LIMITATIONS (USA ONLY)
LIMITED FIFTEEN (15) YEAR WARRANTY
Sonance warrants to the rst end-user purchaser that this Sonance-brand product (“Product”), when purchased
from an authorized Sonance Dealer/Distributor, will be free from defective workmanship and materials for the
period stated below. Sonance will at its option and expense during the warranty period, either repair the defect or
replace the Product with a new or re-manufactured Product or a reasonable equivalent.
EXCLUSIONS
TO THE EXTENT PERMITTED BY LAW, THE WARRANTY SET FORTH ABOVE IS IN LIEU OF, AND EXCLUSIVE OF,
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED
BY SONANCE. ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY, IMPLIED WARRANTY OF FITNESS FOR USE, AND IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED.
No one is authorized to make or modify any warranties on behalf of Sonance. The warranty stated above is the
sole and exclusive remedy, and Sonance’s performance shall constitute full and nal satisfaction of all obligations,
liabilities, and claims with respect to the Product.
IN ANY EVENT, SONANCE SHALL NOT BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL, ECONOMIC, PROPERTY,
BODILY INJURY, OR PERSONAL INJURY DAMAGES ARISING FROM THE PRODUCT, ANY BREACH OF THIS WARRANTY, OR OTHERWISE.
This warranty statement gives you specic legal rights, and you may have other rights which vary from state to
state. Some states do not allow the exclusion of implied warranties or limitations of remedies, so the above exclusions and limitations may not apply. If your state does not allow disclaimer of implied warranties, the duration of
such implied warranties is limited to period of Sonance’s express warranty. Your Product Model and Description:
IS6T Invisible Speakers. Warranty Period for this Product: Fifteen (15) years from the date on the original sales
receipt or invoice or other satisfactory proof of purchase. Additional Limitations and Exclusions from Warranty
Coverage: The warranty described above is nontransferable, applies only to the initial installation of the Product,
does not include installation of any repaired or replaced Product, does not include damage to allied or associated
equipment which may result for any reason from use with this Product, and does not include labor or parts caused
by accident, disaster, negligence, improper installation, misuse (e.g. overdriving the amplier or speaker, excessive
heat, cold or humidity, mishandling, etc.), or from service or repair which has not been authorized by Sonance. Obtaining Authorized Service: To qualify for the warranty, you must contact your authorized Sonance Dealer/Installer
or call Sonance Customer Service at (949) 492-7777 within the warranty period, must obtain a return merchandise
number (RMA), and must deliver the Product to Sonance shipping prepaid during the warranty period, together
with the original sales receipt, or invoice or other satisfactory proof of purchase.
©2021 Sonance. All rights reserved. Sonance is a registered trademarks of Dana Innovations. Due to continuous product
improvement, all features and specications are subject to change without notice. For the latest Sonance product
specication information visit our website at www.sonance.com.
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA
PHONE: (949) 492-7777 • FAX: (949) 361-5151 • Technical Support: (949) 492-7777 • www.sonance.com
02.12.2021
9
Loading...
